LG 26LU55 User manual

iiil kiill _i_
_x
......'*_* E ...... ° A UA
LCD TV /LCD -rv
Please read this manual carefully before operating
your set and retain it for future reference.
LED LCD TV MODELS LCD TV MODELS
19LE5300 32LE5300 42LE7300 32LD420 32LD520
22LE5300 37LE5300 47LE7300 42LD420 42LD520
26LE5300 42LE5300 55LE7300 47LD420 47LD520
22LE5500 47LE5300 42LE530C 32LD450 55LD520
26LE5500 55LE5300 47LE530C 37LD450 42LD630
55LE530C 42LD450 47LD650
47LD450 55LD630
37LD450C
42LD450C
47LD450C
55LD520C
42LD451C
47LD451C
26LD352C
32LD452C
37LD452C
42LD452C
47LD452C
32LD452B
42LD452B
47LD452B
P/NO :SAC34134204 (1106-REV14) www.lg.com

WARNING /CAUTION
2
TO REDUCE THE RISK OF FIRE AND
ELECTRIC SHOCK; DO NOT EXPOSE THIS
PRO DUCTTO R A !N 0 R MO!STU R
This reminder is provided to call the CATV system
installer's attention to Article 820-40 of the National
Electric Code (U.S.A.). The code provides guide-
lines for proper grounding and, in particular, speci-
fies that the cable ground shall be connected to the
grounding system of the building, as close to the
point of the cable entry as practical.
WARNING /CAUTION
To prevent fire or shock hazards, do not expose
this product to rain or moisture.
Class B digital device
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable pro-
tection against harmful interference in a residen-
tial installation. This equipment generates, uses
and can radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is encour-
aged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
-Increase the separation between the equip-
ment and receiver.
- Connect the equipment to an outlet on a circuit
different from that to which the receiver is con-
nected.
- Consult the dealer or an experienced radio/TV
technician for help.
This device complies with part 15 of the FCC
Rules.
Operation is subject to the following two condi-
tions: (1) This device may not cause (harmful)
interference, and (2) this device must accept
any interference received, including interference
that may cause undesired operation (of the
device).
Any changes or modifications in construction of
this device which are not expressly approved by
the party responsible for compliance could void
the user's authority to operate the equipment.
Do not attempt to modify this product in any
way without written authorization from LG
Electronics.
Unauthorized modification could void the user's
authority to operate this product.

SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTI
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
O Do not use this apparatus
near water.
Clean only with dry cloth.
O Do not block any ventilation
openings. Install in accordance
with the manufacturer's
instructions.
O Do not install near any heat
sources such as radiators, heat
registers, stoves, or other appa-
ratus (including amplifiers) that
produce heat.
O Do not defeat the safety pur-
pose of the polarized or ground-
ing-type plug. A polarized plug
has two blades with one wider
than the other• A grounding
type plug has two blades and a
third grounding prong, The wide
blade or the third pronq are
provided for your safety• Tf the
provided plug does not fit into
your outlet, consult an electri-
cian for replacement of the
obsolete outlet•
Protect the power cord from
being walked on or pinched_"_
particularly at plugs, conve-J'0__
nience receptacles, and the__ I
point where they exit from the
apparatus.
Only use attachments/acces-
sories specified by the manu-
facturer.
Q Use only with the cart, stand,
tripod, bracket, or table speci-
fied by the manufacturer, or
sold with the apparatus. When
a cart is used, use caution
when moving the cart/appara-
tus combination to avoid injury
from tip-over.
O Unplug apparatus during
this
lighting storms or when unused
for long periods of time.
@
0
®
ONS
Refer all servicing to qualified service per-
sonnel. Servicing is required when the appa-
ratus has been damaged in any way, such
as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not oper-
ate normally, or has been dropped.
Never touch this apparatus or antenna dur-
ing a thunder or lighting storm.
When mounting a TV on the wall, make sure
not to install the TV by the hanging power
and signal cables on the back of the TV.
Do not allow an impact shock or any objects
to fall into the product, and do not drop
onto the screen with something.
@CAUTION concerning the Power Cord:
It is recommend that appliances be placed
upon a dedicated circuit; that is, a single
outlet circuit which powers only that appli-
ance and has no additional outlets or
branch circuits. Check the specification
page of this owner's manual to be certain.
Do not connect too many appliances to the
same AC power outlet as this could result in
fire or electric shock.
Do not overload wall outlets. Overloaded
wall outlets, loose or damaged wall outlets,
extension cords, frayed power cords, or
damaged or cracked wire insulation are
dangerous .Any of these conditions could
result in electric shock or fire. Periodically
examine the cord of your appliance, and if its
appearance indicates damage or deteriora-
tion, unplug it, discontinue use of the appli-
ance, and have the cord replaced with an
exact replacement part by an authorized
servicer. Protect the power cord from phys-
ical or mechanical abuse, such as being
twisted, kinked, pinched, closed in a door, or
walked upon. Pay particular attention to
plugs, wall outlets, and the point where the
cord exits the appliance.
Do not make the TV with the power cord
plugged in. Do not use a damaged or loose
power cord. Be sure do grasp the plug
when unplugging the power cord. Do not
pull on the power cord to unplug the TV.
3

