LG lg-d821 User manual

Internal Use Only
Service Manual
LG-D821
Date: September, 2013 / Issue 0.9

- 2 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Table Of Contents
1. INTRODUCTION..................................................................... 3
1.1 Purpose ........................................................................................................3
1.2 Regulatory Information.........................................................................3
2. PERFORMANCE...................................................................... 5
2.1 Product Name............................................................................................5
2.2 Supporting Standard..............................................................................5
2.3 Main Parts & Solution .............................................................................6
2.4 HW Features ...............................................................................................6
2.5 SW Features ................................................................................................9
2.6 H/W SPEC.................................................................................................. 12
2.7 LG-D821 Figures..................................................................................... 29
3. TROUBLE SHOOTING .......................................................... 30
3.1 RF Component ....................................................................................... 30
3.2 SIGNAL PATH........................................................................................... 33
3.3 Checking XO Block................................................................................ 37
3.4 Checking RF Front-end Separator.................................................. 40
3.5 Checking RF Block................................................................................. 43
3.6 GPS Trouble shooting........................................................................122
3.7 WIFI/BT Trouble shooting.................................................................128
3.8 Audio troubleshooting .....................................................................133
3.9 Camera.....................................................................................................150
3.10 Main LCD trouble..............................................................................156
3.11 Touch Trouble Shooting.................................................................160
3.12 Vibrator Troubleshooting ..............................................................162
3.13 Gyro/Accel Sensor Troubleshooting.........................................165
3.14 Compass sensor troubleshooting..............................................167
3.15 Barometer sensor troubleshooting (Pressure Sensor )......169
3.16 Proximity Sensor on/o troubleshooting...............................171
3.17 Light Sensor on/o trouble..........................................................173
3.18 NFC .........................................................................................................175
3.19 Power ON Troubleshooting..........................................................178
3.20 Wireless Charging Troubleshooting..........................................182
3.21 USB Trouble shooting .....................................................................185
3.22 HDMI Troubleshooting...................................................................188
4. DOWNLOAD.......................................................................192
5. BLOCK DIAGRAM..............................................................209
6. CIRCUIT DIAGRAM ............................................................223
7. BGA PIN MAP.....................................................................238
8. PCB LAYOUT.......................................................................246
9. CALIBRATION.....................................................................252
10. DISASSEMBLE GUIDE......................................................271
11. EXPLODED VIEW & REPLACEMENT PART LIST .............281

- 3 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
1. INTRODUCTION
1. Introduction
This manual provides the information necessary to repair, calibration, description and download the features
of this model.
1. 1 Purpose
Toll fraud, the unauthorized use of telecommunications system by an unauthorized part (for example,
persons other than your company’s employees, agents, subcontractors, or person working on your
company’s behalf) can result in substantial additional charges for your telecommunications services.
System users are responsible for the security of own system. There are may be risks of toll fraud associated
with your telecommunications system. System users are responsible for programming and configuring
the equipment to prevent unauthorized use. The manufacturer does not warrant that this product is
immune from the above case but will prevent unauthorized use of common carrier
telecommunication service of facilities accessed through or connected to it. The manufacturer will not
be responsible for any charges that result from such unauthorized use.
1. 2 Regulatory Information
A. Security
B. Incidence of Harm
If a telephone company determines that the equipment provided to customer is faulty and possibly
causing harm or interruption in service to the telephone network, it should disconnect telephone
service until repair can be done. A telephone company may temporarily disconnect service as long as repair
is not done.
C. Changes in Service
A local telephone company may make changes in its communications facilities or procedure. If these
changes could reasonably be expected to affect the use of the phones or compatibility with the net work,
the telephone company is required to give advanced written notice to the user, allowing the user to take
appropriate steps to maintain telephone service.
D. Maintenance Limitation
Maintenance limitations on the phones must be performed only by the manufacturer or its authorized agent.
The user may not make any changes and/or repairs expect as specifically noted in this manual. Therefore,
note that unauthorized alternations or repair may affect the regulatory status of the system and may void any
remaining warranty.

