Service Manual
LG-D410
Date: March, 2014 / Issue 1.0

- 2 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Table Of Contents
1. INTRODUCTION..................................................................... 3
1.1 Purpose ........................................................................................................3
1.2 Regulatory Information.........................................................................3
2. PERFORMANCE...................................................................... 5
2.1 Product Name............................................................................................5
2.2 Supporting Standard..............................................................................5
2.3 Main Parts : GSM Solution.....................................................................5
2.4 HW Features ...............................................................................................6
2.5 SW Features................................................................................................9
2.6 HW SPEC. ................................................................................................. 12
3. TROUBLE SHOOTING .......................................................... 21
3.1 RF Component ....................................................................................... 21
3.2 SIGNAL PATH........................................................................................... 23
3.3 Checking XO Block................................................................................ 26
3.4 Checking FEMID (GSM, W B1/B2/B8) Block................................. 28
3.5 Checking WCDMA Block .................................................................... 31
3.6 Checking GSM Block............................................................................ 58
3.7 GPS/WIFI/BT............................................................................................. 65
3.8 GPS/WIFI/BT SIGNAL PATH ................................................................ 67
3.9 Checking GPS/WIFI/BT........................................................................ 69
3.10 Audio Trouble....................................................................................... 75
3.11 Main CameraTrouble Shooting.................................................... 85
3.12 Main LCD Trouble Shooting ........................................................... 88
3.13 Touch troubleshooting..................................................................... 90
3.14 Compass sensor troubleshooting................................................ 93
3.15 Proximity Sensor troubleshooting............................................... 95
3.16 Power ON Troubleshooting............................................................ 97
3.17 Charging Troubleshooting............................................................100
3.18 USBTrouble shooting.....................................................................103
4. DOWNLOAD.......................................................................108
5. BLOCK DIAGRAM...............................................................125
6. CIRCUIT DIAGRAM ............................................................135
7. BGA PIN MAP ....................................................................151
8. PCB LAYOUT.......................................................................158
9. CALIBRATION.....................................................................162
10. HIDDEN MENU.................................................................181
11. DISASSEMBLE GUIDE......................................................188
12. EXPLODED VIEW & REPLACEMENT PART LIST .............193
12.1 Exploded View ...................................................................................193
12.2 Replacement Parts ...........................................................................194
12.3 Accessory .............................................................................................225

- 3 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
LGE Internal Use Only
1.1 Purpose
This manual provides the information necessary to repair, calibration, description and download the features of
this model.
1.2 Regulatory Information
A. Security
Toll fraud, the unauthorized use of telecommunications system by an unauthorized part (for example, persons
other than your company’s employees, agents, subcontractors, or person working on your company’s behalf)
can result in substantial additional charges for your telecommunications services.
System users are responsible for the security of own system. There are may be risks of toll fraud associated with
your telecommunications system. System users are responsible for programming and configuring the
equipment to prevent unauthorized use. The manufacturer does not warrant that this product is immune from
the above case but will prevent unauthorized use of common carrier telecommunication service of facilities
accessed through or connected to it. The manufacturer will not be responsible for any charges that result from
such unauthorized use.
B. Incidence of Harm
If a telephone company determines that the equipment provided to customer is faulty and possibly causing
harm or interruption in service to the telephone network, it should disconnect telephone service until repair can
be done. A telephone company may temporarily disconnect service as long as repair is not done.
C. Changes in Service
A local telephone company may make changes in its communications facilities or procedure. If these changes
could reasonably be expected to affect the use of the phones or compatibility with the net work, the telephone
company is required to give advanced written notice to the user, allowing the user to take appropriate steps to
maintain telephone service.
D. Maintenance Limitations
Maintenance limitations on the phones must be performed only by the manufacturer or its authorized agent.
The user may not make any changes and/or repairs expect as specifically noted in this manual. Therefore, note
that unauthorized alternations or repair may affect the regulatory status of the system and may void any
remaining warranty.
1. INTRODUCTION

