LF Harbor Breeze Gaskin User manual

GASKIN CEILING FAN
ITEM #2599783
MODEL #GAT24BNK6L
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-800-643-0067, 8 a.m. - 8 p.m., EST, Monday - Sunday.
Purchase Date
1
Español p. 19
ATTACH YOUR RECEIPT HERE
ADJUNTE SU RECIBO AQUÍ
Harbor Breeze® is a registered trademark
of LF, LLC. All Rights Reserved.
VR20320
4007498

TABLE OF CONTENTS
2
Modifications not approved by the party responsible for compliance could void the user's authority to
operate the equipment.
*NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
* Reorient or relocate the receiving antenna.
* Increase the separation between the equipment and receiver.
* Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Distributed by: Litex Industries Inc., P.O. Box 535639, Grand Prairie, TX, 75053; 1-800-527-1292
The device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, (2) this device must accept any
interference received, including interference that may cause undesired operation.
NOTE: Dimmable to 10% with select dimmers. See Lowes.com for more information.
SAFETY INFORMATION
Safety Information .................................................................................................................2
Package Contents .................................................................................................................5
Hardware Contents ...............................................................................................................6
Preparation ..........................................................................................................................
.. 6
Initial Installation ....................................................................................................................6
Wiring ...................................................................................................................................10
Final Installation ...................................................................................................................12
Operating Instructions .......................................................................................................15
Care and Maintenance ........................................................................................................17
Troubleshooting..................................................................................................................
.. 17
Limited Lifetime Warranty ..................................................................................................
.. 18
Replacement Parts List .......................................................................................................18

READ AND SAVE THESE INSTRUCTIONS
Please read and understand this entire manual before attempting to assemble, install or operate the
product.
• Do not discard fan carton or foam inserts. Should this fan need to be returned to the factory for
repairs, it must be shipped in its original packaging to ensure proper protection against damage that
might exceed the initial cause for return.
• Make sure all electrical connections comply with local codes, ordinances, the National Electrical
Code and ANSI/NFPA 70-1999. Hire a qualified electrician or consult a do-it-yourself wiring
handbook if you are unfamiliar with installing electrical wiring.
• Make sure the installation site you choose allows a minimum clearance of 7 ft. from the blades to
the floor and at least 30 in. from the end of the blades to any obstruction.
• After you install the fan, make sure all connections are secure to prevent the fan from falling.
• The net weight of this fan including the light kit is: 11.68 lbs.
SAFETY INFORMATION
3
To reduce the risk of fire, electrical shock or personal injury, mount fan to outlet box
marked "ACCEPTABLE FOR FAN SUPPORT OF 35 LBS. OR LESS" and use
mounting screws provided with the outlet box. Most outlet boxes commonly used for the
support of lighting fixtures are not acceptable for fan support and may need to be replaced.
Consult a qualified electrician if in doubt.
When mounting fan to a ceiling outlet box, use a METAL octagonal outlet box; do NOT use a
plastic outlet box. Secure the outlet box directly to the building structure. The outlet box and its
support must be able to support the moving weight of the fan (at least 35 lbs.).
To avoid personal injury, the use of gloves may be necessary while handling fan parts with sharp
edges.
To reduce the risk of fire, electrical shock or personal injury, wire connectors provided with this fan
are designed to accept only one 12-gauge house wire and two lead wires from the fan. If your
house wire is larger than 12-gauge or there is more than one house wire to connect to the
corresponding fan lead wires, consult an electrician for the proper size wire connectors to use.
WARNING
DANGER
When using an existing outlet box, make sure the outlet box is securely attached to the building
structure and can support the full weight of the fan. Failure to do this can result in serious injury or
death. The stability of the outlet box is essential in minimizing wobble and noise in the fan after
installation is complete.
To reduce the risk of serious bodily injury, DO NOT use power tools to assemble any part of the fan,
including the blades.

