LG Centric PCS200R Pro User manual

PCS200R Pro:Centric ®Server
Installation & Setup
Quick Reference | Warranty
The latest product information and documentation is available online at:
www.lg.com

2
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert
the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the literature
accompanying the appliance.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Conformity Notice
LG Electronics hereby declares that this product is
in compliance with the following Directives.
EMC Directive 2004/108/EC
LOW VOLTAGE Directive 2006/95/EC
ErP Directive 2009/125/EC
RoHS Directive 2011/65/EU
European representative:
LG Electronics Inc. Krijgsman 1, 1186 DM
Amstelveen, The Netherlands
WEEE
Disposal of your old appliance
1. When this crossed-out wheeled bin symbol is
attached to a product it means the product is
covered by the European Directive 2002/96/EC.
2. All electrical and electronic products should be
disposed of separately from the municipal waste
stream via designated collection facilities ap-
pointed by the government or the local authori-
ties.
3. The correct disposal of your old appliance will
help prevent potential negative consequences
for the environment and human health.
4. For more detailed information about disposal
of your old appliance, please contact your city
ofce, waste disposal service or the shop where
you purchased the product.

3
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufac-
turer’s instructions.
8. Do not install near any heat sources, such
as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the
polarized or grounding-type plug. A polar-
ized plug has two blades with one wider
than the other. A grounding-type plug has
two blades and a third grounding prong.
The wide blade or the third prong are
provided for your safety. If the provided
plug does not fit into your outlet, consult
an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked
on or pinched, particularly at plugs,
convenience receptacles, and the point
where it exits from the apparatus.
11. Only use attachments/accessories
specified by the manufacturer.
12. Use only with the cart, stand, tripod, brack-
et, or table specified by the
manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination
in order to avoid injury from tip-over.
13. Refer all servicing to qualied service per-
sonnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is dam-
aged, liquid has been spilled or objects
have fallen into the apparatus, the appara-
tus has been exposed to rain or moisture,
does not operate normally, or has been
dropped.
14. Power Sources
This product should be operated only from the
type of power source indicated on the marking
label. If you are not sure of the type of power
supply to your INSTALLATION, consult your
product dealer or local power company.
15. Overloading
Do not overload wall power outlets and exten-
sion cords as this can result in a risk of fire or
electric shock.
16. Disconnect Device
The AC mains plug is used as the disconnect
device. The disconnect device must remain
readily operable.
(Continued on next page)
IMPORTANT SAFETY INSTRUCTIONS
• Please read these safety precautions carefully before using the product.
• In this manual, the illustration may be somewhat different from your product because it is just example.
• Manufacturer and installer cannot provide service related to human safety as the applicable wireless
device has possibility of electric wave interference.
WARNING If you ignore the warning message, you may be seriously injured or there is a
possibility of accident or death.
CAUTION If you ignore the caution message, you may be slightly injured or the product may
be damaged.

