LG Cloud T Series User manual

www.lg.com
OWNER'S MANUAL
LG CLOUD T SERIES BOX
CBT42
Please read the safety information carefully before using the product.
LG Cloud T Series Box Model List
ENG

2
ENG
English
Table of Contents
3 ASSEMBLING AND
PREPARING
3 Unpacking
4 PartsandButtons
5 ProductInstallation
5 - UsinginHorizontalPosition
5 - UsinginVerticalPosition
5 - MountingontheBackoftheMonitor
6 CONNECTING LAN/
PERIPHERALS
6 - LANConnection
6 - DVIConnection
7 - ExtendedMonitorConnection
7 - Peripheraldeviceconnection
9 TROUBLESHOOTING
10 SPECIFICATIONS
10 PowerIndicator

3
ENG
English
ASSEMBLING AND PREPARING
MainUnit StandBase MountBracket
PowerCordOwner'sManual/Card FourScrews AC/DCAdapter
ASSEMBLING AND PREPARING
Unpacking
Pleasecheckwhetherallthecomponentsareincludedintheboxbeforeusingtheproduct.Ifthereare
missingcomponents,contacttheretailstorewhereyoupurchasedtheproduct.Notethattheproductand
componentsmaylookdifferentfromthoseshownhere.
 OnlyuseanapprovedLGpoweradapter.
 Damagecausedbyotherpoweradaptersisnotcoveredbywarranty.
 Notethatthecomponentsmaylookdifferentfromthoseshownhere.
 Withoutpriornotice,allinformationandspecificationsinthismanualaresubjecttochangetoimprove
theperformanceoftheproduct.
 Topurchaseoptionalaccessories,visitanelectronicsstoreoronlineshoppingsiteorcontacttheretail
storewhereyoupurchasedtheproduct.
CAUTION
NOTE

4
ENG
English
ASSEMBLING AND PREPARING
Parts and Buttons
Power Indicator &
Power Button
 On:PowerOn
 Off:PowerOff
InputConnectors
Front Side
Rear Side

5
ENG
English
ASSEMBLING AND PREPARING
Product Installation
Using in Horizontal Position
Using in Vertical Position
1 Firmlyattachthestandonthebottomofthe
productasillustratedbelow.
2 Usingacoin,turnthescrewclockwiseto
securethestandbase.
Mounting on the Back of the
Monitor
1 Fixthemountbracketonthebackofthe
monitorwith4screwsasillustratedbelow.
2 Puttheproductonthetwolatchesasillustrated
below.
Assembletheproductbyaligningthebelow
twoholesoutof4holesontheproduct.
 Attachthestand
basetothe
standhingewith
itsfrontpartfac-
ingforward.
 Ifthisproductisusedwithupsidedown,it
maynotworkproperly.
 UsetheproductwiththeKensingtonlock
facingupward.
NOTE
 Theproductmaynotbemountedonsome
monitorswithmountbracket.
-Inthiscase,usetheproductinhorizontal
orverticalposition.
 Whenconnectingtheperipheralsafter
mountingtheproductonthemonitor,be
suretoholdtheproduct.
CAUTION
NOTE

6
ENG
English
Connecting LAN/Peripherals
CONNECTING LAN/PERIPHERALS
DVI Connection
Transmitsdigitalvideosignalstothemonitor.Con-
necttheproductusingtheDVIcableasillustrated
below.
 Connecttheinputsignalcable
andturninthedirectionofthe
arrow.Topreventdisconnection
securethecabletightly.
 TheLANcableissoldseparately.
 ThefollowingLANcabletypecanbeused:
Standard:IEEE802.3ETHERNET
 ConnecttheLANcableandtheperipheralde-
vicestousetheCITRIXcloudmonitor.
 Whenconnectingthepowercordtothe
outlet,useagrounded(3-hole)multi-socket
oragroundedpoweroutlet.
 DVIcableisnotincludedinthebasiccom-
ponents.UsetheDVIcableprovidedwith
themonitororthestandardDVIcable.
CAUTION
NOTE
NOTE
LAN Connection
Connecttherouterorswitchtothemonitorusinga
LANcableasillustratedbelow.