SAFETY INSTRUCTIONS
4
WARNING - To reduce the risk of
fire or electrical shock, do not
expose this product to rain,
moisture or other liquids. Do notl
touch the TV with wet hands. Do
not install this product near
flammable objects such as gas-
oline or candles or expose the
TV to direct air conditioning.
@Do not expose to dripping or
splashing and do not place
objects filled with liquids, such
as vases, cups, etc. on or over
the apparatus (e.g. on shelves
above the unit).
0GROUNDING
Ensure that you connect the earth ground wire
to prevent possible electric shock (i.e. a TV with
a three-prong grounded AC plug must be con-
nected to a three-prong grounded AC outlet). If
grounding methods are not possible, have a
qualified electrician install a separate circuit
breaker.
Do not try to ground the unit by connecting it to
telephone wires, lightening rods, or gas pipes.
I_ Power
iSupply
Breaker
DISCONNECTING DEVICE FROM MAINS
Mains plug is the disconnecting device. The
plug must remain readily operable.
@As long as this unit is connected to the AC
wall outlet, it is not disconnected from the AC
power source even if you turn off this unit by
SWITCH.
Cleaning
When cleaning, unplug the power cord and
scrub gently with a soft cloth to prevent
scratching. Do not spray water or other liquids
directly on the TV as electric shock may
occur. Do not clean with chemicals such as
alcohol, thinners or benzene.
Moving
Make sure the product is turned off, unplugged
and all cables have been removed. It may
take 2 or more people to carry larger TVs. Do
not press against or put stress on the front
panel of the TV.
@
ANTENNAS
Outdoor antenna grounding
If an outdoor antenna is installed, follow the
precautions below. An outdoor antenna sys-
tem should not be located in the vicinity of
overhead power lines or other electric light
or power circuits, or where it can come in
contact with such power lines or circuits as
death or serious injury can occur.
Be sure the antenna system is grounded so
as to provide some protection against volt-
age surges and built-up static charges.
Section 810 of the National Electrical Code
(NEC) in the U.S.A. provides information
with respect to proper grounding of the
mast and supporting structure, grounding
of the lead-in wire to an antenna discharge
unit, size of grounding conductors, location
of antenna discharge unit, connection to
grounding electrodes and requirements for
the grounding electrode.
Antenna grounding according to the
National Electrical Code, ANSI/NFPA 70
Ground Clamp Antenna Lead in Wire
Antenna Discharge Unit
(NEC Section 810-20)
Grounding Conductor
(NEC Section 810-21)
Ground Clamps
Power Service Grounding
Electrode System (NEC
Art 250, Part H)
NEC: National Electrical Code
Ventilation
Install your TV where there is proper ventila-
tion. Do not install in a confined space such
as a bookcase. Do not cover the product
with cloth or other materials (e.g.) plastic
while plugged in. Do not install in exces-
sively dusty places.
Take care not to touch the ventilation open-
ings. When watching the TV for a long
period, the ventilation openings may
become hot.
If you smell smoke or other odors coming
from the TV, unplug the power cord contact
and authorized service center.
Do not press strongly upon the
panel with hand or sharp object
such as nail, pencil or pen, or
make a scratch on it.
Keep the product away from direct sunlight.

