Service Manual
LG-E977
Date: March, 2013 / Issue 1.0

- 2 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Table Of Contents
1. INTRODUCTION..................................................................... 3
1.1 Purpose ........................................................................................................3
1.2 Regulatory Information.........................................................................3
2. PERFORMANCE...................................................................... 5
2.1 Product Name............................................................................................5
2.2 Supporting Standard..............................................................................5
2.3 Main Parts : GSM Solution.....................................................................5
2.4 HW Features ...............................................................................................6
2.5 SW Features............................................................................................. 11
2.6 HW SPEC. ................................................................................................. 14
3. CIC_AND SERVICE CENTER................................................. 23
3.1 CIC FAQ...................................................................................................... 23
4. TROUBLE SHOOTING .......................................................... 41
4.1 RF Component ....................................................................................... 41
4.2 SIGNAL PATH........................................................................................... 44
4.3 Checking XO Block................................................................................ 47
4.4 Checking FEMiD (GSM, WCDMA B1/B2/B5) Block ................... 50
4.5 Checking WCDMA Block .................................................................... 52
4.6 Checking GSM Block............................................................................ 80
4.7 Checking LTE Block............................................................................... 90
4.8 GPS/WIFI/BT Module..........................................................................112
4.8 GPS/WIFI/BT SIGNAL PATH ..............................................................114
4.10 Checking GPS/WIFI/BT....................................................................115
4.11 Audio troubleshooting...................................................................121
4.12 13M AF Camera Trouble Shooting.............................................129
4.13 1.3M front Camera Trouble Shooting.......................................132
4.14 Camera Flash Trouble Shooting..................................................134
4.15 Main LCD trouble..............................................................................136
4.16 Touch trouble .....................................................................................139
4.17 Vibrator Troubleshooting ..............................................................141
4.18 Gyro Sensor troubleshooting......................................................144
4.19 Compass sensor troubleshooting..............................................146
4.20 Proximity Sensor on/o trouble.................................................149
4.21 Light Sensor on/o trouble..........................................................151
4.22 Pressure Sensor troubleshooting...............................................152
4.23 Power ON Troubleshooting..........................................................154
4.24 Charging Troubleshooting............................................................159
4.25.USB Trouble shooting .....................................................................160
4.26 HDMI Troubleshooting...................................................................164
5. DOWNLOAD.......................................................................165
6. BLOCK DIAGRAM...............................................................185
7. CIRCUIT DIAGRAM ............................................................197
8. BGA PIN MAP ....................................................................216
9. PCB LAYOUT.......................................................................227
10. CALIBRATION...................................................................237
11. HIDDEN MENU.................................................................257
12. Guide to............................................................................272
12.1 Guide to apply label,approval.....................................................272
12.2 Guide to read IMEI by IMEI reader..............................................273
12.3 Guide to disassemble......................................................................275
13. EXPLODED VIEW & REPLACEMENT PART LIST .............281
13.1 EXPLODED VIEW................................................................................281
13.2 Replacement Parts ...........................................................................282
13.3 Accessory .............................................................................................331

- 3 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
LGE Internal Use Only
1.1 Purpose
This manual provides the information necessary to repair, calibration, description and download the features of
this model.
1.2 Regulatory Information
A. Security
Toll fraud, the unauthorized use of telecommunications system by an unauthorized part (for example, persons
other than your company’s employees, agents, subcontractors, or person working on your company’s behalf)
can result in substantial additional charges for your telecommunications services.
System users are responsible for the security of own system. There are may be risks of toll fraud associated with
your telecommunications system. System users are responsible for programming and configuring the
equipment to prevent unauthorized use. The manufacturer does not warrant that this product is immune from
the above case but will prevent unauthorized use of common carrier telecommunication service of facilities
accessed through or connected to it. The manufacturer will not be responsible for any charges that result from
such unauthorized use.
B. Incidence of Harm
If a telephone company determines that the equipment provided to customer is faulty and possibly causing
harm or interruption in service to the telephone network, it should disconnect telephone service until repair can
be done. A telephone company may temporarily disconnect service as long as repair is not done.
C. Changes in Service
A local telephone company may make changes in its communications facilities or procedure. If these changes
could reasonably be expected to affect the use of the phones or compatibility with the net work, the telephone
company is required to give advanced written notice to the user, allowing the user to take appropriate steps to
maintain telephone service.
D. Maintenance Limitations
Maintenance limitations on the phones must be performed only by the manufacturer or its authorized agent.
The user may not make any changes and/or repairs expect as specifically noted in this manual. Therefore, note
that unauthorized alternations or repair may affect the regulatory status of the system and may void any
remaining warranty.
1. INTRODUCTION

