LG 42PT200 User manual

.LG
Life's Good
PLASMA TV
Please read this manual carefully before operating
your set and retain it for future reference.
42PT200
50PV400 42PT250U 42PT350C
50PT200
60PV400 50PT250U 50PT350C
42PT330 50PV430
50PV550U
50PV450C
50PT330 60PV430
60PV550U
60PV450C
42PT350 50PV450
50PT350
60PV450
PING: MFL62861007 (1102-REV01)
Printed in Mexico
www.lg.com

WARNING
WARNING
TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER TO
QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead
Asymbol, within an equilateral triangle,
IA is intended to alert the user to the
presence of uninsulated "dangerous
voltage" within
the product's enclosure that may
be of sufficient magnitude to constitute arisk of
electric shock to persons.
A The exclamation point within an equilateral
~ triangle is intended to alert the user to
the presence of important operating
and maintenance (servicing) instructions
in the
literature accompanying the appliance.
WARNING
TO REDUCE THE RISK OF FIRE AND ELECTRIC
SHOCK,
DO NOT EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.
This reminder
is provided to call the CATV system
installer's attention
to Article 820-40 of the National
Electric Code (U.s.A.). The code provides guidelines
for
proper grounding and, in particular, specifies that the
cable ground shall be connected
to the grounding system
of the building, as close to the point of the cable entry
as practical.
To prevent fire or shock hazards, do not expose
this product to rain or moisture.
Class Bdigital device
This equipment has been tested and found to com-
ply with the limits
for a Class Bdigital device, pur-
suant
to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference
in aresidential installation. This
equipment generates,
uses and can radiate radio fre-
quency energy and,
if not installed and used in accor-
dance with the instructions,
may cause harmful inter-
ference
to radio communications. However, there is
no guarantee that interference will not occur in apar-
ticular installation.
If this equipment does cause
harmful interference
to radio or television reception,
which
can be determined by turning the equipment
off and on, the user is encouraged to try to correct
the interference
by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment
and
receiver.
-Connect the equipment to an outlet on acircuit dif-
ferent from that
to which the receiver is connected.
-Consult the dealer
or an experienced radio/TV
technician for help.
This device complies with part
15 ofthe FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause (harmful) interference,
and (2) this device must accept any interference
received, including interference
that may cause unde-
sired operation
(of the device).
Any changes
or modifications in construction of this
device which
are not expressly approved by the party
responsible
for compliance could void the user's
authority to operate the equipment.
Do
not attempt to modify this product in any way
without written authorization from LG Electronics.
Unauthorized modification could void the user's
authority
to operate this product
;
!
I
A IMPORTANT INFORMATION TO PREVENT "IMAGE BURN
/ BURN-IN" ON YOUR TV SCREEN
When afixed image (e.g. logos, screen menus, video game, and computer display) is displayed on the TV
for an extended period, it can become permanently imprinted on the screen. This phenomenon is known
as "image burn" or "burn-in." Image burn is not covered under the manufacturer's warranty.
In
order to prevent image burn, avoid displaying afixed image on your TV screen for aprolonged period
(2 or more hours for LCD, 1 or more hours for Plasma).
Image burn
can also occur on the letterboxed
areas
of your TV if you use the 4:3 aspect
ratio setting
for an extended period.
2

SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
~
.",,;:' Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles,
and the point where they exit from
the apparatus.
Only use attachments/accessories specified by
the manufacturer.
Use only with
the cart, stand, tripod, bracket,
or table specified by the manufacturer, or sold
with
the apparatus. When a cart is used, use
caution when moving
the cart/apparatus com-
bination
to avoid injury from tip-over .
Clean only with
soft dry cloth.
•
Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions. •
(I)
S3125A~
Do not install near any heat sources such as
radiators,
heat registers, stoves, or other
apparatus (including amplifiers)that produce
heat.
Do
not defeat the safety purpose of the polarized
or grounding-type plug. Apolarized plug has
two
blades with one wider than the other. A
grounding type plug has two blades and a
third
grounding prong, The wide blade or the
third prong are provided for your safety. If the
provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet. (Can differ by country)
Unplug this apparatus during lighting storms
or when unused for long periods of time.
Refer
all servicing to qualified service personnel.
Servicing
is required when the apparatus has
been damaged in any way, such as power-
supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or
has been dropped.
