LG DV690H User manual

OWNER’S MANUAL
DVD Player
Please read this manual carefully before operating
your set and retain it for future reference.
DV690H / DV691H
DV692H / DV697H
P/NO : MFL66859889
ENGLISH

Getting Started2
Getting Started
1
Safety Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK) NO
USER-SERVICEABLE PARTS INSIDE REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
This lightning ash with arrowhead
symbol within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product’s
enclosure that may be of sucient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing) instructions
in the literature accompanying the product.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
WARNING: Do not install this equipment in a
conned space such as a book case or similar unit.
CAUTION: Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the
product and to protect it from over heating. The
openings shall be never be blocked by placing
the product on a bed, sofa, rug or other similar
surface. This product shall not be placed in a built-
in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s
instruction has been adhered to.
CAUTION: This product employs a Laser System.
To ensure proper use of this product, please read
this owner’s manual carefully and retain it for future
reference. Shall the unit require maintenance,
contact an authorized service center.
Use of controls, adjustments or the performance of
procedures other than those specied herein may
result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try
to open the enclosure. Visible laser radiation when
open. DO NOT STARE INTO BEAM.
CAUTION concerning the Power Cord
Most appliances recommend they be placed upon
a dedicated circuit;
That is, a single outlet circuit which powers only
that appliance and has no additional outlets or
branch circuits. Check the specication page of this
owner’s manual to be certain. Do not overload wall
outlets. Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power cords, or
damaged or cracked wire insulation are dangerous.
Any of these conditions could result in electric
shock or re. Periodically examine the cord of your
appliance, and if its appearance indicates damage
or deterioration, unplug it, discontinue use of the
appliance, and have the cord replaced with an
exact replacement part by an authorized service
center. Protect the power cord from physical or
mechanical abuse, such as being twisted, kinked,
pinched, closed in a door, or walked upon. Pay
particular attention to plugs, wall outlets, and
the point where the cord exits the appliance. To
disconnect power from the mains, pull out the
mains cord plug. When installing the product,
ensure that the plug is easily accessible.

1 Getting Started
Getting Started 3
Getting Started
1
This device is equipped with a portable battery or
accumulator.
Safety way to remove the battery or the
battery from the equipment: Remove the
old battery or battery pack, follow the steps
in reverse order than the assembly. To prevent
contamination of the environment and bring on
possible threat to human and animal health, the
old battery or the battery put it in the appropriate
container at designated collection points. Do
not dispose of batteries or battery together with
other waste. It is recommended that you use
local, free reimbursement systems batteries and
accumulators. The battery shall not be exposed to
excessive heat such as sunshine, re or the like.
CAUTION: The apparatus shall not be exposed to
water (dripping or splashing) and no objects lled
with liquids, such as vases, shall be placed on the
apparatus.
Notes on Copyrights
This product incorporates copyright protection
technology that is protected by U.S. patents
and other intellectual property rights. Use of
this copyright protection technology must be
authorized by Rovi Corporation, and is intended for
home and other limited viewing uses only unless
otherwise authorized by Rovi Corporation. Reverse
engineering or disassembly is prohibited.
Under the U.S. Copyright laws and Copyright
laws of other countries, unauthorized recording,
use, display, distribution, or revision of television
programs, videotapes, DVDs, CDs and other
materials may subject you to civil and/or criminal
liability.
Caution of Unit treatment
yShipping the unit
Save the original packing materials and re-pack
the unit with them to maximize protection.
yCleaning the unit
Clean the unit using a soft and dry cloth with
a mild detergent solution, not strong solvents
occurred the damage of surface.
yMaintaining performance of the unit
Maintain the cleaing status of optical pick-up
lens and disc drive parts. If they are dirty or worn,
the displayed quality could be diminished. For
details, please contact your nearest authorized
service center.

Getting Started4
Getting Started
1
Important Safety
Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9. Do not defeat the safety purpose of the polar-
ized or grounding-type plug. A polarized plug
has two blades with one wider than the other.
A grounding type plug has two blades and a
third grounding prong. The wide blade or the
third prong are provided for your safety. If the
provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
11. Only use attachments/accessories specified
by the manufacturer.
12. Use only the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold
with apparatus. When a cart is used, use
caution when moving the cart/ apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14. Refer all servicing to qualified service person-
nel. Servicing is required when the appa-
ratus has been damaged in any way, such
as power- supply cord or plug is damaged,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.

