LG 55G2 User manual

Quick Setup Guide
G2/G3 series
P/N:MBM63660424 (REV01-1207)
Inserting batteries
1. Open the battery cover as shown
below.
COIN
COIN
2. Pull out the battery holder.
COIN
COIN
3. Place the batteries into the holder.
COIN
COIN
4. Re-insert the holder into the re-
mote control.
COIN
COIN
5. Close the battery cover as shown
below.
COIN
COIN
How to pair the remote control
REMOTE CONTROL
For more information
Refer to manual or go to www.lg.com
Press the Wake-up pointer button
to pair the remote control.
How to use the zoom in/out gestures 1. Press and hold the zoom button for
2 seconds.
2. While holding the zoom button,
draw a circle in a clockwise direction
to zoom in or counter-clockwise
direction to zoom out.
(This feature is only available while
using the Web.)
TV (FN+1)
Activate TV player app
PIP (FN+4)
Activate/Deactivate PIP
INFO (FN+7)
Show channel information (available only on Live TV)
EXT1 PWR (FN+2)
Turn on/off external device 1
EXT 2 PWR (FN+5)
Turn on/off external device 2
INPUT (FN+8)
Show external input list
Fn
Combination key with other keys
Shift
Combination key with alphabet keys;input upper case
Ctrl
Combination key with other keys
Trick play keys
Play, pause, stop, scan –/+, skip -/+
Spacebar
Enter a space
/ (FN+∧ / FN+∨)
Zoom in/out
EXT VOL -/+ (FN+< / FN+>)
Volume up/down on audio receiver
ESC
Cancel state or command
Tab
Move focus to next depth or step
X (Backspace)
Delete the preceding character and
moves the cursor one position backwards
Enter
Confirm the text entry
QWERTY Side - BackQWERTY Side - Front
BACK
Move to previous or superior step.
(Wake-up pointer)
Activate the pointer.
MENU
Call option pop-up for activating app.
VOL
Adjust the volume level.
CH
Change TV channels.
GUIDE
Access the EPG on connected
set-top box.
(Available only on Live TV)
Change between 2D and 3D
mode.
(MUTE)
Mute all sounds.
(POWER)
Turn the TV on or off.
HOME
Access the homescreen.
SEARCH
Access the Quick Search Bar.
Press and hold to use the voice
search.
Microphone
OK
Select item by pushing key.
Wheel
Spin the wheel up/down to scroll
up/down.
Navigation Buttons
(up/down/left/right)
Move focus
Color buttons
(red, green, yellow, blue)
Use with other devices.
* Make sure that the qwerty side is
faced up to use the qwerty function.
MBM63660424_QSG.indd 1 2012-07-03 �� 11:07:42

Cable/Satellite Box
3
You can see the screen shown above to start
the set up routine. There, select (A) to access
the IR blaster settings.
h
Select the correct port that is connected to the
cable/satellite box. You should see a TV signal once
the correct port is selected.
h
Select your lineup provider from the list. A TV signal should
appear once you pick the correct provider.
h
Select the correct cable/satellite box manufacturer.
h
Check if the IR Blaster is firmly plugged into the IR Blaster
port and is placed near the remote sensor of your device as
shown above.
h
The TV will generate a test code to see if the remote is
properly working with the cable/satellite box. Press the CH
up and down to check the code. If the Channel doesn’t
change, then select [No, try next code] to repeat this step
until you find right code.
h
The TV will generate a list of premium channels. Select
[Yes] if you receive any of these channels.
h
Select and customize your premium channel list.
h
Your LG remote is now set up to your cable/satellite box.
You can now access the channel guide or
connected set-top box with your remote.
Wired Wireless
TV & Movies makes it easy to browse and filter live and on-demand TV shows and movies, web video content, and
DVR content (if compatible). Browse offerings from Netflix, Amazon Instant Video, HBO GO, YouTube and other
sources.
To access TV & Movies:
Press the Home key and select TV & Movies.
Once in TV & Movies, use the left navigation bar to filter by live, shows and movies.
IR BLASTER SETTINGS HOME
TV & MOVIES
CONNECTIONS
The Setup Wizard will begin when you turn on the TV for the first time. You can connect the LG remote to a
cable/satellite box by following the steps shown below.
Place the IR Blaster so that
the infrared transmitter points
to the remote sensor of the
Cable/Satellite Box.
Router
HDMI or Component..
IR Blaster cable
Other devices
Home theater/ Blu-ray player/ ...
12
Connecting to a network
Connect the TV to a router with a LAN cable.
Or, connect with Wi-Fi by accessing Network Setup in the initial
Setup Wizard. For seamless internet streaming LG recommends a
stable 4Mbps broadband speed and 1.5Mbps as a minimum.
1
Connecting the cable/satellite box
Use the appropriate cable that is provided from your cable or satellite pro-
vide to connect the cable/satellite box to the TV. Place the IR Blaster near
the remote sensor.
2
Connect other devices
Connect the Audio amplifier and other devices to the TV if necessary.
3
Live TV Input List & Settings Next page
Launcher Bar
Channel
description
* Please note that you need to have a Google account to setup
the TV. It makes it more convenient to use Google’s services and
automatically restores your personal apps after a software update.
MBM63660424_QSG.indd 2 2012-07-03 �� 11:07:50