- 4 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
LGE Internal Use Only
E. Notice of Radiated Emissions
This model complies with rules regarding radiation and radio frequency emission as defined by local regulatory
agencies. In accordance with these agencies, you may be required to provide information such as the following
to the end user.
F. Pictures
The pictures in this manual are for illustrative purposes only; your actual hardware may look slightly different.
G. Interference and Attenuation
A phone may interfere with sensitive laboratory equipment, medical equipment, etc. Interference from
unsuppressed engines or electric motors may cause problems.
H. Electrostatic Sensitive Devices
ATTENTION
Boards, which contain Electrostatic Sensitive Device (ESD), are indicated by the sign.
Following information is ESD handling:
• Service personnel should ground themselves by using a wrist strap when exchange system boards. • When
repairs are made to a system board, they should spread the floor with anti-static mat which is also grounded.
• Use a suitable, grounded soldering iron. • Keep sensitive parts in these protective packages until these are used.
• When returning system boards or parts like EEPROM to the factory, use the protective package as described.

2. PERFORMANCE
- 5 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
2.1 Product Name
LG-E977 : WCDMA 850/1900/2100+GSM850/EGSM/DCS/PCS, LTE B7, 17
(HSUPA 5.8Mbps(cat6)/HSPA+ 42Mbps(cat24)/GPRS Class12/EDGE Class12)
2.2 Supporting Standard
Item Feature Comment
Supporting Standard WCDMA(FDD1,2,5)/EGSM/GSM850/DCS1800/PCS1900
with seamless handover
Phase 2+(include AMR)
SIM Toolkit : Class 1, 2, 3, C-E
Frequency Range WCDMA(FDD1) TX : 1920 – 1980 MHz
WCDMA(FDD1) RX : 2110 – 2170 MHz
WCDMA(FDD2) TX : 1850 – 1910 MHz
WCDMA(FDD2) RX : 1930 – 1990 MHz
WCDMA(FDD5) TX : 824 – 849 MHz
WCDMA(FDD5) RX : 869 – 894 MHz
EGSM TX : 880 – 915 MHz
EGSM RX : 925 – 960 MHz
GSM850 TX : 824 – 849 MHz
GSM850 RX : 869 – 894 MHz
GSM900 TX : 880 – 915 MHz
GSM900 RX : 925 – 960 MHz
DCS1800 TX : 1710 – 1785 MHz
DCS1800 RX : 1805 – 1880 MHz
PCS1900 TX : 1850 – 1910 MHz
PCS1900 RX : 1930 – 1990 MHz
LTE Band7 TX : 2500 – 2570 MHz
LTE Band7 RX : 2620 – 2690 MHz
LTE Band17 TX : 704 – 716 MHz
LTE Band17 RX : 734 – 746 MHz
Application Standard
2.3 Main Parts : GSM Solution
Item Part Name Comment
AP Chip APQ8064 : Qualcomm
CP Chip MDM9215M : Qualcomm
RF Chip WTR1605L : Qualcomm
2. PERFORMANCE
2.1 Product Name
2.2 Supporting Standard
LG-E977 : WCDMA 850/1900/2100+GSM850/EGSM/DCS/PCS, LTE B7, 17
(HSUPA 5.8Mbps(cat6)/HSPA+ 42Mbps(cat24)/GPRS Class12/EDGE Class12)
2.3 Main Parts : GSM Solution