Table of Contents 5
1
2
3
4
5
6
Table of Contents
1 Getting Started
2 Safety Information
6 Introduction
6 – Symbols Used in this Manual
6 – About the “&” Symbol Display
6 – Regional Code
6 – Playable Discs
7 – File compatibility
8 Front panel
8 Rear panel
8 Supplied Accessories
9 Remote control
2 Connecting
10 Connecting to your TV
10 – Connecting Video / Audio cable
10 – Connecting Component Video cable
10 – Connecting HDMI cable
11 Connecting to an Amplifier
11 – Connecting Audio cable
11 – Connecting COAXIAL or OPTICAL
(digital audio) cable
11 – Connecting HDMI cable
3 System Setting
12 Setup
12 – Adjust the settings
12 – [LANGUAGE] Menu
12 – [DISPLAY] Menu
12 – [AUDIO] Menu
13 – [LOCK] Menu
13 – [OTHERS] Menu
4 Operating
14 On-Screen display
14 – Displaying content information on-
screen
14 General Playback
14 – Playing Disc
14 – Playing Karaoke Disc
(DV691H/DV697H only)
14 – Playing USB Device
(DV692H/DV697H only)
15 General operation
15 Advanced Playback
15 – Movie
16 – Music
16 – Photo
5 Troubleshooting
17 Troubleshooting
6 Appendix
18 Area Code List
19 Language code List
20 Specifications
20 Trademarks and Licenses

Getting Started6
Getting Started
1
Introduction
Symbols Used in this Manual
A section whose title has one of the following
symbols are applicable only to the disc represented
by the symbol.
rDVD-Video, DVD±R/RW
tAudio CDs
yMovie les contained in the
USB/Disc
uMusic les contained in the
USB/Disc
iPhoto les contained in the
USB/Disc
About the “&” Symbol
Display
“&” may appear on your TV display during
operation and indicates that the function explained
in this owner’s manual is not available on that
specic media.
Regional Code
This unit has a regional code printed on the rear of
the unit. This unit can play only DVD disc labeled
same as the rear of the unit or “ALL”.
Playable Discs
DVD-VIDEO (8 cm / 12 cm disc)
Discs such as movies that can be
purchased or rented.
DVD±R (8 cm / 12 cm disc)
-Video mode and nalized only
-Supports the dual layer disc also
-DVD±R discs that contain Movie,
Music or Photo les.
DVD-RW (8 cm / 12 cm disc)
-VR mode, Video mode and
nalized only
-DVD-RW discs that contain Movie,
Music or Photo les.
DVD+RW (8 cm / 12 cm disc)
-Video mode and nalized only
-DVD+RW discs that contain
Movie, Music or Photo les.
Audio CD (8 cm / 12 cm disc)
CD-R/RW (8 cm / 12 cm disc)
CD-R/RW discs that contain audio
titles, Movie, Music or Photo les.
• You have to set the disc format option
to [Mastered] in order to make the discs
compatible with the LG players when
formatting rewritable discs. When setting
the option to Live System, you cannot use
it on LG player. (Mastered/Live File System :
Disc format system for windows Vista)
, Note

