LG 32LD460B User manual

LCD TV
SERVICE MANUAL
CAUTION
BEFORE SERVICING THE CHASSIS,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
CHASSIS : LJ01Z
MODEL : 32LD460B 32LD460B-SA
North/Latin America http://aic.lgservice.com
Europe/Africa http://eic.lgservice.com
Asia/Oceania http://biz.lgservice.com
Internal Use Only
Printed in KoreaP/NO : MFL67183304 (1108-REV00)

Copyright LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
- 2 -
CONTENTS
CONTENTS .............................................................................................. 2
PRODUCT SAFETY ................................................................................. 3
SPECIFICATION....................................................................................... 6
ADJUSTMENT INSTRUCTION............................................................... 10
BLOCK DIAGRAM...................................................................................15
EXPLODED VIEW .................................................................................. 16
SVC. SHEET ...............................................................................................

Copyright LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
- 3 -
SAFETY PRECAUTIONS
Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by in the
Schematic Diagram and Exploded View.
It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent
Shock, Fire, or other Hazards.
Do not modify the original design without permission of manufacturer.
General Guidance
An isolation Transformer should always be used during the
servicing of a receiver whose chassis is not isolated from the AC
power line. Use a transformer of adequate power rating as this
protects the technician from accidents resulting in personal injury
from electrical shocks.
It will also protect the receiver and it's components from being
damaged by accidental shorts of the circuitry that may be
inadvertently introduced during the service operation.
If any fuse (or Fusible Resistor) in this TV receiver is blown,
replace it with the specified.
When replacing a high wattage resistor (Oxide Metal Film Resistor,
over 1 W), keep the resistor 10 mm away from PCB.
Keep wires away from high voltage or high temperature parts.
Before returning the receiver to the customer,
always perform an AC leakage current check on the exposed
metallic parts of the cabinet, such as antennas, terminals, etc., to
be sure the set is safe to operate without damage of electrical
shock.
Leakage Current Cold Check(Antenna Cold Check)
With the instrument AC plug removed from AC source, connect an
electrical jumper across the two AC plug prongs. Place the AC
switch in the on position, connect one lead of ohm-meter to the AC
plug prongs tied together and touch other ohm-meter lead in turn to
each exposed metallic parts such as antenna terminals, phone
jacks, etc.
If the exposed metallic part has a return path to the chassis, the
measured resistance should be between 1 MΩand 5.2 MΩ.
When the exposed metal has no return path to the chassis the
reading must be infinite.
An other abnormality exists that must be corrected before the
receiver is returned to the customer.
Leakage Current Hot Check (See below Figure)
Plug the AC cord directly into the AC outlet.
Do not use a line Isolation Transformer during this check.
Connect 1.5 K / 10 watt resistor in parallel with a 0.15 uF capacitor
between a known good earth ground (Water Pipe, Conduit, etc.)
and the exposed metallic parts.
Measure the AC voltage across the resistor using AC voltmeter
with 1000 ohms/volt or more sensitivity.
Reverse plug the AC cord into the AC outlet and repeat AC voltage
measurements for each exposed metallic part. Any voltage
measured must not exceed 0.75 volt RMS which is corresponds to
0.5 mA.
In case any measurement is out of the limits specified, there is
possibility of shock hazard and the set must be checked and
repaired before it is returned to the customer.
Leakage Current Hot Check circuit
1.5 Kohm/10W
To Instrument’s
exposed
METALLIC PARTS
Good Earth Ground
such as WATER PIPE,
CONDUIT etc.
AC Volt-meter
When 25A is impressed between Earth and 2nd Ground
for 1 second, Resistance must be less than 0.1
*Base on Adjustment standard
IMPORTANT SAFETY NOTICE
0.15 uF
Ω

Copyright LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
- 4 -
CAUTION: Before servicing receivers covered by this service
manual and its supplements and addenda, read and follow the
SAFETY PRECAUTIONS on page 3 of this publication.
NOTE: If unforeseen circumstances create conflict between the
following servicing precautions and any of the safety precautions on
page 3 of this publication, always follow the safety precautions.
Remember: Safety First.
General Servicing Precautions
1. Always unplug the receiver AC power cord from the AC power
source before;
a. Removing or reinstalling any component, circuit board
module or any other receiver assembly.
b. Disconnecting or reconnecting any receiver electrical plug or
other electrical connection.
c. Connecting a test substitute in parallel with an electrolytic
capacitor in the receiver.
CAUTION: A wrong part substitution or incorrect polarity
installation of electrolytic capacitors may result in an
explosion hazard.
2. Test high voltage only by measuring it with an appropriate high
voltage meter or other voltage measuring device (DVM,
FETVOM, etc) equipped with a suitable high voltage probe.
Do not test high voltage by "drawing an arc".
3. Do not spray chemicals on or near this receiver or any of its
assemblies.
4. Unless specified otherwise in this service manual, clean
electrical contacts only by applying the following mixture to the
contacts with a pipe cleaner, cotton-tipped stick or comparable
non-abrasive applicator; 10 % (by volume) Acetone and 90 %
(by volume) isopropyl alcohol (90 % - 99 % strength)
CAUTION: This is a flammable mixture.
Unless specified otherwise in this service manual, lubrication of
contacts in not required.
5. Do not defeat any plug/socket B+ voltage interlocks with which
receivers covered by this service manual might be equipped.
6. Do not apply AC power to this instrument and/or any of its
electrical assemblies unless all solid-state device heat sinks are
correctly installed.
7. Always connect the test receiver ground lead to the receiver
chassis ground before connecting the test receiver positive
lead.
Always remove the test receiver ground lead last.
8. Use with this receiver only the test fixtures specified in this
service manual.
CAUTION: Do not connect the test fixture ground strap to any
heat sink in this receiver.
Electrostatically Sensitive (ES) Devices
Some semiconductor (solid-state) devices can be damaged easily
by static electricity. Such components commonly are called
Electrostatically Sensitive (ES) Devices. Examples of typical ES
devices are integrated circuits and some field-effect transistors and
semiconductor "chip" components. The following techniques
should be used to help reduce the incidence of component
damage caused by static by static electricity.
1. Immediately before handling any semiconductor component or
semiconductor-equipped assembly, drain off any electrostatic
charge on your body by touching a known earth ground.
Alternatively, obtain and wear a commercially available
discharging wrist strap device, which should be removed to
prevent potential shock reasons prior to applying power to the
unit under test.
2. After removing an electrical assembly equipped with ES
devices, place the assembly on a conductive surface such as
aluminum foil, to prevent electrostatic charge buildup or
exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES
devices.
4. Use only an anti-static type solder removal device. Some solder
removal devices not classified as "anti-static" can generate
electrical charges sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate
electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective
package until immediately before you are ready to install it.
(Most replacement ES devices are packaged with leads
electrically shorted together by conductive foam, aluminum foil
or comparable conductive material).
7. Immediately before removing the protective material from the
leads of a replacement ES device, touch the protective material
to the chassis or circuit assembly into which the device will be
installed.
CAUTION: Be sure no power is applied to the chassis or circuit,
and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged
replacement ES devices. (Otherwise harmless motion such as
the brushing together of your clothes fabric or the lifting of your
foot from a carpeted floor can generate static electricity
sufficient to damage an ES device.)
General Soldering Guidelines
1. Use a grounded-tip, low-wattage soldering iron and appropriate
tip size and shape that will maintain tip temperature within the
range or 500 °F to 600 °F.
2. Use an appropriate gauge of RMA resin-core solder composed
of 60 parts tin/40 parts lead.
3. Keep the soldering iron tip clean and well tinned.
4. Thoroughly clean the surfaces to be soldered. Use a mall wire-
bristle (0.5 inch, or 1.25 cm) brush with a metal handle.
Do not use freon-propelled spray-on cleaners.
5. Use the following unsoldering technique
a. Allow the soldering iron tip to reach normal temperature.
(500 °F to 600 °F)
b. Heat the component lead until the solder melts.
c. Quickly draw the melted solder with an anti-static, suction-
type solder removal device or with solder braid.
CAUTION: Work quickly to avoid overheating the circuit
board printed foil.
6. Use the following soldering technique.
a. Allow the soldering iron tip to reach a normal temperature
(500 °F to 600 °F)
b. First, hold the soldering iron tip and solder the strand against
the component lead until the solder melts.
c. Quickly move the soldering iron tip to the junction of the
component lead and the printed circuit foil, and hold it there
only until the solder flows onto and around both the
component lead and the foil.
CAUTION: Work quickly to avoid overheating the circuit
board printed foil.
d. Closely inspect the solder area and remove any excess or
splashed solder with a small wire-bristle brush.
SERVICING PRECAUTIONS

Copyright LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
- 5 -
IC Remove/Replacement
Some chassis circuit boards have slotted holes (oblong) through
which the IC leads are inserted and then bent flat against the
circuit foil. When holes are the slotted type, the following technique
should be used to remove and replace the IC. When working with
boards using the familiar round hole, use the standard technique
as outlined in paragraphs 5 and 6 above.
Removal
1. Desolder and straighten each IC lead in one operation by gently
prying up on the lead with the soldering iron tip as the solder
melts.
2. Draw away the melted solder with an anti-static suction-type
solder removal device (or with solder braid) before removing the
IC.
Replacement
1. Carefully insert the replacement IC in the circuit board.
2. Carefully bend each IC lead against the circuit foil pad and
solder it.
3. Clean the soldered areas with a small wire-bristle brush.
(It is not necessary to reapply acrylic coating to the areas).
"Small-Signal" Discrete Transistor
Removal/Replacement
1. Remove the defective transistor by clipping its leads as close as
possible to the component body.
2. Bend into a "U" shape the end of each of three leads remaining
on the circuit board.
3. Bend into a "U" shape the replacement transistor leads.
4. Connect the replacement transistor leads to the corresponding
leads extending from the circuit board and crimp the "U" with
long nose pliers to insure metal to metal contact then solder
each connection.
Power Output, Transistor Device
Removal/Replacement
1. Heat and remove all solder from around the transistor leads.
2. Remove the heat sink mounting screw (if so equipped).
3. Carefully remove the transistor from the heat sink of the circuit
board.
4. Insert new transistor in the circuit board.
5. Solder each transistor lead, and clip off excess lead.
6. Replace heat sink.
Diode Removal/Replacement
1. Remove defective diode by clipping its leads as close as
possible to diode body.
2. Bend the two remaining leads perpendicular y to the circuit
board.
3. Observing diode polarity, wrap each lead of the new diode
around the corresponding lead on the circuit board.
4. Securely crimp each connection and solder it.
5. Inspect (on the circuit board copper side) the solder joints of
the two "original" leads. If they are not shiny, reheat them and if
necessary, apply additional solder.
Fuse and Conventional Resistor
Removal/Replacement
1. Clip each fuse or resistor lead at top of the circuit board hollow
stake.
2. Securely crimp the leads of replacement component around
notch at stake top.
3. Solder the connections.
CAUTION: Maintain original spacing between the replaced
component and adjacent components and the circuit board to
prevent excessive component temperatures.
Circuit Board Foil Repair
Excessive heat applied to the copper foil of any printed circuit
board will weaken the adhesive that bonds the foil to the circuit
board causing the foil to separate from or "lift-off" the board. The
following guidelines and procedures should be followed whenever
this condition is encountered.
At IC Connections
To repair a defective copper pattern at IC connections use the
following procedure to install a jumper wire on the copper pattern
side of the circuit board. (Use this technique only on IC
connections).
1. Carefully remove the damaged copper pattern with a sharp
knife. (Remove only as much copper as absolutely necessary).
2. carefully scratch away the solder resist and acrylic coating (if
used) from the end of the remaining copper pattern.
3. Bend a small "U" in one end of a small gauge jumper wire and
carefully crimp it around the IC pin. Solder the IC connection.
4. Route the jumper wire along the path of the out-away copper
pattern and let it overlap the previously scraped end of the good
copper pattern. Solder the overlapped area and clip off any
excess jumper wire.
At Other Connections
Use the following technique to repair the defective copper pattern
at connections other than IC Pins. This technique involves the
installation of a jumper wire on the component side of the circuit
board.
1. Remove the defective copper pattern with a sharp knife.
Remove at least 1/4 inch of copper, to ensure that a hazardous
condition will not exist if the jumper wire opens.
2. Trace along the copper pattern from both sides of the pattern
break and locate the nearest component that is directly
connected to the affected copper pattern.
3. Connect insulated 20-gauge jumper wire from the lead of the
nearest component on one side of the pattern break to the lead
of the nearest component on the other side.
Carefully crimp and solder the connections.
CAUTION: Be sure the insulated jumper wire is dressed so the
it does not touch components or sharp edges.

Copyright LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
- 6 -
SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement .
1. Application range
This specification is applied to the LCD TV used LJ01Z chassis.
2. Requirement for Test
Each part is tested as below without special appointment.
1) Temperature
: 25 ºC ± 5 ºC (77 ºF ± 9 ºF), CST : 40 ºC ± 5 ºC
2) Relative Humidity : 65 % ± 10 %
3) Power Voltage
: Standard input voltage (AC 100-240 V~ 50 / 60 Hz)
* Standard Voltage of each products is marked by models.
4) Specification and performance of each parts are followed each drawing and specification by part number in accordance with
BOM.
5) The receiver must be operated for about 5 minutes prior to the adjustment.
3. Test method
1) Performance: LGE TV test method followed
2) Demanded other specification
- Safety: CE, IEC specification
- EMC:CE, IEC
4. General Specification(TV)
No Item Specification Remark
1 Receivable System 1) SBTVD / NTSC / PAL-M / PAL-N
2 Available Channel VHF : 02 ~ 13
UHF : 14 ~ 69
DTV : 07 ~ 69
CATV : 01 ~ 135
3 Input Voltage 1) AC 100 ~ 240V 50/60Hz
4 Market Central and South AMERICA
5 Screen Size 32 inch Wide (1920 x 1080) 32LD460H-SA
42 inch Wide (1920 x 1080) 42LD460H-SA
6 Aspect Ratio 16:9
7 Tuning System FS
8 LCD Module LC320WUG-SCA1 LGD 32LD460H-SA
LC320WUN-SCA2
LC420WUG-SCA1 LGD 42LD460H-SA
9 Operating Environment Temp : 0 ~ 40 deg
Humidity : ~ 80 %
10 Storage Environment Temp : -20 ~ 60 deg
Humidity : -85 %

5. Chrominance & Luminance Specification
- 32LD460H-SA
- 7 - LGE Internal Use OnlyCopyright LG Electronics. Inc. All right reserved.
Only for training and service purposes
1) Standard Test Condition (The unit has been ‘ON’)
2) Stable for approximately 30 minutes in a dark environment at 25 °C ± 2 °C
3) The values specified are at approximate distance 50cm from the LCD surface
4) Ta= 25°C ± 2 °C, VDD, H_VDD, VGH, VGL=TPY, fV=60Hz, Clk=148.5MHz

Copyright LG Electronics. Inc. All right reserved.
Only for training and service purposes - 8 - LGE Internal Use Only
6. DCR/RT specification
Classification Model Freq. DCR RT
min Typ
Edge LED 32/37/42/47/55LE5300 120Hz 2,400,000 3,000,000 2.4ms
22/26LE5300 HD 60Hz 800,000 1,000,000 5ms
LE4600 120Hz 2,400,000 3,000,000 2.4ms
LE6500 FHD 60Hz 1,600,000 2,000,000 4ms
CCFL LD460(H) FHD 60Hz 45,000 60,000 4ms
LD350 HD 60Hz 40,000 50,000 5ms
7. Component Video Input (Y, CB/PB, CR/PR)
No Resolution H-freq(kHz) V-freq.(kHz) Pixel clock Proposed
1. 720*480 15.73 60 13.5135 SDTV ,DVD 480I
2. 720*480 15.73 59.94 13.5 SDTV ,DVD 480I
3. 720*480 31.50 60 27.027 SDTV
4. 720*480 31.47 59.94 27.0 SDTV
5. 1280*720 45.00 60.00 74.25 HDTV
6. 1280*720 44.96 59.94 74.176 HDTV
7. 1920*1080 33.75 60.00 74.25 HDTV
8. 1920*1080 33.72 59.94 74.176 HDTV
9. 1920*1080 67.500 60 148.50 HDTV
10. 1920*1080 67.432 59.94 148.352 HDTV
11. 1920*1080 27.000 24.000 74.25 HDTV
12. 1920*1080 26.97 23.976 74.176 HDTV
13. 1920*1080 33.75 30.000 74.25 HDTV
14. 1920*1080 33.71 29.97 74.176 HDTV
8. RGB Input (PC)
No Resolution H-freq(kHz) V-freq.(kHz) Pixel clock Proposed
PC DDC
1. 640*350 31.468 70.09 25.17 EGA X
2. 720*400 31.469 70.08 28.32 DOS O
3. 640*480 31.469 59.94 25.17 VESA(VGA) O
4 . 800*600 37.879 60.31 40.00 VESA(SVGA) O
5. 1024*768 48.363 60.00 65.00 VESA(XGA) O
6. 1280*768 47.776 59.87 79.50 CVT(WXGA) X
7. 1360*768 47.712 60.015 85.50 VESA(WXGA) X
8. 1280*1024 63.981 60.020 108.00 VESA(SXGA) O
9. 1600*1200 75.00 60.00 162 VESA(UXGA) O
10. 1920*1080 66.50 60 148.5 HDTV 1080P O
• RGB PC Monitor Range Limits
Min Vertical Freq - 56 Hz
Max Vertical Freq - 62 Hz
Min Horiz. Freq - 30 kHz
Max Horiz. Freq - 80 kHz
Pixel Clock - 170 MHz

Copyright LG Electronics. Inc. All right reserved.
Only for training and service purposes - 9 - LGE Internal Use Only
9. HDMI input (PC/DTV)
No Resolution H-freq(kHz) V-freq.(kHz) Pixel clock Proposed
PC DDC
1. 640*350 31.468 70.09 25.17 EGA X
2. 720*400 31.469 70.08 28.32 DOS O
3. 640*480 31.469 59.94 25.17 VESA(VGA) O
4 . 800*600 37.879 60.31 40.00 VESA(SVGA) O
5. 1024*768 48.363 60.00 65.00 VESA(XGA) O
6. 1280*768 47.776 59.870 79.50 CVT(WXGA) X
7. 1360*768 47.712 60.015 85.50 VESA(WXGA) X
8. 1280*1024 63.981 60.020 108.00 VESA(SXGA) O
9. 1600*1200 75.00 60.00 162 VESA(UXGA) O
10. 1920*1080 67.5 60 148.5 HDTV 1080P O
DTV
1 720*480 31.5 60 27.027 SDTV 480P
2 720*480 31.47 59.94 27.00 SDTV 480P
3 1280*720 45.00 60.00 74.25 HDTV 720P
4 1280*720 44.96 59.94 74.176 HDTV 720P
5 1920*1080 33.75 60.00 74.25 HDTV 1080I
6 1920*1080 33.72 59.94 74.176 HDTV 1080I
7 1920*1080 67.500 60 148.50 HDTV 1080P
8 1920*1080 67.432 59.939 148.352 HDTV 1080P
9 1920*1080 27.000 24.000 74.25 HDTV 1080P
10 1920*1080 26.97 23.976 74.176 HDTV 1080P
11 1920*1080 33.75 30.000 74.25 HDTV 1080P
12 1920*1080 33.71 29.97 74.176 HDTV 1080P
• HDMI Monitor Range Limits
Min Vertical Freq - 56 Hz Max Vertical Freq - 62 Hz
Min Horiz. Freq - 30 kHz Max Horiz. Freq - 80 kHz
Pixel Clock - 170 MHz

Copyright LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
- 10 -
ADJUSTMENT INSTRUCTION
1. Application Range
This specification sheet is applied to all of the LCD TV with
LJ01A/LJ01B/LJ01D/LJ01G/LJ01Z chassis.
2. Designation
1) The adjustment is according to the order which is designated
and which must be followed, according to the plan which can
be changed only on agreeing.
2) Power Adjustment: Free Voltage
3) Magnetic Field Condition: Nil.
4) Input signal Unit: Product Specification Standard
5) Reserve after operation: Above 5 Minutes (Heat Run)
Temperature : at 25 ºC ± 5 ºC
Relative humidity : 65 % ± 10 %
Input voltage : 100 ~ 220 V, 50/60 Hz
6) Adjustment equipments: Color Analyzer(CA-210 or CA-110),
DDC Adjustment Jig equipment, Service remote control.
7) Push the “IN STOP” key - For memory initialization.
3. Main PCB check process
* APC - After Manual-Insult, executing APC
* Boot file Download
1) Execute ISP program “Mstar ISP Utility” and then click
“Config” tab.
2) Set as below, and then click “Auto Detect” and check “OK”
message
If “Error” is displayed, Check connection between
computer, jig, and set.
3) Click “Read” tab, and then load download file (XXXX.bin)
by clicking “Read”
4) Click “Connect” tab. If “Can’t” is displayed, check
connection between computer, jig, and set.
5) Click “Auto” tab and set as below
6) Click “Run”.
7) After downloading, check “OK” message.
* USB DOWNLOAD
1) Put the USB Stick to the USB socket
2) Automatically detecting update file in USB Stick
- If your downloaded program version in USB Stick is Low,
it didn’t work. But your downloaded version is High, USB
data is automatically detecting
3) Show the message “Copying files from memory”
filexxx.bin
(4)
(7) .OK
(5)
(6)
(1)
filexxx.bin
(2) (3)
Please Check the Speed :
To use speed between
from 200KHz to 400KHz
Case1 : Software version up
1. After downloading S/W by USB, TV set will reboot
automatically
2. Push “In-stop”key
3. Push “Power on”key
4. Function inspection
5. After function inspection, Push “In-stop”key.
Case2 : Function check at the assembly line
1. When TV set is entering on the assembly line, Push
“In-stop”key at first.
2. Push “Power on”key for turning it on.
-> If you push “Power on”key, TV set will recover
channel information by itself.
3. After function inspection, Push “In-stop”key.

Copyright LG Electronics. Inc. All right reserved.
Only for training and service purposes
4) Updating is staring.
5) Uploading completed, The TV will restart automatically.
6) If your TV is turned on, check your updated version and
Tool option.(explain the Tool option, next stage)
* If downloading version is more high than your TV have,
TV can lost all channel data. In this case, you have to
channel recover. if all channel data is cleared, you didn’t
have a DTV/ATV test on production line.
* After downloading, have to adjust Tool Option again.
1) Push "IN-START" key in service remote control.
2) Select “Tool Option 1”and Push “OK”button.
3) Punch in the number. (Each model has their number)
4) Completed selecting Tool option.
3.1. ADC Process
(1) ADC
- Enter Service Mode by pushing “ADJ”key,
- Enter Internal ADC mode by pushing “G”key at “5. ADC
Calibration”
<Caution> Using ‘power on’button of the Adjustment R/C,
power on TV.
* ADC Calibration Protocol (RS232)
Adjust Sequence
•aa 00 00 [Enter Adjust Mode]
•xb 00 40 [Component1 Input (480i)]
•ad 00 10 [Adjust 480i Comp1]
•xb 00 60 [RGB Input (1024*768)]
•ad 00 10 [Adjust 1024*768 RGB]
•aa 00 90 End Adjust mode
* Required equipment : Adjustment R/C.
3.2. Function Check
* Check display and sound
- Check Input and Signal items. (cf. work instructions)
1) TV
2) AV (SCART1/SCART2/ CVBS)
3) COMPONENT (480i)
4) RGB (PC : 1024 x 768 @ 60hz)
5) HDMI
6) PC Audio In
* Display and Sound check is executed by Remote control.
- 11 - LGE Internal Use Only
No Item CMD1 CMD2 Data0
Enter Adjust Adjust A A 0 0 When transfer the ‘Mode In’,
Mode ‘Mode In’Carry the command.
ADC adjust ADC Adjust A D 1 0 Automatically adjustment
(The use of a internal pattern)

4. Total Assembly line process
4.1. Adjustment Preparation
·W/B Equipment condition
CA210 : CH 9, Test signal : Inner pattern (85IRE)
·Above 5 minutes H/run in the inner pattern. (“power on”key
of adjust remote control)
* Connecting picture of the measuring instrument
(On Automatic control)
Inside PATTERN is used when W/B is controlled. Connect to
auto controller or push Adjustment R/C POWER ON ->
Enter the mode of White-Balance, the pattern will come out.
* Auto-control interface and directions
1) Adjust in the place where the influx of light like floodlight
around is blocked. (illumination is less than 10 lux).
2) Adhere closely the Color Analyzer (CA210) to the module
less than 10 cm distance, keep it with the surface of the
Module and Color Analyzer’s prove vertically.(80°~ 100°).
3) Aging time
- After aging start, keep the power on (no suspension of
power supply) and heat-run over 5 minutes.
- Using ‘no signal’or ‘full white pattern’or the others,
check the back light on.
•Auto adjustment Map(RS-232C)
RS-232C COMMAND
[CMD ID DATA]
Wb 00 00 White Balance Start
Wb 00 ff White Balance End
<Caution>
Color Temperature : COOL, Medium, Warm.
One of R Gain/G Gain/ B Gain should be kept on 0xC0, and
adjust other two lower than C0.
(when R/G/B Gain are all C0, it is the FULL Dynamic Range
of Module)
* Manual W/B process using adjusts Remote control.
•After enter Service Mode by pushing “ADJ”key,
•Enter White Balance by pushing “G”key at “6. White
Balance”.
* After done all adjustments, Press “In-start”button and
compare Tool option and Area option value with its BOM, if
it is correctly same then unplug the AC cable. If it is not
same, then correct it same with BOM and unplug AC cable.
For correct it to the model’s module from factory Jig model.
* Push the “IN STOP”key after completing the function
inspection. And Mechanical Power Switch must be set
“ON”.
4.2. DDC EDID Write (RGB 128Byte)
•Connect D-sub Signal Cable to D-sub Jack.
•Write EDID Data to EEPROM(24C02) by using DDC2B
protocol.
•Check whether written EDID data is correct or not.
* For SVC main Assembly, EDID have to be downloaded to
Insert Process in advance.
4.3. DDC EDID Write (HDMI 256Byte)
•Connect HDMI Signal Cable to HDMI Jack.
•Write EDID Data to EEPROM(24C02) by using DDC2B
protocol.
•Check whether written EDID data is correct or not.
* For SVC main Assembly, EDID have to be downloaded to
Insert Process in advance.
4.4. EDID DATA
1) All Data : HEXA Value
2) Changeable Data :
*: Serial No : Controlled / Data:01
**: Month : Controlled / Data:00
***:Year : Controlled
****:Check sum
- 12 - LGE Internal Use OnlyCopyright LG Electronics. Inc. All right reserved.
Only for training and service purposes
Cool 13,000 K X=0.269(±0.002)
Y=0.273(±0.002) <Test Signal>
Medium 9,300 K X=0.285(±0.002) Inner pattern
Y=0.293(±0.002) (216gray,85IRE)
Warm 6,500 K X=0.313(±0.002)
Y=0.329(±0.002)
Full White Pattern
COLOR
ANALYZER
TYPE: CA-210
RS-232C Communication
CA-210
RS-232C COMMAND MIN CENTER MAX
[CMD ID DATA] (DEFAULT)
Cool Mid Warm Cool Mid Warm
R Gain jg Ja jd 00 172 192 192 192
G Gain jh Jb je 00 172 192 192 192
B Gain ji Jc jf 00 192 192 172 192
R Cut 64 64 64 128
G Cut 64 64 64 128
B Cut 64 64 64 128