7
ENG
English
Connecting LAN/Peripherals
 Ifthemain/subscreenwaschangedafter
extendedmonitorwasconnected,themain/
subcanbechangedinSetup.
Extended Monitor Connection
Transmitsanalogsignalstothemonitor.Connect
theproductusingtheD-subcableasillustrated
below.
Peripheral device connection
UsetheUSB,microphone,andheadphoneportto
connectaperipheraldevicetotheBOX.Connect
asillustrated.
Front Side
Rear Side
NOTE

8
ENG
English
Connecting LAN/Peripherals
 Thecloudserversettingsmayaffecttheperfor-
manceoftheheadphones,earphonesorspeak-
ersdependingontheconnectedcloudserver.
 Thecloudserversettingsmayaffectthe
functionsorspeedofthespecificUSBstor-
agedevicedependingontheconnected
cloudserver.
 Peripheraldevicesaresoldseparately.
 TheUSBportscanbeusedtoconnectthe
keyboard,mouse,andotherUSBdevices.
 Foranangleplugearphone/microphone,itis
difficultconnectitwithaperipheraldevice,so
useastraighttype.
AngleType StraightType
NOTE
NOTE

9
ENG
English
TROUBLESHOOTING
TROUBLESHOOTING
Nothing is displayed on the screen
IsthepoweradapteroftheBox
pluggedin?

Checkifthepowercordiscorrectlypluggedintothepoweroutlet.
Isthepowerindicatoron? 
Checkthepowerindicator.
Isthepowerindicatordisplayingas
red?

Adjustthebrightnessandthecontrastoftheconnectedmonitor.
AretheBOXandthemonitorcon-
nectedwiththesignalcable?

CheckwhetherthemonitorandtheBoxareproperlyconnectedtoDVI
cableorD-SUBcable(usingDVItoD-Subgender).
 Thisboxtypeproductisusedbyconnectingthemonitor.
 Ifthemonitordoesnotworknormally,thescreenmaynotbedisplayedcorrectly.
NOTE

10
ENG
English
SPECIFICATIONS
SPECIFICATIONS
SupportedDis-
playResolution
(D-SUB,DVI-D)
MaximumResolution 1920x1200@60Hz
RecommendedResolution 1920x1200@60Hz
Power Voltage 19V 1.2A
Powerconsumption(Typ.)
(Cloud)
CloudMode8W
OffMode≤0.5W
Dimension Dimensions(WidthxHeightxDepth)
Withstand 70.3mmx189.3mmx143.6mm
WithoutStand 185mmx30.5mmx143.6mm
Weight(Without
Packaging)
0.65kg
AC/DCadapter TypeADS-40SG-19-319025G,manufacturedbySHENZHENHONORELECTRONIC
OrTypeLCAP21,manufacturedbyLIENCHANGELECTRONICENTERPRISE
OrTypePSAB-L203A,manufacturedbyLGInnotekCo.,Ltd
Output:19V 1.3A
Environmental
Conditions
OperatingCondition Temperature:10°Cto35°C;Humidity:10%to80%
StoringCondition Temperature:-20°Cto60°C;Humidity:5%to90%
Thespecificationsaresubjecttochangewithoutnotice.
Power Indicator
Mode LED Color
OnMode Red
OffMode Off

ThisdevicemeetstheEMCrequire-
mentsforhomeappliances(ClassB)
andisintendedforhomeuse.
Thisdevicecanbeusedinallregions.
Readtheowner'smanual(CD)carefully
andkeepitathand.
Theproductlabelcontainsnecessary
informationforafter-service.
Model
SerialNo.
Declaration of Conformity
Trade Name: LG
Model : CBT42L
Responsible Party: LG Electronics Inc.
Address : 1000 Sylvan Ave. Englewood Cliffs
NJ 07632 U.S.A
TEL: [phone]
*above information is only for USA FCC Regulatory