4
SAFETY INFORMATION
CAUTION
Read all instructions and safety information before installing your new fan. Review the
accompanying assembly diagrams.
Be sure outlet box is properly grounded and that a ground wire (green or bare) is present.
Once installation is complete, carefully check all screws, bolts and nuts on fan motor assembly
to ensure that they are secured.
Do NOT tamper with or attempt to repair LED component. The light source is designed for this
specific application and should not be serviced by untrained personnel. If any servicing is
required, call our customer service department.
WARNING
To reduce the risk of fire or electrical shock, do not use the fan with any solid state speed control
device or control fan speed with a full range dimmer switch.
To reduce the risk of fire, electrical shock or personal injury, do not bend the blades when
installing or balancing them or cleaning the fan. Do not insert objects between the rotating fan
blades.
To reduce the risk of personal injury, use only parts provided with this fan. The use of parts
OTHER than those provided with this fan will void the warranty.
Before proceeding, be sure to shut off electricity at main switch or circuit breaker in order to avoid
electrical shock.
WARNING

A
D
B
F
M
L
I
IMPORTANT REMINDER: You must use the
parts provided with this fan for proper installation
and safety.
A Downrod 1
B Canopy 1
C Mounting Bracket 1
D Motor Housing 1
E Yoke Cover 1
F LED Light Kit 1
G Blade 6
H Switch Housing 1
I Shade 1
J Canopy Cover 1
DESCRIPTIONPART QUANTITY
PACKAGE CONTENTS
5
E
O
DESCRIPTIONPART QUANTITY
K Canopy Mounting Screw 2
(preassembled)
L Pin (preassembled) 1
M Clip (preassembled) 1
N Blade Arm 6
O Switch Housing Screw 3
(preassembled)
P Motor Plate Screw 3
(preassembled)
Q Motor Screw/Lock Washer 12
(preassembled) + 1 extra
H
G
C
K
J
N
Q
P

6
PREPARATION
HARDWARE CONTENTS (shown actual size)
Before beginning assembly of product, make sure all parts are present. Place motor on carpet or on
foam to avoid damage to finish. Compare parts with package contents list and hardware contents list. If
any part is missing or damaged, do not attempt to install, operate or assemble the product.
Estimated Assembly Time: 120 minutes
Tools Required for Assembly (not included): Electrical Tape, Phillips Screwdriver, Pliers, Safety Glasses,
Stepladder and Wire Strippers
Helpful Tools (not included): AC Tester Light, Tape Measure, Do-It-Yourself Wiring Handbook and Wire
Cutters
Wire
Connector
Qty. 3
AA BB
Blade
Screw
Qty. 18
+ 1 extra
CC
INITIAL INSTALLATION
Turn off circuit breakers or fuse and wall switch to
the fan supply line leads.
DANGER: Failure to disconnect power supply
prior to installation may result in serious injury or
death.
1.
ON
OFF
ON
OFF
1
Fiber
Blade
Washer
Qty. 18
+ 1 extra
Pull Chain
Extension
Qty. 2
DD

2. Determine mounting method to use.
A. Standard mount
B. Angle mount
IMPORTANT: If using the angle mount, ensure the
ceiling angle is not steeper than 19°.
NOTE: Closemount option is not available for this
fan.
*Helpful Hint: Downrod-style mounting is best
suited for ceilings 8 ft. high or higher. For taller
ceilings you may want to use a longer downrod
(not included). Angle-style mounting is best suited
for angled or vaulted ceilings. A longer downrod is
sometimes necessary to ensure proper blade
clearance.
7
Check to make sure blades (G) will be at least
30 inches from any obstruction. Check downrod
(A) length to ensure blades (G) will be at least 7 ft.
above the floor.
3.
INITIAL INSTALLATION
7 ft.
min.
30 in.
min.
3
G
2
4.
Open End
4
C
C
ANGLE MOUNTSTANDARD MOUNT
Secure mounting bracket (C) to outlet box (not
included) using screws, spring washers and flat
washers provided with the outlet box.
*NOTE: It is very important you use the proper
hardware when installing the mounting bracket (C)
as this will support the fan.
IMPORTANT: If using the angle mount, make sure
open end of mounting bracket (C) is installed facing
the higher point of the ceiling, and ensure the
ceiling angle is not steeper than 19°.
B
A
19° max.