2. PERFORMANCE
- 6 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
2.4 HW Features
Item Feature Comment
Form Factor DOP type
Battery
1) Capacity
Standard : Li-Ion Polymer, 2100mAh
2) Packing Type : Soft Pack
Size Standard :
131.9 x 68.9 x 8.45 mm
Weight 141 g (TBD) With Battery
PCB Full Layer type, 12 Layers , 0.65t
Stand by time
2G Up to 460 hrs
3G Up to 420 hrs
@ Paging Period 5 (2G)
@ DRX 7 (3G)
Charging time 3 hrs. 15mins @ Power Off /
2100mAh
Talk time 2G Up to 10 hrs. 45mins
3G Up to 12 hrs. 40mins
@ Tx=Max(2G)
@ Tx = 12dBm (3G)
RX sensitivity
WCDMA(FDD1) : -106.7 dBm
WCDMA(FDD2) : -106.7 dBm
WCDMA(FDD5) : -106.7 dBm
EGSM : -105 dBm
GSM850 : -105 dBm
DCS 1800 : -105 dBm
PCS 1900 : -105 dBm
LTE : - 97dBm
TX output power
WCDMA/
GSM/
LTE/
GPRS
WCDMA :
23dBm/3.84MHz,+1/-
3dBm
EGSM : 33dBm
GSM850 : 33 dBm
DCS1800 : 30dBm
PCS 1900: 29.5 dBm
LTE : 23dBm
2.4 HW Features

2. PERFORMANCE
- 7 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
GPRS
compatibility
EDGE
EGSM : 27 dBm
GSM850 :27dBm
DCS 1800 : 26 dBm
PCS 1900 : 26 dBm
Class3(WCDMA)
Class4 (EGSM)
Class4 (GSM850)
Class1 (PCS)
Class1 (DCS)
GPRS
Class 12 E2 (GSM850/GSM900) E2 (DCS/PCS)
EDGE compatibility EDGE Class 12
SIM card type Plug-In SIM
3.0V /1.8V
Display Main LCD (HD)
TFT Main LCD(4.67”, 768X1280)
Built-in Camera 13M Camera, 1.3M secondary
Status Indicator YES
Keypad Side Key : 3
Side Key :
Volume up,down,
power key
ANT
Main : LDS(Laser Direct Structure) type
Sub : F-PCB Type
NFC : Attached Battery cover
System connector 5 Pin Micro USB 2.0 HS
Ear Phone Jack 3.5Phi, 4 Pole, Stereo
PC synchronization Yes
Memory(AP) eMMC : 32GB
LP-DDR2 : 16GB
Speech coding FR, HR, EFR HR/FR,AMR HR/ FR, SAIC
Data & Fax Built in Data & Fax support
Vibrator Built in Vibrator
BlueTooth V4.0 BLE (BT Low Energy)
MIDI(for Buzzer SW Decoded 72Poly

2. PERFORMANCE
- 8 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Cell power(dBm) GSM WCDMA LTE Comment
Bar 5->4 -80dBm ±3dBm -78dBm ±3dBm -84dBm ±3dBm
1. Cell Connecteted
& CPICH level
= 3.3
2. LTE l RSRP
Bar 4->3 -89dBm ±3dBm -87dBm ±3dBm -95dBm ±3dBm
Bar 3->2 -98dBm ±3dBm -97dBm ±3dBm -104dBm ±3dBm
Bar 2->1 -104dBm ±3dBm -103dBm ±3dBm -114dBm ±3dBm
Bar 1->No
service No service No service No service
1) RSSI Display
LGE Internal Use Only
Function)
Music Player MP3/WMA/AAC/MIDI/EAAC+/AAC+/3GPP/MIDI/
AMR/MMF/MP4/WAV
Video Player MPEG4, H.264, H.263 + AMR-NB, WMV7, WMV8,
WMV9, DIVX, WVC1
Camcorder MPEG4 or H.263, H.264
Voice Recording Yes
Speaker Phone mode
Support Yes
Travel Adapter Yes
CDROM No
Stereo Headset Yes
Data Cable Yes
T-Flash
(External Memory) NO
1) RSSI Display
Cell Power
[dBm]
GSM WCDMA LTE Comment
Bar 54 -80 ± 3dB -78 ± 3dB -84 ± 3dB
1. Call Connected
& CPIPH Level=-
3.3
2. LTE: RSRP
Bar 43 -89 ± 3dB -87 ± 3dB -95 ± 3dB
Bar 32 -98 ± 3dB -97 ± 3dB -104 ± 3dB
Bar 21 -104 ± 3dB -103 ± 3dB -114 ± 3dB
Bar 1
No Service No Service No Service No Service
Measure RSSI after 10 seconds if you change power.
Measure RSSI after 10 seconds if you change power.

