LG Q1C-A5 Series User manual

Please read this manual carefully before operating
your set and retain it for future reference
www.lg-solar.com
Installation manual
PV Solar
MODULE
P/NO : MFL69724902 (Rev 00)
N-TYPE MODELS
LGXXXQ1C(K)-A5
All manuals and user guides at all-guides.com
all-guides.com

Table of Contents
CONTENTS
1. Safety 3
2. Before & After Installation 4
3. Electrical Installation 5
4. Mechanical Installation 6
5. Product Specifications 8
6. Disclaimer of Liability / Disposal 10
7. Transporting and Storage 10
8. Appendix. 11
Revisions Table
Date Version Description of change Remark
2016.09.02 1.0 (1st edition)
2016.12.07 2.0
Add New Products(Black Model)
2
All manuals and user guides at all-guides.com

Safety
3
The instructions related to the safety indicated in
the following are for preventing unexpected danger
or damage in advance by safely and exactly using
the product.
Non-compliance of the instructions may immedia-
tely cause serious injury or death.
Non-compliance of the instructions may cause
death or serious injury to the user.
Non-compliance of the instructions may cause
injury or property damage to the user.
①Do not contact with electrically active parts of
the panel, such as terminals, regardless of
connection of the module. It may result in spark
or lethal electric shock.
②Please don’t use the module with the broken
window or the torn back side. There is a danger
of electric shock.
①Please perform works in the dry condition and
use only dry tools. Do not handle the wet panels
without protection equipment. It may result in
safety accident.
②Damaged module must be treated with safety
protection equipment. It may result in injury.
③Do not approach the damaged or broken module
unless you are an expert. It may result in serious
injury.
④No electrical parts like cables are located after
installation between laminate and mounting
structure.
⑤Do Not reconnect or repair Junction box Cable.
It may occur spark or electric shock.
⑥Do not bending junction box's cable. While
under stress, it may occur module damage.
Cable bending radius should be more than
4 times the cable diameter, at least.
①②
①Please use proper equipment, connector, wire
and buttress for system configuration of the
module. It may result in damage or failure of the
product.
②Do not perform installation in rainy, heavily
windy or snowy days. It may result in safety
accident.
③Do not make holes in the frame or glass of the
module. It may decrease the strength of the
frame or break the glass.
④Do not touch the glass surface or frame of the
solar module after installation of the module. It
may result in injury.
⑤Do not locate a heavy object onto the module.
Do not stand on or step on the module. Do not
drop or suddenly lay down the module. It may
result in injury.
⑥Do not scratch the coating surface of the frame.
It may decrease the strength due to corrosion of
the frame.
⑦Do not concentrate sunlight on the module
surface. It may result in damage of the product.
⑧Do not apply a shock to the junction box of the
module or pull the cable. Do not remove the
labels attached to the module. It may result in
damage of the product.
⑨If the installing structure has a curved surface
e.g. arch type as shown in the below picture, do
not forcefully modify the module in installation
when connecting it with the structure. Please
install the module in the place where the structure
has been completely set up because deformation
of the structure may cause deformation of the
product when performing installation by using a
crane, etc after assembling the module to the
installing structure.
⑨
①②③
④⑤⑥
⑦⑧
①
③④
⑤
②
All manuals and user guides at all-guides.com

