Important Safety Precautions
1
Important Safety Precautions
Read these instructions. Breaking the rules may be dangerous or
illegal. Further detailed information is given in this user guide.
WARNING! Violation of the instructions may cause serious injury or
death.
1. Never use an unapproved battery since this could
damage the phone and/or battery and could cause
the battery to explode.
2. Never place your phone in a microwave oven as it will
cause the battery to explode.
3. Never store your phone in temperatures less than
-4°F or greater than 122°F.
4. Do not dispose of your battery by fire or with
hazardous or flammable materials.
5. When riding in a car, do not leave your phone or set
up the hands-free kit near to the air bag. If wireless
equipment is improperly installed and the air bag is
deployed, you may be seriously injured.
6. Do not use a hand-held phone while driving.
7. Do not use the phone in areas where its use is
prohibited. (For example: aircraft)
AX380_Eng_100.qxd 6/27/07 10:43 AM Page 1

Important Safety Precautions
2
Important Safety Precautions
1. Do not expose the battery charger or adapter to direct
sunlight or use it in places with high humidity, such as
a bathroom.
2. Do not use harsh chemicals (such as alcohol, benzene,
thinners, etc.) or detergents to clean your phone. This
could cause a fire.
3. Do not drop, strike, or shake your phone severely. It
may harm the internal circuit boards of the phone.
4. Do not use your phone in high explosive areas as the
phone may generate sparks.
5. Do not damage the power cord by bending, twisting,
pulling, or heating. Do not use the plug if it is loose as
it may cause a fire or electric shock.
6. Do not place any heavy items on the power cord. Do
not allow the power cord to be crimped as it may
cause electric shock or fire.
7. Do not handle the phone with wet hands while it is
being charged. It may cause an electric shock or
seriously damage your phone.
8. Do not disassemble the phone.
AX380_Eng_100.qxd 6/27/07 10:43 AM Page 2

3
Important Safety Precautions
1. Do not place or answer calls while charging the phone as
it may short-circuit the phone and/or cause electric
shock or fire.
2. Do not hold or let the antenna come in contact with
your body during a call.
3. Make sure that no sharp-edged items such as animal’s
teeth or nails, come into contact with the battery. This
could cause a fire.
4. Store the battery out of reach of children.
5. Be careful that children do not swallow any parts (such
as rubber plugs, earphone, connection parts of the
phone, etc.) This could cause asphyxiation or
suffocation resulting in serious injury or death.
6. Unplug the power cord and charger during lightning
storms to avoid electric shock or fire.
7. Only use the batteries and chargers provided by LG. The
warranty will not be applied to products provided by
other suppliers.
8. Only authorized personnel should service the phone and
its accessories. Faulty installation or service may result in
accidents and consequently invalidate the warranty.
9. An emergency call can be made only within a service
area. For an emergency call, make sure that you are
within a service area and that the phone is turned on.
AX380_Eng_100.qxd 6/27/07 10:43 AM Page 3

Table of Contents
4
Table of Contents
Important Safety Precautions
1
Table of Contents 4
Welcome 9
Technical Details 10
FCC RF Exposure Information 12
Phone Overview 14
Menus Overview 16
Getting Started with Your
Phone 18
The Battery 18
Installing the Battery 18
Removing the Battery 18
Charging the Battery 18
Battery Charge Level 19
Turning the Phone On and Off 19
Turning the Phone On 19
Turning the Phone Off 19
Signal Strength 19
Screen Icons 20
Making Calls 20
Correcting Dialing Mistakes 21
Redialing Calls 21
Receiving Calls 21
Quick Access to Convenient
Features 22
Lock Mode 22
Mute Function 22
Volume Quick Adjustment 22
Call Waiting 22
Caller ID 23
Speed Dialing 23
Entering and Editing
Information 24
Text Input 24
Key Functions 24
AX380_Eng_100.qxd 6/27/07 10:43 AM Page 4