4
IMPORTANT SAFETY INSTRUCTIONS
(Continued from previous page)
17. Object and Liquid Entry
Never push objects of any kind into this
product through openings as they may touch
dangerous voltage points or short-out parts
that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
Do not use liquid cleaners or aerosol cleaners.
18. Outdoor Use
Warning: To prevent fire or shock hazards,
do not expose this product to rain or mois-
ture.
19. Wet Location
Do not use this product near water or moisture
or in an area, such as a basement, that might
become flooded. The apparatus shall not
be exposed to dripping or splashing and no
objects filled with liquids, such as vases, shall
be placed on the apparatus.
20. Test Equipment
In some cases, LG has supplied or recom-
mended the use of test equipment and devices
for the setup and testing of the equipment. The
operation and maintenance of test equipment is
described in their associated instruction manu-
als. Please refer to these manuals for explicit
instructions regarding the safe use and handling
of the equipment.
21. Damage Requiring Service
Unplug this product from the wall power
outlet and refer servicing to qualied service
personnel under the following conditions:
a. If the power-supply cord or plug is dam-
aged.
b. If liquid has been spilled, or objects have
fallen into the product.
c. If the product has been exposed to rain or
water.
d. If the product does not operate normally by
following the operating instructions. Adjust
only those controls that are covered by the
operating instructions, as an improper
adjustment of other controls may result in
damage and will often require extensive
work by a qualied technician to restore the
product to its normal operation.
e. If the product has been dropped or the cabi-
net has been damaged.
f. If the product exhibits a distinct change in
performance.
Caution: Refer all servicing to qualied
service personnel.
22. Servicing
Caution: These servicing instructions are
for use by qualied service personnel only.
To reduce the risk of electrical shock, do not
perform any servicing other than that
described in the operating instructions
unless you are qualied to do so.
23. Replacement Parts
When replacement parts are required, be sure
the service technician uses replacement parts
specied by the manufacturer or that have the
same characteristics as the original parts.
Unauthorized substitutions may result in re,
electric shock, or other hazards.
24. Safety Check
Upon completion of any service or repairs to
this product, ask the service technician to per-
form safety checks to determine that the prod-
uct is in proper operating condition.
25. Handling Notice
Caution: Only qualified service
personnel should handle and install this
unit. A series of screws with lock washers
are used to secure the top and bottom cov-
ers of the unit. Use caution when handling
the unit as the lock washers may have
rough edges.

5
IMPORTANT SAFETY INSTRUCTIONS
Do NOT run your fingers over the top and
bottom covers of the unit.
26. Do not block any of the ventilation open-
ings. Install in accordance with the manu-
facturer’s instructions.
- The product can be deformed or fire can
break out due to overheating inside the
product.
27. Do not place the product in a built-in instal-
lation such as bookcase or rack.
- Ventilation required.
28. DISCONNECTING DEVICE FROM MAINS
- Mains plug is the disconnecting device.
The plug must remain readily operable.
29. Do not place anything containing liquid on
top of the product such as flowerpot, cup,
cosmetics or candle.
- This may cause a fire hazard.
PCS200R Rack Installation (also see pages 9 to
10)
To install the PCS200R in a rack:
• Carefully slide the PCS200R into a standard 19-
inch equipment rack.
• When mounting in the rack, make sure to use
the appropriate hardware. ALL FOUR MOUNT-
ING SCREWS MUST BE USED.
• This equipment is not designed to support other
devices. Do NOT stack other equipment on the
top of the PCS200R.
• Rear cabling must be dressed and supported so
that the weight of the cabling is not a strain on
the PCS200R connectors.
• MOUNTING OF THE EQUIPMENT IN THE
RACK SHOULD BE SUCH THAT A HAZARD-
OUS CONDITION IS NOT ACHIEVED DUE TO
UNEVEN MECHANICAL LOADING.
Rack-mount Considerations
A. Elevated Operating Ambient
If installed in a closed or multi-unit rack assem-
bly, the operating ambient temperature of the
rack environment may be greater than room
ambient. Therefore, consideration should be
given to installing the equipment in an environ-
ment compatible with the maximum ambient
temperature (Tma) specified by the manufac-
turer. See specifications information in this
document.
B. Reduced Air Flow
Installation of the equipment in a rack should
be such that the amount of air flow required
for safe operation of the equipment is not
compromised. To ventilate the system normally
and avoid overheating, leave at least 1 inch
(2.5 cm) on each side (including top and bot-
tom) of the PCS200R. Do NOT stack other
equipment on the top of the PCS200R. Also,
ensure that the unit’s AC power adapter is
never stacked or bundled with other AC power
adapters. Each adapter should have adequate
ventilation and should be isolated from other
heat sources.
C. Circuit Overloading
Consideration should be given to the
connection of the equipment to the supply
circuit and the effect that overloading of the
circuits might have on overcurrent protection
and supply wiring.
D. Reliable Earthing
Maintain reliable earthing of rack-mounted
equipment. Particular attention should be
given to supply connections other than direct
connections to the branch circuit (e.g. use of
power strips).
E. Mains Outlet Earthing
The apparatus with Class I construction must
be connected to a mains socket outlet with a
protective earthing connection.

