LG LRTPC1831NI Service User manual

LRTPC1831NI
LRTPC2031NI
REFRIGERATOR-
FREEZER
OWNER'S MANUAL
PLEASE
READ THIS OWNER'S MANUAL THOROUGHLY
BEFORE OPERATING AND KEEP IT HANDY
FOR REFERENCE AT ALL TIMES.
RÉFRIGÉRATEUR-
CONGÉLATEUR
MANUEL DE L’UTILISATEUR
LISEZ ATTENTIVEMENT CE MANUEL AVANT FAIRE
FONCTIONNER L’APPAREIL ET CONSERVEZ-LE
POUR TOUTE RÉFÉRENCE À TOUT MOMENT.
REFRIGERADOR-
CONGELADOR
MANUAL DE INSTRUCCIONES
LEA ESTE MANUAL DE INSTRUCCIONES
DETENIDAMENTE Y GUÁRDELO COMO
REFERENCIA PARA EL FUTURO.
P/NO. 3828JD8315K
website: http://www.lgservice.com
e-mail: http://www.lgeservice.com/techsup.html
3828JD8315K(O/M)˙¥`01.10.2410:15AM ˘`1

2
TABLE OF
CONTENTS
REFRIGERATOR SAFETY ........................... 3
INSTALLING YOUR REFRIGERATOR ......... 4
Unpacking Your Refrigerator ....................... 4
Installation .................................................... 4
Electrical Requirements ............................... 5
FEATURES CHART ...................................... 6
OPERATION .................................................. 7
Starting ........................................................ 7
Temperature Control .................................... 7
Defrosting .................................................... 8
Disassembly and Adjustment ...................... 9
SUGGESTIONS ON FOOD STORAGE ...... 10
CLEANING YOUR REFRIGERATOR ......... 11
LAMP REPLACEMENT ............................... 12
GENERAL INFORMATION ......................... 12
REPLACEMENT OF
DOOR OPENING TYPE .............................. 13
BEFORE CALLING FOR SERVICE ............ 16
ICE MAKER INSTALLATION ...................... 17
Water Connection Instruction Guide .......... 17
Operation Instruction Guide ....................... 19
Trouble Shooting ....................................... 21
3828JD8315K(O/M)¿ (2~21)01.10.2410:15AM˘`2

ENGLISH ESPAÑOLFRANÇAIS
3
REFRIGERATOR SAFETY
Proper Disposal of
Your Old Refrigerator
IMPORTANT - Child entrapment and
suftocation are not problems of the past.
Junked or abandoned refrigerators are still
dangerous - even if they will sit for just a few
days. If you are getting rid of your old
refrigerator, please follow these instructions to
help prevent accidents.
Before you throw away your old
refrigerator or freezer:
■Take off the
doors.
■Leave the shelves
in place so that
children may not
easily climb
inside.
Your safety and the safety of others is very important.
We have provided many important safety messages in this manual and on your appliance.
Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to hazards that can kill or hurt you and others.
AII safety messages will be preceded by the safety alert symbol and the word
DANGER or WARNING. These words mean:
You will be killed or seriously injured if
you don’t follow instructions.
You can be killed or seriously injured if
you don’t follow instructions.
All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell
you what can happen if the instructions are not followed.
w
ww
DANGER
ww
WARNING
IMPORTANT SAFETY INSTRUCTIONS
WARNING:
To reduce the risk of fire, electric shock, or injury when using your refrigerator,
follow these basic precautions:
SAVE THESE INSTRUCTIONS
■Plug into a grounded 3-prong outlet.
■Do not remove ground prong.
■Do not use an adapter.
■Do not use an extension cord.
■Disconnect power before servicing.
■Replace all panels before operating.
■Remove doors from your old refrigerator.
■Use nonflammable cleaner.
■Keep flammable materials and vapors,
such as gasoline, away from refrigerator.
■Use two or more people to move
refrigerator using handles and install
refrigerator.
■Disconnect power before installing ice
maker.
(on some models)
Suffocation Hazard
Remove doors from your old refrigerator.
Failure to do so can result in death or
brain damage.
ww
DANGER
3828JD8315K(O/M)¿ (2~21)01.10.2410:16AM˘`3