2. PERFORMANCE
- 9 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
2) Charging Time
210 minutes under
3) Travel Charger
Input : 100 ~ 240 V, 50/60 Hz
Output : 5.0V, 1200 mA
4) Battery Type
Li-ion Battery Pack, 2100 mAh
Standard Voltage : 3.8 V, Battery Full Charge Voltage : 4.35V
5) Current Consumption
ITEM
Specification
GSM WCDMA LTE
1. Sleep Mode Less than 6 mA 6mA or less 9mA less than
2. Sleep : Ear jack to
connect Less than 7.5 mA 7.5mA or less 10.5mA or less
3. Standby (Sleep & Idle
current average) 9mA Less than @ P.P 5 9mA less than @ DRX 7 11mA or less
4. BT Connected Standby
10.5mA quiescent
current compared to less
than (less than 1.5mA)
10.5mA quiescent
current compared to
less than (less than
1.5mA)
12.5mA quiescent
current compared to less
than (less than 1.5mA)
5. Talk Mode GSM LVL 5
400 mA or less @ Avg
- Max Pwr
600mA or less
@ Avg
- Tx 10dBm
400 mA or less @ Avg
450mA or less LTE Cat2 @
TX 10dBm
6. No SVC Mode 200 mA or less 200 mA or less
7. Power Off Mode 200uA or less 200uA or less 200uA or less
5) Current Consumption
2) Charging Time
210 minutes under
3) Travel Charger
Input : 100 ~ 240 V, 50/60 Hz
Output : 5.0V, 1200 mA
4) Battery Type
Li-ion Battery Pack, 2100 mAh
Standard Voltage : 3.8 V, Battery Full Charge Voltage : 4.35V

2. PERFORMANCE
- 10 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
6) Battery Bar
Battery Bar Specification Battery Bar Specification
Bar 20(Full) 98% Bar 9 -> Bar 8 43% -> 42%
Bar 20 -> Bar 19 98% -> 97% Bar 8 -> Bar 7 38% -> 37%
Bar 19 -> Bar 18 93% -> 92% Bar 7 -> Bar 6 33% -> 32%
Bar 18 -> Bar 17 88% -> 87% Bar 6 -> Bar 5 28% -> 27%
Bar 17 -> Bar 16 83% -> 82% Bar 5 -> Bar 4 23% -> 22%
Bar 16 -> Bar 15 78% -> 77% Bar 4 -> Bar 3 18% -> 17%
Bar 15 -> Bar 14 73% -> 72% Bar 3 -> Bar 2 13% -> 12%
Bar 14 -> Bar 13 68% -> 67% Bar 2 -> Bar 1 8% -> 7%
Bar 13 -> Bar 12 63% -> 62% Bar 1 -> Bar 0 3% -> 2%
Bar 12 -> Bar 11 58% -> 57% Power off 1%이하
Bar 11 -> Bar 10 53% -> 52% Low battery pop-up 15% , 5%, 0%
Bar 10 -> Bar 9 48% -> 47%
6) Battery Bar