6
PCS200R Product Description
Note: Design and specications subject to change without prior notice.
The LG PCS200R Pro:Centric ®server is a stand-alone, remotely-controlled processor
and controller for the Pro:Centric system. The server can be used to capture data from an
Internet source, assemble the data as display pages, and output the pages in DTV format
over ASI, RF, or IP.
Features
• Three output options: ASI, RF, or IP
−ASI output: The PCS200R generates one channel for GEM data only or multiplexed
GEM/site data.
−RF output: Both QAM-B (6 MHz) and DVB-C (7 MHz or 8 MHz) modulations are
supported. The PCS200R generates one 256-QAM or 64-QAM RF channel for GEM/
site data.
−IP output: The PCS200R generates two multicast streams for GEM/site data.
• Provides remote management capability over Ethernet
• Small, lightweight chassis
• 19-inch rack-mountable
• 1U height prole to minimize rack space usage
An Internet browser-based Admin Client graphical user interface (GUI), provided for system
integrator (SI) partners and lodging/institution administrators, facilitates support and main-
tenance of the Pro:Centric system. The Admin Client enables users to remotely manage
system backups, output conguration, software updates, portal/information
section content, TV conguration settings, etc.

7
Setup Information
Check the following items before you begin PCS200R installation and setup procedures.
Note: Once the PCS200R hardware is installed and the initial setup is completed,
output parameters are congured in the Pro:Centric server Admin Client. Along with this docu-
ment, it is recommended that you have a copy of the Pro:Centric Server Admin Client User
Guide readily available.
ASI Output (Optional)
__ If the system is using ASI output, install the modulator and upconverter that will receive
the ASI output signal from the PCS200R. Refer to the manufacturer’s
documentation.
PCS200R
__ Unpack the PCS200R Pro:Centric server unit and all accessories.
PCS200R Accessories: • AC Power Cord and Adapter
__ Select the location for mounting the PCS200R. Ensure adequate ventilation is available .
__ Obtain the necessary attachment hardware to mount the PCS200R chassis in its
targeted location.
__ Plan and install the necessary cabling and network (Ethernet) and AC power access for
the PCS200R. You also will need the following to connect a PC directly to the PCS200R
for system setup purposes: FTDI TTL-USB cable (P/N TTL-232R-5V-AJ).
Refer to the PCS200R Pro:Centric Server Installation & Setup Guide for further
installation and conguration information.
Product documentation is available online at: www.lg.com.

8
Rear and Front Panel Overviews
POWER
12V
ServicePort
FeaturePort Control Port
RF-OUT
ASI-OUT
RF OUT
(0 dBmV)
AC Power
Cord & Adapter
SSD Slot
(for future SATA
solid state drive
functionality)
RF OUT
FEATURE
& CONTROL
(Ethernet) Ports
Service Port
USB Port
(reserved for
future functionality)
RF-OUT
0 dBmV
SSD (OPTIONAL)
MAXIMUM CURRENT +5V DC @ 2.0A
FIRMWAREVER:
Rx.x
MACADDRESS:
<Eth0>
xx:xx:xx:xx:xx:xx
<Eth1>
xx:xx:xx:xx:xx:xx
MODEL:PCS200R DATE: xx/xx/xx
IIIIII IIIIIIII IIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII
*201-1252008*
ASI OUT
Disconnect Device
The AC mains plug is used as the disconnect device.
The disconnect device must remain readily operable.
PWR
POWER LED
PCS200R Rear View
PCS200R Front View
Ventilation
Air flow must not be obstructed. To ventilate the system normally
and avoid overheating, leave at least 1 inch (2.5 cm) on each side
(including top and bottom) of the PCS200R. Do NOT stack other
equipment on the top of the PCS200R.
RF OUT (0 dBmV) Connector
Reserved for service technician use only. When not
in use, this connector must remain terminated with
attached terminator accessory.
Screws with Lock Washers
Only qualified service personnel should handle and install the
PCS200R. A series of screws with lock washers are used to secure
the top and bottom covers of the PCS200R. Use caution when
handling the unit as the lock washers may have rough edges. Do
NOT run your fingers over the top and bottom covers of the unit.