Getting Started 7
Getting Started
1
File compatibility
Overall
Available File extensions: “.jpg”, “.jpeg”, “.avi”, “.divx”,
“.mpg”, “.mpeg”, “.mp3”, “.wma”
yThe le name is limited to 45 characters.
yDepending on the size and number of the les,
it may take several minutes to read the contents
on the media.
Maximum Files/Folder: Less than 600 (total
number of les and folders)
CD-R/RW, DVD±R/RW Format: ISO 9660+JOLIET
MOVIE
Available resolution size:
720 x 576 (W x H) pixels
Playable subtitle: SubRip (.srt / .txt), SAMI (.smi),
SubStation Alpha (.ssa/.txt), MicroDVD (.sub/.
txt), SubViewer 2.0 (.sub/.txt), TMPlayer (.txt), DVD
Subtitle System (.txt)
Playable Codec format: “DIVX3.xx”, “DIVX4.xx”,
“DIVX5.xx”, “DIVX6.xx” (Standard playback only),
“MP43”, “3IVX”
yThis unit does not support the le that
are recorded with GMC*1 or Qpel*2. Those
are video encoding techniques in MPEG4
standard, like DivX or XVID have.
*1 GMC – Global Motion Compensation
*2 Qpel – Quarter pixel
, Note
Playable Audio format: “Dolby Digital”, ”DTS”,
“MP3”, “WMA”
Sampling frequency: within 8 - 48 kHz (MP3),
within 32 - 48 kHz (WMA)
Bit rate: within 32 - 320 kbps (MP3),
within 32 - 320 kbps (WMA)
MUSIC
Sampling frequency: within 8 - 48 kHz (MP3),
within 32 - 48 kHz (WMA)
Bit rate: within 8 - 320 kbps (MP3),
within 32 - 192 kbps (WMA)
Recommended size: less than 2 MB
y
yDo not extract the USB device during
operation (play, etc.).
yA USB device which requires additional
program installation when you have
connected it to a computer, is not
supported.
yUSB device: USB device that supports
USB1.1 and USB2.0.
yMovie, music and photo les can be played.
For details of operations on each le, refer to
relevant pages.
yRegular back up is recommended to
prevent data loss.
yIf you use a USB extension cable, USB HUB
or USB Multi-reader, the USB device may not
be recognized.
ySome USB device may not work with this
unit.
yDigital camera and mobile phone are not
supported.
yUSB Port of the unit cannot be connected
to PC. The unit cannot be used as a storage
device.
, Notes of USB Device
(DV692H/DV697H only)

Getting Started8
Getting Started
1
Front panel
456
Rear panel
5
6
Supplied Accessories
RCA Video/Audio cable (1) Remote control (1) Battery (1)
aDisc Tray
bDisplay window
cRemote sensor
dMIC. (Microphone jack)
(DV691H/DV697H only)
eVOL. (Volume controller)
(DV691H/DV697H only)
fB (Open / Close)
z (Play)
C/V (Skip)
Z (Stop)
1 (Power)
gUSB Port (DV692H/DV697H only)
aPower Cord
bVideo Out
cDigital Audio Out (COAXIAL/OPTICAL)
d2CH Audio Out (Left/Right)
eComponent Video Out (Y PBPR)
fHDMI Out

Getting Started 9
Getting Started
1
Remote control
2011
• • • • • • • • • • a • • • • • • • • •
1(POWER): Switches the player ON or OFF.
B(OPEN/CLOSE): Opens and closes the disc tray.
0-9 numerical buttons: Selects numbered options
or inputs letters.
CLEAR: Removes a mark on the Search menu or a
number when setting the password.
TV Control Buttons : Controls the sound volume,
channel, source, and power On/O on TV.
• • • • • • • • • • b • • • • • • • • •
c/v(SCAN): Searchs backward or forward.
C/V (SKIP): Goes to the next or previous
chapter/track/le.
M(PAUSE/STEP): Pauses playback.
z(PLAY): Starts playback.
Z(STOP): Stops playback.
• • • • • • • • • • c • • • • • • • • •
DVD MENU : Accesses or exits the DVD menu.
DISPLAY: Accesses On-Screen Display.
TITLE: Accesses the disc’s title menu
x(RETURN): Returns the former menu or exits the
menu, and change to the USB mode.
wsad (Direction buttons): Selects an option in
the menu.
b (ENTER): Conrms menu selection.
• • • • • • • • • • d • • • • • • • • •
[ (AUDIO): Selects an audio language or audio
channel.
] (SUBTITLE): Selects a subtitle language.
} (ANGLE): Selects a DVD camera angle if it is
available on the disc being played.
SETUP: Accesses or exits the setup menu.
MARKER: Marks any desired point during playback,
and select or removes any specic track/le.
SEARCH: Displays or exits the search menu.
PROGRAM: Enters the program edit mode.
ZOOM: Enlarges video image in disc mode.
REPEAT: Repeats a desired selection or sequence.
A-B: Repeats a section.
RESOLUTION: Sets the appropriate resolution to
HDMI Out and Component Video Out.
KARAOKE (ECHO) (DV691H/DV697H only): Accesses
or exits KARAOKE menu.
Battery Installation:
Remove the battery cover on the rear of the Remote
Control, and insert one R03 (size AAA) batteries with
4and 5 matched correctly.
Code number to control TVs:
Press the below proper number of TV maker on
holding down 1 (TV Power) and just press 1 (TV
Power). If TV is turned on or o, it is to be set. But,
some or all buttons may not be operated according
to TV, even though it is to be set or input the proper
number.
Maker Code Number
LG 1 (Default), 2
Zenith 1, 3, 4
GoldStar 1, 2
Samsung 6, 7
Sony 8, 9
Hitachi 4