4
INSTALLING YOUR
REFRIGERATOR
Unpacking Your Refrigerator
Remove tape and any temporary labels from
your refrigerator before using. Do not remove
any warning type labels, the model and serial
number label, or the Tech Sheet that is
attached to back wall of the refrigerator.
To remove any remaining tape or glue, rub the
area briskly with your thumb. Tape or glue residue
can also be easily removed by rubbing a small
amount of liquid dish soap over the adhesive with
your fingers. Wipe with warm water and dry.
Do not use sharp instruments, rubbing alcohol,
flammable fluids, or abrasive cleaners to remove
tape or glue. These products can damage the
surface of your refrigerator. For more
information, see Important Safety Instructions
in the Refrigerator Safety section.
Refrigerator shelves are installed in the
shipping position.
Please reinstall shelves according to your
individual storage needs.
Installation
1. Avoid placing the unit near heat sources,
direct sunlight, or moisture.
2. To avoid vibration, the unit must be level.
If required, adjust the leveling screws to
compensate for unevenness of the floor.
The front should be slightly higher than the
rear to aid in door closing.
Leveling screws can be turned easily by
tipping the cabinet slightly.
Turn the leveling screws clockwise ( ) to
raise the unit, counterclockwise ( ) to
lower it.
3. Install this appliance between 55 °F (13 °C)
and 110 °F (43 °C.) If the temperature
around the appliance is too low or high,
cooling ability may lessen.
NEXT
1. Clean your refrigerator thoroughly and wipe
off all dust accumulated during shipping.
2. Install accessories such as ice cube bin,
drawers, shelves, etc., in their proper places.
They are packed together to prevent possible
damage during shipment.
3. Let your refrigerator run for 2 or 3 hours
before putting food in it.
Check the flow of cold air in the freezer
compartment to ensure proper cooling.
Your refrigerator is now ready for use.
Excessive Weight Hazard
Use two or more people to move and
install refrigerator.
Failure to do so can result in back or
other injury.
When Moving Your Refrigerator:
Your refrigerator is heavy. When moving the
refrigerator for cleaning or service, be sure
to protect the floor.
Always pull the refrigerator straight out when
moving it.
Do not wiggle or walk the refrigerator when
trying to move it, as floor damage could occur.
ww
WARNING
Explosion Hazard
Keep flammable materials and vapors,
such as gasoline, away from refrigerator.
Failure to do so can result in death,
explosion, or fire.
ww
WARNING
3828JD8315K(O/M)¿ (2~21)01.10.2410:16AM˘`4

ENGLISH ESPAÑOLFRANÇAIS
5
Electrical Requirements
Before you move your refrigerator into its final
location, it is important to make sure you have
the proper electrical connection:
Recommended Grounding Method
A 115 Volt, 60 Hz., AC only 15 or 20 ampere
fused, grounded electrical supply is required. It
is recommended that a separate circuit serving
only your refrigerator be provided. Use an outlet
that cannot be turned off by a switch. Do not
use an extension cord.
NOTE: Before performing any type of
installation, cleaning, or removing a light bulb,
turn the control, (Thermostat, Refrigerator, or
Freezer Control depending on the model) to
OFF and then disconnect the refrigerator from
the electrical source. When you are finished,
reconnect the refrigerator to the electrical
source and reset the control (Thermostat,
Refrigerator, or Freezer Control, depending on
the model) to the desired setting.
Electrical Shock Hazard
Plug into a grounded 3-prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can
result in death, fire, or electrical shock.
ww
WARNING
3828JD8315K(O/M)¿ (2~21)01.10.2410:16AM˘`5