2. PERFORMANCE
- 11 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
2.5 SW Features
Item Feature Comment
RSSI 1 ~ 5 Levels
Battery Charging 0 ~ 7 Levels
Key Volume 0 ~ 7 Level
Audio Volume 0 ~ 15 Level
Time / Date Display Yes
Multi-Language Yes English, Espanol, Franch, Korea,
Chinese
Quick Access Mode Phone / Messaging / Apps / Web /
Camera
PC Sync No
Speed Dial Yes Voice mail center -> 1 key
Profile Yes not same with feature phone
setting
CLIP / CLIR Yes
Phone Book
Name / Number / Email / Website /
Postal addresses / Organizations /
Groups / Birthday Notes / Ringtone
There is no limitation on the
number of items. It depends on
available memory amount.
Last Dial Number Yes
There is no limitation on the
number of items. It depends on
available memory amount..
Last Received
Number Yes
There is no limitation on the
number of items. It depends on
available memory amount...
Last Missed Number Yes
There is no limitation on the
number of items. It depends on
available memory amount...
Search by Number
/ Name Name / Number
Group Yes
There is no limitation on the
number of items. It depends on
available memory amount.
2.5 SW Features

2. PERFORMANCE
- 12 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
Fixed Dial Number Yes
Service Dial Number No
Own Number Yes Read / Write
Voice Memo No Only Support Voice Command
Call Reminder No
Network Selection Automatic
Mute Yes
Call Divert No
Call Barring No
Call Charge (AoC) No
Call Duration Yes
SMS (EMS)
There is no limitation on the number
of items. It depends on available
memory amount.
EMS does not support.
SMS Over GPRS No
EMS Melody / Picture No
Send / Receive / Save No
MMS MPEG4
Send / Receive / Save Yes
Long Message MAX 761 characters SMS 5 concatenated
Cell Broadcast Yes
Download Yes
Game No
Calendar Yes
Memo No
World Clock Yes
Unit Convert No

2. PERFORMANCE
- 13 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
Stop Watch No
Wall Paper Yes
WAP Browser No WAP stack and wml are not
supported.
Download Melody /
Wallpaper Yes Over web browser
SIM Lock Yes Operator Dependent
SIM Toolkit Class 1, 2, 3, C, D
MMS Yes Google MMS Client
EONS Yes
CPHS Yes V4.2
ENS Yes
Camera Yes 8M AF
VT : 1.3 M HD
JAVA No Android do not support JAVA
Voice Dial Yes
IrDa No
Bluetooth Yes Ver. 4.0+LE
FM radio No
GPRS Yes Class 12
EDGE
Yes
Class 12
Hold / Retrieve Yes
Conference Call
Yes
Max. 7
DTMF Yes
Memo pad
Yes
TTY Yes
AMR Yes
SyncML No
IM Yes GTalk
Email Yes

2. PERFORMANCE
- 14 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
2.6 HW SPEC.
1) GSM transceiver specification
Item Specification
Phase Error Rms : 5°
Peak : 20 °
Frequency Error GSM : 0.1 ppm
DCS/PCS : 0.1 ppm
EMC(Radiated Spurious Emission
Disturbance) GSM/DCS : < -28dBm
Transmitter Output power and Burst
Timing
GSM : 5dBm – 33dBm ± 3dB
DCS/PCS : 0dBm – 30dBm ± 3dB
Burst Timing <3.69us
Spectrum due to modulation out to
less than 1800kHz offset
200kHz : -36dBm
600kHz : -51dBm/-56dBm
Spectrum due to modulation out to
larger than 1800kHz offset to the
edge of the transmit band
GSM :
1800-3000kHz :< -63dBc(-46dBm)
3000kHz-6000kHz : <-65dBc(-46dBm)
6000kHz < : < -71dBc(-46dBm)
DCS :
1800-3000kHz :< -65dBc(-51dBm)
6000kHz < : < -73dBc(-51dBm)
Spectrum due to switching transient 400kHz : -19dBm/-22dBm(5/0), -23dBm
600kHz : -21dBm/-24dBm(5/0), -26dBm
Reference Sensitivity – TCH/FS Class II(RBER) : -105dBm(2.439%)
Usable receiver input level range 0.012(-15 - -40dBm)
Intermodulation rejection – Speech
channels
± 800kHz, ± 1600kHz
: -98dBm/-96dBm (2.439%)
AM Suppression
- GSM : -31dBm
- DCS : -29dBm
-98dBm/-96dBm (2.439%)
Timing Advance ± 0.5T
2.6 HW SPEC
1) GSM transceiver specication