3

SAFETY INSTRUCTIONS
Never touch this apparatus or antenna during
a
thunder or lighting storm.
When mounting aTV on the wall,
make sure
not to install the TV by the hanging power and
signal cables on the back
of the TV.
WARNING - To reduce the risk of fire or electrical
shock,
do not expose this product to rain,
moisture
or other liquids. Do not touch the TV
with wet hands. Do not install this product
near flammable objects such as gasoline or
candles or expose the TV to direct air
conditioning.
Do not allow an impact shock or any objects to
fall into the product, and do not drop onto the
screen with something.
DISCONNECTING DEVICE FROM MAINS
Mains plug is the disconnecting device. The
plug must remain readily operable.
Do not expose to dripping or splashing and do
not place objects filled with liquids, such as
vases, cups, etc. on or over the apparatus (e.g.
on shelves above the unit).
GROUNDING
Ensure that you connect the earth ground wire
to prevent possible electric shock (i.e. aTV
with athree-prong grounded
AC plug must be
connected
to athree-prong grounded AC out-
let). If grounding methods are not possible,
have aqualified electrician install aseparate
circuit
breaker.
Do not try to ground the unit by connecting it
to telephone wires, lightening rods, or gas
pipes.
Power
Supply
•
~
Short-circuit
Breaker
.•• r,~
CAUTION concerning the Power Cord:
It is recommend that appliances be placed
upon a dedicated circuit; that is, asingle
outlet circuit which powers only that appliance
and has
no additional outlets or branch
circuits. Check the specification page of this
owner's manual
to be certain.
Do not connect too many appliances to the
same AC power outlet as this could result in
fire
or electric shock.
Do not overload wall outlets. Overloaded wall
outlets, loose
or damaged wall outlets, extension
cords, frayed power cords,
or damaged or
cracked wire insulation are dangerous. Any of
these conditions could result in electric shock
or fire. Periodically examine the cord of your
appliance, and if its appearance indicates damage
or deterioration, unplug it, discontinue use of
the appliance, and have the cord replaced with
an exact replacement part by an authorized
servicer. Protect the power cord from physical
or mechanical abuse, such as being twisted,
kinked, pinched, closed
in adoor, or walked
upon.
Pay particular attention to plugs, wall
outlets, and the point where the cord exits the
appliance.
Do not make the TV with the power cord
plugged in.
Do not use adamaged or loose
power cord.
Be sure do grasp the plug when
unplugging
the power cord. Do not pull on the
power cord
to unplug the TV.
"As long as this unit is connected to the AC wall
outlet, it is not disconnected from the AC power
source
even if you turn off this unit by SWITCH"
4

ANTENNAS
Outdoor antenna grounding
(Can differ by country) If an outdoor antenna
is installed, follow the precautions below. An
outdoor antenna system should not be located
in the vicinity
of overhead power lines or other
electric light
or power circuits, or where it can
come in contact with such power lines or cir-
cuits
as death or serious injury can occur.
Be sure the antenna system is grounded so as
to provide some protection against voltage
surges and built-up static charges.
Section 810
of the National Electrical Code
(NEC)
in the U.s.A. provides information with
respect
to proper grounding of the mast and
supporting structure, grounding
of the lead-in
wire
to an antenna discharge unit, size of
grounding conductors, location of antenna dis-
charge unit, connection
to grounding elec-
trodes and requirements for the grounding
electrode.
Antenna grounding according to the
National Electrical Code, ANSI/NFPA 70
Ground Clamp
Antenna Discharge Unit
(NEG Section 810-20)
Grounding Conductors
(NEG Section 810-21)
Ground Clamps
.,.., Power Service Grounding
____ Electrode System (NEG
Art 250. Part H)
NEC: National Electrical Code
Cleaning
When cleaning, unplug the power cord and
scrub gently with asoft cloth
to prevent
scratching. Do
not spray water or other liquids
directly on the
TV as electric shock may occur.
Do
not clean with chemicals such as alcohol,
thinners
or benzene.
Moving
Make sure the product is turned off,
unplugged and
all cables have been removed. It
may take 2 or more people to carry larger TVs.
Do not press against or put stress on the front
panel
of the TV.
Ventilation
Install your TV where there is proper ventila-
tion. Do
not install in aconfined space such as
abookcase. Do not cover the product with
cloth
or other materials (e.g.) plastic while
plugged
in. Do not install in excessively dusty
places.