DotDefec'r
ThePlasmaor LCDpanelisa hightechnol-
ogyproductwithresolutionof twomillionto
sixmillionpixels.Inaveryfewcases,you
couldseefinedotsonthescreenwhileyou're
viewingthe TV.Thosedots are deactivated
pixelsanddo notaffecttheperformanceand
reliabilityoftheTV.
GeneratedSound
"Cracking"noise:A crackingnoisethatoccurs
whenwatchingorturningofftheTVisgener-
ated by plasticthermalcontractiondue to
temperatureandhumidity.Thisnoiseiscom-
monfor productswherethermaldeformation
isrequired.
Electricalcircuit humming/panelbuzzing:A
lowlevelnoiseisgeneratedfromahigh-speed
switchingcircuit,whichsuppliesalargeamount
of currentto operatea product. It varies
dependingontheproduct.
This generatedsounddoes not affect the
performanceandreliabilityofthe product.
ForLEDLCDTV/LCDTV
IftheTVfeelscoldtothetouch,theremaybe
a small"flicker"whenit is turnedon.Thisis
normal,thereisnothingwrongwithTV.
Someminutedot defectsmaybe visibleon
the screen,appearingastiny red,green,or
bluespots. However,they haveno adverse
effectonthemonitor'sperformance.
AvoidtouchingtheLCDscreenorholdingyour
finger(s)againstit for longperiodsof time.
Doingsomayproducesometemporarydis-
tortioneffectson thescreen.
5

CONTENTS
WARNING /CAUTION ...............................2
SAFETY INSTRUCTIONS
Important Safety Instructions .............................. _3
FEATURE OF THIS TV ................................8
Accessories ............................................................. 9
Front Panel Information ..................................... 11
Back Panel Information ..................................... 16
Stand Instructions ............................................... 20
VESA wall mounting ......................................... 28
Cable Management .......................................... 30
Desktop Pedestal Installation ......................... 32
Swivel Stand ........................................................ 32
Kensington Security System .......................... 32
Attaching the TV to a Desk ............................ 33
Securing the TV to the Wall to Prevent Falling
when the TV is used on a stand ................... 34
Antenna or Cable Connection ....................... 35
HD Receiver setup ............................................. 36
DVD setup ............................................................ 39
VCR SETUP .......................................................... 41
Other A/V Source Setup ................................. 42
USB Connection ................................................ 43
Headphone Setup ............................................ 43
Audio out Connection ...................................... 44
PC Setup .............................................................. 45
Remote Control Functions .............................. .52
Turning on the TV .............................................. 54
Channel Selection .............................................. .54
Volume Adjustment .......................................... 54
Initial Setting ....................................................... .55
On-Screen Menus Selection .......................... .57
Quick menu ......................................................... 59
Customer Support
6
- Picture Test /Sound Test ........................... 60
- Product/Service Info ....................................... 61
Simple Manual .................................................... 62
Channel Setup
- Auto Scan (Auto Tuning) .............................. 63
- Add/Delete Channel (Manual Tuning) .....64
- Channel Editing ............................................... 65
Favorite Channel Setup .................................... 66
Favorite Channel List ........................................ 66
Channel List ........................................................ 67
Channel Information ......................................... 68
Channel Brief Information ............................... 69
Input List .............................................................. 70
Input Label ............................................................ 71
Reset to factory default (initial Setting) ...... 72
Mode Setting ...................................................... 73
Demo Mode ........................................................ 74
AV Mode ............................................................... 75
SIMPLINK ............................................................. 76
Connection Method .......................................... 78
Entry Mode .......................................................... 79
Movie List ............................................................ SO
Photo List ............................................................. 87
Music List ............................................................. 93
Extra Contents .................................................... 97
EzSign TV ............................................................. 98
DivX Registration Code /Deactivation ......... 99
Picture Size (Aspect Ratio) Control ............ 100
Picture Wizard ................................................... 102
Energy Saving ............................................ 104
Preset Picture Settings (Picture mode) ..... 105
Manual Picture Adjustment - User Mode 106
Picture Improvement Technology (Advanced
Control) ................................................................ 107
Expert Picture Control .................................... 108
Picture Reset ........................................................ 111
Power Indicator .................................................... 111
TruMotion ............................................................ 112

