LG Telus 200 User manual

User Guide
LLGG220000
Guide de L’utilisateur
LLGG220000
LLGG220000
User Guide
MMBB0183201(1.1)
H
CX200(TELUS)_cover_1.1.qxd 12/2/05 8:46 AM Page 1

Copyright ©2005 LG Electronics, Inc. All rights reserved.
LG and the LG logo are registered trademarks of LG Group
and its related entities. All other trademarks are the property
of their respective owners.
CX200(TELUS)_cover_1.1.qxd 12/2/05 8:46 AM Page 2

IMPORTANT SAFETY PRECAUTIONS
1
IMPORTANT SAFETY PRECAUTIONS
Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is
given in this user guide.
WARNING! Violation of the instructions may cause serious injury or death.
1. Never use an unapproved battery since this could damage the phone and/or battery and could
cause the battery to explode.
2. Never place your phone in a microwave oven as it will cause the battery to explode.
3. Do not dispose of your battery by fire or with hazardous or flammable materials.
4. Make sure that no sharp-edged items such as animal’s teeth or nails, come into contact with the
battery. There is a risk of this causing a fire.
5. Store the battery out of reach of children.
6. Be careful that children do not swallow any parts as this could cause asphyxiation or suffocation.
CX200_Eng_Telus_1.1.qxd 11/22/05 1:53 PM Page 1

IMPORTANT SAFETY PRECAUTIONS
2
IMPORTANT SAFETY PRECAUTIONS
1. Unplug the power cord and charger during lightning storms to avoid electric shock or fire.
2. When in a car, do not leave your phone or set up the hands-free kit near to the air bag. If
wireless equipment is improperly installed and the air bag is activated, you may be seriously
injured.
3. Do not use a hand-held phone while driving.
4. Do not use the phone in areas where its use is prohibited. (i.e.: aircraft, hospital).
5. Do not expose the battery charger or adapter to direct sunlight or use it in places with high
humidity, such as a bathroom.
6. Never store your phone in temperatures less than -15°C or greater than 50°C
7. Do not use harsh chemicals (i.e.: alcohol, benzene, thinners, etc.) or detergents to clean your
phone. There is a risk of this causing a fire.
8. Do not drop, strike, or shake your phone severely. Such actions may harm the internal circuit
boards of the phone.
9. Do not use your phone in high explosive areas as the phone may generate sparks.
10. Do not damage the power cord by bending, twisting, pulling or heating. Do not use the
Battery Charger if it is loose as it may cause a fire or electric shock.
CX200_Eng_Telus_1.1.qxd 11/22/05 1:53 PM Page 2

3
IMPORTANT SAFETY PRECAUTIONS
1. Do not place any heavy items on the power cord. Do not allow the power cord to be crimped as
it may cause fire or electric shock.
2. Do not handle the phone with wet hands while it is being charged. It may cause an electric
shock or seriously damage your phone.
3. Do not disassemble the phone.
4. Do not place or answer calls while charging the phone as it may short-circuit the phone and/or
cause electric shock or fire.
5. Only use the batteries, antennas and chargers provided by LG. The warranty will not be applied
to products provided by other suppliers.
6. Only authorized personnel should service the phone and its accessories. Faulty installation or
service may result in accidents and consequently invalidate the warranty.
7 Do not hold or let the antenna come in contact with your body during a call.
8. An emergency call can be made only within a service area. For an emergency call, make sure that
you are within a service area and that the phone is turned on.
CX200_Eng_Telus_1.1.qxd 11/22/05 1:53 PM Page 3

CONTENTS
CONTENTS
4
IMPORTANT SAFETY
PRECAUTIONS 1
CONTENTS 4
Welcome 9
Important Information
FCC Part 15 Class B
Compliance
Industry Canada Compliance
Technical Details
FCC RF Exposure
Information 11
Phone Overview 12
Menus Overview 14
Getting Started with Your
Phone 16
The Battery
Installing the Battery
Removing the Battery
Charging the Battery
Battery Charge Level
Turning the Phone On and Off 17
Turning the Phone On
Turning the Phone Off
Signal Strength
Screen Icons 18
Making Calls 19
Correcting Dialing Mistakes
Redialing Calls
Receiving Calls
Some of contents in this user guide may be different from your phone depending on the software of the phone
or your service provider. Features and specifications might be subject to change without prior notice.
CX200_Eng_Telus_1.1.qxd 11/22/05 1:53 PM Page 4