9
PWR
POWER
12V
ServicePort
FeaturePort ControlPort
RF-OUT
ASI-OUT
RF-OUT
0 dBmV
FIRMWAREVER:
Rx.x
MACADDRESS:
<Eth0>
xx:xx:xx:xx:xx:xx
<Eth1>
xx:xx:xx:xx:xx:xx
MODEL:PCS200R DATE:xx/xx/xx
IIIIII IIIIIIII IIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII
*201-1252008*
SSD (OPTIONAL)
MAXIMUM CURRENT +5V DC @ 2.0A
PWR
POWER
12V
ServicePort
FeaturePort ControlPort
RF-OUT
ASI-OUT
RF-OUT
0 dBmV
FIRMWAREVER:
Rx.x
MACADDRESS:
<Eth0>
xx:xx:xx:xx:xx:xx
<Eth1>
xx:xx:xx:xx:xx:xx
MODEL:PCS200R DATE:xx/xx/xx
IIIIII IIIIIIII IIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII
*201-1252008*
SSD (OPTIONAL)
MAXIMUM CURRENT +5V DC @ 2.0A
Rack Installation
Typical Rack Installation
1. (Optional) As shipped, the PCS200R mounting brackets are attached ush with the front of
the unit (see diagram a). If desired, the mounting brackets may be detached from the unit
and reattached, for example, so that they are ush with the rear of the unit (see diagram
b). If you wish to change the location/orientation of the mounting brackets, carefully remove
each of the four (M4 x 10 mm) screws and attendant washers (one at and one lock washer
per screw) holding each bracket in place. Then, use the same screws and washers to reat-
tach the mounting brackets in the desired location.
2. Carefully slide the chassis into a standard 19-inch equipment rack.
3. Use all four mounting screws to secure the chassis to the rack.
To rack
Use at washer and
lock washer with each
M4 x 10 mm mounting
bracket screw.
To rack
(a)
(b)

10
Rack Installation (Cont.)
Rack-mount Considerations
A. Elevated Operating Ambient
If installed in a closed or multi-unit rack assembly, the operating ambient temperature
of the rack environment may be greater than room ambient. Therefore, consideration
should be given to installing the equipment in an environment compatible with the
maximum ambient temperature (Tma) specified by the manufacturer (see Specifications
information in this document).
B. Reduced Air Flow
Installation of the equipment in a rack should be such that the amount of air flow required
for safe operation of the equipment is not compromised. To ventilate the system normally
and avoid overheating, leave at least 1 inch (2.5 cm) on each side (including top and
bottom) of the PCS200R. Do NOT stack other equipment on the top of the PCS200R.
Also, ensure that the unit’s AC power adapter is never stacked or bundled with other AC
power adapters. Each adapter should have adequate ventilation and should be isolated
from other heat sources.
C. Circuit Overloading
Consideration should be given to the connection of the equipment to the supply circuit
and the effect that overloading of the circuits might have on overcurrent protection and
supply wiring.
D. Reliable Earthing
Maintain reliable earthing of rack-mounted equipment. Particular attention should be
given to supply connections other than direct connections to the branch circuit (e.g.,
use of power strips).
E. Mains Outlet Earthing
The apparatus with Class I construction must be connected to a mains socket outlet
with a protective earthing connection.
PWR
Front View
of Rack Cabinet 1 inch minimum
1 inch minimum

11
System Setup
PCS200R
Feature Port
Control Port
Laptop
PC
Service Port
Connection
Network
RF Out
ASI Out
RF
Coaxial
Cable
IF Out
QAM
Modulator
ASI In IF In
RF Out
DTV
Upconverter
ASI
Coaxial
Cable
RF Out
(0 dBmV) RF
Cable
Room
Receiver
Room
Receiver
Room
Receiver
RF
Distribution
System
Combiner
Refer to the following diagrams, and complete the system installation as described on
pages 14 to 18.
Caution: Do NOT make system connections until instructed to do so during
the system installation procedure. In some instances, configuration steps
must be performed before physical connections are made.
Typical Setup Flow Chart for PCS200R with ASI Output