- 4 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
LGE Internal Use Only
E. Notice of Radiated Emissions
This model complies with rules regarding radiation and radio frequency emission as defined by local regulatory
agencies. In accordance with these agencies, you may be required to provide information such as the following
to the end user.
F. Pictures
The pictures in this manual are for illustrative purposes only; your actual hardware may look slightly different.
G. Interference and Attenuation
A phone may interfere with sensitive laboratory equipment, medical equipment, etc. Interference from
unsuppressed engines or electric motors may cause problems.
H. Electrostatic Sensitive Devices
ATTENTION
Boards, which contain Electrostatic Sensitive Device (ESD), are indicated by the sign.
Following information is ESD handling:
• Service personnel should ground themselves by using a wrist strap when exchange system boards. • When
repairs are made to a system board, they should spread the floor with anti-static mat which is also grounded.
• Use a suitable, grounded soldering iron. • Keep sensitive parts in these protective packages until these are used.
• When returning system boards or parts like EEPROM to the factory, use the protective package as described.

2. PERFORMANCE
- 5 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
2. PERFORMANCE
LGE Internal Use Only
2.1 Product Name
LG- D410 : WCDMA900/1900/2100+EGSM/GSM850/DCS1800/PCS1900(HSPA + / GPRS Class 12 / EDGE Class 12)
2.2 Supporting Standard
Item Feature Comment
Supporting Standard WCDMA(FDD1,2,8)/
EGSM/GSM850/DCS1800/PCS1900
Frequency Range WCDMA(FDD1) TX: 1920 – 1980 MHz
WCDMA(FDD1) RX: 2110 – 2170 MHz
WCDMA(FDD2) TX: 1852.4– 1907.6 MHz
WCDMA(FDD2) RX: 1932.4 – 1987.6 MHz
WCDMA(FDD8) TX: 880–915 MHz
WCDMA(FDD8) RX: 925 – 960 MHz
EGSM TX : 880 – 915 MHz
EGSM RX : 925 – 960 MHz
GSM850 TX : 824 – 849 MHz
GSM850 RX : 869 – 894 MHz
DCS1800 TX : 1710 – 1785 MHz
DCS1800 RX : 1805 – 1880 MHz
PCS1900 TX : 1850 – 1910 MHz
PCS1900 RX : 1930 – 1990 MHz
Application Standard WAP 2.0
2.3 Main Parts : GSM Solution
Item Part Name Comment
Digital Baseband MSM8226: Qualcomm
Analog Baseband MSM8226 : Qualcomm
RF Chip WTR2605 : Qualcomm
2.1 Product Name
LG- D410 : WCDMA900/1900/2100+EGSM/GSM850/DCS1800/PCS1900(HSPA + / GPRS Class 12 / EDGE Class 12)
2.2 Supporting Standard
2.3 Main Parts : GSM Solution
LGE Internal Use Only
2.1 Product Name
LG- D410 : WCDMA900/1900/2100+EGSM/GSM850/DCS1800/PCS1900(HSPA + / GPRS Class 12 / EDGE Class 12)
2.2 Supporting Standard
Item Feature Comment
Supporting Standard WCDMA(FDD1,2,8)/
EGSM/GSM850/DCS1800/PCS1900
Frequency Range WCDMA(FDD1) TX: 1920 – 1980 MHz
WCDMA(FDD1) RX: 2110 – 2170 MHz
WCDMA(FDD2) TX: 1852.4– 1907.6 MHz
WCDMA(FDD2) RX: 1932.4 – 1987.6 MHz
WCDMA(FDD8) TX: 880–915 MHz
WCDMA(FDD8) RX: 925 – 960 MHz
EGSM TX : 880 – 915 MHz
EGSM RX : 925 – 960 MHz
GSM850 TX : 824 – 849 MHz
GSM850 RX : 869 – 894 MHz
DCS1800 TX : 1710 – 1785 MHz
DCS1800 RX : 1805 – 1880 MHz
PCS1900 TX : 1850 – 1910 MHz
PCS1900 RX : 1930 – 1990 MHz
Application Standard WAP 2.0
2.3 Main Parts : GSM Solution
Item Part Name Comment
Digital Baseband MSM8226: Qualcomm
Analog Baseband MSM8226 : Qualcomm
RF Chip WTR2605 : Qualcomm