2 Connecting
10
Connecting
2
Connecting
Connecting to your TV
Connecting Video / Audio
cable
Connect the VIDEO/AUDIO OUT on the unit to
VIDEO/AUDIO IN on TV with AV cable, such as
VIDEO with yellow, AUDIO Left/Right with white/
red.
Connecting Component Video
cable
Connect the COMPONENT VIDEO OUT on the unit
to COMPONET VIDEO IN on TV with COMPONET
cable, such as Y with green, Pb with blue, and Pr
with red.
yYou should still connect the AUDIO cable
between the unit and TV.
Connecting HDMI cable
Connect the HDMI OUT on the unit to the HDMI IN
on compatible TV with HDMI cable. (Type A, High
Speed HDMI™ Cable)
Additional Information for HDMI
yWhen you connect a HDMI or DVI compatible
device make sure of the following:
-Try switching o the HDMI/DVI device and
this unit. Next, switch on the HDMI/DVI device
and leave it for around 30 seconds, then
switch on this unit.
-The connected device’s video input is set
correctly for this unit.
-The connected device is compatible with
720x576i(480i), 720x576p(480p), 1280x720p,
1920x1080i or 1920x1080p video input.
-The 1080p, 720p and 576p(480p) resolutions
are the progressive scan applied resolution.
yNot all HDCP-compatible HDMI or DVI devices
will work with this unit.
-The picture will not be displayed properly
with non-HDCP device.
-This unit does not playback and TV screen is
changed to black screen.
Resolution Setting
yDepending on your TV, some of the resolution
settings may result in the picture disappearing
or an abnormal picture appearing. In this case,
press RESOLUTION repeatedly until the picture
re-appears.
yChanging the resolution when the unit is
connected with HDMI connector may result in
malfunctions. To solve the problem, turn o the
unit and then turn it on again.
Rear of the Unit
Rear of TV
Video/Audio Cable
TV
Component Cable
TV
Rear of the Unit
Rear of TV
HDMI Cable
TV
Rear of the Unit
Rear of TV

Connecting 11
Connecting
2
Connecting to an
Amplifier
Connecting Audio cable
Connect the AUDIO OUT on the unit to 2CH AUDIO
IN on amplier with Audio cable, such as AUDIO
Left/Right with white/red
Connecting COAXIAL or
OPTICAL (digital audio) cable
Connect the COAXIAL or OPTICAL (digital audio
out) on the unit to Digital Audio IN (COAXIAL or
OPTICAL) on amplier with COAXIAL or OPTICAL
cable.
OPTICAL
yIf your TV is not capable of handling 96 kHz
sampling frequency, set the [Sample Freq.]
option to [48 KHz] on the setup menu (See page
12).
yIf your TV is not equipped with Dolby Digital
and MPEG decoder, set the [Dolby Digital] and
[MPEG] options to [PCM] on the setup menu
(See page 12).
Connecting HDMI cable
Connect the HDMI OUT on the unit to the HDMI IN
on amplier with HDMI cable.
Connect the HDMI OUT jack on amplier to HDMI
IN jack on TV with HDMI cable, if the amplier has
HDMI OUT jack.
Audio Cable
Amplier/
Receiver
Rear of the Unit
Coaxial CableOptical Cable
Amplier/
Receiver
Rear of the Unit
Rear of the Unit
TV
HDMI Cable
Amplier/
Receiver
HDMI Cable