8
INITIAL INSTALLATION
5. Remove preassembled motor screws/lock washers
(Q) from underside of motor housing (D). If there
are plastic motor blocks installed with the motor
screws/lock washers (Q), discard the plastic motor
blocks.
Note: Make sure to keep loose hardware separate
to avoid confusion during installation.
5
J
D
Plastic
Motor
Block
K
7. Insert downrod (A) through canopy (B), canopy
cover (J) and yoke cover (E). NOTE: Canopy
cover (J) must be turned with the shiny side
toward the motor housing (D).
Then, thread wires from motor housing (D)
through downrod (A).
Remove pin (L) and clip (M) from downrod (A).
Partially loosen preassembled set screws and nut
in motor housing yoke at top of motor housing (D).
6a. 6a
M
L
6b
A
Set Screw
Sideview
D
Yoke
6b.
B
E
A
J
7

9
INITIAL INSTALLATION
Depending on the length of downrod you use, you
may need to cut the lead wires back to simplify
the wiring. If you decide to cut back the lead
wires, it is suggested you do so in the following
manner:
Take the lead wires and make sure you have
pulled them all the way through the top of the
downrod. Start at the TOP of the hanging ball on
the downrod and measure 8 in. of lead wire, then
cut the excess wire off with wire cutters (not
included).
NOTE: If you do not cut back the lead wires,
Steps 9 and 10 are not necessary and you may
proceed to Step 11 instead.
9.
Hanging
Ball
9
8 in.
If you decided to cut back the lead wires in Step 8,
strip 1/2 in. of insulation from end of each wire --
white, black, green and blue (if applicable). Twist
stripped ends of each strand of wire within the
insulation with pliers (not included).
10. 10
8. Slip downrod (A) into motor housing yoke, align
holes and re-install pin (L) and clip (M). Tighten
set screws in motor housing yoke and then tighten
preassembled nut on one of the set screws. Then,
slide yoke cover (E) down until it rests on top of
motor housing (D).
8
D
E
L
M
Yoke
M
L
Set Screw
and Nut
Sideview
A

10
WIRING
WARNING: To reduce the risk of fire, electrical shock or personal injury, wire connectors provided
with this fan are designed to accept only one 12-gauge house wire and two lead wires from the fan. If
your house wire is larger than 12-gauge or there is more than one house wire to connect to the
corresponding fan lead wires, consult an electrician for the proper size wire connectors to use.
CAUTION: Be sure outlet box is properly grounded and that a ground (green or bare) wire is
present.
WARNING: If house wires are different colors than referred to in the following steps, stop
immediately. A professional electrician is recommended to determine wiring.
WARNING: Using a full range dimmer switch (not included) to control fan speed will cause a loud
humming noise from fan. To reduce the risk of fire or electrical shock, do NOT use a full range dimmer
switch to control fan speed.
NOTE: This fan is remote control adaptable (remote control not included). Please refer to instructions
provided with the remote control before proceeding with these wiring instructions.
Choose wiring diagram (Fig. 1a, Fig. 1b or Fig. 1c)
that fits your situation and make appropriate wiring
connections as follows: [IMPORTANT: Use one of
the wire connectors (AA) provided to make each wire
connection, making sure to screw wire connector
(AA) on in a clockwise direction.]
1a. FAN AND LIGHT CONTROLLED BY PULL
CHAINS: Connect BLACK and BLUE wire from fan
to BLACK wire from ceiling. Connect WHITE wire
from fan to WHITE wire from ceiling. Connect
GROUND (GREEN) wires from downrod (A) and
mounting bracket (C) to BARE/GREEN wire from
ceiling.
1.
1a
FAN AND LIGHT CONTROLLED BY PULL CHAINS
120V POWER
FROM CEILING
GREEN
WHITE BLACK
BLUE
BLACK(POWER)
WHITE(NEUTRAL)
GROUND/GREEN (BARE)
AA
AA AA
INITIAL INSTALLATION
11. Install hanging ball of downrod (A) into opening of
mounting bracket (C). Align one of the slots in
hanging ball with tab in mounting bracket (C).
DANGER: Failure to align one of the slots in
the ball with the tab may result in serious injury or
death.
ATab
11
C
Slot