Before & After Installation
Before Installation
Please carefully read this manual before
installation.
• Solar module installation should be performed by
an authorized installer for the safety and
maintenance of the system.
• All installation instructions should be clearly
understood before attempting installation.
• Do not twist, pull, or scratch the cable attached to
the solar module.
• Do not touch the solar module with bare hands. It
may result in a burn or injury.
• Do not drop the solar module and cause an
excessive load on solar module.
• Do not disassemble the solar module.
• After installation or repair, check whether solar
module operates properly or not.
• In case the currently used solar module or the
parts applied to the solar module have been
replaced, check whether the changed solar
module is properly operated or not. The newly
replaced solar module and its parts must be the
same solar module(module name) and parts with
the current solar module.
• Please contact the local office to confirm the
regulations and to obtain permission.
• Do not let anyone approach the solar module
who has little knowledge of solar modules or on
the measures to take when solar modules are
damaged in order to avoid the risk of injury or
electrical shock.
• Do not locate the solar module horizontally, as
this may cause dirt or white efflorescence (glass
deformation)
• Panels produce voltage even when not
connected to an electrical circuit or load.
• Panels are intended for outdoors, land based
applications only. Panels are not intended for use
indoor use or application on moving vehicles of
any kind.
• Reflection from external environments such as
snow, water or other surfaces can increase the
power generated by the panel.
• Industry standard rated specifications are made
at conditions of 1000W/m2irradiance and 25°C
(77ºF) solar cell temperature. Colder temperatur-
es can substantially increase voltage and power.
• Keep the solar module and system away from
children when installing.
• Keep the module packed in the carton until the
time of installation.
• Make sure flammable gases are not generated
near the installation site.
• Do not work alone. Please work as part of a team
of two or more people.
• Wear a safety belt if working high above the
ground.
• Contact with electrically active parts of the panels,
such as terminals, can result in burns, sparks and
lethal shock whether the panel is connected or
disconnected.
• Even partial shadowing can substantially reduce
panel and system output.
• Care must be taken to avoid low tilt angles which
may cause dirt to buildup on the glass against the
frame edge.
• Dirt build-up on the surface of the panel can
cause active solar cells to be shaded and
electrical performance to be impaired.
• Always keep the back surface of the panel free
from any foreign objects or structural elements
which could come into contact with the panel,
especially when the panel is under mechanical
load.
• For permission to use mounting methods not
described in the Mounting Guide please consult
LG Solar. Failure to do so will void the warranty
and panel certification.
After Installation
•Plug the connector in tightly and ensure that the
wiring properly works.
• It is advisable to conduct periodic inspection of
the panels for damage to front glass, back sheet,
frame, junction box, or external electrical
connections.
• Check electrical connections for loose connec-
tions and corrosion.
• PV panels can operate effectively without ever
being washed, although removal of dirt from the
front glass can increase output.
•Water, ethanol or a conventional glass cleanser
with a micro-fiber cloth can be used for regular
washing or rinsing of the front glass to remove
dust, dirt or other deposits.
• No aggressive and abrasive cleansers or
chemicals such as alkali chemicals including
ammonia based solution should ever be used on
the treated front glass.
• Always wear rubber gloves for electrical
insulation while maintaining, washing or cleaning
panels.
• Deposits of foreign material on the frame surface
can be cleaned using a wet sponge or cloth and
dried in air or by using a clean chamois.
• Perform the wiring work by connecting the
connector and wires to the stand away from the
roof or ground.
4
All manuals and user guides at all-guides.com