Copyright LG Electronics. Inc. All right reserved.
Only for training and service purposes
4.5. Auto Download
1) Press Adj. key on the Adj. Remote control.
2) Select EDID D/L menu.
3) By pressing Enter key, EDID download will begin
4) If Download is successful, OK is display, but If Download if
failure, NG is displayed.
5) If Download is failure, Re-try downloads.
* Edid data and Model option download (RS232)
- Manual Download
* Caution
1) Use the proper signal cable for EDID Download
- Analog EDID : Pin3 exists
- Digital EDID : Pin3 exists
2) Never connect HDMI & D-sub Cable at the same time.
3) Use the proper cables below for EDID Writing
4) Download HDMI1, HDMI2, separately because HDMI1 is
different from HDMI2
1) FHD RGB EDID data(Check sum:1D)
2) FHD HDMI EDID data
HDMI 1 (Check sum:04, 5A)
HDMI 2 (Check sum:04, 4A)
HDMI 3 (Check sum:04, 3A)
LGE Internal Use Only
- 13 -
Item
Manufacturer ID
Version
Revision
Condition
GSM
Digital : 1
Digital : 3
Data(Hex)
1E6D
01
03
D-sub to D-sub DVI-D to HDMI or HDMI to HDMI
For HDMI EDIDFor Analog EDID
NO Item CMD1 CMD2 Data0
Enter Download A A 0 0 When transfer the ‘Mode In’,
download Mode ‘Mode In’Carry the command.
EDID data Download A E 00 10 Automatically Download
and Model (The use of a internal pattern)
option download

HDMI 4 (Check sum:04, 2A)
3) HD RGB EDID data(Check sum:70)
4) HD HDMI EDID data
HDMI 1 (Check sum:1C, BA)
HDMI 2 (Check sum:1C, AA)
- Model List
4.5. V-COM Adjust(Only LGD(M+S) Module)
- Why need Vcom adjustment?
AThe Vcom (Common Voltage) is a Reference Voltage of
Liquid Crystal Driving.
-> Liquid Crystal need for Polarity Change with every frame.
- Adjust sequence
·Press the PIP key of th ADJ remote control.(This PIP key is
hot key to enter the VCOM adjusting mode)
(Or After enter Service Mode by pushing “ADJ”key, then
Enter V-Com Adjust mode by pushing “G”key at “10. V-
Com”
·As pushing the right or the left key on the remote control,
and find the V-COM value which is no or minimized the
Flicker. (If there is no flicker at default value, Press the exit
key and finish the VCOM adjustment.)
·Push the “OK”key to store value. Then the message
“Saving OK”is pop.
·Press the exit key to finish VCOM adjustment.
(Visual Adjust and control the Voltage level)
4.6. Outgoing condition Configuration
- When pressing IN-STOP key by SVC remocon, Red LED
are blinked alternatively. And then Automatically turn off.
(Must not AC power OFF during blinking)
4.7. Internal pressure
Confirm whether is normal or not when between power
board’s ac block and GND is impacted on 1.5 kV(dc) or 2.2
kV(dc) for one second.
- 14 - LGE Internal Use OnlyCopyright LG Electronics. Inc. All right reserved.
Only for training and service purposes
HD(CCFL) FHD(CCFL) HD(LED) FHD Small(LED) FHD(LED)
32LD350-SB 32LD460-SA 22LE5300-SA 22LE6500-SA 32LE4600-SA
37LD460-SA 26LE5300-SA 26LE6500-SA 42LE4600-SA
42LD460-SA 47LE4600-SA
47LD460-SA 55LE4600-SA
32LD420-SA 32LE5300-SA
42LD420-SA 37LE5300-SA
32LD460H-SA 42LE5300-SA
42LD460H-SA 47LE5300-SA
55LE5300-SA
Row Line
Column Line
CLC CST
Panel
S
Y
S
T
E
M
Gat e Driv e IC
Source D rive I C
Circuit Block
Ti m in g
Cont roll e r
Po w er
Blo ck
VCOM
Gamma
Reference V oltage
Gamm a Reference
Volta ge
Data(R,G,B) & C ontrol signal
Control signal
Data (R,G,B ) &
Control signal
In terface
TFT
Po w er I np ut
Power Input
Da t a I n pu t
Da t a I n pu t
VCOM
Liquid
Crystal
VCOM

Copyright LG Electronics. Inc. All right reserved.
Only for training and service purposes - 15 - LGE Internal Use Only
BLOCK DIAGRAM

Copyright LG Electronics. Inc. All right reserved.
Only for training and service purposes
- 16 - LGE Internal Use Only
300
200
530
810
400
510
120
500
A7
A2 A5 A10
A21
900
910
800
LV1
540
521
550
EXPLODED VIEW
Many electrical and mechanical parts in this chassis have special safety-related characteristics. These
parts are identified by in the Schematic Diagram and EXPLODED VIEW.
It is essential that these special safety parts should be replaced with the same components as
recommended in this manual to prevent X-RADIATION, Shock, Fire, or other Hazards.
Do not modify the original design without permission of manufacturer.
IMPORTANT SAFETY NOTICE

