LG SC105 User manual

Owner's Manual
Laser Display Screen
Please read the safety information carefully before using the product.
www.lg.com
P/NO : MFL67864905 (1307-REV01)
SC105

2SAFETY PRECAUTIONS
SAFETY PRECAUTIONS
Please take note of the safety instructions to prevent any potential accident or misuse
of the product.
 Safety precautions are given in two forms, i.e. Warning and Caution as detailed below.
WARNING: Failure to follow the instructions may cause serious injury and even
death.
CAUTION: Failure to follow the instructions may cause minor injury or damage to
the product.
 Read the owner's manual carefully and keep it at hand.
CAUTION
 Follow the instructions in the manual
to install the product.
- Otherwise, it may cause serious
injury or damage to the product.
 When installing the product or
adjusting the height of the product,
two or more people are needed.
- If you do it by yourself, you may
drop the product causing personal
injury or damage to the product.
 When installing the product, check
whether the wall is strong enough to
hold the product and use the
anchors and screws provided.
- Otherwise, the product could fall
causing safety issues.
Installation
WARNING
 The product should be installed by a
qualified professional specified by the
retail store.
- The product installation by a non-
qualified personnel is dangerous
and may cause personal injury.
 The product should be installed
where its weight can be supported.
- Otherwise, the product may fall and
cause personal injury.
 When moving or replacing the
product after installation, contact a
qualified installer specified by the
retail store.
- If an unqualified person moves and
installs the product, this may cause
safety issues as this task requires
the special technique.
 Do not hang on the product or apply
shock to the product.
- The product may fall and cause
injury.

3
SAFETY PRECAUTIONS
CAUTION
 When drilling the holes in the wall,
make sure you use a drill and a drill
bit with the specified size of diameter.
Ensure that you also follow the
instructions regarding the depth of
the holes.
- Otherwise, the product may be
installed improperly causing safety
issues.
 Do not clean the product with wet
towels, and do not use a heater or
humidifier underneath the product.
- Moisture permeating into the
product, steam or heat may result in
fire, electric shock or damage to the
product.
 Keep the product away from sprin-
klers, sensors, high-tension wires
and power sources. Do not install the
product in a location where vibrations
or shock impacts are likely to occur.
 Wear working gloves when installing
the product. Do not use bare hands.
- Otherwise, it may cause personal
injury.
 Do not place the product where it is
directly exposed to the light.
- The image may look dark due to
the light.

4PREPARATION
PREPARATION
Accessories
Check the accessories provided with the product.
The picture may be different from the actual product.
Accessories are subject to change without prior notice in order to improve the perfor-
mance of the product. New accessories may be added or old ones may be removed.
Preparations
Drill (M6, M8), leveler, tapeline, driver, tape
Up
Down
8 anchors for
attaching rings
(Ф8)
8 bolts for attaching
rings (Ф8) Magnet 15 EA Paper template
Tape 6 EA
1 sheet of warp
correction sponge 2 Rings
1 piece of tape to
attach the paper
template
18 Steel Spacers 1 warp correction ring Safety lock pin
2 EA Thread

5
INSTALLATION
INSTALLATION
Fixing the Anchor, Screw
CAUTION
 Check the material of the wall and the thickness of the finishing.
 
Use the anchors for wall material of concrete, light concrete, strong natural
stone, soft natural stone masonry
 brick and hallow block that do not crack.
 
When installing the product on wall material not designated, install the
product so that each fixated location can withstand the pull out load of 70
kgf (686 N) and shear load of 100 kgf (980 N) or above.
a. Use a drill bit Ø8 mm to drill a hole for the anchor location within a depth of
80 mm - 100 mm.
b. Clean the drilled hole.
c. Insert the sealed anchor to the hole. (When inserting the anchor, use a hammer.)
d. Set the wall mount on the wall by aligning to the location of the hole. and, set the
angle adjusting part to face upward.
Align the wall mount bolt to the hole and tighten it. Then, fasten the bolts at torque
of 45 kgf/cm - 60 kgf/cm.
ab
c
d
Anchor
Ring and Space steel fixing screw

6INSTALLATION
INSTALLATION STEP
1 Attach a paper screen to the place where the screen will be located. (The paper
screen helps to easily install the adjustable bracket and bore holes in the wall.)
2Two people lift the screen up until its bottom edge is level to the magnets at the
bottom of the paper screen. Put the screen close to the wall aligning with the loca-
tions marked with the tapes and hang the brackets on the rings by carefully pulling
it down.
CAUTION
 Align the top of screen with the top of the tape and the left and right sides of
the screen with the tape. Hang the bracket on the rings by lowering the screen
carefully. If the screen is upside down, the screen will be dark and no image will
be displayed.

7
INSTALLATION
<Ceiling type>
Tape
Down
Up
Magnet
Down
Up

8INSTALLATION
<Stand type>
Tape
Down
Up
Magnet
Down
Up

9
INSTALLATION
CAUTION
 If the screen is tilted when pulling it down, the screen may not fix to the bracket
and result in damage to the screen.
3Move the screen in all directions to check whether the screen is securely hung on
the rings.

10 SPECIFICATIONS
SPECIFICATIONS
1272 1073
142
2030
2245
147
Model SC105
Width (mm)
2245 ± 5 mm
Height (mm)
1272 ± 3 mm
Frame Height (mm)
12.0 ± 1.0 mm
Depth (mm)
9.1 ± 0.2 mm
Weight (kg)
32.30 kg