5
Table of Contents
Contacts in Your Phone’s
Memory 25
The Basics of Storing Contacts
Entries 25
Phone Numbers With Pauses 25
Storing a Number with Pauses 26
Adding a Pause to an Existing
Number
26
Searching Your Phone’s Memory 27
Scrolling Through Your Contacts 27
Making a Call From Your Phone’s
Memory 28
Using Phone Menus 30
Messaging 30
1. New Text Message 30
2. New Picture Message 32
3. Inbox 34
4. Sent 35
5. Drafts 36
6. Voicemail 36
7. Quick-Text 36
8. Settings 37
9. Delete All 39
Axcess Apps 39
1. Axcess Apps 40
2. Axcess Info 41
Axcess Web 42
1. Start Browser 42
2. Web Message 44
3. Web Settings 44
Multimedia 45
1. Take Photo 45
2. Record Video 46
3. Record Voice 47
Contacts 47
1. New Contact 47
2. Contact List 48
3. My Circle 48
4. Groups 48
5. Speed Dials 49
6. My Name Card 50
AX380_Eng_100.qxd 6/27/07 10:43 AM Page 5

Table of Contents
6
Table of Contents
Recent Calls 50
1. Missed Calls 50
2. Received Calls 51
3. Dialed Calls 51
4. Data 51
5. All Calls 51
6. Call Timer 51
7. Data Counter 52
My Media 52
1. Image 52
2. Video 52
3. Audio 53
4. Shuffle 53
5. Music 53
Celltop 54
Settings 55
1. Tools 55
1.1 Voice Command 55
1.2 My Menu 55
1.3 Alarm Clock 56
1.4 Calendar 56
1.5 Ez Tip Calc 57
1.6 Notepad 57
1.7 Calculator 58
1.8 World Clock 58
1.9 Stopwatch 58
1.0 Unit Converter 59
2. Sound 59
2.1 Ringers 59
2.2 Volume 59
2.3 Message Alerts 59
2.4 Alert Type 60
2.5 Service Alerts 60
2.5.1 Minute Beep 60
2.5.2 Call Connect 60
2.5.3 Back to Top 60
2.5.4 Low Battery 60
2.6 Power On/Off Tones 60
3. Display 61
3.1 Wallpaper 61
AX380_Eng_100.qxd 6/27/07 10:43 AM Page 6

7
Table of Contents
3.2 Banner 61
3.3 Backlight 61
3.4 Menu Style 62
3.5 Languages 62
3.6 Clocks & Calendar 62
3.7 Font Settings 62
3.8 Color Schemes 63
4. Security 63
4.1 Lock Phone 63
4.2 Restrict Calls 64
4.3 Emergency #s 64
4.4 Change Lock Code 64
4.5 Reset Default 65
5. Call Settings 65
5.1 Answer Options 65
5.2 Auto Retry 65
5.3 One-Touch Dial 66
5.4 Voice Privacy 66
5.5 Auto Volume 66
5.6 Airplane Mode 66
5.7 TTY Mode 67
6. Bluetooth®67
6.1 Paired Devices 68
6.2 Power 69
6.3 My Visibility 69
6.4 My Bluetooth Name 69
6.5 My Bluetooth Info 70
7. PC Connection 70
8. System 73
8.1 Network 73
8.2 Location 74
9. Memory 74
0. Touch Sensor Level 74
*. Software Update 75
#. Phone Info 75
Safety 76
TIA Safety Information 76
Exposure to Radio Frequency Signal 76
Antenna Care 76
Phone Operation 77
Tips on Efficient Operation 77
Driving 77
AX380_Eng_100.qxd 6/27/07 10:43 AM Page 7

Table of Contents
8
Table of Contents
Electronic Devices 77
Pacemakers 77
Persons with pacemakers: 78
Hearing Aids 78
Other Medical Devices 78
Health Care Facilities 78
Vehicles 79
Posted Facilities 79
Aircraft 79
Blasting Areas 79
Potentially Explosive Atmosphere 79
For Vehicles Equipped with an Air
Bag 80
Safety Information 80
Charger and Adapter Safety 80
Battery Information and Care 81
Explosion, Shock, and Fire Hazards81
General Notice 82
Warning! Important safety
information 84
Avoiding hearing damage 84
Using your phone safely 84
Avoiding hearing damage 85
Using headsets safely 85
FDA Consumer Update 86
10 Driver Safety Tips 96
Consumer Information on SAR
10 0
FCC Hearing-Aid
Compatibility (HAC)
Regulations for Wireless
Devices 102
Accessories 105
Limited Warranty Statement
106
Index 110
AX380_Eng_100.qxd 6/27/07 10:43 AM Page 8