5
CONTENTS
Quick Access to
Convenient Features 20
Manner Mode
Lock Mode
Mute Function
Volume Quick Adjustment
Call Waiting 21
Caller ID
Speed Dialing
Entering and Editing
Information 22
Text Input
Text Input Examples 23
Using Abc (Multi-tap) Text Input
Using T9 Mode Text Input 24
Using the NEXT Key
Ading Words to the T9 Database
Contacts in Your Phone’s
Memory 25
Contacts Entries
The Basics of Storing Contacts Entries
Options to Customize Your Contacts 26
Editing Contacts Entries 28
Deleting 30
Phone Numbers With Pauses 31
Searching Your Phone’s Memory 32
Making a Call From Your Phone’s
Memory
Using Phone Menus 34
Menu Access
Contacts
Access and Options
1. List Entries 35
2. New Entry
3. Groups 36
4. Speed Dials
5. Erase all Contacts
CX200_Eng_Telus_1.1.qxd 11/22/05 1:53 PM Page 5

CONTENTS
CONTENTS
6
Call History 37
Access and Options
1. All Calls
2. Dialed Calls
3. Received Calls 38
4. Missed Calls
5. Erase History
6. Timers
Messaging 39
Access and Options
1. Voice Mail 40
2. Text and Multimedia
1. Send New
2. Inbox 41
3. Outbox/Sent 42
4. Drafts 43
5. Saved
6. Erase Messages 44
7. Settings 44
8. Memory Status 45
3. Web Alert
4. E-mail
5. IM & Chat
Do More 46
Access and Options
1. Wireless Web
2. Sounds 47
2.1 Ringtones
2.2 Sound Clips
2.3 Voice Memo 48
3. Images 49
3.1 Wallpaper
3.2 Image Clips
3.3 Picture Album
3.4 Online Album
4. Games
5. Tools 50
Get New
Calculator
Alarm Clock 51
Scheduler
Notepad 52
Ez Tip Calc 53
World Clock
6. Favourites 54
6.1 Shortcode List
6.2 Web Links
7. Memory Status
Camera 55
Access and Options
1. Take Picture
2. Take Video 56
3. Picture Album 57
4. Video Album
CX200_Eng_Telus_1.1.qxd 11/22/05 1:53 PM Page 6

7
CONTENTS
Settings 58
Access and Options
1. Sounds
1.1 Ringers
1.2 Keypad 59
1.3 Volume
1.4 Alerts 60
2. Display 61
2.1 Banner
2.2 Wallpaper
2.3 Main Display
2.4 Keypad light 62
2.5 Time and Date
2.6 Menu Style 63
2.7 Fonts
3. Games/Tools
3.1 Backlight Settings
3.2 Volume
3.3 Notification 64
4. Others 64
4.1 Assign Shortcut
4.2 Call Setup
4.3 Language 65
4.4 TTY Mode 66
4.5 Data Setup
5. Advanced 67
5.1 Phone Info
5.2 System 68
5.3 Security 69
6. Airplane Mode 71
Safety 72
TIA Safety Information
Exposure to Radio Frequency Signal
Antenna Care
Phone Operation
Tips on Efficient Operation
Driving 73
Electronic Devices
Pacemakers
Hearing Aids 74
Other Medical Devices
Health Care Facilities
Vehicles
Posted Facilities
Aircraft
Blasting Areas
Potentially Explosive Atmosphere 75
For Vehicles Equipped with an Air Bag
CX200_Eng_Telus_1.1.qxd 11/22/05 1:53 PM Page 7

CONTENTS
CONTENTS
8
Safety Information 75
Charger and Adapter Safety
Battery Information and Care
Explosion, Shock, and Fire Hazards 76
General Notice
FDA Consumer Update 78
Consumer Information on
SAR 85
Accessories 87
Travel Charger
Battery
Vehicle Power Charger
USB Data Cable
Hands-Free Car Kit (Portable)
Headset
Holster
Warranty information 88
CX200_Eng_Telus_1.1.qxd 11/22/05 1:53 PM Page 8