11
WIRING
Wrap electrical tape (not included) around each
individual wire connector (AA) down to the wire.
WARNING: Make sure no bare wire or wire
strands are visible after making connections. Place
GREEN and WHITE wire connections on the
opposite side of the outlet box from the BLACK and
BLUE wire connections.
Turn spliced/taped wires upward and gently push
wires and wire connectors (AA) into outlet box.
2. 2
1c. FAN AND LIGHT CONTROLLED BY TWO
WALL SWITCHES: Connect BLACK wire from fan
to BLACK (or RED) wire from the independent
wall switch for the fan. Connect BLUE wire from
fan to the BLACK (or RED) wire from the other
independent wall switch for the light. Connect
WHITE wire from fan to WHITE wire from ceiling.
Connect GROUND (GREEN) wires from downrod
(A) and mounting bracket (C) to BARE/GREEN
wire from ceiling.
NOTE: BLACK wire is hot power for fan. BLUE wire
is hot power for light kit. WHITE wire is common for
fan and light kit. GREEN or BARE wire is ground.
BLACK (WALL SWITCH)
BLACK (WALL SWITCH FOR LIGHT)
FAN AND LIGHT CONTROLLED BY TWO WALL SWITCHES
FAN AND LIGHT CONTROLLED BY TWO WALL SWITCHES
1c
WHITE BLACK
BLUE
120V POWER
FROM CEILING
WHITE(NEUTRAL)
GROUND/GREEN (BARE)
GREEN
Hardware Used
Wire Connector x 4
AA
AA
AA
AA AA
AA
1b. FAN CONTROLLED BY PULL CHAIN, LIGHT
BY WALL SWITCH: Connect BLACK wire from fan
to BLACK wire from ceiling. Connect BLUE wire
from fan to the BLACK wire from the independent
wall switch for the light. Connect WHITE wire from
fan to WHITE wire from ceiling. Connect GROUND
(GREEN) wires from fan (on downrod (A), if
applicable, and mounting bracket (C)) to
BARE/GREEN wire from ceiling.
FAN CONTROLLED BY PULL CHAIN, LIGHT BY WALL SWITCH
1b
WHITE BLACK
BLUE
120V POWER
FROM CEILING
BLACK(POWER)
BLACK (WALL SWITCH)
WHITE(NEUTRAL)
GROUND/GREEN (BARE)
GREEN
AA
AA AA
AA

12
FINAL INSTALLATION
1. 1
K
B
J
Locate two canopy mounting screws (K) on underside
of mounting bracket (C) and remove canopy mounting
screw (K) closest to the open end of the mounting
bracket (C). Partially loosen the other canopy
mounting screw (K). Lift canopy (B) to mounting
bracket (C). Place rounded part of slotted hole in
canopy (B) over loosened canopy mounting screw (K)
and push up. Twist canopy (B) to lock. Re-insert
canopy mounting screw (K) that was removed, then
tighten both canopy mounting screws (K).
Use arrows on inside of canopy cover (J) to locate
knobs on center ring of canopy cover (J). Slide
canopy cover (J) up to canopy (B), aligning knobs on
canopy cover (J) with openings in bottom of canopy
(B). Press up firmly on the canopy cover (J) until it fits
into the bottom of the canopy (B) and then turn canopy
cover (J) about ½ in.
DANGER: To reduce the risk of serious bodily
injury, DO NOT use power tools to assemble the
blades (G). If screws are overtightened, blades (G)
may crack and break.
Partially insert three blade screws (CC) along with
three blade washers (BB) into holes in blade (G) to
attach blade arm (N) to blade (G). Then, tighten
each blade screw (CC) starting with the one in the
middle.
Repeat Step 2 for remaining blades (G) and blade
arms (N).
2.
Fiber Blade Washer x 18
BB
Hardware Used
D
2
BB
CC
G
N
3
G
N
CC Blade Screw x 18
Knobs
Attach blade arms (N) to the bottom of motor housing
(D) with motor screws/lock washers (Q) previously
removed (Step 5, page 8). Tighten motor screws/lock
washers (Q) securely.
NOTE: Make sure to completely secure each blade
arm (N) before proceeding to the next.
3.
Q