Welcome
9
Welcome
Thank you for choosing the AX380
cellular phone designed to operate
with the latest digital mobile
communication technology, Code
Division Multiple Access (CDMA).
Along with the many advanced
features of the CDMA system, such
as greatly enhanced voice clarity,
this compact phone offers:

Celltop capability

Music capability and microSDTM
card slot

Significantly enhanced voice
clarity.

Slim and sleek design with
internal antenna (Internal
antenna described as antenna
throughout this user guide)

Large, easy-to-read, 9-line
backlit LCD with status icons.

Paging, messaging, voice mail,
and caller ID.

22-key keypad.

Speakerphone feature.

Menu-driven interface with
prompts for easy operation and
configuration.

Any key answer, auto answer,
auto retry, one-touch and speed
dialing with 99 memory
locations.

Bilingual (English and Spanish)
capabilities.

Bluetooth®wireless technology.
Note
The Bluetooth
®
word mark and
logos are owned by the Bluetooth
SIG, Inc. and any use of such marks
by LG Electronics is under license.
Other trademarks and trade names
are those of their respective owners.
AX380_Eng_100.qxd 6/27/07 10:43 AM Page 9

Technical Details
10
Technical Details
Important Information
This user’s guide provides
important information on the use
and operation of your phone.
Please read all the information
carefully prior to using the
phone for the best performance
and to prevent any damage to or
misuse of the phone. Any
unapproved changes or
modifications will void your
warranty.
FCC Part 15 Class B
Compliance
This device and its accessories
comply with part 15 of FCC rules.
Operation is subject to the
following two conditions: (1) This
device and its accessories may not
cause harmful interference, and
(2) this device and its accessories
must accept any interference
received, including interference
that causes undesired operation.
Technical Details
The AX380 is an all digital phone
that operates on both Code
Division Multiple Access (CDMA)
frequencies: Cellular services at
800 MHz and Personal
Communication Services (PCS) at
1.9 GHz.
CDMA technology uses a feature
called DSSS (Direct Sequence
Spread Spectrum) that enables the
phone to keep communication from
being crossed and to use one
frequency channel by multiple users
in the same specific area. This results
in a 10-fold capacity increase when
compared with analog mode. In
addition, features such as soft /
softer handoff, hard handoff, and
dynamic RF power control
technologies combine to reduce call
interruptions.
The Cellular and PCS CDMA
networks consist of MSO (Mobile
Switching Office), BSC (Base
Station Controller), BTS (Base
Station Transmission System), and
MS (Mobile Station).
* TSB-74: Protocol between an IS-
95A system and ANSI J-STD-
008
AX380_Eng_100.qxd 6/27/07 10:43 AM Page 10

11
Technical Details
Its battery life is twice as long as
IS-95. High-speed data
transmission is also possible.
The following tab lists some
major CDMA standards.
CDMA Standard
Basic Air
Interface
TIA/EIA-95A
TSB-74
ANSI J-STD-008
TIA/EIA-IS2000
CDMA Dual-Mode Air Interface
14.4kbps radio link protocol and inter-
band operations
IS-95 adapted for PCS frequency band
CDMA2000 1xRTT Air Interface
MAS-BS
PCSC-RS
Intersystem operations
Non-signaling data comm.
CDMA2000 High Rate Packet Data Air
Interface
1xEV-DO Inter-Operability Specification for
CDMA2000 Access Network Interfaces
Recommended Minimum Performance
Standards for CDMA2000 High Rate
Packet Data Access Terminal Test
Application Specification (TAS) for High
Rate Packet Data Air Interface
TIA/EIA/IS-634
TIA/EIA/IS/651
TIA/EIA/IS-41-C
TIA/EIA/IS-124
TIA/EIA/IS-856
TIA/EIA/IS-878
TIA/EIA/IS-866
TIA/EIA/IS-890
TIA/EIA/IS-96-B
TIA/EIA/IS-637
TIA/EIA/IS-657
IS-801
TIA/EIA/IS-707-A
Speech CODEC
Short Message Service
Packet Data
Position Determination Service (gpsOne)
High Speed Packet Data
Network
Service
1x EV-DO
Related
interface
Designator Description
AX380_Eng_100.qxd 6/27/07 10:43 AM Page 11