2. PERFORMANCE
- 6 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
2.4HW Features
Item Part Name Comment
Form Factor DOP type
Battery 1) Capacity
Standard : Li-Ion, 2540mAh
2) Packing Type : Changeable
Size Standard :133.55 x 66.02 x 9.65
Weight 124g With Battery
Volume 62cc Without Batter
PCB 10Any Layers , 0.8t
Charging time 4.3hrs @ Power Off / 2540mAh
RX sensitivity WCDMA(FDD1) : -106.7dBm
WCDMA(FDD2) : -106.7dBm
WCDMA(FDD8) : -103.7dBm
EGSM : -105dBm
GSM850 : -105dBm
DCS 1800 : -105dBm
PCS 1900 : -105dBm
TX
output
power
WCDMA/
GSM/
GPRS
WCDMA : 24dBm/3.84MHz,+1/-3dBm
EGSM : 33 dBm
GSM850 : 33dBm
DCS 1800 : 30dBm
PCS 1900 : 30dBm
Class3(WCDMA)
Class4 (EGSM)
Class4 (GSM850)
Class1 (PCS)
Class1 (DCS)
EDGE GSM850 : 27dBm
GSM 900 : 27 dBm
DCS 1800 : 26 dBm
PCS 1900 : 26 dBm
E2 (GSM900)
E2 (PCS)
E2 (DCS)
GPRS compatibility GPRS Class 12
EDGE compatibility EDGE Class 12
SIM card type Plug-In SIM
3V /1.8V
Display Main LCD(qHD)
TFT Main LCD(4. 7”,960 x 540)
Built-in Camera 5M AF / VGA VT
2.4 HW Features

2. PERFORMANCE
- 7 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
Status Indicator N/A
Keypad Function Key : 4
Side Key : 3
Function Key:
Home,Back,
menu,
SIM-switch
Side Key : Volume
up,down, power key
ANT Main : Internal Fixed Type
System connector 5 Pin micro USB
Ear Phone Jack 3.5Phi, 4 Pole, Stereo
PC synchronization Yes
Memory NAND Flash : 8GByte
SDRAM : 1GByte
Speech coding FR, EFR, HR,AMR
Data & Fax Built in Data & Fax support
Vibrator Built in Vibrator
BlueTooth V4.0
MIDI(for Buzzer
Function)
128 Poly
Music Player MP3,AAC,(e)AAC+,WMA,RA,WAV
Video Player Playback : 30fps 1080p (H.264/263, MPEG4/2,
WMV9, VC1, VP8, DivX, XVID)
Recording : 30fps 1080p (H.264/263, MPEG4/8)
30fps 720p (Wi-Fi display)
Camcorder MPEG4/8
Voice Recording Yes
Speaker Phone mode
Support
Yes
Travel Adapter Yes In-box item
CDROM No
Stereo Headset Yes
Data Cable Yes In-box item
T-Flash(External
Memory)
Yes

2. PERFORMANCE
- 8 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
Specification
GSM WCDMA
Stand by current
(Sleep & Idle Avg.)
Under 4.5mA@ P.P 5 Under 4.5mA @ DRX 7
Talk current
Under 400 mA
@GSM Level 5
Under 600mA
@ Max Power Avg.
Under 400 mA
@ Tx -10dBm Avg.

2. PERFORMANCE
- 9 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
2.5 SW Features
Item Feature Comment
RSSI 0 ~ 5 Levels
Battery Charging 0 ~ 20 Levels
Key Volume 0 ~ 7 Level
Audio Volume 1 ~ 15 Level
Time / Date Display Yes
Multi-Language Yes Support total 41 languages
[English/Spanish/French/Korean/Chi
nese(Simplified)/Chinese(Traditional
)/…]
Quick Access Mode Phone / Messaging / Browser/
Applications
Phone / Contact / Messaging /
Applications
PC Sync Yes
Speed Dial Yes Voice mail center -> 1 key
Profile Yes not same with feature phone setting
CLIP / CLIR Yes
Phone Book Name / Number / Email / Groups /
Postal addresses / Organizations / IM
/ Note / Nickname / Website / Event /
There is no limitation on the number
of items.
It depends on available memory
amount.
Last Dial Number Yes
Last ReceivedNumber Yes
Last Missed Number Yes
Search by
Number/Name
Yes
Group Yes There is no limitation on the number
of items.
It depends on available memory
amount.
Fixed Dial Number Yes
Service Dial Number No
2.5 SW Features