2. PERFORMANCE
- 15 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
2) WCDMA transmitter specification
Item Specification
Transmit Frequency
Band 1 : 1850 ~ 1910 MHz
Band2 : 1920 MHz ~ 1980 MHz
Band5 : 824 - 849 MHz
Maximum Output Power +22.5 dBm / 3.84 MHz, +1 / -3 dB
Frequency Error within ±0.1 PPM
Open Loop Power Control Normal Conditions : within ±9 dB,
Extreme Conditions : within ±12 dB
Minimum Transmit Power < -50 dBm /3.84 MHz
Occupied Bandwidth < 5 MHz at 3.84 Mcps (99% of power)
Adjacent Channel Leakage
Power Ratio (ACLR)
> 33 dB @ ±5 MHz,
> 43 dB @ ±10 MHz
Spurious Emissions
|f-fc| > 12.5 MHz
< -36 dBm / 1 kHz RW @ 9 kHz ≤ f < 150 kHz
< -36 dBm / 10 kHz RW @ 150 KHz ≤ f < 30 MHz
< -36 dBm / 100 kHz RW @ 30 MHz ≤ f < 1 GHz
< -30 dBm / 1 MHz RW @ 1 GHz ≤ f < 12.75 GHz
< -60 dBm / 3.84 MHz RW @ 869 MHz ≤ f ≤ 894 MHz
< -60 dBm / 3.84 MHz RW @ 1930 MHz ≤ f ≤ 1900 MHz
< -60 dBm / 3.84 MHz RW @ 2110 MHz ≤ f ≤ 2155 MHz
< -67 dBm / 100 kHz RW @ 925 MHz ≤ f ≤ 935 MHz
< -79 dBm / 100 kHz RW @ 935 MHz < f ≤ 960 GHz
< -71 dBm / 100 kHz RW @ 1805 MHz ≤ f ≤ 1880 MHz
< -41 dBm / 300 kHz RW @ 1884.5 MHz < f < 1919.6 MHz
Transmit Intermodulation < -31 dBc @ 5 MHz & < -41 dBc @ 10 MHz
when Interference CW Signal Level = -40 dBc
Error Vector Magnitude < 17.5 %, when Pout ≥ -20 dBm
Peak Code Domain Error < -15 dB at Pout ≥-20 dBm
2) WCDMA transmitter specication

2. PERFORMANCE
- 16 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
3) WCDMA receiver specification
Item Specification
Receive Frequency
Band1 : 2110 ~ 2170 MHz
Band 2 : 1930 ~ 1990 MHz
Band5 :869 ~ 894MHz
Reference Sensitivity Level Band1 : BER < 0.001 when Îor = -106.7 dBm / 3.84 MHz
Band4 : BER < 0.001 when Îor = -103.7 dBm / 3.84 MHz
Maximum Input Level BER < 0.001 when Îor = -25 dBm / 3.84 MHz
Adjacent Channel Selectivity
(ACS)
ACS > 33 dB where BER < 0.001 when
Îor = -92.7 dBm / 3.84 MHz
& Ioac = –52 dBm / 3.84 MHz @ ±5 MHz
Blocking Characteristic
BER < 0.001 when Îor = -103.7 dBm / 3.84 MHz
& Iblocking = -56 dBm / 3.84 MHz @ Fuw(offset) = ±10 MHz
or Iblocking = -44 dBm / 3.84 MHz @ Fuw(offset) = ±15 MHz
Spurious Response BER < 0.001 when Îor = -103.7 dBm / 3.84 MHz
& Iblocking = -44 dBm
Intermodulation
BER < 0.001 when Îor= -103.7 dBm / 3.84 MHz
& Iouw1 = -46 dBm @ Fuw1(offset) = ±10 MHz
& Iouw2 = -46 dBm / 3.84 MHz @ Fuw2(offset) = ±20 MHz
Spurious Emissions < -57 dBm / 100 kHz BW @ 9 kHz ≤ f < 1 GHz
< -47 dBm / 1 MHz BW @ 1 GHz ≤ f ≤ 12.75 GHz
Inner Loop Power Control
In Uplink
Adjust output(TPC command)
cmd 1dB 2dB 3dB
+1 +0.4/1.6 +1/3 +1.5/4
0 -0.5/+0.5 -0.5/+0.5 -0.5/+0.5
-1 -0.4/-1.6 -1/-3 -1.5/-4
group(10equal command group)
+1 +8/+12 +16/+24
3) WCDMA receiver specication