WELCOME
Congratulations for choosing the advanced and compact
LG 200 cellular phone, designed to operate with the
latest digital mobile communication technology, Code
Division Multiple Access (CDMA). Along with the many
advanced features of the CDMA system, such as greatly
enhanced voice clarity, this phone offers:
1. Large, easy-to-read, 9-line backlight LCD with status
icons.
2. Paging, messaging, Voice Mail and Caller ID.
3. 23-key keypad.
4. Menu-driven interface with prompts for easy operation
and configuration.
5. Any key answer, auto answer, auto retry, one-touch dial
and speed dialing with 99 memory locations.
6. Bilingual (English and French) capabilities.
Important Information
This user’s guide provides important information on the
use and operation of your phone. Please read all the
information carefully prior to using the phone for the
best performance and to prevent any damage to or
misuse of the phone. Any unapproved changes or
modifications will void your warranty.
FCC Part 15 Class B Compliance
This device and its accessories comply with part 15 of
FCC rules. Operation is subject to the following two
conditions: (1) This device and its accessories may not
cause harmful interference, and (2) this device and its
accessories must accept any interference received,
including interference that causes undesired operation.
Industry Canada Compliance
This phone complies with Industry Canada RSS 133.
This phone complies with the Class B limits for radio
noise emissions as set out in the interference causing
standard entitled "Digital Apparatus" ICES-003 of
Industry Canada.
Technical Details
The LG 200 is an all digital phone that operates on both
Code Division Multiple Access (CDMA) frequencies:
cellular services at 800 Mhz and Personal
Communication Services (PCS) at 1.9 Ghz. Also, the
LG 200 works on Advanced Mobile Phone Service
(AMPS). We call it a tri-mode phone. Since the phone
operates on Cellular, PCS and AMPS, the call fail rate is
WELCOME
9
CX200_Eng_Telus_1.1.qxd 11/22/05 1:53 PM Page 9

10
WELCOME
WELCOME
CDMA Standard
Basic Air
Interface
TIA/EIA-95A
TSB-74
ANSI J-STD-008
TIA/EIA-IS2000
ANSI TIA/EIA
553A
CDMA Dual-Mode Air Interface
14.4kbps radio link protocol and
inter-band operations
IS-95 adapted for PCS frequency
band CDMA2000 1xRTT Air
Interface
Advanced Mobile Phone Service
MAS-BS
PCSC-RS
Intersystem operations
Nom-signaling data comm.
Cellular base station
Cellular mobile station
PCS personal station
PCS base station
Speech CODEC
TIA/EIA/IS-634
TIA/EIA/IS/651
TIA/EIA/IS-41-C
TIA/EIA/IS-124
TIA/EIA/IS-97
TIA/EIA/IS-98
ANSI J-STD-018
ANSI J-STD-019
TIA/EIA/IS-125
TIA/EIA/IS-96-B
TIA/EIA/IS-99
TIA/EIA/IS-637
TIA/EIA/IS-657
IS-801
TIA/EIA/IS-707-A
Speech CODEC
Async Data and Fax
Short message service
Packet Data
Position Determination Service
(gpsOne)
High Speed Packet Data
Network
Service
Performance
Designator Description
less than on a conventional dual-mode or
singlemode phone.
CDMA technology uses a feature called DSSS
(Direct Sequence Spread Spectrum) that enables
the phone to keep communication from being
crossed and to use one frequency channel by
multiple users in the same specific area. This
results in a 10-fold capacity increase when
compared with analog mode. In addition, features
such as soft / softer handoff, hard Handoff, and
dynamic RF power control technologies combine
to reduce call interruptions.
The Cellular and PCS CDMA networks consist of
MSO (Mobile Switching Office), BSC (Base
Station Controller), BTS (Base Station
Transmission System), and MS (Mobile Station).
The following table lists some major CDMA
standards.
* TSB -74: Protocol between an IS-95A system
and ANSI J-STD-008
1xRTT system receives twice as many subscribers
in the wireless section as IS-95. Its battery life is
twice as long as IS-95. High-speed data
transmission is also possible.
CX200_Eng_Telus_1.1.qxd 11/22/05 1:53 PM Page 10