6
FEATURES CHART
Egg Tray
FREEZER
COMPARTMENT
REFRIGERATOR
COMPARTMENT
Freezer Temperature
Control Dial
Freezer Shelf
Door Cooling
On the refrigerator door,
the cold air passageway is
installed to supply
cold air to the doorside of
the refrigerator
compartment.
Temperature
Control Dial
Lamp
Shelves
Egg Box
Snack Corner
Crisper
Used to keep fruits
and vegetables
fresh and crisp.
Freezer Door Bin
Lamp
Refrigerator Door
Rack
Can Server
Can Storage
Adjustable
Door Bin
Leveling Screw
(Inside)
Base Grille
Push the grille toward
the refrigerator
until it snaps
into place.
Dairy Corner
Automatic Ice Maker
and Ice Cube Box
3828JD8315K(O/M)¿ (2~21)01.10.2410:16AM˘`6

ENGLISH ESPAÑOLFRANÇAIS
7
OPERATION
Starting
When your refrigerator is first installed, allow to
run 2-3 hours to stabilize at normal operating
temperature prior to filling it with fresh or frozen
foods.
If operation is interrupted, wait 5 minutes before
restarting.
Temperature Control
❒REFRIGERATOR
■Your refrigerator has two controls that let you
regulate the temperature in the freezer and
refrigerator compartments.
■Initially set the REFRIGERATOR CONTROL
at 5 and the FREEZER CONTROL at 2.
Leave it at this setting for 24 hours (one day)
to stabilize.
Then adjust the compartment temperature
according to your desire.
■REFRIGERATOR CONTROL - 1, 2, 3, 4, 5,
6, 7, 8
The higher the number setting, the colder the
refrigerator compartment will become.
■To turn the refrigerator off, turn the dial to the
right to the word “off”.
❒FREEZER
■FREEZER CONTROL - 1, 2, 3
Setting at 3, the freezer compartment
becomes colder.
But the refrigerator compartment becomes
warmer because less cold air flows into the
refrigerator compartment.
■In cold weather the unit operates less and
the freezer compartment has a tendency to
warm up.
For a colder freezer, turn the FREEZER
CONTROL to 3.
■If you put a lot of food in the freezer or open
its door frequently, its temperature is apt to
be somewhat higher. In this case, set the
FREEZER CONTROL dial at 3 to cool it.
Return the FREEZER CONTROL dial to the
original position to cut down the consumption
of energy.
■In hot weather or if a lot of food is put in
the refrigerator compartment, the
refrigerator compartment has a tendency to
warm up.
For a colder refrigerator, turn the FREEZER
CONTROL to 1 to direct more cold air into
the refrigerator compartment, and the
REFRIGERATOR CONTROL to 6~8.
If the FREEZER CONTROL is set at 3, the
refrigerator compartment will not be cold
enough.
5
1
3
2
1
2
3
Freezer Control
Min
Normal
Max
REFRIGERATOR CONTROL
3828JD8315K(O/M)¿ (2~21)01.10.2410:16AM˘`7

8
Defrosting
■Defrosting takes place automatically.
■Defrosted water flows down to the
evaporating tray which is located in the lower
back side of the refrigerator and is
evaporated automatically.
Adjusting the Crisper
Humidity Control
You can control the amount of humidity in the
moisture-sealed crispers. Adjust the control to
any setting between Veg. and Fruit.
■Fruit (open) lets moist air out of the crisper
for best storage of fruits.
■Veg. (closed) keeps moist air in the crisper
for best storage of fresh, leafy vegetables.
Freezer Shelf
Lift the front side of the shelf slightly and pull it
forward to remove it.
Adjusting Shelves
The shelves in your refrigerator are adjustable
to make room for various types of food.
■To remove a shelf
Tilt up the front of the shelf in the direction of
(1) and lift it in the direction of (2). Pull the
shelf out.
■To replace a shelf
Tilt the front of the shelf up and guide the
shelf hooks into the slots at a desired height.
Then lower the front of the shelf so that the
hooks drop into the slots.
Veg. Fruit
3828JD8315K(O/M)¿ (2~21)01.10.2410:16AM˘`8

