LG VOLT LG700 User manual

Important Safety Precautions
1
Important Safety Precautions
Read these instructions. Breaking the rules may be dangerous or
illegal. Further detailed information is given in this user guide.
WARNING! Violation of the instructions may cause serious injury or
death.
1. Never use an unapproved battery since this could
damage the phone and/or battery and could cause
the battery to explode.
2. Never place your phone in a microwave oven as it will
cause the battery to explode.
3. Never store your phone in temperatures less than
-4°F or greater than 122°F.
4. Do not dispose of your battery by fire or with
hazardous or flammable materials.
5. When riding in a car, do not leave your phone or set
up the hands-free kit near tothe air bag. If wireless
equipment is improperly installed and the air bag is
deployed, you may be seriously injured.
6. Do not use a hand-held phone while driving.
7. Do not use the phone in areas where its use is
prohibited. (For example: aircraft)

Important Safety Precautions
2
Important Safety Precautions
1. Do not expose the battery charger or adapter to direct
sunlight or use it in places with high humidity, such as
abathroom.
2. Do not use harsh chemicals (such as alcohol, benzene,
thinners, etc.) or detergents to clean your phone. This
could cause a fire.
3. Do not drop, strike, or shake your phone severely. It
may harm the internal circuit boards of the phone.
4. Do not use your phone in high explosive areas as the
phone may generate sparks.
5. Do not damage the power cord by bending, twisting,
pulling, or heating. Do not use the plug if it is loose as
it may cause a fire or electric shock.
6. Do not place any heavy items on the power cord. Do
not allow the power cord to be crimped as it may
cause electric shock or fire.
7. Do not handle the phone with wet hands while it is
being charged. It maycause an electric shock or
seriously damage your phone.
8. Do not disassemble the phone.

3
Important Safety Precautions
1. Do not place or answer calls while charging the phone as it may
short-circuit the phone and/or cause electric shock or fire.
2. Do not hold or let the antenna come in contact with your body
during a call.
3. Make sure that no sharp-edged items such as animal’s teeth or
nails, come into contact with the battery. This could cause a fire.
4. Storethe battery out of reach of children.
5. Be careful thatchildren do not swallow any parts (such as
rubber plugs, earphone, connection parts of the phone, etc.)
This could cause asphyxiation or suffocation resulting in serious
injury or death.
6. Unplug the power cordand charger during lightning storms to
avoid electric shock or fire.
7. Only use the batteries and chargers provided by LG. The
warrantywill notbe applied toproductsprovided by other
suppliers.
8. Only authorized personnel should service the phone and its
accessories. Faulty installation or service may result in accidents
and consequently invalidate the warranty.
9. Your service provider programs one or more emergency phone
numbers, such as 911, that you can call under any
circumstances, even when your phone is locked. Your phone’s
preprogrammed emergency number(s) may not work in all
locations, and sometimes an emergency call cannot be placed
due to network, environmental, or interference issues.

Table of Contents
4
Table of Contents
Important Safety
Precautions 1
Table of Contents 4
Welcome 10
Technical Details 11
Important Information 11
FCC Part 15 Class B Compliance 11
Technical Details 11
FCC RF Exposure Information 13
Bodily Contact During Operation 13
Vehicle-Mounted the External
Antenna 14
FCC Notice and Cautions 14
Phone Overview15
Menus Overview 20
Getting Started with
Your Phone 24
The Battery 24
Installing the Battery 24
Removing the Battery 24
Charging the Battery 24
How to Install Your microSD™
Card 25
How to Remove Your microSD™
Card 26
Battery Charge Level 26
Turning the Phone On and Off 26
Turning the Phone On 26
Turning the Phone Off 26
Signal Strength 27
Screen Icons 27
Making Calls 27
Correcting Dialing Mistakes 28
Redialing Calls 28
Receiving Calls 28
Quick Access to
Convenient Features 29
Lock Mode 29
Speakerphone 29
Quick Volume Adjustment 29
Call Waiting 29
Caller ID 30