Take care not to touch the ventilation open-
ings. When watching the TV
for along period,
the ventilation openings
may become hot. This
does
not affect the performance of the product
or
cause defects in the proudct.
If you smell smoke or other odors coming from
the
TV or hear strange sounds, unplugthe power
cord contact
an authorized service center.
Do not press strongly upon the panel with
hand
or sharp object such as nail, pencil or
pen, or make ascratch on it. Do not allow a
impact shock
onto the panel.
Keep the product away from direct sunlight.
Dot Defect
The Plasma or LCD panel is ahigh technology
product with resolution
of two million to six
million pixels. In avery few cases, you could see
fine dots on the screen while you'reviewing the
TV. Those dots are deactivated pixels and do
not affect the performance and reliability of the
TV.
Generated Sound
"Cracking" noise: Acracking noise that occurs
when watching
or turning off the TV is gener-
ated by plastic thermal contraction due
to
temperature and humidity. This noise is com-
mon
for products where thermal deformation
is required.
Electrical circuit humming/panel buzzing: Alow
level noise is generated from ahigh-speed
switching circuit, which supplies alarge
amount
of current to operate aproduct. It
varies depending on the product.This generat-
ed sound does not affect the performance and
reliability
of the product.
5

CONTENTS
WARNING .
SAFETY INSTRUCTIONS.
PREPARATION
2
.3
WATCHING TV
Turning On TV
Initial Setting .
On-Screen Menus Selection
13
.13
.14
Accessories
Stand Instructions
Cable Management.
Desktop Pedestal Installation
Swivel Stand
VESA Wall Mounting.
.... .7
8
.10
10
. .10
11
APPENDIX
Maintenance.
Troubleshooting .
Product Specifications
15
16
.. 18
EXTERNAL EQUIPMENT SETUP
Connecting your TV
12
HOW TO USE THE OWNER'S MANUAL ON THE CD-ROM
To view the Owner's Manual on the CD-ROM, Adobe Acrobat Reader must be installed on your Pc.
The "ACRORD" folder
on the CD-ROM contains the installation prol;?rams for them.
If you want to install those programs, Open the "My Computer -Open the "LG"- Open the
"ACRORD"-double-click your language.
TO VIEW THE OWNER'S MANUAL ON THE CD-ROM
The Owner's Manual files are included in the supplied CD-ROM.
Load the supplied CD-ROM into the CD-ROM drive
of your Pc.
After awhile, the
web page of the CD-ROM will open automatically. (for Window only)
,)LG
'-LG
........
I, 1I
........
'"
",",'-"
I
When you click, display the PDF file.
You can find the
desired contents
easily using the
bookmark.
1'-- _
6
oNOTE
If the web page does not appear automatically, open the Owner's Manual file directly.
Open the
"My computer"-Open the "LG" -Open the "index.htm" file.

PREPARATION
ACCESSORIES
Ensure that the following accessories are included with your TV. If an accessory is missing, please contact the
dealer where you purchased the TV.
The accessories included may differ from the images below.
D
Owner's Manual
CD Manual
Protection Cover and Tape
(Refer
to P.9) Power Cord Ferrite Core
(Depending on model)
Power
Cord Holder
1/' A40 ....
M5x24
M4x28
(For 60PV400, 60PV430, 60PV4S0,
60PV4S0C,60PVSSOU)
M5x14.5
M4x26
(For 421S0PT200. 421S0PT330, 421S0PT3S0,
42/S0PT3SOC, 42/S0PT2S0U,SOPV400,
SOPV430, SOPV4S0, SOPV4S0C, SOPVSSOU)
Screws for stand assembly
(Refer
to P8, 9)
Screws for stand assembly
(Refer
to P8, 9)
Remote Control,
Batteries
(AAA)
Cable Holder
Polishing
Cloth
(Not included with all models)
Wipe spots on the exterior only with
the polishing cloth.
Do not wipe roughly when removing
spots.
Excessive pressure may cause
scratch or discoloration.
Option Extras
D-sub 15 pin Cable
When using the VGA (D-sub 15 pin cable)
PC connection. the user must use shielded
signal interface cables with ferrite cores
to
maintain standards compliance.
[Cross Section of
Ferrite Core]
[to
the TV]
[to an External device]
How to use the Ferrite Core
1. Use the ferrite core to reduce the electromagnetic interference in the PC audio cable.
Wind
the PC audio cable on the ferrite core thrice. Place the ferrite core close to the TV.