Electrical Installation
Caution
•Avoid all electrical hazards when installing, wiring,
operating and maintaining a panel.
•Do not use panels of different electrical or
physical configurations in the same system.
•Match the polarities of cables and terminals when
making the connections; failure to do so may
result in damage to the panel.
•When reverse currents can exceed the value
marked on the name plate, a properly rated and
certified over-current device (fuse or circuit
breaker) must be connected in series with each
panel or string of panels.
•The rating of the over-current device shall not
exceed the maximum series fuse rating marked
on the name plate.
•The panel contains factory installed bypass
diodes located inside the junction box.
•When installing the system, it is recommended to
install the lightning rod to protect the system.
•The junction box should not be opened. Opening
the junction box may void the warranty.
•Panels with a suspected electrical problem
should be returned to LG Electronics for
inspection andpossible repair or replacement as
per the warranty conditions provided by LG
Electronics.
Electrical Connections
•Modules may be connected in series and/or
parallel to achieve the desired electrical output as
long as certain requirements are met.
•Please use only the same type of modules in a
combined source circuit.
•Do not disconnect the module under load.
Shock hazard can occur near the solar modules
connection means.
Series Connection
•The solar modules may be wired in series to
produce the desired voltage output.
•The current of each module connected in series
should be same.
•The maximum number of series connected
modules can be determined by basis on max.
system voltage, the 125% safety factor, and the
module Voc which can be checked in “Product
Specifications” in this document.
•Do notexceed 80% of maximum system voltage.
•The maximum solar module configuration can be
found in “Product Specifications”.
Series connection for more voltage
Parallel Connection
•The solar modules may be combined in parallel
to produce the desired currentoutput.
•When modules are combined in parallel, the total
current is equal to the sum of currents from each
module.
•The voltage of each module connected in parallel
should be same.
•When connecting plural strings of modules in
parallel every series string or solar module must
be fused prior to combining with other strings.
By pass diodes are factory installed in the solar
modules.
•Please refer to the applicable regionaland local
codes for additional fusing requirements and
limitations on the maximum number of solar
modules in parallel.
•Maximum series fuse rating is refer to “Product
specifications;page 8”.
•A multiplying factor is required for increased
output of the PV modules. Under normal
conditions, a PV module is likely to experience
conditions that produce more current and/or
voltage than reported at standard test conditions.
Accordingly, the values of Isc and Voc marked on
this PV module should be multiplied by a factor of
125% when determining component voltage
ratings, conductor ampacities, fuse sizes, and
size of controls to the PV output.
•Depending on national directives additional
safety factors might be applicable for overcurrent
protection.
Parallel connection for more current
…………..
+-
+
--
+- +
-+
-+
…………..
+-
+
--
+- +
5
All manuals and user guides at all-guides.com

Electrical Installation
General Wiring
•LG Electronics recommends that all wiring be
double insulated with a minimum rating of 90°C
(194°F).
•All wiring should use a flexible copper (Cu)
conductor.
•The minimum size should be determined by the
applicable codes.
•We recommend a size not smaller than 4mm2.
Earth Grounding
•The solar modules from LG Electronics meet the
conditions of safety class II. Therefore grounding is
not mandatory. However grounding is
recommended. Also equipotential bonding must be
realized. The national directives must be respected.
•Specific information on the solar module
dimensions and location of grounding holes is
provided in ‘Product Specifications’.
•One M4 stainless steel bolt, one nut, one spring
washer, two flat washers, one cup washer, one
star washer and 12 AWG Cu wires are
recommended per solar module.
•There is an earth hole in the center of the module
frame. Using this hole, an earth conductor and the
solar module frame may be recommended to
connected and earthed as the below drawing.
•To prevent electric shock and fire, a protective
ground must be done on the frames of solar
modules and arrays although the solar modules
from LG meet the conditions of safety class Ⅱ.
The national directives must be respected.
Module frame
Bolt
Flat washer
Star washer
Cup washer
Grounding wire
Spring washer
Nut
Flat washer
6
Module Mounting
•The LG Electronics’ (LGE) Limited Warranty for
solar modules is contingent upon modules being
mounted in accordance with the requirements
described in this section.
•The solar modules are in Application Class A and
have the Safety Class II. Therefore they can be
operated in systems with 120 V DC and higher.
General access is not restricted.
Site Consideration
LGE solar modules should be mounted in a loca-
tion that meets the following requirements.
Operating Temperature
•Maximum Operating Temperature: +90°C (194°F)
•Minimum Operating Temperature: -40°C (-40°F)
Excluded Operating Environments
•The solar modules from LG Electronics can be
operated in a location where they could come in
contact with salt water or ammonia, if they have
been tested successfully for these operating
conditions. Please see related certificates. Please
get a release from LG Electronics for increased
conditions.
Design Strength
•Snow loads(Front side): 5400 Pascal
•Wind loads(Rear side): 2400 Pascal
Mechanical Installation
①
②
①
②
①
②
①
②
60Cell
①
: 200mm
②
: 300mm
※ This mounting method is by using frame bolt holes.
All manuals and user guides at all-guides.com
all-guides.com

