SIMPLE MANUAL
Wireless
Sound Bar
Please read this manual carefully before operating your set and
retain it for future reference.
To view the instructions of advanced features, visit
http://www.lg.com and then download Owner’s Manual.
Some of the content in this manual may differ from your unit.
MODEL
DSN4
ENGLISH DEUTSCH FRANÇAIS NEDERLANDS ITALIANO SLOVENŠČINA
2105_Rev01
MFL71686164
SN4.DDEULLM_SIM_ENG_MFL71686164.indd 1 2021-06-09   2:47:39

Front Panel
The buttons are located on the side.
1(Standby) ············Switches the unit ON or OFF.
F(Function) ··························Selects function.
p/o(Volume)······················ Adjusts volume.
Rear Panel
DC IN····················· Connect to the AC adapter.
OPTICAL IN ············Connect to an optical device.
HDMI IN ··········Connect to device with HDMI OUT.
HDMI OUT (TV ARC)··············· Connect to a TV.
USB Port ····················Connect to a USB device.
Make sure to properly align and connect the
optical cable; improper alignment may cause
damage to the jack.
Subwoofer Connection
Place the wireless subwoofer near the sound bar and
follow steps below.
a Connect the power cord of the sound bar and the
wireless subwoofer to the outlet.
b Turn on the sound bar.
• The sound bar and wireless subwoofer will be
automatically connected. The subwoofer’s
yellow - green LED turns on.
Manual Subwoofer Connection
If the subwoofer does not make sound, try to
connect manually.
a Press PAIRING on the rear of the wireless
subwoofer.
• The yellow - green LED on the front of the
wireless subwoofer blinks quickly.
(If the yellow - green LED does not blink, press
and hold the PAIRING.)
b Turn on the sound bar.
• Pairing is completed. The yellow - green LED on
the front of the wireless subwoofer turns on.
Keep the sound bar and the subwoofer
away from the device (ex. wireless router,
microwave oven, etc.) over 1 m to prevent
wireless interference.
!
1 m
SN4.DDEULLM_SIM_ENG_MFL71686164.indd 2 2021-06-09   2:47:41

TV Connection
Connect the sound bar and TV using Optical ( ) or
HDMI ARC ( ).
Optical Connection
a Connect the sound bar to the TV using Optical
cable.
b Set up [External Speaker (Optical)] on your TV
setting menu.
TV
HDMI (ARC) Connection
a Connect the sound bar to the TV using HDMI
cable.
b Set up [External Speaker (HDMI ARC)] on your
TV setting menu.
TV
• HDMI connection is unavailable if your TV
does not support HDMI ARC.
• If this unit is connected by OPTICAL and
ARC at the same time, the ARC signal
has a higher priority.
Additional Device Connection
a Connect to the external device like as follow.
TV
OR
(Set-top Box,
Player etc.)
OR
b Set the input source by pressing Frepeatedly.
Remote control
Replacement of Battery
C/V:Skip/Search
N:Play/Pause
-Bluetooth connection lock (BT LOCK): Select
the Bluetooth function by pressing Frepeatedly.
Long press Nand press it again to limit
Bluetooth connection to only BT and LG TV.
SOUND EFFECT: Selects a sound effect mode.
-TV remote: Long press SOUND EFFECT and
press it again to use TV remote control.
FOLDER W/S: Searches a folder.
J:Displaystheinformationofale,aninputsource
or connected Bluetooth device name.
-Auto Power ON/OFF: Long press Jand press
it again.
: Adjusts sound level of each speaker.
REPEAT:Listenstoyourlesrepeatedlyorrandomly.
SN4.DDEULLM_SIM_ENG_MFL71686164.indd 3 2021-06-09   2:47:42

Additional Information
Specication
Power
consumption
Refer to the main label.
Networked standby : 1.0 W
(If all network ports are
activated.)
AC adapter
• Model : DA-38A25
• Manufacturer : Asian Power
Devices Inc.
• Input : 100 - 240 V ~
50 - 60 Hz
• Output : 25 V 01.52 A
• Model : MS-Z1520R250-
038A0-P
• Manufacturer : MOSO POWER
SUPPLY TECHNOLOGY CO.,
LTD.
• Input : 100 - 240 V ~
50/60 Hz
• Output : 25 V 01.52 A
Dimensions
(W x H x D)
Approx.
890.0 mm X 57.0 mm X
85.0 mm With foot
Bus Power
Supply
(USB)
5 V 0500 mA
Amplier
(Total RMS
Output
power)
300 W RMS
Designandspecicationsaresubjecttochange
without notice.
How to disconnect the wireless network
connection or the wireless device
Set up the AUTO POWER ON/OFF function to off
and turn off the unit.
OPEN SOURCE SOFTWARE NOTICE
INFORMATION
To obtain the source code under GPL, LGPL, MPL, and
other open source licenses, that is contained in this
product, please visit http://opensource.lge.com.
In addition to the source code, all referred license
terms, warranty disclaimers and copyright notices are
available for download.
LG Electronics will also provide open source code to
you on CD-ROM for a charge covering the cost of
performing such distribution (such as the cost of
media, shipping, and handling) upon email request to
opensourc[email protected].
This offer is valid for a period of three years after our
last shipment of this product. This offer is valid to
anyone in receipt of this information.
Declaration of Conformity
Hereby, LG Electronics declares that the radio
equipment type Wireless Sound Bar is in compliance
with Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the following
internet address:
http://www.lg.com/global/support/cedoc/cedoc#
For consideration of the user, this device should be
installed and operated with a minimum distance of
20 cm between the device and the body.
Frequency range Output power (Max.)
2402 to 2480 MHz 10 dBm
5730 to 5850 MHz 13.35 dBm
