The BX403B is a business projector that features high brightness and
a semi short throw. Perfect for smaller rooms that cannot afford large
projection distances; the BX403B can project a 100” diagonal
image from only 2.5 meters (8’2”). DLP technology combined with
a native 1024x768 XGA resolution renders images and color with
incredible accuracy. Its 4,000 ANSI-lumens high brightness also
makes the BX403B capable of displaying a bright and easily
viewed picture. Even in the most challenging projector placements,
this projector displays captivating video, stills and presentations with
superb image quality.
ADVANCED DIGITAL KEYSTONE CORRECTION (H/V)
Square the image with digital precision even when
the projector is at an off-angle
PICTURE STILL
Using the remote, the projector can freeze a motion image
from any input source
EXPERT COLOR CONTROL
Separately control the contrast, saturation, and the tone of all colors
BRILLIANT COLOR™
Increase brightness in non-primary colors and amplify color mid-tones
VIDI™ TECHNOLOGY
Increase brightness and enhances contrast
using the electronics of the lamp system
6-SEGMENT COLOR WHEEL
elps provide a better balance of color and brightness
QUICK POWER ON/OFF
AUTO SLEEP
DLP®PROJECTOR BX403B
w w w. LG s o l u t i o n s . c o m
XGA DLP Semi Short-Throw Projector
projector
for Classroom an Conference
Room

specifications
projector
LG Electronics U.S.A., Inc.
Commercial Displays Group
2000 Millbrook Drive
Lincolnshire, IL 60069
Customer Service: 888.865.3026
www.LGsolutions.com/support
Contact your LG Regional Sales Representative:
Hospitality: 800.228.1236
Vertical Markets: 800.897.8788
C annel: 800.897.8871
Healt care: 877.793.6484
Customer Service: 888.865.3026
E-mail: [e-mail]
SPEC_BX403B_011114_PR
All screen images are simulated. Dimensions and weights are approximate. Design,
features and specifications subject to change without notice.
© Copyright 2011 LG Electronics USA, Inc. All Rights Reserved. “LG Life’s Good” is a
registered trademark of LG Corp.
DMI, the DMI Logo and igh-Definition Multimedia Interface are trademarks or
registered trademarks of DMI Licensing. DLP is a trademark of Texas Instruments. All
other product and brand names are trademarks or registered trademarks of their
respective companies.
Printed in the USA. January 2011
www.LGsolutions.com
PROJECTION SYSTEM
Display Technology 0.7" DMD (DDP3020)
Native Resolution XGA (1024x768)
Brightness (ANSI-Lumens) 4000
Contrast Ratio (FIFO) 2800:1
Noise igh Brightness 33dB
Economic 30dB
Uniformity >80%
Color Wheel 6 segment (RGBWYC)
Projection Lens Focus Manual
Zoom Manual 1.2x
Projection Image Standard 100" @ 2.5m (4:3) Semi Short Throw
Throw Ratio 1.23 to 1.47
Image Size (Diagonal) 40" to 300"
Projection Offset 100%
Lamp Life igh Brightness 2000 hrs
Life Economic 2500 hrs
GENERAL SPECIFICATIONS
Menu Language Korean/English/French/Spanish/German/Italian/Swedish
Portuguese/Chinese Simplified/polski/Brazilian/Portuguese/
Turkish / Japanese
Aspect Ratio Control Native 4:3, Support 16:9 & 15:10
Dimension (inch) Wx xD 15.9" x 5.4" x 11.5"/ eight 5.6" (With Leg)
Weight (lbs) 12.8 lbs
Power Consumption 380W (Maximum)/ Under 1W (Standby)
Power Supply AC 100~240V (Free Voltage), 50/60 z
Input Signal Compatibility Digital (DVI, DMI) 1080i/720p/576p/480p up to SXGA+
(1400 x 1050 @ 60 z)
RGB up to SXGA+ (1400 x 1050@60 z)
Component 1080i/720p/576p/576i/480p/480i
Composite NTSC-M/NTSC 4.43/PAL/PAL-M/PAL-N/SECAM
INPUT/OUTPUT Terminals
RGB In/ Out 2/1
Composite (AV) In 1
Component (YPbPr) 1 (thru RGB)
RS-232C 1
RJ45 1 (Ethernet)
DMI 1 (Ver 1.3)
USB(SVC) 1 (For service only)
SPECIAL FEATURES Advanced Keystone Correction ( /V), Auto Source Detection,
Picture Still, Quick Power on/off, Auto Sleep, Blank (Blue, Green,
Black, Logo, Captured image), Image Flip ( /V), Color
Temperature Control, Over Scan (0~10%), Brillant Color™,
Black Level Control ( igh/Low), Expert Color Control (Only YUV
format of DMI Input), VIDI™, Kensington®Lock Port
ACCESSORIES Owner’s Manual, Remote Control, AAA Battery (2 ea.),
Power Code, D-sub 15 pin cable
WARRANTY/UPC
Limited Warranty 2 Year Parts and Labor / 90 days for lamp
BX403B 719192579347
AJ-LDX5 (Lamp) 719192579163
BX403B DLP PROJECTOR
REAR REMOTE
CONTROL SENSOR
USB
(SVC Only)
RS-232C
HDMI IN
RGB IN-1
RJ45 VIDEO
RGB OUT
15.9”
11.5”
5.4”
RGB IN-2