Mechanical Installation
Mounting Methods
General Information
•Select the appropriate orientation to maximize
sunlight exposure.
•In order to prevent water from entering the
junction box, which could present a safety hazard,
module should not be mounted such that the
front/top glass faces downward.
•Clearance between the solar module frames and
structures such as roofs or ground is required to
prevent wiring damage and to allow air to
circulate behind the solar module. The
recommended standoff height is a minimum of
100mm.
•When installed on a roof, the solar module must
be mounted over a fire-resistant roof covering
rated for the application. The fire resistance of the
solar module from LG Electronics is class C after
ANSI/UL790.
•The solar module is only IEC listed for use when
its factory frame is fully intact.
•Do not remove or alter the solar module frame.
•Creating additional mounting holes may damage
the solar module and reduce the strength of the
frame.
•A 6mm gap between module frames should be
allowed to avoid tension from thermal expansion.
•The solar module may be mounted using the
following methods: (*Torque:8~12Nm )
•When installing modules in heavy snow areas,
special care should be taken to install the
modules in a manner that provides sufficient
design strength while meeting local code
requirements.
Mounting by using frame bolts holes
•Secure the solar module to the structure using
the factory mounting holes.
•Four M8 stainless steel bolts, four nuts, four
spring washers, and eight flat washers are
recommended per solar module.
•The module may be fastened to a support using
both the outer and inner bolt holes of the frame.
•Each module should be securely fastened at a
minimum 4 points on two opposite sides.
•Specific information on the solar module
dimensions and location of mounting holes is
provided in ‘Product Specifications’.
•Tighten the bolt securely using this combination.
Place spring washer between Flat washer and
Nut.
Mounting by using clip or clamps
•The module may be fastened to a support using
clips or clamps on both the long edge and the
short edge of the modules.
•Specific information on location of clamping
is provided in ‘Mechanical Installation Scene’
(Refer Appendix.).
•The module frame must overlap more than 15mm.
Clamp system requirements
•Clamp width is more than 30mm, depth is more
than 10mm. Clamp height compliant with a frame
height.
•The clamp should not be touched with the
module’s glass.
•Use corrosion resistant material clamps and
hardware.(If you use a special clamp, it needs to
test for compatibility by LGE.)
•Use appropriate bolted connections as per clamp
manufacturer’s instructions.
•Follow the clamp manufacturer’s recommended
applied torque to fasten the clamps.
7
Module frame
Bolt
Flat washer
Flat washer
Spring washer
Nut
Mounting Rail
All manuals and user guides at all-guides.com

