LG ASNQ092BRW0 User manual

R410A(60Hz)
6RMI0-05A(Replaces 6RMI0-04C)
Brazil
Inverter Single Wall Mounted
P/No. : MFL66305305

1. Models line up
2. Features & Benefits
3. Specifications
4. Dimensions
5. Wiring diagrams
6. Refrigerant cycle diagrams
7. Capacity tables
8. Capacity coefficient factor
9. Operation range
10. Air flow and temperature distributions(reference data)
11. Sound levels
12. Remote controller
13. Installation
Inverter Single
Inverter Single-60Hz(R410A)

CLASSIFICATION KSC ISO ARI AHAM AS SSA
9306 5151 210/240 1861.1 385
Indoor DB°C(°F) 27.0 27.0 26.7(80) 26.7(80) 27.0 29.0
Cooling WB°C(°F) 19.5 19.0 19.4(67) 19.4(67) 19.0 19.0
Capacity Outdoor DB°C(°F) 35.0 35.0 35.0(95) 35.0(95) 35.0 46.0
WB°C(°F) 24.0 24.0 23.9(75) 23.9(75) 24.0 24.0
Indoor DB°C(°F) 20.0 20.0 21.1(70) 21.1(70) 20.0 21.0
Heating WB°C(°F) 15.0 15.0 15.6(60) 15.6(60) 15.0 15.5
Capacity Outdoor DB°C(°F) 7.0 7.0 8.3(47) 8.3(47) 7.0 7.0
WB°C(°F)) 6.0 6.0 6.1(43) 6.1(43) 6.0 6.0
Indoor DB°C(°F) 32.0 32.0 26.7(80) 32.2(90) 32.0 29.0
Maximum WB°C(°F) 23.0 23.0 19.4(67) 22.8(73) 23.0 19.0
Cooling
Outdoor DB°C(°F) 43.0 43.0 46.1(115) 43.3(110) 43.0 54.0
Operating WB°C(°F) 26.0 26.0 23.9(75) 25.6(78) 26.0 24.0
Indoor DB°C(°F) 27.0 27.0 26.7(80) 26.7(80) - -
Maximum WB°C(°F) 19.0 19.0 19.4(67) 22.8(73) - -
Heating
Outdoor DB°C(°F) 21.0 24.0 23.9(75) 23.9(75) - -
Operating WB°C(°F) 15.0 18.0 18.3(65) 18.3(65) - -
Enclosure Indoor DB°C(°F) 27.0 27.0 26.7(80) 26.7(80) 27.0 27.0
Sweat / WB°C(°F) 24.0 24.0 23.9(75) 23.9(75) 24.0 24.0
Condensate Outdoor DB°C(°F) 27.0 27.0 26.7(80) 26.7(80) 27.0 27.0
Disposal WB°C(°F) 24.0 24.0 23.9(75) 23.9(75) 24.0 24.0
Freeze-up/ Indoor DB°C(°F) 21.0 21.0 19.4(67) 21.1(70) 21.0 21.0
Low WB°C(°F) 15.0 15.0 13.9(57) 15.6(60) 16.0 16.0
Temperature Outdoor DB°C(°F) 21.0 21.0 19.4(67) 21.1(70) 21.0 21.0
WB°C(°F) 15.0 15.0 13.9(57) 15.6(60) 16.0 16.0
KS : Korea Standard AS : Australia Standard
ISO : International Standard Organization SSA : Saudi Arabian Standard
ARI : Airconditioning and Refrigeration Institute
AHAM : Association of Home Appliance Manufacturers
Test condition of international standard
Inverter Single

Split type of Air conditioners are known by the category name of Wall Mounted Type of units.These units can be
easily installed in a small space and have exceptional Cooling capacity.Designed for Low-noise operation,it
ensures a pleasant air conditioned environment.
LG Offers various types of units to its customers to suit for the best application and requirement.The following
are the important categories offered by LG :
1) General Wall Mounted Type Units : Units with Simplicity in design.
2) Art Cool Units : A new concept of cooling introduced by LG in the field of Air Conditioning.
3) Inverter Units : These units are capable of minimising the Power consumption with the unique inverter
technology.
Some of the Important Features of these units are listed below :
1) Providing Health to the Customers : By having the Filters such as Plasma Filter which is capable of removing
the Micro Organisms up to 0.1 microns.
2) Long Term Money Saving : By providing Features such as Gold Fin, Auto Clean etc. to maintain the same
performance for the years.
3) Best Comfort : With Features such as Sleep Mode,Timer,Auto Restart etc.
The Units are available with many standard and optional features which gives our Customers the free choice to
select the unit of their own desire.For details refer to the Detailed specification followed after this description.
LG Electronics Inc.
Air Conditioning Company
General Description
Inverter Single

Inverter Single-60Hz(R410A) _ 5
Publication history
Inverter Single
Inverter Single
Plb.No Model No. Notes Publication in
6RMI0-03A All models Add models for Brazil July.2010
6RMI0-04A All models Add ʼ11 new models Feb. 2011
6RMI0-04B AS-W092B1U0
AS-W122B1U0 Change spec sheet Mar. 2011
6RMI0-04C All Outdoor Unit Product logo revise Jun. 2011
6RMI0-05A All models Add ʻ13 models for Brazil Jun. 2013

1.2 Outdoor Unit
6_ Inverter Single-60Hz(R410A)
1. Models Line up
Inverter Single
Inverter Single
kW (kBtu/h)
Indoor Type 2.50(9) 3.50(12) 5.28(18) 7.03(24) 8.0(30) 9.0(36)
Hero
Mega 2.0
Libero ARTCOOL
Libero R
Libero E
ASNW092HDW0
USNQ092WSZ2
USNW092WSZ2
USNQ122BSZ2
USNW122BSZ2
USNQ182CSZ2
USNW182CSZ2
USNQ242CSZ2
USNW242CSZ2
ASNW122HDW0
ASNQ092BRW0
ASNW092BRW0
ASNQ092BRZ0
ASNW092BRZ0
ASNQ122BRW0
ASNW122BRW0
ASNQ122BRZ0
ASNW122BRZ0
ASNQ182CRW0
ASNW182CRW0
ASNQ182CRZ0
ASNW182CRZ0
ASNQ242CRW0
ASNW242CRW0
ASNQ242CRZ1
ASNW242CRZ1
ASNW092B1U0 ASNW122B1U0 ASNW182C2U0 ASNW242C2U0
ASNQ092B4A0
ASNW092B4A0
ASNQ122B4A0
ASNW122B4A0
ASNQ182C4A0
ASNW182C4A0
ASNQ242C4A0
ASNW242C4A0
1.1 Indoor Unit
* Denotes the color or the picture used on the front grille of the unit (refer to the Nomenclature section)
Heat pump
ASUW092HDW0
ASUW092BRW0
ASUQ092BRW0
ASUW092B4A0
ASUQ092B4A0
USUW092WSZ2
USUQ092WSZ2
ASUQ092BRZ0
ASUW092BRZ0
ASUW122HDW0
ASUW122BRW0
ASUQ122BRW0
ASUW122B4A0
ASUQ122B4A0
USUW122BSZ2
USUQ122BSZ2
ASUQ122BRZ0
ASUW122BRZ0
No. of connectable indoor units Max.1
Total capacity index of connectable kW 2.50 2.64 3.50 3.52
indoor units kBtu/h 9 12
Power supply 220V, 60Hz
Chassis
UA3

Inverter Single-60Hz(R410A) _ 7
1. Models Line up
Inverter Single
Inverter Single
Heat pump
ASUW092B1U0 ASUW122B1U0 USUW182CSZ2
USUQ182CSZ2
No. of connectable indoor units Max.1
Total capacity index of connectable kW 2.50 3.50 5.28
indoor units kBtu/h 9 12 18
Power supply 220V, 60Hz
Chassis
UL2
Heat pump
ASUW182CRW0
ASUW182C4A0
ASUW182C2U0
ASUQ182CRW0
ASUQ182C4A0
ASUQ182CRZ0
ASUW182CRZ0
USUW242CSZ2
USUQ242CSZ2
ASUQ242CRZ1
ASUW242CRZ1
No. of connectable indoor units Max.1
Total capacity index of connectable kW 5.28 6.45
indoor units kBtu/h 18 24
Power supply 220V, 60Hz
Chassis
UE
Heat pump
ASUQ242CRW0
ASUQ242C4A0
ASUW242CRW0
ASUW242C4A0
ASUW242C2U0
No. of connectable indoor units Max.1
Total capacity index of connectable kW 6.45 7.03
indoor units kBtu/h 22 24
Power supply 220V, 60Hz
Chassis
UE1+UE1

S
A- W 0 9 2 H D W 0
Serial Number
Function
Chassis name
Ex) H : SH
G : Plasma + (A / Changeove) + A / Clean + Low A
M : Plasma + (A / Changeove) + A / Clean + 4way
S : Eco eye + Plasma + Allergy Filter + 4way
U : Plasma + Allergy Filter + 4way
W : Allergy Filter + 2way
Electric Ratings
220/60Hz/1Ø
Capacity
Ex) ‘09’ →9,000 Btu/h Class
Model Type
C : Cooling Only
H : Heat Pump
Q : DC Inverter C/O
W : DC Inverter H/P
Supply method dividing and Type
- : SET
N : Indoor Unit
U : Outdoor Unit
Product type
S: Split
Refrigerant type & code
L: R22
A: R410A
CHASIS
SH D Panel Type
SB
1 Libero R (White+Silver deco)
Libero E (White panel)
Mirror
SC
4
R
R
2
4
Libero R (White+Silver deco)
Libero E (White panel)
Mirror
LOOK Classification
8_ Inverter Single-60Hz(R410A)
Inverter Single
Inverter Single
• Model Number
2. Nomenclature

