LG EA790SP User manual

Operating Instructions
Built in Oven
EA790SP
www.lg.com
Please read this instruction manual carefully before using the oven.
This will ensure that you know the important safety information and the
correct operation of the oven.
Please keep this manual in a easily accessible place and refer to it
anytime.
Please transfer this manual to new owner if you sell the oven.

2
Contents
Safety ......................................................................................... 4~12
Appliance description .................................................................. 13
Control panel .......................................................................... 14~15
Accessories ............................................................................ 16~18
Telescopic runners ....................................................................... 19
Before using for the first time ............................................... 20~22
Operating the oven ................................................................. 23~25
Oven functions ....................................................................... 26~28
Oven program logic..................................................................29~34
Manual cook..............................................................................35~36
Setting the functions .................................................................... 35
Selecting an oven function............................................................ 35
Setting a temperature .................................................................. 35
Pre-set temperature...................................................................... 36
Using the oven ........................................................................ 37~46
Changing the temperature ........................................................... 37
Enter the Duration......................................................................... 37
Changing the Duration.................................................................. 38
Cooling system ............................................................................. 38
Residual Heat Indicator ................................................................ 38
Before starting the rotisserie function ........................................... 39
Using the rotisserie....................................................................... 40
Rotisserie Table ............................................................................ 41
Using the Low temperature cook.................................................. 42
Using the meat probe ................................................................... 43
Removing the meat probe ............................................................ 44
Child lock ...................................................................................... 45
Energy efficiency .......................................................................... 45
Safety cut-out................................................................................ 45
Rapid heat-up ............................................................................... 46
Auto cook................................................................................. 47~48
Using the Auto Cook..................................................................... 47
Using the speed auto cook ........................................................... 48
Recipes .................................................................................... 49~54

3
Cleaning ........................................................................................ 55
Using the Cleaning ....................................................................... 55
Pyrolytic self-cleaning....................................................................55
Changing settings .................................................................. 56~59
Using the Setting ......................................................................... 56
Cooking setting............................................................................. 56
Heating-up .................................................................................... 56
Oven lighting................................................................................. 57
Start .............................................................................................. 57
Default temperature...................................................................... 57
Initial stage.................................................................................... 57
General setting ............................................................................. 58
Sound ........................................................................................... 58
Language...................................................................................... 58
Clock............................................................................................. 58
Display.......................................................................................... 59
Default all settings ........................................................................ 59
Auto cook table ....................................................................... 60~86
Baking ...................................................................................... 87~88
Baking Tables .......................................................................... 89~93
Roasting ................................................................................... 94~95
Roasting tables.............................................................................. 96
Grilling...................................................................................... 97~98
Defrosting....................................................................................... 99
Special functions ........................................................................ 100
Cleaning and care........................................................................ 101
Oven light..................................................................................... 102
Oven door............................................................................. 103~107
Troubleshooting .................................................................. 108~109
Error codes .................................................................................. 110
Technical specifications ............................................................. 111
Installation instructions.............................................................. 112
Customer service & spare parts ................................................ 113
Reference ..................................................................................... 114

4
Safety
• This oven must only be installed by a licensed
electrician.
• The installer is responsible for the correct
electrical connection of the appliances and the
observance of the relative safety codes and
recommendations.
Electrical Safety
If the oven has been damaged in transport, do not
connect it.
• This appliance must be connected to the mains
power supply by a specially licensed electrician
only.
• In the event of a fault or damage to the appliance,
do not attempt to operate it.
• Repairs of the appliance should be carried out
by a licensed technician only. Wrong repairs may
result in considerable danger.
If you need repairs, contact an LG Service Center
or your dealer
• If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.

5
• Electrical leads and cables should not be allowed
to touch the oven.
• The oven should be connected to the electricity
supply by means of a proper circuit breaker or
fuse.
Never use multiple plug adapters or extension
leads.
• Rating plate is located on the left side of door or
on the back cover.
• The power supply of the appliance should be
turned off when it is being repaired or cleaned.
• Be careful in connecting electrical appliances to
sockets near to this appliance.
• This connection may be achieved by having the
plug accessible or by incorporating a switch in the
xed wiring in accordance with the wiring rules.
• Do not use harsh abrasive cleaners or sharp
metal scrapers to clean the oven door glass since
they can scratch the surface, which may result in
shattering of the glass.
• Never use the oven door as a resting table at any
time.