ENGLISH ESPAÑOLFRANÇAIS
9
■Encouraged shelf position
If you put shelf on the place indicated by
arrow, it is profitable for the food storage.
Sliding out Shelves
You can slide some glass shelves in and out of
your refrigerator as follows.
■To slide shelf out, carefully pull front of shelf
toward you.
■To slide shelf in, push shelf in until it stops.
Snack Corner
While holding it with one hand, pull it forward
slightly.
Lift it slightly and pull it out.
Make sure that a shelf is placed
horizontally.
Failure to do so may result in falling of
the shelf, causing spilling or spoiling of
food.
ww
CAUTION
3828JD8315K(O/M)¿ (2~21)01.10.2410:16AM˘`9

10
SUGGESTIONS ON
FOOD STORAGE
Storing Food
■Store fresh food in the refrigerator
compartment. How food is frozen and
defrosted is an important factor in
maintaining freshness and flavor.
■Do not store food which spoils easily at low
temperatures, such as bananas, pineapples,
and melons.
■Allow hot food to cool prior to storing. Placing
hot food in the refrigerator could spoil other
food, and lead to high electricity bills!
■When storing, wrap food in vinyl, or place in
a covered container. This prevents moisture
from evaporating, and helps food to keep its
taste and nutritional value.
■Do not block air vents with food. Smooth
circulation of chilled air keeps the refrigerator
temperature even.
■Do not open the door frequently. Opening the
door lets warm air enter the refrigerator,
causing temperature to rise.
■To adjust the temperature control easily, do
not store food near the temperature control
dial.
Freezer Compartment
■Do not store bottles in the freezer
compartment - they may break when frozen.
■Do not refreeze food that has been
defrosted. This causes loss of taste and
nutritional value.
■When storing frozen food, like ice cream, for
a long period, place it on the freezer shelf,
not in the door rack.
Refrigerator Compartment
■Avoid placing moist food on deep interior
refrigerator shelves, it could freeze upon
direct contact with chilled air. To avoid this, it
is better to store food in a covered container.
■Always clean food prior to refrigeration.
Vegetables and fruits should be washed and
wiped, and packed food should be wiped
clean, to prevent other food from spoiling.
■If you keep the refrigerator in a hot and
humid place, frequently opening the door
or putting a lot of vegetables in it may
cause dew to form. This has no effect on
its performance. Remove the dew with a
dry, dust-free cloth.
■If droplets form beneath the cover of the
vegetable drawer, keep vegetables or
fruits wrapped with plastic wrap.
NOTE
3828JD8315K(O/M)¿ (2~21)01.10.2410:16AM˘`10

ENGLISH ESPAÑOLFRANÇAIS
11
CLEANING YOUR
REFRIGERATOR
Both the refrigerator and freezer sections
defrost automatically. However, clean both
sections about once a month to prevent odors
from building up. Wipe up spills immediately.
To clean your refrigerator.
■Unplug refrigerator or disconnect power.
■Remove all removable parts from inside,
such as shelves, crispers, etc.
■Use a clean sponge or soft cloth and a mild
detergent in warm water. Do not use
abrasive or harsh cleaners.
■Hand wash, rinse, and dry all surfaces
thoroughly.
■Plug in refrigerator or reconnect power.
■Additional cleaning tips are listed below:
PART
Outside
Inside walls
(allow
freezer to
warm up so
cloth won’t
stick)
Door liners
and gaskets
Plastic parts
(covers and
panels)
Condenser
coils
COMMENTS
■Waxing external painted
metal surfaces helps provide
rust protection. Do not wax
plastic parts. Wax painted
metal surfaces at least twice
a year using appliance wax
(or auto paste wax). Apply
wax with a clean, soft cloth.
■For products with a stainless
steel exterior, use a clean
sponge or soft cloth and a
mild detergent in warm
water. Do not use abrasive
or harsh cleaners. Dry
thoroughly with a soft cloth.
■To help remove odors, you
can wash the inside of the
refrigerator with a mixture of
baking soda and warm water.
Mix 2 tablespoons soda to 1
quart of water (26 g soda to 1
liter water.) Be sure the soda
is completely dissolved so it
is not abrasive and doesn’t
scratch the surfaces of the
refrigerator.
■Do not use cleaning waxes,
concentrated detergents,
bleaches, or cleaners
containing petroleum on
plastic parts.
■Do not use paper towels,
window sprays, abrasive
cleansers, or flammable
fluids. These can scratch or
damage material.
■Remove base grille. (See
the Base grille section on
page 6.)
■Use a vacuum with an
extended attachment to
clean condenser coils.
■Vacuum coils when dusty or
dirty.
Coils may need to be
cleaned as often as every
other month.
■Replace base grille.
Explosion Hazard
Use nonflammable cleaner.
Failure to do so can result in death,
explosion, or fire.
ww
WARNING
3828JD8315K(O/M)¿ (2~21)01.10.2410:16AM˘`11