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
MODEL_OPT_2
/PCM_WE
10K
R104
OPT
HP_DET
S7_RXD
I2C_SDA
SPI_SDI
FRC_RESET
+3.3V_Normal
I2C_SDA
/PF_OE
PCM_A[0-7]
+3.5V_ST
8pF
OPT
C104
0.1uF
OPT
C108
CAT24WC08W-T
IC103
3
A2
2
A1
4
VSS
1
A0
5SDA
6SCL
7WP
8VCC
TUNER_RESET
FRC_PWM1
CI_TS_DATA[0-7]
100
R158
SCAN
M_REMOTE_RX
1K
OPT
R105
UART_FRC_TX
1K
OPT
R108
DEMOD_RESET
PCM_D[0-7]
1KR126
PF_ALE
PF_ALE
SPI_SCK
HY27UF082G2B-TPCB
IC102
2GBIT
26 NC_17
27 NC_18
28 NC_19
29 I/O0
30 I/O1
31 I/O2
32 I/O3
33 NC_20
34 NC_21
35 NC_22
36 VSS_2
37 VCC_2
38 NC_23
39 NC_24
40 NC_25
41 I/O4
42 I/O5
43 I/O6
44 I/O7
45 NC_26
46 NC_27
47 NC_28
48 NC_29
17
ALE
3
NC_3
6
NC_6
16
CLE
15
NC_10
14
NC_9
13
VSS_1
12
VCC_1
11
NC_8
10
NC_7
9
CE
8
RE
7
R/B
4
NC_4
5
NC_5
25 NC_16 24
NC_15
23
NC_14
2
NC_2
22
NC_13
21
NC_12
1
NC_1
20
NC_11
19
WP
18
WE
/PCM_WAIT
1K
R125
OPT
DSUB_DET
4.7K
R113
M_REMOTE_TX
USB1_OCD
/PF_WE
FE_TS_VAL_ERR
1K
R115
ERROR_OUT
22R134
100
R159
SCAN
CI_TS_SYNC
SC1/COMP1_DET
A_DIM
/PCM_REG
FE_TS_SYNC
PCM_5V_CTL
S7_TXD
5V_DET_HDMI_4
22
R128
+3.3V_Normal
/PCM_IRQA
+5V_Normal
/PF_OE
2.2uF
C111
FRC_SCL
1K OPT
R118
SC_RE1
/PCM_IOWR
0
R103
SCAN_BLK1/OPC_OUT
/PF_CE1
SPI_SDO
0.1uF
C107
22 R149
M_REMOTE
/PCM_IORD
5V_DET_HDMI_3
PWM2
0.1uF
C105
0.1uF
C103
/PF_WE
22R135
I2C_SDA
5V_DET_HDMI_2
ET_RXER
1KR124
MODEL_OPT_3
1K
R120
OPT
8pF
OPT
C106
FRC_PWM0
1K
R123
OPT
33 R146
/PF_CE1
/PF_CE0
3.3K
OPT
R101
AV_CVBS_DET
RGB_DDC_SDA
PWM0
MODEL_OPT_1
I2C_SCL
22 R148
M_REMOTE
CI_TS_VAL
PCM_A[0-14]
10K
R133
I2C_SCL
/F_RB
/RST_PHY
0
SCAN_CCFL_55"
R155
PWM_DIM
/PCM_OE
UART_FRC_RX
KRC103S
OPT
Q101
E
B
C
1K R106
22R138
FE_TS_DATA[0-7]
PCM_RST
1K
R117
/PF_WP
I2C_SCL
SCAN_BLK2
SC_RE2
1K OPT
R116
+3.3V_Normal
1K
R107
100
R157
NON_SCAN_CCFL_55"
10K
R132
22R137
CI_TS_CLK
SIDEAV_DET
/PF_CE0
HY27US08121B-TPCB
512MBIT
IC102-*1
26 NC_17
27 NC_18
28 NC_19
29 I/O0
30 I/O1
31 I/O2
32 I/O3
33 NC_20
34 NC_21
35 NC_22
36 VSS_2
37 VCC_2
38 PRE
39 NC_23
40 NC_24
41 I/O4
42 I/O5
43 I/O6
44 I/O7
45 NC_25
46 NC_26
47 NC_27
48 NC_28
17
ALE
3
NC_3
6
NC_6
16
CLE
15
NC_10
14
NC_9
13
VSS_1
12
VCC_1
11
NC_8
10
NC_7
9
CE
8
RE
7
R/B
4
NC_4
5
NC_5
25 NC_16 24
NC_15
23
NC_14
2
NC_2
22
NC_13
21
NC_12
1
NC_1
20
NC_11
19
WP
18
WE
/PCM_CD
/F_RB
0.1uF
C101
22R139
5V_DET_HDMI_1
/SPI_CS
/PCM_CE
/PF_WP
3.9KR109
0.1uF
C109
4.7KR127
+3.3V_Normal
USB1_CTL
MODEL_OPT_0
PWM0
FRC_SDA
22R129
PWM1
+3.3V_Normal
PWM2
WIRELESS_DL_RX
22R136
RGB_DDC_SCL
WIRELESS_DL_TX
1KR121
FE_TS_CLK
3.3K
R102
33 R147
33 R151
PWM0
PWM1
AUD_LRCH
AUD_MASTER_CLK
AUD_SCK
+3.3V_Normal
22R111
22R112
10K
R156
/FLASH_WP
/RST_HUB
10uF
C102
12505WS-03A00
P3903
URSA_DEBUG
1
2
3
4
12505WS-03A00
P3904
URSA_DEBUG
1
2
3
4
NEC_SDA
I2C_SDA
I2C_SCL
AMP_SCL
3.3K R142 2.2K R145 3.3K R143 2.2K R144
AMP_SDA
+3.3V_Normal
NEC_SCL
CONTROL_ATTEN
1K
R160 /PIF_SPI_CS
M24M01-HRMN6TP
IC104
3
E2
2
E1
4
VSS
1
NC
5SDA
6SCL
7WP
8VCC
22
AR104
22
AR103
22
AR101
22
AR102
1K R141 1K R140
0 R110
0 R150
MODEL_OPT_6
NAND01GW3B2CN6E
IC102-*2
1GBIT
26 NC_17
27 NC_18
28 NC_19
29 I/O0
30 I/O1
31 I/O2
32 I/O3
33 NC_20
34 NC_21
35 NC_22
36 VSS_2
37 VDD_2
38 NC_23
39 NC_24
40 NC_25
41 I/O4
42 I/O5
43 I/O6
44 I/O7
45 NC_26
46 NC_27
47 NC_28
48 NC_29
17
AL
3
NC_3
6
NC_6
16
CL
15
NC_10
14
NC_9
13
VSS_1
12
VDD_1
11
NC_8
10
NC_7
9
E
8
R
7
RB
4
NC_4
5
NC_5
25 NC_16 24
NC_15
23
NC_14
2
NC_2
22
NC_13
21
NC_12
1
NC_1
20
NC_11
19
WP
18
W
LGE107D (S7M Divx_Non RM)
IC101
S7M_DIVX & MS10
PCM_D0
U22
PCM_D1
T21
PCM_D2
T22
PCM_D3
AB18
PCM_D4
AC18
PCM_D5
AC19
PCM_D6
AC20
PCM_D7
AC21
PCM_A0
U21
PCM_A1
V21
PCM_A2
Y22
PCM_A3
AA22
PCM_A4
R22
PCM_A5
R21
PCM_A6
T23
PCM_A7
T24
PCM_A8
AA23
PCM_A9
Y20
PCM_A10
AB17
PCM_A11
AA21
PCM_A12
U23
PCM_A13
Y23
PCM_A14
W23
PCM_REG_N
W22
PCM_OE_N
AA17
PCM_WE_N
V22
PCM_IORD_N
W21
PCM_IOWR_N
Y21
PCM_CE_N
AA20
PCM_IRQA_N
V23
PCM_CD_N
P23
PCM_WAIT_N
R23
PCM_RESET
P22
PCM_PF_CE0Z
AC17
PCM_PF_CE1Z
AB20
PCM_PF_OEZ
AA18
PCM_PF_WEZ
AB21
PCM_PF_ALE
AB19
PCM_PF_AD[15]
AD17
PCM_PF_RBZ
AA19
UART_TX2/GPIO65
M23
UART_RX2/GPIO64
N23
DDCR_DA/GPIO71
M22
DDCR_CK/GPIO72
N22
DDCA_DA/UART0_TX
A5
DDCA_CK/UART0_RX
B5
PWM0/GPIO66
K23
PWM1/GPIO67
K22
PWM2/GPIO68
G23
PWM3/GPIO69
G22
PWM4/GPIO70
G21
SAR0/GPIO31
C6
SAR1/GPIO32
B6
SAR2/GPIO33
C8
SAR3/GPIO34
C7
SAR4/GPIO35
A6
GPIO143/TCON0 N21
GPIO145/TCON2 M21
GPIO147/TCON4 L22
GPIO149/TCON6 L21
GPIO151/TCON8 P21
GPIO36/UART3_RX K21
GPIO37/UART3_TX L23
GPIO38 K20
GPIO39 L20
GPIO40 M20
GPIO41 G20
GPIO42 G19
GPIO50/UART1_RX F20
GPIO51/UART1_TX F19
GPIO6/PM0/INT0 E7
GPIO7/PM1/PM_UART_TX D7
GPIO8/PM2 E11
GPIO9/PM3 G9
GPIO10/PM4 F9
GPIO11/PM5/PM_UART_RX/INT1 C5
PM_SPI_CS1/GPIO12/PM6 E8
PM_SPI_WP1/GPIO13/PM7 E9
PM_SPI_WP2/GPIO14/PM8/INT2 F7
GPIO15/PM9 F6
PM_SPI_CS2/GPIO16/PM10 D8
GPIO17/PM11/INT3 G12
GPIO18/PM12/INT4 F10
PM_SPI_CK/GPIO1 D9
GPIO0/PM_SPI_CZ D11
PM_SPI_DI/GPIO2 E10
PM_SPI_DO/GPIO3 D10
TS0_CLK AA9
TS0_VLD AA5
TS0_SYNC AA10
TS0_D0 AB5
TS0_D1 AC4
TS0_D2 Y6
TS0_D3 AA6
TS0_D4 W6
TS0_D5 AA7
TS0_D6 Y9
TS0_D7 AA8
TS1_CLK AC5
TS1_VLD AC6
TS1_SYNC AB6
TS1_D0 AC10
TS1_D1 AB10
TS1_D2 AC9
TS1_D3 AB9
TS1_D4 AC8
TS1_D5 AB8
TS1_D6 AC7
TS1_D7 AB7
MPIF_CLK D12
MPIF_CS_N D14
MPIF_BUSY E14
MPIF_D0 E12
MPIF_D1 F12
MPIF_D2 D13
MPIF_D3 E13
LGE101D (S7 Non_Tcon/RM)
IC101-*8
S7_DIVX & MS10
NC_48
AE1
NC_78
AF16
NC_64
AF1
NC_50
AE3
NC_45
AD14
NC_34
AD3
NC_77
AF15
NC_65
AF2
NC_62
AE15
NC_33
AD2
NC_47
AD16
NC_46
AD15
NC_63
AE16
NC_66
AF3
NC_76
AF14
NC_32
AD1
NC_44
AD13
NC_61
AE14
NC_60
AE13
NC_51
AE4
NC_36
AD5
NC_67
AF4
NC_35
AD4
NC_49
AE2
NC_71
AF8
NC_40
AD9
NC_56
AE9
NC_72
AF9
NC_58
AE11
NC_69
AF6
NC_53
AE6
NC_74
AF11
NC_37
AD6
NC_43
AD12
NC_52
AE5
NC_75
AF12
NC_68
AF5
NC_59
AE12
NC_57
AE10
NC_70
AF7
NC_42
AD11
NC_38
AD7
NC_41
AD10
NC_54
AE7
NC_73
AF10
NC_39
AD8
NC_55
AE8
NC_12
Y11
GND_105
Y19
LVACLKP/LLV6P/BLUE[3] W26
LVACLKN/LLV6N/BLUE[2] W25
LVA0P/LLV3P/BLUE[9] U26
LVA0N/LLV3N/BLUE[8] U25
LVA1P/LLV4P/BLUE[7] U24
LVA1N/LLV4N/BLUE[6] V26
LVA2P/LLV5P/BLUE[5] V25
LVA2N/LLV5N/BLUE[4] V24
LVA3P/LLV7P/BLUE[1] W24
LVA3N/LLV7N/BLUE[0] Y26
LVA4P/LLV8P Y25
LVA4N/LLV8N Y24
LVBCLKP/LLV0P/GREEN[5] AC26
LVBCLKN/LLV0N/GREEN[4] AC25
LVB0P/RLV6P/RED[1] AA26
LVB0N/RLV6N/RED[0] AA25
LVB1P/RLV7P/GREEN[9] AA24
LVB1N/RLV7N/GREEN[8] AB26
LVB2P/RLV8P/GREEN[7] AB25
LVB2N/RLV8N/GREEN[6] AB24
LVB3P/LLV1P/GREEN[3] AC24
LVB3N/LLV1N/GREEN[2] AD26
LVB4P/LLV0P/GREEN[1] AD25
LVB4N/LLV0N/GREEN[0] AD24
RLV3P/RED[7] AD23
RLV3N/RED[6] AE23
RLV0P/LVSYNC AE26
RLV0N/LHSYNC AE25
RLV1N/LCK AF26
RLV2P/RED[9] AF25
RLV1P/LDE AE24
RLV2N/RED[8] AF24
RLV4P/RED[5] AF23
RLV4N/RED[4] AD22
RLV5P/RED[3] AE22
RLV5N/RED[2] AF22
TCON3/OE/GOE/GCLK2 AD19
TCON15/SCAN_BLK1 AE19
TCON18/CS7/GCLK5 AD21
TCON19/CS8/GCLK6 AE21
TCON11/CS5/HCON AF21
TCON10/CS4/OPT_N AD20
TCON9/CS3/OPT_P AE20
TCON16/WPWM AF20
TCON12/DPM AF19
TCON1/STV/GSP/VST AD18
TCON5/TP/SOE AE18
TCON14/SACN_BLK AF18
TCON21/CS10/VGH_ODD AB22
TCON20/CS9/VGH_EVEN AB23
TCON13/LEDON AC23
TCON17/CS6/GCLK4 AC22
NC_26 AB16
NC_19 AA14
NC_30 AC15
NC_15 Y16
NC_31 AC16
NC_29 AC14
NC_21 AA16
NC_20 AA15
NC_11 Y10
NC_17 AA11
NC_25 AB15
NC_24 AB14
LGE105D(S7-Tcon Divx_ Non_RM)
IC101-*4
S7T_DIVX & MS10
NC_43
AE1
NC_73
AF16
NC_59
AF1
NC_45
AE3
NC_40
AD14
NC_29
AD3
NC_72
AF15
NC_60
AF2
NC_57
AE15
NC_28
AD2
NC_42
AD16
NC_41
AD15
NC_58
AE16
NC_61
AF3
NC_71
AF14
NC_27
AD1
NC_39
AD13
NC_56
AE14
NC_55
AE13
NC_46
AE4
NC_31
AD5
NC_62
AF4
NC_30
AD4
NC_44
AE2
NC_66
AF8
NC_35
AD9
NC_51
AE9
NC_67
AF9
NC_53
AE11
NC_64
AF6
NC_48
AE6
NC_69
AF11
NC_32
AD6
NC_38
AD12
NC_47
AE5
NC_70
AF12
NC_63
AF5
NC_54
AE12
NC_52
AE10
NC_65
AF7
NC_37
AD11
NC_33
AD7
NC_36
AD10
NC_49
AE7
NC_68
AF10
NC_34
AD8
NC_50
AE8
NC_12
Y11
GND_105
Y19
RLV3P W26
RLV3N W25
RLV0P U26
RLV0N U25
RLV1P U24
RLV1N V26
RLV2P V25
RLV2N V24
RLVCKP W24
RLVCKN Y26
RLV4P Y25
RLV4N Y24
WPWM AC26
OPTP/FLK2 AC25
RLV5P AA26
RLV5N AA25
RLV6P AA24
RLV6N AB26
RLV7P AB25
RLV7N AB24
OPTN/FLK3 AC24
FLK AD26
GCLK6 AD25
GCLK5 AD24
LLV3P AD23
LLV3N AE23
LLV0P AE26
LLV0N AE25
LLV1P AF26
LLV1N AF25
LLV2P AE24
LLV2N AF24
LLVCKP AF23
LLVCKN AD22
LLV4P AE22
LLV4N AF22
GOE/GCLK1 AD19
GSC/GCLK3 AE19
LLV5P AD21
LLV5N AE21
LLV6P AF21
LLV6N AD20
LLV7P AE20
LLV7N AF20
GSPR AF19
GSP/VST AD18
SOE AE18
POL AF18
VDD_ODD AB22
VDD_EVEN AB23
GCLK4 AC23
GCLK2 AC22
NC_23 AB16
DPM AA14
HCON AC15
NC_15 Y16
NC_26 AC16
LEDON AC14
NC_20 AA16
NC_19 AA15
NC_11 Y10
NC_17 AA11
SCAN_BLK AB15
SCAN_BLK1 AB14
LGE101 (S7 NON_TON/DiX/RM)
IC101-*10
S7_NON_DIVX & MS10
NC_48
AE1
NC_78
AF16
NC_64
AF1
NC_50
AE3
NC_45
AD14
NC_34
AD3
NC_77
AF15
NC_65
AF2
NC_62
AE15
NC_33
AD2
NC_47
AD16
NC_46
AD15
NC_63
AE16
NC_66
AF3
NC_76
AF14
NC_32
AD1
NC_44
AD13
NC_61
AE14
NC_60
AE13
NC_51
AE4
NC_36
AD5
NC_67
AF4
NC_35
AD4
NC_49
AE2
NC_71
AF8
NC_40
AD9
NC_56
AE9
NC_72
AF9
NC_58
AE11
NC_69
AF6
NC_53
AE6
NC_74
AF11
NC_37
AD6
NC_43
AD12
NC_52
AE5
NC_75
AF12
NC_68
AF5
NC_59
AE12
NC_57
AE10
NC_70
AF7
NC_42
AD11
NC_38
AD7
NC_41
AD10
NC_54
AE7
NC_73
AF10
NC_39
AD8
NC_55
AE8
NC_12
Y11
GND_105
Y19
LVACLKP/LLV6P/BLUE[3] W26
LVACLKN/LLV6N/BLUE[2] W25
LVA0P/LLV3P/BLUE[9] U26
LVA0N/LLV3N/BLUE[8] U25
LVA1P/LLV4P/BLUE[7] U24
LVA1N/LLV4N/BLUE[6] V26
LVA2P/LLV5P/BLUE[5] V25
LVA2N/LLV5N/BLUE[4] V24
LVA3P/LLV7P/BLUE[1] W24
LVA3N/LLV7N/BLUE[0] Y26
LVA4P/LLV8P Y25
LVA4N/LLV8N Y24
LVBCLKP/LLV0P/GREEN[5] AC26
LVBCLKN/LLV0N/GREEN[4] AC25
LVB0P/RLV6P/RED[1] AA26
LVB0N/RLV6N/RED[0] AA25
LVB1P/RLV7P/GREEN[9] AA24
LVB1N/RLV7N/GREEN[8] AB26
LVB2P/RLV8P/GREEN[7] AB25
LVB2N/RLV8N/GREEN[6] AB24
LVB3P/LLV1P/GREEN[3] AC24
LVB3N/LLV1N/GREEN[2] AD26
LVB4P/LLV0P/GREEN[1] AD25
LVB4N/LLV0N/GREEN[0] AD24
RLV3P/RED[7] AD23
RLV3N/RED[6] AE23
RLV0P/LVSYNC AE26
RLV0N/LHSYNC AE25
RLV1N/LCK AF26
RLV2P/RED[9] AF25
RLV1P/LDE AE24
RLV2N/RED[8] AF24
RLV4P/RED[5] AF23
RLV4N/RED[4] AD22
RLV5P/RED[3] AE22
RLV5N/RED[2] AF22
TCON3/OE/GOE/GCLK2 AD19
TCON15/SCAN_BLK1 AE19
TCON18/CS7/GCLK5 AD21
TCON19/CS8/GCLK6 AE21
TCON11/CS5/HCON AF21
TCON10/CS4/OPT_N AD20
TCON9/CS3/OPT_P AE20
TCON16/WPWM AF20
TCON12/DPM AF19
TCON1/STV/GSP/VST AD18
TCON5/TP/SOE AE18
TCON14/SACN_BLK AF18
TCON21/CS10/VGH_ODD AB22
TCON20/CS9/VGH_EVEN AB23
TCON13/LEDON AC23
TCON17/CS6/GCLK4 AC22
NC_26 AB16
NC_19 AA14
NC_30 AC15
NC_15 Y16
NC_31 AC16
NC_29 AC14
NC_21 AA16
NC_20 AA15
NC_11 Y10
NC_17 AA11
NC_25 AB15
NC_24 AB14
LGE105 (S7-Tcon Non_Divx/RM)
IC101-*6
S7T_NON_DIVX & MS10
NC_43
AE1
NC_73
AF16
NC_59
AF1
NC_45
AE3
NC_40
AD14
NC_29
AD3
NC_72
AF15
NC_60
AF2
NC_57
AE15
NC_28
AD2
NC_42
AD16
NC_41
AD15
NC_58
AE16
NC_61
AF3
NC_71
AF14
NC_27
AD1
NC_39
AD13
NC_56
AE14
NC_55
AE13
NC_46
AE4
NC_31
AD5
NC_62
AF4
NC_30
AD4
NC_44
AE2
NC_66
AF8
NC_35
AD9
NC_51
AE9
NC_67
AF9
NC_53
AE11
NC_64
AF6
NC_48
AE6
NC_69
AF11
NC_32
AD6
NC_38
AD12
NC_47
AE5
NC_70
AF12
NC_63
AF5
NC_54
AE12
NC_52
AE10
NC_65
AF7
NC_37
AD11
NC_33
AD7
NC_36
AD10
NC_49
AE7
NC_68
AF10
NC_34
AD8
NC_50
AE8
NC_12
Y11
GND_105
Y19
RLV3P W26
RLV3N W25
RLV0P U26
RLV0N U25
RLV1P U24
RLV1N V26
RLV2P V25
RLV2N V24
RLVCKP W24
RLVCKN Y26
RLV4P Y25
RLV4N Y24
WPWM AC26
OPTP/FLK2 AC25
RLV5P AA26
RLV5N AA25
RLV6P AA24
RLV6N AB26
RLV7P AB25
RLV7N AB24
OPTN/FLK3 AC24
FLK AD26
GCLK6 AD25
GCLK5 AD24
LLV3P AD23
LLV3N AE23
LLV0P AE26
LLV0N AE25
LLV1P AF26
LLV1N AF25
LLV2P AE24
LLV2N AF24
LLVCKP AF23
LLVCKN AD22
LLV4P AE22
LLV4N AF22
GOE/GCLK1 AD19
GSC/GCLK3 AE19
LLV5P AD21
LLV5N AE21
LLV6P AF21
LLV6N AD20
LLV7P AE20
LLV7N AF20
GSPR AF19
GSP/VST AD18
SOE AE18
POL AF18
VDD_ODD AB22
VDD_EVEN AB23
GCLK4 AC23
GCLK2 AC22
NC_23 AB16
DPM AA14
HCON AC15
NC_15 Y16
NC_26 AC16
LEDON AC14
NC_20 AA16
NC_19 AA15
NC_11 Y10
NC_17 AA11
SCAN_BLK AB15
SCAN_BLK1 AB14
LGE107 (S7M Non Divx/RM)
IC101-*2
S7M_NON_DIVX& MS10
FRC_DDR3_A0/DDR2_NC
AE1
FRC_DDR3_A1/DDR2_A6
AF16
FRC_DDR3_A2/DDR2_A7
AF1
FRC_DDR3_A3/DDR2_A1
AE3
FRC_DDR3_A4/DDR2_CASZ
AD14
FRC_DDR3_A5/DDR2_A10
AD3
FRC_DDR3_A6/DDR2_A0
AF15
FRC_DDR3_A7/DDR2_A5
AF2
FRC_DDR3_A8/DDR2_A2
AE15
FRC_DDR3_A9/DDR2_A9
AD2
FRC_DDR3_A10/DDR2_A11
AD16
FRC_DDR3_A11/DDR2_A4
AD15
FRC_DDR3_A12/DDR2_A8
AE16
FRC_DDR3_BA0/DDR2_BA2
AF3
FRC_DDR3_BA1/DDR2_ODT
AF14
FRC_DDR3_BA2/DDR2_A12
AD1
FRC_DDR3_MCLK/DDR2_MCLK
AD13
FRC_DDR3_CKE/DDR2_RASZ
AE14
FRC_DDR3_MCLKZ/DDR2_MCLKZ
AE13
FRC_DDR3_ODT/DDR2_BA1
AE4
FRC_DDR3_RASZ/DDR2_WEZ
AD5
FRC_DDR3_CASZ/DDR2_CKE
AF4
FRC_DDR3_WEZ/DDR2_BA0
AD4
FRC_DDR3_RESETB/DDR2_A3
AE2
FRC_DDR3_DQSL/DDR2_DQS0
AF8
FRC_DDR3_DQSLB/DDR2_DQSB0
AD9
FRC_DDR3_DQSU/DDR2_DQS1
AE9
FRC_DDR3_DQSUB/DDR2_DQSB1
AF9
FRC_DDR3_DML/DDR2_DQ7
AE11
FRC_DDR3_DMU/DDR2_DQ11
AF6
FRC_DDR3_DQL0/DDR2_DQ6
AE6
FRC_DDR3_DQL1/DDR2_DQ0
AF11
FRC_DDR3_DQL2/DDR2_DQ1
AD6
FRC_DDR3_DQL3/DDR2_DQ2
AD12
FRC_DDR3_DQL4/DDR2_DQ4
AE5
FRC_DDR3_DQL5/DDR2_NC
AF12
FRC_DDR3_DQL6/DDR2_DQ3
AF5
FRC_DDR3_DQL7/DDR2_DQ5
AE12
FRC_DDR3_DQU0/DDR2_DQ8
AE10
FRC_DDR3_DQU1/DDR2_DQ14
AF7
FRC_DDR3_DQU2/DDR2_DQ13
AD11
FRC_DDR3_DQU3/DDR2_DQ12
AD7
FRC_DDR3_DQU4/DDR2_DQ15
AD10
FRC_DDR3_DQU5/DDR2_DQ9
AE7
FRC_DDR3_DQU6/DDR2_DQ10
AF10
FRC_DDR3_DQU7/DDR2_DQM1
AD8
FRC_DDR3_NC/DDR2_DQM0
AE8
FRC_REXT
Y11
FRC_TESTPIN
Y19
ACKP/RLV3P/RED[3] W26
ACKM/RLV3N/RED[2] W25
A0P/RLV0P/RED[9] U26
A0M/RLV0N/RED[8] U25
A1P/RLV1P/RED[7] U24
A1M/RLV1N/RED[6] V26
A2P/RLV2P/RED[5] V25
A2M/RLV2N/RED[4] V24
A3P/RLV4P/RED[1] W24
A3M/RLV4N/RED[0] Y26
A4P/RLV5P/GREEN[9] Y25
A4M/RLV5N/GREEN[8] Y24
BCKP/TCON13/GREEN[1] AC26
BCKM/TCON12/GREEN[0] AC25
B0P/RLV6P/GREEN[7] AA26
B0M/RLV6N/GREEN[6] AA25
B1P/RLV7P/GREEN[5] AA24
B1M/RLV7N/GREEN[4] AB26
B2P/RLV8P/GREEN[3] AB25
B2M/RLV8N/GREEN[2] AB24
B3P/TCON11/BLUE[9] AC24
B3M/TCON10/BLUE[8] AD26
B4P/TCON9/BLUE[7] AD25
B4M/TCON8/BLUE[6] AD24
CCKP/LLV3P AD23
CCKM/LLV3N AE23
C0P/LLV0P/BLUE[5] AE26
C0M/LLV0N/BLUE[4] AE25
C1P/LLV1P/BLUE[3] AF26
C1M/LLV1N/BLUE[2] AF25
C2P/LLV2P/BLUE[1] AE24
C2M/LLV2N/BLUE[0] AF24
C3P/LLV4P AF23
C3M/LLV4N AD22
C4P/LLV5P AE22
C4M/LLV5N AF22
DCKP/TCON5 AD19
DCKM/TCON4 AE19
D0P/LLV6P AD21
D0M/LLV6N AE21
D1P/LLV7P AF21
D1M/LLV7N AD20
D2P/LLV8P AE20
D2M/LLV8N AF20
D3P/TCON3 AF19
D3M/TCON2 AD18
D4P/TCON1 AE18
D4M/TCON0 AF18
GPIO0/TCON15/HSYNC/VDD_ODD AB22
GPIO1/TCON14/VSYNC/VDD_EVEN AB23
GPIO2/TCON7/LDE/GCLK4 AC23
GPIO3/TCON6/LCK/GCLK2 AC22
FRC_GPIO0/UART_RX AB16
FRC_GPIO1 AA14
FRC_GPIO3 AC15
FRC_GPIO8 Y16
FRC_GPIO9/UART_TX AC16
FRC_GPIO10 AC14
FRC_I2CM_DA AA16
FRC_I2CM_CK AA15
FRC_I2CS_DA Y10
FRC_I2CS_CK AA11
FRC_PWM0 AB15
FRC_PWM1 AB14
LGE107DB-LF-1 (S7M Divx_Non RM/MS10)
IC101-*1
S7M_DIVX & DD
FRC_DDR3_A0/DDR2_NC
AE1
FRC_DDR3_A1/DDR2_A6
AF16
FRC_DDR3_A2/DDR2_A7
AF1
FRC_DDR3_A3/DDR2_A1
AE3
FRC_DDR3_A4/DDR2_CASZ
AD14
FRC_DDR3_A5/DDR2_A10
AD3
FRC_DDR3_A6/DDR2_A0
AF15
FRC_DDR3_A7/DDR2_A5
AF2
FRC_DDR3_A8/DDR2_A2
AE15
FRC_DDR3_A9/DDR2_A9
AD2
FRC_DDR3_A10/DDR2_A11
AD16
FRC_DDR3_A11/DDR2_A4
AD15
FRC_DDR3_A12/DDR2_A8
AE16
FRC_DDR3_BA0/DDR2_BA2
AF3
FRC_DDR3_BA1/DDR2_ODT
AF14
FRC_DDR3_BA2/DDR2_A12
AD1
FRC_DDR3_MCLK/DDR2_MCLK
AD13
FRC_DDR3_CKE/DDR2_RASZ
AE14
FRC_DDR3_MCLKZ/DDR2_MCLKZ
AE13
FRC_DDR3_ODT/DDR2_BA1
AE4
FRC_DDR3_RASZ/DDR2_WEZ
AD5
FRC_DDR3_CASZ/DDR2_CKE
AF4
FRC_DDR3_WEZ/DDR2_BA0
AD4
FRC_DDR3_RESETB/DDR2_A3
AE2
FRC_DDR3_DQSL/DDR2_DQS0
AF8
FRC_DDR3_DQSLB/DDR2_DQSB0
AD9
FRC_DDR3_DQSU/DDR2_DQS1
AE9
FRC_DDR3_DQSUB/DDR2_DQSB1
AF9
FRC_DDR3_DML/DDR2_DQ7
AE11
FRC_DDR3_DMU/DDR2_DQ11
AF6
FRC_DDR3_DQL0/DDR2_DQ6
AE6
FRC_DDR3_DQL1/DDR2_DQ0
AF11
FRC_DDR3_DQL2/DDR2_DQ1
AD6
FRC_DDR3_DQL3/DDR2_DQ2
AD12
FRC_DDR3_DQL4/DDR2_DQ4
AE5
FRC_DDR3_DQL5/DDR2_NC
AF12
FRC_DDR3_DQL6/DDR2_DQ3
AF5
FRC_DDR3_DQL7/DDR2_DQ5
AE12
FRC_DDR3_DQU0/DDR2_DQ8
AE10
FRC_DDR3_DQU1/DDR2_DQ14
AF7
FRC_DDR3_DQU2/DDR2_DQ13
AD11
FRC_DDR3_DQU3/DDR2_DQ12
AD7
FRC_DDR3_DQU4/DDR2_DQ15
AD10
FRC_DDR3_DQU5/DDR2_DQ9
AE7
FRC_DDR3_DQU6/DDR2_DQ10
AF10
FRC_DDR3_DQU7/DDR2_DQM1
AD8
FRC_DDR3_NC/DDR2_DQM0
AE8
FRC_REXT
Y11
FRC_TESTPIN
Y19
ACKP/RLV3P/RED[3] W26
ACKM/RLV3N/RED[2] W25
A0P/RLV0P/RED[9] U26
A0M/RLV0N/RED[8] U25
A1P/RLV1P/RED[7] U24
A1M/RLV1N/RED[6] V26
A2P/RLV2P/RED[5] V25
A2M/RLV2N/RED[4] V24
A3P/RLV4P/RED[1] W24
A3M/RLV4N/RED[0] Y26
A4P/RLV5P/GREEN[9] Y25
A4M/RLV5N/GREEN[8] Y24
BCKP/TCON13/GREEN[1] AC26
BCKM/TCON12/GREEN[0] AC25
B0P/RLV6P/GREEN[7] AA26
B0M/RLV6N/GREEN[6] AA25
B1P/RLV7P/GREEN[5] AA24
B1M/RLV7N/GREEN[4] AB26
B2P/RLV8P/GREEN[3] AB25
B2M/RLV8N/GREEN[2] AB24
B3P/TCON11/BLUE[9] AC24
B3M/TCON10/BLUE[8] AD26
B4P/TCON9/BLUE[7] AD25
B4M/TCON8/BLUE[6] AD24
CCKP/LLV3P AD23
CCKM/LLV3N AE23
C0P/LLV0P/BLUE[5] AE26
C0M/LLV0N/BLUE[4] AE25
C1P/LLV1P/BLUE[3] AF26
C1M/LLV1N/BLUE[2] AF25
C2P/LLV2P/BLUE[1] AE24
C2M/LLV2N/BLUE[0] AF24
C3P/LLV4P AF23
C3M/LLV4N AD22
C4P/LLV5P AE22
C4M/LLV5N AF22
DCKP/TCON5 AD19
DCKM/TCON4 AE19
D0P/LLV6P AD21
D0M/LLV6N AE21
D1P/LLV7P AF21
D1M/LLV7N AD20
D2P/LLV8P AE20
D2M/LLV8N AF20
D3P/TCON3 AF19
D3M/TCON2 AD18
D4P/TCON1 AE18
D4M/TCON0 AF18
GPIO0/TCON15/HSYNC/VDD_ODD AB22
GPIO1/TCON14/VSYNC/VDD_EVEN AB23
GPIO2/TCON7/LDE/GCLK4 AC23
GPIO3/TCON6/LCK/GCLK2 AC22
FRC_GPIO0/UART_RX AB16
FRC_GPIO1 AA14
FRC_GPIO3 AC15
FRC_GPIO8 Y16
FRC_GPIO9/UART_TX AC16
FRC_GPIO10 AC14
FRC_I2CM_DA AA16
FRC_I2CM_CK AA15
FRC_I2CS_DA Y10
FRC_I2CS_CK AA11
FRC_PWM0 AB15
FRC_PWM1 AB14
LGE107B-LF-1 (S7M Non Divx/RM/MS10)
IC101-*3
S7M_NON_DIVX& DD
FRC_DDR3_A0/DDR2_NC
AE1
FRC_DDR3_A1/DDR2_A6
AF16
FRC_DDR3_A2/DDR2_A7
AF1
FRC_DDR3_A3/DDR2_A1
AE3
FRC_DDR3_A4/DDR2_CASZ
AD14
FRC_DDR3_A5/DDR2_A10
AD3
FRC_DDR3_A6/DDR2_A0
AF15
FRC_DDR3_A7/DDR2_A5
AF2
FRC_DDR3_A8/DDR2_A2
AE15
FRC_DDR3_A9/DDR2_A9
AD2
FRC_DDR3_A10/DDR2_A11
AD16
FRC_DDR3_A11/DDR2_A4
AD15
FRC_DDR3_A12/DDR2_A8
AE16
FRC_DDR3_BA0/DDR2_BA2
AF3
FRC_DDR3_BA1/DDR2_ODT
AF14
FRC_DDR3_BA2/DDR2_A12
AD1
FRC_DDR3_MCLK/DDR2_MCLK
AD13
FRC_DDR3_CKE/DDR2_RASZ
AE14
FRC_DDR3_MCLKZ/DDR2_MCLKZ
AE13
FRC_DDR3_ODT/DDR2_BA1
AE4
FRC_DDR3_RASZ/DDR2_WEZ
AD5
FRC_DDR3_CASZ/DDR2_CKE
AF4
FRC_DDR3_WEZ/DDR2_BA0
AD4
FRC_DDR3_RESETB/DDR2_A3
AE2
FRC_DDR3_DQSL/DDR2_DQS0
AF8
FRC_DDR3_DQSLB/DDR2_DQSB0
AD9
FRC_DDR3_DQSU/DDR2_DQS1
AE9
FRC_DDR3_DQSUB/DDR2_DQSB1
AF9
FRC_DDR3_DML/DDR2_DQ7
AE11
FRC_DDR3_DMU/DDR2_DQ11
AF6
FRC_DDR3_DQL0/DDR2_DQ6
AE6
FRC_DDR3_DQL1/DDR2_DQ0
AF11
FRC_DDR3_DQL2/DDR2_DQ1
AD6
FRC_DDR3_DQL3/DDR2_DQ2
AD12
FRC_DDR3_DQL4/DDR2_DQ4
AE5
FRC_DDR3_DQL5/DDR2_NC
AF12
FRC_DDR3_DQL6/DDR2_DQ3
AF5
FRC_DDR3_DQL7/DDR2_DQ5
AE12
FRC_DDR3_DQU0/DDR2_DQ8
AE10
FRC_DDR3_DQU1/DDR2_DQ14
AF7
FRC_DDR3_DQU2/DDR2_DQ13
AD11
FRC_DDR3_DQU3/DDR2_DQ12
AD7
FRC_DDR3_DQU4/DDR2_DQ15
AD10
FRC_DDR3_DQU5/DDR2_DQ9
AE7
FRC_DDR3_DQU6/DDR2_DQ10
AF10
FRC_DDR3_DQU7/DDR2_DQM1
AD8
FRC_DDR3_NC/DDR2_DQM0
AE8
FRC_REXT
Y11
FRC_TESTPIN
Y19
ACKP/RLV3P/RED[3] W26
ACKM/RLV3N/RED[2] W25
A0P/RLV0P/RED[9] U26
A0M/RLV0N/RED[8] U25
A1P/RLV1P/RED[7] U24
A1M/RLV1N/RED[6] V26
A2P/RLV2P/RED[5] V25
A2M/RLV2N/RED[4] V24
A3P/RLV4P/RED[1] W24
A3M/RLV4N/RED[0] Y26
A4P/RLV5P/GREEN[9] Y25
A4M/RLV5N/GREEN[8] Y24
BCKP/TCON13/GREEN[1] AC26
BCKM/TCON12/GREEN[0] AC25
B0P/RLV6P/GREEN[7] AA26
B0M/RLV6N/GREEN[6] AA25
B1P/RLV7P/GREEN[5] AA24
B1M/RLV7N/GREEN[4] AB26
B2P/RLV8P/GREEN[3] AB25
B2M/RLV8N/GREEN[2] AB24
B3P/TCON11/BLUE[9] AC24
B3M/TCON10/BLUE[8] AD26
B4P/TCON9/BLUE[7] AD25
B4M/TCON8/BLUE[6] AD24
CCKP/LLV3P AD23
CCKM/LLV3N AE23
C0P/LLV0P/BLUE[5] AE26
C0M/LLV0N/BLUE[4] AE25
C1P/LLV1P/BLUE[3] AF26
C1M/LLV1N/BLUE[2] AF25
C2P/LLV2P/BLUE[1] AE24
C2M/LLV2N/BLUE[0] AF24
C3P/LLV4P AF23
C3M/LLV4N AD22
C4P/LLV5P AE22
C4M/LLV5N AF22
DCKP/TCON5 AD19
DCKM/TCON4 AE19
D0P/LLV6P AD21
D0M/LLV6N AE21
D1P/LLV7P AF21
D1M/LLV7N AD20
D2P/LLV8P AE20
D2M/LLV8N AF20
D3P/TCON3 AF19
D3M/TCON2 AD18
D4P/TCON1 AE18
D4M/TCON0 AF18
GPIO0/TCON15/HSYNC/VDD_ODD AB22
GPIO1/TCON14/VSYNC/VDD_EVEN AB23
GPIO2/TCON7/LDE/GCLK4 AC23
GPIO3/TCON6/LCK/GCLK2 AC22
FRC_GPIO0/UART_RX AB16
FRC_GPIO1 AA14
FRC_GPIO3 AC15
FRC_GPIO8 Y16
FRC_GPIO9/UART_TX AC16
FRC_GPIO10 AC14
FRC_I2CM_DA AA16
FRC_I2CM_CK AA15
FRC_I2CS_DA Y10
FRC_I2CS_CK AA11
FRC_PWM0 AB15
FRC_PWM1 AB14
LGE105DB-LF-1 (S7-Tcon Divx_ Non_RM/MS10)
IC101-*5
S7T_DIVX & DD
NC_43
AE1
NC_73
AF16
NC_59
AF1
NC_45
AE3
NC_40
AD14
NC_29
AD3
NC_72
AF15
NC_60
AF2
NC_57
AE15
NC_28
AD2
NC_42
AD16
NC_41
AD15
NC_58
AE16
NC_61
AF3
NC_71
AF14
NC_27
AD1
NC_39
AD13
NC_56
AE14
NC_55
AE13
NC_46
AE4
NC_31
AD5
NC_62
AF4
NC_30
AD4
NC_44
AE2
NC_66
AF8
NC_35
AD9
NC_51
AE9
NC_67
AF9
NC_53
AE11
NC_64
AF6
NC_48
AE6
NC_69
AF11
NC_32
AD6
