LG LS090HEV Installation and user guide

Date:
JobName/Location:
PONo.:
Architect:
Engr:
GC:
Rep:
For: File
A
pp
roval
Mech:
Resubmit
Other
Tag#:
(Company) (ProjectManager)
MegaSingleZoneInverter
LS090HEV
Performance:
Capacity(Btu/h) 8,500
SEER 16.3
EER 10.90
Cooling:
Heating:
Capacity(Btu/h) 9,000
HSPF 8.5
CoolingNominalTestConditions: HeatingNominalTestConditions:
Indoor: 80°FDB/67°FWB Indoor: 70°FDB/60°FWB
Outdoor: 95°FDB/75°FWB Outdoor: 47°FDB/43°FWB
Electrical:
MCA(A) 9
MOP(A) 15
Compressor(A) 6.8
FanMotor(A) 0.5
OutdoorUnit:
CoolingRatedAmps(A) 7.3
HeatingRatedAmps(A) 7.3
IndoorUnit:
CoolingPowerInput(kW) 0.78
HeatingPowerInput(kW) 0.78
Piping:
LiquidLine(in,OD) 1/4
AdditionalRefrigerant(oz/ft) 0.22
MaxElevation(ft) 22.9
PipingLength(noadd'lrefrigerant,ft) 24.6
ControlsFeatures:
Page1of2DFS‐SB‐AL‐001‐US013D23
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
©LGElectronicsU.S.A.,Inc.,EnglewoodCliffs,NJ.Allrightsreserved.“LGLife’sGood”isaregisteredtrademarkofLGCorp./www.lghvac.com.
PowerSupply(V¹/Hz/Ø) 208‐230/60/1
PowerSupply(V¹/Hz/Ø) 208‐230/60/1
VaporLine(in,OD) 3/8
MaxPipeLength(ft)² 49.2
OperatingRange:
OutdoorUnit:
Cooling(°FDB) 64‐118
Heating(°FDB) 23‐75
Cooling(°FDB) 64‐90
Heating(°FDB) 61‐86
IndoorUnit:
UnitData:
RefrigerantType R410A
RefrigerantCharge(lbs) 1.65
Fan:
Notes:
1.Acceptableoperangvoltage:187V‐253V.
2.Pipinglengthsareequivalent.
3.SoundPressurelevelsaretestedinananechoicchamberunderISOStandard1996.
4.Allpower/communicaoncabletobeminimum18AWG,4‐conductor,stranded,shielded
andmustcomplywithapplicablelocalandnationalcode.
5.SeeEngineeringManualforsensibleandlatentcapacies.
6.Powerwiringcablesizemustcomplywiththeapplicablelocalandnaonalcode.
7.Theindoorunitcomeswithadryheliumcharge.
8.Thisdataisrated0abovesealevel,with24.6ofrefrigerantlineanda0leveldifference
betweenoutdoorandindoorunits.
9.MustfollowinstallaoninstruconsintheapplicableLGinstallaonmanual.
ODUType Propeller
IDUType CrossFlow
Motor/Drive BrushlessDigitallyControlled/Direct
Dehumidification(pts/hr) 2.12
RefrigerantControl CapillaryTube
HeatExchangerCoating GoldFin™
ODUSoundPressure(±3dB(A))³ 47
ODUNetUnitWeight(lbs) 52
ODUShippingWeight(lbs) 56
IDUShippingWeight(lbs) 21
FanSpeeds(Fan/Cooling/Heating) 3/4/3
Quantity(ODU+IDU) 1+1
IDUAirFlowRateH/M/L(CFM) 276/226/177
ODUMaxAirFlowRate(CFM) 953
IndoorUnit(IDU)‐LSN090HEVOutdoorUnit(ODU)‐LSU090HEV
SEER‐SeasonalEnergyEfficiencyRatio EER‐EnergyEfficiencyRatio
HSPF‐HeatingSeasonalPerformanceFactor
MOP‐MaximumOvercurrentProtection MCA‐MinimumCircuitAmpacity
IDUSoundPressure±3(H/M/L/Sleep)dB(A)³ 39/33/25/19
IDUNetUnitWeight(lbs) 16
•24‐Houron/offmer
•2‐Way(up/down)auto
swing
•Autochangeover
•Autorestart
•Condensatesensor
connection
•Energysaving
•Inverter(variablespeed
compressor)
•Jetcool
•Self‐cleaningindoorcoil
•Sleepmode
•Ultraquietoperaon

JobName/Location:
Tag#:
Date:
PONo.:
MegaSingleZoneInverter
Page2of2DFS‐SB‐AL‐001‐US013D23
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
©LGElectronicsU.S.A.,Inc.,EnglewoodCliffs,NJ.Allrightsreserved.“LGLife’sGood”isaregisteredtrademarkofLGCorp./www.lghvac.com.
OutdoorUnit(ODU)‐LSU090HEV

JobName/Location:
Tag#:
Date:
PONo.:
MegaSingleZoneInverter
Page3of3DFS‐SB‐AL‐001‐US013D23
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
©LGElectronicsU.S.A.,Inc.,EnglewoodCliffs,NJ.Allrightsreserved.“LGLife’sGood”isaregisteredtrademarkofLGCorp./www.lghvac.com.
IndoorUnit
(
IDU
)
‐LSN090HEV