Product Specifications
- Electrical and Mechanical Properties
(Rated electrical characteristics are -5 to +5 percent)
Standard Test Condition(STC) : Irradiation 1000W/m2, Cell temp. 25℃, 1.5AM
8
Certificates Electrical Properties Mechanical Properties
Module Series
Model Name
IEC61215 Ed.2, IEC 61730,
Safety Class II, CE, ISO9001
Pmax at STC
Power Tolerance
Voc at STC
Isc at STC
Vmpp at STC
Impp at STC
Max. No. of modules in
series
Max. Series Fuse Rating
Max. System Voltage
Connector
Length
Width
Height
Weight
W % V A V A A V
mm mm mm kg
LG340Q1C-A5 Yes 340 3% 42.6 10.75 35.6 9.56 18 20 1000 *MC4/05-8 1700 1016 40 18.5
LG345Q1C-A5 Yes 345 3% 42.6 10.76 35.8 9.64 18 20 1000 MC4/05-8 1700 1016 40 18.5
LG350Q1C-A5 Yes 350 3% 42.7 10.77 36.1 9.70 18 20 1000 MC4/05-8 1700 1016 40 18.5
LG355Q1C-A5 Yes 355 3% 42.7 10.78 36.3 9.79 18 20 1000 MC4/05-8 1700 1016 40 18.5
LG360Q1C-A5 Yes 360 3% 42.7 10.79 36.5 9.87 18 20 1000 MC4/05-8 1700
1016
40 18.5
LG365Q1C-A5 Yes 365 3% 42.8 10.80 36.7 9.95 18 20 1000 MC4/05-8 1700 1016 40 18.5
LG370Q1C-A5 Yes 370 3% 42.8 10.82 37.0 10.01 18 20 1000 MC4/05-8 1700 1016 40 18.5
LG375Q1C-A5 Yes 375 3% 42.8 10.83 37.2 10.09 18 20 1000 MC4/05-8 1700 1016 40 18.5
LG380Q1C-A5 Yes 380 3% 42.9 10.84 37.4 10.17 18 20 1000 MC4/05-8 1700 1016 40 18.5
LG385Q1C-A5 Yes 385 3% 42.9 10.85 37.7 10.22 18 20 1000 MC4/05-8 1700 1016 40 18.5
LG315Q1K-A5 Yes 315 3% 41.4 10.00 34.7 9.09 19 20 1000 MC4/05-8 1700 1016 40 18.5
LG320Q1K-A5 Yes 320 3% 41.6 10.06 34.9 9.18 19 20 1000 MC4/05-8 1700 1016 40 18.5
LG325Q1K-A5 Yes 325 3% 41.9 10.11 35.1 9.27 19 20 1000 MC4/05-8 1700 1016 40 18.5
LG330Q1K-A5 Yes 330 3% 42.1 10.17 35.3 9.36 19 20 1000 MC4/05-8 1700
1016
40 18.5
LG335Q1K-A5 Yes 335 3% 42.3 10.22 35.6 9.42 18 20 1000 MC4/05-8 1700 1016 40 18.5
LG340Q1K-A5 Yes 340 3% 42.5 10.28 35.8 9.51 18 20 1000 MC4/05-8 1700 1016 40 18.5
LG345Q1K-A5 Yes 345 3% 42.7 10.33 36.0 9.59 18 20 1000 MC4/05-8 1700 1016 40 18.5
LG350Q1K-A5 Yes 350 3% 42.9 10.39 36.2 9.68 18 20 1000 MC4/05-8 1700 1016 40 18.5
LG355Q1K-A5 Yes 355 3% 43.1 10.44 36.4 9.76 18 20 1000 MC4/05-8 1700 1016 40 18.5
LG360Q1K-A5 Yes 360 3% 43.3 10.50 36.7 9.82 18 20 1000 MC4/05-8 1700 1016 40 18.5
LG365Q1K-A5 Yes 365 3% 43.5 10.55 36.9 9.90 18 20 1000 MC4/05-8 1700 1016 40 18.5
LG370Q1K-A5 Yes 370 3% 43.7 10.61 37.1 9.98 18 20 1000 MC4/05-8 1700 1016 40 18.5
LG375Q1K-A5 Yes 375 3% 43.9 10.66 37.3 10.06 18 20 1000 MC4/05-8 1700 1016 40 18.5
Note : *MC4 formal name : PV-KST4 / 6II-UR, PV-KBT4 / 6II-UR
LGXXXQ1C-A5LGXXXQ1K-A5
All manuals and user guides at all-guides.com

Product Specifications
- Dimensions of Modules
9
60Cell Module
Unit: mm / in.
All manuals and user guides at all-guides.com