2. PERFORMANCE
- 10 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
Own Number Yes My Profile (add/edit/delete are
supported)
Voice Memo Yes Support voice recorder
Call Reminder No
Network Selection Automatic
Mute Yes
Call Divert Yes
Call Barring Yes
Call Charge (AoC) No
Call Duration Yes
SMS (EMS) There is no limitation on the number
of items.
It depends on available memory
amount.
EMS does not support.
SMS Over GPRS Yes
EMS Melody / Picture
Send / Receive / Save
No
MMS MPEG4
Send /Receive / Save
Yes
Long Message MAX 2000 characters The standard of Open vender
Cell Broadcast Yes
Download Over the Web
Game No
Calendar Yes
Memo Yes There is no limitation on the number
of items.
It depends on available memory
amount.
World Clock Yes
Unit Convert No
Stop Watch Yes
Wall Paper Yes
WAP Browser No Support only web browser based on
webkit. WAP stack and wml are not

2. PERFORMANCE
- 11 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
supported.
Download Melody /
Wallpaper
Yes Over web browser
SIM Lock No
SIM Toolkit No
MMS Yes Google MMS Client
EONS Yes
CPHS Yes V4.2
ENS Yes
Camera Yes 8M AF /
Digital Zoom : x4
JAVA No
Voice Dial No US English only
IrDa Yes
Bluetooth Yes Ver. 4.0 [HSP, HFP, A2DP, AVRCP, PBAP,
FTP(Server only), OPP, MAP, HID,
PAN]
FM radio Yes
GPRS Yes Class 12
EDGE Yes Class 12
Hold / Retrieve Yes
Conference Call Yes Max. 6
DTMF Yes
Memo pad No
TTY No
AMR Yes
SyncML No
IM Yes Google Talk
Email Yes
Item Feature Comment

2. PERFORMANCE
- 12 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
2.6 HW SPEC.
1) GSM transceiverspecification
Item Specification
Phase Error Rms : 5°/ Peak : 20 °
Frequency Error GSM : 0.1 ppm
DCS/PCS : 0.1 ppm
EMC(Radiated Spurious Emission
Disturbance) GSM/DCS : < -28dBm
Transmitter Output power and Burst
Timing
GSM : 5dBm – 33dBm ± 2dB
DCS/PCS : 0dBm – 30dBm ± 2dB
Burst Timing <3.69us
Spectrum due to modulation out to
less than 1800kHz offset
200kHz : -36dBm
600kHz : -51dBm/-56dBm
Spectrum due to modulation out to
larger than 1800kHz offset to the
edge of the transmit band
GSM :
1800-3000kHz :< -63dBc(-46dBm)
3000kHz-6000kHz : <-65dBc(-46dBm)
6000kHz < : < -71dBc(-46dBm)
DCS :
1800-3000kHz :< -65dBc(-51dBm)
6000kHz < : < -73dBc(-51dBm)
Spectrum due to switching transient 400kHz : -19dBm/-22dBm(5/0),
600kHz : -21dBm/-24dBm(5/0),
Reference Sensitivity – TCH/FS Class II(RBER) : -105dBm(2.439%)
Usable receiver input level range 0.012(-15 - -40dBm)
Intermodulation rejection – Speech
channels
± 800kHz, ± 1600kHz
: -98dBm/-96dBm (2.439%)
AM Suppression
-GSM : -31dBm
- DCS : -29dBm
-98dBm/-96dBm (2.439%)
Timing Advance ± 0.5T
2.6 HW SPEC.
1) GSM transceiverspecication