AutoVolume.......................................................113
ClearVoiceII......................................................114
Balance................................................................115
PresetSoundSettings(SoundMode).......116
SoundSettingAdjustment- UserMode...117
AudioReset........................................................118
TVSpeakersOn/Off Setup...........................119
ExternalSpeakersOn/OffSetup.................119
Stereo/SAPBroadcastSetup......................120
AudioLanguage..............................................121
On-screenMenusLanguageSelection....122
CaptionMode
- AnalogBroadcastingSystemCaptions.123
- DigitalBroadcastingSystemCaptions...124
- CaptionOption..............................................125
Troubleshooting................................................142
Maintenance......................................................145
ProductSpecifications...................................146
IRCode................................................................151
ExternalControlthroughRS-232C...........152
OpenSourceLicense.....................................158
ClockSetting
- AutoClockSetup.........................................126
- ManualClockSetup.....................................127
AutoOn/OffTimeSetting............................128
SleepTimerSetting........................................129
AutoShut-OffSetting....................................129
SetPassword& LockSystem
- SettingupYourPassword.............................
- SetPassword..................................................131
- LockSystem...................................................132
ChannelBlocking.............................................133
Movie& TVRating..........................................134
DownloadableRating......................................139
ExternalInputBlocking..................................140
KeyLock..............................................................141
7

FEATURE OF THIS TV
_ Some of these features are not available on all models.
CLEAR
VOICE II
High-definition television. High-
resolution digital television broadcast
and playback system composed of
roughly a million or more pixels, 16:9
aspect-ratio screens, and AC3 digital
audio. A subset of digital television,
HDTV formats include 1080i and 720p
resolutions.
AV Mode is three preset picture and
audio settings. It allows the viewer to
quickly switch between common set-
tings. It includes Cinema, Sports, and
Game Modes.
A unique invisible speaker system
tuned by renowned audio expert, Mr.
Mark Levinson. Speakers are embed-
ded in strategic spots behind the front
cabinet and use minute vibrations to
turn the entire front bezel into the
speaker system. The result s a clean,
polished look, and enhanced audio by
increasing the "sweet spot", giving a
wider and richer sound field.
Automatically enhances and amplifies
the sound of human voice frequency
range to help keep dialogue audible
when background noise swells.
Unlike other sensors which can only
sense brightness of ambient light, LG's
"Intelligent Sensor" uses 4,096 sens-
ing steps to evaluate its surroundings.
Using a sophisticated algorithm, the LG
processes picture quality elements
including brightness, contrast, color,
sharpness and white balance. The result
is a picture optimized for it's surround-
ings, more pleasing to watch and which
can also save up to 50% in power con-
sumption.
FT1DOLBY
DIGITAL I
Manufactured under license from Dolby
Laboratories. "Dolby "and the double-D
symbol are trademarks of Dolby
Laboratories.
H_rn| HDMI, the HDMI logo and High-
Definition Multimedia Interface are
trademarks or registered trademarks of
HDMI Licensing LLC."
_m,% Displays HDTV programs in full 1920 x
FUh_osHe_p_. 1080ppicture.resolution for a more detailed
View videos and photos and listen to
USa.__ music on your TV through USB 2.0
. ('videos' dependent on model).
IlmJllfl_lP_ll_ ABOUT DIVX VIDEO: DivX ':_:'is a digital
video format created by DivX,Inc. This is
HD an official DivX Certified device that
plays DivX video. Visit www.divx.com for
more information and software tools to
convert your files into DivX video.
ABOUT DIVX VIDEO-ON-DEMAND:
This DivX Certified _ device must be
registered in order to play DivX Video-
on-Demand (VOD) content. To gener-
ate the registration code, locate the
DivX VOD section in the device setup
menu. Go to vod.divx.com with this
code to complete the registration pro-
cess and learn more about DivX VOD.
"DivX Certified' to play DivX _ video up
to HD 1080p, including premium con-
tent"
"DivX _, DivX Certified' and associated
Iogos are registered trademarks of
DivX, Inc. and are used under license."
Pat. 7,295,673; 7,460,668; 7,515,710;
7,519,274
8

PREPARATION
ACCESSORIES
Ensure that the following accessories are included with your TV. If an accessory is missing, please con-
tact the dealer where you purchased the TV.
The accessories included may differ from the images below.
(For 32/42/47LD452B) m
SiS
-4
0
Z
Owner's Manual CD Manual EzSign TV Editor Remote Control,
S/W & Manual Batteries (AAA)
Not included with all models
Polishing Cloth
* Wipe spots on the exterior only with the
polishing cloth.
* Do not wipe roughly when removing
stains. Excessive pressure may cause
scratches or discoloration. D-sub 15 pin Cable
When using the VGA (D-sub 15
pin cable) PC connection, the user
must use shielded signal interface
cables with ferrite cores to main-
tain standards compliance.
(For 26LE5300,
26LE5500)
x4 x4
(For 26LE5300,
26LE5500)
x4
(M4 x 14) (M4 x 20)
Screws for stand assembly
(Refer to R20, 22) Cable Holder
(Refer to p.31) Ring spacers (Refer to p.29) AC/DC Adapter Power Cord
(For 37/42/47LD450C,
x8
(For 32/37/42LD450, 37/42/LD450C,
42LD630, 42LD451C, 32/37/42LD452C,
32/42LD452B, 26LD352C)
32/37/42/47LD452C,
32/42/47LD452B,
26LD352C)
(M4 x 20)
Screws for stand
assembly
(Refer to R24)
Screws for stand fixing
(Refer to R33) Protection Cover (Refer to R25) Power Cord Protective Bracket
and Screw for
Power Cord
(Refer to R30)
9