2. PERFORMANCE
- 17 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
4) HSDPA transmitter specification
Item Specification
Transmit Frequency
Band1 : 1920 MHz ~ 1980 MHz
Band8 : 880MHz~915 MHz
Maximum Output Power
Sub-Test
1=1/15, 2=12/15 21~25dBm / 3.84 MHz
3=13/15 4=15/8 20~25dBm / 3.84 MHz
5=15/7 6=15/0 19~25dBm / 3.84 MHz
HS-DPCCH
Sub-
test in
table
C.10.1.4
Power
step
Power step
slot boundary
Power
step
size, P
[dB]
Transmitter power
step tolerance [dB]
5
1 Start of
Ack/Nack 6 +/- 2.3
2 Start of CQI 1 +/- 0.6
3 Middle of CQI 0 +/- 0.6
4 End of CQI 5 +/- 2.3
Spectrum Emission Mask
Sub-Test : 1=1/15, 2=12/15, 3=13/15, 4=15/8, 5=15/7, 6=15/0
Frequency offset
from carrier
△
fMinimum requirement Measurement
Bandwidth
2.5 ~ 3.5 MHz -35-15×(
△
f-2.5)dBc 30 kHz
3.5 ~ 7.5 MHz -35-1×(
△
f-3.5)dBc 1 MHz
7.5 ~ 8.5 MHz -35-10×(
△f-7.5)dBc
1 MHz
8.5 ~ 12.5 MHz -49dBc 1 MHz
Adjacent Channel
Leakage
Power Ratio (ACLR)
Sub-Test : 1=1/15, 2=12/15, 3=13/15, 4=15/8, 5=15/7, 6=15/0
> 33 dB @ ±5 MHz
> 43 dB @ ±10 MHz
Error Vector Magnitude < 17.5 %, when Pout ≥ -20 dBm
4) HSDPA transmitter specication

2. PERFORMANCE
- 18 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
5) HSDPA receiver specication
LGE Internal Use Only
5) HSDPA receiver specification
Item Specification
Receive Frequency Band1 : 2110 ~ 2170 MHz
Band8 : 925 ~ 960Hz
Maximum Input Level
(BLER or R), 16QAM Only
Sub-Test : 1=1/15, 2=12/15, 3=13/15, 4=15/8, 5=15/7, 6=15/0
BLER < 10% or R >= 700kbps
6) WLAN 802.11b transceiver specification
Item Specification
Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13 )
Tx Power Level ≤ 20dBm under
Frequency Tolerance within ±25 PPM
Chip clock Frequency
Tolerance within ±25 PPM
Spectrum Mask ≤ -30 @ fc-22MHz< f <fc-11MHz and fc+11MHz< f <fc+22MHz
≤ -50 @ f < fc-22MHz and f > fc+22MHz
Power ramp on/off time ≤ 2us
Carrier Suppression ≤ -15dB
Modulation Accuracy
(Peak EVM) ≤ 35%
Spurious Emissions
< -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity ≤ -85dBm(1Mbps,2Mbps,5.5Mbps,11Mbps) @ FER ≤ 8%
Rx Max input Sensitivity ≥ -10dBm(1Mbps,2Mbps,5.5Mbps,11Mbps) @ FER ≤ 8%
Rx Adjacent Channel
Rejection
≥ 35dB @FER ≤ 8%,
interference input signal -70dBm@fc±25MHz(11Mbps)
6) WLAN 802.11b transceiver specication
2400 MHz~ 2483.5 MHz (CH1 ~ CH11)

