LG LXU-800 User manual

1

2
LXU800 User’s Manual
Welcome-------------------------------------------------- 2
• Installation – Windows XP ------------------- 3
• UI Features Introduction -------------------- 10
• Data Connection & Disconnection ------- 11
• Voice call Connection & Disconnection- 14
• SMS Sending -------------------------------- 19
• SMS Receiving ------------------------------- 26
• Phonebook ------------------------------------- 34
• Settings ----------------------------------------- 40
8-1. Data Service Terminal -------- (41)
8-2. SOUND --------------------------- (42)
8-3. SMS ------------------------------- (44)
8-4. LOCK ------------------------------ (45)
8-5. TONE ------------------------------ (46)
8-6. VOICE ----------------------------- (47)
8-7. Others ----------------------------- (48)
9. Information ------------------------------------- 49
9-1. USE -------------------------------- (50)
9-2. Call History ----------------------- (51)
9-3. MODEM --------------------------- (52)
10. Reliance Web Page Connection---------- 53
11. About --------------------------------------------- 54
12. Un-Installation – Windows XP ------------- 56
Contents

3
Welcome
Thank you for choosing LXU-800 USB Modem, cutting edge CDMA 1X technology with the data speed of up to
153.6 Kbps. You can surf the Internet at high speeds, access e-mails as well as make and receive calls and
SMS on the move.
How to Plug LXU-800
Please plug LXU-800 into a PC after installing drivers.
1. Pull out the USB connector on the back of the modem. 2. Adjust the USB connector to the desired angle.
The USB connector is adjustable to a 45, 90, 135 or
180 degree.

4
Welcome
How to Plug LXU-800
Please plug LXU-800 into a PC after installing drivers.
3. Extension Cable
The extension cable provided is specially designed to work with your LXU-800. This is a high
quality USB cable that is capable of delivering high current to the LXU-800 when necessary.
The cable will improve performance.
Note:
Your LXU-800 may not operate correctly if you use a standard USB cable in place of the
provided extension cable. Adjust the USB connector to the desired angle.
The USB connector is adjustable to a 45, 90, 135 or 180 degree.
** USB Length : 50 Cm

5
1. Installation – Windows XP
1. Click the "Next"button to install the LXU800 2. Select the installation path (it is recommended to
use the default location) and click the "Next"button

6
1. Installation – Windows XP
3. Select the Program Folder then click the "Next"
button to continue with the installation 4. Before Installation, please remove the modem then
click the "Next"button

7
1. Installation – Windows XP
6. Push the Next button to install the USB driver.
5. Please wait for the Installation to be completed

8
7. Push “Install” button to begin the installation. 8. Please wait for the USB driver Installation progress.
1. Installation – Windows XP

9
9. Push “Finish” button to finish the USB driver installation.
1. Installation – Windows XP
10. Connect your LXU800 Modem to the USB port.
Please click the "Next" button once the installation of
all 3 drivers is complete.

10
11. Push “Finish” button to complete the installation.
1. Installation – Windows XP

11
1. Installation – Windows XP
12. Open Device Manager to check that the driver has
been installed correctly. 13. When you start the GUI, the above screen will be
displayed (the default banner is "Reliance")

12
2. UI Features Instruction
Data
Voice
SMS
Receive SMS
Phonebook
Settings
Information
www.zapak.com
About

13
3. Data Connection & Disconnection
1. To change the Data Connect (Internet) screen,
please click the "Data"icon 2. To connect the Data (Internet), please click
the "Connect"button
※ you must have a valid ID, password and numbers
(
please see 8-1. Data Service Terminal settings )

14
3. Data Connection & Disconnection
3. Data Connecting (Internet) process screen Once it is
connected, the Internet Browser will appear 4. If the Data Connection is properly connected,
the "Connected"message will be displayed as above

15
3. Data Connection & Disconnection
5. To disconnect the Data Connection (Internet),
click the "Disconnect"button. 6. Click "Yes"to disconnect and "No"to cancel the
disconnection

16
4. Voice call Connection & Disconnection
1. For a voice call, click the "Voice"icon 2. When you click the Voice icon, the above screen will
be displayed with a dial-pad

17
4. Voice call Connection & Disconnection
Call
End Call
Cancel
Volume (Voice)
-Voice call Menu-
Silent (when in Silent mode)
Tone silent (when voice calling)
Voice mute (when voice calling)
Volume (sound & key tone)

18
4. Voice call Connection & Disconnection
1
2
3
3. To make a voice call, STEP ①Dial the numbers,
STEP ②Check the numbers, STEP ③Press call 4. Calling Screen

19
4. Voice call Connection & Disconnection
5. Once you are successfully connected to the
desired number, the screen will change as above

20
4. Voice call Connection & Disconnection
6. To disconnect the voice call, press the "End"
icon. 7. Once you are properly disconnected, the screen will change as above