PREPARATION
-u
m
-u
_>
_>
-q
0
z
(For 55LD520C,
55LD520)
x4 x4
(M4 x 24) (M4 x 14)
Screws for stand assembly
(Refer to R26)
Protection Cover
(Refer to R27)
(For 55LD520C)
2
Torx plus Star head screw
(Refer to R26)
Power Cord
(Except 47LD420,
47/55LD520, 55LD520C)
Screw for stand fixing
(Refer to R33)
(For 55LD520C)
Protective Bracket and Screw
for Power Cord (Refer to R30)
(For 42/47/55LE7300) (For 32LE5300) (For 42/47/55LE530C)
x2 2
Cable Holder Component gender Cable Management Screw for stand Torx plus Star head
(Refer to p.31) cable, AV gender cable Clip fixing screw
(Refer to p.31) (Refer to R33) (Refer to P.22)
10

FRONT PANEL INFORMATION
_ Image shown may differ from your TV.
1912212613213714214715SLES300,
22/26LE5500, 42/47/55LE530C
SPEAKER
19/22/26LE5300, 22/26LE5500
Remote Control Sensor
Power/Standby Indicator
(Can be adjusted using the Power Indicator
in the OPTION menu._,,p.111)
32/37/42/47/55LE5300, 42/47/55LE530C
Remote Control Sensor
Intelligent Sensor
Adjusts picture according to
the surrounding conditions
Power/Standby Indicator
(Can be adjusted using the Power Indicator
in the OPTION menu._,p.111)
"13
m
_>
_>
-4
O
z
19/22/26LE5300, 22/26LE5500
CHANNEL VOLUME
(v,A) (-, +)
Buttons Buttons
32/37/42/47/55LE5300, 42/47/55LE530C
CHANNEL VOLUME ENTER
(V,A) (-, +) Button
Buttons Buttons
POWER
Button
POWER
Button 11

PREPARATION
_ Image shown may differ from your TV.
"13
m
-I3
_>
_>
-4
O
Z
32137142147LD450, 37/42/47LD450C, 42/47LD451C, 32137142147LD452C, 32/42/47LD452B
SPEAKER
Remote Control Sensor
Power/Standby Indicator
(Can be adjusted using the Power indicator
in the OPTION menu./_ p.111)
iiiiiiii_
HL!!i_i!i;!;!;!;!;! CHANNEL
(A,V) Buttons
VOLUME (% -)
Buttons
ENTER Button
MENU Button
INPUT Button
POWER Button
26LD352C
12
SPEAKER
Remote Control Sensor
Power/Standby Indicator
(Can be adjusted using the Power indicator
in the OPTION menu._,.p.111)
CHANNEL
(A,V) Buttons
VOLUME (% -)
Buttons
ENTER Button
MENU Button
INPUT Button
POWER Button

42/47/55LD630
SPEAKER
CHANNEL
(A,V) Buttons
__ VOLUME (% -)
Buttons
ENTER Button
MENU Button
INPUT Button
POWER Button
"13
m
"13
_>
_>
-4
O
Z
Power/Standby Indicator
(Can be adjusted using the Power Indicator
in the OPTION menu._, p.111)
Remote Control Sensor
Intelligent Sensor
Adjusts picture according to the surrounding conditions.
13

PREPARATION
_ Image shown may differ from your TV.
q3
m
q3
_>
_>
-4
0
Z
32/42/47LD420
SPEAKER
Remote Control Sensor
Power/Standby Indicator
(Can be adjusted using the Power Indicator
in the OPTION menu.b.,p.111)
CHANNEL
(A,v) Buttons
__ VOLUME (% -)
Buttons
-- ENTER Button
-- MENU Button
-- INPUT Button
-- POWER Button
32/42/47/55LD520, 55LD520C
SPEAKER
Remote Control Sensor,
Intelligent Sensor
Adjusts picture according to
the surrounding conditions
Power/Standby Indicator
(Can be adjusted using the Power Indicator in
the OPTION menu._, p.111)
CHANNEL
(A,V) Buttons
VOLUME (+, -)
Buttons
ENTER Button
MENU Button
INPUT Button
POWER Button
14