12
LAMP
REPLACEMENT
To Change Refrigerator Lamp:
1. Unplug the power cord from the outlet.
2. Remove refrigerator shelves.
3. Upper Refrigerator Lamp.
Release the hooks on both ends of the lamp
shield and pull the shield downward to
remove it.
4. Turn the lamp counterclockwise.
5. Assemble in reverse order of disassembly.
Replacement bulb must be the same
specification as original.(Max 40 W)
To Change Freezer Lamp:
1. Unplug refrigerator or disconnect power.
2. Reach behind lamp shield to remove bulb.
3. Replace bulb with a 25-watt appliance bulb.
4. Plug in refrigerator or reconnect power.
GENERAL
INFORMATION
Vacation Time
During average length vacations, you will probably
find it best to leave the refrigerator in operation.
Place freezable items in freezer for longer storage.
When you plan to be away for an extended period,
■Disconnect the power cord or set refrigerator
Dial knob to off position.
■ Remove all food and other items from the unit.
■Clean the unit thoroughly.
■Leave the shelves in the unit to discourage
children from playing in the unit.
■Leave the doors open and block them to
ensure that they cannot be closed.
Power Failure
Most power failures are corrected in an hour or
two and will not affect your refrigerator
temperatures. However, you should minimize the
number of door openings while the power is off.
During power failures of longer duration, place a
block of dry ice on top of your frozen packages.
If You Move
Remove or securely fasten down all loose items
inside the refrigerator.
To avoid damaging the leveling screws, turn
them all the way into the base.
Anti-Condensation Pipe
The outside wall of the refrigerator cabinet may
sometimes get warm, especially just after
installation. Don't be alarmed. This is due to the
anti-condensation pipe, which pumps hot refrigerant
to prevent sweating on the outer cabinet wall.
■Dry ice is very cold! Do not allow it to
touch bare skin. It is well below 0 °F and
will cause immediate frostbite and damage
to the skin and other tissue.
■Dry ice is frozen carbon dioxide. Use only
in a well ventilated area. As the ice
releases carbon dioxide vapor, it could
cause light-headedness, fainting,
suffocation, or death.
ww
CAUTION
Anti-Condensation
Pipe
3828JD8315K(O/M)¿ (2~21)01.10.2410:16AM˘`12