- 4 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
1. Introduction
3
E. Notice of Radiated Emission
This model complies with rules regarding radiation and radio frequency emission as defined by local
regulatory agencies. In accordance with these agencies, you may be required to provide information such as
the following to the end user.
ATTENTION
H. Electrostatic Sensitive Devices
Boards, which contain Electrostatic Sensitive Device (ESD), are indicated by the
sign. information is ESD handling: Following
• Service personnel should ground themselves by using a wrist strap when exchange system boards.
• When repairs are made to a system board, they should spread the floor with anti-static mat which is
also grounded.
• Use a suitable, grounded soldering iron.
• Keep sensitive parts in these protective packages until these are used.
• When returning system boards or parts like EEPROM to the factory, use the protective package as
described.
A phone may interfere with sensitive laboratory equipment, medical equipment, etc. Interference from
unsuppressed engines or electric motors may cause problems.
G. Interference and Attenuation
F. Pictures
The pictures in this manual are for illustrative purposes only; your actual hardware may look slightly
different.

2. PERFORMANCE
- 5 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
2. PERFORMANCE
2.1 Product Name
LG-D821 : WCDMA(B1,B2,B4,B5,B8)(HSPA+42Mbps(cat24)/ HSUPA 5.8Mbps(cat6) + GSM850/GSM900/DCS/PCS (GPRS Class10/EDGE
Class10)+ FDD LTE (B1, B3, B5, B7, B8, B20) (DL:102Mpbs, UL:51.0Mbps, Max DL MIMO layers = 2, Release8(Cat3))
2.2 Supporting Standard
LG-D821 Product SPEC
4
2.1 Product Name
LG-D821 :WCDMA(B1,B2,B4,B5,B8)(HSPA+42Mbps(cat24)/ HSUPA 5.8Mbps(cat6)
+ GSM850/GSM900/DCS/PCS (GPRS Class10/EDGE Class10)+ FDD LTE (B1, B3, B5, B7, B8, B20)
(DL:102Mpbs, UL:51.0Mbps, Max DL MIMO layers = 2, Release8(Cat3))
2.2 Supporting Standard
Item Feature Comment
Supporting Standard
WCDMA(FDD1,2,4,5,8)
/EGSM/GSM850/DCS1800/PCS1900 with seamless
handover
Frequency Range
WCDMA(FDD1) TX : 1920 – 1980 MHz
WCDMA(FDD1) RX : 2110 – 2170 MHz
WCDMA(FDD2) TX : 1850 – 1910 MHz
WCDMA(FDD2) RX : 1930 – 1990 MHz
WCDMA(FDD4) TX : 1710 – 1755 MHz
WCDMA(FDD4) RX : 2110 – 2155 MHz
WCDMA(FDD5) TX : 824 – 849 MHz
WCDMA(FDD5) RX : 869 – 894 MHz
WCDMA(FDD8) TX : 880 – 915 MHz
WCDMA(FDD8) RX : 925 – 960 MHz
EGSM TX : 880 – 915 MHz
EGSM RX : 925 – 960 MHz
GSM850 TX : 824 – 849 MHz
GSM850 RX : 869 – 894 MHz
GSM900 TX : 880 – 915 MHz
GSM900 RX : 925 – 960 MHz
DCS1800 TX : 1710 – 1785 MHz
DCS1800 RX : 1805 – 1880 MHz
PCS1900 TX : 1850 – 1910 MHz
PCS1900 RX : 1930 – 1990 MHz
Application Standard WAP 2.0