3 System Setting
System Setting12
System Setting
3
Setup
When the unit is turned-on at the rst time, you
have to select the desired language. (optional)
Adjust the settings
You can change the settings of the player in the
[SETUP] menu.
1. Press SETUP.
2. Select the rst setup option using ws and
press dto move to the second level.
3. Select a second setup option using ws and
press dto move to the third level.
4. Select a desired setting using ws and press
ENTER to conrm.
5. Press SETUP to escape from setup menu.
[LANGUAGE] Menu
Menu Language/Disc Audio/Disc
Subtitle/Disc Menu
Select and set the language you prefer.
[DISPLAY] Menu
TV Aspect
Select and set TV aspect ratio according to your TV
type and preference.
[4:3]: Standard TV type
[16:9]: Wide TV type
Display Mode
Select and set Display Mode according to your
preference. Display Mode works only when the TV
Aspect mode is 4:3.
[Panscan]: Display full screen with cut non-
main scene on TV
[Letterbox]: Display wide screen with black
stripe at top and bottom on TV
[AUDIO] Menu
Set the player’s Audio options according to various
disc output type you use.
Dolby Digital / DTS / MPEG
Select the type of digital audio signal to use the
DIGITAL AUDIO OUT jack.
[Bitstream]: Select to connect DIGITAL AUDIO
OUT jack to an amplier with Dolby Digital, DTS
or MPEG decoder.
[PCM] (for Dolby Digital / MPEG): Select
to connect DIGITAL AUDIO OUT jack to an
amplier without Dolby Digital or MPEG
decoder.
[O] (for DTS): Select to connect DIGITAL
AUDIO OUT jack to an amplier without DTS
decoder.
Sample Freq. (Frequency)
Selects the sampling frequency of the audio signal
between [48KHz] and [96KHz].
DRC (Dynamic Range Control)
To adjust the volume level by itself when Audio
level reaches to more than the specic level (Dolby
Digital only).
Vocal (DV690H/DV692H only)
To mix the vocal with music using the multi-
channel karaoke DVD.

13
System Setting
3
System Setting
[LOCK] Menu
Move to [Area Code] by pressing d. Press ENTER
after input the 4-digit password. Input the same
4-digit with password again to verify and press
ENTER. The Rating and Password menu will be
activated.
Rating
Input the 4-digit password and press ENTER. Select
the level from 1(Kids) to 8 (Adult).
Change Password
Input the former 4-digit password. Input the new
4-digit password and input it again to verify.
If you forget the password
Remove the disc. Input “210499” on Setup
menu and press ENTER. The password will be
cleared.
Area Code
To input the standardized area code refer to the Area
Code List on page 18.
[OTHERS] Menu
B.L.E (Black Level Expansion)
Select [On] or [O ] to expand the black level or not.
It just operates when TV system is set to NTSC.
REC Bitrate (DV692H/DV697H only)
To select bitrate when you record from Audio CD
to USB directly. Higher bitrate gives better sound
quality. For detailed recording method, see page 16.
Score (DV691H/DV697H only)
The score can be displayed after singing a song
with microphone. Select [On] in Score to use this
function. The score is displayed only when a chapter,
title or track is fully nished. Fanfare sounds with the
high score.
DivX VOD
ABOUT DIVX VIDEO: DivX®is a digital video format
created by DivX, Inc. This is an ò cial DivX Certied®
device that plays DivX video. Visit divx.com for more
information and software tools to convert your les
into DivX video.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX
Certied®device must be registered in order to play
purchased DivX Video-on-Demand (VOD) movies. To
obtain your registration code, locate the DivX VOD
section in your device setup menu. Go to vod.divx.
com for more information on how to complete your
registration.
[Register]: Displays the registration code of
your unit.
[Deregister]: Deactivate your unit and display
the deactivation code.