Inverter Single-60Hz(R410A) _ 9
Inverter Single
Inverter Single
Inverter Single, General Wall Mounted(#1)
Note : O : Applie, X : Not applied, – : No relation
• Filters are optional in some specific areas.
* For Circuit Breaker Rating, please conform to local standards whenever necessary.
3. Specifications
Models AS-W092HDW0 AS-W122HDW0
Cooling Capacity kW 0.89 ~ 2.50 ~ 3.70 0.90 ~ 3.50 ~ 4.04
Btu/h. 3,040 ~ 8,500 ~ 12,620 3,070 ~ 11,900 ~ 13,800
Heating Capacity kW 0.89 ~ 3.2 ~ 4.1 0.90 ~ 4.01 ~ 5.1
Btu/h. 3,040 ~ 10,900 ~ 14,000 3,070 ~ 13,700 ~ 17,400
Power Input Cooling/Heating W 620 / 780 1,060 / 1,080
Running Current Cooling/Heating A 2.8 / 3.5 4.7 / 4.8
Starting Current Cooling/Heating A 2.8 / 3.5 4.7 / 4.8
EER W/W 4.03 3.3
Btu/h.W 13.7 11.3
COP W/W 4.1 3.71
Power Supply Ø / V / Hz 1 / 220 / 60 1 / 220 / 60
Power Factor % 96.3 98.1
Air Flow Rate Indoor,Max m3/min(CFM) 11.0(388) 11.0(388)
Outdoor,Max m3/min(CFM) 27.0(953) 27.0(953)
Moisture Removal l/h. 1.1 1.3
Sound Level Indoor,H/M/L dB(A)±3 37 / 33 / 25 38 / 33 / 25
Outdoor,Max dB(A)±3 47 47
Refrigerant & Charge (at 7.5 m) g(oz) R410A, 900(31.75) R410A,9,00(31.75)
Additional Refrigerant charge g/m(oz/ft) 20(0.22) 20(0.22)
Compressor
Type Rotary Rotary
Model GA102DBA GA102DBA
Motor Type Brushless DC Motor Brushless DC Motor
Oil Type PVE(FVC68D) PVE(FVC68D)
Oil Charge cc 310 310
O.L.P. name - -
Fan(Indoor) Type Cross Flow Fan Cross Flow Fan
Motor Output W20 20
Fan(Outdoor)
Type Propeller Propeller
Motor Type BLDC BLDC
Motor Output W43 43
Circuit Breaker* A 15 15
Power Supply Cable No.*mm23 x 1.0 3 x 1.0
Power and Transmission Cable No.*mm2 No.*mm24 x 1.0 (Including Earth) 4 x 1.0 (Including Earth)
Piping Connections
Liquid Side mm(in) 6.35(1/4) 6.35(1/4)
Gas Side mm(in) 9.52(3/8) 9.52(3/8)
Drain Hose(O.D/I.D) mm(in) 21.5 / 16.0 (0.85 / 0.63) 21.5 / 16.0 (0.85 / 0.63)
Dimensions
Indoor (W*H*D) mm 798 x 290 x 210 798 x 290 x 210
inch 31.4 x 11.4 x 8.3 31.4 x 11.4 x 8.3
Outdoor (W*H*D) mm 717 x 483 x 230 717 x 483 x 230
inch 28.2 x 19.0 x 9.1 28.2 x 19.0 x 9.1
Net Weight Indoor kg(lbs) 8.5(18.7) 8.5(18.7)
Outdoor kg(lbs) 28(61.7) 28(61.7)
Operation Range Cooling(Outdoor) °C(°F) -10 ~48 (14 ~118.4) -10 ~48 (14 ~118.4)
Heating(Outdoor) °C(°F) -10 ~24 (14 ~75.2) -10 ~24 (14 ~75.2)
Piping Length (Min) m(ft) 3(9.84) 3(9.84)
Piping Length (Max) m(ft) 15(49.2) 15(49.2)
Chargeless m(ft) - -
Max. Elevation Difference m(ft) 7(23.0) 7(23.0)
Tool Code(Chassis) Indoor + Outdoor SH + UA3 SH + UA3
Functions
Temperature Control Thermistor Thermistor
Plasma Filter O O
Prefilter(washable/Anti-fungus) O O
Auto Clean O O
Natural Wind(Auto Wind) O O
Steps, Fan/Cool/Heat 3 / 5 / 5 3 / 5 / 5
Airflow Direction Control(Up& Down) Auto Auto
Airflow Direction Control(Left & Right) Auto Auto
Setting Temperature
Range
Cooling 18°C ~ 30°C 18°C ~ 30°C
Heating 16°C ~ 30°C 16°C ~ 30°C
Auto Operation (Micom Control) - -
Auto Changeover (Micom Control) O O
Self Diagnosis O O
Timer 24h, On/Off 24h, On/Off
Sleep Operation O O
Soft Dry Operation O O
Restart Delay(Minute) 3 3
Deice Control(Defrost) O O
Hot Start O O
Jet Cool O O
Low Ambient Operation O O
Deluxe wired remote controller - -
Wireless remote controller Wireless LCD(EZ-Remocon) Wireless LCD(EZ-Remocon)
Dry contact - -
PI 485 - -

3. Specifications
10 _ Inverter Single-60Hz(R410A)
Inverter Single
Inverter Single
Inverter Single, General Wall Mounted(#2)
Note : O : Applie, X : Not applied, – : No relation
• Filters are optional in some specific areas.
* For Circuit Breaker Rating, please conform to local standards whenever necessary.
Models Unit AS-W092B1U0 AS-W122B1U0 AS-W182C2U0 AS-W242C2U0
Cooling Capacity kW 0.89~2.50~3.70 0.89~3.50~4.04 0.90~5.2~6.0 0.9~7.03~8.65
Btu/h. 3,070~8,530~12,620 3,070~11,900~13,800 3,070~17,743~20,472 3,070~24,000~29,515
Heating Capacity kW 0.89~3.2~5.0 0.89~4.0~6.0 0.90~6.3~9.0 0.90~8.44~11.4
Btu/h. 3,070~10,920~17,060 3,070~13,600~20,470 3,070~21,496~30,709 3,070~28,800~38,898
Power Input Cooling/Heating W 550/700 880/960 1,500/1,650 2,190/2,330
Running Current Cooling/Heating A 2.4/3.1 4.0/4.3 6.6/7.3 9.8/10.4
Starting Current Cooling/Heating A 2.4/3.1 4.0/4.3 6.6/7.3 9.8/10.4
EER W/W 4.55 3.98 3.47 3.21
Btu/h.W 15.52 13.57 11.84 10.95
COP W/W 4.57 4.17 3.82 3.62
Power Supply Ø / V / Hz 1/220/60 1/220/60 1/220/60 1/220/60
Power Factor % 97.4 95.1 98.8 98.2
Air Flow Rate Indoor,Max
m3/min(CFM) 12.0(423) 12.0(423) 19.5(689) 22(777)
Outdoor,Max
m3/min(CFM) 33(1,165) 33(1,165) 60(2,119) 60(2,119)
Moisture Removal l/h. 1.1 1.3 1.9 2.6
Sound Level Indoor,H/M/L dB(A)±3 38/33/23/19 39/33/23/19 42/40/35 45/40/35
Outdoor,Max dB(A)±3 45 45 51 53
Refrigerant & Charge (at 7.5 m) g(oz) R410A, 1,000 (35.3) R410A, 1,000 (35.3) R410A, 1,350(47.62) R410A, 1,800(63.49)
Additional Refrigerant charge g/m(oz/ft) 20(0.22) 20(0.22) 20(0.21) 35(0.37)
Compressor
Type Rotary Rotary Twin Rotary Twin Rotary
Model 5RS102XAA21 5RS102XAA21 GKT141DAA GJT240DAA
Motor Type Brushless DC Motor Brushless DC Motor Brushless DC Motor Brushless DC Motor
Oil Type PVE(FV50S) PVE(FV50S) FVC68D PVE(FVD68C)
Oil Charge cc 320 320 570 900
O.L.P. name - - - -
Fan(Indoor) Type Cross Flow Fan Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor Output W 20 20 20 20
Fan(Outdoor)
Type Propeller Propeller Propeller Propeller
Motor Type BLDC BLDC BLDC BLDC
Motor Output W 43 43 84 124
Circuit Breaker* A 15 15 15 30
Power Supply Cable No.*mm23*1.0 3*1.0 3*1.5 3*2.5
Power and Transmission Cable No.*mm2 No.*mm24*1.0(Including Earth) 4*1.0(Including Earth) 4*1.0 (Including Earth) 4*1.0(Including Earth)
Piping Connections Liquid Side mm(in) 6.35(1/4) 6.35(1/4) 6.35(1/4) 9.52(3/8)
Gas Side mm(in) 9.52(3/8) 9.52(3/8) 12.70(1/2) 15.88(5/8)
Drain Hose(O.D / I.D.) mm(in) 21.5,16.0(0.85,0.63) 21.5,16.0(0.85,0.63) 21.5 /16.0 (0.85 / 0.63) 21.5/16.0 (0.85/0.63)
Dimensions
Indoor (W*H*D) mm 885*285*210 885*285*210 1030*325*250 1030*325*250
inch 34.8*11.2*8.3 34.8*11.2*8.3 40.6*12.8*9.8 40.6*12.8*9.8
Outdoor (W*H*D) mm 770*545*288 770*545*288 870*655*320 870*800*320
inch 30.3*21.5*11.3 30.3*21.5*11.3 34.3*25.8*12.6 34.3*31.5*12.6
Net Weight Indoor kg(lbs) 12(26.5) 12(26.5) 17(37.5) 17(37.5)
Outdoor kg(lbs) 35(77.2) 35(77.2) 51(111.4) 60(132)
Operation Range Cooling(Outdoor)
°C(°F) -10 ~48 (14 ~118.4) -10 ~48 (14 ~118.4) -10 ~48 (14 ~118.4) -10 ~48 (14 ~118.4)
Heating(Outdoor)
°C(°F) -10 ~24 (14 ~75.2) -10 ~24 (14 ~75.2) -10 ~24 (14 ~75.2) -10 ~24 (14 ~75.2)
Piping Length (Min) m(ft) 2(6.56) 2(6.56) - -
Piping Length (Max) m(ft) 20(65.6) 20(65.6) 20(65.6) 30(98.4)
Chargeless m(ft) 12.5(41.0) 12.5(41.0) - -
Max. Elevation Difference m(ft) 10(32.8) 10(32.8) 15(49.2) 15(49.2)
Tool Code(Chassis) Indoor + Outdoor SB + UL2 SB + UL2 SC + UE S8 + UE1 plus
Functions
Temperature Control Thermistor Thermistor Thermistor Thermistor
PlasmaFilter OOOO
Prefilter(washable/anti-fungus) OOOO
Anti Allergy free filter OOOO
Deodorizer Filter(Triple Filter) OOOO
H1N1 Filter - - - -
AutoClean OOOO
CHAOS Wind(Auto Wind) OOOO
Steps, Fan/Cool/Heat 5/6/6 5/6/6 5/6/6 5/6/6
Airflow Direction Control(up& Down) Auto Auto Auto Auto
Airflow Direction Control(left & right) Auto Auto Auto Auto
Remote Controller Type Wireless LCD(EZ-Remocon) Wireless LCD(EZ-Remocon) Wireless LCD(EZ-Remocon) Wireless LCD(EZ-Remocon)
Setting Temperature
Range
Cooling 18°C ~ 30°C 18°C ~ 30°C 18°C ~ 30°C 18°C ~ 30°C
Heating 16°C ~ 30°C 16°C ~ 30°C 16°C ~ 30°C 16°C ~ 30°C
Auto Operation (Micom Control) - - - -
Auto Changeover (Micom Control) OOOO
Self Diagnosis OOOO
Timer 24h, On/Off 24h, On/Off 24h, On/Off 24h On/Off
SleepOperation OOOO
Soft Dry Operation OOOO
Restart Delay(minute) 3333
Deice Control(Defrost) OOOO
HotStart OOOO
Jet Cool OOOO
Low Ambient Operation OOOO