2. PERFORMANCE
- 6 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D821 Product SPEC
5
2.3 Main Parts & Solution
Item Part Name Comment
Digital Baseband AP Q8064 : Qualcomm
Analog Baseband MDM9215M : Qualcomm
RF Chip WTR1605L : Qualcomm
2.4 HW Features
Item Feature Comment
Form Factor DOP type
Battery
1) Capacity
Standard : Li-Ion Polymer, 2300mAh
2) Packing Type : Soft Pack Embeded
Size Standard :
133.9 x 68.7 x 9.1 (unit : mm)
Weight 139.5 g with Battery
PCB FR4, 10 Layers , 0.8t
Stand by time
CDMA Up to 350 hrs
GSM Up to 350 hrs
WCDMA Up to 350 hrs
LTE Up to 350 hrs
@ SCI2 (CDMA)
@ Paging Period 5 (GSM)
@ DRX 7 (WCDMA)
@ DRX7 (LTE)
Charging time 3 hrs 30min @ Power Off
Talk time
CDMA Up to 690 min
GSM Up to 405 min
WCDMA Up to 530min
LTE Up to 230 min
@ Tx= 10dBm (CDMA)
@ TX=LV5(EGSM)
@ Tx = 10dBm (WCDMA)
@ Tx = 10dBm (LTE )
RX sensitivity
WCDMA(FDD1) : -108 dBm
WCDMA(FDD2) : -108 dBm
WCDMA(FDD2) : -108 dBm
WCDMA(FDD5) : -108 dBm
WCDMA(FDD8) : -108 dBm
EGSM : -108 dBm
GSM850 : -108 dBm
DCS 1800 : -108 dBm
LG-D821 Product SPEC
5
2.3 Main Parts & Solution
Item Part Name Comment
Digital Baseband AP Q8064 : Qualcomm
Analog Baseband MDM9215M : Qualcomm
RF Chip WTR1605L : Qualcomm
2.4 HW Features
Item Feature Comment
Form Factor DOP type
Battery
1) Capacity
Standard : Li-Ion Polymer, 2300mAh
2) Packing Type : Soft Pack Embeded
Size Standard :
133.9 x 68.7 x 9.1 (unit : mm)
Weight 139.5 g with Battery
PCB FR4, 10 Layers , 0.8t
Stand by time
CDMA Up to 350 hrs
GSM Up to 350 hrs
WCDMA Up to 350 hrs
LTE Up to 350 hrs
@ SCI2 (CDMA)
@ Paging Period 5 (GSM)
@ DRX 7 (WCDMA)
@ DRX7 (LTE)
Charging time 3 hrs 30min @ Power Off
Talk time
CDMA Up to 690 min
GSM Up to 405 min
WCDMA Up to 530min
LTE Up to 230 min
@ Tx= 10dBm (CDMA)
@ TX=LV5(EGSM)
@ Tx = 10dBm (WCDMA)
@ Tx = 10dBm (LTE )
RX sensitivity
WCDMA(FDD1) : -108 dBm
WCDMA(FDD2) : -108 dBm
WCDMA(FDD2) : -108 dBm
WCDMA(FDD5) : -108 dBm
WCDMA(FDD8) : -108 dBm
EGSM : -108 dBm
GSM850 : -108 dBm
DCS 1800 : -108 dBm
2.4 HW Features
2.3 Main Parts & Solution

2. PERFORMANCE
- 7 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D821 Product SPEC
6
PCS 1900 : -108 dBm
TX output power
WCDMA/
GSM/
GPRS
WCDMA B1,2, 4,8 :
24dBm/3.84MHz,+1/-
3dBm
WCDMA B5 :
23.5dBm/3.84MHz,+1/-
3dBm
EGSM : 32.5dBm
GSM850 : 32.5 dBm
DCS 1800 : 30 dBm
PCS 1900 : 30 dBm
GPRS
compatibilit
y
EDGE
EGSM : 26 dBm
GSM850 :26 dBm
DCS 1800 : 25 dBm
PCS 1900 : 25 dBm
Class3(WCDMA)
Class4 (EGSM)
Class4 (GSM850)
Class1 (PCS)
Class1 (DCS)
GPRS Class
12
E2 (GSM900)
E2 (PCS)
E2 (DCS)
EDGE compatibility GPRS Class 12
SIM card type Plug-In SIM
3V /1.8V
Display
Main LCD
IPS TFT Main LCD
(5.0”, 1920 X 1080 Pixels)
Built-in Camera 8M AF + 1.3M VT
Status Indicator Yes
Keypad Full Touch Screen
Side Key : 3
Side Key : Power On
Volume up/down
ANT Main : Internal Fixed Type
System connector 5 Pin u-USB
Ear Phone Jack 3.5Phi,
PC synchronization Yes
Memory(AP) 16Gb(SDRAM DDR2)

2. PERFORMANCE
- 8 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D821 Product SPEC
7
+ 16GB eMMC
Speech coding FR, EFR, HR,AMR
Vibrator Built in Vibrator
BlueTooth Bluetooth 3.0
MIDI(for Buzzer
Function) SW Decoded 72Poly
Music Player MP3/WMA/AAC/MIDI/EAAC+/HE
AAC/OGG
Video Player MPEG4, H.264
Camcorder MPEG4 or H.263
Voice Recording Yes
Speaker Phone mode
Support Yes
Travel Adapter Yes
CDROM No
Stereo Headset Yes
Data Cable Yes
T-Flash
(External Memory) No