13
FINAL INSTALLATION
4. Remove one motor plate screw (P) from motor
plate preassembled on the underside of the motor
housing (D) and partially loosen the other two
motor plate screws (P). Align slotted holes in
switch housing (H) with loosened motor plate
screws (P), allowing molex connections from
motor housing (D) to come through hole in switch
housing (H). Twist switch housing (H) to lock.
Re-insert the motor plate screw (P) that was
removed and securely tighten all three motor plate
screws (P).
4
I
P
I
P
I
P
H
D
Motor
Plate
5. Remove two switch housing screws (O) from
underside of switch housing (H) and partially
loosen the other switch housing screw (O).
3
5
O
F
O
D
molex
connections
6
Connect WHITE molex wire from LED light kit (F) to
WHITE molex wire from switch housing (H).
Connect BLUE molex wire from LED light kit (F) to
BLACK (or BLUE) molex wire from switch housing
(H). Make sure molex wire connections snap
together securely.
6.
H
H

F
H
14
FINAL INSTALLATION
Carefully arrange wires inside switch housing (H).
Align hole in edge of LED light kit (F) with loosened
switch housing screw (O) in switch housing (H).
Re-insert the other two switch housing screws (O)
previously removed. Tighten all three switch
housing screws (O) securely.
8. 3
8
O
Align slots on shade (I) with protrusions on the
inside of the switch housing. Turn shade (I) to the
right (clockwise) until it no longer turns.
NOTE: Pull down gently on the shade (I) to make
sure that it is secured completely.
9. 3
9
I
7. Connect male plug from motor housing (D) to female
plug from switch housing (H), matching up the colors
on the male plug with the colors on the female plug
for correct fit. Make sure plugs are connected
completely.
7
OO
D
Male
Plug
Female
Plug
H

15
D
Attach pull chain extensions (DD) or custom pull
chain extensions (not included) to fan and light pull
chains.
10. 10
DD DD
Pull Chain Extension x 2
Hardware Used
DD
FINAL INSTALLATION
The light pull chain, located to the right of the reverse
switch, is used to turn the light ON or OFF.
OPERATING INSTRUCTIONS
The fan pull chain, located to the left of the
reverse switch, has four positions to control fan
speed. One pull is HIGH, two is MEDIUM, three
is LOW and four turns the fan OFF.
1.
2. 2
1
Reverse
Switch
Reverse
Switch

16
OPERATING INSTRUCTIONS
Use the fan reverse switch on the switch housing
(H) to optimize your fan for seasonal performance.
A ceiling fan will allow you to raise your thermostat
setting in summer and lower your thermostat
setting in winter without feeling a difference in your
comfort.
NOTE: Wait for fan to stop before moving the
reverse switch.
3.
Reverse Switch
H
3
3a 3b
3c
3c. IMPORTANT: Reverse switch must be set
either completely LEFT or completely RIGHT for
fan to function. If the reverse switch is set in the
middle position, fan will not operate.
3a. In warmer weather, setting the reverse switch
in the LEFT position will result in downward airflow
creating a wind chill effect.
3b. In cooler weather, setting the reverse switch
in the RIGHT position will result in upward airflow
that can help move stagnant, hot air off the ceiling
area.