4 Operating
14
Operating
4
Operating
On-Screen display
You can display and adjust various information on-
screen about the loaded disc and USB Device.
Displaying content information
on-screen ry
1. Press DISPLAY to see the various playback
information.
2. Select an available contents by pressing
wsad and ENTER.
3. Change an available content by pressing the
numerical button and ENTER.
4. Press DISPLAY to escape from playback
information.
Current title number/total
number of titles
Current chapter number/
total number of chapters
Elapsed playing time
Total playback time of
current title/le
Selected audio language
and output channel
Selected subtitle
Selected angle/total
number of angles
General Playback
Playing Disc
1. Press B, and place a disc on the disc tray.
2. Press Bto close the disc tray.
3. Press zto play the le.
DVD disc will be automatically loaded.
Playing Karaoke Disc
(DV691H/DV697H only)
1. Insert a Karaoke Disc and connect the
microphone to the MIC jack.
2. Press the KARAOKE button and select [ON] to
activate the microphone.
3. Select a desired song and press zto play the
le.
4. Press KARAOKE to display karaoke menu. Select
an option and the desired mode pressing ws
and ad.
[ECHO/MELODY/VOICE/KEY/EFFECT]
yThe karaoke feature functions only with
karaoke-compatible discs.
yThe VOICE and MELODY menus may not be
available on some karaoke discs.
yThere is microphone’s sound output while
PCM is set for DIGITAL AUDIO OUT.
yDepending on the disc, a karaoke option
may not work.
yAccording to TV model or brand, karaoke
sound from mic can be delayed when TV
and the unit are connected directly, so
please connect the unit with an amplier to
enjoy karaoke with mic.
, Notes the Karaoke
Playing USB Device
(DV692H/DV697H only)
1. Connect the USB device.
2. Change to the USB mode by pressing RETURN.
3. Select the desired le.
4. Press zto play the le.

Operating 15
Operating
4
General operation
To Do this
Playback Press z
Pause Press M
Stop Press Z
Skip to the
next or
previous
Press Cor Vduring
playback
Fast / slow
playback
forward or
backward
Press cor vduring
playback
Resume
playback
Press Zduring playback to save
the stopped point.
yPress Zonce: Displayed MZ
on the screen (Resume Stop)
yPress Ztwice: Displayed Zon
the screen (Complete Stop)
Playback disc
or USB device
with several
kinds of les
Select the proper menu by
continuously pressing TITLE as
MUSIC, PHOTO, and MOVIE.
Screen Saver The Screen Saver operates
when unit let leave for 5minutes
on Stop. Press any buttons to
deactivate it.
Last Scene
Memory
This unit can memorize and play
the lastly viewed scene even
if disc is inserted again after
removal or unit is turned on after
o with same disc. (DVD/ACD
only)
Advanced Playback
Movie ry
To Do this
Display disc
menu
Press DVD MENU (DVD Only)
Play
repeatedly
Press REPEAT during playback.
Press REPEAT repeatedly.
yDVD: CHAPTER/ TITLE /REPEAT
O
yMOVIE: Track/ All/O
Repeat a
specic
portion
Press A-B to beginning and end
points desired repeatedly. To
return to normal playback, Press
A-B again to return to normal
playback.
Set the desired
staring time of
playback
Press DISPLAY during playback.
Select the elapsed Time. Input
the desired starting time of
playback using numerical
buttons and then press ENTER.
For example, set “02:10:20” to
start at 2 hours, 10 minutes, and
20 seconds.
Watch an
enlarged scene
Press ZOOM repeatedly during
playback or pause mode. Use
wsad to move the enlarged
picture.
yZOOM rate:
100%/ 200%/ 300%/ 400%
Play frame-by-
frame
Press Mduring playback and
press Mrepeatedly.
Set and play
the memorized
point
Press MARKER to mark the
desired points up to 9. Press
SEARCH and ad to play at the
memorized point.
Select the
proper subtitle
code on Movie
le
Press and hold SUBTITLE for 3
seconds during playback.The
language code will be appeared.
Select properly displayed subtitle
by pressing ad and, press
ENTER.