Inverter Single-60Hz(R410A) _ 11
3. Specifications
Inverter Single
Inverter Single
Note : O : Applie, X : Not applied, – : No relation
• Filters are optional in some specific areas.
* For Circuit Breaker Rating, please conform to local standards whenever necessary.
Models Unit AS-W092B4A0 AS-W122B4A0 AS-W182C4A0 AS-W242C4A0
Cooling Capacity Btu/h. 3,070~8,500~12,600 3,070~12,000~13,800 3,070 ~ 18,000 ~ 20,500 3,070 ~ 24,000 ~ 29,500
kW 0.90~2.49~3.70 0.90~3.52~4.04 0.90 ~ 5.28 ~ 6.00 0.90 ~ 7.03 ~ 8.65
Heating Capacity Btu/h. 3,070 ~ 11,000 ~ 14,000 3,070 ~ 14,000 ~ 17,400 3,070 ~ 22,000 ~ 30,700 3,070 ~ 29,000 ~ 38,900
kW 0.89~3.22~4.10 0.89~4.10~5.10 0.90 ~ 6.45 ~ 9.00 0.90 ~ 8.50 ~ 11.40
Power Input Cooling/Heating W 600 / 770 1,010 / 1,050 1,500 / 1,650 2,190 / 2,330
Running Current Cooling/Heating A 2.70 / 3.50 4.60 / 4.80 6.9 / 7.5 10.0 / 10.6
Starting Current Cooling/Heating A 2.70 / 3.50 4.60 / 4.80 6.9 / 7.5 10.0 / 10.6
EER W/W 4.15 3.48 3.52 3.21
Btu/h.W 14.2 12.7 12.01 10.9
COP W/W 4.19 3.91 3.91 3.65
Power Supply Ø / V / Hz 1/220/60 1/220/60 1/220/60 1/220/60
Power Factor % 97.4 95.5 98.8 96.6
Air Flow Rate Indoor,Max
m3/min(CFM) 12.0(423) 12.0(423) 19.5(689) 22(777)
Outdoor,Max
m3/min(CFM) 27(953) 27(953) 50(1,766) 60(2,119)
Moisture Removal l/h. 1.1 1.3 1.9 2.6
Sound Level Indoor,H/M/L dB(A)±3 38 / 33 / 23 / 19 39 / 33 / 23 / 19 42 / 40 / 35 / 29 45 / 40 / 35 / 29
Outdoor,Max dB(A)±347475153
Refrigerant & Charge (at 7.5 m) g(oz) R410A,900(31.75) R410A,900(31.75) R410A, 1,350(47.62) R410A, 1,800(63.49)
Additional Refrigerant charge g/m(oz/ft) 20(0.22) 20(0.22) 20(0.22) 35(0.37)
Compressor
Type Rotary Rotary Twin Rotary Twin Rotary
Model GA102DBA GA102DBA GKT141DAA GJT240DAA
Motor Type Brushless DC Motor Brushless DC Motor Brushless DC Motor Brushless DC Motor
Oil Type FVC68D FVC68D FVC68D PVE(FVD68C)
Oil Charge cc 310 310 570 900
O.L.P. name ----
Fan(Indoor) Type Cross Flow Fan Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor Output W20202020
Fan(Outdoor)
Type Propeller Propeller Propeller Propeller
Motor Type BLDC BLDC BLDC BLDC
Motor Output W434384124
Circuit Breaker* A 15 15 20 25
Power Supply Cable No.*mm23*1.0 3*1.0 3*1.5 3*2.5
Power and Transmission Cable No.*mm2 No.*mm24*1.0 (Including Earth) 4*1.0 (Including Earth) 4*1.0 (Including Earth) 4*1.0 (Including Earth)
Piping Connections Liquid Side mm(in) 6.35(1/4) 6.35(1/4) 6.35(1/4) 9.52(3/8)
Gas Side mm(in) 9.52(3/8) 9.52(3/8) 12.70(1/2) 15.88(5/8)
Drain Hose(O.D / I.D.) mm(in) 21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63)
Dimensions
Indoor (W*H*D) mm 885*285*210 885*285*210 1,030*325*250 1,030*325*250
inch 34.8*11.2*8.3 34.8*11.2*8.3 40.6*12.8*9.8 40.6*12.8*9.8
Outdoor (W*H*D) mm 717*483*230 717*483*230 870*655*320 870*800*320
inch 28.2*19.0*9.1 28.2*19.0*9.1 34.3*25.8*12.6 34.3*31.5*12.6
Net Weight Indoor kg(lbs) 11(24.5) 11(24.5) 17(37.5) 17(37.5)
Outdoor kg(lbs) 28(61.7) 28(61.7) 46(101.4) 60(132.3)
Gross Weight Indoor kg(lbs) 13(28.7) 13(28.7) 19(41.9) 19(41.9)
Outdoor kg(lbs) 30(66.1) 30(66.1) 53(116.8) 64(141.1)
Operation Range Cooling(Outdoor)
°C(°F) -5 ~48 (23 ~118.4) -5 ~48 (23 ~118.4) -10 ~48 (14 ~118.4) -10 ~48 (14 ~118.4)
Heating(Outdoor)
°C(°F) -10 ~24 (14 ~75.2) -10 ~24 (14 ~75.2) -10 ~24 (14 ~75.2) -10 ~24 (14 ~75.2)
Piping Length (Min/Max) m(ft) 3(9.84) / 15(49.2) 3(9.84) / 15(49.2) 7.5 (24.6) / 20(65.6) 7.5(24.6) / 30(98.4)
Chargeless m(ft) - - - -
Max. Elevation Difference m(ft) 7(23.0) 7(23.0) 15(49.2) 15(49.2)
Tool Code(Chassis) Indoor + Outdoor SB + UA3 SB + UA3 SC + UE SC + UE1+
Functions
Temperature Control Thermistor Thermistor Thermistor Thermistor
Plasma Filter - - - -
Prefilter(washable/anti-fungus) OOOO
Anti Allergy free filter - - - -
Deodorizer Filter(Triple Filter) - - - -
H1N1 Filter - - - -
AutoClean OOOO
CHAOS Wind(Auto Wind) OOOO
Steps, Fan/Cool/Heat 3/4/4 3/4/4 3/4/4 3/4/4
Airflow Direction Control(up& Down) Auto Auto Auto Auto
Airflow Direction Control(left & right) Manual Manual Manual Manual
Remote Controller Type Wireless LCD Wireless LCD Wireless LCD Wireless LCD
Setting Temperature
Range
Cooling 18°C ~ 30°C 18°C ~ 30°C 18°C ~ 30°C 18°C ~ 30°C
Heating 16°C ~ 30°C 16°C ~ 30°C 16°C ~ 30°C 16°C ~ 30°C
Auto Operation (Micom Control) - - - -
Auto Changeover (Micom Control) OOOO
Self Diagnosis OOOO
Timer 24h, On/Off 24h, On/Off 24h, On/Off 24h On/Off
SleepOperation OOOO
SoftDryOperation OOOO
Restart Delay(minute) 3333
Deice Control(Defrost) OOOO
HotStart OOOO
Jet Cool OOOO
Low Ambient Operation OOOO