ENGLISH ESPAÑOLFRANÇAIS
13
REPLACEMENT OF
DOOR OPENING TYPE
How to Replace the Door
Opening Left to Right
(when converting from the
left-opening type to right
opening type)
1. Removing Freezer Door
■Separate the top hinge cover (1).
■Loosen 3 screws and separate off the top
hinge (2).
■Lift the freezer door (3) sightly and separate it.
■Separate the cover (4) using a (-)-
screwdriver and fix it on the right.
■Loosen the screw (5), separate off the
stopper (6), and fix it on the left (on the
opposite side).
■Separate the cover (7) using a (-)-
screwdriver and fix it on the right.
■Separate off (8).
2. Removing Refrigerator Door
■Loosen the screw (9) and separate off the
middle hinge (10).
■Lift the door (11) sightly and separate it.
■Take off the Grille (12).
■Loosen the screw (14) and fix the pin (15)
and the cap (16) into the hole on the left.
■Remove the screw (17).
■Loosen the screw (18). Separate the bottom
hinge (20) and fix it on the left.
■Fix the screw(17) on the right.
■Loosen the screw (22) and fix the stopper
(23) on the left.
1. Before replacing the door opening type,
first of all, you should take out of food and
accessories like shelves or trays, which
are not fixed in the refrigerator.
2. Use a ‘+’Driver, Bolt Driver, Torque
Wrench or Spanner to fix or remove the
bolt.
3. Be careful not to tip over the refrigerator
in disassembling or assembling the Lower
Hinge and the Adjustable Screw
Asm.Don’t lay the refrigerator down when
working it will cause it to malfunction.
4. Be careful not to drop the door in
disassembling or assembling the freezer
or the refrigerator door.
5. This refrigerator, according to the
installation position or user’s preference
can have the door opening from the right
or left.
ww
PRECAUTION
3
4
9
10
11
5
6
8
7
14
15 16
18
23
22
20
17
12
1
2
3828JD8315K(O/M)¿ (2~21)01.10.2410:16AM˘`13

14
3. Moving Freezer Handle
■Loosen 2 screws (4).
■Loosen the screws (1) (two on the top and
two on the bottom), take off the handle (2),
and reverse the handle(2), and attach it on
the right.
■Attach the removed 2 screws (4) on the left.
■Attach the cap (3) on the top on the opposite
side.
4. Moving Refrigerator Handle
■Loosen 2 screws(8).
■Loosen the screws(5) (two on the top and
two on the bottom), take off the handle(6),
and reverse the handle(6), and attach it on
the right.
■Attach the removed 2 screws (8) on the left.
■Attach the cap(7) on the top on the opposite
side.
31
1
4
2
75
8
5
6
3828JD8315K(O/M)¿ (2~21)01.10.2410:16AM˘`14

ENGLISH ESPAÑOLFRANÇAIS
15
5. Attaching Refrigerator Door
■Fix the base Grille (1).
■Fix the door (3) to the bottom hinge pin.
■Fix the middle hinge (4) on the opposite side
with the screw (5).
6. Attaching Freezer Door
■Place the washer (6) to the middle hinge pin
(7).
■Place the door (8) so that it fit (5) into the
middle hinge pin (7).
■Fix the top hinge(10) with screws.
■Fix top hinge cover (11).
7. After Completing the job
■Make sure that the four corners of the door
gasket are not folded. It is recommended to
apply a small amount of silicon grease on
them.
■Adjust the leveling screw on the bottom to
the highest level so that the front side of the
refrigerator is higher than the rear side.
■If you need assistance after switching the
direction of the door opening as shown
above, call a service center.
11
4
1
3
5
67
8
7
10
Corner
3828JD8315K(O/M)¿ (2~21)01.10.2410:16AM˘`15

