Service Manual
LG-D295
Date: Oct, 2014 / Issue 1.0

- 2 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Table Of Contents
1. INTRODUCTION..................................................................... 3
1.1 Purpose ........................................................................................................3
1.2 Regulatory Information.........................................................................3
1.3 Specication...............................................................................................5
2. PERFORMANCE...................................................................... 8
2.1 Product Name............................................................................................8
2.2 Supporting Standard..............................................................................8
2.3 Main Parts : GSM Solution.....................................................................8
2.4 HW Features ...............................................................................................9
2.5 HW SPEC ................................................................................................... 11
3. TROUBLE SHOOTING .......................................................... 24
3.1 WCDMA Rx Part...................................................................................... 24
3.2 WCDMA Tx Part Trouble(B1).............................................................. 47
3.3 WCDMA Tx Part Trouble(B5).............................................................. 61
3.4 GSM Rx Part Troubleshooting(850/900 Rx)................................. 75
3.5 GSM Rx Part Troubleshooting(1800/1900 Rx) ........................... 84
3.6GSM Tx Part Troubleshooting(850/900 Tx)................................... 95
3.7 GSM Tx Part Troubleshooting(1800/1900_Tx).........................103
3.8 Power TS..................................................................................................111
3.9 Charging TS............................................................................................115
3.10 USB TS....................................................................................................117
3.11 Audio TS................................................................................................118
3.12 6 AXIS Sensor on/o TS ..................................................................132
3.13 Proximity Sensor on/o TS............................................................135
3.14 Touch Sensor Trouble Shooting..................................................137
3.15 Vibrator Trouble Shooting.............................................................139
3.16 Camera TS ............................................................................................141
3.17 Main LCD TS ........................................................................................145
3.18 BT/Wi TS .............................................................................................147
3.19 GPS TS....................................................................................................150
3.20 FM TS......................................................................................................153
4. DOWNLOAD.......................................................................155
5. BLOCK DIAGRAM..............................................................172
6. CIRCUIT DIAGRAM ............................................................181
7. BGA PIN MAP .....................................................................198
8. PCB LAYOUT.......................................................................204
9. CALIBRATION.....................................................................207
10. HIDDEN MENU.................................................................226
11. DISASSEMBLE GUIDE......................................................259
11.1 DISASSEMBLE GUIDE ................................................................259
11.2 Shield Can Rework Guide..............................................................264
11.3 Rework Caution Points ...................................................................269
12. EXPLODED VIEW & REPLACEMENT PART LIST .............270

- 3 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
1. INTRODUCTION
1. Introduction
1.Introduction
This manual provides the information necessary to repair, calibration, description and download the features
of this model.
1.1 Purpose
1.2 Regulatory Information
A. Security
Toll fraud, the unauthorized use of telecommunications system by an unauthorized part (for example,
persons other than your company’s employees, agents, subcontractors, or person working on your
company’s behalf) can result in substantial additional charges for your telecommunications services.
System users are responsible for the security of own system. There are may be risks of toll fraud associated
with your telecommunications system. System users are responsible for programming and configuring
the equipment to prevent unauthorized use. The manufacturer does not warrant that this product is
immune from the above case but will prevent unauthorized use of common carrier
telecommunication service of facilities accessed throu
g
h or
A.
Security
g
connected to it. The manufacturer will not be responsible for any charges that result from such
unauthorized use.
B. Incidence of Harm
If a telephone company determines that the equipment provided to customer is faulty and possibly
causing harm or interruption in service to the telephone network, it should disconnect telephone
service until repair can be done. A telephone company may temporarily disconnect service as long as repair
is not done
is
not
done
.
C. Changes in Service
A local telephone company may make changes in its communications facilities or procedure. If these
changes could reasonably be expected to affect the use of the phones or compatibility with the net work,
the telephone company is required to give advanced written notice to the user, allowing the user to take
appropriate steps to maintain telephone service.
D. Maintenance Limitation
D.
Maintenance
Limitation
Maintenance limitations on the phones must be performed only by the manufacturer or its authorized agent.
The user may not make any changes and/or repairs expect as specifically noted in this manual. Therefore,
note that unauthorized alternations or repair may affect the regulatory status of the system and may void any
remaining warranty.
E. Notice of Radiated Emission
This model complies with rules regarding radiation and radio frequency emission as defined by local
‐4‐
regulatory agencies. In accordance with these agencies, you may be required to provide information such as
the following to the end user.