3. Specifications
12 _ Inverter Single-60Hz(R410A)
Inverter Single
Inverter Single
Note : O : Applie, X : Not applied, – : No relation
• Filters are optional in some specific areas.
* For Circuit Breaker Rating, please conform to local standards whenever necessary.
Models Unit AS-Q092B4A0 AS-Q122B4A0 AS-Q182C4A0 AS-Q242C4A0
Cooling Capacity Btu/h. 3,070~9,000~11,600 3,070~12,000~13,600 3,070~18,000~19,500 3,070~22,000~24,000
kW 0.90~2.64~3.40 0.90~3.52~3.99 0.90~5.28~5.72 0.90 ~ 6.45 ~ 7.03
Power Input Cooling W 775 1030 1550 2010
Running Current Cooling A 3.7 4.9 7.2 9.4
Starting Current Cooling A 3.7 4.9 7.2 9.4
EER W/W 3.4 3.41 3.4 3.21
Btu/h.W 11.6 11.6 11.6 11
Power Supply Ø / V / Hz 1/220/60 1/220/60 1/220/60 1/220/60
Power Factor % 95.2 97.1 97.9 97.2
Air Flow Rate Indoor,Max
m3/min(CFM) 9.0 (318) 11.0 (388) 19.5(689) 19.5 (688)
Outdoor,Max
m3/min(CFM) 28 (989) 28 (989) 50(1,766) 60 (2,119)
Moisture Removal l/h. 0.9 1.1 1.3 1.5
Sound Level Indoor,H/M/L dB(A)±3 38 / 33 / 23 / 19 39 / 33 / 23 / 19 42 / 40 / 35 / 29 45 / 40 / 35 / 29
Outdoor,Max dB(A)±348485353
Refrigerant & Charge (at 7.5 m) g(oz) R410A, 730 (26.5) R410A, 830 (29.3) R410A, 1,300(45.86) R410A, 1,650(58.2)
Additional Refrigerant charge g/m(oz/ft) 10(0.11) 10(0.11) 20(0.21) 20(0.21)
Compressor
Type Rotary Rotary Twin Rotary Twin Rotary
Model GA102MAA GA102MAA GKT141DAA GKT176DAA
Motor Type Brushless DC Motor Brushless DC Motor Brushless DC Motor Brushless DC Motor
Oil Type FVC68D FVC68D FVC68D FVC68D
Oil Charge cc 310 310 570 660
O.L.P. name ----
Fan(Indoor) Type Cross Flow Fan Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor Output W20202020
Fan(Outdoor)
Type Propeller Propeller Propeller Propeller
Motor Type AC AC AC AC
Motor Output W 24.5 24.5 79 79
Circuit Breaker* A 15 15 20 20
Power Supply Cable No.*mm23*1.0 3*1.0 3*1.5 3*2.5
Power and Transmission Cable No.*mm2 No.*mm24*1.0 (Including Earth) 4*1.0 (Including Earth) 4*1.0 (Including Earth) 4*1.0 (Including Earth)
Piping Connections Liquid Side mm(in) 6.35(1/4) 6.35(1/4) 6.35(1/4) 9.52(3/8)
Gas Side mm(in) 9.52(3/8) 9.52(3/8) 12.70(1/2) 15.88(5/8)
Drain Hose(O.D / I.D.) mm(in) 21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63)
Dimensions
Indoor (W*H*D) mm 885*285*210 885*285*210 1,030*325*250 1,030*325*250
inch 34.8*11.2*8.3 34.8*11.2*8.3 40.6*12.8*9.8 40.6*12.8*9.8
Outdoor (W*H*D) mm 717*499*230 717*499*230 870*655*320 870*800*320
inch 28.2*19.6*9.1 28.2*19.6*9.1 34.3*25.8*12.6 34.3*31.5*12.6
Net Weight Indoor kg(lbs) 10 (22.04) 10 (22.04) 17 (37.5) 17 (37.5)
Outdoor kg(lbs) 24 (52.91) 24 (52.91) 47 (103.6) 60 (132.3)
Gross Weight Indoor kg(lbs) 12 (26.45) 12 (26.45) 19 (41.9) 19 (41.9)
Outdoor kg(lbs) 26 (57.32) 26 (57.32) 49 (108.0) 62 (136.7)
Operation Range Cooling(Outdoor)
°C(°F) 18 ~ 48 ( 64.4 ~ 118.4) 18 ~ 48 ( 64.4 ~ 118.4) 18 ~ 48 ( 64.4 ~ 118.4) 18 ~ 48 ( 64.4 ~ 118.4)
Heating(Outdoor)
°C(°F) ----
Piping Length (Min/Max) m(ft) 7.5(24.6) / 15(49.2) 7.5(24.6) / 15(49.2) 7.5(24.6) / 20(65.6) 7.5(24.6) / 20(65.6)
Chargeless m(ft) - - - -
Max. Elevation Difference m(ft) 7 (22.96) 7 (22.96) 7 (22.96) 7 (22.96)
Tool Code(Chassis) Indoor + Outdoor SB + UA3 SB + UA3 SC + UE SC + UE1
Functions
Temperature Control Thermistor Thermistor Thermistor Thermistor
Plasma Filter - - - -
Prefilter(washable/anti-fungus) OOOO
Anti Allergy free filter - - - -
Deodorizer Filter(Triple Filter) - - - -
H1N1 Filter - - - -
AutoClean OOOO
CHAOS Wind(Auto Wind) OOOO
Steps, Fan/Cool/Heat -/4/- -/4/- -/4/- -/4/-
Airflow Direction Control(up& Down) Auto Auto Auto Auto
Airflow Direction Control(left & right) Manual Manual Manual Manual
Remote Controller Type Wireless LCD Wireless LCD Wireless LCD Wireless LCD
Setting Temperature
Range
Cooling 18°C ~ 30°C 18°C ~ 30°C 18°C ~ 30°C 18°C ~ 30°C
Heating - - - -
Auto Operation (Micom Control) OOOO
Auto Changeover (Micom Control) - - - -
Self Diagnosis OOOO
Timer 24h, On/Off 24h, On/Off 24h, On/Off 24h On/Off
SleepOperation OOOO
Soft Dry Operation OOOO
Restart Delay(minute) 3333
Deice Control(Defrost) - - - -
Hot Start - - - -
Jet Cool OOOO
Low Ambient Operation - - - -