2. PERFORMANCE
- 13 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
2) WCDMA transmitter specification
Item Specification
Transmit Frequency Band1 : 1920 MHz ~ 1980 MHz
Band2 : 1852 MHz ~ 1907.6 MHz
Band8 :880MHz ~ 915MHz
Maximum Output Power +24dBm / 3.84 MHz, +1 / -3 dB
Frequency Error within ±0.1 PPM
Open Loop Power Control Normal Conditions : within ±9 dB,
Extreme Conditions : within ±12 dB
Minimum Transmit Power < -50 dBm /3.84 MHz
Occupied Bandwidth < 5 MHz at 3.84 Mcps (99% of power)
Adjacent Channel Leakage
Power Ratio (ACLR)
> 33 dB @ ±5 MHz,
> 43 dB @ ±10 MHz
Spurious Emissions
|f-fc| > 12.5 MHz
< -36 dBm / 1 kHz RW @ 9 kHz ≤ f < 150 kHz
< -36 dBm / 10 kHz RW @ 150 KHz ≤ f < 30 MHz
< -36 dBm / 100 kHz RW @ 30 MHz ≤ f < 1 GHz
< -30 dBm / 1 MHz RW @ 1 GHz ≤ f < 12.75 GHz
< -60 dBm / 3.84 MHz RW @ 880 MHz ≤ f ≤ 915 MHz
< -60 dBm / 3.84 MHz RW @ 1920 MHz ≤ f ≤ 1980 MHz
< -67 dBm / 100 kHz RW @ 925 MHz ≤ f ≤ 935 MHz
< -79 dBm / 100 kHz RW @ 935 MHz < f ≤ 960 GHz
< -71 dBm / 100 kHz RW @ 1805 MHz ≤ f ≤ 1880 MHz
< -41 dBm / 300 kHz RW @ 1884.5 MHz < f < 1919.6 MHz
Transmit Intermodulation < -31 dBc @ 5 MHz &< -41 dBc @ 10 MHz
when Interference CW Signal Level = -40 dBc
Error Vector Magnitude < 17.5 %, when Pout ≥ -20 dBm
Peak Code Domain Error < -15 dB at Pout -20 dBm
2) WCDMA transmitter specication

2. PERFORMANCE
- 14 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
3) WCDMA receiver specification
Item Specification
Receive Frequency
Band1 : 2110 MHz ~ 2170 MHz
Band2 : 1932.4 MHz ~ 1987.6 MHz
Band8 :925MHz ~ 960MHz
Reference Sensitivity Level Band1 : BER < 0.001 when Îor = -106.7 dBm / 3.84 MHz
Band8 : BER < 0.001 when Îor = -103.7 dBm / 3.84 MHz
Maximum Input Level BER < 0.001 when Îor = -25 dBm / 3.84 MHz
Adjacent Channel Selectivity
(ACS)
ACS > 33 dB where BER < 0.001 when
Îor = -92.7 dBm / 3.84 MHz
&Ioac = –52 dBm / 3.84 MHz @ ±5 MHz
Blocking Characteristic
BER < 0.001 when Îor = -103.7 dBm / 3.84 MHz
&Iblocking = -56 dBm / 3.84 MHz @ Fuw(offset) = ±10 MHz
orIblocking = -44 dBm / 3.84 MHz @ Fuw(offset) = ±15 MHz
Spurious Response BER < 0.001 when Îor = -103.7 dBm / 3.84 MHz
&Iblocking = -44 dBm
Intermodulation
BER < 0.001 when Îor= -103.7 dBm / 3.84 MHz
& Iouw1 = -46 dBm @ Fuw1(offset) = ±10 MHz
& Iouw2 = -46 dBm / 3.84 MHz @ Fuw2(offset) = ±20 MHz
Spurious Emissions < -57 dBm / 100 kHz BW @ 9 kHz ≤ f < 1 GHz
< -47 dBm / 1 MHz BW @ 1 GHz ≤ f ≤ 12.75 GHz
Inner Loop Power Control
In Uplink
Adjust output(TPC command)
cmd 1dB 2dB 3dB
+1 +0.5/1.5 +1/3 +1.5/4
0 -0.5/+0.5 -0.5/+0.5 -0.5/+0.5
-1 -0.5/-1.5 -1/-3 -1.5/-4
group(10equal command group)
+1 +8/+12 +16/+24
3) WCDMA receiver specication