- 4 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
1.Introduction
F.Pictures
Thepicturesinthismanualareforillustrativepurposesonly;youractualhardwaremaylookslightlydifferent.
H.ElectrostaticSensitiveDevices
Aphonemayinterferewithsensitivelaboratoryequipment,medicalequipment,etc.Interferencefrom
unsuppressedenginesorelectricmotorsmaycauseproblems.
G.InterferenceandAttenuation
ATTENTION
Boards,whichcontainElectrostaticSensitiveDevice(ESD),areindicatedbythesign.Following
informationisESDhandling:
•Service
p
ersonnelshould
g
roundthemselvesb
y
usin
g
awriststra
p
whenexchan
g
es
y
stemboards.
p g y g p g y
•Whenrepairsaremadetoasystemboard,theyshouldspreadthefloorwithanti‐staticmatwhichis
alsogrounded.
•Useasuitable,groundedsolderingiron.
•Keepsensitivepartsintheseprotectivepackagesuntiltheseareused.
•WhenreturningsystemboardsorpartslikeEEPROMtothefactory,usetheprotectivepackageas
described
described
.
‐5‐

- 5 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
1.3 Specication
KEY FEATURES
• Android4.4-(KitKat)
• 4.5”TouchScreenWVGA(480x800)
• 8MPAFwithFlash
• 3GMobileHotspot
ENHANCED USER EXPERIENCE
• Android4.4
• ProximitySensor–locksthetouchscreenandbuttonswhiletalkingonthephone
• MotionSensor–Accelerometer
• USBChargingviaComputer
• AirplaneMode(RFOff)
DESIGN
• SleekandStylishDesign
• 4.5“WVGALCDScreen
• CapacitiveTouchScreen–Plasticwithfastandaccurateresponse
• MicroUSB/ChargingPort

- 6 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
CAMERA/VIDEO
• 8MPAF
• CameraResolutions:3264(H)x2448(V)Pixels
• ImageEditor:zoom,rotate,cropimages
• Brightness,ISO,WhiteBalance,*ColorEffects,Timer
• Cheeseshutter–takephotowithvoicecommand.
• VideoResolutions:640x480320x240176x144Pixels
MULTIMEDIA
• MusicPlayerforMP3,WMA,andUnprotectedAAC
• StereoSoundviaHeadsetorBluetooth
• MusicLibrary–OrganizedbyArtists,Albums,Songs,andPlaylists
• RepeatandShuffleMusicPlaybackModes
BLUETOOTH®
• Version:4.0
• SupportedProfiles:headset,hands-free,objectpush,advancedaudiodistribution(stereo),audio/videoremote
control,filetransfer,phonebookaccess,messageaccess,serialport
• ListentoMusicwithOptionalStereoBluetoothHeadset**
• SendUser-GeneratedPictures(JPEG)andVideosviaBluetoothWirelessTechnology
*Dependsonavailablememory.
**Accessoriessoldseparately.

- 7 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
VOICE/AUDIO
• One-TouchSpeakerphone*
• Speaker-IndependentVoiceCommands
• Voice-ActivatedDialing
• TexttoSpeech
• MP3MusicRingerSupport
TOOLS & DATA
• AndroidApps:Alarm/Clock,Browser,Calculator,Calendar(CorporateorGoogle),Camera,Contacts,
 Email,Gallery,Gmail,Google+,Maps,Messaging,Messenger,MusicPlayer,Phone,Places,PlayBooks,
 PlayMovies,PlayMusic,PlayStore,Talk,VideoPlayer,VoiceRecorder,Youtube
• Navigation–spokenturn-by-turndirectionsshowingreal-timetraffic
• Wi-FiConnectivity–IEEE802.11b/g/n
• A-GPSSupportforEnhancedLocationAccuracy
SPECIFICATIONS
• Technology:GSM/WCMDA
• Frequencies:GSM850,900,1800,1900
WCDMA2100,900
• DataTransmission:WCMDA,GPRS
• Dimensions:127.5X67.9X11.65(mm)
• Display:4.5”,WVGA(480x800)pixels
• StandardBattery:1,900[mAh]
ACCESSORIES
• StandardBattery
• TravelAdapterandUSBCable*
• StereoHeadset