Disclaimer of Liability / Disposal
10
Disclaimer of Liability
•Since the use of this Safety, Installation and
Operation instructions and the conditions or
methods of installation, operation, use and
maintenance of the panel are beyond the control of
LG Electronics, LG Electronics does not assume
responsibility and expressly disclaims liability for
loss, damage, injury or expense arising out of or in
any connected with such installation, operation,
use or maintenance of the panel.
•LG Electronics assumes no responsibility for any
infringement of patents or other rights of third
parties that may result from use of the panel. No
license is granted by implication or otherwise under
any patent or patent rights..
Disposal of your old appliance
1. This crossed-out
wheeled bin symbol
indicates that waste
electrical and electronic
products (WEEE)
should be disposed of
separately from the
municipal waste stream.
2. Old electrical products can contain hazardous
substances so correct disposal of your old appliance
will help prevent potential negative consequences
for the environment and human health. Your old
appliance may contain reusable parts that could be
used to repair other products, and other valuable
materials that can be recycled to conserve limited
resources.
3. You can take your appliance either to the shop
where you purchased the product, or contact your
local government waste office for details of your
nearest authorized WEEE collection point.
For the most up to date information for your country
please see www.lg.com/global/recycling
Transporting and Storage
•Do not loose the banding, when module is
transported by truck, ship and etc.
In case of loose banding, module will be shaken,
which may cause damage, like glass breaking.
•Do not stack on more than one pallet. Maximum
height is two pallets.
Severe stacking can give stress to the module and
may cause product damage.
All manuals and user guides at all-guides.com

Appendix. Mechanical Installation : 60Cell Model
11
Fig.1 Bolting Type Fig.2 Clamping Type
①
②
①
②
①
②
①
②
A
B
B
A
①: 200mm(7.9 in)
②: 300mm(11.8 in)
Front : 6000Pa(125psf)
Rear : 5400Pa(113psf)
A : 200mm(7.9 in)
B : 400mm(15.7 in)
Front : 6000Pa(125psf)
Rear : 5400Pa(113psf)
Fig.3 Clamping Type Fig.4 Clamping Type
A
B
B
A
A
B
A
B
A : 200mm(7.9 in)
B : 400mm(15.7 in)
Front : 6000Pa(125psf)
Rear : 5400Pa(113psf)
A : 120mm(4.7 in) Front : 1800Pa(37.5psf)
Rear : 1800Pa(37.5psf)
B : 200mm(7.9 in) Front : 2850Pa(60psf)
Rear : 2850Pa(60psf)
Fig.5 Clamping Type Fig.6 Clamping Type
A
B
B
A
C
C
B
A
①
②
①
②
①
①
* 4 point installation is allowed in the following cases:
1. Slope roof: If module is installed parallel to the rooftop.
dniwsahcusdnatslanoitiddanahtiwdellatsnifI:foortalF.2
A : 200mm(5.9 in)
B : 400mm(15.7 in)
Front : 6000Pa(125psf)
Rear : 5400Pa(113psf)
mm021:A
(4.7 in) *4point(①)Front : 1800Pa(37.5psf) Rear : 1800Pa(37.5psf)
C : 120mm(4.7in) Front : 3200Pa(67psf)
Rear : 1800Pa(37.5psf)
A : 120mm
mm001±528:B
(32.5±3.9 in)
6point(①+②)Front : 6000Pa(125psf)
Rear : 5400Pa(113psf)
Note) Mechanical installation method(Fig.2 to Fig.6) in this appendix were not tested by VDE.
It is evaluated by LG internal test.
All manuals and user guides at all-guides.com
all-guides.com

LG Electronics Deutschland GmbH
Berliner Straße 93 D-40880 Ratingen, Germany
Contact: [e-mail]
LG Electronics Inc. (Global HQ)
LG Twin Towers, 128, Yeoui-daero, Yeongdeungpo-gu,
Seoul 150-721, Korea
Contact: [e-mail]
http://www.lg-solar.com
This document is subject to change without notice.
LG, LG logo and Life's Good are trademarks of LG Electronics, Inc. worldwide. Trademarks and
intellectual properties of LG Electronics, Inc. are protected by international copyright laws.
Document : II-BC-IEC-V1-EN-201609
All manuals and user guides at all-guides.com