2. PERFORMANCE
- 15 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
4) HSDPA transmitter specication
LGE Internal Use Only
4) HSDPA transmitter specification
Item Specification
Transmit Frequency
Band1 : 1920 MHz ~ 1980 MHz
Band2 : 1852 MHz ~ 1907.6 MHz
Band8 : 880MHz ~ 915MHz
Maximum Output Power
Sub-
T
est
1=1/15, 2=12/15 21~25dBm / 3.84 MHz
3=13/15 4=15/8 20~25dBm / 3.84 MHz
5=15/7 6=15/0 19~25dBm / 3.84 MHz
HS-DPCCH
Sub-
test in
table
C.10.1.4
Power
step
Power step
slot boundary
Power
step
size, P
[dB]
Transmitter power
step tolerance [dB]
5
1 Start of
Ack/Nack 6 +/- 2.3
2 Start of CQI 1 +/- 0.6
3 Middle of CQI 0 +/- 0.6
4 End of CQI 5 +/- 2.3
Spectrum Emission Mask
Sub-Test : 1=1/15, 2=12/15, 3=13/15, 4=15/8, 5=15/7, 6=15/0
Frequency offset
from carrier ᇞf Minimum requirement Measurement
Bandwidth
2.5 ~ 3.5 MHz -35-15×(ᇞf-2.5)dBc 30 kHz
3.5 ~ 7.5 MHz -35-1×(ᇞf-3.5)dBc 1 MHz
7.5 ~ 8.5 MHz -35-10×(ᇞf-7.5)dBc 1 MHz
8.5 ~ 12.5 MHz -49dBc 1 MHz
Adjacent Channel
Leakage
Power Ratio (ACLR)
Sub-Test : 1=1/15, 2=12/15, 3=13/15, 4=15/8, 5=15/7, 6=15/0
> 33 dB @ ±5 MHz
> 43 dB @ ±10 MHz
Error Vector Magnitude < 17.5 %, when Pout ≥ -20 dBm

2. PERFORMANCE
- 16 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
5) HSDPA receiver specication
LGE Internal Use Only
5) HSDPA receiver specification
Item Specification
Receive Frequency Band1 : 2110 MHz ~ 2170 MHz
Band2 : 1932.4 MHz ~ 1987.6 MHz
Band8 : 925 MHz ~ 960MHz
Maximum Input Level
(BLER or R), 16QAM Only
Sub-Test : 1=1/15, 2=12/15, 3=13/15, 4=15/8, 5=15/7, 6=15/0
BLER < 10% or R >= 700kbps

2. PERFORMANCE
- 17 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
6) WLAN 802.11b transceiver specification
Item Specification
Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13 )
T
x Power Level ≤ 20dBm under
Frequency Tolerance within ±25 PPM
Chip clock Frequency
Tolerance
within ±25 PPM
Spectrum Mask
≤ -30 @ fc-22MHz< f <fc-11MHz and fc+11MHz< f <fc+22MHz
≤ -50 @ f < fc-22MHz and f > fc+22MHz
Power ramp on/off time ≤ 2us
Carrier Suppression ≤ -15dB
Modulation Accuracy
(Peak EVM)
≤ 35%
Spurious Emissions
< -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity ≤ -85dBm(1Mbps,2Mbps,5.5Mbps,11Mbps) @ FER ≤ 8%
Rx Max input Sensitivity ≥ -10dBm(1Mbps,2Mbps,5.5Mbps,11Mbps) @ FER ≤ 8%
Rx Adjacent Channel
Rejection
≥ 35dB @FER ≤ 8%,
interference input signal -70dBm@fc±25MHz(11Mbps)
6) WLAN 802.11b transceiver specication