2. PERFORMANCE
- 8 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
2. PERFORMANCE
2.1 Product Name
LG-D295:WCDMA900/2100+EGSM/GSM850/DCS/PCS(HSDPA21MbpsHSUPA5.76Mbps))
2.2 Supporting Standard
LG-D295 Product SPEC
4
2.1 Product Name
LG-D295 : WCDMA900/2100+EGSM/GSM850/DCS/PCS(HSDPA 21Mbps HSUPA 5.76Mbps)
2.2 Supporting Standard
Item Feature Comment
Supporting Standard
WCDMA(FDD1,8)/EGSM/GSM850/DCS1800/PCS1900
with seamless handover
Phase 2+(include AMR)
SIM Toolkit : Class 1, 2, 3, C-E
Frequency Range WCDMA(FDD1) TX : 1920 – 1980 MHz
WCDMA(FDD1) RX : 2110 – 2170 MHz
WCDMA(FDD8) TX : 880 - 915 MHz
WCDMA(FDD8) RX : 925 – 960 MHz
EGSM TX : 880 – 915 MHz
EGSM RX : 925 – 960 MHz
GSM850 TX : 824 – 849 MHz
GSM850 RX : 869 – 894 MHz
GSM900 TX : 880 – 915 MHz
GSM900 RX : 925 – 960 MHz
DCS1800 TX :1710 – 1785 MHz
DCS1800 RX : 1805 – 1880 MHz
PCS1900 TX : 1850 – 1910 MHz
PCS1900 RX : 1930 – 1990 MHz
Application Standard
2.3 Main Parts : GSM Solution
Item Part Name Comment
AP Chip MSM8212
CP Chip MSM8212
2.3 Main Parts : GSM Solution
LG-D295 Product SPEC
4
2.1 Product Name
LG-D295 : WCDMA900/2100+EGSM/GSM850/DCS/PCS(HSDPA 21Mbps HSUPA 5.76Mbps)
2.2 Supporting Standard
Item Feature Comment
Supporting Standard
WCDMA(FDD1,8)/EGSM/GSM850/DCS1800/PCS1900
with seamless handover
Phase 2+(include AMR)
SIM Toolkit : Class 1, 2, 3, C-E
Frequency Range WCDMA(FDD1) TX : 1920 – 1980 MHz
WCDMA(FDD1) RX : 2110 – 2170 MHz
WCDMA(FDD8) TX : 880 - 915 MHz
WCDMA(FDD8) RX : 925 – 960 MHz
EGSM TX : 880 – 915 MHz
EGSM RX : 925 – 960 MHz
GSM850 TX : 824 – 849 MHz
GSM850 RX : 869 – 894 MHz
GSM900 TX : 880 – 915 MHz
GSM900 RX : 925 – 960 MHz
DCS1800 TX :1710 – 1785 MHz
DCS1800 RX : 1805 – 1880 MHz
PCS1900 TX : 1850 – 1910 MHz
PCS1900 RX : 1930 – 1990 MHz
Application Standard
2.3 Main Parts : GSM Solution
Item Part Name Comment
AP Chip MSM8212
CP Chip MSM8212

2. PERFORMANCE
- 9 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
2.4 HW Features
LG-D295 Product SPEC
5
2.4 HW Features
List Type / Spec.
1. Phone Type DOP Type
2. Size 127.5X67.9X11.65 (mm)
3. Weight TBD (with battery)
4. Battery 1,900mAh ( typ.), 1,820mAh(min) (Li-Ion)
5.Chipset MSM8212
6. Memory 4GB(eMMC) +1GB(LPDDR2)
7. LCD Size 4.5 inch
Dot 480(H) X 800(V)
Color 16.7M
Display Type TFT, Incell Touch
NTSC 50% (Typ)
Contrast Ratio 1:1000 (Typ)
Pixel Pitch TBD
Color temperature 6000~10000K (TBD)
8. Main Camera (8M) Type BSI CIS Type
Resolution 3264(H) X 2448(V) pixels.
Frame Rate TBD
View Angle 71.2° ±5% (Diagonal)
Image Scaling Down TBD
Pixel x size 1.12um x1.12um