,~~~
~1,'=~==tlLy
[Figure 1J
2. Use the ferrite core to reduce the electromagnetic interference in the power cable.
Wind
the power cable on the ferrite core once. Place the ferrite core close to the TV.
[to a wall plug]
=======L:k:J
=--
~:i \ '.
~;\ ..
[Figure 2J
[to the TV]
[Cross Section of
Ferrite Core]
3. Use
the ferrite core to reduce the electromagnetic interference in the power cable.
Wind
the power cable on the ferrite core once. Place the ferrite core close to the TV and a wall plug.
[to a
wall plug] cU==.:=. ===1:~ [to the TV]
[Figure 3]
-
If there is one ferrite core. follow as shown in Figure 1.
- If there are two ferrite cores. follow as shown in Figures 1 and 2.
-
If there are three ferrite cores. follow as shown in Figures 1 and 3.38
[Cross Section of
Ferrite CoreJ
7

PREPARATION
STAND INSTRUCTION
!li Image shown may differ from your TV.
Installation
Carefully place the TV screen side down on a
cushioned surface to protect the screen from
damage.
Assemble the parts of the Stand Body with the
Stand Base of the TV.
Stand Body
,-~
I " ' ;
L __ .~ I
iStand Base
M5x24
M5x14.5
(For 60PV400, 60PV430. 60PV4S0.
60PV4S0C. 60PVSSOU)
(For 42/S0PT200, 42/S0PT330. 42/S0PT3S0,
42/S0PT3S0C, 42/S0PT2S0U. SOPV400.
SOPV430. SOPV4S0.S0PV4S0C. SOPVSSOU)
Assemble the TV as shown.
Fix the 4screws securely using the holes in the -
back
of the TV.
M4x28 M4x26
(For 60PV400. 60PV430. 60PV4S0,
60PV4S0C.60PVSSOU)
(For 421S0PT200. 421S0PT330. 42/S0PT3S0,
42/S0PT3S0C, 42/S0PT2S0U. SOPV400.
SOPV430, SOPV4S0. SOPV4S0C. SOPVSSOU)
8

Detachment
-~ Carefully place the TV screen side down on a
cushioned surface to protect the screen from
damage.
Loose the screws from TV.
M4x28 M4x26
(For 60PV400, 60PV430, 60PV4S0, (For 42/S0PT200, 42/S0PT330, 42/S0PT3S0,
60PV4S0C,60PVSSOU) 42/S0PT3S0C,42/S0PT2S0U,SOPV400,
SOPV430, SOPV4S0, SOPV4S0C,SOPVSSOU)
." Detach the stand from TV.
~~:j;}
After removing the stand, install the included
PROTECTION COVER over the hole for
the stand.
Attach the protection cover tape.
When installing the wall mounting bracket, use
the PROTECTION COVER.
/CJOCJ
~~~
6
Attach the protection
cover tape.
PROTECTION COVER
Fix aGuide to the Outsides.
9

PREPARATION
CABLE MANAGEMENT
Image shown may differ from your TV.
Install the power cord holder and power cord.
It will help prevent the power cable from being removed by accident.
'l5 FGather and bind the cables with the cable holder.
POWER CORD
HOLDER
t-.
CABLE HOLDER
DESKTOP PEDESTAL INSTALLATION
"! Image shown may differ from your TV.
For proper ventilation, allow aclearance of 4inches on all four sides from the wall.
A. CAUTION
Ensure adequate ventilation by following the clearance recommendations.
Do
not mount near or above any type of heat source.
SWIVEL STAND
(This feature is not available for all models.)
4inches
After installing the TV, you can adjust the TV manually to the left or right direction by 20 degrees to suit your
viewing position.
10

VESA WALL MOUNTING
Install your wall mount on asolid wall perpendicular to the floor. When attaching to other building materials, please
contact your nearest installer.
If installed on aceiling or slanted wall, it may fall and result in severe personal injury.
We recommend that you use an LG brand wall mount when mounting the TV to awall.
LG recommends that wall mounting be performed by aqualified professional installer.
VESA (A * B) Wall Mounting
Model •Standard Screw Quantity bracket
(sold separately)
42150PT200,
42150PT330,
42150PT350,
42/50PT350C, PSW400B,
50PV400,
400.400 M6 4PSW400BG,
50PV430,
50PV450, DSW400BG
50PV450C,
42/50PT250U,
50PV550U
60PV400,
60PV430,
60PV450.