12
System Setup (Cont.)
Typical Setup Flow Chart for PCS200R with RF Output
PCS200R
Feature Port
Control Port
Laptop
PC
Service Port
Connection
Network
RF
Cable
RF Out
(0 dBmV)
RF Out
ASI Out
Room
Receiver
Room
Receiver
Room
Receiver
RF
Distribution
System
Combiner

13
Typical Setup Flow Chart for PCS200R with IP Output
PCS200R
Feature Port
Control Port
Service Port
Connection
Network
IP
Distribution
Network
Room
Receiver
Room
Receiver
Room
Receiver
RF Out
ASI Out
CAT5E
Cable
1000BaseT (default)
Full Duplex
Laptop
PC
RF Out
(0 dBmV)
System Setup (Cont.)
Laptop
PC
Pro:Centric
VPN Server
Internet/
VPN
VPN Client
VPN Client
PCS200R
VPN Network Connections Overview

14
Typical System Installation
(see also Typical Setup Flow Charts and VPN Network Connections Overview diagrams)
1. If your system is using ASI output, make the following two connections; otherwise, go
to step 2.
• Connect a 75 ohm BNC-to-BNC coaxial cable between ASI OUT on the PCS200R
and ASI IN on the modulator.
• Connect an RF coaxial cable between IF OUT on the modulator and IF IN on the
upconverter.
Note: The BNC cable must be less than 30 feet (9.2 meters) in length.
2. To enable remote management, connect one end of a CAT5 RJ-45 Ethernet cable to
the Control Port on the PCS200R rear panel, and connect the other end of the cable
to the institution’s network.
3. Connect the PCS200R power supply to the POWER connector on the PCS200R rear
panel. Then, plug the AC power cord into a powered AC line receptacle. When power
is applied, the PWR (Power) LED on the PCS200R front panel will initially flash red
and then turn green (blinking during boot-up).
The boot-up process for the PCS200R may take up to two minutes. When boot-up is
complete, the PWR LED on the PCS200R front panel will light continuously green.
4. Once the PWR LED is lit continuously (no longer blinking), use the FTDI TTL-232R-
5V-AJ cable to connect a PC to the Service Port on the PCS200R rear panel.
5. Using HyperTerminal or an equivalent terminal emulation program on the PC, congure
the serial port as follows: Bits per second/baud = 115200; Data bits = 8; Parity = None;
Stop bits = 1; Flow Control = None
Note: To avoid conguration errors, make sure the keyboard settings on the terminal
emulator assign the backspace character to Ctrl + H (ASCII 8).
Once the connection is established, you should see a login prompt. (If the login prompt
is not automatically displayed, press Enter to refresh the screen.)
6. At the login as: prompt, type admin and press Enter. Then, at the password:
prompt, type Password4Partners (case-sensitive) and press Enter.
Note: After the system setup is complete, it is highly recommended that
you use the “pwd” command available from the PCS200R Main Menu
to change the admin user password from its default value. Refer to the
extended Installation & Setup Guide for further information.
System Setup (Cont.)
(Continued on next page)