Inverter Single-60Hz(R410A) _ 13
3. Specifications
Inverter Single
Inverter Single
Inverter Single, Libero ARTCOOL (#2)
Note : O : Applie, X : Not applied, – : No relation
• Filters are optional in some specific areas.
* For Circuit Breaker Rating, please conform to local standards whenever necessary.
Models Unit AS-W092BRW0 AS-W122BRW0 AS-W182CRW0 AS-W242CRW0
Cooling Capacity Btu/h. 3,070~8,500~12,600 3,070~12,000~13,800 3,070 ~ 18,000 ~ 20,500 3,070 ~ 24,000 ~ 29,500
kW 0.90~2.49~3.70 0.90~3.52~4.04 0.90 ~ 5.28 ~ 6.00 0.90 ~ 7.03 ~ 8.65
Heating Capacity Btu/h. 3,070 ~ 11,000 ~ 14,000 3,070 ~ 14,000 ~ 17,400 3,070 ~ 22,000 ~ 30,700 3,070 ~ 29,000 ~ 38,900
kW 0.89~3.22~4.10 0.89~4.10~5.10 0.90 ~ 6.45 ~ 9.00 0.90 ~ 8.50 ~ 11.40
Power Input Cooling/Heating W 600 / 770 1,010 / 1,050 1,500 / 1,650 2,190 / 2,330
Running Current Cooling/Heating A 2.70 / 3.50 4.60 / 4.80 6.9 / 7.5 10.0 / 10.6
Starting Current Cooling/Heating A 2.70 / 3.50 4.60 / 4.80 6.9 / 7.5 10.0 / 10.6
EER W/W 4.15 3.48 3.52 3.21
Btu/h.W 14.2 12.7 12.01 10.9
COP W/W 4.19 3.91 3.91 3.65
Power Supply Ø / V / Hz 1/220/60 1/220/60 1/220/60 1/220/60
Power Factor % 97.4 95.5 98.8 96.6
Air Flow Rate Indoor,Max
m3/min(CFM) 12.0(423) 12.0(423) 19.5(689) 22(777)
Outdoor,Max m3/min(CFM) 27(953) 27(953) 50(1,766) 60(2,119)
Moisture Removal l/h. 1.1 1.3 1.9 2.6
Sound Level Indoor,H/M/L dB(A)±3 38 / 33 / 23 / 19 39 / 33 / 23 / 19 42 / 40 / 35 / 29 45 / 40 / 35 / 29
Outdoor,Max dB(A)±3 47 47 51 53
Refrigerant & Charge (at 7.5 m) g(oz) R410A,900(31.75) R410A,900(31.75) R410A, 1,350(47.62) R410A, 1,800(63.49)
Additional Refrigerant charge g/m(oz/ft) 20(0.22) 20(0.22) 20(0.22) 35(0.37)
Compressor
Type Rotary Rotary Twin Rotary Twin Rotary
Model GA102DBA GA102DBA GKT141DAA GJT240DAA
Motor Type Brushless DC Motor Brushless DC Motor Brushless DC Motor Brushless DC Motor
Oil Type FVC68D FVC68D FVC68D PVE(FVD68C)
Oil Charge cc 310 310 570 900
O.L.P. name - - - -
Fan(Indoor) Type Cross Flow Fan Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor Output W 20 20 20 20
Fan(Outdoor)
Type Propeller Propeller Propeller Propeller
Motor Type BLDC BLDC BLDC BLDC
Motor Output W 43 43 84 124
Circuit Breaker* A 15 15 20 25
Power Supply Cable No.*mm23*1.0 3*1.0 3*1.5 3*2.5
Power and Transmission Cable No.*mm2 No.*mm24*1.0 (Including Earth) 4*1.0 (Including Earth) 4*1.0 (Including Earth) 4*1.0 (Including Earth)
Piping Connections Liquid Side mm(in) 6.35(1/4) 6.35(1/4) 6.35(1/4) 9.52(3/8)
Gas Side mm(in) 9.52(3/8) 9.52(3/8) 12.70(1/2) 15.88(5/8)
Drain Hose(O.D / I.D.) mm(in) 21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63)
Dimensions
Indoor (W*H*D) mm 885*285*210 885*285*210 1,030*325*250 1,030*325*250
inch 34.8*11.2*8.3 34.8*11.2*8.3 40.6*12.8*9.8 40.6*12.8*9.8
Outdoor (W*H*D) mm 717*483*230 717*483*230 870*655*320 870*800*320
inch 28.2*19.0*9.1 28.2*19.0*9.1 34.3*25.8*12.6 34.3*31.5*12.6
Net Weight Indoor kg(lbs) 11(24.5) 11(24.5) 17(37.5) 17(37.5)
Outdoor kg(lbs) 28(61.7) 28(61.7) 46(101.4) 60(132.3)
Gross Weight Indoor kg(lbs) 13(28.7) 13(28.7) 19(41.9) 19(41.9)
Outdoor kg(lbs) 30(66.1) 30(66.1) 53(116.8) 64(141.1)
Operation Range Cooling(Outdoor)
°C(°F) -5 ~48 (23 ~118.4) -5 ~48 (23 ~118.4) -10 ~48 (14 ~118.4) -10 ~48 (14 ~118.4)
Heating(Outdoor)
°C(°F) -10 ~24 (14 ~75.2) -10 ~24 (14 ~75.2) -10 ~24 (14 ~75.2) -10 ~24 (14 ~75.2)
Piping Length (Min/Max) m(ft) 3(9.84) / 15(49.2) 3(9.84) / 15(49.2) 7.5 (24.6) / 20(65.6) 7.5(24.6) / 30(98.4)
Chargeless m(ft) - - - -
Max. Elevation Difference m(ft) 7(23.0) 7(23.0) 15(49.2) 15(49.2)
Tool Code(Chassis) Indoor + Outdoor SB + UA3 SB + UA3 SC + UE SC + UE1+
Functions
Temperature Control Thermistor Thermistor Thermistor Thermistor
Plasma Filter - - - -
Prefilter(washable/anti-fungus) OOOO
Anti Allergy free filter OOOO
Deodorizer Filter(Triple Filter) OOOO
H1N1 Filter OOOO
AutoClean OOOO
CHAOS Wind(Auto Wind) OOOO
Steps, Fan/Cool/Heat 3/4/4 3/4/4 3/4/4 3/4/4
Airflow Direction Control(up& Down) Auto Auto Auto Auto
Airflow Direction Control(left & right) Manual Manual Manual Manual
Remote Controller Type Wireless LCD Wireless LCD Wireless LCD Wireless LCD
Setting Temperature
Range
Cooling 18°C ~ 30°C 18°C ~ 30°C 18°C ~ 30°C 18°C ~ 30°C
Heating 16°C ~ 30°C 16°C ~ 30°C 16°C ~ 30°C 16°C ~ 30°C
Auto Operation (Micom Control) - - - -
Auto Changeover (Micom Control) OOOO
Self Diagnosis OOOO
Timer 24h, On/Off 24h, On/Off 24h, On/Off 24h On/Off
SleepOperation OOOO
SoftDryOperation OOOO
Restart Delay(minute) 3333
Deice Control(Defrost) OOOO
HotStart OOOO
Jet Cool OOOO
Low Ambient Operation OOOO

3. Specifications
14 _ Inverter Single-60Hz(R410A)
Inverter Single
Inverter Single
Note : O : Applie, X : Not applied, – : No relation
• Filters are optional in some specific areas.
* For Circuit Breaker Rating, please conform to local standards whenever necessary.
Models Unit AS-Q092BRW0 AS-Q122BRW0 AS-Q182CRW0 AS-Q242CRW0
Cooling Capacity Btu/h. 3,070~9,000~11,600 3,070~12,000~13,600 3,070~18,000~19,500 3,070~22,000~24,000
kW 0.90~2.64~3.40 0.90~3.52~3.99 0.90~5.28~5.72 0.90 ~ 6.45 ~ 7.03
Power Input Cooling W 775 1030 1550 2010
Running Current Cooling A 3.7 4.9 7.2 9.4
Starting Current Cooling A 3.7 4.9 7.2 9.4
EER W/W 3.4 3.41 3.4 3.21
Btu/h.W 11.6 11.6 11.6 11
Power Supply Ø / V / Hz 1/220/60 1/220/60 1/220/60 1/220/60
Power Factor % 95.2 97.1 97.9 97.2
Air Flow Rate Indoor,Max
m3/min(CFM) 9.0 (318) 11.0 (388) 19.5(689) 19.5 (688)
Outdoor,Max m3/min(CFM) 28 (989) 28 (989) 50(1,766) 60 (2,119)
Moisture Removal l/h. 0.9 1.1 1.3 1.5
Sound Level Indoor,H/M/L dB(A)±3 38 / 33 / 23 / 19 39 / 33 / 23 / 19 42 / 40 / 35 / 29 45 / 40 / 35 / 29
Outdoor,Max dB(A)±3 48 48 53 53
Refrigerant & Charge (at 7.5 m) g(oz) R410A, 730 (26.5) R410A, 830 (29.3) R410A, 1,300(45.86) R410A, 1,650(58.2)
Additional Refrigerant charge g/m(oz/ft) 10(0.11) 10(0.11) 20(0.21) 20(0.21)
Compressor
Type Rotary Rotary Twin Rotary Twin Rotary
Model GA102MAA GA102MAA GKT141DAA GKT176DAA
Motor Type Brushless DC Motor Brushless DC Motor Brushless DC Motor Brushless DC Motor
Oil Type FVC68D FVC68D FVC68D FVC68D
Oil Charge cc 310 310 570 660
O.L.P. name - - - -
Fan(Indoor) Type Cross Flow Fan Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor Output W 20 20 20 20
Fan(Outdoor)
Type Propeller Propeller Propeller Propeller
MotorType ACACACAC
Motor Output W 24.5 24.5 79 79
Circuit Breaker* A 15 15 20 20
Power Supply Cable No.*mm23*1.0 3*1.0 3*1.5 3*2.5
Power and Transmission Cable No.*mm2 No.*mm24*1.0 (Including Earth) 4*1.0 (Including Earth) 4*1.0 (Including Earth) 4*1.0 (Including Earth)
Piping Connections Liquid Side mm(in) 6.35(1/4) 6.35(1/4) 6.35(1/4) 9.52(3/8)
Gas Side mm(in) 9.52(3/8) 9.52(3/8) 12.70(1/2) 15.88(5/8)
Drain Hose(O.D / I.D.) mm(in) 21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63)
Dimensions
Indoor (W*H*D) mm 885*285*210 885*285*210 1,030*325*250 1,030*325*250
inch 34.8*11.2*8.3 34.8*11.2*8.3 40.6*12.8*9.8 40.6*12.8*9.8
Outdoor (W*H*D) mm 717*499*230 717*499*230 870*655*320 870*800*320
inch 28.2*19.6*9.1 28.2*19.6*9.1 34.3*25.8*12.6 34.3*31.5*12.6
Net Weight Indoor kg(lbs) 10 (22.04) 10 (22.04) 17 (37.5) 17 (37.5)
Outdoor kg(lbs) 24 (52.91) 24 (52.91) 47 (103.6) 60 (132.3)
Gross Weight Indoor kg(lbs) 12 (26.45) 12 (26.45) 19 (41.9) 19 (41.9)
Outdoor kg(lbs) 26 (57.32) 26 (57.32) 49 (108.0) 62 (136.7)
Operation Range Cooling(Outdoor)
°C(°F) 18 ~ 48 ( 64.4 ~ 118.4) 18 ~ 48 ( 64.4 ~ 118.4) 18 ~ 48 ( 64.4 ~ 118.4) 18 ~ 48 ( 64.4 ~ 118.4)
Heating(Outdoor)
°C(°F) ----
Piping Length (Min/Max) m(ft) 7.5(24.6) / 15(49.2) 7.5(24.6) / 15(49.2) 7.5(24.6) / 20(65.6) 7.5(24.6) / 20(65.6)
Chargeless m(ft) - - - -
Max. Elevation Difference m(ft) 7 (22.96) 7 (22.96) 7 (22.96) 7 (22.96)
Tool Code(Chassis) Indoor + Outdoor SB + UA3 SB + UA3 SC + UE SC + UE1
Functions
Temperature Control Thermistor Thermistor Thermistor Thermistor
Plasma Filter - - - -
Prefilter(washable/anti-fungus) OOOO
Anti Allergy free filter OOOO
Deodorizer Filter(Triple Filter) OOOO
H1N1 Filter OOOO
AutoClean OOOO
CHAOS Wind(Auto Wind) OOOO
Steps, Fan/Cool/Heat -/4/- -/4/- -/4/- -/4/-
Airflow Direction Control(up& Down) Auto Auto Auto Auto
Airflow Direction Control(left & right) Manual Manual Manual Manual
Remote Controller Type Wireless LCD Wireless LCD Wireless LCD Wireless LCD
Setting Temperature
Range
Cooling 18°C ~ 30°C 18°C ~ 30°C 18°C ~ 30°C 18°C ~ 30°C
Heating - - - -
Auto Operation (Micom Control) OOOO
Auto Changeover (Micom Control) - - - -
Self Diagnosis OOOO
Timer 24h, On/Off 24h, On/Off 24h, On/Off 24h On/Off
SleepOperation OOOO
Soft Dry Operation OOOO
Restart Delay(minute) 3333
Deice Control(Defrost) - - - -
Hot Start - - - -
Jet Cool OOOO
Low Ambient Operation - - - -