NC_38
AD12
NC_47
AE5
NC_70
AF12
NC_63
AF5
NC_54
AE12
NC_52
AE10
NC_65
AF7
NC_37
AD11
NC_33
AD7
NC_36
AD10
NC_49
AE7
NC_68
AF10
NC_34
AD8
NC_50
AE8
NC_12
Y11
GND_105
Y19
RLV3P W26
RLV3N W25
RLV0P U26
RLV0N U25
RLV1P U24
RLV1N V26
RLV2P V25
RLV2N V24
RLVCKP W24
RLVCKN Y26
RLV4P Y25
RLV4N Y24
WPWM AC26
OPTP/FLK2 AC25
RLV5P AA26
RLV5N AA25
RLV6P AA24
RLV6N AB26
RLV7P AB25
RLV7N AB24
OPTN/FLK3 AC24
FLK AD26
GCLK6 AD25
GCLK5 AD24
LLV3P AD23
LLV3N AE23
LLV0P AE26
LLV0N AE25
LLV1P AF26
LLV1N AF25
LLV2P AE24
LLV2N AF24
LLVCKP AF23
LLVCKN AD22
LLV4P AE22
LLV4N AF22
GOE/GCLK1 AD19
GSC/GCLK3 AE19
LLV5P AD21
LLV5N AE21
LLV6P AF21
LLV6N AD20
LLV7P AE20
LLV7N AF20
GSPR AF19
GSP/VST AD18
SOE AE18
POL AF18
VDD_ODD AB22
VDD_EVEN AB23
GCLK4 AC23
GCLK2 AC22
NC_23 AB16
DPM AA14
HCON AC15
NC_15 Y16
NC_26 AC16
LEDON AC14
NC_20 AA16
NC_19 AA15
NC_11 Y10
NC_17 AA11
SCAN_BLK AB15
SCAN_BLK1 AB14
LGE105B-LF-1 (S7-Tcon Non_Divx/RM/MS10)
IC101-*7
S7T_NON_DIVX& DD
NC_43
AE1
NC_73
AF16
NC_59
AF1
NC_45
AE3
NC_40
AD14
NC_29
AD3
NC_72
AF15
NC_60
AF2
NC_57
AE15
NC_28
AD2
NC_42
AD16
NC_41
AD15
NC_58
AE16
NC_61
AF3
NC_71
AF14
NC_27
AD1
NC_39
AD13
NC_56
AE14
NC_55
AE13
NC_46
AE4
NC_31
AD5
NC_62
AF4
NC_30
AD4
NC_44
AE2
NC_66
AF8
NC_35
AD9
NC_51
AE9
NC_67
AF9
NC_53
AE11
NC_64
AF6
NC_48
AE6
NC_69
AF11
NC_32
AD6
NC_38
AD12
NC_47
AE5
NC_70
AF12
NC_63
AF5
NC_54
AE12
NC_52
AE10
NC_65
AF7
NC_37
AD11
NC_33
AD7
NC_36
AD10
NC_49
AE7
NC_68
AF10
NC_34
AD8
NC_50
AE8
NC_12
Y11
GND_105
Y19
RLV3P W26
RLV3N W25
RLV0P U26
RLV0N U25
RLV1P U24
RLV1N V26
RLV2P V25
RLV2N V24
RLVCKP W24
RLVCKN Y26
RLV4P Y25
RLV4N Y24
WPWM AC26
OPTP/FLK2 AC25
RLV5P AA26
RLV5N AA25
RLV6P AA24
RLV6N AB26
RLV7P AB25
RLV7N AB24
OPTN/FLK3 AC24
FLK AD26
GCLK6 AD25
GCLK5 AD24
LLV3P AD23
LLV3N AE23
LLV0P AE26
LLV0N AE25
LLV1P AF26
LLV1N AF25
LLV2P AE24
LLV2N AF24
LLVCKP AF23
LLVCKN AD22
LLV4P AE22
LLV4N AF22
GOE/GCLK1 AD19
GSC/GCLK3 AE19
LLV5P AD21
LLV5N AE21
LLV6P AF21
LLV6N AD20
LLV7P AE20
LLV7N AF20
GSPR AF19
GSP/VST AD18
SOE AE18
POL AF18
VDD_ODD AB22
VDD_EVEN AB23
GCLK4 AC23
GCLK2 AC22
NC_23 AB16
DPM AA14
HCON AC15
NC_15 Y16
NC_26 AC16
LEDON AC14
NC_20 AA16
NC_19 AA15
NC_11 Y10
NC_17 AA11
SCAN_BLK AB15
SCAN_BLK1 AB14
LGE101DB-LF-1 (S7 Non_Tcon/RM/MS10)
IC101-*9
S7_DIVX & DD
NC_48
AE1
NC_78
AF16
NC_64
AF1
NC_50
AE3
NC_45
AD14
NC_34
AD3
NC_77
AF15
NC_65
AF2
NC_62
AE15
NC_33
AD2
NC_47
AD16
NC_46
AD15
NC_63
AE16
NC_66
AF3
NC_76
AF14
NC_32
AD1
NC_44
AD13
NC_61
AE14
NC_60
AE13
NC_51
AE4
NC_36
AD5
NC_67
AF4
NC_35
AD4
NC_49
AE2
NC_71
AF8
NC_40
AD9
NC_56
AE9
NC_72
AF9
NC_58
AE11
NC_69
AF6
NC_53
AE6
NC_74
AF11
NC_37
AD6
NC_43
AD12
NC_52
AE5
NC_75
AF12
NC_68
AF5
NC_59
AE12
NC_57
AE10
NC_70
AF7
NC_42
AD11
NC_38
AD7
NC_41
AD10
NC_54
AE7
NC_73
AF10
NC_39
AD8
NC_55
AE8
NC_12
Y11
GND_105
Y19
LVACLKP/LLV6P/BLUE[3] W26
LVACLKN/LLV6N/BLUE[2] W25
LVA0P/LLV3P/BLUE[9] U26
LVA0N/LLV3N/BLUE[8] U25
LVA1P/LLV4P/BLUE[7] U24
LVA1N/LLV4N/BLUE[6] V26
LVA2P/LLV5P/BLUE[5] V25
LVA2N/LLV5N/BLUE[4] V24
LVA3P/LLV7P/BLUE[1] W24
LVA3N/LLV7N/BLUE[0] Y26
LVA4P/LLV8P Y25
LVA4N/LLV8N Y24
LVBCLKP/LLV0P/GREEN[5] AC26
LVBCLKN/LLV0N/GREEN[4] AC25
LVB0P/RLV6P/RED[1] AA26
LVB0N/RLV6N/RED[0] AA25
LVB1P/RLV7P/GREEN[9] AA24
LVB1N/RLV7N/GREEN[8] AB26
LVB2P/RLV8P/GREEN[7] AB25
LVB2N/RLV8N/GREEN[6] AB24
LVB3P/LLV1P/GREEN[3] AC24
LVB3N/LLV1N/GREEN[2] AD26
LVB4P/LLV0P/GREEN[1] AD25
LVB4N/LLV0N/GREEN[0] AD24
RLV3P/RED[7] AD23
RLV3N/RED[6] AE23
RLV0P/LVSYNC AE26
RLV0N/LHSYNC AE25
RLV1N/LCK AF26
RLV2P/RED[9] AF25
RLV1P/LDE AE24
RLV2N/RED[8] AF24
RLV4P/RED[5] AF23
RLV4N/RED[4] AD22
RLV5P/RED[3] AE22
RLV5N/RED[2] AF22
TCON3/OE/GOE/GCLK2 AD19
TCON15/SCAN_BLK1 AE19
TCON18/CS7/GCLK5 AD21
TCON19/CS8/GCLK6 AE21
TCON11/CS5/HCON AF21
TCON10/CS4/OPT_N AD20
TCON9/CS3/OPT_P AE20
TCON16/WPWM AF20
TCON12/DPM AF19
TCON1/STV/GSP/VST AD18
TCON5/TP/SOE AE18
TCON14/SACN_BLK AF18
TCON21/CS10/VGH_ODD AB22
TCON20/CS9/VGH_EVEN AB23
TCON13/LEDON AC23
TCON17/CS6/GCLK4 AC22
NC_26 AB16
NC_19 AA14
NC_30 AC15
NC_15 Y16
NC_31 AC16
NC_29 AC14
NC_21 AA16
NC_20 AA15
NC_11 Y10
NC_17 AA11
NC_25 AB15
NC_24 AB14
LGE101B-LF-1(S7 Non_Tcon/Divx/RM/MS10)
IC101-*11
S7_NON_DIVX& DD
NC_48
AE1
NC_78
AF16
NC_64
AF1
NC_50
AE3
NC_45
AD14
NC_34
AD3
NC_77
AF15
NC_65
AF2
NC_62
AE15
NC_33
AD2
NC_47
AD16
NC_46
AD15
NC_63
AE16
NC_66
AF3
NC_76
AF14
NC_32
AD1
NC_44
AD13
NC_61
AE14
NC_60
AE13
NC_51
AE4
NC_36
AD5
NC_67
AF4
NC_35
AD4
NC_49
AE2
NC_71
AF8
NC_40
AD9
NC_56
AE9
NC_72
AF9
NC_58
AE11
NC_69
AF6
NC_53
AE6
NC_74
AF11
NC_37
AD6
NC_43
AD12
NC_52
AE5
NC_75
AF12
NC_68
AF5
NC_59
AE12
NC_57
AE10
NC_70
AF7
NC_42
AD11
NC_38
AD7
NC_41
AD10
NC_54
AE7
NC_73
AF10
NC_39
AD8
NC_55
AE8
NC_12
Y11
GND_105
Y19
LVACLKP/LLV6P/BLUE[3] W26
LVACLKN/LLV6N/BLUE[2] W25
LVA0P/LLV3P/BLUE[9] U26
LVA0N/LLV3N/BLUE[8] U25
LVA1P/LLV4P/BLUE[7] U24
LVA1N/LLV4N/BLUE[6] V26
LVA2P/LLV5P/BLUE[5] V25
LVA2N/LLV5N/BLUE[4] V24
LVA3P/LLV7P/BLUE[1] W24
LVA3N/LLV7N/BLUE[0] Y26
LVA4P/LLV8P Y25
LVA4N/LLV8N Y24
LVBCLKP/LLV0P/GREEN[5] AC26
LVBCLKN/LLV0N/GREEN[4] AC25
LVB0P/RLV6P/RED[1] AA26
LVB0N/RLV6N/RED[0] AA25
LVB1P/RLV7P/GREEN[9] AA24
LVB1N/RLV7N/GREEN[8] AB26
LVB2P/RLV8P/GREEN[7] AB25
LVB2N/RLV8N/GREEN[6] AB24
LVB3P/LLV1P/GREEN[3] AC24
LVB3N/LLV1N/GREEN[2] AD26
LVB4P/LLV0P/GREEN[1] AD25
LVB4N/LLV0N/GREEN[0] AD24
RLV3P/RED[7] AD23
RLV3N/RED[6] AE23
RLV0P/LVSYNC AE26
RLV0N/LHSYNC AE25
RLV1N/LCK AF26
RLV2P/RED[9] AF25
RLV1P/LDE AE24
RLV2N/RED[8] AF24
RLV4P/RED[5] AF23
RLV4N/RED[4] AD22
RLV5P/RED[3] AE22
RLV5N/RED[2] AF22
TCON3/OE/GOE/GCLK2 AD19
TCON15/SCAN_BLK1 AE19
TCON18/CS7/GCLK5 AD21
TCON19/CS8/GCLK6 AE21
TCON11/CS5/HCON AF21
TCON10/CS4/OPT_N AD20
TCON9/CS3/OPT_P AE20
TCON16/WPWM AF20
TCON12/DPM AF19
TCON1/STV/GSP/VST AD18
TCON5/TP/SOE AE18
TCON14/SACN_BLK AF18
TCON21/CS10/VGH_ODD AB22
TCON20/CS9/VGH_EVEN AB23
TCON13/LEDON AC23
TCON17/CS6/GCLK4 AC22
NC_26 AB16
NC_19 AA14
NC_30 AC15
NC_15 Y16
NC_31 AC16
NC_29 AC14
NC_21 AA16
NC_20 AA15
NC_11 Y10
NC_17 AA11
NC_25 AB15
NC_24 AB14
LGE107B-LF (SPIL)(S7M Non Divx/RM)
IC101-*12
S7M_NON_DIVX & MS10_SPIL
FRC_DDR3_A0/DDR2_NC
AE1
FRC_DDR3_A1/DDR2_A6
AF16
FRC_DDR3_A2/DDR2_A7
AF1
FRC_DDR3_A3/DDR2_A1
AE3
FRC_DDR3_A4/DDR2_CASZ
AD14
FRC_DDR3_A5/DDR2_A10
AD3
FRC_DDR3_A6/DDR2_A0
AF15
FRC_DDR3_A7/DDR2_A5
AF2
FRC_DDR3_A8/DDR2_A2
AE15
FRC_DDR3_A9/DDR2_A9
AD2
FRC_DDR3_A10/DDR2_A11
AD16
FRC_DDR3_A11/DDR2_A4
AD15
FRC_DDR3_A12/DDR2_A8
AE16
FRC_DDR3_BA0/DDR2_BA2
AF3
FRC_DDR3_BA1/DDR2_ODT
AF14
FRC_DDR3_BA2/DDR2_A12
AD1
FRC_DDR3_MCLK/DDR2_MCLK
AD13
FRC_DDR3_CKE/DDR2_RASZ
AE14
FRC_DDR3_MCLKZ/DDR2_MCLKZ
AE13
FRC_DDR3_ODT/DDR2_BA1
AE4
FRC_DDR3_RASZ/DDR2_WEZ
AD5
FRC_DDR3_CASZ/DDR2_CKE
AF4
FRC_DDR3_WEZ/DDR2_BA0
AD4
FRC_DDR3_RESETB/DDR2_A3
AE2
FRC_DDR3_DQSL/DDR2_DQS0
AF8
FRC_DDR3_DQSLB/DDR2_DQSB0
AD9
FRC_DDR3_DQSU/DDR2_DQS1
AE9
FRC_DDR3_DQSUB/DDR2_DQSB1
AF9
FRC_DDR3_DML/DDR2_DQ7
AE11
FRC_DDR3_DMU/DDR2_DQ11
AF6
FRC_DDR3_DQL0/DDR2_DQ6
AE6
FRC_DDR3_DQL1/DDR2_DQ0
AF11
FRC_DDR3_DQL2/DDR2_DQ1
AD6
FRC_DDR3_DQL3/DDR2_DQ2
AD12
FRC_DDR3_DQL4/DDR2_DQ4
AE5
FRC_DDR3_DQL5/DDR2_NC
AF12
FRC_DDR3_DQL6/DDR2_DQ3
AF5
FRC_DDR3_DQL7/DDR2_DQ5
AE12
FRC_DDR3_DQU0/DDR2_DQ8
AE10
FRC_DDR3_DQU1/DDR2_DQ14
AF7
FRC_DDR3_DQU2/DDR2_DQ13
AD11
FRC_DDR3_DQU3/DDR2_DQ12
AD7
FRC_DDR3_DQU4/DDR2_DQ15
AD10
FRC_DDR3_DQU5/DDR2_DQ9
AE7
FRC_DDR3_DQU6/DDR2_DQ10
AF10
FRC_DDR3_DQU7/DDR2_DQM1
AD8
FRC_DDR3_NC/DDR2_DQM0
AE8
FRC_REXT
Y11
FRC_TESTPIN
Y19
ACKP/RLV3P/RED[3] W26
ACKM/RLV3N/RED[2] W25
A0P/RLV0P/RED[9] U26
A0M/RLV0N/RED[8] U25
A1P/RLV1P/RED[7] U24
A1M/RLV1N/RED[6] V26
A2P/RLV2P/RED[5] V25
A2M/RLV2N/RED[4] V24
A3P/RLV4P/RED[1] W24
A3M/RLV4N/RED[0] Y26
A4P/RLV5P/GREEN[9] Y25
A4M/RLV5N/GREEN[8] Y24
BCKP/TCON13/GREEN[1] AC26
BCKM/TCON12/GREEN[0] AC25
B0P/RLV6P/GREEN[7] AA26
B0M/RLV6N/GREEN[6] AA25
B1P/RLV7P/GREEN[5] AA24
B1M/RLV7N/GREEN[4] AB26
B2P/RLV8P/GREEN[3] AB25
B2M/RLV8N/GREEN[2] AB24
B3P/TCON11/BLUE[9] AC24
B3M/TCON10/BLUE[8] AD26
B4P/TCON9/BLUE[7] AD25
B4M/TCON8/BLUE[6] AD24
CCKP/LLV3P AD23
CCKM/LLV3N AE23
C0P/LLV0P/BLUE[5] AE26
C0M/LLV0N/BLUE[4] AE25
C1P/LLV1P/BLUE[3] AF26
C1M/LLV1N/BLUE[2] AF25
C2P/LLV2P/BLUE[1] AE24
C2M/LLV2N/BLUE[0] AF24
C3P/LLV4P AF23
C3M/LLV4N AD22
C4P/LLV5P AE22
C4M/LLV5N AF22
DCKP/TCON5 AD19
DCKM/TCON4 AE19
D0P/LLV6P AD21
D0M/LLV6N AE21
D1P/LLV7P AF21
D1M/LLV7N AD20
D2P/LLV8P AE20
D2M/LLV8N AF20
D3P/TCON3 AF19
D3M/TCON2 AD18
D4P/TCON1 AE18
D4M/TCON0 AF18
GPIO0/TCON15/HSYNC/VDD_ODD AB22
GPIO1/TCON14/VSYNC/VDD_EVEN AB23
GPIO2/TCON7/LDE/GCLK4 AC23
GPIO3/TCON6/LCK/GCLK2 AC22
FRC_GPIO0/UART_RX AB16
FRC_GPIO1 AA14
FRC_GPIO3 AC15
FRC_GPIO8 Y16
FRC_GPIO9/UART_TX AC16
FRC_GPIO10 AC14
FRC_I2CM_DA AA16
FRC_I2CM_CK AA15
FRC_I2CS_DA Y10
FRC_I2CS_CK AA11
FRC_PWM0 AB15
FRC_PWM1 AB14
LGE107BS-LF-1(SPIL)(S7M Non Divx/RM/MS10)
IC101-*13
S7M_NON_DIVX & DD_SPIL
FRC_DDR3_A0/DDR2_NC
AE1
FRC_DDR3_A1/DDR2_A6
AF16
FRC_DDR3_A2/DDR2_A7
AF1
FRC_DDR3_A3/DDR2_A1
AE3
FRC_DDR3_A4/DDR2_CASZ
AD14
FRC_DDR3_A5/DDR2_A10
AD3
FRC_DDR3_A6/DDR2_A0
AF15
FRC_DDR3_A7/DDR2_A5
AF2
FRC_DDR3_A8/DDR2_A2
AE15
FRC_DDR3_A9/DDR2_A9
AD2
FRC_DDR3_A10/DDR2_A11
AD16
FRC_DDR3_A11/DDR2_A4
AD15
FRC_DDR3_A12/DDR2_A8
AE16
FRC_DDR3_BA0/DDR2_BA2
AF3
FRC_DDR3_BA1/DDR2_ODT
AF14
FRC_DDR3_BA2/DDR2_A12
AD1
FRC_DDR3_MCLK/DDR2_MCLK
AD13
FRC_DDR3_CKE/DDR2_RASZ
AE14
FRC_DDR3_MCLKZ/DDR2_MCLKZ
AE13
FRC_DDR3_ODT/DDR2_BA1
AE4
FRC_DDR3_RASZ/DDR2_WEZ
AD5
FRC_DDR3_CASZ/DDR2_CKE
AF4
FRC_DDR3_WEZ/DDR2_BA0
AD4
FRC_DDR3_RESETB/DDR2_A3
AE2
FRC_DDR3_DQSL/DDR2_DQS0
AF8
FRC_DDR3_DQSLB/DDR2_DQSB0
AD9
FRC_DDR3_DQSU/DDR2_DQS1
AE9
FRC_DDR3_DQSUB/DDR2_DQSB1
AF9
FRC_DDR3_DML/DDR2_DQ7
AE11
FRC_DDR3_DMU/DDR2_DQ11
AF6
FRC_DDR3_DQL0/DDR2_DQ6
AE6
FRC_DDR3_DQL1/DDR2_DQ0
AF11
FRC_DDR3_DQL2/DDR2_DQ1
AD6
FRC_DDR3_DQL3/DDR2_DQ2
AD12
FRC_DDR3_DQL4/DDR2_DQ4
AE5
FRC_DDR3_DQL5/DDR2_NC
AF12
FRC_DDR3_DQL6/DDR2_DQ3
AF5
FRC_DDR3_DQL7/DDR2_DQ5
AE12
FRC_DDR3_DQU0/DDR2_DQ8
AE10
FRC_DDR3_DQU1/DDR2_DQ14
AF7
FRC_DDR3_DQU2/DDR2_DQ13
AD11
FRC_DDR3_DQU3/DDR2_DQ12
AD7
FRC_DDR3_DQU4/DDR2_DQ15
AD10
FRC_DDR3_DQU5/DDR2_DQ9
AE7
FRC_DDR3_DQU6/DDR2_DQ10
AF10
FRC_DDR3_DQU7/DDR2_DQM1
AD8
FRC_DDR3_NC/DDR2_DQM0
AE8
FRC_REXT
Y11
FRC_TESTPIN
Y19
ACKP/RLV3P/RED[3] W26
ACKM/RLV3N/RED[2] W25
A0P/RLV0P/RED[9] U26
A0M/RLV0N/RED[8] U25
A1P/RLV1P/RED[7] U24
A1M/RLV1N/RED[6] V26
A2P/RLV2P/RED[5] V25
A2M/RLV2N/RED[4] V24
A3P/RLV4P/RED[1] W24
A3M/RLV4N/RED[0] Y26
A4P/RLV5P/GREEN[9] Y25
A4M/RLV5N/GREEN[8] Y24
BCKP/TCON13/GREEN[1] AC26
BCKM/TCON12/GREEN[0] AC25
B0P/RLV6P/GREEN[7] AA26
B0M/RLV6N/GREEN[6] AA25
B1P/RLV7P/GREEN[5] AA24
B1M/RLV7N/GREEN[4] AB26
B2P/RLV8P/GREEN[3] AB25
B2M/RLV8N/GREEN[2] AB24
B3P/TCON11/BLUE[9] AC24
B3M/TCON10/BLUE[8] AD26
B4P/TCON9/BLUE[7] AD25
B4M/TCON8/BLUE[6] AD24
CCKP/LLV3P AD23
CCKM/LLV3N AE23
C0P/LLV0P/BLUE[5] AE26
C0M/LLV0N/BLUE[4] AE25
C1P/LLV1P/BLUE[3] AF26
C1M/LLV1N/BLUE[2] AF25
C2P/LLV2P/BLUE[1] AE24
C2M/LLV2N/BLUE[0] AF24
C3P/LLV4P AF23
C3M/LLV4N AD22
C4P/LLV5P AE22
C4M/LLV5N AF22
DCKP/TCON5 AD19
DCKM/TCON4 AE19
D0P/LLV6P AD21
D0M/LLV6N AE21
D1P/LLV7P AF21
D1M/LLV7N AD20
D2P/LLV8P AE20
D2M/LLV8N AF20
D3P/TCON3 AF19
D3M/TCON2 AD18
D4P/TCON1 AE18
D4M/TCON0 AF18
GPIO0/TCON15/HSYNC/VDD_ODD AB22
GPIO1/TCON14/VSYNC/VDD_EVEN AB23
GPIO2/TCON7/LDE/GCLK4 AC23
GPIO3/TCON6/LCK/GCLK2 AC22
FRC_GPIO0/UART_RX AB16
FRC_GPIO1 AA14
FRC_GPIO3 AC15
FRC_GPIO8 Y16
FRC_GPIO9/UART_TX AC16
FRC_GPIO10 AC14
FRC_I2CM_DA AA16
FRC_I2CM_CK AA15
FRC_I2CS_DA Y10
FRC_I2CS_CK AA11
FRC_PWM0 AB15
FRC_PWM1 AB14
LGE107DBS-LF(S7M Divx_Non RM)
IC101-*14
S7M_DIVX & MS10_SPIL
FRC_DDR3_A0/DDR2_NC
AE1
FRC_DDR3_A1/DDR2_A6
AF16
FRC_DDR3_A2/DDR2_A7
AF1
FRC_DDR3_A3/DDR2_A1
AE3
FRC_DDR3_A4/DDR2_CASZ
AD14
FRC_DDR3_A5/DDR2_A10
AD3
FRC_DDR3_A6/DDR2_A0
AF15
FRC_DDR3_A7/DDR2_A5
AF2
FRC_DDR3_A8/DDR2_A2
AE15
FRC_DDR3_A9/DDR2_A9
AD2
FRC_DDR3_A10/DDR2_A11
AD16
FRC_DDR3_A11/DDR2_A4
AD15
FRC_DDR3_A12/DDR2_A8
AE16
FRC_DDR3_BA0/DDR2_BA2
AF3
FRC_DDR3_BA1/DDR2_ODT
AF14
FRC_DDR3_BA2/DDR2_A12
AD1
FRC_DDR3_MCLK/DDR2_MCLK
AD13
FRC_DDR3_CKE/DDR2_RASZ
AE14
FRC_DDR3_MCLKZ/DDR2_MCLKZ
AE13
FRC_DDR3_ODT/DDR2_BA1
AE4
FRC_DDR3_RASZ/DDR2_WEZ
AD5
FRC_DDR3_CASZ/DDR2_CKE
AF4
FRC_DDR3_WEZ/DDR2_BA0
AD4
FRC_DDR3_RESETB/DDR2_A3
AE2
FRC_DDR3_DQSL/DDR2_DQS0
AF8
FRC_DDR3_DQSLB/DDR2_DQSB0
AD9
FRC_DDR3_DQSU/DDR2_DQS1
AE9
FRC_DDR3_DQSUB/DDR2_DQSB1
AF9
FRC_DDR3_DML/DDR2_DQ7
AE11
FRC_DDR3_DMU/DDR2_DQ11
AF6
FRC_DDR3_DQL0/DDR2_DQ6
AE6
FRC_DDR3_DQL1/DDR2_DQ0
AF11
FRC_DDR3_DQL2/DDR2_DQ1
AD6
FRC_DDR3_DQL3/DDR2_DQ2
AD12
FRC_DDR3_DQL4/DDR2_DQ4
AE5
FRC_DDR3_DQL5/DDR2_NC
AF12
FRC_DDR3_DQL6/DDR2_DQ3
AF5
FRC_DDR3_DQL7/DDR2_DQ5
AE12
FRC_DDR3_DQU0/DDR2_DQ8
AE10
FRC_DDR3_DQU1/DDR2_DQ14
AF7
FRC_DDR3_DQU2/DDR2_DQ13
AD11
FRC_DDR3_DQU3/DDR2_DQ12
AD7
FRC_DDR3_DQU4/DDR2_DQ15
AD10
FRC_DDR3_DQU5/DDR2_DQ9
AE7
FRC_DDR3_DQU6/DDR2_DQ10
AF10
FRC_DDR3_DQU7/DDR2_DQM1
AD8
FRC_DDR3_NC/DDR2_DQM0
AE8
FRC_REXT
Y11
FRC_TESTPIN
Y19
ACKP/RLV3P/RED[3] W26
ACKM/RLV3N/RED[2] W25
A0P/RLV0P/RED[9] U26
A0M/RLV0N/RED[8] U25
A1P/RLV1P/RED[7] U24
A1M/RLV1N/RED[6] V26
A2P/RLV2P/RED[5] V25
A2M/RLV2N/RED[4] V24
A3P/RLV4P/RED[1] W24
A3M/RLV4N/RED[0] Y26
A4P/RLV5P/GREEN[9] Y25
A4M/RLV5N/GREEN[8] Y24
BCKP/TCON13/GREEN[1] AC26
BCKM/TCON12/GREEN[0] AC25
B0P/RLV6P/GREEN[7] AA26
B0M/RLV6N/GREEN[6] AA25
B1P/RLV7P/GREEN[5] AA24
B1M/RLV7N/GREEN[4] AB26
B2P/RLV8P/GREEN[3] AB25
B2M/RLV8N/GREEN[2] AB24
B3P/TCON11/BLUE[9] AC24
B3M/TCON10/BLUE[8] AD26
B4P/TCON9/BLUE[7] AD25
B4M/TCON8/BLUE[6] AD24
CCKP/LLV3P AD23
CCKM/LLV3N AE23
C0P/LLV0P/BLUE[5] AE26
C0M/LLV0N/BLUE[4] AE25
C1P/LLV1P/BLUE[3] AF26
C1M/LLV1N/BLUE[2] AF25
C2P/LLV2P/BLUE[1] AE24
C2M/LLV2N/BLUE[0] AF24
C3P/LLV4P AF23
C3M/LLV4N AD22
C4P/LLV5P AE22
C4M/LLV5N AF22
DCKP/TCON5 AD19
DCKM/TCON4 AE19
D0P/LLV6P AD21
D0M/LLV6N AE21
D1P/LLV7P AF21
D1M/LLV7N AD20
D2P/LLV8P AE20
D2M/LLV8N AF20
D3P/TCON3 AF19
D3M/TCON2 AD18
D4P/TCON1 AE18
D4M/TCON0 AF18
GPIO0/TCON15/HSYNC/VDD_ODD AB22
GPIO1/TCON14/VSYNC/VDD_EVEN AB23
GPIO2/TCON7/LDE/GCLK4 AC23
GPIO3/TCON6/LCK/GCLK2 AC22
FRC_GPIO0/UART_RX AB16
FRC_GPIO1 AA14
FRC_GPIO3 AC15
FRC_GPIO8 Y16
FRC_GPIO9/UART_TX AC16
FRC_GPIO10 AC14
FRC_I2CM_DA AA16
FRC_I2CM_CK AA15
FRC_I2CS_DA Y10
FRC_I2CS_CK AA11
FRC_PWM0 AB15
FRC_PWM1 AB14
LGE107DBS-LF-1 (S7M Divx_Non RM/MS10)
IC101-*15
S7M_DIVX & DD_SPIL
FRC_DDR3_A0/DDR2_NC
AE1
FRC_DDR3_A1/DDR2_A6
AF16
FRC_DDR3_A2/DDR2_A7
AF1
FRC_DDR3_A3/DDR2_A1
AE3
FRC_DDR3_A4/DDR2_CASZ
AD14
FRC_DDR3_A5/DDR2_A10
AD3
FRC_DDR3_A6/DDR2_A0
AF15
FRC_DDR3_A7/DDR2_A5
AF2
FRC_DDR3_A8/DDR2_A2
AE15
FRC_DDR3_A9/DDR2_A9
AD2
FRC_DDR3_A10/DDR2_A11
AD16
FRC_DDR3_A11/DDR2_A4
AD15
FRC_DDR3_A12/DDR2_A8
AE16
FRC_DDR3_BA0/DDR2_BA2
AF3
FRC_DDR3_BA1/DDR2_ODT
AF14
FRC_DDR3_BA2/DDR2_A12
AD1
FRC_DDR3_MCLK/DDR2_MCLK
AD13
FRC_DDR3_CKE/DDR2_RASZ
AE14
FRC_DDR3_MCLKZ/DDR2_MCLKZ
AE13
FRC_DDR3_ODT/DDR2_BA1
AE4
FRC_DDR3_RASZ/DDR2_WEZ
AD5
FRC_DDR3_CASZ/DDR2_CKE
AF4
FRC_DDR3_WEZ/DDR2_BA0
AD4
FRC_DDR3_RESETB/DDR2_A3
AE2
FRC_DDR3_DQSL/DDR2_DQS0
AF8
FRC_DDR3_DQSLB/DDR2_DQSB0
AD9
FRC_DDR3_DQSU/DDR2_DQS1
AE9
FRC_DDR3_DQSUB/DDR2_DQSB1
AF9
FRC_DDR3_DML/DDR2_DQ7
AE11
FRC_DDR3_DMU/DDR2_DQ11
AF6
FRC_DDR3_DQL0/DDR2_DQ6
AE6
FRC_DDR3_DQL1/DDR2_DQ0
AF11
FRC_DDR3_DQL2/DDR2_DQ1
AD6
FRC_DDR3_DQL3/DDR2_DQ2
AD12
FRC_DDR3_DQL4/DDR2_DQ4
AE5
FRC_DDR3_DQL5/DDR2_NC
AF12
FRC_DDR3_DQL6/DDR2_DQ3
AF5
FRC_DDR3_DQL7/DDR2_DQ5
AE12
FRC_DDR3_DQU0/DDR2_DQ8
AE10
FRC_DDR3_DQU1/DDR2_DQ14
AF7
FRC_DDR3_DQU2/DDR2_DQ13
AD11
FRC_DDR3_DQU3/DDR2_DQ12
AD7
FRC_DDR3_DQU4/DDR2_DQ15
AD10
FRC_DDR3_DQU5/DDR2_DQ9
AE7
FRC_DDR3_DQU6/DDR2_DQ10
AF10
FRC_DDR3_DQU7/DDR2_DQM1
AD8
FRC_DDR3_NC/DDR2_DQM0
AE8
FRC_REXT
Y11
FRC_TESTPIN
Y19
ACKP/RLV3P/RED[3] W26
ACKM/RLV3N/RED[2] W25
A0P/RLV0P/RED[9] U26
A0M/RLV0N/RED[8] U25
A1P/RLV1P/RED[7] U24
A1M/RLV1N/RED[6] V26
A2P/RLV2P/RED[5] V25
A2M/RLV2N/RED[4] V24
A3P/RLV4P/RED[1] W24
A3M/RLV4N/RED[0] Y26
A4P/RLV5P/GREEN[9] Y25
A4M/RLV5N/GREEN[8] Y24
BCKP/TCON13/GREEN[1] AC26
BCKM/TCON12/GREEN[0] AC25
B0P/RLV6P/GREEN[7] AA26
B0M/RLV6N/GREEN[6] AA25
B1P/RLV7P/GREEN[5] AA24
B1M/RLV7N/GREEN[4] AB26
B2P/RLV8P/GREEN[3] AB25
B2M/RLV8N/GREEN[2] AB24
B3P/TCON11/BLUE[9] AC24
B3M/TCON10/BLUE[8] AD26
B4P/TCON9/BLUE[7] AD25
B4M/TCON8/BLUE[6] AD24
CCKP/LLV3P AD23
CCKM/LLV3N AE23
C0P/LLV0P/BLUE[5] AE26
C0M/LLV0N/BLUE[4] AE25
C1P/LLV1P/BLUE[3] AF26
C1M/LLV1N/BLUE[2] AF25
C2P/LLV2P/BLUE[1] AE24
C2M/LLV2N/BLUE[0] AF24
C3P/LLV4P AF23
C3M/LLV4N AD22
C4P/LLV5P AE22
C4M/LLV5N AF22
DCKP/TCON5 AD19
DCKM/TCON4 AE19
D0P/LLV6P AD21
D0M/LLV6N AE21
D1P/LLV7P AF21
D1M/LLV7N AD20
D2P/LLV8P AE20
D2M/LLV8N AF20
D3P/TCON3 AF19
D3M/TCON2 AD18
D4P/TCON1 AE18
D4M/TCON0 AF18
GPIO0/TCON15/HSYNC/VDD_ODD AB22
GPIO1/TCON14/VSYNC/VDD_EVEN AB23
GPIO2/TCON7/LDE/GCLK4 AC23
GPIO3/TCON6/LCK/GCLK2 AC22
FRC_GPIO0/UART_RX AB16
FRC_GPIO1 AA14
FRC_GPIO3 AC15
FRC_GPIO8 Y16
FRC_GPIO9/UART_TX AC16
FRC_GPIO10 AC14
FRC_I2CM_DA AA16
FRC_I2CM_CK AA15
FRC_I2CS_DA Y10
FRC_I2CS_CK AA11
FRC_PWM0 AB15
FRC_PWM1 AB14
LGE107DC-LF-1-TE (ASEK)(S7M Divx_Non RM/MS10)
EAN60920604
IC101-*19
S7M_R_DIVX & DD
FRC_DDR3_A0/DDR2_NC
AE1
FRC_DDR3_A1/DDR2_A6
AF16
FRC_DDR3_A2/DDR2_A7
AF1
FRC_DDR3_A3/DDR2_A1
AE3
FRC_DDR3_A4/DDR2_CASZ
AD14
FRC_DDR3_A5/DDR2_A10
AD3
FRC_DDR3_A6/DDR2_A0
AF15
FRC_DDR3_A7/DDR2_A5
AF2
FRC_DDR3_A8/DDR2_A2
AE15
FRC_DDR3_A9/DDR2_A9
AD2
FRC_DDR3_A10/DDR2_A11
AD16
FRC_DDR3_A11/DDR2_A4
AD15
FRC_DDR3_A12/DDR2_A8
AE16
FRC_DDR3_BA0/DDR2_BA2
AF3
FRC_DDR3_BA1/DDR2_ODT
AF14
FRC_DDR3_BA2/DDR2_A12
AD1
FRC_DDR3_MCLK/DDR2_MCLK
AD13
FRC_DDR3_CKE/DDR2_RASZ
AE14
FRC_DDR3_MCLKZ/DDR2_MCLKZ
AE13
FRC_DDR3_ODT/DDR2_BA1
AE4
FRC_DDR3_RASZ/DDR2_WEZ
AD5
FRC_DDR3_CASZ/DDR2_CKE
AF4
FRC_DDR3_WEZ/DDR2_BA0
AD4
FRC_DDR3_RESETB/DDR2_A3
AE2
FRC_DDR3_DQSL/DDR2_DQS0
AF8
FRC_DDR3_DQSLB/DDR2_DQSB0
AD9
FRC_DDR3_DQSU/DDR2_DQS1
AE9
FRC_DDR3_DQSUB/DDR2_DQSB1
AF9
FRC_DDR3_DML/DDR2_DQ7
AE11
FRC_DDR3_DMU/DDR2_DQ11
AF6
FRC_DDR3_DQL0/DDR2_DQ6
AE6
FRC_DDR3_DQL1/DDR2_DQ0
AF11
FRC_DDR3_DQL2/DDR2_DQ1
AD6
FRC_DDR3_DQL3/DDR2_DQ2
AD12
FRC_DDR3_DQL4/DDR2_DQ4
AE5
FRC_DDR3_DQL5/DDR2_NC
AF12
FRC_DDR3_DQL6/DDR2_DQ3
AF5
FRC_DDR3_DQL7/DDR2_DQ5
AE12
FRC_DDR3_DQU0/DDR2_DQ8
AE10
FRC_DDR3_DQU1/DDR2_DQ14
AF7
FRC_DDR3_DQU2/DDR2_DQ13
AD11
FRC_DDR3_DQU3/DDR2_DQ12
AD7
FRC_DDR3_DQU4/DDR2_DQ15
AD10
FRC_DDR3_DQU5/DDR2_DQ9
AE7
FRC_DDR3_DQU6/DDR2_DQ10
AF10
FRC_DDR3_DQU7/DDR2_DQM1
AD8
FRC_DDR3_NC/DDR2_DQM0
AE8
FRC_REXT
Y11
FRC_TESTPIN
Y19
ACKP/RLV3P/RED[3] W26
ACKM/RLV3N/RED[2] W25
A0P/RLV0P/RED[9] U26
A0M/RLV0N/RED[8] U25
A1P/RLV1P/RED[7] U24
A1M/RLV1N/RED[6] V26
A2P/RLV2P/RED[5] V25
A2M/RLV2N/RED[4] V24
A3P/RLV4P/RED[1] W24
A3M/RLV4N/RED[0] Y26
A4P/RLV5P/GREEN[9] Y25
A4M/RLV5N/GREEN[8] Y24
BCKP/TCON13/GREEN[1] AC26
BCKM/TCON12/GREEN[0] AC25
B0P/RLV6P/GREEN[7] AA26
B0M/RLV6N/GREEN[6] AA25
B1P/RLV7P/GREEN[5] AA24
B1M/RLV7N/GREEN[4] AB26
B2P/RLV8P/GREEN[3] AB25
B2M/RLV8N/GREEN[2] AB24
B3P/TCON11/BLUE[9] AC24
B3M/TCON10/BLUE[8] AD26
B4P/TCON9/BLUE[7] AD25
B4M/TCON8/BLUE[6] AD24
CCKP/LLV3P AD23
CCKM/LLV3N AE23
C0P/LLV0P/BLUE[5] AE26
C0M/LLV0N/BLUE[4] AE25
C1P/LLV1P/BLUE[3] AF26
C1M/LLV1N/BLUE[2] AF25
C2P/LLV2P/BLUE[1] AE24
C2M/LLV2N/BLUE[0] AF24
C3P/LLV4P AF23
C3M/LLV4N AD22
C4P/LLV5P AE22
C4M/LLV5N AF22
DCKP/TCON5 AD19
DCKM/TCON4 AE19
D0P/LLV6P AD21
D0M/LLV6N AE21
D1P/LLV7P AF21
D1M/LLV7N AD20
D2P/LLV8P AE20
D2M/LLV8N AF20
D3P/TCON3 AF19
D3M/TCON2 AD18
D4P/TCON1 AE18
D4M/TCON0 AF18
GPIO0/TCON15/HSYNC/VDD_ODD AB22
GPIO1/TCON14/VSYNC/VDD_EVEN AB23
GPIO2/TCON7/LDE/GCLK4 AC23
GPIO3/TCON6/LCK/GCLK2 AC22
FRC_GPIO0/UART_RX AB16
FRC_GPIO1 AA14
FRC_GPIO3 AC15
FRC_GPIO8 Y16
FRC_GPIO9/UART_TX AC16
FRC_GPIO10 AC14
FRC_I2CM_DA AA16
FRC_I2CM_CK AA15
FRC_I2CS_DA Y10
FRC_I2CS_CK AA11
FRC_PWM0 AB15
FRC_PWM1 AB14
LGE107DC-LF-T8 (ASEK)(S7M Divx_Non RM)
EAN60920603
IC101-*18
S7M_R_DIVX & MS10
FRC_DDR3_A0/DDR2_NC
AE1
FRC_DDR3_A1/DDR2_A6
AF16
FRC_DDR3_A2/DDR2_A7
AF1
FRC_DDR3_A3/DDR2_A1
AE3
FRC_DDR3_A4/DDR2_CASZ
AD14
FRC_DDR3_A5/DDR2_A10
AD3
FRC_DDR3_A6/DDR2_A0
AF15
FRC_DDR3_A7/DDR2_A5
AF2
FRC_DDR3_A8/DDR2_A2
AE15
FRC_DDR3_A9/DDR2_A9
AD2
FRC_DDR3_A10/DDR2_A11
AD16
FRC_DDR3_A11/DDR2_A4
AD15
FRC_DDR3_A12/DDR2_A8
AE16
FRC_DDR3_BA0/DDR2_BA2
AF3
FRC_DDR3_BA1/DDR2_ODT
AF14
FRC_DDR3_BA2/DDR2_A12
AD1
FRC_DDR3_MCLK/DDR2_MCLK
AD13
FRC_DDR3_CKE/DDR2_RASZ
AE14