600.400
M8
4PSW600B,
60PV450C, PSW600BG
60PV550U
oNOTE
Screw length needed depends on the wall mount
used.
For further information, refer to the instruc-
tions included with the mount.
Standard dimensions
for wall mount kits are shown
in the table.
When purchasing our wall
mount kit, adetailed
installation manual and all parts necessary
for
assembly are provided.
Do
not use screws longer then the standard dimen-
sion,
as they may cause damage to the inside to
the TV.
For wall mounts that do not comply with the VESA
standard screw specifications, the length of the
A. CAUTION
screws may differ depending on their specifica-
tions.
-Do
not use screws that do not comply with the
VESA standard screw specifications.
Do
not use fasten the screws too strongly, this may
damage the
TV or cause the TV to afall, leading to
personal injury. LG is not liable for these kinds of
accidents.
LG is not liable for TV damage or personal injury
when anon-VESA or non specified wall mount is
used or the consumer fails to follow the TV installa-
tion instructions.
Do not install your wall mount kit while your TV is turned on. It may result in personal injury due to electric shock.
11

EXTERNAL EQUIPMENT SETUP
CONNECTING YOUR TV
To connect an additional equipment, see the External Equipment Setup section in CD Manual.
•Typical Layout
HOMI
is the best way to connect adevice.
If
it's not available, move down the list in
order until you find a
connection that's
available on each device.
OJ HOMI
(i~ OVI
'---
i1
(~
L~J
AUOIOIN
(AC8lMl
,,) Component
() Composite
Use HOMI to connect
external devices
when
available. If not available,
use OVI or Component.
Sorry, Aphono
Jack to
stereo 1/8" (0.32 cm)
headphone plug
adapter
is not included.
It is available from most
stores
that carry elec-
tronics.
OPTICAl AUotO IN
A=~(RGBlDVQ
o@
Use Composite
for the video
connection
if
available.
Match the jack
colors.
You can use aadapter to connect OVI
to HOMI, but you will only have 2
channel stereo for sound. The adapter
is not needed when connecting aPc.
Antenna/Cable
Use this connection when you need to con-
nect directly
to an antenna or cable system
instead
of using acable box.
rAntenna
'------I-~
or
Cable TV
12
RF Coaxial Wire
(75 n)
Be careful not
to bend the
copper wire.

WATCHING TV
TURNING ON TV
"'~.'
. ;~
First, connect power cord correctly.
At this moment,
TV is in standby mode.
lEln standby mode to tum TV on, press the 6/1 , INPUT, CH (A
CH( A or v), Number (0-9) button on the remote control.
or v) button on the TV or press the POWER, INPUT,
Select the viewing source by using the IN P UT button on the remote control.
C:, When finished using the TV, press the POWER button on the remote control. The TV reverts to standby mode.
_;r
INITIAL SETTING
This Function guides the user to easily set the essential items for viewing the TV for the first time when pur-
chasing the TV. It will be displayed on the screen when turning the TV on for the first time. It can also be acti-
vated from the user menus.
II Default selection is "Home Use". We recommend setting the TV to "Home Use" mode for the best picture
in your home environment.
III "Store Demo" Mode is only intended for use in retail environments. Customers can adjust the "Picture
menu - Picture mode" manually while inspecting the TV, but the TV will automatically return to preset in-
store mode after 5minutes.
III You can also adjust Initial Setting in the OPTION menu.
Factory defaults are set when you choose "Home Use".
II> If you do not complete the Initial setting, it will appear whenever the TV is switched on until the Initial
setting procedure is completed.
Step1. Welcome Step4. Time setting
Time setting
WELCOME!
Thank you for choosing lG
@NeKt
1/- --\'------------'
\ [E~ERJ .
""'" ." ,'/
Step2. language Selecting
Current Time Setting '.,1m·E ,
Year I~.'---'J
Month [I
Date I I
Hour L. J
Minute C=-~
Time Zone ~~---.J
Daylight Saving i--Auto ----···1
Language
0'. Previous @Next
English
[EsP' not ..--J
lFra~~~~ ~
1-
",---".
~~"~'
l _~ I'!,.l!j' Select menu Language .
.. -------','" .