5
Table of Contents
Speed Dialing 30
Entering and Editing
Information 31
Contacts in Your Phone’s
Memory 32
The Basics of Storing Contact
Entries32
Phone Numbers With Pauses 32
Storing a Number with Pauses 33
Adding a Pause to an Existing
Number 33
Searching Your Phone’s Memory 33
Accessing Options 34
Making a Call From Your Phone’s
Memory 35
Using Phone Menus 36
My Account 36
Web 36
Messaging 39
1. New Text Message 39
2. Quick Text 41
3. New Picture Message 41
4. Inbox 42
5. Outbox 44
6. Drafts 45
7. Communities 46
8. Messenger 46
9. Voicemail 46
10. Web Alerts47
11. Settings 47
11.1 All Messages 47
11.2 Text Messages 48
11.3 Picture Messages 48
11.4 Edit Voicemail # 48
11.5 Web Alerts 48
12. Erase Options 49
Facebook 49
Messenger 49
Speed Dials 49

Table of Contents
6
Table of Contents
Contacts 50
1. New Contact 50
2. Contact List 50
3. Groups 51
4. Speed Dials 51
5. My Name Card 52
Call History 52
1. Missed Calls 53
2. Received Calls 53
3. Dialed Calls 53
4. All Calls 54
5. Call Timer 54
6. Data Counter 54
Camera 55
Video Camera 57
Virgin Mobile Live 58
Record Voice 59
My Stuff 59
1. Ringers 59
2. Games 60
3. Applications 60
TV & Radio 60
Motion Games 61
App Manager 61
Alarm Clock 61
World Clock 62
Notepad 63
Organizer 63
1. Calendar 63
2. Date Finder 64
Calculator 64
Drawing Panel 65
USB Mass Storage 65

7
Table of Contents
More 66
1. Voice Commands 66
1.1 Start Command 66
1.1.1 Call <Name> or <Number> 66
1.1.2 Voicemail 66
1.1.3 Missed Calls 67
1.1.4 Messages 67
1.1.5 Time & Date 67
1.1.6 Help 67
1.2 Command Mode 68
1.3 Announce Alert 68
1.4 Train Word 69
1.5 Best Match 69
2. Stopwatch 69
3. Ez Tip Calculator 70
4. Unit Converter 70
Sound 71
1. Ringers 71
2. Volume 71
3. Message Alerts 72
4. Alert Type 72
5. Service Alerts 73
6. Power On/Off Tones 73
Display 74
1. Wallpaper 74
1.1 Screen 74
1.2 Shuffle 74
2. Banner 74
3. LCD Setting 75
3.1 Power Save 75
3.2 Backlight 75
3.3 Brightness 76
4. Language 76
5. Clock & Calendar 76
6. Font Settings 77
7.Dial Font Size 77
8. Name Match for Dialing 77
9. Time Format77
Touch 78
1. Touchscreen Calibration 78
2. Touchscreen Effect 78
Bluetooth
®
79
1. Power 80
2. Add New 80
3. Paired Devices 81

Table of Contents
8
Table of Contents
4. Settings 81
4.1 My Visibility 81
4.2 My Bluetooth Info 82
4.3 Supported Profiles 82
4.4 Delete All 82
Connectivity 83
1. Network 83
1.1 System Select 83
1.2 Serving System 83
2. Location 84
Phone Settings 84
1. Auto Touch Lock 84
2. Security 85
2.1 Lock Phone 85
2.2 Restrictions 85
2.3 Change Lock Code 86
3. Memory 87
4. Reset Settings 87
Call Settings 88
1. Answer Options 88
2. Auto Retry 88
3. One Touch Dial 88
4. Auto Volume 89
5. Airplane Mode 89
6. TTY Mode 90
7.Auto Prepend 90
Phone Info 90
1. My Number 91
2. ESN/MEID 91
3. Icon Glossary 91
4. Version 91
Safety92
TIA Safety Information 92
Exposure to Radio Frequency
Signal 92
Antenna Care 92
Phone Operation 93
Tips on Efficient Operation 93
Driving 93
Electronic Devices93
Pacemakers 93
Persons with pacemakers: 94

