LG CHAMELEON V 26LD320H User manual

HD VOD PPV ENC YPTION
Integrated Pro:Idiom®
Pro:Centric®ST
(Java/Flash)
EcoSmart™
Dynamic Power Savings
Static Power Savings
ENE GY STA ® 4.1 AND oHS COMPLIANT
NEW! BUILT-IN INTEG ATED b-LAN™ (VE 6.3 UP)
MPEG-4 H.264 DECODING
COMME CIAL MODE SET UP MENU (INSTALLE MENU)
TVLINK-P OTOCOL
MPI SLOT
NATIVE DISPLAY ESOLUTION
1920 x 1080 (37”/42” class)
1366 x 768 (26”/32” class)
NEW! STAND (METAL NECK/STAND BASE METAL)
(32”/37”/42” class)
USB CLONING
USB MEDIA HOST (JPEG & MP3)
SPLASH IMAGE - LOGO
(when booting)
ANTI-THEFT WA NING LABEL
180° DETACHABLE SWIVEL STAND
2 YEA LIMITED WA ANTY
(parts and labor)
lcd tv
w w w. L s o l u t i o n s . c o m
Integrated HDTV with HD-PPV
Capability
LCD Commercial Widescreen
42LD320H
37LD320H
37LD325H
32LD320H
32LD325H
26LD320H
42" class (42.0" diagonal)
37" class (37.0" diagonal)
32" class (31.5" diagonal)
26" class (26.0" diagonal)
i gloss black
i gloss black
matte black
i gloss black
matte black
i gloss black

F R E E - T O - U E S T MANA EMENT APPLIANCE
FMA-LG101
HEAD-END SYSTEM
Manages channel line-up changes, channel label changes, designates a
startup channel, configuration of commercial installer menu settings, and
can set the time/date, and broadcast that information to all the terminals
on a regular basis all from the head-end. Also, enables Pro:Idiom tuning
for Pro:Idiom encrypted content.
•EcoSmart
Dynamic Power Savings - Using built-in algorithms, the TV will automatically
reduce the power consumption based on incoming video, while maximizing
picture performance.
Static Power Savings - Picture brightness level can be set at the preferred power
consumption level to reduce power and increase energy savings.
•RoHS Compliant
Meets directive on restriction of hazardous substances.
•Energy Star 4.1 Qualified - Meets current reduction requirements of energy
consumption.
PHOTO LIST MUSIC LIST
ENERGY SAVING LEVELS
By selecting lower levels of backlight settings, a reduction in power consumption is achieved
resulting in energy savings and lower costs.
USB 2.0 will support JP and MP3 files from a USB storage device.
Page 2/3 No Marked
Photo List
Up Folder
1366x768, 125KB
KY101 06/10/2008
KY102 04/03/2008
JMJ001 01/01/2000
JMJ002 06/15/2008
JMJ003 04/03/2008
JMJ004 02/18/2008
KY103 03/30/2008
KY104 06/19/2008
KY105 01/31/2008
JMJ005 05/13/2008
JMJ006 05/26/2008
JMJ007 02/18/2008
JMJ008 02/18/2008
Up Folder
Drive1
JMJ001
Music List
Up Folder
noitaruDeltiT
Page 2/3 No Marked
Drive1
AA00:00 / 04:16
Up Folder
TESTING CONDITION: PWM Static mode (eyecare off)
HOTEL COSTS FOR FREE-TO-GUEST CHANNEL MANAGEMENT(OVER 5 YEARS)
USB 2.0
M E D I A H O S T
LG'S FREE-TO-GUEST COST EFFECTIVE SOLUTION
For Free-To- uest hotel installations, when using L ’s b-LAN Free-To- uest built-in technology
plus L ’s Free-to- uest Management Appliance (FMA), virtual channel mapping, configuration
of commercial installer menu settings, and other adjustments can be made from the centralized
head-end FMA system. This is an added value of time savings and therefore cost savings in labor
charges by not having to go room to room for a change of settings.
Labor Costs FTG Card
Price
¹FMA
MAP price Total Savings over other brand
Other brand
$20 (est.) x 2 times per
year (to update channels)
x 100 rooms x 5 years
-- -- $20,000 --
L Pro:Idiom TVs with
Integrated b-LAN, plus
FMA²
-- -- $1,999 $1,999 $18,001
¹FMA MAP price subject to change. ²FMA sold separately.