Step3. Mode setting StepS. Auto Tuning
Mode Setting
Auto Tuning
:'~i()ctjng the en\"HCiVillnt
Choose' ,<he- scH,ng n'odf> :-oOlI ,,"Jan I
Select Home Use mode. Start
Auto Tu ning.
@Nel(t
:,--'. Previous
Check your antenna connection.
The previous channel
information will be updated
during Auto Tuning.
,.
. [EN~ERl
@Next
~"-. Previous
Except
42/S0PT2S0U,
SO/60PVSSOU
L-
13

WATCHING TV
ON-SCREEN MENUS SELECTION
Your TV's OSD (On Screen Display) may differ slightly from that shown in this manual.
Except 421S0PT2S0U, SO/60PVSSOU
42/S0PT2S0U.
SO/60PVSSOU
; Enter
.... I----For
. Enter
.> Move
.:- Move "Enter
.:. Move
I
: Off
: Off t·.) +3
:Standard
•Infinte Surround: Off
oTreble 50-
•Bass 50-
•Reset
:On
USB
r-------------
I Photo List
Music list
Movie List
IDivX Reg. Code
IDeactivation
AUDIO
I Auto Volume-
IClear Voice II
IBalance
1Sound Mode
I
!
I TV Speaker
INPUT
.:. Move Enter
m
",
,Q ,
~
0-l
~;: r~I:~-
. . Off Time : Off
e-_A_U_D_I_O_.J TIME IOn Time : Off
~
. n. JSleep Timer: Off
:- I
t.~ :
USB !
I
INPUT .;. M... . En ... I
,---------
lTV
I AV1
IAV2
IComponent1
Component2
RGB-PC
HDMI1
HDMI2
HDMI3
Asoed Ratio :16:9
Picture Wizard ,
el1l Energy Saving : Off
Picture Mode :Standard
•Contrast 90-
•Brightness 50 -
• Sharpness 60 -
oColor 60-
-Tint O~
T
CHANNEL
Lock System : Off
Set Password
Block Channel
TV Rating-English
TV Rating-French
Downloadable Rating
Input Block
iOn
I .• T
:, ~PTION ~
:Home Use '
rI
: Off
: Off
: Off
:1
: Normal
.:. Mow." Enter
.:. Moy~ •Enter
LOCK
CHANNEL
f- Aut~ Tu~;n~
I Manual Tuning
IChannel Edit
I
i
i
I
I __ ----,- _
----" II
i- • ~
OPTION
I L>nguag~
I Input Label
ISIMPLINK
Key Lock
I
ICaption
Demo
Mode
i 15M Method
!SetiD
I Initial Setting
f' Lock System : Off
ISet Password
iBlock Channel
I Movie Rating
I TV Rating-Children
I TV Rating-General I
I
Downloadable Rating ~'
I Input Block
, -------
(Depending on model)
For 42/S0PT3S0. 42/S0PT3S0C,
SO/60PV4S0, SO/60PV4S0C,
42/S0PT2S0U,SO/60PVSSOU
For 42/S0PT3S0, 421S0PT3S0C,
SO/60PV4S0, SO/60PV4S0C,
42/S0PT2S0U. SO/60PVSSOU
1
--
Home Display each menu.
Select amenu item.
3
rN~ERJ Accept the current selection.
4
EXIT.' Return to
TV viewing.
14

APPENDIX
MAINTENANCE
Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of time you can
enjoy your new TV.
Caution: Be sure to turn the power off and unplug the power cord before you begin any cleaning.
Cleaning the Screen
Here's agreat way to keep the dust off your screen for awhile. Wet a soft cloth in amixture of lukewarm
water and alittle fabric
softener or dish washing detergent. Wring the cloth until it's almost dry, and then
use it
to wipe the screen.
Make sure
the excess water is off the screen, and then let it air-dry before you turn on your TV.
Cleaning the Cabinet
To remove dirt or dust, wipe the cabinet with asoft, dry, lint-free cloth.
Please be sure
not to use awet cloth.
Extended Absence
A, CAUTION
If you expect to leave your TV dormant for along time (such as avacation), it's a good idea to unplug
the power cord to protect against possible damage from lightning or power surges.
15

APPENDIX
TROUBLESHOOTING
Abnormal Operation
*This feature is not available for all models.
16
The remote control
doesn't work
Power is suddenly
turned
off
Video PrOblems
No picture &No sound
Picture appears slowly
after switching on
No or poor color
or poor picture
Horizontal/vertical bars
or picture shaking
Poor reception on
some channels
Lines or streaks
in pictures
No picture
when connecting HOMI
Check
to see if there is any object between the product and the remote control
causing obstruction.