9
Welcome
Hearing Aids 94
Other Medical Devices 94
Health Care Facilities 94
Vehicles 95
Posted Facilities 95
Aircraft 95
Blasting Areas 95
Potentially Explosive Atmosphere 95
For Vehicles Equipped with an
Air Bag 96
Safety Information 96
Charger and Adapter Safety 96
Battery Information and Care 97
Explosion, Shock, and Fire
Hazards 97
General Notice 98
Warning! Important safety
information 100
Avoiding hearing damage 100
Using your phone safely 100
Avoiding hearing damage 101
Using headsets safely 101
FDA Consumer Update 102
10Driver Safety Tips 112
Consumer Information
on SAR 116
FCC Hearing-Aid Compatibility
(HAC) Regulations for
Wireless Devices 119
Accessories 122
Limited Warranty
Statement 123
Index126

Welcome
10
Technical Details
Thank you for choosing the
LG700 cellular phone, designed
to operate with the latest digital
mobile communication
technology, Code Division
Multiple Access (CDMA). Along
with the many advanced features
of the CDMA system, such as
greatly enhanced voice clarity,
this compact phone offers:
●
Music capabilityand a
microSD™cardslot.
●
Significantlyenhanced voice
clarity.
●
Slim and sleek design with
internal antenna (referred to as
"antenna" throughout this user
guide).
●
Large, easy-to-read, 9-line
backlit LCD with status icons.
●
Paging, messaging, voice mail,
and caller ID.
●
Touchscreen and 3 key call
control.
●
Speakerphone.
●
2.0-Megapixel camera.
●
Menu-driven interface with
prompts for easy operation and
configuration.
●
Any key answer, auto answer,
auto retry, and one-touch and
speed dialing with 99 memory
locations.
●
Bilingual (English and French)
capabilities.
●
Bluetooth®wireless technology.
Note
The Bluetooth®word mark and
logos are owned by the Bluetooth
SIG, Inc, and any use of such marks
by LG Electronics is under license.
Other trademarks and trade names
are those of their respective owners.

Technical Details
11
Technical Details
Important Information
This user’s guide provides
important information on the use
and operation of your phone.
Please read all the information
carefully prior to using the
phone for the best performance
and to prevent any damage to or
misuse of the phone. Any
unapproved changes or
modifications will void your
warranty.
FCC Part 15 Class B
Compliance
This device and its accessories
comply with part 15 of FCC rules.
Operation is subject to the
following two conditions: (1) This
device and its accessories may not
cause harmful interference, and
(2) this device and its accessories
must accept any interference
received, including interference
that causes undesired operation.
Technical Details
The LG700 is an all digital phone
that operates on both Code
Division Multiple Access (CDMA)
frequencies: Cellular services at
800 MHz and Personal
Communication Services (PCS) at
1.9 GHz.
CDMA technology uses a feature
called DSSS (Direct Sequence
Spread Spectrum) that enables the
phone to keep communication from
being crossed and to use one
frequency channel by multiple users
in the same specific area. This results
in a 10-fold capacity increase when
compared with analog mode. In
addition, features such as soft /
softer handoff, hard handoff, and
dynamic RF power control
technologies combine to reduce call
interruptions.
The Cellular and PCS CDMA
networks consist of MSO (Mobile
Switching Office), BSC (Base
Station Controller), BTS (Base
Station Transmission System), and
MS (Mobile Station).