FRC_DDR3_MCLKZ/DDR2_MCLKZ
AE13
FRC_DDR3_ODT/DDR2_BA1
AE4
FRC_DDR3_RASZ/DDR2_WEZ
AD5
FRC_DDR3_CASZ/DDR2_CKE
AF4
FRC_DDR3_WEZ/DDR2_BA0
AD4
FRC_DDR3_RESETB/DDR2_A3
AE2
FRC_DDR3_DQSL/DDR2_DQS0
AF8
FRC_DDR3_DQSLB/DDR2_DQSB0
AD9
FRC_DDR3_DQSU/DDR2_DQS1
AE9
FRC_DDR3_DQSUB/DDR2_DQSB1
AF9
FRC_DDR3_DML/DDR2_DQ7
AE11
FRC_DDR3_DMU/DDR2_DQ11
AF6
FRC_DDR3_DQL0/DDR2_DQ6
AE6
FRC_DDR3_DQL1/DDR2_DQ0
AF11
FRC_DDR3_DQL2/DDR2_DQ1
AD6
FRC_DDR3_DQL3/DDR2_DQ2
AD12
FRC_DDR3_DQL4/DDR2_DQ4
AE5
FRC_DDR3_DQL5/DDR2_NC
AF12
FRC_DDR3_DQL6/DDR2_DQ3
AF5
FRC_DDR3_DQL7/DDR2_DQ5
AE12
FRC_DDR3_DQU0/DDR2_DQ8
AE10
FRC_DDR3_DQU1/DDR2_DQ14
AF7
FRC_DDR3_DQU2/DDR2_DQ13
AD11
FRC_DDR3_DQU3/DDR2_DQ12
AD7
FRC_DDR3_DQU4/DDR2_DQ15
AD10
FRC_DDR3_DQU5/DDR2_DQ9
AE7
FRC_DDR3_DQU6/DDR2_DQ10
AF10
FRC_DDR3_DQU7/DDR2_DQM1
AD8
FRC_DDR3_NC/DDR2_DQM0
AE8
FRC_REXT
Y11
FRC_TESTPIN
Y19
ACKP/RLV3P/RED[3] W26
ACKM/RLV3N/RED[2] W25
A0P/RLV0P/RED[9] U26
A0M/RLV0N/RED[8] U25
A1P/RLV1P/RED[7] U24
A1M/RLV1N/RED[6] V26
A2P/RLV2P/RED[5] V25
A2M/RLV2N/RED[4] V24
A3P/RLV4P/RED[1] W24
A3M/RLV4N/RED[0] Y26
A4P/RLV5P/GREEN[9] Y25
A4M/RLV5N/GREEN[8] Y24
BCKP/TCON13/GREEN[1] AC26
BCKM/TCON12/GREEN[0] AC25
B0P/RLV6P/GREEN[7] AA26
B0M/RLV6N/GREEN[6] AA25
B1P/RLV7P/GREEN[5] AA24
B1M/RLV7N/GREEN[4] AB26
B2P/RLV8P/GREEN[3] AB25
B2M/RLV8N/GREEN[2] AB24
B3P/TCON11/BLUE[9] AC24
B3M/TCON10/BLUE[8] AD26
B4P/TCON9/BLUE[7] AD25
B4M/TCON8/BLUE[6] AD24
CCKP/LLV3P AD23
CCKM/LLV3N AE23
C0P/LLV0P/BLUE[5] AE26
C0M/LLV0N/BLUE[4] AE25
C1P/LLV1P/BLUE[3] AF26
C1M/LLV1N/BLUE[2] AF25
C2P/LLV2P/BLUE[1] AE24
C2M/LLV2N/BLUE[0] AF24
C3P/LLV4P AF23
C3M/LLV4N AD22
C4P/LLV5P AE22
C4M/LLV5N AF22
DCKP/TCON5 AD19
DCKM/TCON4 AE19
D0P/LLV6P AD21
D0M/LLV6N AE21
D1P/LLV7P AF21
D1M/LLV7N AD20
D2P/LLV8P AE20
D2M/LLV8N AF20
D3P/TCON3 AF19
D3M/TCON2 AD18
D4P/TCON1 AE18
D4M/TCON0 AF18
GPIO0/TCON15/HSYNC/VDD_ODD AB22
GPIO1/TCON14/VSYNC/VDD_EVEN AB23
GPIO2/TCON7/LDE/GCLK4 AC23
GPIO3/TCON6/LCK/GCLK2 AC22
FRC_GPIO0/UART_RX AB16
FRC_GPIO1 AA14
FRC_GPIO3 AC15
FRC_GPIO8 Y16
FRC_GPIO9/UART_TX AC16
FRC_GPIO10 AC14
FRC_I2CM_DA AA16
FRC_I2CM_CK AA15
FRC_I2CS_DA Y10
FRC_I2CS_CK AA11
FRC_PWM0 AB15
FRC_PWM1 AB14
LGE107C-LF-SA (ASEK)(S7M Non Divx/RM)
EAN60920503
IC101-*16
S7M_R_NON_DIVX & MS10
FRC_DDR3_A0/DDR2_NC
AE1
FRC_DDR3_A1/DDR2_A6
AF16
FRC_DDR3_A2/DDR2_A7
AF1
FRC_DDR3_A3/DDR2_A1
AE3
FRC_DDR3_A4/DDR2_CASZ
AD14
FRC_DDR3_A5/DDR2_A10
AD3
FRC_DDR3_A6/DDR2_A0
AF15
FRC_DDR3_A7/DDR2_A5
AF2
FRC_DDR3_A8/DDR2_A2
AE15
FRC_DDR3_A9/DDR2_A9
AD2
FRC_DDR3_A10/DDR2_A11
AD16
FRC_DDR3_A11/DDR2_A4
AD15
FRC_DDR3_A12/DDR2_A8
AE16
FRC_DDR3_BA0/DDR2_BA2
AF3
FRC_DDR3_BA1/DDR2_ODT
AF14
FRC_DDR3_BA2/DDR2_A12
AD1
FRC_DDR3_MCLK/DDR2_MCLK
AD13
FRC_DDR3_CKE/DDR2_RASZ
AE14
FRC_DDR3_MCLKZ/DDR2_MCLKZ
AE13
FRC_DDR3_ODT/DDR2_BA1
AE4
FRC_DDR3_RASZ/DDR2_WEZ
AD5
FRC_DDR3_CASZ/DDR2_CKE
AF4
FRC_DDR3_WEZ/DDR2_BA0
AD4
FRC_DDR3_RESETB/DDR2_A3
AE2
FRC_DDR3_DQSL/DDR2_DQS0
AF8
FRC_DDR3_DQSLB/DDR2_DQSB0
AD9
FRC_DDR3_DQSU/DDR2_DQS1
AE9
FRC_DDR3_DQSUB/DDR2_DQSB1
AF9
FRC_DDR3_DML/DDR2_DQ7
AE11
FRC_DDR3_DMU/DDR2_DQ11
AF6
FRC_DDR3_DQL0/DDR2_DQ6
AE6
FRC_DDR3_DQL1/DDR2_DQ0
AF11
FRC_DDR3_DQL2/DDR2_DQ1
AD6
FRC_DDR3_DQL3/DDR2_DQ2
AD12
FRC_DDR3_DQL4/DDR2_DQ4
AE5
FRC_DDR3_DQL5/DDR2_NC
AF12
FRC_DDR3_DQL6/DDR2_DQ3
AF5
FRC_DDR3_DQL7/DDR2_DQ5
AE12
FRC_DDR3_DQU0/DDR2_DQ8
AE10
FRC_DDR3_DQU1/DDR2_DQ14
AF7
FRC_DDR3_DQU2/DDR2_DQ13
AD11
FRC_DDR3_DQU3/DDR2_DQ12
AD7
FRC_DDR3_DQU4/DDR2_DQ15
AD10
FRC_DDR3_DQU5/DDR2_DQ9
AE7
FRC_DDR3_DQU6/DDR2_DQ10
AF10
FRC_DDR3_DQU7/DDR2_DQM1
AD8
FRC_DDR3_NC/DDR2_DQM0
AE8
FRC_REXT
Y11
FRC_TESTPIN
Y19
ACKP/RLV3P/RED[3] W26
ACKM/RLV3N/RED[2] W25
A0P/RLV0P/RED[9] U26
A0M/RLV0N/RED[8] U25
A1P/RLV1P/RED[7] U24
A1M/RLV1N/RED[6] V26
A2P/RLV2P/RED[5] V25
A2M/RLV2N/RED[4] V24
A3P/RLV4P/RED[1] W24
A3M/RLV4N/RED[0] Y26
A4P/RLV5P/GREEN[9] Y25
A4M/RLV5N/GREEN[8] Y24
BCKP/TCON13/GREEN[1] AC26
BCKM/TCON12/GREEN[0] AC25
B0P/RLV6P/GREEN[7] AA26
B0M/RLV6N/GREEN[6] AA25
B1P/RLV7P/GREEN[5] AA24
B1M/RLV7N/GREEN[4] AB26
B2P/RLV8P/GREEN[3] AB25
B2M/RLV8N/GREEN[2] AB24
B3P/TCON11/BLUE[9] AC24
B3M/TCON10/BLUE[8] AD26
B4P/TCON9/BLUE[7] AD25
B4M/TCON8/BLUE[6] AD24
CCKP/LLV3P AD23
CCKM/LLV3N AE23
C0P/LLV0P/BLUE[5] AE26
C0M/LLV0N/BLUE[4] AE25
C1P/LLV1P/BLUE[3] AF26
C1M/LLV1N/BLUE[2] AF25
C2P/LLV2P/BLUE[1] AE24
C2M/LLV2N/BLUE[0] AF24
C3P/LLV4P AF23
C3M/LLV4N AD22
C4P/LLV5P AE22
C4M/LLV5N AF22
DCKP/TCON5 AD19
DCKM/TCON4 AE19
D0P/LLV6P AD21
D0M/LLV6N AE21
D1P/LLV7P AF21
D1M/LLV7N AD20
D2P/LLV8P AE20
D2M/LLV8N AF20
D3P/TCON3 AF19
D3M/TCON2 AD18
D4P/TCON1 AE18
D4M/TCON0 AF18
GPIO0/TCON15/HSYNC/VDD_ODD AB22
GPIO1/TCON14/VSYNC/VDD_EVEN AB23
GPIO2/TCON7/LDE/GCLK4 AC23
GPIO3/TCON6/LCK/GCLK2 AC22
FRC_GPIO0/UART_RX AB16
FRC_GPIO1 AA14
FRC_GPIO3 AC15
FRC_GPIO8 Y16
FRC_GPIO9/UART_TX AC16
FRC_GPIO10 AC14
FRC_I2CM_DA AA16
FRC_I2CM_CK AA15
FRC_I2CS_DA Y10
FRC_I2CS_CK AA11
FRC_PWM0 AB15
FRC_PWM1 AB14
LGE107C-LF-1 (ASEK)(S7M Non Divx/RM/MS10)
EAN60920504
IC101-*17
S7M_R_NON_DIVX& DD
FRC_DDR3_A0/DDR2_NC
AE1
FRC_DDR3_A1/DDR2_A6
AF16
FRC_DDR3_A2/DDR2_A7
AF1
FRC_DDR3_A3/DDR2_A1
AE3
FRC_DDR3_A4/DDR2_CASZ
AD14
FRC_DDR3_A5/DDR2_A10
AD3
FRC_DDR3_A6/DDR2_A0
AF15
FRC_DDR3_A7/DDR2_A5
AF2
FRC_DDR3_A8/DDR2_A2
AE15
FRC_DDR3_A9/DDR2_A9
AD2
FRC_DDR3_A10/DDR2_A11
AD16
FRC_DDR3_A11/DDR2_A4
AD15
FRC_DDR3_A12/DDR2_A8
AE16
FRC_DDR3_BA0/DDR2_BA2
AF3
FRC_DDR3_BA1/DDR2_ODT
AF14
FRC_DDR3_BA2/DDR2_A12
AD1
FRC_DDR3_MCLK/DDR2_MCLK
AD13
FRC_DDR3_CKE/DDR2_RASZ
AE14
FRC_DDR3_MCLKZ/DDR2_MCLKZ
AE13
FRC_DDR3_ODT/DDR2_BA1
AE4
FRC_DDR3_RASZ/DDR2_WEZ
AD5
FRC_DDR3_CASZ/DDR2_CKE
AF4
FRC_DDR3_WEZ/DDR2_BA0
AD4
FRC_DDR3_RESETB/DDR2_A3
AE2
FRC_DDR3_DQSL/DDR2_DQS0
AF8
FRC_DDR3_DQSLB/DDR2_DQSB0
AD9
FRC_DDR3_DQSU/DDR2_DQS1
AE9
FRC_DDR3_DQSUB/DDR2_DQSB1
AF9
FRC_DDR3_DML/DDR2_DQ7
AE11
FRC_DDR3_DMU/DDR2_DQ11
AF6
FRC_DDR3_DQL0/DDR2_DQ6
AE6
FRC_DDR3_DQL1/DDR2_DQ0
AF11
FRC_DDR3_DQL2/DDR2_DQ1
AD6
FRC_DDR3_DQL3/DDR2_DQ2
AD12
FRC_DDR3_DQL4/DDR2_DQ4
AE5
FRC_DDR3_DQL5/DDR2_NC
AF12
FRC_DDR3_DQL6/DDR2_DQ3
AF5
FRC_DDR3_DQL7/DDR2_DQ5
AE12
FRC_DDR3_DQU0/DDR2_DQ8
AE10
FRC_DDR3_DQU1/DDR2_DQ14
AF7
FRC_DDR3_DQU2/DDR2_DQ13
AD11
FRC_DDR3_DQU3/DDR2_DQ12
AD7
FRC_DDR3_DQU4/DDR2_DQ15
AD10
FRC_DDR3_DQU5/DDR2_DQ9
AE7
FRC_DDR3_DQU6/DDR2_DQ10
AF10
FRC_DDR3_DQU7/DDR2_DQM1
AD8
FRC_DDR3_NC/DDR2_DQM0
AE8
FRC_REXT
Y11
FRC_TESTPIN
Y19
ACKP/RLV3P/RED[3] W26
ACKM/RLV3N/RED[2] W25
A0P/RLV0P/RED[9] U26
A0M/RLV0N/RED[8] U25
A1P/RLV1P/RED[7] U24
A1M/RLV1N/RED[6] V26
A2P/RLV2P/RED[5] V25
A2M/RLV2N/RED[4] V24
A3P/RLV4P/RED[1] W24
A3M/RLV4N/RED[0] Y26
A4P/RLV5P/GREEN[9] Y25
A4M/RLV5N/GREEN[8] Y24
BCKP/TCON13/GREEN[1] AC26
BCKM/TCON12/GREEN[0] AC25
B0P/RLV6P/GREEN[7] AA26
B0M/RLV6N/GREEN[6] AA25
B1P/RLV7P/GREEN[5] AA24
B1M/RLV7N/GREEN[4] AB26
B2P/RLV8P/GREEN[3] AB25
B2M/RLV8N/GREEN[2] AB24
B3P/TCON11/BLUE[9] AC24
B3M/TCON10/BLUE[8] AD26
B4P/TCON9/BLUE[7] AD25
B4M/TCON8/BLUE[6] AD24
CCKP/LLV3P AD23
CCKM/LLV3N AE23
C0P/LLV0P/BLUE[5] AE26
C0M/LLV0N/BLUE[4] AE25
C1P/LLV1P/BLUE[3] AF26
C1M/LLV1N/BLUE[2] AF25
C2P/LLV2P/BLUE[1] AE24
C2M/LLV2N/BLUE[0] AF24
C3P/LLV4P AF23
C3M/LLV4N AD22
C4P/LLV5P AE22
C4M/LLV5N AF22
DCKP/TCON5 AD19
DCKM/TCON4 AE19
D0P/LLV6P AD21
D0M/LLV6N AE21
D1P/LLV7P AF21
D1M/LLV7N AD20
D2P/LLV8P AE20
D2M/LLV8N AF20
D3P/TCON3 AF19
D3M/TCON2 AD18
D4P/TCON1 AE18
D4M/TCON0 AF18
GPIO0/TCON15/HSYNC/VDD_ODD AB22
GPIO1/TCON14/VSYNC/VDD_EVEN AB23
GPIO2/TCON7/LDE/GCLK4 AC23
GPIO3/TCON6/LCK/GCLK2 AC22
FRC_GPIO0/UART_RX AB16
FRC_GPIO1 AA14
FRC_GPIO3 AC15
FRC_GPIO8 Y16
FRC_GPIO9/UART_TX AC16
FRC_GPIO10 AC14
FRC_I2CM_DA AA16
FRC_I2CM_CK AA15
FRC_I2CS_DA Y10
FRC_I2CS_CK AA11
FRC_PWM0 AB15
FRC_PWM1 AB14
LGE107C-LF (SPIL)(S7M Non Divx/RM)
IC101-*20
S7M_R_NON_DIVX & MS10_SPIL
FRC_DDR3_A0/DDR2_NC
AE1
FRC_DDR3_A1/DDR2_A6
AF16
FRC_DDR3_A2/DDR2_A7
AF1
FRC_DDR3_A3/DDR2_A1
AE3
FRC_DDR3_A4/DDR2_CASZ
AD14
FRC_DDR3_A5/DDR2_A10
AD3
FRC_DDR3_A6/DDR2_A0
AF15
FRC_DDR3_A7/DDR2_A5
AF2
FRC_DDR3_A8/DDR2_A2
AE15
FRC_DDR3_A9/DDR2_A9
AD2
FRC_DDR3_A10/DDR2_A11
AD16
FRC_DDR3_A11/DDR2_A4
AD15
FRC_DDR3_A12/DDR2_A8
AE16
FRC_DDR3_BA0/DDR2_BA2
AF3
FRC_DDR3_BA1/DDR2_ODT
AF14
FRC_DDR3_BA2/DDR2_A12
AD1
FRC_DDR3_MCLK/DDR2_MCLK
AD13
FRC_DDR3_CKE/DDR2_RASZ
AE14
FRC_DDR3_MCLKZ/DDR2_MCLKZ
AE13
FRC_DDR3_ODT/DDR2_BA1
AE4
FRC_DDR3_RASZ/DDR2_WEZ
AD5
FRC_DDR3_CASZ/DDR2_CKE
AF4
FRC_DDR3_WEZ/DDR2_BA0
AD4
FRC_DDR3_RESETB/DDR2_A3
AE2
FRC_DDR3_DQSL/DDR2_DQS0
AF8
FRC_DDR3_DQSLB/DDR2_DQSB0
AD9
FRC_DDR3_DQSU/DDR2_DQS1
AE9
FRC_DDR3_DQSUB/DDR2_DQSB1
AF9
FRC_DDR3_DML/DDR2_DQ7
AE11
FRC_DDR3_DMU/DDR2_DQ11
AF6
FRC_DDR3_DQL0/DDR2_DQ6
AE6
FRC_DDR3_DQL1/DDR2_DQ0
AF11
FRC_DDR3_DQL2/DDR2_DQ1
AD6
FRC_DDR3_DQL3/DDR2_DQ2
AD12
FRC_DDR3_DQL4/DDR2_DQ4
AE5
FRC_DDR3_DQL5/DDR2_NC
AF12
FRC_DDR3_DQL6/DDR2_DQ3
AF5
FRC_DDR3_DQL7/DDR2_DQ5
AE12
FRC_DDR3_DQU0/DDR2_DQ8
AE10
FRC_DDR3_DQU1/DDR2_DQ14
AF7
FRC_DDR3_DQU2/DDR2_DQ13
AD11
FRC_DDR3_DQU3/DDR2_DQ12
AD7
FRC_DDR3_DQU4/DDR2_DQ15
AD10
FRC_DDR3_DQU5/DDR2_DQ9
AE7
FRC_DDR3_DQU6/DDR2_DQ10
AF10
FRC_DDR3_DQU7/DDR2_DQM1
AD8
FRC_DDR3_NC/DDR2_DQM0
AE8
FRC_REXT
Y11
FRC_TESTPIN
Y19
ACKP/RLV3P/RED[3] W26
ACKM/RLV3N/RED[2] W25
A0P/RLV0P/RED[9] U26
A0M/RLV0N/RED[8] U25
A1P/RLV1P/RED[7] U24
A1M/RLV1N/RED[6] V26
A2P/RLV2P/RED[5] V25
A2M/RLV2N/RED[4] V24
A3P/RLV4P/RED[1] W24
A3M/RLV4N/RED[0] Y26
A4P/RLV5P/GREEN[9] Y25
A4M/RLV5N/GREEN[8] Y24
BCKP/TCON13/GREEN[1] AC26
BCKM/TCON12/GREEN[0] AC25
B0P/RLV6P/GREEN[7] AA26
B0M/RLV6N/GREEN[6] AA25
B1P/RLV7P/GREEN[5] AA24
B1M/RLV7N/GREEN[4] AB26
B2P/RLV8P/GREEN[3] AB25
B2M/RLV8N/GREEN[2] AB24
B3P/TCON11/BLUE[9] AC24
B3M/TCON10/BLUE[8] AD26
B4P/TCON9/BLUE[7] AD25
B4M/TCON8/BLUE[6] AD24
CCKP/LLV3P AD23
CCKM/LLV3N AE23
C0P/LLV0P/BLUE[5] AE26
C0M/LLV0N/BLUE[4] AE25
C1P/LLV1P/BLUE[3] AF26
C1M/LLV1N/BLUE[2] AF25
C2P/LLV2P/BLUE[1] AE24
C2M/LLV2N/BLUE[0] AF24
C3P/LLV4P AF23
C3M/LLV4N AD22
C4P/LLV5P AE22
C4M/LLV5N AF22
DCKP/TCON5 AD19
DCKM/TCON4 AE19
D0P/LLV6P AD21
D0M/LLV6N AE21
D1P/LLV7P AF21
D1M/LLV7N AD20
D2P/LLV8P AE20
D2M/LLV8N AF20
D3P/TCON3 AF19
D3M/TCON2 AD18
D4P/TCON1 AE18
D4M/TCON0 AF18
GPIO0/TCON15/HSYNC/VDD_ODD AB22
GPIO1/TCON14/VSYNC/VDD_EVEN AB23
GPIO2/TCON7/LDE/GCLK4 AC23
GPIO3/TCON6/LCK/GCLK2 AC22
FRC_GPIO0/UART_RX AB16
FRC_GPIO1 AA14
FRC_GPIO3 AC15
FRC_GPIO8 Y16
FRC_GPIO9/UART_TX AC16
FRC_GPIO10 AC14
FRC_I2CM_DA AA16
FRC_I2CM_CK AA15
FRC_I2CS_DA Y10
FRC_I2CS_CK AA11
FRC_PWM0 AB15
FRC_PWM1 AB14
LGE107C-LF-1 (SPIL)(S7M Non Divx/RM/MS10)
IC101-*21
S7M_R_NON_DIVX & DD_SPIL
FRC_DDR3_A0/DDR2_NC
AE1
FRC_DDR3_A1/DDR2_A6
AF16
FRC_DDR3_A2/DDR2_A7
AF1
FRC_DDR3_A3/DDR2_A1
AE3
FRC_DDR3_A4/DDR2_CASZ
AD14
FRC_DDR3_A5/DDR2_A10
AD3
FRC_DDR3_A6/DDR2_A0
AF15
FRC_DDR3_A7/DDR2_A5
AF2
FRC_DDR3_A8/DDR2_A2
AE15
FRC_DDR3_A9/DDR2_A9
AD2
FRC_DDR3_A10/DDR2_A11
AD16
FRC_DDR3_A11/DDR2_A4
AD15
FRC_DDR3_A12/DDR2_A8
AE16
FRC_DDR3_BA0/DDR2_BA2
AF3
FRC_DDR3_BA1/DDR2_ODT
AF14
FRC_DDR3_BA2/DDR2_A12
AD1
FRC_DDR3_MCLK/DDR2_MCLK
AD13
FRC_DDR3_CKE/DDR2_RASZ
AE14
FRC_DDR3_MCLKZ/DDR2_MCLKZ
AE13
FRC_DDR3_ODT/DDR2_BA1
AE4
FRC_DDR3_RASZ/DDR2_WEZ
AD5
FRC_DDR3_CASZ/DDR2_CKE
AF4
FRC_DDR3_WEZ/DDR2_BA0
AD4
FRC_DDR3_RESETB/DDR2_A3
AE2
FRC_DDR3_DQSL/DDR2_DQS0
AF8
FRC_DDR3_DQSLB/DDR2_DQSB0
AD9
FRC_DDR3_DQSU/DDR2_DQS1
AE9
FRC_DDR3_DQSUB/DDR2_DQSB1
AF9
FRC_DDR3_DML/DDR2_DQ7
AE11
FRC_DDR3_DMU/DDR2_DQ11
AF6
FRC_DDR3_DQL0/DDR2_DQ6
AE6
FRC_DDR3_DQL1/DDR2_DQ0
AF11
FRC_DDR3_DQL2/DDR2_DQ1
AD6
FRC_DDR3_DQL3/DDR2_DQ2
AD12
FRC_DDR3_DQL4/DDR2_DQ4
AE5
FRC_DDR3_DQL5/DDR2_NC
AF12
FRC_DDR3_DQL6/DDR2_DQ3
AF5
FRC_DDR3_DQL7/DDR2_DQ5
AE12
FRC_DDR3_DQU0/DDR2_DQ8
AE10
FRC_DDR3_DQU1/DDR2_DQ14
AF7
FRC_DDR3_DQU2/DDR2_DQ13
AD11
FRC_DDR3_DQU3/DDR2_DQ12
AD7
FRC_DDR3_DQU4/DDR2_DQ15
AD10
FRC_DDR3_DQU5/DDR2_DQ9
AE7
FRC_DDR3_DQU6/DDR2_DQ10
AF10
FRC_DDR3_DQU7/DDR2_DQM1
AD8
FRC_DDR3_NC/DDR2_DQM0
AE8
FRC_REXT
Y11
FRC_TESTPIN
Y19
ACKP/RLV3P/RED[3] W26
ACKM/RLV3N/RED[2] W25
A0P/RLV0P/RED[9] U26
A0M/RLV0N/RED[8] U25
A1P/RLV1P/RED[7] U24
A1M/RLV1N/RED[6] V26
A2P/RLV2P/RED[5] V25
A2M/RLV2N/RED[4] V24
A3P/RLV4P/RED[1] W24
A3M/RLV4N/RED[0] Y26
A4P/RLV5P/GREEN[9] Y25
A4M/RLV5N/GREEN[8] Y24
BCKP/TCON13/GREEN[1] AC26
BCKM/TCON12/GREEN[0] AC25
B0P/RLV6P/GREEN[7] AA26
B0M/RLV6N/GREEN[6] AA25
B1P/RLV7P/GREEN[5] AA24
B1M/RLV7N/GREEN[4] AB26
B2P/RLV8P/GREEN[3] AB25
B2M/RLV8N/GREEN[2] AB24
B3P/TCON11/BLUE[9] AC24
B3M/TCON10/BLUE[8] AD26
B4P/TCON9/BLUE[7] AD25
B4M/TCON8/BLUE[6] AD24
CCKP/LLV3P AD23
CCKM/LLV3N AE23
C0P/LLV0P/BLUE[5] AE26
C0M/LLV0N/BLUE[4] AE25
C1P/LLV1P/BLUE[3] AF26
C1M/LLV1N/BLUE[2] AF25
C2P/LLV2P/BLUE[1] AE24
C2M/LLV2N/BLUE[0] AF24
C3P/LLV4P AF23
C3M/LLV4N AD22
C4P/LLV5P AE22
C4M/LLV5N AF22
DCKP/TCON5 AD19
DCKM/TCON4 AE19
D0P/LLV6P AD21
D0M/LLV6N AE21
D1P/LLV7P AF21
D1M/LLV7N AD20
D2P/LLV8P AE20
D2M/LLV8N AF20
D3P/TCON3 AF19
D3M/TCON2 AD18
D4P/TCON1 AE18
D4M/TCON0 AF18
GPIO0/TCON15/HSYNC/VDD_ODD AB22
GPIO1/TCON14/VSYNC/VDD_EVEN AB23
GPIO2/TCON7/LDE/GCLK4 AC23
GPIO3/TCON6/LCK/GCLK2 AC22
FRC_GPIO0/UART_RX AB16
FRC_GPIO1 AA14
FRC_GPIO3 AC15
FRC_GPIO8 Y16
FRC_GPIO9/UART_TX AC16
FRC_GPIO10 AC14
FRC_I2CM_DA AA16
FRC_I2CM_CK AA15
FRC_I2CS_DA Y10
FRC_I2CS_CK AA11
FRC_PWM0 AB15
FRC_PWM1 AB14
LGE107DC-LF (SPIL)(S7M Divx_Non RM)
IC101-*22
S7M_R_DIVX & MS10_SPIL
FRC_DDR3_A0/DDR2_NC
AE1
FRC_DDR3_A1/DDR2_A6
AF16
FRC_DDR3_A2/DDR2_A7
AF1
FRC_DDR3_A3/DDR2_A1
AE3
FRC_DDR3_A4/DDR2_CASZ
AD14
FRC_DDR3_A5/DDR2_A10
AD3
FRC_DDR3_A6/DDR2_A0
AF15
FRC_DDR3_A7/DDR2_A5
AF2
FRC_DDR3_A8/DDR2_A2
AE15
FRC_DDR3_A9/DDR2_A9
AD2
FRC_DDR3_A10/DDR2_A11
AD16
FRC_DDR3_A11/DDR2_A4
AD15
FRC_DDR3_A12/DDR2_A8
AE16
FRC_DDR3_BA0/DDR2_BA2
AF3
FRC_DDR3_BA1/DDR2_ODT
AF14
FRC_DDR3_BA2/DDR2_A12
AD1
FRC_DDR3_MCLK/DDR2_MCLK
AD13
FRC_DDR3_CKE/DDR2_RASZ
AE14
FRC_DDR3_MCLKZ/DDR2_MCLKZ
AE13
FRC_DDR3_ODT/DDR2_BA1
AE4
FRC_DDR3_RASZ/DDR2_WEZ
AD5
FRC_DDR3_CASZ/DDR2_CKE
AF4
FRC_DDR3_WEZ/DDR2_BA0
AD4
FRC_DDR3_RESETB/DDR2_A3
AE2
FRC_DDR3_DQSL/DDR2_DQS0
AF8
FRC_DDR3_DQSLB/DDR2_DQSB0
AD9
FRC_DDR3_DQSU/DDR2_DQS1
AE9
FRC_DDR3_DQSUB/DDR2_DQSB1
AF9
FRC_DDR3_DML/DDR2_DQ7
AE11
FRC_DDR3_DMU/DDR2_DQ11
AF6
FRC_DDR3_DQL0/DDR2_DQ6
AE6
FRC_DDR3_DQL1/DDR2_DQ0
AF11
FRC_DDR3_DQL2/DDR2_DQ1
AD6
FRC_DDR3_DQL3/DDR2_DQ2
AD12
FRC_DDR3_DQL4/DDR2_DQ4
AE5
FRC_DDR3_DQL5/DDR2_NC
AF12
FRC_DDR3_DQL6/DDR2_DQ3
AF5
FRC_DDR3_DQL7/DDR2_DQ5
AE12
FRC_DDR3_DQU0/DDR2_DQ8
AE10
FRC_DDR3_DQU1/DDR2_DQ14
AF7
FRC_DDR3_DQU2/DDR2_DQ13
AD11
FRC_DDR3_DQU3/DDR2_DQ12
AD7
FRC_DDR3_DQU4/DDR2_DQ15
AD10
FRC_DDR3_DQU5/DDR2_DQ9
AE7
FRC_DDR3_DQU6/DDR2_DQ10
AF10
FRC_DDR3_DQU7/DDR2_DQM1
AD8
FRC_DDR3_NC/DDR2_DQM0
AE8
FRC_REXT
Y11
FRC_TESTPIN
Y19
ACKP/RLV3P/RED[3] W26
ACKM/RLV3N/RED[2] W25
A0P/RLV0P/RED[9] U26
A0M/RLV0N/RED[8] U25
A1P/RLV1P/RED[7] U24
A1M/RLV1N/RED[6] V26
A2P/RLV2P/RED[5] V25
A2M/RLV2N/RED[4] V24
A3P/RLV4P/RED[1] W24
A3M/RLV4N/RED[0] Y26
A4P/RLV5P/GREEN[9] Y25
A4M/RLV5N/GREEN[8] Y24
BCKP/TCON13/GREEN[1] AC26
BCKM/TCON12/GREEN[0] AC25
B0P/RLV6P/GREEN[7] AA26
B0M/RLV6N/GREEN[6] AA25
B1P/RLV7P/GREEN[5] AA24
B1M/RLV7N/GREEN[4] AB26
B2P/RLV8P/GREEN[3] AB25
B2M/RLV8N/GREEN[2] AB24
B3P/TCON11/BLUE[9] AC24
B3M/TCON10/BLUE[8] AD26
B4P/TCON9/BLUE[7] AD25
B4M/TCON8/BLUE[6] AD24
CCKP/LLV3P AD23
CCKM/LLV3N AE23
C0P/LLV0P/BLUE[5] AE26
C0M/LLV0N/BLUE[4] AE25
C1P/LLV1P/BLUE[3] AF26
C1M/LLV1N/BLUE[2] AF25
C2P/LLV2P/BLUE[1] AE24
C2M/LLV2N/BLUE[0] AF24
C3P/LLV4P AF23
C3M/LLV4N AD22
C4P/LLV5P AE22
C4M/LLV5N AF22
DCKP/TCON5 AD19
DCKM/TCON4 AE19
D0P/LLV6P AD21
D0M/LLV6N AE21
D1P/LLV7P AF21
D1M/LLV7N AD20
D2P/LLV8P AE20
D2M/LLV8N AF20
D3P/TCON3 AF19
D3M/TCON2 AD18
D4P/TCON1 AE18
D4M/TCON0 AF18
GPIO0/TCON15/HSYNC/VDD_ODD AB22
GPIO1/TCON14/VSYNC/VDD_EVEN AB23
GPIO2/TCON7/LDE/GCLK4 AC23
GPIO3/TCON6/LCK/GCLK2 AC22
FRC_GPIO0/UART_RX AB16
FRC_GPIO1 AA14
FRC_GPIO3 AC15
FRC_GPIO8 Y16
FRC_GPIO9/UART_TX AC16
FRC_GPIO10 AC14
FRC_I2CM_DA AA16
FRC_I2CM_CK AA15
FRC_I2CS_DA Y10
FRC_I2CS_CK AA11
FRC_PWM0 AB15
FRC_PWM1 AB14
LGE107DC-LF-1 (SPIL)(S7M Divx_Non RM/MS10)
IC101-*23
S7M_R_DIVX & DD_SPIL
FRC_DDR3_A0/DDR2_NC
AE1
FRC_DDR3_A1/DDR2_A6
AF16
FRC_DDR3_A2/DDR2_A7
AF1
FRC_DDR3_A3/DDR2_A1
AE3
FRC_DDR3_A4/DDR2_CASZ
AD14
FRC_DDR3_A5/DDR2_A10
AD3
FRC_DDR3_A6/DDR2_A0
AF15
FRC_DDR3_A7/DDR2_A5
AF2
FRC_DDR3_A8/DDR2_A2
AE15
FRC_DDR3_A9/DDR2_A9
AD2
FRC_DDR3_A10/DDR2_A11
AD16
FRC_DDR3_A11/DDR2_A4
AD15
FRC_DDR3_A12/DDR2_A8
AE16
FRC_DDR3_BA0/DDR2_BA2
AF3
FRC_DDR3_BA1/DDR2_ODT
AF14
FRC_DDR3_BA2/DDR2_A12
AD1
FRC_DDR3_MCLK/DDR2_MCLK
AD13
FRC_DDR3_CKE/DDR2_RASZ
AE14
FRC_DDR3_MCLKZ/DDR2_MCLKZ
AE13
FRC_DDR3_ODT/DDR2_BA1
AE4
FRC_DDR3_RASZ/DDR2_WEZ
AD5
FRC_DDR3_CASZ/DDR2_CKE
AF4
FRC_DDR3_WEZ/DDR2_BA0
AD4
FRC_DDR3_RESETB/DDR2_A3
AE2
FRC_DDR3_DQSL/DDR2_DQS0
AF8
FRC_DDR3_DQSLB/DDR2_DQSB0
AD9
FRC_DDR3_DQSU/DDR2_DQS1
AE9
FRC_DDR3_DQSUB/DDR2_DQSB1
AF9
FRC_DDR3_DML/DDR2_DQ7
AE11
FRC_DDR3_DMU/DDR2_DQ11
AF6
FRC_DDR3_DQL0/DDR2_DQ6
AE6
FRC_DDR3_DQL1/DDR2_DQ0
AF11
FRC_DDR3_DQL2/DDR2_DQ1
AD6
FRC_DDR3_DQL3/DDR2_DQ2
AD12
FRC_DDR3_DQL4/DDR2_DQ4
AE5
FRC_DDR3_DQL5/DDR2_NC
AF12
FRC_DDR3_DQL6/DDR2_DQ3
AF5
FRC_DDR3_DQL7/DDR2_DQ5
AE12
FRC_DDR3_DQU0/DDR2_DQ8
AE10
FRC_DDR3_DQU1/DDR2_DQ14
AF7
FRC_DDR3_DQU2/DDR2_DQ13
AD11
FRC_DDR3_DQU3/DDR2_DQ12
AD7
FRC_DDR3_DQU4/DDR2_DQ15
AD10
FRC_DDR3_DQU5/DDR2_DQ9
AE7
FRC_DDR3_DQU6/DDR2_DQ10
AF10
FRC_DDR3_DQU7/DDR2_DQM1
AD8
FRC_DDR3_NC/DDR2_DQM0
AE8
FRC_REXT
Y11
FRC_TESTPIN
Y19
ACKP/RLV3P/RED[3] W26
ACKM/RLV3N/RED[2] W25
A0P/RLV0P/RED[9] U26
A0M/RLV0N/RED[8] U25
A1P/RLV1P/RED[7] U24
A1M/RLV1N/RED[6] V26
A2P/RLV2P/RED[5] V25
A2M/RLV2N/RED[4] V24
A3P/RLV4P/RED[1] W24
A3M/RLV4N/RED[0] Y26
A4P/RLV5P/GREEN[9] Y25
A4M/RLV5N/GREEN[8] Y24
BCKP/TCON13/GREEN[1] AC26
BCKM/TCON12/GREEN[0] AC25
B0P/RLV6P/GREEN[7] AA26
B0M/RLV6N/GREEN[6] AA25
B1P/RLV7P/GREEN[5] AA24
B1M/RLV7N/GREEN[4] AB26
B2P/RLV8P/GREEN[3] AB25
B2M/RLV8N/GREEN[2] AB24
B3P/TCON11/BLUE[9] AC24
B3M/TCON10/BLUE[8] AD26
B4P/TCON9/BLUE[7] AD25
B4M/TCON8/BLUE[6] AD24
CCKP/LLV3P AD23
CCKM/LLV3N AE23
C0P/LLV0P/BLUE[5] AE26
C0M/LLV0N/BLUE[4] AE25
C1P/LLV1P/BLUE[3] AF26
C1M/LLV1N/BLUE[2] AF25
C2P/LLV2P/BLUE[1] AE24
C2M/LLV2N/BLUE[0] AF24
C3P/LLV4P AF23
C3M/LLV4N AD22
C4P/LLV5P AE22
C4M/LLV5N AF22
DCKP/TCON5 AD19
DCKM/TCON4 AE19
D0P/LLV6P AD21
D0M/LLV6N AE21
D1P/LLV7P AF21
D1M/LLV7N AD20
D2P/LLV8P AE20
D2M/LLV8N AF20
D3P/TCON3 AF19
D3M/TCON2 AD18
D4P/TCON1 AE18
D4M/TCON0 AF18
GPIO0/TCON15/HSYNC/VDD_ODD AB22
GPIO1/TCON14/VSYNC/VDD_EVEN AB23
GPIO2/TCON7/LDE/GCLK4 AC23
GPIO3/TCON6/LCK/GCLK2 AC22
FRC_GPIO0/UART_RX AB16
FRC_GPIO1 AA14
FRC_GPIO3 AC15
FRC_GPIO8 Y16
FRC_GPIO9/UART_TX AC16
FRC_GPIO10 AC14
FRC_I2CM_DA AA16
FRC_I2CM_CK AA15
FRC_I2CS_DA Y10
FRC_I2CS_CK AA11
FRC_PWM0 AB15
FRC_PWM1 AB14
PCM_A[8]
CI_TS_DATA[6]
PCM_A[3] PCM_A[10]
FE_TS_DATA[5]
PCM_A[0]
PCM_D[6]
CI_TS_DATA[0]
PCM_D[2]
PCM_A[7]
PCM_A[9]
FE_TS_DATA[3]
PCM_A[12]
PCM_A[4] PCM_D[5]
CI_TS_DATA[3]
PCM_A[5]
FE_TS_DATA[0]
CI_TS_DATA[5]
PCM_A[2]
PCM_A[13]
FE_TS_DATA[4]
PCM_A[1]
PCM_A[3]
PCM_A[2]
CI_TS_DATA[4]
PCM_D[1]
PCM_A[11]
FE_TS_DATA[2]
PCM_D[4]
PCM_A[7]
PCM_A[6]
PCM_A[0]
CI_TS_DATA[7]
PCM_A[4]
PCM_D[0]
FE_TS_DATA[6]
CI_TS_DATA[1]
CI_TS_DATA[2]
PCM_A[6]
PCM_A[14]
PCM_D[3]
PCM_D[7]
FE_TS_DATA[1]
FE_TS_DATA[7]
PCM_A[5]
PCM_A[1]
FLASH/EEPROM/GPIO
GP2_Saturn7M
DIMMING
URSA degug port
for WIRELESS READY
for SERIAL FLASH
/PF_CE0
H : Serial Flash
L : NAND Flash
/PF_CE1
H : 16 bit
L : 8 bit Boot from SPI flash : 1’b0
Boot from NOR flash : 1’b1
Addr:10101--
I2C
A0’h
<T3 CHIP Config>
(AUD_SCK, AUD_MASTER_CLK, PWM1, PWM0)
EEPROM
<T3 CHIP Config(AUD_LRCH)>
for ETHERNET PHY
HDCP EEPROM
NAND FLASH MEMORY
from CI SLOT
TO SCART1
MIPS_no_EJ_NOR8 : 4’h3 (MIPS as host. No EJ PAD. Byte mode NAND flash.)
MIPS_EJ1_NOR8 : 4’h4 (MIPS as host. EJ use PAD1. Byte mode NAND flash.)
MIPS_EJ2_NOR8 : 4’h5 (MIPS as host. EJ use PAD2. Byte mode NAND flash.)
B51_Secure_no scramble : 4’hb (8051 as host. Internal SPI flash secure boot, no scramble)
B51_Sesure_scramble : 4’hc (8051 as host. Internal SPI flash secure boot with scarmble)
for SYSTEM/HDCP
EEPROM&URSA3
Internal demod out
/External demod in
$0.199
Ver. 1.3
1
LD650 Scan
& MS10 :Region that support MS10(ex:DTV Country)
& DD :Region that support only Dolby Digital(ex:AISA Analog/KOREA)
For EMI Improvement in LED MODELS
S7M REVISION LIST
(Package ASEK) S7M REVISION LIST
(Package SPIL)