WELCOME
FCC RF Exposure Information
WARNING! Read this information before operating
the phone.
In August 1996, the Federal Communications
Commission (FCC) of the United States, with its action in
Report and Order FCC 96-326, adopted an updated
safety standard for human exposure to Radio Frequency
(RF) electromagnetic energy emitted by FCC regulated
transmitters. Those guidelines are consistent with the
safety standard previously set by both U.S. and
international standards bodies.
The design of this phone complies with the FCC
guidelines and these international standards.
Bodily Contact During Operation
This device was tested for typical use with the back of the
phone kept 3/4 inches (2 cm) from the body. To comply
with FCC RF exposure requirements, a minimum
separation distance of 3/4 inches (2 cm) must be
maintained between the user’s body and the back of the
phone, including the antenna, whether extended or
retracted. Third-party belt-clips, holsters and similar
accessories containing metallic components should not
be used. Avoid the use of accessories that cannot
maintain 3/4 inches (2 cm) distance between the user’s
body and the back of the phone and have not been
tested for compliance with FCC RF exposure limits.
Vehicle-Mounted External Antenna
(Optional, if available.)
A minimum separation distance of 8 inches (20 cm) must
be maintained between the user / bystander and the
vehicle-mounted external antenna to satisfy FCC RF
exposure requirements. For more information about RF
exposure, visit the FCC website at www.fcc.gov.
Caution
Use only the supplied and approved antenna. Use of
unauthorized antennas or modifications could impair call
quality, damage the phone, void your warranty and/or
result in violation of FCC regulations.
Do not use the phone with a damaged antenna. If a
damaged antenna comes into contact with the skin a
minor burn may result. Contact your local dealer for a
replacement antenna.
11
CX200_Eng_Telus_1.1.qxd 11/22/05 1:53 PM Page 11

12
PHONE OVERVIEW
PHONE OVERVIEW
Earpiece
Navigation Keys
Right Soft Key
END/PWR Key
Side Camera Key
BACK Key
Speaker Key
Microphone
Lock Mode Key
Alphanumeric Keypad
Flip
LCD Screen
Headset Jack
Left Soft Key
Side Keys
SEND Key
Voice Dial Key
Manner Mode Key
CX200_Eng_Telus_1.1.qxd 11/22/05 1:53 PM Page 12

PHONE OVERVIEW
13
Earpiece
Flip
Open the case to answer an incoming call and
close to end the call.
LCD Screen Displays messages and indicator icons.
Headset Jack
Left Soft Key
Use to display the function Message
menu.
Side Keys Use to adjust the ringer volume in standby
mode and the earpiece volume during a call.
SEND Key Use to place or answer calls.
Voice Dial Key Use for quick access to Voice Memo.
Manner Mode Key Use to set the mode (from
standby mode press and hold for about 3
seconds).
Navigation Keys Scrolls through the phone’s menu
options and acts as a shortcut key from standby
mode. (Contacts, Call History, Messasing, Tools,
Camera, Settings.)
Right Soft Key Use to select an action within a
menu.
Side Camera Key Use for quick access to Camera
function. (Press and hold for about 3 seconds to use
camera function.)
END Key Use to turn the power on/off and to end a
call. Also use to return to the main menu display
screen.
BACK Key Press to delete a single space or character.
Press and hold to delete entire words. Press this key
once in a menu to go back one level.
Speaker Key Use to turn the speaker on/off during a
call.
Alphanumeric Keypad Use to enter numbers and
characters and select menu items.
Lock Mode Key Use in Main Menu Screen to set the
lock function by pressing and holding the key
for about 3 seconds.
Microphone
CX200_Eng_Telus_1.1.qxd 11/22/05 1:53 PM Page 13

14
MENUS OVERVIEW
MENUS OVERVIEW
1. Contacts
1. List Entries
2. New Entry
3. Groups
4. Speed Dials
5. Erase all Contacts
2. Call History
1. All Calls
2. Dialed Calls
3. Received Calls
4. Missed Calls
5. Erase History
1. All Calls
2. Dialed Calls
3. Received Calls
4. Missed Calls
6. Timers
1. Last Call
2. Lifetime
3. Messaging
1. Voice Mail
2. Text/Multimedia
1. Send New
2. Inbox
3. Outbox/Sent
4. Drafts
5. Saved
6. Erase Messages
7. Settings
8. Memory Status
3. Web Alert
4. E-mail
5. IM & Chat
4. Do More
1. Wireless Web
2. Sounds
3. Images
4. Games
5. Tools
6. Favourites
7. Memory Status
CX200_Eng_Telus_1.1.qxd 11/22/05 1:53 PM Page 14