Inverter Single-60Hz(R410A) _ 15
3. Specifications
Inverter Single
Inverter Single
Inverter Single, Libero ARTCOOL (#3)
Note : O : Applie, X : Not applied, – : No relation
• Filters are optional in some specific areas.
* For Circuit Breaker Rating, please conform to local standards whenever necessary.
Models AS-Q092BRZ0 AS-Q122BRZ0 AS-Q182CRZ0 AS-Q242CRZ1
Cooling Capacity Btu/h. 3,070~9,000~11,600 3,070~12,000~13,600 3,070~18,000~19,500 3,700 ~ 22,000 ~ 24,000
kW 0.90~2.64~3.40 0.90~3.52~3.99 0.90~5.28~5.72 1.08 ~ 6.45 ~ 7.03
Heating Capacity Btu/h.
kW
Power Input Cooling/Heating W 775 1030 1550 1,990
Running Current Cooling/Heating A 3.7 4.9 7.2 9.52
Starting Current Cooling/Heating A 3.7 4.9 7.2 9.52
EER W/W 3.4 3.41 3.4 3.24
Btu/h.W 11.6 11.6 11.6 11.06
COP W/W
Power Supply Ø / V / Hz 1/220/60 1/220/60 1/220/60 1/220/60
Power Factor % 95.2 97.1 97.9 95
Air Flow Rate Indoor,Max m3/min(CFM) 9.0 (318) 11.0 (388) 19.5(689) 19.5(689)
Outdoor,Max m3/min(CFM) 28 (989) 28 (989) 50(1,766) 50(1,766)
Moisture Removal l/h. 0.9 1.1 1.3 1.9
Sound Level Indoor,H/M/L dB(A)±3 38 / 33 / 23 / 19 39 / 33 / 23 / 19 42 / 40 / 35 / 29 45 / 40 / 35 / 29
Outdoor,Max dB(A)±3 48 48 53 53
Refrigerant & Charge (at 7.5 m) g(oz) R410A, 730 (26.5) R410A, 830 (29.3) R410A, 1,350(45.86) R410A, 1,245(43.92)
Additional Refrigerant charge g/m(oz/ft) 10(0.11) 10(0.11) 20(0.21) 30(0.32)
Compressor
Type Rotary Rotary Twin Rotary Twin Rotary
Model GA102MAA GA102MAA GKT141DAA GKT176MF
Motor Type Brushless DC Motor Brushless DC Motor Brushless DC Motor Brushless DC Motor
Oil Type FVC68D FVC68D FVC68D POE
Oil Charge cc 310 310 570 470
O.L.P. name ----
Fan(Indoor) Type Cross Flow Fan Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor Output W 20 20 20 30
Fan(Outdoor)
Type Propeller Propeller Propeller Propeller, Fan
Motor Type AC AC AC BLDC
Motor Output W 24.5 24.5 79 85
Circuit Breaker* A 15 15 20 20
Power Supply Cable No.*mm23*1.0 3*1.0 3*1.5 3*1.5
Power and Transmission Cable No.*mm2 No.*mm24*1.0 (Including Earth) 4*1.0 (Including Earth) 4*1.0 (Including Earth) 4*1.0 (Including Earth)
Piping Connections Liquid Side mm(in) 6.35(1/4) 6.35(1/4) 6.35(1/4) 6.35(1/4)
Gas Side mm(in) 9.52(3/8) 9.52(3/8) 12.70(1/2) 15.88(5/8)
Drain Hose(O.D / I.D.) mm(in) 21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63)
Dimensions
Indoor (W*H*D) mm 885*285*210 885*285*210 1,030*325*250 1,030*325*250
inch 34.84*11.22*8.26 34.84*11.22*8.26 40.6*12.8*9.84 40.6*12.8*9.84
Outdoor (W*H*D) mm 717*499*230 717*499*230 870*665*320 870*655*320
inch 28.22*19.64*9.05 28.22*19.64*9.05 34.3*26.2*12.6 34.3*27.4*12.6
Net Weight Indoor kg(lbs) 10 (22.04) 10 (22.04) 17 (37.5) 17 (37.5)
Outdoor kg(lbs) 24 (52.91) 24 (52.91) 47 (103.6) 48.3(106.48)
Operation Range Cooling(Outdoor) °C 18 ~ 48 ( 64.4 ~ 118.4) 18 ~ 48 ( 64.4 ~ 118.4) 18 ~ 48 ( 64.4 ~ 118.4) -10~48
Heating(Outdoor) °C ----
Piping Length (Min) m(ft) 7.5(24.6) 7.5(24.6) 7.5(24.6) 7.5(24.6)
Piping Length (Max) m(ft) 15(49.2) 15(49.2) 20(65.6) 20(65.6)
Chargeless m(ft) ----
Max. Elevation Difference m(ft) 7 (22.96) 7 (22.96) 7 (22.96) 10(32.8)
Tool Code(Chassis) Indoor + Outdoor SB + UA3 SB + UA3 SC + UE SC + UE
Functions
Temperature Control Thermistor Thermistor Thermistor Thermistor
PlasmaFilter ----
Prefilter(washable/anti-fungus) OOOO
3M multi protection filter OOOO
Anti Allergy free filter ----
Deodorizer Filter(Triple Filter) ----
H1N1 Filter ----
Auto Clean OOOO
CHAOS Wind(Auto Wind) OOOO
Steps, Fan/Cool/Heat -/4/- -/4/- -/4/- -/4/-
Airflow Direction Control(up& Down) Auto Auto Auto Auto
Airflow Direction Control(left & right) Manual Manual Manual Manual
Remote Controller Type
Wireless LCD(Better-Remocon) Wireless LCD(Better-Remocon) Wireless LCD(Better-Remocon) Wireless LCD(Better-Remocon)
Setting Temperature
Range
Cooling 18°C ~ 30°C 18°C ~ 30°C 18°C ~ 30°C 18°C ~ 30°C
Heating ----
Auto Operation (Micom Control) OOOO
Auto Changeover (Micom Control) ----
Self Diagnosis OOOO
Timer 24h, On/Off 24h, On/Off 24h, On/Off 24h On/Off
Sleep Operation OOOO
SoftDryOperation OOOO
Restart Delay(minute) 3333
Deice Control(Defrost) ----
HotStart ----
Jet Cool OOOO
Low Ambient Operation ----
Ionizer OOOO