2. PERFORMANCE
- 9 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D821 Product SPEC
8
2.5 SW Features
Item Feature Comment
RSSI 0 ~4 Levels
Battery Charging 0 ~ 7 Levels
Key Volume 0 ~ 7 Level
Audio Volume 0 ~ 15 Level
Time / Date Display Yes
Multi-Language Yes English, Espanol, Franch,
Korea, Chinese, etc
Quick Access Mode Camera/Chrome/App/Message/Phone
PC Sync No
Speed Dial Yes Voice mail center -> 1 key
Profile Yes not same with feature phone
setting
CLIP / CLIR Yes
Phone Book
Name / Number / Email /Organization/
Website / Postal addresses /Events/
Note / IM / Nickname / Internet call/
Group
Last Received
Number Yes
There is no limitation on the
number of items.
It depends on available
memory amount.
Last Missed Number Yes
There is no limitation on the
number of items.
It depends on available
memory amount.
Search by Number
/ Name Name / Number
Group Yes
There is no limitation on the
number of items.
It depends on available
memory amount.
2.5 SW Features

2. PERFORMANCE
- 10 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D821 Product SPEC
9
Fixed Dial Number Yes
Service Dial Number No
Own Number Yes Read / Write
Voice Memo No
Call Reminder No
Network Selection Automatic
Mute Yes
Call Divert Yes
Call Barring No
Call Charge (AoC) No
Call Duration No
SMS (EMS)
There is no limitation on the number of
items.
It depends on available memory
amount.
EMS does not support.
SMS Over GPRS Yes
EMS Melody / Picture
Send / Receive / Save
No
No
MMS MPEG4
Send / Receive / Save TBD
Long Message Yes
Cell Broadcast Yes
Download Yes
Game Yes
Calendar Yes
Memo No
World Clock No
Unit Convert Yes
Stop Watch Yes
Wall Paper No
WAP Browser Yes WAP stack and wml are not
supported.
Download Melody /
Wallpaper Over web browser

2. PERFORMANCE
- 11 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D821 Product SPEC
10
SIM Lock No
SIM Toolkit Class 1, 2, 3, C, E
MMS Yes
EONS Yes
CPHS Yes V4.2
ENS No
Camera Yes 8M AF
VT : 1.3 M HD
JAVA Android do not support JAVA
Voice Dial No
IrDa No
Bluetooth No Ver.4.0
FM radio Yes
GPRS No Class 12
EDGE Yes Class 12
Hold / Retrieve Yes
Conference Call Yes Max. 7
DTMF Yes
Memo pad No
TTY Yes
AMR Yes
SyncML No
IM Yes Gtalk
Email Yes

2. PERFORMANCE
- 12 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D821 Product SPEC
11
2.6 HW SPEC.
1) GSM transceiver specification
Item Specification
Phase Error Rms : 5°/ Peak : 20 °
Frequency Error GSM : 0.1 ppm/ DCS / PCS : 0.1 ppm
EMC
(Radiated Spurious Emission Disturbance) GSM/DCS : < -28dBm
Transmitter Output power GSM850, EGSM : 5dBm ~ 32.5dBm ± 3dB
DCS/PCS : 0dBm ~ 30dBm ± 3dB
Burst Timing < 3.69us
Spectrum due to modulation out to less than
1800kHz offset
200kHz : -36dBm
600kHz : -51dBm/-56dBm
Spectrum due to modulation out to larger than
1800kHz offset to the edge of the transmit
band
GSM850, EGSM :
1800-3000kHz :< -63dBc(-46dBm)
3000kHz-6000kHz : <-65dBc(-46dBm)
6000kHz < : < -71dBc(-46dBm)
DCS, PCS :
1800-3000kHz :< -65dBc(-51dBm)
6000kHz < : < -73dBc(-51dBm)
Spectrum due to switching transient 400kHz : -19dBm/-22dBm(5/0), -23dBm
600kHz : -21dBm/-24dBm(5/0), -26dBm
Reference Sensitivity – TCH/FS Class II(RBER) : -105dBm(2.439%)
Usable receiver input level range 0.012(-15 - -40dBm)
Intermodulation rejection
– Speech channels
± 800kHz, ± 1600kHz
: -98dBm / -96dBm (2.439%)
AM Suppression
-GSM : -31dBm
- DCS : -29dBm
-98dBm/-96dBm (2.439%)
Timing Advance ± 0.5T
2.6 H/W SPEC.
1) GSM transceiver specication