2. PERFORMANCE
- 10 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D295 Product SPEC
6
10. Audio
1) MIDI MIDI
2) Mono 18 X 10 X 3T Speaker
3) Receiver 12 X 06 X 2.5T Receiver
11. Bluetooth Effective Distance 10M
Distance 0 m ~ 10 m (depend on environment)
12. WLAN standard IEEE 802.11 b/g/n
Throughput Max 40Mbps (SDIO Driver performance)
depend on environment 0 ~ 50m (depend on environment)
13. GPS type A-GPS

2. PERFORMANCE
- 11 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
2.5 HW SPEC
1) WCDMA transmitter specication
LG-D295 Product SPEC
7
2.5 HW SPEC.
1) WCDMA transmitter specification
Item Spec. Min Typ. Max Unit
Transmit
Frequency
B1(W2100):
1920 ~ 1980 MHz
B8(W900)
880 - 915 MHz
- - - MHz
Maximum Output
Power Power class Ⅲ21.0 23.0 25.0 dBm/3.84MHz
Frequency
Accuracy - -200 - +200 Hz
Minimum Output
Power - - - -50 dBm/3.84MHz
Occupied
Bandwidth - - - 4.6 MHz
Adjacent Channel
Leakage Power
Ratio
Δf = 5MHz - - -33 dBm/3.84MHz
Δf = 10MHz - - -43 dBm/3.84MHz
Error Vector
Magnitude(EVM) - - - 17 %
Peak Code
Domain Error - - - 15 dBm/3.84MHz
Open Loop
Output Power
Ior =-106.7dBm/3.84MHz -46.7 - -28.7 dBm/3.84MHz
Ior =-65.7dBm/3.84MHz -23.0 - -5.0 dBm/3.84MHz
Ior =-25.0dBm/3.84MHz -0.0 - 14.0 dBm/3.84MHz
Transmit Off
Power - - - -56 dBm/3.84MHz
Spectrum
Emission Mask
Δf = 2.5~3.5MHz -35-15 * (Δf-2.5) dBc/30KHz
Δf = 3.5~7.5MHz -35-1 * (Δf-3.5) dBc/1MHz

2. PERFORMANCE
- 12 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D295 Product SPEC
8
Δf = 7.5~8.5MHz -39 10 * (Δf-7.5) dBc/1MHz
Δf = 8.5~12.5MHz -49 dBc/1MHz
Transmit Spurious
Emission
9kHz ~ 150kHz -36 dBm
150kHz ~ 30MHz -36 dBm
30MHz ~ 1GHz -36 dBm
1GHz ~ 12.5GHz -30 dBm

2. PERFORMANCE
- 13 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
2) WCDMA receiver specication
LG-D295 Product SPEC
9
2) WCDMA receiver specification
Item Specification
Receive Frequency B1(W2100): 2110 – 2170 MHz
B8(W900): 925 – 960 MHz
Reference Sensitivity Level
<REFÎor>
Band1 : BER < 0.001 when Îor = -106.7 dBm / 3.84 MHz
Band8 : BER < 0.001 when Îor = -103.7 dBm / 3.84 MHz
Maximum Input Level BER < 0.001 when Îor = -25 dBm / 3.84 MHz
Adjacent Channel Selectivity
(ACS)
ACS > 33 dB where BER < 0.001 when
Îor = <REFÎor> + 14 dB / 3.84 MHz
& Ioac = –52 dBm / 3.84 MHz @ ±5 MHz
Blocking Characteristic
BER < 0.001 when Îor = <REFÎor> + 3 dB / 3.84 MHz
& Iblocking = -56 dBm / 3.84 MHz @ Fuw(offset) = ±10 MHz
or Iblocking = -44 dBm / 3.84 MHz @ Fuw(offset) = ±15 MHz
Spurious Response BER < 0.001 when Îor = <REFÎor> + 3 dB / 3.84 MHz
& Iblocking = -44 dBm
Intermodulation
BER < 0.001 when Îor= <REFÎor> + 3 dB / 3.84 MHz
& Iouw1 = -46 dBm @ Fuw1(offset) = ±10 MHz
& Iouw2 = -46 dBm / 3.84 MHz @ Fuw2(offset) = ±20 MHz
Spurious Emissions < -57 dBm / 100 kHz BW @ 9 kHz ≤ f < 1 GHz
< -47 dBm / 1 MHz BW @ 1 GHz ≤ f ≤ 12.75 GHz
Inner Loop Power Control
In Uplink
Adjust output(TPC command)
cmd 1dB 2dB 3dB
+1 +0.5/1.5 +1/3 +1.5/4
0 -0.5/+0.5 -0.5/+0.5 -0.5/+0.5
-1 -0.5/-1.5 -1/-3 -1.5/-4
group(10equal command group)
+1 +8/+12 +16/+24