2. PERFORMANCE
- 18 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
7) WLAN 802.11g transceiver specification
Item Specification
Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13 )
T
x Power Level ≤ 20dBm
Frequency Tolerance within ±25 PPM
Chip clock Frequency
Tolerance within ±25 PPM
Spectrum Mask
≤ -20 @ ±11MHz offset (9Mhz ~ 11MHz)
≤ -28 @ ±20MHz offset (11MHz ~ 20Mhz)
≤ -40 @ ±30MHz offset (20MHz ~ 30Mhz)
Transmitter constellation error
(rms EVM) ≤ -5dB
Spurious Emissions
< -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity
PER ≤ 10%
-82dBm@6Mbps, -81dBm@9Mbps, -79dBm@12Mbps
-77dBm@18Mbps, -74dBm@24Mbps, -70dBm@36Mbps
-66dBm@48Mbps, -65dBm@54Mbps
Rx Max input Sensitivity ≥ -20dBm(6,9,12,18,24,36,48,54Mbps) @ PER ≤ 10%
Rx Adjacent Channel
Rejection
PER ≤ 10%,
ACR ≥ 16dB@6Mbps, ACR ≥ 15dB@9Mbps,
ACR ≥ 13dB@12Mbps, ACR ≥ 11dB@18Mbps,
ACR ≥ 8dB@24Mbps, ACR ≥ 4dB@36Mbps
ACR ≥ 0dB@48Mbps, ACR ≥ -1dB@54Mbps
※ACR shall be measured by setting the desired signal's strength 3
dB above the rate-dependent
sensitivity specified in min input sensitivity
7) WLAN 802.11g transceiver specication

2. PERFORMANCE
- 19 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
8) WLAN 802.11n transceiver specication
LGE Internal Use Only
8) WLAN 802.11n transceiver specification
Item Specification
Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13 )
Tx Power Level ≤ 20dBm
Frequency Tolerance within ±25 PPM
Chip clock Frequency
Tolerance
within ±25 PPM
Spectrum Mask
≤ -20 @ ±11MHz offset (9Mhz ~ 11MHz)
≤ -28 @ ±20MHz offset (11MHz ~ 20Mhz)
≤ -45 @ ±30MHz offset (20MHz ~ 30Mhz)
Transmitter constellation error
(rms EVM)
≤ -5dB
Spurious Emissions
< -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity
PER ≤ 10%
[email protected], -79dBm@13Mbps, -77d[email protected]
-74dBm@26Mbps, -70dBm@39Mbps, -66dBm@52Mbps
[email protected]bps, -64dBm@65Mbps
Rx Max input Sensitivity ≥ -20dBm(6,9,12,18,24,36,48,54Mbps) @ PER ≤ 10%
Rx Adjacent Channel
Rejection
PER ≤ 10%,
ACR ≥ [email protected], ACR ≥ 13dB@13Mbps,
ACR ≥ [email protected], ACR ≥ 8dB@26Mbps,
ACR ≥ 4dB@39Mbps, ACR ≥ 0dB@52Mbps
ACR ≥ [email protected], ACR ≥ -2dB@65Mbps
※ACR shall be measured by setting the desired signal's strength
3 dB above the rate-dependent
sensitivity specified in min input sensitivity

2. PERFORMANCE
- 20 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
9) GPS receiver specification
Item Specification
Receive Frequency 1574.42 MHz ~ 1576.42 MHz
Minimum Sensitivity 1 satellite ≥-142dBm, 7 satellites ≥ -147dBm at coarse time aiding
10) Signal Bar
Antenna BAR
Specification(dBm)
Comment
WCDMA(RSSI) GSM
54-86±2 -91±2
1. Call
Connected &
CPIPH
Level=-3.3
43-93±2 -96±2
32-99±2 -99±2
21-103±2 -103±2
10-109±2 -105±2
9) GPS receiver specication
10) Signal Bar
LGE Internal Use Only
9) GPS receiver specification
Item Specification
Receive Frequency 1574.42 MHz ~ 1576.42 MHz
Minimum Sensitivity 1 satellite ≥-142dBm, 7 satellites ≥ -147dBm at coarse time aiding
10) Signal Bar
Antenna BAR
Specification(dBm)
Comment
WCDMA(RSSI) GSM
54-86±2 -91±2
1. Call
Connected &
CPIPH
Level=-3.3
43-93±2 -96±2
32-99±2 -99±2
21-103±2 -103±2
10-109±2 -105±2