2. PERFORMANCE
- 13 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D821 Product SPEC
12
2) WCDMA transmitter specification
Item Spec. Min Typ. Max Unit
Maximum Output Power Power class Ⅲ21.0 24 25.0 dBm/3.84MHz
Frequency Accuracy - -200 - +200 Hz
Minimum Output Power - - - -50 dBm/3.84MHz
Occupied Bandwidth - - - 4.6 MHz
Adjacent Channel
Leakage Power Ratio
Δf = ±5MHz - - -33 dBm/3.84MHz
Δf = ±10MHz - - -43 dBm/3.84MHz
Error Vector
Magnitude(EVM) - - - 17 %
Peak Code Domain Error - - - 15 dBm/3.84MHz
Open Loop
Output Power
Ior =-
106.7dBm/3.84MHz -46.7 - -28.7 dBm/3.84MHz
Ior =-65.7dBm/3.84MHz -23.0 - -5.0 dBm/3.84MHz
Ior =-25.0dBm/3.84MHz -0.0 - 14.0 dBm/3.84MHz
Transmit Off Power - - - -56 dBm/3.84MHz
Spectrum Emission Mask
Δf = 2.5~3.5MHz -35-15 * (Δf-2.5) dBc/30KHz
Δf = 3.5~7.5MHz -35-1 * (Δf-3.5) dBc/1MHz
Δf = 7.5~8.5MHz -39 10 * (Δf-7.5) dBc/1MHz
Δf = 8.5~12.5MHz -49 dBc/1MHz
Transmit Spurious
Emission
9kHz ~ 150kHz
-36 dBm
150kHz ~ 30MHz
-36 dBm
30MHz ~ 1GHz
-36 dBm
1GHz ~ 12.5GHz
-30 dBm
2) WCDMA transmitter specication

2. PERFORMANCE
- 14 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D821 Product SPEC
13
3) WCDMA receiver specification
Item Spec. Min Typ. Max Unit
Reference
Sensitivity Level BER < 0.001% - - -106.7 dBm/3.84MHz
Maximum
Input Level Pin = -25dBm - - 0.1 BER(%)
Adjacent Channel
Selectivity(ACS)
Jammer(Modulation)
= -52dBm/3.84MHz
Δf = ±5MHz
BER < 0.001%
- - -103 dBm/3.84MHz
In Band Blocking
Jammer(Modulation)
= -56dBm/3.84MHz
Δf = ±10MHz
BER < 0.001%
- - -103.7 dBm/3.84MHz
Jammer(Modulation)
= -44dBm/3.84MHz
Δf = ±15MHz
BER < 0.001%
- - -103.7 dBm/3.84MHz
Inter-modulation
Desensitization
Jammer1(CW)= -46dBm
Jammer2(Modulation)
= -46dBm/3.84MHz
Δf=±10MHz
BER < 0.001%
- - -103.7 dBm/3.84MHz
Jammer1= -46dBm(CW)
Jammer2(Modulation)
= -46dBm/3.84MHz
Δf=±20MHz
BER < 0.001%
- - -103.7 dBm/3.84MHz
Spurious Emissions
30kHz ~ 1GHz - - -57 dBm/30kHz
1GHz ~ 1.92GHz - - -47 dBm/1MHz
1.92GHz ~ 1.98GHz - - -60 dBm/3.84MHz
1.98GHz ~ 2.11GHz - - -47 dBm/3.84MHz
2.11GHz ~ 2.17GHz - - -60 dBm/3.84MHz
2.17GHz ~ 12.75GHz - - -47 dBm/1MHz
3) WCDMA receiver specication