17
CARE AND MAINTENANCE
At least twice each year, lower canopy (B) to check downrod (A) assembly, and then tighten all
screws on fan. Clean motor housing (D) with only a soft brush or lint-free cloth to avoid scratching the
finish. Clean blades (G) with a lint-free cloth. You may occasionally apply a light coat of furniture
polish to wood blades for added protection.
IMPORTANT: Shut off main power supply before beginning any maintenance. Do not use water or a
damp cloth to clean the ceiling fan.
Total wattage for this fan is 12 watts; do not attempt to replace the LEDs.
WARNING: Before beginning work, shut off the power supply to avoid electrical shock.
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Fan does not move. 1. Reverse switch not engaged.
2. Power is off or fuse is blown.
3. Faulty wire connection.
4. Plugs in switch housing not connected
properly.
1. Push switch firmly either left or
right.
2. Turn power on or check fuse.
3. Turn power off. Loosen canopy
and check all connections.
4. Check that male and female plugs
in switch housing are connected
properly according to instructions
on page 14.
Noisy operation. 1. Blades are loose.
2. Cracked blade.
3. Full range dimmer switch.
4. Fan is new.
1. Tighten all blade screws.
2. Replace blade.
3. Replace with an approved speed
control device.
4. Allow fan a “break in” period of
a few days, especially when
running the fan at Medium and
High speeds.
Excessive wobbling. 1. Blades are loose.
2. Blade arms incorrectly attached.
3. Unbalanced blades.
4. Fan not securely mounted.
5. Fan too close to vaulted ceiling.
6. Set screw(s) on motor housing yoke is
(are) not tightened properly.
7. Set screw on hanging ball is not
tightened properly.
1. Tighten all blade screws.
2. Re-install blade arms.
3. Switch one blade with a blade
from the opposite side.
4. Turn power off. Carefully loosen
canopy and verify that mounting
bracket is secure.
5. Use a longer downrod or move
fan to another location.
6. Tighten yoke set screw(s)
securely.
7. Carefully loosen and lower canopy
and verify that set screw on
hanging ball is tightened securely.
Fan operates but
light fails.
1. Wires in canopy not wired properly. 1. Check wires in canopy and, if
necessary, re-wire according to
instructions on pages 10 and 11.

C
G
PART DESCRIPTION
2599783-A
2599783-B
2599783-C
2599783-G
2599783-N
PART #
B
A
A Mounting Bracket
B Downrod
C Canopy
G Blade
N Blade Arm
N
18 Printed in China
REPLACEMENT PARTS LIST
LIMITED LIFETIME WARRANTY
KHLI2007
The distributor warrants this fan to be free from defects in workmanship and materials present at time of
shipment from the factory for Lifetime limited from the date of purchase. This warranty applies only to the
original purchaser. The distributor agrees to correct any defect at no charge or, at our option, replace the
ceiling fan with a comparable or superior model.
To obtain warranty service, present a copy of your sales receipt as proof of purchase. All cost of removal
and reinstallation are the express responsibility of the purchaser. Any damage to the ceiling fan by
accident, misuse or improper installation, or by using parts not produced by the manufacturer of this fan or
affixing accessories not produced by the manufacturer of this fan, are the purchaser's own responsibility.
The distributor assumes no responsibility whatsoever for fan installation during the limited lifetime warranty.
Any service performed by an unauthorized person will render the warranty invalid.
Due to varying climatic conditions, this warranty does not cover changes in brass finish, rusting, pitting,
tarnishing, corroding or peeling. Brass finish fans maintain their beauty when protected from varying
weather conditions. Any glass provided with this fan is not covered by the warranty.
Any replacement of defective parts for the ceiling fan must be reported within the first year from the date of
purchase. For the balance of the warranty, call our customer service department (at 1-800-643-0067) for
return authorization and shipping instructions so that we may repair or replace the ceiling fan. Any fan or
parts returned improperly packaged is/are the sole responsibility of the purchaser. There is no further
express warranty. The distributor disclaims any and all implied warranties. The duration of any implied
warranty which cannot be disclaimed is limited to the limited lifetime period as specified in our warranty.
The distributor shall not be liable for incidental, consequential or special damages arising at or in
connection with product use or performance except as may otherwise be accorded by law. This warranty
gives you specific legal rights and you may also have other rights which vary from state to state. This
warranty supersedes all prior warranties.
For replacement parts, call our customer service department at 1-800-643-0067, 8 a.m. - 8 p.m., EST,
Monday - Sunday.
NOTE: A small amount of "wobble" is normal and should not be considered a defect.
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
[Fan operates but
light fails.]
2. Wall switch to fan is off.
3. Wires in LED light kit not wired
correctly.
2. Make sure that wall switch to fan is
on.
3. Check that molex connections in
LED light kit are connected properly
according to instructions on page 13.