2. PERFORMANCE
- 19 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
7) WLAN 802.11g transceiver specication
LGE Internal Use Only
7) WLAN 802.11g transceiver specification
Item Specification
Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13 )
Tx Power Level ≤ 20dBm
Frequency Tolerance within ±25 PPM
Chip clock Frequency
Tolerance within ±25 PPM
Spectrum Mask
≤ -20 @ ±11MHz offset (9Mhz ~ 11MHz)
≤ -28 @ ±20MHz offset (11MHz ~ 20Mhz)
≤ -40 @ ±30MHz offset (20MHz ~ 30Mhz)
Transmitter constellation error
(rms EVM) ≤ -5dB
Spurious Emissions
< -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity
PER ≤ 10%
-82dBm@6Mbps, -81dBm@9Mbps, -79dBm@12Mbps
-77dBm@18Mbps, -74dBm@24Mbps, -70dBm@36Mbps
-66dBm@48Mbps, -65dBm@54Mbps
Rx Max input Sensitivity ≥ -20dBm(6,9,12,18,24,36,48,54Mbps) @ PER ≤ 10%
Rx Adjacent Channel
Rejection
PER ≤ 10%,
ACR ≥ 16dB@6Mbps, ACR ≥ 15dB@9Mbps,
ACR ≥ 13dB@12Mbps, ACR ≥ 11dB@18Mbps,
ACR ≥ 8dB@24Mbps, ACR ≥ 4dB@36Mbps
ACR ≥ 0dB@48Mbps, ACR ≥ -1dB@54Mbps
※ACR shall be measured by setting the desired signal's strength 3
dB above the rate-dependent
sensitivity specified in min input sensitivity
2400 MHz~ 2483.5 MHz (CH1 ~ CH11)

2. PERFORMANCE
- 20 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
8) WLAN 802.11n transceiver specication
LGE Internal Use Only
8) WLAN 802.11n transceiver specification
Item Specification
Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13 )
Tx Power Level ≤ 20dBm
Frequency Tolerance within ±25 PPM
Chip clock Frequency
Tolerance within ±25 PPM
Spectrum Mask
≤ -20 @ ±11MHz offset (9Mhz ~ 11MHz)
≤ -28 @ ±20MHz offset (11MHz ~ 20Mhz)
≤ -45 @ ±30MHz offset (20MHz ~ 30Mhz)
Transmitter constellation error
(rms EVM) ≤ -5dB
Spurious Emissions
< -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity
PER ≤ 10%
[email protected], -79dBm@13Mbps, -77dBm@19.5Mbps
-74dBm@26Mbps, -70dBm@39Mbps, -66dBm@52Mbps
[email protected]ps, -64dBm@65Mbps
Rx Max input Sensitivity ≥ -20dBm(6,9,12,18,24,36,48,54Mbps) @ PER ≤ 10%
Rx Adjacent Channel
Rejection
PER ≤ 10%,
ACR ≥ 16dB@6.5Mbps, ACR ≥ 13dB@13Mbps,
ACR ≥ 11dB@19.5Mbps, ACR ≥ 8dB@26Mbps,
ACR ≥ 4dB@39Mbps, ACR ≥ 0dB@52Mbps
ACR ≥ [email protected]bps, ACR ≥ -2dB@65Mbps
※ACR shall be measured by setting the desired signal's strength
3 dB above the rate-dependent
sensitivity specified in min input sensitivity
2400 MHz~ 2483.5 MHz (CH1 ~ CH11)