42/47/55LE7300
Power/Standby Indicator
(Can be adjusted using the
Power Indicator in the OPTION
menu. _,.p.111)
CHANNEL
(A,V) Buttons
ME (% -)
Buttons
-- ENTER Button
-- MENU Button
-- INPUT Button
-- POWER Button
"13
m
-13
_>
_>
-4
O
Z
Remote Control Sensor
Intelligent Sensor
Adjusts picture according to
the surrounding conditions.
15

PREPARATION
BACK PANEL INFORMATION
_ Image shown may differ from your TV.
-u
m
-u
_>
_>
O
z
19/22/26LE5300, 22/26LE5500,
19/22LE5300,
22LE5500 26LE5300, 26LE5500
Power Connecfion
@ Connect the AC/DC adapter plug to the
power input jack on the TV.
@ Connect the power cord to the AC/DC
adapter first, then plug the power cord into
the wall power outlet.
AC/DC Adaptor
16

32137142147155LE5300, 42147155LE530C
42/47/55LE7300
!iiiilililil;
iiiiiii_ii
i!iiiii!i_ii_iiiili!il
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
A CAUTION
For HDMI IN 4 and USB IN
_, For an optimal connection,
HDMI cables and USB
devices should have bezels
less than 10 mm (0.39
inches) thick.
*A=< 10 mm (0.39 inches)
"13
m
"13
_>
:;D
_>
--4
O
Z
17

PREPARATION
32/42/47LD420, 32/37/42/47LD450, 42/47LD451C
"13
::;D
rrl
"13
-4
0
Z
32/42/47/55LD5200 55LD520C, 42/47/55LD630
32/42/47/55LD520,
55LD520C 42/47/55LD630
_((®.v;
18

37142147LD450C, 32137142147LD452C, 32142147LD452B, 26LD352C
m
)>
>.
-4
0
z
@ HDMI/DVI IN, HDMI IN
Digital Connection.
Supports HD video and Digital audio. Doesn't
support 480i.
Accepts DVI video using an adapter or HDMI
to DVI cable (not included).
@ RGB IN (PC)
Analog PC Connection. Uses a D-sub 15 pin
cable (VGA cable).
AUDIO IN (RGB/DVI)
0.32 cm (1/8 inch) headphone jack for analog
PC audio input.
@ OPTICAL DIGITAL AUDIO OUT
Digital optical audio output for use with amps
and home theater systems.
Note: In standby mode, this port doesn't work.
0 RS-232C IN (CONTROL & SERVICE)
Used by third party devices.
This port is used for service or Hotel mode.
@ AV (Audio/Video) IN
Analog composite connection. Supports stan-
dard definition video only (480i).
ANTENNAICABLE IN
Connect over-the-air or cable signals to this
jack.
COMPONENT IN
Analog Connection.
Supports HD.
Uses a red, green, and blue cable for video &
red and white for audio.
USB INPUT
Used for viewing videos, photos and listening
to MP3s.
@ HEADPHONE
0.32 cm (1/8 inch) headphone jack
Impedance 16 0, Maximum audio out 15 mW
Power Cord Socket
For operation with AC power.
Caution: Never attempt to operate the TV on
DC pwer.
0 REMOTE CONTROL IN
For a wired remote control.
0 EXTERNARL SPEAKER OUT
For use with external speakers.
@ RaP
Connect this to an LG remote jack pack sys-
tem.
19

PREPARATION
_]
m
-D
_>
_]
_>
0
Z
2O
STAND INSTRUCTIONS IFor19/22LE5300, 22LE5500)
_ Image shown may differ from your TV.
INSTALLATION
0Carefully place the TV screen side down
on a cushioned surface to protect the
screen from damage.
Assemble the parts of the STAND BODY
with the STAND BASE of the TV.
STAND BODY
I
D BASE
Assemble the TV as shown.
O Install the 4 screws into the holes shown.
DETACHMENT
Carefully place the TV screen side down on
a cushioned surface to protect the screen
from damage.
zi....
Remove the screws from the TV.
Detach the stand from TV.