Technical Details
12
Technical Details
*TSB-74: Protocol between an IS-
95A system and ANSI J-STD-
008
Its battery life is twice as long as
IS-95. High-speed data
transmission is also possible.
The following tab lists some
major CDMA standards.
CDMA Standard
Basic Air
Interface
TIA/EIA-95A
TSB-74
ANSI J-STD-008
TIA/EIA-IS2000
CDMA Dual-Mode Air Interface
14.4kbps radio link protocol and inter-
band operations
IS-95 adapted for PCS frequency band
CDMA2000 1xRTT Air Interface
MAS-BS
PCSC-RS
Intersystem operations
Non-signaling datacomm.
CDMA2000 High Rate Packet Data Air
Interface
1xEV-DO Inter-Operability Specification for
CDMA2000 Access Network Interfaces
Recommended Minimum Performance
Standards for CDMA2000 High Rate
Packet Data Access Terminal Test
Application Specification (TAS) for High
Rate Packet Data Air Interface
TIA/EIA/IS-634
TIA/EIA/IS/651
TIA/EIA/IS-41-C
TIA/EIA/IS-124
TIA/EIA/IS-856
TIA/EIA/IS-878
TIA/EIA/IS-866
TIA/EIA/IS-890
TIA/EIA/IS-96-B
TIA/EIA/IS-637
TIA/EIA/IS-657
IS-801
TIA/EIA/IS-707-A
Speech CODEC
Short Message Service
Packet Data
Position Determination Service (gpsOne)
High Speed Packet Data
Network
Service
1x EV-DO
Related
interface
Designator Description

13
Technical Details
FCC RF Exposure Information
WARNING! Read this
information before operating
the phone.
In August 1996, the Federal
Communications Commission
(FCC) of the United States, with
its action in Report and Order
FCC 96-326, adopted an
updated safety standard for
human exposure to Radio
Frequency (RF) electromagnetic
energy emitted by FCC regulated
transmitters. Those guidelinesare
consistent with the safety
standard previously set by both
U.S. and international standards
bodies. The design of this phone
complies with the FCC guidelines
and these international
standards.
Bodily Contact During
Operation
This device was tested for typical
use with the back of the phone
kept 0.79 inches (2.0 cm) from
the body. To comply with FCC
RF exposure requirements, a
minimum separation distance of
0.79 inches (2.0 cm) must be
maintained between the user’s
body and the back of the phone,
including the antenna, whether
extended or retracted. Third-
partybelt-clips, holsters, and
similar accessories containing
metallic componentsshould not
be used. Avoid the use of
accessories that cannot maintain
0.79inches (2.0 cm) distance
between the user’s body and the
back of the phone and have not
been tested for compliance with
FCC RF exposure limits.

14
Technical Details
Vehicle-Mounted the External
Antenna
(Optional, if available.)
To satisfy FCC RF exposure
requirements, keep 8 inches (20
cm) between the user /
bystander and vehicle-mounted
the external antenna. For more
information about RF exposure,
visit the FCC website at
www.fcc.gov.
FCC Notice and Cautions
This device and itsaccessories
complywith part 15of FCC
rules. Operation is subject to the
following twoconditions: (1)
This device and its accessories
maynot cause harmful
interference, and (2) this device
and its accessories must accept
anyinterference received,
including interference that
causes undesired operation.
Any changes or modifications
not expressly approved in this
user guide could void your
warranty for this equipment. Use
only the supplied antenna. Use
of unauthorized antennas (or
modifications to the antenna)
could impair call quality, damage
the phone, void your warranty
and/or violateFCC regulations.
Don't use the phone with a
damaged antenna. A damaged
antenna could cause a minor skin
burn. Contact your local dealer
for a replacement antenna.

Phone Overview
15
Phone Overview
1. Speaker Lets you play music and use
speakerphone.
2. Earphone Jack Allows you to use a headset to
hear the caller's voice.
3. LCD Screen Displays incoming calls, messages,
and indicator icons and lets you view the wide
variety of content that interests you.
4. SEND Key Lets you place or answer calls.
This key is also called the TALK Key.
5. Microphone Captures your voice for calls and
other phone features.
6. PWR/END Key Use to turn the power on/off
and toend a call. Also putsthe phone in
standby mode.
7. BACK/Keyguard mode Key Deletes single
spaces or characters with a quick press; press
and hold todelete entire words. It will also back
you out of menus, one level at a time. During a
call, press this to activate speaker mode.
8. microSD™card slot (accommodates optional
microSD™cards up to8GB) Insert a microSD™
card for external memory. Use LG-approved
microSD™cards. Toaccess the microSD™card
slot, you must remove the battery cover located
atthe back of your phone.
9. Camera Lens Used to take photos and record
video. Keep it clean for optimal photo quality.