3. Specifications
16 _ Inverter Single-60Hz(R410A)
Inverter Single
Inverter Single
Note : O : Applie, X : Not applied, – : No relation
• Filters are optional in some specific areas.
* For Circuit Breaker Rating, please conform to local standards whenever necessary.
Models
Cooling Capacity Btu/h.
kW
Heating Capacity Btu/h.
kW
Power Input Cooling/Heating W
Running Current Cooling/Heating A
Starting Current Cooling/Heating A
EER W/W
Btu/h.W
COP W/W
Power Supply Ø / V / Hz
Power Factor %
Air Flow Rate Indoor,Max m3/min(CFM)
Outdoor,Max m3/min(CFM)
Moisture Removal l/h.
Sound Level Indoor,H/M/L dB(A)±3
Outdoor,Max dB(A)±3
Refrigerant & Charge (at 7.5 m) g(oz)
Additional Refrigerant charge g/m(oz/ft)
Compressor
Type
Model
Motor Type
Oil Type
Oil Charge cc
O.L.P. name
Fan(Indoor) Type
Motor Output W
Fan(Outdoor)
Type
Motor Type
Motor Output W
Circuit Breaker* A
Power Supply Cable No.*mm2
Power and Transmission Cable No.*mm2 No.*mm2
Piping Connections Liquid Side mm(in)
Gas Side mm(in)
Drain Hose(O.D / I.D.) mm(in)
Dimensions
Indoor (W*H*D) mm
inch
Outdoor (W*H*D) mm
inch
Net Weight Indoor kg(lbs)
Outdoor kg(lbs)
Operation Range Cooling(Outdoor) °C
Heating(Outdoor) °C
Piping Length (Min) m(ft)
Piping Length (Max) m(ft)
Chargeless m(ft)
Max. Elevation Difference m(ft)
Tool Code(Chassis) Indoor + Outdoor
Functions
Temperature Control
Plasma Filter
Prefilter(washable/anti-fungus)
3M multi protection filter
Anti Allergy free filter
Deodorizer Filter(Triple Filter)
H1N1 Filter
Auto Clean
CHAOS Wind(Auto Wind)
Steps, Fan/Cool/Heat
Airflow Direction Control(up& Down)
Airflow Direction Control(left & right)
Remote Controller Type
Setting Temperature
Range
Cooling
Heating
Auto Operation (Micom Control)
Auto Changeover (Micom Control)
Self Diagnosis
Timer
Sleep Operation
Soft Dry Operation
Restart Delay(minute)
Deice Control(Defrost)
Hot Start
Jet Cool
Low Ambient Operation
Ionizer
AS-W092BRZ0 AS-W122BRZ0 AS-W182CRZ0 AS-W242CRZ1
3,070~8,500~12,600 3,070~12,000~13,800 3,070 ~ 18,000 ~ 20,500 3,700 ~ 22,000 ~ 24,000
0.90~2.49~3.70 0.90~3.52~4.04 0.90 ~ 5.28 ~ 6.00 1.08 ~ 6.45 ~ 7.03
3,070 ~ 11,000 ~ 14,000 3,070 ~ 14,000 ~ 17,400 3,070 ~ 22,000 ~ 30,700 3,700 ~ 22,000 ~ 25,000
0.89~3.22~4.10 0.89~4.10~5.10 0.90 ~ 6.45 ~ 9.00 1.08 ~ 6.45 ~ 7.40
600 / 770 1,010 / 1,050 1,500 / 1,650 1,990 / 1,785
2.70 / 3.50 4.60 / 4.80 6.9 / 7.5 9.52 / 8.54
2.70 / 3.50 4.60 / 4.80 6.9 / 7.5 9.52 / 8.54
4.15 3.48 3.52 3.24
14.2 12.7 12.0 11.1
4.19 3.91 3.91 3.61
1/220/60 1/220/60 1/220/60 1/220/60
97.4 95.5 98.8 95
12.0(423) 12.0(423) 19.5(689) 19.5(689)
27(953) 27(953) 50(1,766) 50(1,766)
1.1 1.3 1.9 1.9
38 / 33 / 23 / 19 39 / 33 / 23 / 19 42 / 40 / 35 / 29 45 / 40 / 35 / 29
47 47 51 53
R410A,900(31.75) R410A,900(31.75) R410A, 1,350(47.62) R410A, 1,245(43.92)
20(0.22) 20(0.22) 20(0.22) 30(0.32)
Rotary Rotary Twin Rotary Twin Rotary
GA102DBA GA102DBA GKT141DAA GKT176MF
Brushless DC Motor Brushless DC Motor Brushless DC Motor Brushless DC Motor
FVC68D FVC68D FVC68D POE
310 310 570 470
--- -
Cross Flow Fan Cross Flow Fan Cross Flow Fan Cross Flow Fan
20 20 20 30
Propeller Propeller Propeller Propeller, Fan
BLDC BLDC BLDC BLDC
43 43 84 85
15 15 20 20
3*1.0 3*1.0 3*1.5 3*1.5
4*1.0 (Including Earth) 4*1.0 (Including Earth) 4*1.0 (Including Earth) 4*1.0 (Including Earth)
6.35(1/4) 6.35(1/4) 6.35(1/4) 6.35(1/4)
9.52(3/8) 9.52(3/8) 12.70(1/2) 15.88(5/8)
21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63)
885*285*210 885*285*210 1,030*325*250 1,030*325*250
35.2*11.2*8.3 35.2*11.2*8.3 40.6*12.8*9.84 40.6*12.8*9.84
717*483*230 717*483*230 870*655*320 870*655*320
28.2*19.0*9.1 28.2*19.0*9.1 34.3*25.79*12.6 34.3*27.4*12.6
11(24.5) 11(24.5) 17(37.5) 17(37.5)
28(61.7) 28(61.7) 46(101.4) 43(94.8)
-5 ~ 48 -5 ~ 48 -10~48 18~48
-10 ~ 24 -10 ~ 24 -10~24 -5~24
3(9.84) 3(9.84) 7.5 (24.6) 7.5(24.6)
15(49.2) 15(49.2) 20(65.6) 20(65.6)
--- -
7(23.0) 7(23.0) 15(49.2) 10(32.8)
SB + UA3 SB + UA3 SC + UE SC + UE
Thermistor Thermistor Thermistor Thermistor
--- -
OOO O
OOO O
--- -
--- -
--- -
OOO O
OOO O
3/4/4 3/4/4 3/4/4 3/4/4
Auto Auto Auto Auto
Manual Manual Manual Manual
Wireless LCD(Better-Remocon) Wireless LCD(Better-Remocon) Wireless LCD(Better-Remocon) Wireless LCD(Better-Remocon)
18°C ~ 30°C 18°C ~ 30°C 18°C ~ 30°C 18°C ~ 30°C
16°C ~ 30°C 16°C ~ 30°C 16°C ~ 30°C 16°C ~ 30°C
--- -
OOO O
OOO O
24h, On/Off 24h, On/Off 24h, On/Off 24h On/Off
OOO O
OOO O
333 3
OOO O
OOO O
OOO O
OOO O
OOO O

Inverter Single-60Hz(R410A) _ 17
3. Specifications
Inverter Single
Inverter Single
Inverter Single, Mega2.0 (#3)
Note : O : Applie, X : Not applied, – : No relation
• Filters are optional in some specific areas.
* For Circuit Breaker Rating, please conform to local standards whenever necessary.
Models
Cooling Capacity Btu/h.
kW
Heating Capacity Btu/h.
kW
Power Input Cooling/Heating W
Running Current Cooling/Heating A
Starting Current Cooling/Heating A
EER W/W
Btu/h.W
COP W/W
Power Supply Ø / V / Hz
Power Factor %
Air Flow Rate Indoor,Max m3/min(CFM)
Outdoor,Max m3/min(CFM)
Moisture Removal l/h.
Sound Level Indoor,H/M/L dB(A)±3
Outdoor,Max dB(A)±3
Refrigerant & Charge (at 7.5 m) g(oz)
Additional Refrigerant charge g/m(oz/ft)
Compressor
Type
Model
Motor Type
Oil Type
Oil Charge cc
O.L.P. name
Fan(Indoor) Type
Motor Output W
Fan(Outdoor)
Type
Motor Type
Motor Output W
Circuit Breaker* A
Power Supply Cable No.*mm2
Power and Transmission Cable No.*mm2 No.*mm2
Piping Connections Liquid Side mm(in)
Gas Side mm(in)
Drain Hose(O.D / I.D.) mm(in)
Dimensions
Indoor (W*H*D) mm
inch
Outdoor (W*H*D) mm
inch
Net Weight Indoor kg(lbs)
Outdoor kg(lbs)
Operation Range Cooling(Outdoor) °C
Heating(Outdoor) °C
Piping Length (Min) m(ft)
Piping Length (Max) m(ft)
Chargeless m(ft)
Max. Elevation Difference m(ft)
Tool Code(Chassis) Indoor + Outdoor
Functions
Temperature Control
Plasma Filter
Prefilter(washable/anti-fungus)
3M multi protection filter
Anti Allergy free filter
Deodorizer Filter(Triple Filter)
H1N1 Filter
Auto Clean
CHAOS Wind(Auto Wind)
Steps, Fan/Cool/Heat
Airflow Direction Control(up& Down)
Airflow Direction Control(left & right)
Remote Controller Type
Setting Temperature
Range
Cooling
Heating
Auto Operation (Micom Control)
Auto Changeover (Micom Control)
Self Diagnosis
Timer
Sleep Operation
Soft Dry Operation
Restart Delay(minute)
Deice Control(Defrost)
Hot Start
Jet Cool
Low Ambient Operation
Ionizer
US-Q092WSZ2 US-Q122BSZ2 US-Q182CSZ2 US-Q242CSZ2
3,070 ~ 9,000 ~ 9,500 3,070~12,000~13,000 3,700 ~ 18,000 ~ 18,500 3,700 ~ 22,000 ~ 24,000
0.90~2.64~2.78 0.90~3.52~3.81 1.08 ~ 5.28 ~ 5.42 1.08 ~ 6.45 ~ 7.03
805 1,085 1,600 1,990
4.16 5.08 7.66 9.52
4.16 5.08 7.66 9.52
3.28 3.24 3.30 3.24
11.18 11.06 11.3 11.1
1/220/60 1/220/60 1/220/60 1/220/60
88 97 95 95
8(283) 10(353) 17.8 (629) 19.5 (689)
27(953) 27(953) 38 (1342) 50.0 (1,766)
0.83 0.95 1.62 1.9
39 / 33 / 25 / 19 39 / 33 / 25 / 19 42 / 40 / 35 / 29 45 / 40 / 35 / 29
47 47 51 53
R410A,650(22.9) R410A,800(28.2) R410A, 1,135(40.0) R410A, 1,245(43.92)
20(0.22) 20(0.22) 30(0.32) 30(0.32)
Rotary Rotary Twin Rotary Twin Rotary
GA092MAB GA092MAB GKT141MBA GKT176MFA
Brushless DC Motor Brushless DC Motor Brushless DC Motor Brushless DC Motor
POE POE FVC68D FVC68D
310 310 470 470
--- -
Cross Flow Fan Cross Flow Fan Cross Flow Fan Cross Flow Fan
20 20 20 20
Propeller Propeller Propeller Propeller, Fan
AC AC BLDC BLDC
26 26 43 85
15 15 20 20
3*1.0 3*1.0 3*1.5 3*1.5
4*0.75 (Including Earth) 4*0.75 (Including Earth) 4*0.75 (Including Earth) 4*0.75 (Including Earth)
6.35(1/4) 6.35(1/4) 6.35(1/4) 6.35(1/4)
9.52(3/8) 9.52(3/8) 12.70(1/2) 15.88(5/8)
21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63)
756 *265 * 184 885*285*210 1,030*325*250 1,030*325*250
29.8 *10.4*7.2 35.2*11.2*8.3 40.6*12.8*9.84 40.6*12.8*9.84
717*483*230 717*483*230 770*545*288 870*655*320
28.2*19.0*9.1 28.2*19.0*9.1 30.3*21.5*11.3 34.3*27.4*12.6
7.4(16.3) 9.0(19.8) 12.4(27.3) 12.6(27.9)
24.9(54.8) 25.0(55.1) 32.4(71.4) 41.8(92.2)
18 ~ 48 18 ~ 48 18 ~ 48 18 ~ 48
7.5 (24.6) 7.5 (24.6) 7.5 (24.6) 7.5(24.6)
15(49.2) 15(49.2) 20(65.6) 20(65.6)
--- -
7(23.0) 7(23.0) 10(32.8) 10(32.8)
SW + UA3 SB + UA3 SC + UL2 SC + UE
Thermistor Thermistor Thermistor Thermistor
--- -
OOO O
OOO O
--- -
--- -
--- -
OOO O
OOO O
3/4/- 3/4/- 3/4/- 3/4/-
Auto Auto Auto Auto
Manual Manual Manual Manual
Wireless LCD(Better-Remocon) Wireless LCD(Better-Remocon) Wireless LCD(Better-Remocon) Wireless LCD(Better-Remocon)
18°C ~ 30°C 18°C ~ 30°C 18°C ~ 30°C 18°C ~ 30°C
--- -
OOO O
--- -
OOO O
24h, On/Off 24h, On/Off 24h, On/Off 24h On/Off
OOO O
OOO O
333 3
--- -
--- -
OOO O
--- -
OOO O