2. PERFORMANCE
- 14 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
3) HSDPA transmitter specication
LG-D295 Product SPEC
10
3) HSDPA transmitter specification
Item Spec. Min Typ. Max Unit
Trandsmitter
5.2.A Maximum
Output Power
with HS-DPCCH
1/15 c/d 12/15
13/15 c/d 15/8
15/7 c/d 15/0
21.0
20
19
23.0
23.0
22.5
25.0
25
25
dBm/3.84MH
z
5.7A HS-DPCCH MAX
/
0dBm
Step 0 0 dBm +/- 1 dB dB
Step 1 – Step
06 dB +/- 2.3 dB dB
Step 2 – Step
31 dB +/- 0.6 dB dB
Step 5 – Step
40 dB +/- 0.6 dB dB
Step 6 – Step
75 dB +/- 2.3 dB dB
5.9A Spectrum
Emission Mask
with HS-DPCCH
Δf = 2.5~3.5MHz -35-15 * (Δf-2.5) dBc/30KHz
Δf = 3.5~7.5MHz -35-1 * (Δf-3.5) dBc/1MHz
Δf = 7.5~8.5MHz -39 10 * (Δf-7.5) dBc/1MHz
Δf = 8.5~12.5MHz -49 dBc/1MHz
5.10A Adjacent
Channel Leakage
Power Ratio with
HS-DPCCH
Δf = 5MHz ---33 dBm/3.84MH
z
Δf = 10MHz ---43 dBm/3.84MH
z
5.13.1A Error
Vector
Magnitude (EVM)
with HS-DPCCH
MAX Power
-20 dBm --17.5 %
Receiver
6.3A Maximum
Input Level for
HS-PDSCH
Reception
Pin = -25dBm --10 BLER(%)

2. PERFORMANCE
- 15 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D295 Product SPEC
11
4) GSM receiver specification
Item Spec.
Phase Error Rms : 5°
Peak : 20 °
Frequency Error GSM : 0.1 ppm
DCS/PCS : 0.1 ppm
EMC(Radiated Spurious Emission
Disturbance) GSM/DCS : < -28dBm
Transmitter Output power and Burst Timing GSM : 5dBm – 33dBm ± 3dB
DCS/PCS : 0dBm – 30dBm ± 3dB
Burst Timing <3.69us
Spectrum due to modulation out to less
than 1800kHz offset 200kHz : -36dBm
600kHz : -51dBm/-56dBm
Spectrum due to modulation out to larger
than 1800kHz offset to the edge of the
transmit band
GSM :
1800-3000kHz :< -63dBc(-46dBm)
3000kHz-6000kHz : <-65dBc(-46dBm)
6000kHz < : < -71dBc(-46dBm)
DCS :
1800-3000kHz :< -65dBc(-51dBm)
6000kHz < : < -73dBc(-51dBm)
Spectrum due to switching transient 400kHz : -19dBm/-22dBm(5/0), -23dBm
600kHz : -21dBm/-24dBm(5/0), -26dBm
Reference Sensitivity – TCH/FS Class II(RBER) : -105dBm(2.439%)
Usable receiver input level range 0.012(-15 - -40dBm)
Intermodulation rejection – Speech
channels
± 800kHz, ± 1600kHz
: -98dBm/-96dBm (2.439%)
AM Suppression
-GSM : -31dBm - DCS : -29dBm -98dBm/-96dBm (2.439%)
Timing Advance ± 0.5T
5) Bluetooth transmitter specification
4) GSM receiver specication