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
0.1uFC4058
FRC_LPLL
0.047uFC219
0.047uFC227
FRCVDDC
VDD33
BLM18PG121SN1D
L212
+1.5V_DDR
DDC_SDA_1
SIDEAV_L_IN
0.1uFC4019
0.1uFC4056
0.1uFC4027
VDD33
0.1uF
C291 FRC
0.1uF C4032
10uF
C263
LNA2_CTL
DDC_SCL_2
D2-_HDMI1
33R257
SCART1_Lout
100R203
DSUB_B-
0.047uFC218
COMP2_R_IN
0.1uFC4011
2.2uFC236
AVDD_DDR0
SC1_R-/COMP1_Pr-
VDD33_DVI
BLM18PG121SN1D
L227
33R230
TU_SDA
IF_AGC_SEL
D1-_HDMI1
33R4016
DEMOD_SDA
EPHY_MDIO
SC1_B-/COMP1_Pb-
33
R239
33R282ETHERNET
33
R255
+3.3V_Normal
SC1/COMP1_L_IN
COMP2_Y-
IF_P_MSTAR
100R289
0.1uF C4038
TU_CVBS
AVDD_DDR0
+3.3V_Normal
COMP2_Pb-
68R252
COMP2_L_IN
1000pF
OPT
C264
MODEL_OPT_0
68R231
+1.26V_VDDC
MVREFAVDD_DDR_FRC
BLM18PG121SN1D
L219
AMP_SDA
33R285ETHERNET
0.047uFC222
MODEL_OPT_1
33R237
1/16W 1K 1% R4014
AUD_SCK
BLM18SG700TN1D
L226
HPD1
24MHz
X201
0.1uFC283
0.1uF C4009
0.1uF C4002
33R232
0.047uFC204
PC_R_IN
0.047uFC225
SC1_B+/COMP1_Pb+ 0.047uF
C215
0.047uFC233
AU25
+1.5V_FRC_DDR
VDD_RSDS
COMP2_Y+
33R228
AVDD2P5
AVDD25_PGA
AVDD_DDR0
68
R256
33R253
DDC_SCL_1
DSUB_B+
BT_LOUT
33R244
22
R4024
HP_LOUT
ADC2P5
BT_DP
BLM18SG700TN1D
L225
AVDD_DMPLL
D0-_HDMI2
MODEL_OPT_5
2.2uFC4059
SIDE_USB_DM
22
R4018
FRC
DEMOD_SCL
10K
R4023
2.2uFC244
BLM18PG121SN1D
L213
OPT
0.1uFC4012
0.047uFC205
AVDD_DDR0
2.2uFC238
EPHY_RXD1
SOC_RESET
+3.3V_Normal
AVDD_DMPLL
0.1uFC295
0.1uF C4017
MVREF
0.1uFC4062
0.047uFC211
0.1uFC285
0
NON_EU
R236
D1+_HDMI1
COMP2_Pr-
CEC_REMOTE_S7
EPHY_TXD0
0.1uFC4023
EPHY_TXD1
AV_L_IN
+3.3V_Normal
1000pF
OPT
C203
SC1_CVBS_IN
68R238
BLM18PG121SN1D
L207
1/10W
0
5%
R4027
100R201
DSUB_VSYNC
AVDD_DMPLL
0.047uFC207
AVDD25_PGA
FRC_RESET
33R278ETHERNET
0.047uFC230
DSUB_HSYNC
AVDD_DDR1
D0-_HDMI1
FRC_VDD33_DDR
2.2uFC245
DSUB_G-
0.1uFC286
2.2uF
C237
1000pFC210
COMP2_Pr+
0.1uF
C4015
0.1uFC258
VDD33
AVDD2P5
33R249
BLM18PG121SN1D
L209
10K
R4020
0.1uFC292
0.1uF C294
0.047uFC226
EPHY_REFCLK
AVDD2P5
2.2uFC243
1uF
C253
CK+_HDMI1
SC1_G-/COMP1_Y-
100R288
1K
R4019
0.047uFC221
VDD33
RF_SWITCH_CTL
0.1uFC4007
PC_L_IN
0.047uFC208
TP204
100R204
AU33
+2.5V_Normal
CK-_HDMI1
+2.5V_Normal
+2.5V_Normal
D2+_HDMI1
D0+_HDMI2
0.047uF
C213
0.1uF C4003
68R254
0.047uFC229 AVDD_DDR_FRC
+2.5V_Normal
MODEL_OPT_3
SC1_FB
0.047uFC212
COMP2_Pb+
SIDEAV_CVBS_IN
2.2uF
C247 OPT
AMP_SCL
0.1uFC4006
1000pFC217
AU33
BLM18PG121SN1D
L222
47R4002
0.1uFC280
33R245
CK-_HDMI2
SPDIF_OUT
EPHY_RXD0
10K
R4006
0.1uFC4013
10K
R4026
SC1_ID
BT_ON/OFF
BLM18PG121SN1D
FRC
L214
+1.26V_VDDC
100R202
SC1_SOG_IN
BLM18PG121SN1D
L217
FRC_AVDD
D2-_HDMI2
68R258
33R283ETHERNET
BLM18PG121SN1D
L210
FRC
0.047uFC206
0.047uFC232
DTV/MNT_VOUT
0.1uF C290
0.1uFC4026
COMP2_DET
TU_SIF
0.047uFC231
CK+_HDMI2
0.047uFC4057
TU_SCL
TP206
0.1uF C4036
68R233
AUD_LRCH
BLM18PG121SN1D
L221
FRC
VDD33
MIU1VDDC
0.1uF
C4004 FRC
D2+_HDMI2
+1.26V_VDDC
ADC2P5
AUD_LRCK
0.1uF C4008
0.1uF
C298 FRC
0R243
1/16W 1K 1% R4015
EPHY_CRS_DV
AV_R_IN
BT_DM
D1+_HDMI2
0.047uF
C216
0.1uFC4041
0.1uF C297
DSUB_R-
1M
R287
SC1_G+/COMP1_Y+
DSUB_G+
100R296
D0+_HDMI1
0.1uF
C256
68R242
0.047uF
C214
33R284ETHERNET
EPHY_EN
0.1uFC4024
2.2uF
OPT
C235
1/10W
0
5%
R4022
BLM18PG121SN1D
L215
HPD2
0.1uF C4028
2.2uF
OPT
C234
IR
0.022uF
16V
C4065
IF_AGC_MAIN
0.1uFC257
AUD_MASTER_CLK
0.1uFC296
2.2uF
C239
FRC_AVDD
33R246
TP205
VDD33_DVI
33R241
47R4003
SCART1_Rout
100R298 OPT
FRC_VDD33_DDR
0.1uF
C4064
IF_N_MSTAR
0.1uFC4014
33R248
DSUB_R+
HP_ROUT
AVDD_DDR1
33R251
0R234
2.2uF
C242
+2.5V_Normal
1000pFC224
0.047uFC209
0.1uFC251
AVDD2P5
SIDEAV_R_IN
0.1uFC4016
33R280ETHERNET
2.2uF
C246 OPT
0.047uFC223
SIDE_USB_DP
MODEL_OPT_2
2.2uF
C4060
SC1_R+/COMP1_Pr+
TP201
33R250
22
R4025
BLM18PG121SN1D
L211
68
R240
FRC_LPLL
AV_CVBS_IN
DDC_SDA_2
0.1uFC250
0.047uFC220
68R229
+1.26V_VDDC
TP202
AU25
VDD_RSDS
10K
R4017
OPT
0.1uFC277
BLM18PG121SN1D
L206
0.1uFC299
BLM18PG121SN1D
L204
FRCVDDC
EPHY_MDC
0.1uFC4040
TP203
D1-_HDMI2
0.1uF
C288
VDD33
SC1/COMP1_R_IN
0.1uF
C4010 FRC
BLM18SG121TN1D
L202
BLM18SG121TN1D
L223
0.1uF
C4005
TP207
TP208
TP209
TP210
D1+_HDMI3
D0-_HDMI3
HPD3
CK+_HDMI3
CK-_HDMI3
D1-_HDMI3
DDC_SCL_3
D2+_HDMI3
D0+_HDMI3
DDC_SDA_3
D2-_HDMI3
D1-_HDMI4
D2+_HDMI4
HPD4
DDC_SCL_4
D0+_HDMI4
D0-_HDMI4
DDC_SDA_4
D2-_HDMI4
CK+_HDMI4
D1+_HDMI4
CK-_HDMI4
10uFC275 10uFC276
10uF
C279 FRC
10uF
C278
10uF
C282 FRC
10uF
C281 10uFC284
10uF
C287
10uFC289 10uFC293
10uFC4001
10uF
C4018
10uF
C4022
10uFC4061
10uFC4063
4.7uF
C249
1uFC4045
0.1uFC4020
0.1uFC4025
0.1uFC4031
MIU1VDDC
VDD33
NEC_SCL
NEC_SDA
0OPT
R4029
0OPT
R4028
AMP_SCL
AMP_SDA
CHB_CVBS_IN
0
R4032
0
R4033
22R292
DEMOD_OPT
22R291
DEMOD_OPT
AV_CVBS_IN2
AV_CVBS_IN2 TP211
1K
NO_FRC
R227
1K
LVDS
R212
1K
FRC
R226
1K
DDR_256MB
R209
1K
MINI_LVDS
R211
1K
HD
R207 1K
FHD
R206
1K
DDR_512MB
R208
MODEL_OPT_4
10uFC4066
BLM18SG700TN1D
L228
MODEL_OPT_5
MODEL_OPT_4
1K
100/120Hz LVDS
R2941K
50/60Hz LVDS
R297
1K
GIP
R2951K
NON_GIP
R293
MIU0VDDC
MIU0VDDC
+1.26V_VDDC
10uFC228
0.1uF
FRC
C240
0.1uF
C241
0.1uF C4042
0.1uF C4046
0.1uFC4043 0.1uFC4044
27pFC261
27pFC262
+3.3V_Normal
10K
R205
FRC
3D_POWER_EN 100
3D
R210
/3D_FPGA_RESET 100
3D
R213
4.7uF C268 4.7uF C272
5.6uHL205
CM2012F5R6KT
5.6uH
L203
CM2012F5R6KT
MODEL_OPT_6
1K
LCD
R215 1K
OLED
R214
LGE107D (S7M Divx_Non RM)
IC101
S7M_DIVX & MS10
A_RXCP
F1
A_RXCN
F2
A_RX0P
G2
A_RX0N
G3
A_RX1P
H3
A_RX1N
G1
A_RX2P
H1
A_RX2N
H2
DDCDA_DA/GPIO24
F5
DDCDA_CK/GPIO23
F4
HOTPLUGA/GPIO19
E6
B_RXCP
D3
B_RXCN
C1
B_RX0P
D1
B_RX0N
D2
B_RX1P
E2
B_RX1N
E3
B_RX2P
F3
B_RX2N
E1
DDCDB_DA/GPIO26
D4
DDCDB_CK/GPIO25
E4
HOTPLUGB/GPIO20
D5
C_RXCP
AA2
C_RXCN
AA1
C_RX0P
AB1
C_RX0N
AA3
C_RX1P
AB3
C_RX1N
AB2
C_RX2P
AC2
C_RX2N
AC1
DDCDC_DA/GPIO28
AB4
DDCDC_CK/GPIO27
AA4
HOTPLUGC/GPIO21
AC3
D_RXCP
A2
D_RXCN
A3
D_RX0P
B3
D_RX0N
A1
D_RX1P
B1
D_RX1N
B2
D_RX2P
C2
D_RX2N
C3
DDCDD_DA/GPIO30
B4
DDCDD_CK/GPIO29
C4
HOTPLUGD/GPIO22
E5
CEC/GPIO5
D6
HSYNC0
G5
VSYNC0
G6
RIN0P
K1
RIN0M
L3
GIN0P
K3
GIN0M
K2
BIN0P
J3
BIN0M
J2
SOGIN0
J1
HSYNC1
G4
VSYNC1
H6
RIN1P
K5
RIN1M
K4
GIN1P
J4
GIN1M
K6
BIN1P
H4
BIN1M
J6
SOGIN1
J5
HSYNC2
H5
RIN2P
N3
RIN2M
N2
GIN2P
M2
GIN2M
M1
BIN2P
L2
BIN2M
L1
SOGIN2
M3
CVBS0P
N4
CVBS1P
N6
CVBS2P
L4
CVBS3P
L5
CVBS4P
L6
CVBS5P
M4
CVBS6P
M5
CVBS7P
K7
CVBS_OUT1
M6
CVBS_OUT2
M7
VCOM0
N5
VIFP W2
VIFM W1
IP V2
IM V1
SSIF/SIFP Y2
SSIF/SIFM Y1
QP U3
QM V3
IFAGC Y5
RF_TAGC Y4
TGPIO0/UPGAIN U1
TGPIO1/DNGAIN U2
TGPIO2/I2C_CLK R3
TGPIO3/I2C_SDA T3
XTALIN T2
XTALOUT T1
SPDIF_IN/GPIO177 G14
SPDIF_OUT/GPIO178 G13
DM_P0 B7
DP_P0 A7
DM_P1 AF17
DP_P1 AE17
I2S_IN_BCK/GPIO175 F14
I2S_IN_SD/GPIO176 F13
I2S_IN_WS/GPIO174 F15
I2S_OUT_BCK/GPIO181 D20
I2S_OUT_MCK/GPIO179 E20
I2S_OUT_SD/GPIO182 D19
I2S_OUT_SD1/GPIO183 F18
I2S_OUT_SD2/GPIO184 E18
I2S_OUT_SD3/GPIO185 D18
I2S_OUT_WS/GPIO180 E19
LINE_IN_0L N1
LINE_IN_0R P3
LINE_IN_1L P1
LINE_IN_1R P2
LINE_IN_2L P4
LINE_IN_2R P5
LINE_IN_3L R6
LINE_IN_3R T6
LINE_IN_4L U5
LINE_IN_4R V5
LINE_IN_5L U6
LINE_IN_5R V6
LINE_OUT_0L U4
LINE_OUT_2L W3
LINE_OUT_3L W4
LINE_OUT_0R V4
LINE_OUT_2R Y3
LINE_OUT_3R W5
MIC_DET_IN R4
MICCM T5
MICIN R5
AUCOM T4
VRM P7
VAG R7
VRP P6
HP_OUT_1L R1
HP_OUT_1R R2
ET_RXD0 E21
ET_TXD0 E22
ET_RXD1 D21
ET_TXD1 F21
ET_REFCLK E23
ET_TX_EN D22
ET_MDC F22
ET_MDIO D23
ET_CRS F23
AVLINK F8
IRINT G8
TESTPIN K8
RESET A4
U3_RESET Y17
LGE107D (S7M Divx_Non RM)
IC101
S7M_DIVX & MS10
VDDC_1
H11
VDDC_2
H12
VDDC_3
H13
VDDC_4
H14
VDDC_5
H15
VDDC_6
J12
VDDC_7
J13
VDDC_8
J14
VDDC_9
J15
VDDC_10
J16
VDDC_11
L18
A_DVDD
H16
B_DVDD
K19
FRC_VDDC_0
L19
FRC_VDDC_1
M18
FRC_VDDC_2
M19
FRC_VDDC_3
N18
FRC_VDDC_4
N19
FRC_VDDC_5
N20
FRC_VDDC_6
P18
FRC_VDDC_7
P19
FRC_VDDC_8
P20
U3_DVDD_DDR
Y12
AVDD1P2
J11
DVDD_NODIE
L7
AVDD2P5_ADC_1
H7
AVDD2P5_ADC_2
J7
AVDD25_REF
J8
AVDD_AU25
L8
PVDD_1
W15
PVDD_2
Y15
AVDD25_PGA
U8
AVDD_NODIE
M8
AVDD_DVI_1
N9
AVDD_DVI_2
P9
AVDD3P3_CVBS
N8
AVDD_DMPLL
P8
AVDD_AU33
T7
AVDD_EAR33
U7
AVDD33_T
T9
VDDP_1
R8
VDDP_2
R9
VDDP_3
T8
FRC_VD33_2_1
V20
FRC_VD33_2_2
W20
FRC_AVDD_RSDS_1
U19
FRC_AVDD_RSDS_2
U20
FRC_AVDD_RSDS_3
V19
FRC_AVDD
W19
FRC_AVDD_LPLL
U18
FRC_AVDD_MPLL
T20
FRC_VDD33_DDR
Y14
AVDD_MEMPLL
R19
FRC_AVDD_MEMPLL
W14
AVDD_DDR0_D_1
D15
AVDD_DDR0_D_2
D16
AVDD_DDR0_D_3
E15
AVDD_DDR0_D_4
E16
AVDD_DDR0_C
E17
AVDD_DDR1_D_1
F16
AVDD_DDR1_D_2
F17
AVDD_DDR1_D_3
G16
AVDD_DDR1_D_4
G17
AVDD_DDR1_C
H17
FRC_AVDD_DDR_D_1
AB11
FRC_AVDD_DDR_D_2
AB12
FRC_AVDD_DDR_D_3
AC11
FRC_AVDD_DDR_D_4
AC12
FRC_AVDD_DDR_C
AA12
MVREF
G15
NC_1
Y7
NC_2
Y8
GND_1 G18
GND_2 H9
GND_3 H10
GND_4 H18
GND_5 H19
GND_6 J10
GND_7 J17
GND_8 J18
GND_9 J19
GND_10 K9
GND_11 K10
GND_12 K11
GND_13 K12
GND_14 K13
GND_15 K14
GND_16 K15
GND_17 K16
GND_18 K17
GND_19 K18
GND_20 L9
GND_21 L10
GND_22 L11
GND_23 L12
GND_24 L13
GND_25 L14
GND_26 L15
GND_27 L16
GND_28 L17
GND_29 M9
GND_30 M10
GND_31 M11
GND_32 M12
GND_33 M13
GND_34 M14
GND_35 M15
GND_36 M16
GND_37 M17
GND_38 N10
GND_39 N11
GND_40 N12
GND_41 N13
GND_42 N14
GND_43 N15
GND_44 N16
GND_45 N17
GND_46 P10
GND_47 P11
GND_48 P12
GND_49 P13
GND_50 P14
GND_51 P15
GND_52 P16
GND_53 P17
GND_54 R10
GND_55 R11
GND_56 R12
GND_57 R13
GND_58 R14
GND_59 R15
GND_60 R16
GND_61 R17
GND_62 R18
GND_63 T10
GND_64 T11
GND_65 T12
GND_66 T13
GND_67 T14
GND_68 T15
GND_69 T16
GND_70 T17
GND_71 T18
GND_72 T19
GND_73 U10
GND_74 U11
GND_75 U12
GND_76 U13
GND_77 U14
GND_78 U15
GND_79 U16
GND_80 U17
GND_81 V7
GND_82 V8
GND_83 V9
GND_84 V10
GND_85 V11
GND_86 V12
GND_87 V13
GND_88 V14
GND_89 V15
GND_90 V16
GND_91 V17
GND_92 V18
GND_93 W7
GND_94 W8
GND_95 W9
GND_96 W10
GND_97 W11
GND_98 W12
GND_99 W13
GND_100 W16
GND_101 W17
GND_102 W18
GND_103 Y13
GND_104 Y18
GND_105 AA13
GND_106 AB13
GND_107 AC13
GND_FU J9
PGA_VCOM U9
GND_108 D17
GND_109 H23
GND_110 AF13
GP2_Saturn7M
MAIN_2
ANALOG SIF
RMII For Ethernet
RSDS Power OPT
FRC
I2S_I/F
PIN NAME
DSUB
Normal 2.5V
Close to MSTAR
MODEL OPTION
FRC_LPLL:13mA
Normal Power 3.3V
DTV_IF
AVDD_DMPLL/AVDD_NODIE:7.362mA
FRC_MPLL:4mA
AU25:10mA
Close to MSTAR
AVDD_MEMPLL:24mA
F7
VDD33_DVI:163mA
FHD
SCART1_RGB/COMP1
G19
AVDD2P5/ADC2P5:162mA
MODEL_OPT_3
AVDD25_PGA:13mA
C5
VDDC : 2026mA
AVDD_DDR0:55mA
H/P OUT
VDDC 1.26V
PIN NO.
NO FRC
MODEL_OPT_0
CVBS In/OUT
AUDIO OUT
TU/DEMOD_I2C
FRC_AVDD:60mA
HD
AUDIO IN
VDD_RSDS:88mA
MODEL_OPT_1
FRC_VDD33_DDR:50mA
COMP2
DDR_512MB
Close to MSTAR
SIDE USB
DDR3 1.5V
VDD33_T/VDDP/U3_VD33_2:47mA
B6
MODEL OPTION
HDMI
AVDD_DDR_FRC:55mA
LOW
AU33:31mA
DDR_256MB
HIGH
MODEL_OPT_2
B/T USB
Close to MSTAR
RSDS Power OPT
AVDD_DDR1:55mA
Ver. 1.4
2
MINI LVDS LVDS
MODEL_OPT_4
MODEL_OPT_5
100/120Hz LVDS
E18
GIP NON_GIPD18
50/60Hz LVDS
MODEL_OPT_6 F9 LCDOLED
NO_FRC : LOW LOW
U3_INTERNAL : HIGH LOW
U3_EXTERNAL : HIGH HIGH
PWIZ TCON with LG FRC : HIGH HIGH
OPT_0 OPT_4