2. PERFORMANCE
- 15 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D821 Product SPEC
14
4) HSDPA transmitter / receiver specification
Item Spec. Min Typ. Max Unit
transmitter
5.2.A Maximum
Output Power
with HS-DPCCH
1/15 ≤βc/βd ≤12/15
13/15 ≤βc/βd ≤15/8
15/7 ≤βc/βd ≤15/0
21
20
19
23
22.5
22
25
25
25
dBm/3.84MHz
5.7A HS-DPCCH MAX /
0dBm
Step 0 0 dBm +/- 1 dB dB
Step 1 – Step 0 6 dB +/- 2.3 dB dB
Step 2 – Step 3 1 dB +/- 0.6 dB dB
Step 5 – Step 4 0 dB +/- 0.6 dB dB
Step 6 – Step 7 5 dB +/- 2.3 dB dB
5.9A Spectrum
Emission Mask
with HS-DPCCH
Δf = 2.5~3.5MHz -35-15 * (Δf-2.5) dBc/30KHz
Δf = 3.5~7.5MHz -35-1 * (Δf-3.5) dBc/1MHz
Δf = 7.5~8.5MHz -39 10 * (Δf-7.5) dBc/1MHz
Δf = 8.5~12.5MHz -49 dBc/1MHz
5.10AAdjacent
Channel
Leakage Power
Ratio with HS-
DPCCH
Δf = ±5MHz - - -33 dBm/3.84MHz
Δf = ±10MHz - - -43 dBm/3.84MHz
5.13.1A Error
Vector
Magnitude
(EVM) with HS-
DPCCH
MAX Power
-20 dBm - - 17.5 %
receiver
6.3A Maximum
Input Level
for
HS-PDSCH
Reception
Pin = -25dBm - - 10 BLER(%)
4) HSDPA transmitter / receiver specication

2. PERFORMANCE
- 16 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
5) LTE Transmitter specication
LG-D821 Product SPEC
15
5) LTE Transmitter specification
Item Spec. Min Typ. Max Unit
Maximum Output
Power (Class III)
Power class 3
(Environmental Test )
20.3
( 20.3)
23.0
( 23.0)
25.7
( 25.7)
dBm/
10MHz
Frequency Error QPSK -0.1 PPM
-15hz - +0.1 PPM
+15hz
EVM QPSK
16QAM
17.5
12.5 %
IQ-component QPSK, 12RB
-24.2 dBc
In-band emissions
for non allocated RB QPSK, 12RB -24.2 dB
Spectrum Flatness QPSK, 50RB -2
+3.4 dB
Occupied bandwidth QPSK, 50RB 10 MHz
ACLR
(Adjacent Channel
Leakage Power Ratio)
E-UTRA ACLR1
-29.2 dB
UTRA ACLR1
-32.2 dB
UTRA ACLR2
-35.2 dB
Transmitter
Spurious emissions
9 kHz < f < 150 kHz -36 dBm/1kHz
150kHz < f < 30 MHz
-36 dBm/10kHz
30MHz < f < 1GHz
-36 dBm/100kHz
1GHz < f < 12.75GHz
-30 dBm/1MHz

2. PERFORMANCE
- 17 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
6) LTE receiver specication
LG-D821 Product SPEC
16
6) LTE receiver specification
Item Spec. Min Typ. Max Unit
Sensitivity Level
(DL : QPSK, 50RB
UL : QPSK, 25RB)
Dual Receiver
B2: -95
B4 : -97
B17: -94
dBm/
10MHz
Single Receiver
(exception in 3GPP)
B2 : -92
B4 : -94.0
B17: -91.0
dBm
/10MHz
Maximum input Level
Dual Receiver
(DL : 64QAM, 50RB
UL : QPSK, 12RB) -25.7 dBm
/10MHz
ACS
(Adjacent Channel
Selectivity)
Dual Receiver
(DL : QPSK, 50RB
UL : QPSK, 12RB)
Δf = ± 7.5MHz, LTE BW
5MHz
33 dB
In-Band Blocking
(DL : QPSK, 50RB
UL : QPSK, 20RB)
Dual Receiver
Δf = ± 7.5MHz, LTE BW
5MHz
Δf = ± 12.5MHz, LTE BW
5MHz
-88.3 dBm
/10MHz
Narrow Band Blocking
(DL : QPSK, 50RB
UL : QPSK, 20RB)
Dual Receiver
Δf = ± 5.2125MHz, CW -81.3 dBm
/10MHz
Intermodulation
(DL : QPSK, 50RB
UL : QPSK, 20RB)
Dual Receiver
Δf = ± 12.5MHz, CW
Δf = ± 25MHz, LTE BW
5MHz
-88.3 dBm
/10MHz
Spurious emissions
(DL : QPSK, 0RB
UL : QPSK, 0RB)
Dual Receiver
30MHz < f < 1GHz -57 dBm
/100kHz
1GHz < f < 12.75 GHz -47 dBm
/1MHz