6
Safety
WARNING: The appliance should be powered
down before replacing the lamp to
avoid the possibility of electric
shock.
WARNING: When the oven operates, the
interior parts will be very hot.
WARNING: Accessible parts may become hot
during use. Young children should
be kept away.
WARNING: Accessible parts may become hot
when the grill is in use. Children
should be kept away.
WARNING: Please ensure cooking times are
correctly set as over cooking may
result in the food catching re and
subsequent damage to your oven.
WARNING: Do not touch an electric cord with a
wet hand. It is very dangerous. You
can get an electric shock.

7
Safety during Operation
• This oven has been designed only for the cooking
of household foods and is not warranted for
commercial or mobile applications.
• When in use, the oven interior surfaces become
very hot!
Care should be taken to avoid touching heating
elements inside the oven.
• Never store flammable or easily deformable
materials in the oven.
• The oven surfaces will become hot when the
appliance is operated at a high temperature for a
long period of time.
• Excess spillage should be removed before self
cleaning and all utensils should not be left in the
oven during pyrolytic selfcleaning.
•
During self cleaning the surfaces get hotter than
usual and children should be kept at a safe distance.
• When cooking, take care when openning the oven
door as hot air and steam will escape rapidly.
• When cooking dishes that contain alcohol, the
alcohol can evaporate due to the high
temperatures. The vapour can catch fire if it
comes into contact with a hot oven part.

8
Safety
• Do not use high-pressure water cleaners or
steam jet cleaners for electrical safety reasons.
• This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall
not be made by children without supervision.
WARNING: The appliance and its accessible
parts become hot during use. Care
should be taken to avoid touching
heating elements. Children less
than 8 years of age shall be kept
away unless continuously
supervised.

9
• Children should be kept at a safe distance when
the oven operates.
• Frozen foods such as pizzas should be cooked
on the wire grille.
If a Baking tray is used, it may become deformed
due to the great difference in temperature.
• Don’t pour water into the oven bottom when it is
hot.
This could cause damage to the enamel surface
and deform the base.
• The oven door must be closed when cooking is
performing.
• Don’t spread aluminium foil on the bottom of the
oven and do not place any baking trays or tins on
it at any time.
The aluminium foil blocks the heat, which may
result in damage to the enamel surfaces and
cause poor cooking results by lack of heat
circulation.
• Dripping fruit juices from the baking tray will leave
stains, which become indelible. When cooking
very moist cakes, use the deep pan.
• Do not use the oven door as a rest table under
any circumstances.

10
Safety
• The appliance is not intended for use by young
children or infirm persons without supervision.
• Young children should be supervised to ensure
that they do not play with the appliance.
• Children should be kept at a safe distance until
the oven has cooled down after cooking.
• This appliance is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.

11
Disposal
Packaging material
• Your new oven has been correctly packaged
for transportation. Remove all of the packaging
material before putting the appliance into use.
• The packaging material can be completely
recycled.You can obtain addresses for
environmentally-friendly disposal operations from
your local City Council.
Used appliances
WARNING
• Used appliances must be rendered unusable
prior to disposal so that they no longer present
a risk.To achieve this,disconnect from the mains
supply and remove the power supply cable.

12
Safety
For the protection of the environment,used
appliances must be disposed of properly.
• The appliance must not be disposed of along with
normal domestic waste.
• Your local City Council will inform you of times for
uplifting special waste or identify public disposal
facilities for you.

13
Overview
Oven levels are numbered from the bottom up.
The 5 and 6 levels are mainly used for grill functions. Always grill
with the door closed.
Grilling must be operated with the door closed.
The cooking tables throughout these operating instructions give you
suggested oven settings, however you can change these to suit
yourself.
Note : The rating label is located at the left-hand inner edge of the
door or front-side of the oven.
Appliance description
Control panel
Top-heating
and grill heating
element
Side runners
or Grooves
Door
handle
Halogen heater mesh
Air outlet filter
Door seal
Rear wall heating
element
Rotisserie motor
Meat probe socket
Oven cavity
Level 6
Level 5
Level 4
Level 3
Level 2
Level 1
Rating label
Full glass
door
Oven lights

14
1. Power Key : Power On/Off button
2. Home Key : Go to the home screen
3. Timer Key : Set the timer & Set or disable the child lock
function ((Touch the key for 3 ~ 5 seconds) Input the long
key)
4. Chef’s recipe Key : Go to the Chef’s recipe screen
5. Auto cook Key : Go to the auto cook screen
Control Panel
145
2
3 7
8 96