F R E E - T O - U E S T INTE RATED b-LAN
b-LAN
F EE-TO-GUEST TECHNOLOGY
Will allow viewing of HD secured Pro:Idiom encrypted content from
Pro:Idiom licensed Cable or Satellite providers. Compatible with
FMA-100 and FMA-L 101 head-end systems. system. Pay-Per-View ready.
L IF E’ S O O D .. .
WHEN IT’sREEN.
L is committed to improving product development,
manufacturing and usage to meet the demand
for environmentally friendlier products.
The LD320H series has technologies to reduce power
consumption and in return increase cost savings per
room. We’ve also placed limits on the amounts of
harmful materials used in these televisions.
Applied Model Backlight Setting
Value
Power
Consumption
[Watts]
Energy savings
[%]
42LD320H
Level 100 108 0%
90 87 19%
80 79 27%
70 73 32%
60 67 38%
50 61 44%
40 56 48%
30 53 51%
20 48 56%
10 43 60%
1 39 64%
37LD320H
37LD325H
Level 100 89 0%
90 84 5%
80 78 12%
70 72 19%
60 66 25%
50 61 31%
40 57 36%
30 52 41%
20 48 46%
10 44 51%
1 40 55%
32LD320H
32LD325H
Level 100 73 0%
90 64 13%
80 59 20%
70 54 27%
60 44 39%
50 41 43%
40 39 47%
30 36 50%
20 34 54%
10 31 58%
1 29 61%
26LD320H
Level 100 57 0%
90 52 9%
80 47 17%
70 42 26%
60 40 30%
50 37 34%
40 36 36%
30 35 38%
20 33 43%
10 30 47%
1 28 51%
Note: Energy Saving percentages listed are percentages off of level 100.

4-Screws
(not provided)
Stand
Desk
MOUNTING HOLES ON STAND
ATTACHIN THE TV TO A DESK
UPDATE
RESET
AUDIO IN
(RGB/DVI)
RS-232C IN
(SERVICE ONLY)
.....
....
.. ... .. .. .
2
1
HDMI
/DVI IN
RJP
VIDEO
L/MONO-AUD IO-R
AV IN 1
RGB IN (PC)
.....
.....
.....
TV-LINK
CFG
GAME
CONTROL
.. ... .. .. .
REMOTE
CONTROL
OUT
SPEAKER
OUT
8
HDMI
COMPONENT IN
R
L
PB
YPR
VIDEO
AUDIO
()
AV IN 2
L/MONO -AUDIO- R
VIDEO
USB IN
ANTENNA IN MP I
42/37/32LD320H SIDE JAC
PANEL
AV IN 2
VIDEO
AV IN 2
H -AUDIO
VIDEO
AV IN 2
H
-AUDIO
-
USB IN
SOUND IS HEARD, NOT SEEN
Enjoy a combination of smart technology
and stylish design with the invisible
speaker system custom tuned by audio
expert Mr. Mark Levinson. This unique
system provides a clean, polished look
and an enhanced auditory experience
by increasing the sweet spot and
providing a wider sound field.
SHARPER
BRIGHTER
CLEARER
Dramatization
Six distinct processes contribute to picture improvement. L ’s XD Engine takes
the low resolution of analog signals to near HD levels by improving brightness,
contrast, detail and enhancing color as well as reducing signal noise.
Dramatization
USB CLONING
USB cloning will allow for easy transfer
of Commercial Installer Menu Settings
from the “Master TV” to an unlimited
number of same type televisions.
42LD320H
37LD320H
40.5”
19.2”
3.5”
10.3”
200mm
200mm
25.8”
27.8”
40.5” 3.5”
10.3”
200mm
200mm
25.8”
27.8”
36.3”
19.2”
3.5”
10.3”
200mm
200mm
23.4”
25.6”
32LD320H
31.7”
15.7”
4.3”
8.1”
100mm
200mm
20.8”
23.0”
26LD320H
26.0”
15.7”
3.1”
8.1”
100mm
200mm
17.6”
19.8”
UPDATE
RESET
AUDIO IN
(RGB/DVI)
RS-232C IN
(SERVICE ONLY)
. . . . .
. . . .
.. ... .. .. .