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
RXD3-
RXA4+
C-MODT
RXB4+
C-TMA12
C-TMBA2
RXC4+
C-TMODT
C-TMDQU7
0.1uF
C319
C-MA6
C-MDQU5
C-TMCK
C-MA9
C-MA3
C-MDQSU
820
R317
0.1uF
C322
0.1uF
C313
C-MDQU1
C-TMA4
C-MA12
C-TMA3
C-MDQSUB
C-TMA6
FRC_CONF1
10uF
10V
C324
C-TMDQU4
C-TMA1
VCC1.5V_U3_DDR
RXA0-
TP301
0.1uF
C323
C-TMDQL4
RXACK+
C-MA1
C-MA12
RXA0+
C-MCK
UART_FRC_RX
C-TMBA2
RXCCK-
1K
R323
0.1uF
C310
C-MDQL1
UART_FRC_TX
0.1uF
C306
C-TMDQL7
0.1uF
C317
C-MDQU4
C-TMCKB
C-MDMU
C-MCKE
0.1uF
C320
RXB0+
C-MA8
C-TMA6
RXB1+
150
OPT
R306
C-TMA4
0.1uF
C302
C-MDQL1
C-TMCKE
C-MDQSL
C-MA10
RXC3+
FRC_PWM0
C-TMODT
C-TMDML
C-MDQSLB
C-TMDQSLB
C-MA11
C-TMDMU
240
1%
R303
C-TMCASB
FRC_CONF0
RXD2-
C-TMA12
C-TMA7
C-TMCKB
C-MA6
VCC1.5V_U3_DDR
C-TMDQSLB
C-TMA1
0.1uF
C318
RXD1+
RXBCK-
GVDD_EVEN
0R300 OPT
C-TMBA1
FRC_PWM1
C-TMDQU3
C-TMDQL4
RXCCK+
TP302
0.1uF
C316
RXC1-
C-TMA0
C-MDQL7
RXB2-
C-TMDQU3
C-MRASB
+3.3V_Normal
C-MDMU
C-MBA0
C-MDQU7
C-TMWEB
C-MDQU2
GCLK2
C-MCKB
C-TMA11
1K 1%
R305
1K 1%
R301
C-TMA2
C-TMDQU7
C-TMDQL2 GCLK4
I2C_SDA
C-MDQU2
RXA3-
C-TMDQU6
C-TMA5
C-MA10
0.1uF
16V
C325
RXC3-
RXA1+
RXB1-
C-TMCKE
C-MDQSU
C-MA7
C-TMRESETB
C-MBA0
C-MVREFDQ
C-MCKB
RXB4-
C-MDQL0
C-TMDQU2
C-TMDQL3
1K
OPT R322
C-TMBA1
C-TMDQSUB
1KR318
C-MDQU3
C-MA3
C-MA0
C-TMDQSU
C-TMDQSU
C-TMA0
C-MRESETB
C-MDQU4
C-MDQL5
1000pF
C314
C-TMDML
RXC2+
RXC1+
C-TMDQL1
C-MRASB
C-TMDQL7
RXD3+
RXD4+
C-TMA2
1K 1%
R302
C-TMRASB
C-MDQL3
0.1uF
C305
C-TMCASB
C-MDQU6
C-MDQSUB
C-TMDQU5
C-MCASB
C-MDQU1
C-MA5
RXB3+
RXDCK-
RXD0+
C-TMA7
RXC4-
C-TMDQL1
C-MVREFCA
1K
OPT R319
RXC2-
C-MDQSL
C-TMCK
C-MDQL6 C-TMDQL6
RXBCK+
RXB2+
C-MDQL4
C-MDQL4
C-TMDQL0
C-MDQU6
C-TMRASB
C-MA0
VCC1.5V_U3_DDR
C-TMA9
C-MA2
C-MVREFCA
C-TMDQU5
C-MA11
C-TMDQU4
C-TMRESETB
RXD0-
VCC1.5V_U3_DDR
0.1uF
C311
C-MODT
C-MDQU5
0.1uF
C315
C-MA4
C-MDQL5
C-TMDQL2
RXA2-
C-TMDQL5
C-MBA1
C-TMDQU0
C-TMA9
1K 1%
R304
C-TMDQU2
C-MDQU0
RXDCK+
C-MDQU3
DPM_A
C-MDQSLB
C-TMA10
C-MA1
C-MBA2
C-MDQL2
C-MDQL6
0.1uF
C309
RXB0-
RXA4-
C-MA4
C-TMDQL3
C-MA2
0.1uF
C321
C-MBA2
C-TMBA0
RXA2+
C-TMA11
C-TMA8
+1.5V_FRC_DDR
RXD2+
RXD4-
C-MA7
0.1uF
C303
C-MA8
FRC_CONF0
C-MDQL3
C-MWEB
RXC0+
C-TMWEB
0.1uF
C312
RXA1-
RXC0-
C-MCASB
C-MDQU7
FRC_CONF1
C-TMA8
10uF C301
1000pF
C304
C-MDQL0
C-TMA10
C-MVREFDQ
RXA3+
C-MDQL2
L301
C-MA5
C-TMDQU0
C-MCK
C-MDQU0
C-TMDQL0
1K
R320
C-MA9
RXD1-
RXB3-
C-MCKE
C-TMDQU1
1K
OPT R321
C-TMDQL6
FRC_PWM1
C-TMBA0
RXACK-
C-MDML
GVDD_ODD
I2C_SCL
C-TMA3
C-MRESETB
0.1uF
C307
C-TMDQSL
C-TMDQU1
C-TMDQL5
C-TMA5
C-TMDQU6
C-TMDMU
1K
OPT R324
1KR325
C-TMDQSL
C-MBA1
C-TMDQSUB
VCC1.5V_U3_DDR
FRC_PWM0
C-MWEB
C-MDML
C-MDQL7
0.1uF
C308
V_SYNC
0
R332
VCC1.5V_U3_DDR
10K
R333
10
R314
10
R313
10
R310
10
R308
10
R315
10
R311
10
R316
10
R307
10
R312
10
R309
10
AR302
10
AR309
10
AR303
10
AR306
10
AR305
10
AR301
10
AR307
10
AR308
10
AR304
FRC_SDA
22
R335
OPT
22R334
OPT
FRC_SCL
0
MINI_LVDS
R336
22
R326 FRC
22
R331 FRC
H5TQ1G63BFR-12C
IC301
FRC_DDR_1600
A0 N3
A1 P7
A2 P3
A3 N2
A4 P8
A5 P2
A6 R8
A7 R2
A8 T8
A9 R3
A10/AP L7
A11 R7
A12/BC N7
A13 T3
A15 M7
BA0 M2
BA1 N8
BA2 M3
CK J7
CK K7
CKE K9
CS L2
ODT K1
RAS J3
CAS K3
WE L3
RESET T2
DQSL F3
DQSL G3
DQSU C7
DQSU B7
DML E7
DMU D3
DQL0 E3
DQL1 F7
DQL2 F2
DQL3 F8
DQL4 H3
DQL5 H8
DQL6 G2
DQL7 H7
DQU0 D7
DQU1 C3
DQU2 C8
DQU3 C2
DQU4 A7
DQU5 A2
DQU6 B8
DQU7 A3
VREFCA
M8
VREFDQ
H1
ZQ
L8
VDD_1
B2
VDD_2
D9
VDD_3
G7
VDD_4
K2
VDD_5
K8
VDD_6
N1
VDD_7
N9
VDD_8
R1
VDD_9
R9
VDDQ_1
A1
VDDQ_2
A8
VDDQ_3
C1
VDDQ_4
C9
VDDQ_5
D2
VDDQ_6
E9
VDDQ_7
F1
VDDQ_8
H2
VDDQ_9
H9
NC_1
J1
NC_2
J9
NC_3
L1
NC_4
L9
NC_6
T7
VSS_1
A9
VSS_2
B3
VSS_3
E1
VSS_4
G8
VSS_5
J2
VSS_6
J8
VSS_7
M1
VSS_8
M9
VSS_9
P1
VSS_10
P9
VSS_11
T1
VSS_12
T9
VSSQ_1
B1
VSSQ_2
B9
VSSQ_3
D1
VSSQ_4
D8
VSSQ_5
E2
VSSQ_6
E8
VSSQ_7
F9
VSSQ_8
G1
VSSQ_9
G9
0R327
0
R328
LGE107D (S7M Divx_Non RM)
IC101
S7M_DIVX & MS10
FRC_DDR3_A0/DDR2_NC
AE1
FRC_DDR3_A1/DDR2_A6
AF16
FRC_DDR3_A2/DDR2_A7
AF1
FRC_DDR3_A3/DDR2_A1
AE3
FRC_DDR3_A4/DDR2_CASZ
AD14
FRC_DDR3_A5/DDR2_A10
AD3
FRC_DDR3_A6/DDR2_A0
AF15
FRC_DDR3_A7/DDR2_A5
AF2
FRC_DDR3_A8/DDR2_A2
AE15
FRC_DDR3_A9/DDR2_A9
AD2
FRC_DDR3_A10/DDR2_A11
AD16
FRC_DDR3_A11/DDR2_A4
AD15
FRC_DDR3_A12/DDR2_A8
AE16
FRC_DDR3_BA0/DDR2_BA2
AF3
FRC_DDR3_BA1/DDR2_ODT
AF14
FRC_DDR3_BA2/DDR2_A12
AD1
FRC_DDR3_MCLK/DDR2_MCLK
AD13
FRC_DDR3_CKE/DDR2_RASZ
AE14
FRC_DDR3_MCLKZ/DDR2_MCLKZ
AE13
FRC_DDR3_ODT/DDR2_BA1
AE4
FRC_DDR3_RASZ/DDR2_WEZ
AD5
FRC_DDR3_CASZ/DDR2_CKE
AF4
FRC_DDR3_WEZ/DDR2_BA0
AD4
FRC_DDR3_RESETB/DDR2_A3
AE2
FRC_DDR3_DQSL/DDR2_DQS0
AF8
FRC_DDR3_DQSLB/DDR2_DQSB0
AD9
FRC_DDR3_DQSU/DDR2_DQS1
AE9
FRC_DDR3_DQSUB/DDR2_DQSB1
AF9
FRC_DDR3_DML/DDR2_DQ7
AE11
FRC_DDR3_DMU/DDR2_DQ11
AF6
FRC_DDR3_DQL0/DDR2_DQ6
AE6
FRC_DDR3_DQL1/DDR2_DQ0
AF11
FRC_DDR3_DQL2/DDR2_DQ1
AD6
FRC_DDR3_DQL3/DDR2_DQ2
AD12
FRC_DDR3_DQL4/DDR2_DQ4
AE5
FRC_DDR3_DQL5/DDR2_NC
AF12
FRC_DDR3_DQL6/DDR2_DQ3
AF5
FRC_DDR3_DQL7/DDR2_DQ5
AE12
FRC_DDR3_DQU0/DDR2_DQ8
AE10
FRC_DDR3_DQU1/DDR2_DQ14
AF7
FRC_DDR3_DQU2/DDR2_DQ13
AD11
FRC_DDR3_DQU3/DDR2_DQ12
AD7
FRC_DDR3_DQU4/DDR2_DQ15
AD10
FRC_DDR3_DQU5/DDR2_DQ9
AE7
FRC_DDR3_DQU6/DDR2_DQ10
AF10
FRC_DDR3_DQU7/DDR2_DQM1
AD8
FRC_DDR3_NC/DDR2_DQM0
AE8
FRC_REXT
Y11
FRC_TESTPIN
Y19
ACKP/RLV3P/RED[3] W26
ACKM/RLV3N/RED[2] W25
A0P/RLV0P/RED[9] U26
A0M/RLV0N/RED[8] U25
A1P/RLV1P/RED[7] U24
A1M/RLV1N/RED[6] V26
A2P/RLV2P/RED[5] V25
A2M/RLV2N/RED[4] V24
A3P/RLV4P/RED[1] W24
A3M/RLV4N/RED[0] Y26
A4P/RLV5P/GREEN[9] Y25
A4M/RLV5N/GREEN[8] Y24
BCKP/TCON13/GREEN[1] AC26
BCKM/TCON12/GREEN[0] AC25
B0P/RLV6P/GREEN[7] AA26
B0M/RLV6N/GREEN[6] AA25
B1P/RLV7P/GREEN[5] AA24
B1M/RLV7N/GREEN[4] AB26
B2P/RLV8P/GREEN[3] AB25
B2M/RLV8N/GREEN[2] AB24
B3P/TCON11/BLUE[9] AC24
B3M/TCON10/BLUE[8] AD26
B4P/TCON9/BLUE[7] AD25
B4M/TCON8/BLUE[6] AD24
CCKP/LLV3P AD23
CCKM/LLV3N AE23
C0P/LLV0P/BLUE[5] AE26
C0M/LLV0N/BLUE[4] AE25
C1P/LLV1P/BLUE[3] AF26
C1M/LLV1N/BLUE[2] AF25
C2P/LLV2P/BLUE[1] AE24
C2M/LLV2N/BLUE[0] AF24
C3P/LLV4P AF23
C3M/LLV4N AD22
C4P/LLV5P AE22
C4M/LLV5N AF22
DCKP/TCON5 AD19
DCKM/TCON4 AE19
D0P/LLV6P AD21
D0M/LLV6N AE21
D1P/LLV7P AF21
D1M/LLV7N AD20
D2P/LLV8P AE20
D2M/LLV8N AF20
D3P/TCON3 AF19
D3M/TCON2 AD18
D4P/TCON1 AE18
D4M/TCON0 AF18
GPIO0/TCON15/HSYNC/VDD_ODD AB22
GPIO1/TCON14/VSYNC/VDD_EVEN AB23
GPIO2/TCON7/LDE/GCLK4 AC23
GPIO3/TCON6/LCK/GCLK2 AC22
FRC_GPIO0/UART_RX AB16
FRC_GPIO1 AA14
FRC_GPIO3 AC15
FRC_GPIO8 Y16
FRC_GPIO9/UART_TX AC16
FRC_GPIO10 AC14
FRC_I2CM_DA AA16
FRC_I2CM_CK AA15
FRC_I2CS_DA Y10
FRC_I2CS_CK AA11
FRC_PWM0 AB15
FRC_PWM1 AB14
H5TQ1G63BFR-H9C
IC301-*1
FRC_DDR_1333_HYNIX
A0
N3
A1
P7
A2
P3
A3
N2
A4
P8
A5
P2
A6
R8
A7
R2
A8
T8
A9
R3
A10/AP
L7
A11
R7
A12/BC
N7
A13
T3
A15
M7
BA0
M2
BA1
N8
BA2
M3
CK
J7
CK
K7
CKE
K9
CS
L2
ODT
K1
RAS
J3
CAS
K3
WE
L3
RESET
T2
DQSL
F3
DQSL
G3
DQSU
C7
DQSU
B7
DML
E7
DMU
D3
DQL0
E3
DQL1
F7
DQL2
F2
DQL3
F8
DQL4
H3
DQL5
H8
DQL6
G2
DQL7
H7
DQU0
D7
DQU1
C3
DQU2
C8
DQU3
C2
DQU4
A7
DQU5
A2
DQU6
B8
DQU7
A3
VREFCA M8
VREFDQ H1
ZQ L8
VDD_1 B2
VDD_2 D9
VDD_3 G7
VDD_4 K2
VDD_5 K8
VDD_6 N1
VDD_7 N9
VDD_8 R1
VDD_9 R9
VDDQ_1 A1
VDDQ_2 A8
VDDQ_3 C1
VDDQ_4 C9
VDDQ_5 D2
VDDQ_6 E9
VDDQ_7 F1
VDDQ_8 H2
VDDQ_9 H9
NC_1 J1
NC_2 J9
NC_3 L1
NC_4 L9
NC_6 T7
VSS_1 A9
VSS_2 B3
VSS_3 E1
VSS_4 G8
VSS_5 J2
VSS_6 J8
VSS_7 M1
VSS_8 M9
VSS_9 P1
VSS_10 P9
VSS_11 T1
VSS_12 T9
VSSQ_1 B1
VSSQ_2 B9
VSSQ_3 D1
VSSQ_4 D8
VSSQ_5 E2
VSSQ_6 E8
VSSQ_7 F9
VSSQ_8 G1
VSSQ_9 G9
K4B1G1646E-HCH9000
IC301-*2
FRC_DDR_1333_SS
A0
N3
A1
P7
A2
P3
A3
N2
A4
P8
A5
P2
A6
R8
A7
R2
A8
T8
A9
R3
A10/AP
L7
A11
R7
A12/BC
N7
A13
T3
NC_5
M7
BA0
M2
BA1
N8
BA2
M3
CK
J7
CK
K7
CKE
K9
CS
L2
ODT
K1
RAS
J3
CAS
K3
WE
L3
RESET
T2
DQSL
F3
DQSL
G3
DQSU
C7
DQSU
B7
DML
E7
DMU
D3
DQL0
E3
DQL1
F7
DQL2
F2
DQL3
F8
DQL4
H3
DQL5
H8
DQL6
G2
DQL7
H7
DQU0
D7
DQU1
C3
DQU2
C8
DQU3
C2
DQU4
A7
DQU5
A2
DQU6
B8
DQU7
A3
VREFCA M8
VREFDQ H1
ZQ L8
VDD_1 B2
VDD_2 D9
VDD_3 G7
VDD_4 K2
VDD_5 K8
VDD_6 N1
VDD_7 N9
VDD_8 R1
VDD_9 R9
VDDQ_1 A1
VDDQ_2 A8
VDDQ_3 C1
VDDQ_4 C9
VDDQ_5 D2
VDDQ_6 E9
VDDQ_7 F1
VDDQ_8 H2
VDDQ_9 H9
NC_1 J1
NC_2 J9
NC_3 L1
NC_4 L9
NC_6 T7
VSS_1 A9
VSS_2 B3
VSS_3 E1
VSS_4 G8
VSS_5 J2
VSS_6 J8
VSS_7 M1
VSS_8 M9
VSS_9 P1
VSS_10 P9
VSS_11 T1
VSS_12 T9
VSSQ_1 B1
VSSQ_2 B9
VSSQ_3 D1
VSSQ_4 D8
VSSQ_5 E2
VSSQ_6 E8
VSSQ_7 F9
VSSQ_8 G1
VSSQ_9 G9
NT5CB64M16AP-CG
IC301-*3
FRC_DDR_1333_NY
A0
N3
A1
P7
A2
P3
A3
N2
A4
P8
A5
P2
A6
R8
A7
R2
A8
T8
A9
R3
A10/AP
L7
A11
R7
A12
N7
NC_6
T3
NC_5
M7
BA0
M2
BA1
N8
BA2
M3
CK
J7
CK
K7
CKE
K9
CS
L2
ODT
K1
RAS
J3
CAS
K3
WE
L3
RESET
T2
DQSL
F3
DQSL
G3
DQSU
C7
DQSU
B7
DML
E7
DMU
D3
DQL0
E3
DQL1
F7
DQL2
F2
DQL3
F8
DQL4
H3
DQL5
H8
DQL6
G2
DQL7
H7
DQU0
D7
DQU1
C3
DQU2
C8
DQU3
C2
DQU4
A7
DQU5
A2
DQU6
B8
DQU7
A3
VREFCA M8
VREFDQ H1
ZQ L8
VDD_1 B2
VDD_2 D9
VDD_3 G7
VDD_4 K2
VDD_5 K8
VDD_6 N1
VDD_7 N9
VDD_8 R1
VDD_9 R9
VDDQ_1 A1
VDDQ_2 A8
VDDQ_3 C1
VDDQ_4 C9
VDDQ_5 D2
VDDQ_6 E9
VDDQ_7 F1
VDDQ_8 H2
VDDQ_9 H9
NC_1 J1
NC_2 J9
NC_3 L1
NC_4 L9
NC_7 T7
VSS_1 A9
VSS_2 B3
VSS_3 E1
VSS_4 G8
VSS_5 J2
VSS_6 J8
VSS_7 M1
VSS_8 M9
VSS_9 P1
VSS_10 P9
VSS_11 T1
VSS_12 T9
VSSQ_1 B1
VSSQ_2 B9
VSSQ_3 D1
VSSQ_4 D8
VSSQ_5 E2
VSSQ_6 E8
VSSQ_7 F9
VSSQ_8 G1
VSSQ_9 G9
DDR3(FRC)
GP2_Saturn7M Ver. 1.4
3’d5 : boot from internal SRAM
3’d6 : boot from EEPROM
3’d7 : boot form SPI flash
CLose to Saturn7M IC
HIGH : I2C ADR = B8
LOW : I2C ADR = B4
(FRC_CONF1,FRC_PWM1, FRC_PWM0)
DDR3 1.5V By CAP - Place these Caps near Memory
CLose to DDR3
<U3 CHIP Config>
Close to DDR Power Pin
(FRC_CONF0)
3