2. PERFORMANCE
- 16 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D295 Product SPEC
12
Item Spec. Min Typ. Max Unit
Output Power DH5
PRBS9
Power
(Class I) 0 - 20 dBm
Power Density DH5
PRBS9 @100kHz RBW - +20 dBm
Power Control DH1
PRBS9
Step size 2 - 8 dB
Power(min) - 4 dBm
Frequency Range DH5
PRBS9
-30dBc
@100kHz RBW 2400 - 2483.5 MHz
Tx Output Spectrum
(20dB BW)
DH5
PRBS9 Δf =fH-fL- 1 MHz
Tx Output Spectrum
(Adjacent Output
Power)
DH5
PRBS9
@M-N = 2 - -20 dBm
@M-N 3 - -40 dBm
Modulation Index
DH5
11110000 f1AVG 140 - 175 kHz
DH5
10101010
f2MAX 115 - kHz
f2AVG/f1AVG 0.8 -
Initial Carrier Freq.
Tolerance
DH5
PRBS9 -75 - +75 kHz
Carrier Frequency Drift
DH1
10101010
Freq. Drift -25 - +25 kHz
Drift Rate -20 - +20 kHz/50us
DH3
10101010
Freq. Drift -40 - +40 kHz
Drift Rate -20 - +20 kHz/50us
DH5
10101010
Freq. Drift -40 -+40 kHz
Drift Rate -20 -+20 kHz/50us
6) Bluetooth receiver specification
5) Bluetooth transmitter specication

2. PERFORMANCE
- 17 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D295 Product SPEC
13
Item Spec. BER=0.1% Min Typ. Max Unit
Sensitivity
(Single Slot Packet)
DH1
PRBS9
Input power @BT_w
---70 dBm
Sensitivity
(Multi Slot Packet)
DH5
PRBS9
Input power @BT_w
---70 dBm
C/I Performance* DH1 PRBS9
Input power @BT_i
C/I@Co-Channel
-60dBm @ BT -11
dB
C/I @1MHz
-60dBm@ BT -0
C/I @2MHz
-60dBm@ BT --30
C/I @≥3MHz
-67dBm@ BT -40 -37
C/I @Image
-67dBm@ BT --9
C/I @ Image1MHz
-67dBm@ BT --20
Blocking Performance DH1 PRBS9
Input power @CW
30M ~2 GHz
-67dBm@ BT -10 -
dBm
2 ~ 2.4 GHz
-67dBm@ BT -27 -
2.5 ~ 3 GHz
-67dBm@ BT -27 -
3 ~ 12.75 GHz
-67dBm@ BT -10 -
Intermodulation
Performance
DH1
PRBS9
Input power @CW_i
Δf = +5MHz (CW_i)
Δf = +10MHz (BT_i)
-64dBm@ BT_w
-39 -dBm
Δf = -5MHz (CW_i)
Δf = -10MHz (BT_i)
-64dBm@ BT_w
-39 -dBm
Maximum Input Level DH1 PRBS9
Input power @BT_w --20 -dBm
7) WLAN 802.11b transceiver specification
6) Bluetooth receiver specication

2. PERFORMANCE
- 18 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D295 Product SPEC
14
Item Specification
Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13)
Tx Power Level ≤ 20dBm under (Europe), ≤ 30dBm under (USA)
Frequency Tolerance within ±25 PPM
Chip clock Frequency
Tolerance
within ±25 PPM
Spectrum Mask ≤ -30 @ fc-22MHz< f <fc-11MHz and fc+11MHz< f <fc+22MHz
≤ -50 @ f < fc-22MHz and f > fc+22MHz
Power ramp on/off
time
≤ 2us
Carrier Suppression ≤ -15dB
Modulation Accuracy
(Peak EVM) ≤ 35%
Spurious Emissions < -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity ≤ -76dBm(1Mbps,2Mbps,5.5Mbps,11Mbps) @ FER ≤ 8%
Rx Max input
Sensitivity
≥ -10dBm(1Mbps,2Mbps,5.5Mbps,11Mbps) @ FER ≤ 8%
Rx Adjacent Channel
Rejection
≥ 35dB @FER ≤ 8%,
interference input signal -70dBm@fc±25MHz(11Mbps)
8) WLAN 802.11g transceiver specification
7) WLAN 802.11b transceiver specication