2
1
HDMI
/DVI IN
RJP
VIDEO
L/MONO-AUD IO-R
AV IN 1
RGB IN (PC)
. . . . .
. . . . .
. . . . .
TV-LINK
CFG
GAME
CONTROL/MPI
.. ... .. .. .
REMOTE
CONTROL
OUT
SPEAKER
OUT
8
HDMI
COMPONENT IN
R
L
PB
YPR
VIDEO
AUDIO
()
ANTENNA IN
AV IN 2
L/MONO -AUDIO- R
VIDEO
USB IN
REAR JAC PANEL SIDE JAC
PANEL
REAR JAC PANEL

All screen images are simulated. Dimensions and weights are approximate.
Design, features and specifications subject to change without notice.
© Copyright 2011 L Electronics USA, Inc. All Rights Reserved. “L Life’s ood” is
a registered trademark of L Corp.
XD Engine, Pro:Centric and EcoSmart are registered
trademarks or trademarks of L Electronics, Inc. Pro:Idiom is a registered trademark
of Zenith Electronics Corp. SRS and the SRS symbol and TruSurround XT are trademarks
or registered trademarks of SRS Labs, Inc. VESA is a trademark of Video Electronics
Standards Association.
b-LAN is a trademark of LodgeNet Interactive Corporation.
All other product and brand names are trademarks or registered trademarks of their
respective companies.
Printed in the USA. March 2011
180
specifications
www.L s o l u t i o n s .com
lcd tv
LCD SPECIFICATION
Screen Size (Class) 42” class (42.0” diagonal)
37" class (37.0" diagonal)
32" class (31.5" diagonal)
26" class (26.0" diagonal)
Native Display Resolution 1920 x 1080 (42, 37”)
1366 x 768 (32, 26”)
Dynamic Contrast Ratio 60,000:1
Viewing Angle 1
78°/178°
Color Reproduction 8 bit
Response Time 4ms
Life Span (Typical) 60,000 hrs
BROADCASTING SYSTEM
Analog Yes
ATSC/NTSC/Clear QAM Yes
b-LAN (RFModem) Yes
VIDEO
XD Engine Yes
Video Codec MPE -2/4
Aspect Ratio 16:9
Aspect Ratio Correction 5 Modes
Just Scan 0% over scan
HDMI/Component: HD/DTV
Enhanced Noise Reduction (Video Noise Filter) Yes, 3D NR/MPE NR
Digital Comb Filter Yes (3D)
Color Temperature Control 3 Modes (Medium, Warm, Cool)
Black Stretcher Yes
24p Real Cinema Yes
Cinema 5:5/2:2 Mode Yes
Picture Reset Yes
EZ Picture/PSM Yes (5 mode)
xvYCC (richer color) Yes
DTV Signal Strength Indicator Yes
Video Reset/Initializing Yes
AUDIO
Mono/Stereo/Dual (MTS/SAP) Yes
Audio Output Power 10W x 2 (32”, 37”, 42”), 7W x 2 (26”)
Invisible Speaker System Details 1 Way 2 Speaker
Dolby Digital 5.1 Decoder Yes
Surround System Type Infinite Sound
Bass/Treble/Balance Controls Yes
Clear Voice II Yes
Auto Volume Leveler Yes
EZ Sound Mode/SSM 5 Modes
SPECIAL FEATURES
Integrated Pro:Idiom Yes
Pro:Centric ST (Java/Flash) Yes
b-LAN Embeded (Version 6.3 or up) Yes
MPE 4 Yes
Auto-Sensing RJP compatible Yes (with select RJP versions, non - PIP)
Commercial Mode Set Up Menu Yes
(Installer Menu)
TVLink Protocol Yes
USB Cloning Yes
USB Mode Host (JPE & MP3) Yes
Splash Image Yes
Multi Remote IR code (Bed1-9) Yes
720p/1080p Source Input
HDMI 60f/30f/24f
Component 60f/30f/29f
Auto Screen Adjust Yes
Fresh White Yes
Flashback (Previous Channel) Yes
Quick Setup uide Yes
Parental Control w/V-Chip Yes
Key Lock/Child Lock Yes
Customizable Closed Caption/Sub-title Yes