3. Specifications
18 _ Inverter Single-60Hz(R410A)
Inverter Single
Inverter Single
Note : O : Applie, X : Not applied, – : No relation
• Filters are optional in some specific areas.
* For Circuit Breaker Rating, please conform to local standards whenever necessary.
Models
Cooling Capacity Btu/h.
kW
Heating Capacity Btu/h.
kW
Power Input Cooling/Heating W
Running Current Cooling/Heating A
Starting Current Cooling/Heating A
EER W/W
Btu/h.W
COP W/W
Power Supply Ø / V / Hz
Power Factor %
Air Flow Rate Indoor,Max m3/min(CFM)
Outdoor,Max m3/min(CFM)
Moisture Removal l/h.
Sound Level Indoor,H/M/L dB(A)±3
Outdoor,Max dB(A)±3
Refrigerant & Charge (at 7.5 m) g(oz)
Additional Refrigerant charge g/m(oz/ft)
Compressor
Type
Model
Motor Type
Oil Type
Oil Charge cc
O.L.P. name
Fan(Indoor) Type
Motor Output W
Fan(Outdoor)
Type
Motor Type
Motor Output W
Circuit Breaker* A
Power Supply Cable No.*mm2
Power and Transmission Cable No.*mm2 No.*mm2
Piping Connections Liquid Side mm(in)
Gas Side mm(in)
Drain Hose(O.D / I.D.) mm(in)
Dimensions
Indoor (W*H*D) mm
inch
Outdoor (W*H*D) mm
inch
Net Weight Indoor kg(lbs)
Outdoor kg(lbs)
Operation Range Cooling(Outdoor) °C
Heating(Outdoor) °C
Piping Length (Min) m(ft)
Piping Length (Max) m(ft)
Chargeless m(ft)
Max. Elevation Difference m(ft)
Tool Code(Chassis) Indoor + Outdoor
Functions
Temperature Control
Plasma Filter
Prefilter(washable/anti-fungus)
3M multi protection filter
Anti Allergy free filter
Deodorizer Filter(Triple Filter)
H1N1 Filter
Auto Clean
CHAOS Wind(Auto Wind)
Steps, Fan/Cool/Heat
Airflow Direction Control(up& Down)
Airflow Direction Control(left & right)
Remote Controller Type
Setting Temperature
Range
Cooling
Heating
Auto Operation (Micom Control)
Auto Changeover (Micom Control)
Self Diagnosis
Timer
Sleep Operation
Soft Dry Operation
Restart Delay(minute)
Deice Control(Defrost)
Hot Start
Jet Cool
Low Ambient Operation
Ionizer
US-W092WSZ2 US-W122BSZ2 US-W182CSZ2 US-W242CSZ2
3,070 ~ 9,000 ~ 9,500 3,070~12,000~13,000 3,700 ~ 18,000 ~ 18,500 3,700 ~ 22,000 ~ 24,000
0.90~2.64~2.78 0.90~3.52~3.81 1.08 ~ 5.28 ~ 5.42 1.08 ~ 6.45 ~ 7.03
3,070 ~ 9,000 ~ 9,900 3,070 ~ 12,000 ~ 13,600 3,700 ~ 19,000 ~ 23,000 3,700 ~ 22,000 ~ 24,500
0.90~2.64~2.90 0.90~3.52~3.99 1.08 ~ 5.57 ~ 6.74 1.08 ~ 6.45 ~ 7.18
805 / 730 1,085 / 950 1,600 / 1,540 1,990 / 1,785
4.16 / 3.77 5.08 / 4.45 7.66 / 7.37 9.52 / 8.54
4.16 / 3.77 5.08 / 4.45 7.66 / 7.37 9.52 / 8.54
3.28 3.24 3.30 3.24
11.18 11.06 11.3 11.1
3.61 3.7 3.62 3.61
1/220/60 1/220/60 1/220/60 1/220/60
88.0 97 95 95
8(283) 10(353) 17.8 (629) 19.5 (689)
27(953) 27(953) 38 (1342) 50.0 (1,766)
0.83 0.95 1.6 1.9
39 / 33 / 25 / 19 39 / 33 / 25 / 19 42 / 40 / 35 / 29 45 / 40 / 35 / 29
47 47 51 53
R410A,650(22.9) R410A,800(28.2) R410A, 1,135(40.0) R410A, 1,245(43.92)
20(0.22) 20(0.22) 30(0.32) 30(0.32)
Rotary Rotary Twin Rotary Twin Rotary
GA092MAB GA092MAB GKT141MBA GKT176MF
Brushless DC Motor Brushless DC Motor Brushless DC Motor Brushless DC Motor
POE POE FVC68D FVC68D
310 310 470 470
--- -
Cross Flow Fan Cross Flow Fan Cross Flow Fan Cross Flow Fan
20 20 20 20
Propeller Propeller Propeller Propeller, Fan
AC AC BLDC BLDC
26 26 43 85
15 15 20 20
3*1.0 3*1.0 3*1.5 3*1.5
4*0.75 (Including Earth) 4*0.75 (Including Earth) 4*0.75 (Including Earth) 4*0.75 (Including Earth)
6.35(1/4) 6.35(1/4) 6.35(1/4) 6.35(1/4)
9.52(3/8) 9.52(3/8) 12.70(1/2) 15.88(5/8)
21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63) 21.5 / 16.0(0.85 / 0.63)
756 *265 * 184 885*285*210 1,030*325*250 1,030*325*250
29.8 *10.4*7.2 35.2*11.2*8.3 40.6*12.8*9.84 40.6*12.8*9.84
717*483*230 717*483*230 770*545*288 870*655*320
28.2*19.0*9.1 28.2*19.0*9.1 30.3*21.5*11.3 34.3*27.4*12.6
7.4(16.3) 9.0(19.8) 12.4(27.3) 12.6(27.9)
24.9(54.8) 25.0(55.1) 32.4(71.4) 41.8(92.2)
18 ~ 48 18 ~ 48 18 ~ 48 18 ~ 48
-5 ~ 24 -5 ~ 24 -5 ~ 24 -5 ~ 24
7.5 (24.6) 7.5 (24.6) 7.5 (24.6) 7.5(24.6)
15(49.2) 15(49.2) 20(65.6) 20(65.6)
7.5 7.5 7.5 7.5
7(23.0) 7(23.0) 10(32.8) 10(32.8)
SW + UA3 SB + UA3 SC + UL2 SC + UE
Thermistor Thermistor Thermistor Thermistor
--- -
OOO O
OOO O
--- -
--- -
--- -
OOO O
OOO O
3/4/4 3/4/4 3/4/4 3/4/4
Auto Auto Auto Auto
Manual Manual Manual Manual
Wireless LCD(Better-Remocon) Wireless LCD(Better-Remocon) Wireless LCD(Better-Remocon) Wireless LCD(Better-Remocon)
18°C ~ 30°C 18°C ~ 30°C 18°C ~ 30°C 18°C ~ 30°C
16°C ~ 30°C 16°C ~ 30°C 16°C ~ 30°C 16°C ~ 30°C
--- -
OOO O
OOO O
24h, On/Off 24h, On/Off 24h, On/Off 24h On/Off
OOO O
OOO O
333 3
OOO O
OOO O
OOO O
--- -
OOO O

Inverter Single-60Hz(R410A) _ 19
Inverter Single
Inverter Single
Hero
CHASSIS CODE : SH
210
210
290
51
104.5
50
798
Ø70
Ø70
100 145
Right rear
piping
Left rear piping
Place a level on raised tab
Unit Outline
199
148
399 399
Installation Plate
Measuring Tape
Measuring Tape
Hanger
5
4
2
3
1
4. Dimensional drawings
4.1 Indoor Units
[Unit : mm]

Ø70
Ø70
133 95
Right rear piping
Left rear piping
Installation Plate
Place a level on raised tab
Unit Outline
217
175
442 442
Libero R / E
CHASSIS CODE : SB
210
3
885
210
285
2
1
4
50.5
59.5
159.5
23
5
[Unit : mm]
4. Dimensional drawings
20 _ Inverter Single-60Hz(R410A)
Inverter Single
Inverter Single