Technical Details
12
Technical Details
FCC RF Exposure Information
WARNING! Read this
information before operating the
phone.Read this information
before operating the phone.
In August 1996, the Federal
Communications Commission
(FCC) of the United States, with its
action in Report and Order FCC
96-326, adopted an updated
safety standard for human exposure
to Radio Frequency (RF)
electromagnetic energy emitted by
FCC regulated transmitters. Those
guidelines are consistent with the
safety standard previously set by
both U.S. and international
standards bodies. The design of
this phone complies with the FCC
guidelines and these international
standards.
Bodily Contact During
Operation
This device was tested for typical
use with the back of the phone
kept 0.6 inches (1.5 cm) from
the body. To comply with FCC
RF exposure requirements, a
minimum separation distance of
0.6 inches (1.5 cm) must be
maintained between the user’s
body and the back of the phone,
including the antenna, whether
extended or retracted. Third-
party belt-clips, holsters, and
similar accessories containing
metallic components should not
be used. Avoid the use of
accessories that cannot maintain
0.6 inches (1.5 cm) distance
between the user’s body and the
back of the phone and have not
been tested for compliance with
FCC RF exposure limits.
AX380_Eng_100.qxd 6/27/07 10:43 AM Page 12

13
Technical Details
Vehicle-Mounted External
Antenna
(Optional, if available.)
A minimum distance of 8 inches
(20cm) must be maintained
between the user / bystander
and the vehicle-mounted external
antenna to satisfy FCC RF
exposure requirements. For more
information about RF exposure,
visit the FCC website at
www.fcc.gov.
Caution
Use only the supplied and
approved antenna. Use of
unauthorized antennas or
modifications could impair call
quality, damage the phone, void
your warranty and/or result in
violation of FCC regulations.
Do not use the phone with a
damaged antenna. If a damaged
antenna comes into contact
with the skin a minor burn may
result. Contact your local dealer
for a replacement antenna.
AX380_Eng_100.qxd 6/27/07 10:43 AM Page 13

Phone Overview
14
Phone Overview
1. Earpiece Lets you hear the caller.
2. Flip Open to answer an incoming call and close to
end the call.
3. LCD Screen Displays messages and indicator icons.
When the flip is open, Power Save mode
automatically dims the screen and then darkens it if
no keys are pressed.
4. Left Soft Key Use to display the function setting
menu.
5. Speakerphone Key Use to set the speakerphone
mode.
6. SEND Key Use to place or answer calls.
7. Alphanumeric Keypad Use to enter numbers and
characters and select menu items.
8. Lock Mode Key Use to lock the phone (from
standby mode press and hold for about 3 seconds).
9. Navigation Key Use for quick access to Contact List,
Organizer, Ringtones and Wallpaper.
10. Right Soft Key Use to select an action within a
menu.
11.
OK Key Selects the function displayed at the
bottom of the LCD between the Left and Right Soft
Key functions.
12. Camera Key
Use for quick access to Take Photo
menu.
13. END/PWR Key Use to turn the power on/off and
to end a call. Also returns to the main menu display
screen.
14. BACK Key Deletes single spaces or characters with
a quick press, but press and hold to delete entire
words. Will also back you out of menus, one level at
a time.
15.
Vibrate Mode Key Use to set the mode (from
standby mode press and hold for about 3
seconds).
16. Microphone Lets callers hear you.
* Speakerphone function is only available while a
call is in progess.
AX380_Eng_100.qxd 6/27/07 10:43 AM Page 14