16
BEFORE CALLING FOR SERVICE
SERVICE CALLS CAN OFTEN BE AVOIDED!
IF YOU FEEL YOUR REFRIGERATOR IS NOT OPERATING PROPERLY, CHECK THESE
POSSIBLE CAUSES FIRST:
Customer Assistance Numbers:
■To Prove Warranty Coverage
Retain your Sales Receipt to prove date of purchase.
A copy of your Sales Receipt must be submitted at the time warranty service is provided.
■To Obtain Product, Customer or Service Assistance
Call Toll-free for Customer Service
Tel : [phone]
■To Obtain Nearest Authorized Service Center
Call 1-800-243-0000, push option #1, 24 hours a day, 7days per week.
Please have your product type (Monitor, TV, VCR, MWO, Refrigerator) and ZIP code ready.
PROBLEM
REFRIGERATOR DOES NOT
OPERATE
REFRIGERATOR OR
FREEZER COMPARTMENT
TEMPERATURE TOO WARM
ABNORMAL NOISE(S)
REFRIGERATOR HAS ODOR
DEW FORMS ON THE
CABINET SURFACE
POSSIBLE CAUSES
■Has a house fuse blown or circuit breaker tripped?
■Has the power cord plug been removed or loosened from
the electrical wall outlet?
■Temperature control not set on proper position.
■Appliance is placed close to wall or heat source.
■Warm weather-frequent door openings.
■Door is not closed entirely.
■Door left open for a long time.
■Large amount of foods are kept in the refrigerator.
■Refrigerator is installed in a weak or uneven place or
leveling screw needs adjusting.
■Unnecessary objects placed in the back side of the
refrigerator.
■Foods with strong odors should be tightly covered or
wrapped.
■Interior needs cleaning.
■Not unusual during periods of high humidity.
■Door may have been left ajar.
3828JD8315K(O/M)¿ (2~21)01.10.2410:16AM˘`16

ENGLISH ESPAÑOLFRANÇAIS
17
ICE MAKER
INSTALLATION
Water Connection
Instruction Guide
❒Connecting the Refrigerator to a
Water Source
Read all directions carefully before you
begin.
❒ Tools required:
■Standard screwdriver
■7/16 - inch and 1/2 - inch open-end wrenches
or two adjustable wrenches
■1/4 - inch nut driver
■ 1/4 - inch drill bit
■Hand drill or electric drill (properly grounded)
❒ Cold Water Supply:
The ice maker water valve contains a flow
washer which is used as a water pressure
regulator.
The ice maker needs to be connected to a
cold water line with water pressure 207 ~
827 kPa (30 ~ 120 psi).
If a problem occurs, call your utility
company.
Connect to potable water supply only.
ww
WARNING
IMPORTANT
■If operating the refrigerator before
installing the water connection, turn ice
maker to the OFF position to prevent
operation without water.
■All installations must be in accordance
with local plumbing code requirements.
■Use copper tubing and check for leaks.
■Install copper tubing only in areas where
temperatures will remain above freezing.
■It may take up to 24 hours for your ice
maker to begin producing ice.
Your refrigerator dealer has a kit available
with a 1/4 - inch saddle-type shut - off valve,
a union, and copper tubing. Before
purchasing, make sure a saddle-type valve
complies with your local plumbing codes. Do
not use a piercing-type or 3/16 - inch saddle
valve which reduces water flow and clogs
more easily.
NOTE
3828JD8315K(O/M)¿ (2~21)01.10.2410:16AM˘`17

18
❒ Connect the Tubing to Water Line :
1. Unplug refrigerator or disconnect power.
2. Turn OFF main water supply. Turn ON
nearest faucet long enough to empty water
pipes.
3. Find a 1/2 - inch to 1-1/4 - inch vertical COLD
water pipe near the refrigerator.
4. To determine the length of copper tubing you
will need, measure from the connection on
the lower left rear of the refrigerator to the
water pipe. Add 7 feet (2.1m)to allow for
moving refrigerator for cleaning. Use 1/4 -
inch O.D. (outside diameter) copper tubing.
Be sure both ends of copper tubing are cut
square.
5. Using a grounded drill, drill a 1/4 - inch hole
in the cold water pipe you have selected.
6. Fasten shut - off valve to cold water pipe with
pipe clamp. Be sure outlet end is solidly in
the 1/4-inch drilled hole in the water pipe and
that the washer is under the pipe clamp.
Tighten packing nut. Tighten the pipe clamp
screws carefully and evenly so washer
makes a watertight seal. Do not over tighten
or you may crush the copper tubing,
especially if soft (coiled) copper tubing is
used. Now you are ready to connect the
copper tubing.
7. Slip compression sleeve and compression
nut on copper tubing as shown. Insert end of
tubing into outlet end squarely as far as it will
go. Screw compression nut onto outlet end
with adjustable wrench.
Do not over tighten.
8. Place the free end of the tubing into a
container or sink, and turn ON main water
supply and flush out tubing until water is
clear. Turn OFF shut - off valve on the water
pipe. Coil copper tubing.
Horizontal pipe will work, but the following
precaution must be taken: Drill on the top
side of the pipe, not the bottom. This will
help keep water away from the drill. This
also keeps normal sediment from collecting
in the valve.
NOTE
Cold Water Pipe
Pipe Clamp
Coil of polyethylene or
Copper Tubing
Compression NutCompression Sleeve
Shut Off Valve
Packing Nut
3828JD8315K(O/M)¿ (2~21)01.10.2410:16AM˘`18