MENUS OVERVIEW
15
5. Camera
1. Take Picture
2. Take Video
3. Picture Album
4. Video Album
6. Settings
1. Sounds
1. Ringers
2. Keypad
3. Volume
4. Alerts
2. Display
1. Banner
2. Wallpaper
3. Main Display
4. Keypad light
5. Time and Date
6. Menu Style
7. Fonts
3. Games / Tools
1. Backlight Settings
2. Volume
3. Notification
4. Others
1. Assign Shortcut
2. Call Setup
3. Language
4. TTY Mode
5. Data Setup
5. Advanced
1. Phone Info
2. System
3. Security
6. Airplane Mode
CX200_Eng_Telus_1.1.qxd 11/22/05 1:53 PM Page 15

16
GETTING STARTED WITH YOUR PHONE
GETTING STARTED WITH YOUR PHONE
The Battery
The phone comes with a rechargeable battery. Keep
the battery charged while not in use in order to
maximize talk and standby time. The battery charge
level is shown at the top of the LCD screen.
Installing the Battery
To install the battery, insert the battery into the
opening on the back of the phone. Put the battery
cover on the battery and push it slightly upwards.
Removing the Battery
Remove the battery by pressing the upper area, and
pulling the battery.
Charging the Battery
To use the charger provided with your phone:
WARNING! Use only the charger provided with the
phone. Using any charger other than the one included
with the LG 200 may damage your phone or battery.
1. Plug the end of the adapter into the phone's
charger port and the other end into an electrical
outlet.
2. The charge time varies depending upon the
battery level. The maximum charge time for a fully
discharged battery is 3.5 hours.
Battery Charge Level
The battery charge level is shown at the top right of
the LCD screen. When the battery charge level
becomes low, the low battery sensor alerts you in
three ways: sounding an audible tone, blinking the
battery icon, and displaying
LOW BATTERY
WARNING!
If the battery charge level becomes
exceedingly low, the phone automatically switches off
and any function in progress is not saved.
Note
It is important to fully charge the battery before
initial use of the phone.
CX200_Eng_Telus_1.1.qxd 11/22/05 1:53 PM Page 16

17
GETTING STARTED WITH YOUR PHONE
Turning the Phone On and Off
Turning the Phone On
1. Install a charged battery or connect the phone to
an external power source such as a cigarette lighter
charger or hands-free car kit.
2. Press for a few seconds until the LCD screen
lights up.
Turning the Phone Off
1. Press and hold until the display turns off.
Signal Strength
Call quality depends on the signal strength in your
area. The signal strength is indicated on the screen
as the number of bars next to the signal strength
icon: The more bars, the better the signal strength. If
the signal quality is poor, move to an open area. If
you are in a building, the reception may be better
near a window.
Fully DischargedFully Charged
Note
Like any other radio device, avoid any
unnecessary contact with the antenna while your
phone is on.
CX200_Eng_Telus_1.1.qxd 11/22/05 1:53 PM Page 17

18
GETTING STARTED WITH YOUR PHONE
GETTING STARTED WITH YOUR PHONE
Screen Icons
When the phone is powered on, the top line of the LCD screen displays icons indicating the status of the phone.
To see the icons below, go to Menu->Settings->Advanced->Phone Info->Icon Glossary.
Signal strength indicator. The strength of the
signal received by the phone is indicated by the
number of bars displayed.
In Use indicator. A call is in progress.
* No icon indicates the phone is in Main Menu
Screen.
No service indicator. The phone is not
receiving a system signal.
IS-2000.
Digital.
Analog.
Alarm.
1X Data active.
1X Data dormant.
New voicemails.
Roaming.
New msgs&voice.
New msgs.
Battery strength. Indicates battery charge level.
Vibrate On.
Ringer & Vibrate.
Ringer Off / Silence All mode.
Airplane mode.
SSL.
Ringer On.
QNC Data active
CX200_Eng_Telus_1.1.qxd 11/22/05 1:53 PM Page 18