15
Phone Overview
1. Earphone Jack Allow the use of a headset to hear
caller's voice.
2. Side Keys Use to adjust the ringer volume in
standby mode and the earpiece volume during a
call.
3. Music Shortcut Key Activates Music Player.
4. Charger Port Connects the phone to the battery
charger or other available accessories.
5. Side Camera Key Use for quick access to Camera
function.
6. microSDTM card slot Insert microSD card for
external memory. Use LG approved microSD card.
7. Camera Lens Used to take a photo. Keep it clean
for optimal photo quality.
Note
Please insert a microSDTM card into your
phone in the correct direction as illustrated.
Also make sure the location of the port and
the direction of your phone when inserting
the microSD card. Improper handling of the
port may cause damage to your phone and
void the warranty.
AX380_Eng_100.qxd 6/27/07 10:43 AM Page 15

Messaging
1. New Text Message
2. New Picture
Message
3. Inbox
4. Sent
5. Drafts
6. Voicemail
7. Quick-Text
8. Settings
1. All Messages
2. Text Message
3. Picture Message
9. Delete All
1. Delete Inbox
2. Delete Sent
3. Delete Drafts
4. Delete All
Messages
Axcess Apps
1. Axcess Apps
2. Axcess Info
Axcess Web
1. Start Browser
2. Web Messages
3. Web Settings
Multimedia
1. Take Photo
2. Record Video
3. Record Voice
Contacts
1. New Contact
2. Contact List
3. My Circle
4. Groups
5. Speed Dials
6. My Name Card
Recent Calls
1. Missed Calls
2. Received Calls
3. Dialed Calls
4. Data
5. All Calls
6. Call Timer
1. Last Call
2. Home Calls
3. Roam Calls
4. All Calls
7. Data Counter
1. Received Data
2. Sent Data
3. All Data
My Media
1. Image
2. Video
3. Audio
4. Shuffle
5. Music
Celltop
1. Start Celltop
Settings
1. Tools
1. Voice Command
2. My Menu
3. Alarm Clock
Menus Overview
16
Menus Overview
AX380_Eng_100.qxd 6/27/07 10:43 AM Page 16

17
Menus Overview
4. Calendar
5. Ez Tip Calc
6. Notepad
7. Calculator
8. World Clock
9. Stopwatch
0. Unit Converter
2. Sound
1. Ringers
2. Volume
3. Message Alerts
4. Alert Type
5. Service Alerts
6. Power On/Off
Tones
3. Display
1. Wallpaper
2. Banner
3. Backlight
4. Menu Style
5. Languages
6. Clocks &
Calendar
7. Font Settings
8. Color Schemes
4. Security
1. Lock Phone
2. Restrict Calls
3. Emergency #s
4. Change Lock
Code
5. Reset Default
5. Call Settings
1. Answer Options
2. Auto Retry
3. One-Touch Dial
4. Voice Privacy
5. Auto Volume
6. Airplane Mode
7. TTY Mode
6. Bluetooth
1. Paired Devices
2. Power
3. My Visibility
4. My Bluetooth
Name
5. My Bluetooth
Info
7. PC Connection
8. System
9. Memory
1. Save Options
2. Internal Memory
3. External
Memory
0. Touch Sensor Level
*. Software Update
#. Phone Info
Menu Access
Press Menu to
access nine phone
menus. There are two
methods of accessing
menus and submenus:

Use the navigation
key to highlight and
select, or

Press the number
key that
corresponds to the
menu (or submenu).
AX380_Eng_100.qxd 6/27/07 10:43 AM Page 17

The Battery
The phone comes with a
rechargeable battery. Keep the
battery charged while not in use
in order to maximize talk and
standby time. The battery charge
level is shown at the top of the
LCD screen.
Installing the Battery
Press the button and align the
battery.
Removing the Battery
Press the button and lift the
battery to get the battery out.
Charging the Battery
To use the charger provided with
your phone:
Warning! Use only the charger
provided with the phone. Using
any charger other than the one
included with the AX380 may
damage your phone or battery.
1. Plug the end of the adapter
into the phone’s charger port
and the other end into an
electrical outlet.
2. The charge time varies
depending upon the battery
level.
Getting Started with Your Phone
18
Getting Started with Your Phone
Note
It is important to fully charge the
battery before initial use of the
phone.
NOTICE
Triangle symbol
should face up.
AX380_Eng_100.qxd 6/27/07 10:43 AM Page 18