Operating16
Operating
4
Music tu
To Do this
Play
repeatedly
Press REPEAT during playback.
Press REPEAT repeatedly.
yTrack/ ALL/(REPEAT O )
Create or
delete your
own program
Press PROGRAM on stop mode,
and then E will be displayed on
screen. Select the desired one or
more les or tracks by pressing
ENTER. If you want to delete
undesired list,
yOne le: Select the le and
press CLEAR
yAll le: Select [Clear All] and
press ENTER
Display le
information
(ID3 Tag)
While playing a MP3 le
containing le information,
the information is displayed by
pressing DISPLAY repeatedly.
Record the
Audio CD to
USB device
(DV692H/
DV697H only)
Insert Audio CD and USB Device,
and then AUDIO Ripping will be
displayed on screen. Press AUDIO,
and then recording will be started.
Recording speed can be adjusted
as X1 or X4 by pressing AUDIO
repeatdly.
yX1: Played back during
recording
yX4: Non-played back during
recording
yRecording of one track:
Playback, pause, or resume stop
mode
yRecording of all tracks: Stop
mode
If you want to stop recording,
press STOP.
The making of unauthorized copies of copy-
protected material, including computer
programs, les, broadcasts and sound
recordings, may be an infringement of
copyrights and constitute a criminal oense.
This equipment should not be used for such
purposes.
Be responsible
Respect copyrights
Photo i
To Do this
Move to
previous or
next photo
Press DISPLAY, and move to
previous or next photo by
pressing Cor V.
Rotate a
Press DISPLAY, and rotate the
photo counterclockwise or
clockwise using ws while
displaying a photo in full screen.
Watch an
enlarged
During slide show, press ZOOM
repeatedly to select zoom mode.
yZOOM rate:
100%/ 200%/ 300%/ 400%
yMove the zoomed photo using
wsad.
View the slide
show Move to“ ” by pressing d
and press ENTER.
Adjust the
slide show
speed
Move to “ ” by pressing
ds and adjust the slide
show speed by pressing ad
repeatedly.
Listen to
music during
slide show
Move to “ ” by pressing ds
and press ENTER.

5 Troubleshooting
17
Troubleshooting
5
Troubleshooting
Troubleshooting
Symptom Cause Solution
No power. The power cord is disconnected. Plug the power cord.
The unit does not
start playback.
An unplayable disc is inserted. Insert a playable disc. (Check the disc type and
regional code.)
The rating level is set. Change the rating level.
The remote
control does not
work properly.
The remote control is not pointed
at the remote sensor on the unit.
Point the remote control at the remote sensor
of the unit.
The remote control is too far from
the unit.
Operate the remote control closer to the unit.
Poor picture
quality and sound
distortion
Fingerprints and dust is stained
on the disc.
Wipe the disc from the center to out with
a clean cloth. Do not use strong solvents
(alcohol, benzine, thinner, commercially
available cleaners)
No picture. The TV is not set to receive the
signal from the unit.
Select the appropriate video input mode on
the TV.
The video cable is not connected
securely
Connect the video cable securely.
The TV does not accept the
resolution that is set on the unit.
Press RESOLUTION repeatedly to select
appropriate resolution till TV accepts it.
No sound. The equipment connected with
the audio cable is not set to
receive the signal from the unit.
Select the correct input mode of the audio
amplier.
The AUDIO options are set to the
wrong position.
Set the AUDIO settings to the correct position.

6 Appendix
Appendix18
Appendix
6
Area Code List
Choose an area code from this list.
Area Code Area Code Area Code Area Code
Afghanistan AF
Argentina AR
Australia AU
Austria AT
Belgium BE
Bhutan BT
Bolivia BO
Brazil BR
Cambodia KH
Canada CA
Chile CL
China CN
Colombia CO
Congo CG
Costa Rica CR
Croatia HR
Czech Republic CZ
Denmark DK
Ecuador EC
Egypt EG
El Salvador SV
Ethiopia ET
Fiji FJ
Finland FI
France FR
Germany DE
Great Britain GB
Greece GR
Greenland GL
Hong Kong HK
Hungary HU
India IN
Indonesia ID
Israel IL
Italy IT
Jamaica JM
Japan JP
Kenya KE
Kuwait KW
Libya LY
Luxembourg LU
Malaysia MY
Maldives MV
Mexico MX
Monaco MC
Mongolia MN
Morocco MA
Nepal NP
Netherlands NL
Antilles AN
New Zealand NZ
Nigeria NG
Norway NO
Oman OM
Pakistan PK
Panama PA
Paraguay PY
Philippines PH
Poland PL
Portugal PT
Romania RO
Russian
Federation RU
Saudi Arabia SA
Senegal SN
Singapore SG
Slovak Republic SK
Slovenia SI
South Africa ZA
South Korea KR
Spain ES
Sri Lanka LK
Sweden SE
Switzerland CH
Taiwan TW
Thailand TH
Turkey TR
Uganda UG
Ukraine UA
United States US
Uruguay UY
Uzbekistan UZ
Vietnam VN
Zimbabwe ZW