ENGLISH ESPAÑOLFRANÇAIS
19
Operation Instruction Guide
❒ Connect the Tubing to the
Refrigerator
Before making the connection to the
refrigerator, be sure the refrigerator power
cord is not plugged into the wall outlet.
1. Remove the plastic flexible cap from the
water valve.
2. Place the compression nut and ferrule
(sleeve) onto the end of the tubing as shown.
3 Insert the end of the copper tubing into the
water valve connection as far as possible.
While holding the tubing, tighten the fitting.
❒ Turn the Water on at the Shutoff
Valve
Tighten any connections that leak.
■Plug In the Refrigerator
Arrange the coil of copper tubing so that it
does not vibrate against the back of the
refrigerator or against the wall. Push the
refrigerator back to the wall.
■Start the lcemaker
Set the ice making stop switch to the ON
position The icemaker will not begin to
operate until it reaches its operating
temperature of 15 °F (-9 °C) or below. It will
then begin operation automatically if the ice
making stop switch is in the ON position.
Copper tubing
(Provided)
Compression nut
(Provided)
Ferrule (sleeve)
Water valve
The icemaker may double-cycle when it first
starts, causing some water to spill from the
icemaker into the ice bucket. This is normal
and should not happen again.
NOTE
3828JD8315K(O/M)¿ (2~21)01.10.2410:16AM˘`19

20
❒ Automatic Ice Maker
■The automatic ice maker can automatically
make 14 pieces of ice cube at a time, 110-
120 pieces a day.
But these quantities may be varied according
to various conditions including how many
times the refrigerator door opens and closes.
■Ice making stops when the ice storage bin is
full.
❒ When Ice Maker does not operate
smoothly
Ice is clumped together
■ When ice is clumped together, take the ice
clumps out of the ice storage bin, break them
into small pieces, and then place them into
the ice storage bin again.
■ When the ice maker produces too small or
clumped ice, the amount of water supplied to
the ice maker need to adjusted. Contact the
service center.
■ If ice is not used frequently, it may clump
together.
Power failure
■ Water may drop into the freezer
compartment. Take the ice storage bin out
and discard all the ice then dry it and place it
back.
The unit is newly installed
■ It takes about 12 hours for a newly installed
refrigerator to make ice in the freezer
compartment.
Throw away the ice (about 20 pieces) first
made after refrigerator installation.
The first ice and water may include particles
or odor from the feed water pipe or feed
water box.
This is also necessary if the refrigerator has
not been used for a long time.
Never store beverage cans or other foods in
ice storage bin for the purpose of rapid
cooling.
Such actions may damage the automatic ice
maker.
Never remove the ice maker cover.
Sometimes level the surface so that the ice
storage bin is fully filled with ice.
Ice may pile up just around the ice maker
causing the ice maker to think that the ice
storage bin is ful.
If discolored ice is dispensed, immediately
contact Service Center. Do not use until
problem is solved.
ww
CAUTION
It is nomal that a noise is produced when ice
made is dropped into the ice storage bin.
NOTE
3828JD8315K(O/M)¿ (2~21)01.10.2410:16AM˘`20
