LG Art Cool LA240HSV2 Manual

Date:
JobName/Location:
PONo.:
Architect:
Engr:
GC:
Rep:
For: File
A
pp
roval
Mech:
Resubmit
Other
Tag#:
(Company) (ProjectManager)
ArtCool™SingleZoneInverter
LA240HSV2
Page1of3DFS‐SB‐AA‐030‐US012H29
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
LGElectronicsU.S.A.,Inc.,EnglewoodCliffs,NJ.Allrightsreserved.“LGLife’sGood”isaregisteredtrademarkofLGCorp./www.lghvac.com
Performance:
Capacity(Btu/h) 22,000
SEER 20.0
EER 10.8
Cooling:
Heating:
Capacity(Btu/h) 27,600
HSPF 10.0
CoolingNominalTestConditions: HeatingNominalTestConditions:
Indoor: 80°FDB/67°FWB Indoor: 70°FDB/60°FWB
Outdoor: 95°FDB/75°FWB Outdoor: 47°FDB/43°FWB
Electrical:
MCA(A) 19
MOP(A) 30
FanMotor(A) 0.75
OutdoorUnit:
CoolingRatedAmps(A) 17.0
HeatingRatedAmps(A) 17.0
IndoorUnit:
CoolingPowerInput(kW) 2.04
HeatingPowerInput(kW) 1.67
Piping:
LiquidLine(in,OD) 3/8
AdditionalRefrigerant(oz/ft) 0.38
MaxElevation(ft) 49
PipingLength(noadd'lrefrigerant,ft) 25
PowerSupply(V¹/Hz/Ø) 208‐230/60/1
MaxPipeLength(ft)² 98
Compressor(A) 14.6
VaporLine(in,OD) 5/8
Features:
OperatingRange:
OutdoorUnit:
IndoorUnit:
UnitData:
RefrigerantType R410A
RefrigerantCharge(lbs) 3.97
Fan:
StandardFeatures:
•LimitedFiveYearCompressorWarranty
•LimitedThreeYearFunconalPartsWarranty
Notes:
1.Acceptableoperangvoltage:187V‐253V.
2.Pipinglengthsareequivalent.
3.SoundPressurelevelsaretestedinananechoicchamberunderISOStandard1996.
4.Allcommunicaoncabletobeminimum18AWG,2‐conductor,stranded,shieldedandmust
complywithapplicablelocalandnationalcode.
5.SeeEngineeringManualforsensibleandlatentcapacies.
6.Powerwiringcablesizemustcomplywiththeapplicablelocalandnaonalcode.
7.Theindoorunitcomeswithadryheliumcharge.
8.Thisdataisrated0abovesealevel,with24.6ofrefrigerantlineanda0leveldifference
betweenoutdoorandindoorunits.
9.
Must follow installaon instrucons in the applicable LG installaon manual.
ODUType Propeller
IDUType CrossFlow
Motor/Drive BrushlessDigitallyControlled/Direct
Dehumidification(pts/hr) 5.5
RefrigerantControl EEV
HeatExchangerCoating GoldFin™
ODUNetUnitWeight(lbs) 133
ODUShippingWeight(lbs) 142
IDUNetUnitWeight 38
IDUShippingWeight(lbs) 42
FanSpeeds(Fan/Cooling/Heating) 5/6/6
Quantity(ODU+IDU) 1+1
IDUMaxAirFlowH/M/L(CFM) 600/510/420
ODUMaxAirFlowRate(CFM) 2,119
CommunicationCable(NoxAWG)⁴4x18
Cooling(°FDB) 14‐118
Heating(°FDB) 5‐75
Cooling(°FDB) 64‐90
Heating(°FDB) 61‐86
ODUSoundPressureMax(±3dB(A))³ 53
IDUSoundPressure(H/M/L)(±3dB(A))³ 45/40/35
PowerSupply(V¹/Hz/Ø) 208‐230/60/1
OptionalAccessories(soldseparately):
7‐DayProgrammableController(Black)‐PQRCVSL0
7‐DayProgrammableController(White)‐PQRCVSL0QW
IndoorUnit(IDU)‐LAN240HSV2OutdoorUnit(ODU)‐LAU240HSV2
PI485‐PMNFP14A0
SEER‐SeasonalEnergyEfficiencyRatioEER‐EnergyEfficiencyRatio
HSPF‐HeatingSeasonalPerformanceFactor
MOP‐MaximumOvercurrentProtection MCA‐MinimumCircuitAmpacity
•4‐Wayautoswing
•24‐Houron/offmer
•Autorestart
•Autochangeover
•Built‐inlowambient
standard,downto14°F
(coolingmode)
•Jetcool/Jetheat
•Plasmaairpurifying
system
•Self‐cleaningindoorcoil
•Sleepmode
•Ultraquietoperaon
•Chaoswind
•CondensateSensor
Connection
•Energysaving
•Inverter(variablespeed
compressor)
DryContactforthirdpartythermostat‐PQDSBNGCM1
AWG‐AmericanWireGage

JobName/Location:
Tag#:
Date:
PONo.:
ArtCool™SingleZoneInverter
Page2of3DFS‐SB‐AA‐030‐US012H29
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
LGElectronicsU.S.A.,Inc.,EnglewoodCliffs,NJ.Allrightsreserved.“LGLife’sGood”isaregisteredtrademarkofLGCorp./www.lghvac.com
OutdoorUnit
(
ODU
)
‐LAU240HSV2

JobName/Location:
Tag#:
Date:
PONo.:
ArtCool™SingleZoneInverter
Page3of3
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
LGElectronicsU.S.A.,Inc.,EnglewoodCliffs,NJ.Allrightsreserved.“LGLife’sGood”isaregisteredtrademarkofLGCorp./www.lghvac.com DFS‐SB‐AA‐030‐US012H29
IndoorUnit(IDU)‐LAN240HSV2