2. PERFORMANCE
- 19 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D295 Product SPEC
15
Item Specification
Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13)
Tx Power Level ≤ 20dBm under (Europe), ≤ 30dBm under (USA)
Frequency Tolerance within ±25 PPM
Chip clock Frequency
Tolerance within ±25 PPM
Spectrum Mask
≤ -20 @ ±11MHz offset (9Mhz ~ 11MHz)
≤ -28 @ ±20MHz offset (11MHz ~ 20Mhz)
≤ -40 @ ±30MHz offset (20MHz ~ 30Mhz)
Transmitter constellation error (rms EVM) ≤ -5dB
Spurious Emissions
< -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity
PER ≤ 10%
-82dBm@6Mbps, -81dBm@9Mbps, -79dBm@12Mbps
-77dBm@18Mbps, -74dBm@24Mbps, -70dBm@36Mbps
-66dBm@48Mbps, -65dBm@54Mbps
Rx Max input Sensitivity ≥ -20dBm(6,9,12,18,24,36,48,54Mbps) @ PER ≤ 10%
Rx Adjacent Channel
Rejection
PER ≤ 10%,
ACR ≥ 16dB@6Mbps, ACR ≥ 15dB@9Mbps,
ACR ≥ 13dB@12Mbps, ACR ≥ 11dB@18Mbps,
ACR ≥ 8dB@24Mbps, ACR ≥ 4dB@36Mbps
ACR ≥ 0dB@48Mbps, ACR ≥ -1dB@54Mbps
※ACR shall be measured by setting the desired signal's
strength 3 dB above the rate-dependent
sensitivity specified in min input sensitivity
9) WLAN 802.11n transceiver specification
8) WLAN 802.11g transceiver specication

2. PERFORMANCE
- 20 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D295 Product SPEC
16
Item Specification
Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13)
Tx Power Level ≤ 20dBm under (Europe), ≤ 30dBm under (USA)
Frequency Tolerance within ±25 PPM
Chip clock Frequency
Tolerance
within ±25 PPM
Spectrum Mask ≤ -20 @ ±11MHz offset (9Mhz ~ 11MHz)
≤ -28 @ ±20MHz offset (11MHz ~ 20Mhz)
≤ -45 @ ±30MHz offset (20MHz ~ 30Mhz)
Transmitter constellation error
(rms EVM)
≤ [email protected], ≤ -10dB@13Mbps, ≤ -13d[email protected],
≤ -16dB@26Mbps, ≤ -19dB@39Mbps, ≤ -22dB@52Mbps,
≤ [email protected], ≤ -28dB@65Mbps
Spurious Emissions < -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity PER ≤ 10%
[email protected], -79dBm@13Mbps, [email protected]
-74dBm@26Mbps, -70dBm@39Mbps, -66dBm@52Mbps
[email protected]bps, -64dBm@65Mbps
Rx Max input Sensitivity ≥ -20dBm(6.5,13,19.5,26,39,52,58.5,65Mbps) @ PER ≤ 10%
Rx Adjacent Channel
Rejection
PER ≤ 10%,
ACR ≥ [email protected], ACR ≥ 13dB@13Mbps,
ACR ≥ [email protected], ACR ≥ 8dB@26Mbps,
ACR ≥ 4dB@39Mbps, ACR ≥ 0dB@52Mbps
ACR ≥ [email protected], ACR ≥ -2dB@65Mbps
※ACR shall be measured by setting the desired signal's strength
3 dB above the rate-dependent
sensitivity specified in min input sensitivity
10) GPS receiver specification
9) WLAN 802.11n transceiver specication