Ensure you are pointing the remote control directly at the TV.
Ensure that the batteries are installed with correct polarity (+ to +, - to -).
Ensure
that the correct remote operating mode is set: TV, VCR etc.
Install
new batteries.
Is the sleep timer set?
Check the power control settings.
Power interrupted.
TV will
be automatically turned off, in case of no signal for 15 minutes.
Check whether the product
is turned on.
Try another channel. The problem
may be with the broadcast.
Is the power cord inserted into wall power outlet?
Check
your antenna direction and/or location.
Test
the wall power outlet, plug another product's power cord into the outlet
where the product's power cord was plugged in.
This
is normal, the image is muted during the product startup process. Please
contact your service center, if the picture has not appeared after five minutes.
Adjust
Color in menu option.
Keep asufficient distance between the
product and the VCR.
Try another channel. The problem may be with the broadcast.
Are the video cables installed properly?
Activate any function
to restore the brightness of the picture.
Check
for local interference such as an electrical appliance or power tool.
Station
or cable product experiencing problems, tune to another station.
Station signal
is weak, reorient antenna to receive weaker station.
Check
for sources of possible interference.
Check antenna (Change the direction
of the antenna).
If an HOMI cable doesn't support High Speed HOM, it can cause flickers or no
screen display.
In this case use the latest cables that support High Speed HOMI.

Audio Problems
Picture OK & No sound
No output from one
of the speakers
Unusual sound
from
inside the product
Press the
VOL or VOLUME button.
Sound muted? Press MUTE button.
,
Try another channel. The problem may be with the broadcast.
., Are the audio cables installed properly?
,Adjust Balance
in menu option.
Achange
in ambient humidity or temperature may result in an unusual noise
when the product
is turned on or off and does not indicate afault with the
product.
No sound
when connecting
HDMI/USB
Check High Speed HDMI cable.
"Check USB cable over version 2.0.
;~ Use normal MP3 file.
'This feature is not available for all models.
- --~
PC Mode Problems
The signal is out of range
Vertical bar or stripe on
background &
Horizontal Noise &
Incorrect position
Screen color
is unstable
or single color
"Adjust resolution. horizontal frequency.
or vertical frequency.
'" Check the input source.
,
Work the Auto configure or adjust clock. phase. or H/V position. (Option)
,- Check the signal cable.
Reinstall the
PC video card.
r - -----.------- -.-- . ------ .- . - -- .. -. -- - .. ---- --
! Movie list Problems
The file does not
appear on the Movie List.
Message is displayed
saying "This
file is
invalid" or the audio is
working normally but
the video is not working
normally.
Message
is displayed
saying "Unsupported
Audio" or
the video is
working normally but
the audio is not working
normally.
Subtitle
is not working.
Check whether the
file extension is supported.
Check whether the
file is playing normally on a Pc.
(Check whether thefile
is damaged.)
Check whether the resolution
is supported.
.Check whether the video/audio codec
is supported.
Check whether the frame rate
is supported.
Check whether the
file is playing normally on aPc.
(Check whether thefile
is damaged.)
Check whether the audio codec
is supported.
Check whether the bit rate
is supported.
Check whether the sample rate
is supported.
Check whether the
file is playing normally on a Pc.
(Check whether thefile
is damaged.)
Check whether the video
file and subtitle file name are the same.
Check whether
the video file and subtitle file are located in the same folder.
Check whether the subtitle
file is supported.
Check whether the language
is supported. (When you open the subtitle file on a
PC, you can check the language of the subtitle file.)