15
6. Display(TFT Color LCD)
7. UP & Down key : Change the list or data value
8. OK key : Select the list or go to the next step
9. Back key : Cancel and go to the previous step
145
2
3 7
8 96
Note
The operation speed of the ‘Up or Down key’ is about 0.4 sec, when the ‘Up or
Down key’ is pressed for about 0.8 sec.
• Timer
- 0:00 ~ 9:59 min (Increase and decrease by 10 sec), Pressing the ‘Up or Down
key’ for about 0.4 sec (Increase and decrease by 1 min)
- 0:10 ~ 9:59 h (Increase and decrease by 1 min), Pressing the ‘Up or Down
key’ for about 0.4 sec (Increase and decrease by 10 min)
• Duration time (Default : 00:30 h input)
- 0:00 ~ 11:59 h (Increase and decrease by 1 min), Pressing the ‘Up or Down
key’ for about 0.4 sec (Increase and decrease by 1 min)
- 0:10 ~ 9:59 h (Increase and decrease by 1 min), Pressing the ‘Up or Down
key’ for about 0.4 sec (Increase and decrease by 10 min)

16
Accessories
Wire grille
For dishes, baking tins, grilling and
roasting tins.
For grilling meat, place the wire grille on
the upper level above the deep pan.
Baking tray
For cakes, sponges and biscuits.
Deep pan
For moist cakes, for roasting and for
catching roasting juices or fat.
Grill tray
To be placed on top of the deep pan.
Dripping fat is caught in the deep pan
when grilling meat.

17
Tips on using the trays and wire grilles
Ensure that the trays and
wire grilles are properly
fitted onto both sides of
the desired level.
Take particular care
when removing finished
dishes and meals from
the oven!
Use a suitable cloth pot
holder or oven gloves.
If you are using the grill tray in combination with the deep pan or the
baking tray to catch dripping liquids or fat, then do not put the trays
down on the bottom of the oven, slide them into the lower levels.
If you place trays on the oven floor, the resulting build-up of heat
can damage the surface of the oven. For this reason, there must
always be a minimum gap of 2 cm between the accessories and the
oven floor.
Fitting the wire grille, baking tray and deep pan
Slide the tray or wire grille in at
the desired level.
The oven levels are numbered
from the bottom up to the top.
6
5
3
2
1
4
6
5
3
2
1
4
Baking tray
Deep pan
gap 2cm

18
Meat probe
The electronic meat probe enables the
meat temperature to be monitored while
cooking and to assist in giving good
cooking results each time it is used.
Rotisserie
For grilling thicker items such as stuffed
meat, poultry and kebabs. The rotisserie
motor turns the spit to grill food evenly
from all sides. Food does not need to
be manually turned when using the
rotisserie.
Note :
Before using the rotisserie for the first time, it shoult be cleaned with
a combination of hot water and dishwashing liquid.
Accessories

19
Telescopic runners
Attaching the telescopic runners
When fitting the accessories for the first time, attach the
telescopic runners as following procedures.
1. Put the inserting bar of the side
telescopic runner into the hole.
2. Align the front recess with the front
screw hole. Insert and fasten the
screw clockwise.
3. Attach the other telescopic runner in the same way.
4. The baking tray and Wire grille
should be positioned accurately on
the upright pins of the telescopic
runners.
An unstable coupling between the
baking tray and the telescopic
runners may cause the trays to
drop or food to fall onto the oven
floor.
Warning : You should not do self-cleaning with these telescopic
runners or any other accessories in the oven.
Because self-cleaning is performed at high temperature
(about 500°C), the telescopic runners and utensils may
become distorted and become unuseable.

20
Booting
(System initialization)
When the oven is connected to
the electrical supply, it will switch
on automatically and the LG
logo will appear in the display.
After the LG logo appears in
the display, you can set the
language.
1
Press the Up( )or
Down( ) key until the
language you want is
highlighted in the display.
2
Press the OK key to confirm
your selection.
The clock settings menu will
then appear in the display.
When the oven Is rst switched
on the clock will show 00:00 until
you have set the correct time.
Set the clock using the Up( )
and Down( ) key and OK key.
See "General setting - Clock"
for details. The Main menu will
then appear in the display. The
factory default setting for the
clock is 24h.
Tip : When you set the clock
or temperature if you press
and hold the Up( )or Down
( ) key for about 2 seconds,
the hours and minutes can be
changed more easily.
Before using for the first time