15
(Continued from previous page)
7. At the Command > prompt, type info and press Enter. (You can press Enter at any
PCS200R command prompt to view current menu, if desired.)
The initial System Information display identies PCS200R, default conguration
settings, including the Control Port IP address and the output conguration, for example:
PCS200R Pro:Centric Server v6.7
Copyright (c) 2010 - 2014 Zenith Electronics LLC
SN: 201-12301011
Hardware ID: 2
OS version: Linux 3.4.0-zenith-pcs200+
OS release: #112 SMP Mon Aug 19 10:38:49 CDT 2013
Ctrl MAC: 00:0C:63:40:36:14
Ctrl IP: 10.166.60.92
Feat MAC: 00:0C:63:40:36:15
Feat IP: n/a
VPN IP: n/a
RF config: Mode 3, 256-QAM-B, RF: 6 MHz, 5.36 MSps, ASI: 38.81
RF channel: 75
Channels: 1
Local time: Tue May 20 14:42:02 EDT 2014
8. Check the Ctrl IP (Control Port IP address) eld in the System Information display. By
default, the PCS200R uses DHCP; thus, the DHCP server, if congured, assigns an IP
address to the Control Port once the PCS200R successfully connects to the network.
• If the Crtl IP eld shows an IP address, the PCS200R is up and running on the
network. If you wish to congure a static IP address for the Control Port and/or if you
need to congure a static IP address for the Feature Port (for IP output purposes),
continue with step 9. Otherwise, you can go to step 10 at this time.
• If the network is congured for DHCP but the Ctrl IP eld is blank, refer to “Network
Setup” troubleshooting information on page 19.
• If the network is not congured for DHCP, you will need to congure a static IP
address for the PCS200R Control Port as described in step 9.
System Setup (Cont.)
(Continued on next page)
Mbps

16
(Continued from previous page)
9. This step describes how to set a static IP address for the Control Port and/or
Feature Port.
Caution: Setting a static IP address for the Control Port (for remote
management purposes) is optional. However, if you will be using IP output
from the PCS200R, you MUST configure the Feature Port as described in
step (c) below.
a) At the Command > prompt, type setip and press Enter. The system will display
the current network configuration, followed by the Network Configuration Menu.
Use the Network Configuration Menu commands indicated below and follow the
system prompts to configure the port(s). Refer to the extended Installation &
Setup Guide for further information on the commands.
b) Use the “eth0” and “dns” commands to congure the Control Port, as necessary.
c) Use the “eth1” command to congure the Feature Port, if required, for PCS200R IP
output.
Note that the Feature Port MUST be congured with a static IP address that is on
the same network as the TV(s). Also, make sure the Feature Port speed (default:
1000 Mbps) is appropriate for your system. If necessary, at the prompt for the port
speed, change the value to 100 Mbps.
d) When you are nished with network conguration, type exit at the Network
Conguration Menu > prompt. The system will display an overview of the new
network conguration and then prompt for conrmation to save the changes:
Do you want to save the new configuration? [y/n]:
Type yor nand press Enter, as appropriate.
Note: Review the New Network Configuration overview carefully before you confirm
the configuration settings. Ensure each of the addresses was entered correctly.
Note: If you changed the conguration of the port(s), you will be prompted to reset the
system. You may wait to reset the system until you are directed to do so in step 11.
System Setup (Cont.)
(Continued on next page)

17
(Continued from previous page)
10. (Optional) Set the date and time on the PCS200R.
By default, the PCS200R is synchronized with an NTP server and congured for the
US Eastern time zone. If the PCS200R is connected to the Internet, the NTP client will
periodically update the time setting on the PCS200R. You can set the time zone as
required. If the PCS200R is not connected to the Internet, you also have the option to
disable NTP synchronization and specify date and time data manually.
Use the PCS200R “tz” and/or “time” commands (available from the Command >
prompt), as necessary, to set the date and time on the PCS200R.
• Use the “tz” command and follow the system prompts to change the time zone.
• Use the “time” command and follow the system prompts to change the NTP
conguration or manually congure the date and time parameters on the PCS200R.
Refer to the extended Installation & Setup Guide for further information on these
commands.
Note: If you changed the time zone and/or the NTP conguration, you will be
prompted to reset the system. Continue with step 11, where you will be directed to
initiate a reset.
11. If you made any conguration changes in steps 9 and 10 that require a system reset,
at the Command > prompt, type reset and press Enter.
The reset process may take up to two minutes, after which the PCS200R resumes
normal operation.
12. Make the appropriate connection to the RF distribution system or IP distribution
network depending on the PCS200R output option to be used.
• ASI output: Connect the RF output on the upconverter to the RF distribution center
combiner, and balance the RF signal so that the Pro:Centric signal level at the
TV(s) is between 0 to +7 dBmV.
• RF output: Connect RF OUT on the PCS200R to the RF distribution center
combiner, and balance the RF signal so that the Pro:Centric signal level at the
TV(s) is between 0 to +7 dBmV.
• IP output: Connect a CAT5E or better Ethernet cable between the Feature Port on
the PCS200R rear panel and the institution’s IP distribution network.
System Setup (Cont.)
(Continued on next page)