17

18
APPENDIX
PRODUCT SPECIFICATIONS
-
MODEL 42PT200 (42PT200-UB) SOPT200 (SOPT200-UB)
42PT2S0U (42PT2S0U-UA) SOPT2S0U (SOPT2S0U-UA)
Dimensions With stand
987.6 mm x 662.8 mm x 230.5 mm
1171.9mm x 770.9 mm x289.8 mm
(Width xHeight
(38.8 inch x 26 inch x9 inch)
(46.1 inch x 30.3 inch x 11.4 inch)
xDepth) Without stand
987.6 mm x 608.9 mm x 52.5 mm 1171.9 mm x 712.2 mm x 52.5 mm
(38.8 inch x 23.9 inch x2 inch)
(46.1 inch x 28 inch x2 inch)
Weight With stand
21.4 kg (47.1 Ib)
29.5 kg (65 Ib)
Without stand
19.9 kg (43.8Ib)
27.2 kg (59.6 Ib)
Current Value I Power consumption
2.1 A/210W 3.0A/300W
42PT330 (42PT330-UB) SOPT330 (SOPT330-UB)
MODEL 42PT3S0 (42PT350-UD) \ SOPT3S0 (SOPT3S0-UD)
42PT3S0C (42PT3S0C-UD) SOPT3S0C (50PT350C-UD)
Dimensions With stand
991.8 mm x 667 mm x 230.5 mm 1176.1 mm x 774.7 mm x289.8 mm
(Width xHeight
(39 inch x 26.2 inch x9 inch) (46.3 inch x 30.5 inch x 11.4 inch)
XDepth) Without stand
991 .8 mm x 613.8 mm x 52.5 mm 1176.1 mm x 716.5 mm x 52.5 mm
(39 inch x 24.1 inch x2 inch) (46.3 inch x 28.2 inch x2 inch)
Weight With stand
21.5 kg (47.3 Ib) 29.6 kg (65.2 Ib)
Without stand 20
kg (44lb) 27.3 kg (60.1 Ib)
Current Value I Power consumption
2.1 A/210W 3.0A/300W
SOPV400 (SOPV400-UB) 60PV400 (60PV400-UB)
SOPV430 (50PV430-UC) 60PV430 (60PV430-UC)
MODEL SOPV4S0 (50PV450-UA) 60PV4S0 (60PV4S0-UA)
SOPV4S0C (SOPV450C-UA) 60PV4S0C (60PV450C-UA)
Dimensions With stand
1168.4 mm x 770.9 mm x289.8 mm
1387.4 mm x 905.2 mm x 334.7 mm
(Width xHeight
(46 inch x 30.3 inch x 11.4 inch)
(54.6 inch x 35.6 inch x 13.1 inch)
xDepth) Without stand
1168.4 mm x 712.2 mm x 52.5 mm
1387.4 mm x 834.7mm x 52.5 mm
(46 inch x 28 inch x2 inch)
( 54.6 inch x 32.8 inch X 2.6 inch)
Weight With stand
29.6 kg (65.2 Ib)
42.6 kg (93.9 Ib)
Without stand
27.3 kg (60.1 Ib) 38.5 kg (84.8 Ib)
Current Value I Power consumption
3.3 AI 300 W 4.6A/460W
MODEL SOPVSSOU (50PVSSOU-UC) 60PVSSOU (60PVSSOU-UC)
Dimensions With stand
1172.3 mm x 770.9 mm x 289.8 mm 1390.4 mm x 905.2 mm x 334.7 mm
(Width xHeight
(46.1 inch X 30.3 inch X 11.4 inch)
(54.7 inch x 35.6 inch X 13.1 inch)
xDepth) Without stand
1172.3 mm x 712.2 mm x 52.5 mm 1390.4 mm x 835.5mm x 52.5 mm
(46.1 inch x 28 inch x2 inch) ( 54.7 inch x 32.8 inch x2 inch)
Weight With stand
29.8 kg (65.6Ib) 42.6 kg (93.9 Ib)
Without stand
27.5 kg (66.6Ib) 38.5 kg (84.8 Ib)
Current Value I Power consumption
3.3 AI 300 W
4.6A/460W

Power requirement
Television System
Program Coverage
External Antenna
Impedance
AC 100-240 V - 50/60 Hz
NTSC-M, ATSC, 64 & 256 QAM
VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135
75 Q
Environment
condition
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
32 - 104 T (0 - 40 "C)
Less than 80%
-4 - 140 of (-20 - 60°C)
Less than 85'7'0
The specifications shown above may be changed without prior notice for quality improvement.
19

The ,-nodel and sefla! number of TV Is located
on the bcc1CK and one side of the
F~,,,c:ord it below shouid you evel need service
MODEL
SERIAL
!s n"!cHiuals thi:JT contain informc]
features of thiS LG TV are
In an electronic
CD-ROVl dllve.
1...G Customer Information Center
For inquires or comments; visit www.lge.com or
1-888-542-2623 CANi\DA
1-800-243-0000 Consumer
1-888-865-3026 U Commercial
Register your product Online!
www.lg.com