2. PERFORMANCE
- 18 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D821 Product SPEC
17
7) WLAN 802.11a transceiver specification
Item Specification
Transmit Frequency 5170 ~ 5815 MHz (CH36 ~ 64, CH100 ~ 124, CH149 ~ 161)
Tx Power Level ≤ 2.5mW/MHz(CH36 ~ 48), ≤ 10mW/MHz(CH52 ~ 161)
Frequency Tolerance within ±20 PPM
Chip clock Frequency
Tolerance within ±20 PPM
Spectrum Mask
≤ -20 @ ±11MHz offset (9Mhz ~ 11MHz)
≤ -28 @ ±20MHz offset (11MHz ~ 20Mhz)
≤ -40 @ ±30MHz offset (20MHz ~ 30Mhz)
Transmitter constellation error
(rms EVM)
≤ -5dB@6Mbps, ≤ -8dB@9Mbps, ≤ -10dB@12Mbps,
≤ -13dB@18Mbps, ≤ -16dB@24Mbps, ≤ -19dB@36Mbps,
≤ -22dB@48Mbps, ≤ -25dB@54Mbps
Spurious Emissions
< -36 dBm @ 30 MHz to 47 MHz
< -54 dBm @ 47 MHz to 74 MHz
< -36 dBm @ 74 MHz to 87,5 MHz
< -54 dBm @ 87,5 MHz to 118 MHz
< -36 dBm @ 118 MHz to 174 MHz
< -54 dBm @ 174 MHz to 230 MHz
< -36 dBm @ 230 MHz to 470 MHz
< -54 dBm @ 470 MHz to 862 MHz
< -36 dBm @ 862 MHz to 1 GHz
< -30 dBm @ 1 GHz to 5.15 GHz
< -30 dBm @ 5.35 GHz to 5.47 GHz
< -30 dBm @ 5.725 GHz to 26.5 GHz
Rx Min input Sensitivity
PER ≤ 10%
-82dBm@6Mbps, -81dBm@9Mbps, -79dBm@12Mbps
-77dBm@18Mbps, -74dBm@24Mbps, -70dBm@36Mbps
-66dBm@48Mbps, -65dBm@54Mbps
Rx Max input Sensitivity ≥ -30dBm(6,9,12,18,24,36,48,54Mbps) @ PER ≤ 10%
7) WLAN 802.11a transceiver specication