18
(Continued from previous page)
Caution (ASI/RF Output only): For proper system performance, the
Pro:Centric signal level at the TV input (ANTENNA IN) must be between
0 to +7 dBmV. Note that additional equipment may be required to adjust
the signal level.
Caution: When not in use, the RF OUT (0 dBmV) connector must remain
terminated with attached terminator accessory.
13. Configure the ASI/RF or IP output parameters in the Pro:Centric server Admin Client
“RF/IP Configuration” screen. Refer to the Pro:Centric Server Admin Client User
Guide for further information.
Note: By default, the server output is enabled for 256-QAM-B modulation (RF output),
with the data channel set to 75.
14. Check one or more room receivers to make sure all content is properly mapped
and available.
System Setup (Cont.)

19
Troubleshooting
This section provides introductory PCS200R installation and setup troubleshooting
information. Refer to the extended Installation & Setup Guide for additional trouble-
shooting information.
Equipment Setup Review
• Make sure all connectors and connections are tight and secure on all entertainment
system components.
• Check the PCS200R LED: Under standard operating conditions, i.e., when the
PCS200R is booted and operating normally, the PWR (Power) LED on the PCS200R
front panel is continuously lit green. If there is a hardware fault, the PWR LED will turn
and stay red.
Note: When power is rst applied to the PCS200R, the PWR LED initially flashes red
and then turns green (blinking during boot-up).
Network Setup
If the network is configured for DHCP but the PCS200R has not been assigned an IP
address, i.e., the Ctrl IP field in the PCS200R System Information display is blank:
1. Check the Control Port connector on the rear panel of the PCS200R. Make sure the
cable connection is tight and secure.
2. Observe the green LED on the Control Port. Once the PCS200R is connected to
the network, the LED will be lit continuously.
3. Contact the network administrator to verify the network status and check that the
DHCP server is working properly.

20
Specications
Dimensions
Height: 42.977 mm
Width: 482.6 mm (for EIA standard 19-inch rack mount)
Depth: 215.9 mm
Weight: 2.56 kg (rack-only weight)
Environmental Storage Conditions
Temperature: -20° to 70° Celsius
-4° to 158° Fahrenheit
Humidity: 95% non-condensing
Environmental Operating Conditions
Temperature (Tma): 0° to 40° Celsius
32° to 104° Fahrenheit
Humidity: 95% non-condensing
Electrical
RF Out Connectors (2)*: 75 Ohm, Type ‘F’
Frequency: VHF/UHF 54-865 MHz
RF Output Span **: Up to 8 Contiguous Channels (typically
48–64 MHz)
RF Output Frequency Range : 54 MHz to 865 MHz
Active Output Level at RF Out jacks: -6 dBm (+42 dBmV) Minimum, -2 dBm
(+46 dBmV) Typical
Test Output Level: -48.75 dBm (0 dBmV) Typical
Frequency Accuracy: ±5 ppm
Impedance at ASI Out jack: 75 Ohms
Level at ASI Out jack: 800 mv
DC Input: +12V DC @ 3.25 Amps
Ethernet Connector (Control Port): 10/100/1000BaseT, RJ-45
Ethernet Connector (Feature Port): 100/1000BaseT Full Duplex, RJ-45
USB Port**: USB 2.0
Solid State Drive **:UL listed, FCC compliant, and/or other applicable
agency-recognized/listed
(Maximum current draw = +5V DC @ 2.0 Amps)
* RF OUT (0 dBmV) connector reserved for service technician use only.
** Specication for future functionality.
Note: Design and specications subject to change without prior notice.