VENTILADOR DE TECHO GASKIN
Harbor Breeze® es una marca registrada
de LF, LLC. Todos los derechos reservados.
19
ADJUNTE SU RECIBO AQUÍ
Fecha de compra
¿Preguntas, problemas, piezas faltantes? Antes de volver a la tienda, llame a nuestro
Departamento de Servicio al Cliente al 1-800-643-0067, de lunes a domingo de 8 a. m.
a 8 p. m., hora estándar del Este.
ARTÍCULO #2599783
MODELO #GAT24BNK6L
4007498

20
Información de seguridad .......................................................................................................20
Contenido del paquete ...........................................................................................................23
Lista de aditamentos ..............................................................................................................24
Preparación ............................................................................................................................24
Instalación inicial ....................................................................................................................24
Cableado ................................................................................................................................28
Instalación final........................................................................................................................29
Instrucciones de funcionamiento ............................................................................................33
Cuidado y mantenimiento .......................................................................................................35
Solución de problemas ...........................................................................................................35
Garantía limitada de por vida .................................................................................................36
Lista de piezas de repuesto ...................................................................................................36
ÍNDICE
Las modificaciones que no estén aprobadas por la parte responsable del cumplimiento podrían
anular la autorización del usuario para utilizar el equipo.
*NOTA: este equipo ha sido probado y se ha verificado que cumple con los límites para un
dispositivo digital clase B, conforme a la sección 15 de las reglas de la FCC. Estos límites se han
diseñado para proporcionar una protección razonable contra la interferencia perjudicial en una
instalación residencial. Este equipo genera, utiliza y puede irradiar energía de radiofrecuencia y, si
no se instala y se usa de acuerdo con las instrucciones, puede causar interferencia perjudicial a las
comunicaciones de radio. Sin embargo, no se garantiza que no se producirán interferencias en una
instalación en especial. Si este equipo genera una interferencia perjudicial para la recepción de
radio o televisión, que se puede determinar apagando y encendiendo el equipo, se recomienda al
usuario que intente corregir la interferencia con una o más de las siguientes medidas:
* Reoriente o reubique la antena de recepción.
* Aumente la separación entre el equipo y el receptor.
* Conecte el equipo a un tomacorriente de un circuito distinto al que usa el receptor.
Solicite ayuda al distribuidor o a un técnico con experiencia en radio/TV.
Distribuido por: Litex Industries Inc., P.O. Box 535639, Grand Prairie, TX, 75053; 1-800-527-1292
Este dispositivo cumple con la Parte 15 de las Reglas de la FCC. La operación está sujeta a las dos
siguientes condiciones: (1) Este dispositivo no provoca ninguna interferencia perjudicial; (2) Este
dispositivo aceptará cualquier interferencia que reciba, incluyendo aquellas que provoquen una
operación no deseada.
NOTA: se puede regular al 10 % con reguladores seleccionados. Consulte Lowes.com para obtener
más información.
INFORMACIÓN DE SEGURIDAD