2. PERFORMANCE
- 19 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
8) WLAN 802.11b transceiver specication
LG-D821 Product SPEC
18
Rx Adjacent Channel
Rejection
PER ≤ 10%,
ACR ≥ 16dB@6Mbps, ACR ≥ 15dB@9Mbps,
ACR ≥ 13dB@12Mbps, ACR ≥ 11dB@18Mbps,
ACR ≥ 8dB@24Mbps, ACR ≥ 4dB@36Mbps
ACR ≥ 0dB@48Mbps, ACR ≥ -1dB@54Mbps
※
ACR shall be measured by setting the desired signal's strength
3 dB above the rate-dependent
sensitivity specified in min input sensitivity
7) WLAN 802.11b transceiver specification
Item Specification
Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13 )
Tx Power Level ≤ 20dBm under (Europe), ≤ 30dBm under (USA)
Frequency Tolerance within ±25 PPM
Chip clock Frequency
Tolerance within ±25 PPM
Spectrum Mask ≤ -30 @ fc-22MHz< f <fc-11MHz and fc+11MHz< f <fc+22MHz
≤ -50 @ f < fc-22MHz and f > fc+22MHz
Power ramp on/off time ≤ 2us
Carrier Suppression ≤ -15dB
Modulation Accuracy(Peak EVM) ≤ 35%
Spurious Emissions
< -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity ≤ -76dBm(1Mbps,2Mbps,5.5Mbps,11Mbps) @ FER ≤ 8%
Rx Max input Sensitivity ≥ -10dBm(1Mbps,2Mbps,5.5Mbps,11Mbps) @ FER ≤ 8%
Rx Adjacent Channel
Rejection
≥ 35dB @FER ≤ 8%,
interference input signal -70dBm@fc±25MHz(11Mbps)
LG-D821 Product SPEC
18
Rx Adjacent Channel
Rejection
PER ≤ 10%,
ACR ≥ 16dB@6Mbps, ACR ≥ 15dB@9Mbps,
ACR ≥ 13dB@12Mbps, ACR ≥ 11dB@18Mbps,
ACR ≥ 8dB@24Mbps, ACR ≥ 4dB@36Mbps
ACR ≥ 0dB@48Mbps, ACR ≥ -1dB@54Mbps
※
ACR shall be measured by setting the desired signal's strength
3 dB above the rate-dependent
sensitivity specified in min input sensitivity
7) WLAN 802.11b transceiver specification
Item Specification
Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13 )
Tx Power Level ≤ 20dBm under (Europe), ≤ 30dBm under (USA)
Frequency Tolerance within ±25 PPM
Chip clock Frequency
Tolerance within ±25 PPM
Spectrum Mask ≤ -30 @ fc-22MHz< f <fc-11MHz and fc+11MHz< f <fc+22MHz
≤ -50 @ f < fc-22MHz and f > fc+22MHz
Power ramp on/off time ≤ 2us
Carrier Suppression ≤ -15dB
Modulation Accuracy(Peak EVM) ≤ 35%
Spurious Emissions
< -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity ≤ -76dBm(1Mbps,2Mbps,5.5Mbps,11Mbps) @ FER ≤ 8%
Rx Max input Sensitivity ≥ -10dBm(1Mbps,2Mbps,5.5Mbps,11Mbps) @ FER ≤ 8%
Rx Adjacent Channel
Rejection
≥ 35dB @FER ≤ 8%,
interference input signal -70dBm@fc±25MHz(11Mbps)

2. PERFORMANCE
- 20 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
9) WLAN 802.11g transceiver specication
LG-D821 Product SPEC
19
8) WLAN 802.11g transceiver specification
Item Specification
Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13 )
Tx Power Level ≤ 20dBm under (Europe), ≤ 30dBm under (USA)
Frequency Tolerance within ±25 PPM
Chip clock Frequency Tolerance within ±25 PPM
Spectrum Mask
≤ -20 @ ±11MHz offset (9Mhz ~ 11MHz)
≤ -28 @ ±20MHz offset (11MHz ~ 20Mhz)
≤ -40 @ ±30MHz offset (20MHz ~ 30Mhz)
Transmitter constellation error
(rms EVM)
≤ -5dB@6Mbps, ≤ -8dB@9Mbps, ≤ -10dB@12Mbps,
≤ -13dB@18Mbps, ≤ -16dB@24Mbps, ≤ -19dB@36Mbps,
≤ -22dB@48Mbps, ≤ -25dB@54Mbps
Spurious Emissions
< -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity
PER ≤ 10%
-82dBm@6Mbps, -81dBm@9Mbps, -79dBm@12Mbps
-77dBm@18Mbps, -74dBm@24Mbps, -70dBm@36Mbps
-66dBm@48Mbps, -65dBm@54Mbps
Rx Max input Sensitivity ≥ -20dBm(6,9,12,18,24,36,48,54Mbps) @ PER ≤ 10%
Rx Adjacent Channel
Rejection
PER ≤ 10%,
ACR ≥ 16dB@6Mbps, ACR ≥ 15dB@9Mbps,
ACR ≥ 13dB@12Mbps, ACR ≥ 11dB@18Mbps,
ACR ≥ 8dB@24Mbps, ACR ≥ 4dB@36Mbps
ACR ≥ 0dB@48Mbps, ACR ≥ -1dB@54Mbps
※
ACR shall be measured by setting the desired signal's strength 3 dB
above the rate-dependent
sensitivity specified in min input sensitivity