Appendix 19
Appendix
6
Language code List
Use this list to input your desired language for the following initial settings: [Disc Audio], [Disc Subtitle] and
[Disc Menu].
Language Code Language Code Language Code Language Code
Afar 6565
Afrikaans 6570
Albanian 8381
Ameharic 6577
Arabic 6582
Armenian 7289
Assamese 6583
Aymara 6588
Azerbaijani 6590
Bashkir 6665
Basque 6985
Bengali; Bangla 6678
Bhutani 6890
Bihari 6672
Breton 6682
Bulgarian 6671
Burmese 7789
Byelorussian 6669
Chinese 9072
Croatian 7282
Czech 6783
Danish 6865
Dutch 7876
English 6978
Esperanto 6979
Estonian 6984
Faroese 7079
Fiji 7074
Finnish 7073
French 7082
Frisian 7089
Galician 7176
Georgian 7565
German 6869
Greek 6976
Greenlandic 7576
Guarani 7178
Gujarati 7185
Hausa 7265
Hebrew 7387
Hindi 7273
Hungarian 7285
Icelandic 7383
Indonesian 7378
Interlingua 7365
Irish 7165
Italian 7384
Japanese 7465
Kannada 7578
Kashmiri 7583
Kazakh 7575
Kirghiz 7589
Korean 7579
Kurdish 7585
Laothian 7679
Latin 7665
Latvian, Lettish 7686
Lingala 7678
Lithuanian 7684
Macedonian 7775
Malagasy 7771
Malay 7783
Malayalam 7776
Maori 7773
Marathi 7782
Moldavian 7779
Mongolian 7778
Nauru 7865
Nepali 7869
Norwegian 7879
Oriya 7982
Panjabi 8065
Pashto, Pushto 8083
Persian 7065
Polish 8076
Portuguese 8084
Quechua 8185
Rhaeto-Romance 8277
Rumanian 8279
Russian 8285
Samoan 8377
Sanskrit 8365
Scots Gaelic 7168
Serbian 8382
Serbo-Croatian 8372
Shona 8378
Sindhi 8368
Singhalese 8373
Slovak 8375
Slovenian 8376
Spanish 6983
Sudanese 8385
Swahili 8387
Swedish 8386
Tagalog 8476
Tajik 8471
Tamil 8465
Telugu 8469
Thai 8472
Tonga 8479
Turkish 8482
Turkmen 8475
Twi 8487
Ukrainian 8575
Urdu 8582
Uzbek 8590
Vietnamese 8673
Volapük 8679
Welsh 6789
Wolof 8779
Xhosa 8872
Yiddish 7473
Yoruba 8979
Zulu 9085

Appendix20
Appendix
6
Specifications
Power
requirements
AC 110 - 240 V, 50/60 Hz
Power
consumption
11 W
Dimensions
(W x D x H)
Approx.
(430 x 200 x 35) mm
Net Weight
(Approx.)
1.5 kg
Operating
temperature
0 °C to 40 °C
Operating
humidity
5 % to 90 %
Laser Semiconductor laser
Signal system NTSC
Bus Power
Supply (USB)
5 V 0500 mA
Video Out 1.0 V (p-p), 75 Ω, sync
negative, RCA jack x 1
Component
Video Out
(Y) 1.0 V (p-p), 75 Ω, sync
negative, RCA jack x 1,
(PB)/(PR) 0.7 V (p-p), 75 Ω,
RCA jack x 2
HDMI Out
(Video/Audio)
19 pin (Type A, HDMI™
Connector)
Audio Out 2.0 Vrms (1 kHz, 0 dB),
600 Ω, RCA jack (L, R) x 1
Digital Audio
Out (COAXIAL)
0.5 V (p-p), 75 Ω,
RCA jack x 1
Digital Audio
Out (OPTICAL)
3 V (p-p), Optical jack x 1
Design and specications are subject to change
without prior notice.
Trademarks and
Licenses
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.
HDMI, the HDMI logo and High-Denition
Multimedia Interface are trademarks or registered
trademarks of HDMI licensing LLC.
“DVD Logo” is a trademark of DVD Format/Logo
Licensing Corporation.
DivX®, DivX Certied®and associated logos are
trademarks of DivX, Inc. and are used under
license.