Phone Overview
16
Phone Overview
1. Charger Port Connects the phone to the
battery charger or other available accessories.
2. HOLD Key Use to lock your phone. To unlock,
press the HOLD key ()twice, or press the
Touch to Unlock button on the screen.
3. Side Camera Key Use for quick access to
Camera functions.
4. Side Keys Use to adjust the ringer volume in
standby mode and the earpiece volume during
acall.
5. Earpiece Lets you hear the caller when you use
the earphone.
Touch-Sensitive Soft Keys
( , , , )
1. Make sure your hands are
clean and dry. Remove
moisture from the surface of
your hands. Don't use the
touch keys in humid
environments.
2. Touch-key sensors are
sensitive to a light touch. You
don't need topress them
forcefully. Protect your phone
from impacts to avoid
damaging the touch key
sensors.
3. Use the tip of your finger to
touch the center of a touch
key. If you touch off-center,
you may activate the adjacent
function instead.

17
Phone Overview
4. The touch sensor level, such as
the Tone Level and Vibrate
Level, can be adjusted as
desired.
5. When both the outside LCD
screen and the touch key lights
are off, the touch keys are
deactivated. Press the HOLD
Key ( )or the END Key to
turn on the Touch Screen.
6. Keep metal and other
conductivematerials away from
the surface of touch keys;
contact maycause electrical
interference.
WARNING
●
Do not put heavy objects on the
Touch Screen.
●
Do not sit on your phone; this
may damage the Touch Screen.
●
Do not drag your phone on or
scratch it with sharp materials.
●
Do not store your phone in
extreme conditions (places that
are too humid, hot, or cold).
●
Keep chemicals away from your
phone because they may change
its appearance or functional
features.
Warning! Do not sit on your
phone or put heavy items on it;
this could damage your phone.

Phone Overview
18
Phone Overview
The Touch Screen is a great way to interact with LG700 software. Take a
little time to become accustomed to using it. If it doesn’t react as you
expect, adjust the Touch Screen calibration in the TOUCH SETTINGS
menu.
Standby Mode Idle Screens
Customize your Touch Screen to have instant access to features you
want to keep as close as a single finger touch.
The LG700 has four Standby Mode Idle Screens for quick, direct
access to several frequently used device features.
Main: Displays standby mode idle screens.
Shortcut: Provides quick access to the Analog Clock, Dual Clock,
Digital Clock, Timer, Calendar, Quick note, Memory, and Help Wizard.
Contacts: Displays the Contacts you want to instantly view, call, or
message.
Multimedia: Displays your favorite photos, music, and videos so you
can show them off at a moment’s notice without having to search.

19
Phone Overview
Main MultimediaShortcut Contacts
Set the features and items you want on each Idle screen, and even display
different backgrounds for each.
1. Messaging Displays Message menu.
2. Dialing DisplaysDial touch keys.
3. Menu Displays the list of Main Menus.
4. Contacts List Displays your Contact List.
You can slide your finger to get to the next one.

Menus Overview
20
Menus Overview
My Account
Web
Messaging
New Text Message
Quick Text
NewPictureMessage
Inbox
Outbox
Drafts
Communities
Facebook
My Space
Red Light Lounge
Lavalife
Bebo
Mocospace
Messenger
Voicemail
Web Alerts
Settings
All Messages
Text Messages
Picture Messages
Edit Voicemail #
Web Alerts
Erase Options
Erase Inbox
Erase Outbox
Erase Drafts
Erase Web Alerts
Erase All
Facebook
Messenger
Speed Dials
Contacts
New Contact
Contact List
Groups
Speed Dials
My Name Card
Call History
Missed Calls
Received Calls
Dialed Calls
All Calls
Call Timer
Data Counter
Camera
Get New Pictures
Take Photo
My Photo Album
Default Images