CONVENIENCE FEATURES
Language English/Spanish/French/Korean
Alvin UI Yes
Commercial Function Menu Yes
Auto Tuning/Programming Yes
Channel Add/Delete Yes
Auto/Manual Clock Yes
On/Off Timer/Sleep Timer Yes
Auto Off/Auto Sleep (When no video is present) Yes
AUDIO/VIDEO INPUTS/OUTPUTS
RF In (Antenna/Cable) 1
L/R Audio/Composite Video In 1 (rear), 1 (side)
HD Component Video In (Y, Pb, Pr) + L/R Audio 1
Speaker Out 1 (1W mono)
HDMI/HDCP Input (V1.3 with Deep Color) 2 (1 port PC mode)
RB In (D-Sub 15pin) - PC 1 (up to WX A)
PC Audio Input 1
RS-232c In (Service Only) 1
USB 2.0 Input 1(Side) Media Host (jpeg, mp3), Cloning,
Service
Remote Control Port out 1
RJ45 (for RJP interface, non PIP) 1
MPI Jack (RJ-12) 1 on MPI Card Slot (32”, 37”, 42”)
ame Port/MPI Yes (26” only)
ame Port (RJ-12) 1 for LodgeNet game controller
CABINET/ACCESSORIES
Cabinet Color Hi loss Black (320H)/Matte Black (325H)
Swivel Stand (degrees) + 90°/-90°
Fire Retardant Cabinet Material Yes
Kensington Security System Slot Yes
Security Screws (TORX) Yes (optional use)
VESA®Standard Mount Compatible (WxH) 200mm x 100mm (26”, 32”)
200mm x 200mm (37”, 42”)
Remote Control Yes
Cloning Capable USB input, opt. LT2002, or opt. TLL-1100A
POWER
Voltage, Hz 100V - 240V, 50/60 Hz
Stand-by Mode Less than1W
Dynamic/Static Power Savings Yes
Power Consumption Max 110
(26”) , 150 (32”) , 200 (37”) , 270 (42”)
(with Power Saving Modes Disabled) Typical 60 (26”) , 80 (32”) , 90 (37”) , 120 (42”)
ENER Y STAR 4.1 Qualified Yes
RoHS Compliant Yes
DIMENSIONS & WEIGHT
TV without stand (WxHxD) 26.0" x 17.6" x 3.1" (26”)
31.7" x 20.8" x 4.3" (32”)
36.3" x 23.4" x 3.5" (37”)
40.5" x 25.8" x 3.5" (42”)
TV with stand (WxHxD) 26.0" x 19.8" x 8.1" (26”)
31.7" x 23.0" x 8.1" (32”)
36.3” x 25.6” x 10.3” (37”)
40.5” x 27.8” x 10.3” (42”)
Shipping Dimensions (WxHxD) 32.9" x 21.3" x 6.9" (26”)
38.7" x 24.6" x 7.4" (32”)
44.9” x 27.0” x 6.8” (37”)
48.4” x 30.3” x 6.9” (42”)
TV without stand weight 16.9 Ibs (26”)
25.1 Ibs (32”)
28.6 Ibs (37”)
33.7 Ibs (42”)
TV with stand weight 20.7 Ibs (26”)
28.8 Ibs (32”)
34.3 Ibs (37”)
39.4 Ibs (42”)
Shipping Weight 25.7 Ibs (26”)
34.3 Ibs (32”)
40.9 Ibs (37”)
46.6 Ibs (42”)
SERVICE/LIMITED WARRANTY 2 Years (Parts/Labor)
UPC CODE
42LD320H 7 19192 90179 7
37LD320H/37LD325H 7 19192 90178 0/7 19192 90181 0
32LD320H/32LD325H 7 19192 90177 3/7 19192 90180 3
26LD320H 7 19192 90176 6
L Electronics U.S.A., Inc.
Commercial Displays
2000 Millbrook Drive
Lincolnshire, IL 60069
Customer Service: 888.865.3026
www.L solutions.com/support
Contact your LG Regional Sales Representative
Hospitality: 800.228.1236
Vertical Markets: 800.897.8788
Channel: 800.897.8871
E-mail: info@L solutions.com
SPEC_LD320H_031120_PR
42" class (42.0" diagonal)
37" class (37.0" diagonal)
32" class (31.5" diagonal)
26" class (26.0" diagonal)
i gloss black
i gloss black
matte black
i gloss black
matte black
i gloss black
42LD320H
37LD320H
37LD325H
32LD320H
32LD325H
26LD320H