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
0.1uF
50V
C467
+24V +3.5V_ST
10K
R411
L417
100pF
50V
OPT
C482
22uF
10V
C472
NON_EU
4.7K
1%
R461
100uF
16V
C401
Non_Commercial
+3.5V_ST
100
R415
POWER_18_INV_CTL
10K
R456
1/10W
10
1%
R452
+1.5V_DDR
+2.5V_Normal
10K
R421
1/16W 5.1K 5% R447
PD_+12V
0R441
MP2212DN
IC403
NON_FRC
3
IN
2
GND
4
BS
1
FB
5VCC
6SW_1
7SW_2
8EN/SYNC
POWER_ON/OFF2_2
RL_ON
0.1uF
16V
C408
POWER_ON/OFF1
10K
R401
NR8040T3R6N
3.6uH
L423
POWER_ON/OFF2_1
0.1uF
16V
C432
100pF 50V C439
10K R443
FRC
10K
1%
R467
33K
1%
R416
22K 1%
R442
100uF
16V
C402
Non_Commercial
0.1uF
16V
C407
12K 1%
PD_+12V
R448
NR8040T3R6N
3.6uH
L421
A_DIM
+12V/+15V
0.1uF
16V
C406
10K 1%
R457
24K 1%
R444
PWM_DIM
SCAN_BLK1/OPC_OUT
10K
R464
100pF 50V C463
4.7K
R406
CIC21J501NE
L420
1
R473
2SC3052
Q401
E
B
C
MLB-201209-0120P-N2
L404
6.2K
1%
R417
ERROR_OUT
6.8K
OPT
R418
+5V_USB
+12V/+15V
100pF
50V
OPT
C429
+12V/+15V
+3.3V_Normal
12K
R458
0.1uF
C410
0.1uF
16V
C477
27K
1%
R460
22uF
10V
C453
1uF
10V
C444
4.7uF
10V
OPT C435
0
POWER_16_GND
R412
L416
0.1uF
50V
C418
+3.5V_ST
+12V/+15V
L401
51K
5%
R465
NR8040T3R6N
3.6uH
L422
POWER_DET
OPC_OUT
1.5K
1%
R466
AOZ1073AIL
IC405
Extinct
3
AGND
2
VIN
4
FB
1
PGND
5COMP
6EN
7LX_1
8LX_2
100pF
50V
OPT
C423
10uF
25V
C458
2200pF
C466
+1.5V_FRC_DDR
100pF
50V
OPT
C427
22uF
10V
C430
+5V_Normal
0.1uF
16V
C424
+1.26V_VDDC
0.1uF
16V
C473
MLB-201209-0120P-N2
L407
4.7uF
OPT
C445
10uF
25V
C457
0.1uF
16V
C416
OPT
POWER_ON/OFF2_1
+3.3V_Normal
0.1uF
50V
C448
0R455
22uF
10V
C461
NON_EU
0 R478
POWER_23_SCAN_BLK2
0.1uF
C456
+3.5V_ST
SCAN_BLK2
0
POWER_24_PWM_DIM
R472
0
POWER_22_PWM_DIM
R471
POWER_ON/OFF2_2
10K R463
OPT
0.1uF
16V
C404
+24V
1/8W
75K
1%
R432
+3.3V_Normal
10uF
10V
C403
10uF
25V
C405
68uF
35V
C426
2SC3052
Q405
E
B
C
10uF
25V
C459
INV_CTL
+12V/+15V
L413
1uF
10V
C465
10K
OPT
R427
MLB-201209-0120P-N2
L402
0.1uF
C476
0.1uF 16V
OPT
C412
1/10W
10
1%
R436
1/10W
11K
5%
R449
0.1uF
16V
C428
+3.5V_ST
2200pF
C464
120K
OPT
R434
1uF
50V
C414
+3.5V_ST
+3.5V_ST
+1.5V_DDR
9.1K
R454
10K
R426 OPT
NR8040T3R6N
3.6uH
L406
10uF
25V
C460
POWER_ON/OFF2_1
0.1uF
16V
C440
MP2212DN
IC407
3
IN
2
GND
4
BS
1
FB
5VCC
6SW_1
7SW_2
8EN/SYNC
10K
R410
30K 1%
OPT
R446
0 R438
FRC
10K
1%
R462
100
POWER_24_INV_CTL
R425
NR8040T3R6N
3.6uH
L415
RT1P141C-T112
Q402
1
2
3
MP8706EN-C247-LF-Z
IC401
3
SW_2
2
SW_1
4
BST
1
IN
5EN/SYNC
6FB
7VCC
8GND
1uF
25V
OPT
C419
10K
R445
NCP803SN293
IC408
1
GND
3
VCC 2RESET
10K
R459
100
R480
PD_+12V
FW20020-24S
P403
NORMAL_EXPEPT_32
19
14
9
4
18
13
8
3
17
12
7
2
16
11
6
1
20
15
10
5
21 22
23 24
0
POWER_18_A_DIM
R451
0
POWER_20_A_DIM
R453
1uF 25V
OPT
C484
V_SYNC
0
POWER_20_PWM_DIM
R484
CIC21J501NE
L424
0.1uF
16V
C485
0
POWER_22_A_DIM
R485
+3.3V_Normal
4.7K R486
OPT
22
R487
100K
R488
OLP
0
POWER_16_V_SYNC
R477
0
POWER_24_GND
R475
0
POWER_23_GND
R476
1K
R419
0
POWER_22_SCAN_BLK1/OPC_OUT
R422
0
OPT
R470
0.1uF
C486
27K 1%
PD_+3.5V
R447-*1 1K
1%
PD_+3.5V
R450
100
R402
+24V
AOZ1072AI
IC406
Extinct
3
AGND
2
VIN
4
FB
1
PGND
5COMP
6EN
7LX_1
8LX_2
AZ2940D-2.5TRE1
IC402
2
GND
3VOUT 1
VIN
AO3438
Q408
FRC
G
D S
100K
R404 PD_+12V
NCP803SN293
IC409
PD_+12V
1
GND
3
VCC 2RESET
24K
1%
R482-*1
POWER_+20V
FM20020-24
P404
NORMAL_32
19
14
9
4
18
13
8
3
17
12
7
2
16
11
6
1
20
15
10
5
21 22
23 24
25
SMAW200-H24S2
SLIM_32~52
P401
19
12V
14 GND
9
3.5V
424V
18 INV ON
13
GND
8GND
3
24V
17
12V
12 3.5V
7
GND
224V
16 GND/V-sync
11
3.5V
6GND
1
PWRON
20 A.DIM
15
GND
10 3.5V
5
GND
21
12V 22 P.DIM1
23
GND/P.DIM2 24 Err OUT
25
0
R479
24K
1%
R482
POWER_+24V
4.3K
1%
R403
POWER_+24V
5.1K
5%
R403-*1
POWER_+20V
0.1uF
C474
22uF
10V
C411
OPT
100
POWER_20_ERROR_OUT
R437
100
R420
POWER_24_ERROR_OUT
330uF
4V
C409
OPT
3.9K
C419-*1
PWM_PULL-DOWN
5.6K
1%
R403-*2
POWER_+18.5V
24K
1%
POWER_+18.5V
R482-*2
MP2212DN(Marking)
IC403-*1
FRC
3
IN
2
GND
4
BS
1
FB
5VCC
6SW_1
7SW_2
8EN/SYNC
22uF
16V
C420-*1
EU
10uF
16V
C461-*1
EU
10uF
16V
C469-*1
EU
10uF
16V
C471-*1
EU
10uF
16V
C472-*1
EU
22uF
16V
C471
NON_EU
22uF
16V
C469
NON_EU
22uF
16V
C420
NON_EU
2SC3052
Q406
E
B
C
L412
22K
R435
10uF
16V
OPT
C442
0.1uF
16V
C455
1uF
25V
C451
OPT
10K R439-*1
NON_GIP_CCFL_55"
1.8K R440-*1
PANEL_CTL
1:AK10
22K
R431
0.01uF
25V
C436
2SC3052
Q407
E
B
C
2.2K
R405
PANEL_DISCHARGE_RES
0.1uF
16V
C438
2.2K
R407
PANEL_DISCHARGE_RES
AO3407A
Q409
G
D
S
PANEL_VCC
33K
R439
EXCEPT_NON_GIP_CCFL_55"
5.6K R440
EXCEPT_NON_GIP_CCFL_55"
10K
OPT
R430
4.7uF
16V
C443
47K
R429
+12V/+15V
MP2212DN-C358
IC403-*2
REVISION_FRC
3
IN
2
GND
4
BS
1
FB
5VCC
6SW_1
7SW_2
8EN/SYNC
0 5% R450-*1
PD_+3.5V_0 ohm
22uF
16V
C469-*2
BRAZIL
22uF
16V
C471-*2
BRAZIL
0.1uF
16V
R447-*2
PD_+3.5V_0.1UF
100uF
16V
C401-*1
Commercial
100uF
16V
C402-*1
Commercial
AOZ1073AIL-3
IC405-*1
REVISION
3
AGND
2
VIN
4
FB
1
PGND
5COMP
6EN
7LX_1
8LX_2
AOZ1072AI-3
IC406-*1
REVISION
3
AGND
2
VIN
4
FB
1
PGND
5COMP
6EN
7LX_1
8LX_2
+5V_USB
POWER
GP2_Saturn7M Ver. 1.2
Power_DET
R2
+5V_Normal
INV_ON
R2
3A
PWM_DIM
or LIPS
+2.5V/+1.8V
22
Placed on SMD-TOP
PIN No
Vout=0.8*(1+R1/R2)
3A
Placed on SMD-TOP
R1
Vout=0.8*(1+R1/R2)
+5V_USB
AUO
VBR-A
C IN
Vd=550mV
1074 mA
S7M DDR 1.5V
26/32/52:PWM
Err_out
3A
1934 mA
Vout=(1+R1/R2)*0.8
20
ST_3.5V--> 3.375V
+1.5V_DDR_FRC
Placed on SMD-TOP
Err_out
R2
Placed on SMD-TOP
R1
Replaced Part
R1
INV_ON
PWM_DIM
SHARP
INV_ON
300 mA
18
R1
PWM_DIM
R1
20V-->3.51V
24V-->3.64V
Close to IC
Vout=(1+R1/R2)*0.8
24
NC
FROM LIPS & POWER B/D
MAX 2000mA
R2
A-DIM
2026 mA
Close to IC
C IN
12V-->3.58V
2A
Vout=0.8*(1+R1/R2)
Replaced Part
S7M core 1.26V volt
3A
+3.3V_Normal
MAX 1A
NC
CMO
INV_ON
R2
<OS MODULE PIN MAP>
4
23
IPS-@
+3.5V_ST -> 3.375V
INV_ON
Err_out
GND GND GND GND
52/60:ERROR
26/32HD:NC
GND
PWM_DIM
NC
(PSU) (PSU)(PSU)(PSU)
Only for 32/37LED MODEL
18.5V-->3.5V
60:NC
26/32/52:GND
60:PWM
LGD(PSU)
New item
PANEL_POWER
2000hrs item for Commercial model
1000hrs item for Non commercial model
