LG DSN8YG Specification sheet

SIMPLE MANUAL
LG Wi-Fi
Sound Bar
Please read this manual carefully before operating your set and retain it for
future reference.
To view the instructions of advanced features, visit http://www.lg.com and
then download Owner’s Manual. Some of the content in this manual may
differ from your unit.
MODEL
DSN8YG
www.lg.com
Copyright © 2020-2021 LG Electronics Inc. All Rights Reserved.2104_Rev03
ENGLISH FRANÇAIS NEDERLANDS DEUTSCH ITALIANO
MFL71828463
SN8YG.DNLDLLK_SIMPLE_ENG_MFL71828463.indd 1 2021-04-12  1:13:52

Front Panel
Google Assistant LED
Microphone
1(Standby) ············Switches the unit ON or OFF.
F(Function) ··························Selects function.
p/o(Volume)······················ Adjusts volume.
N········································Play / pause
>(Mic mute)·········································
Enables and disables Voice recognition.
····················································
Standby and Stops feedback of Google Assistant.
Reset the Unit
Press and hold the >on the unit until you
hear the beep sound once.
Rear Panel
DC IN····················· Connect to the AC adapter.
HDMI IN········ Connect to device with HDMI OUT.
HDMI OUT (TV eARC/ARC) ······· Connect to a TV.
OPTICAL IN·············Connect to an optical device.
USB port ····················Connect to a USB device.
Make sure to properly align and connect
the optical cable; improper alignment may
cause damage to the jack.
Subwoofer Connection
Place the wireless subwoofer near the sound bar and
follow steps below.
a Connect the power cord of the sound bar and the
wireless subwoofer to the outlet.
b Turn on the sound bar.
• The sound bar and wireless subwoofer will be
automatically connected. The subwoofer's
green LED turns on.
Manually Subwoofer Connection
If the subwoofer does not make sound, try to
connect manually.
a Press Pairing on the rear of the wireless
subwoofer.
• The green LED on the rear of the wireless
subwoofer blinks quickly.
(If the green LED does not blink, press and
hold the Pairing.)
b Turn on the sound bar.
• Pairing is completed. The green LED on the
rear of the wireless subwoofer turns on.
Keep the sound bar and the subwoofer
away from the device (ex. wireless router,
microwave oven, etc.) over 1 m to prevent
wireless interference.
!1 m
SN8YG.DNLDLLK_SIMPLE_ENG_MFL71828463.indd 2 2021-04-12  1:13:53

TV Connection
Connect the sound bar and TV using Optical ( ) or
HDMI ARC ( ).
Optical Connection
a Connect the sound bar to the TV using Optical
cable.
b Set up [External Speaker (Optical)] on your TV
setting menu.
HDMI (TV eARC/ARC) Connection
a Connect the sound bar to the TV using HDMI
cable.
b Set up [External Speaker (HDMI ARC)] on your
TV setting menu.
• HDMI connection is unavailable if your TV
does not support HDMI ARC.
• If this unit is connected by OPTICAL and
ARC at the same time, the ARC signal has
a higher priority.
Additional Device Connection
a Connect to the external device like as follow.
(Set-top Box,
Player etc.)
OR
b Set the input source by pressing Frepeatedly.
Network Connection
a
b
c
a Check network condition. A router connected to
network should be installed.
b Connect your smart device to your home
network.
c Connect the sound bar to the power supply.
All devices should be connected to same
router.
Step.1 Install “Google Home” App
Download the Google Home App from the Google
Play or App Store.
Step.2 Set up the Wi-Fi connection with
app
a Connect your smart device to the Wi-Fi network
that you’ll use for your unit.
In case of iOS devices, it should be turned
on Bluetooth setting on your smart device.
b Launch the “Google Home” app.
c Follow the steps for Wi-Fi connection on the app.
• When the unit is properly connected to Wi-Fi,
“CONNECTED” will appear on the display
window with sound.
SN8YG.DNLDLLK_SIMPLE_ENG_MFL71828463.indd 3 2021-04-12  1:13:54

• When connect to Wi-Fi, this app may
request to create a Google Account. You
will need a Google account to use this app.
• “Google Home” app is provided by Google.
It might be revised by a change of Google
Policy.
• For more information (Set up, Usage,
Help etc.), research “Google Assistant
Help” or visit the web site. https://support.
google.com/assistant This public site is
provided for devices that work with Google
Assistant.
• The unit may not be available for use on
some functions from the “Google Assistant
Help” site.
• The speaker is not compatible with ”Smart
ThinQ” app. Therefore it is not available in
setup and cannot be controlled by using
“Smart ThinQ” app.
Bluetooth Connection
Step 1. Connect the Wi-Fi
Make sure the unit connects to Wi-Fi by using
“Google Home” app.
Bluetooth function is inactive before
connecting to Wi-Fi.
Step 2. Change Function
Select the Bluetooth function by pressing F
repeatedly.
Step 3. Find and Select your speaker
name
Select speaker name that was set on “Google Home”
app on the device list of your smart device. When
successfully connected Bluetooth, “PAIRED” will
appear on display window.
How to Use “Google Assistant”
Make sure the unit is connected to Wi-Fi.
Case 1. Say “Hey Google”
Hey Google.
The Google Assistant only responds to
voice commands when you are using Wi-Fi
or BT (Bluetooth) as the input.
If you are using HDMI, Optical, ARC, Optical
Sound Sync, or USB input, then you must
use the button to activate the Google
Assistant.
Case 2. Press .
OR
SN8YG.DNLDLLK_SIMPLE_ENG_MFL71828463.indd 4 2021-04-12  1:13:54

Voice command
• Plan your day
“Tell me about my day.”
“What’s my next meeting?”
“Set a reminder to check schedule at 6pm.”
• Weather
“What’s the weather?”
“What’s the weather like tomorrow?”
“What’s the weather like in Cardiff?”
• Music
“Play the music.” “Next song.”
“Previous song.” “Pause the music”
• Availability
“How many calories in a pie?”
“How do I get to Paddington Station?”
“How do you say hello in Korean?”
• Internet
“What movies are showing this weekend?”
“Why is the sky blue?”
“What is the smallest country in Europe?”
“How much sugar is there in a Coke?”
• Smart Home
“Turn up the thermostat.”
“Set the thermostat to 22 degrees”
“Dim the lights in the kitchen.”
“Is the light on in the living room?”
• For more information on the voice
commands, refer to the “Google Home”
app screen or visit the web site. https://
support.google.com/assistant
• If you're having problems with Voice
recognition or this product, suggest your
feedback by saying “Hey Google, feedback”.
It is helpful to Google Service quality
enhancement.
Additional
Comfortable Function
With the Google Assistant built in, you can control
compatible smart home devices such as TV’s, lights,
switches, plugs, thermostats and more by simply
using your voice.
For more information, visit the below web
site.
• Set up, Usage and more: https://support.
google.com/assistant
• Compatible LG appliance models: Visit
http://www.lg.com and then search the
information.
Download LG Sound Bar Application
You can manage the speaker settings and control the
speaker by using “LG Sound Bar”.
Download “LG Sound Bar” on the App Store or
Google Play Store.
AI Room calibration
AI Room Calibration is a sound tuning tool, which
adjusts the audio settings of the Sound Bar based on
the room acoustics and environment.
To access the AI Room Calibration it is necessary to
install the “LG Sound Bar” app. On [Sound Setting]
menu, choose [AI Room Calibration].
SN8YG.DNLDLLK_SIMPLE_ENG_MFL71828463.indd 5 2021-04-12  1:13:54

Remote control
Replacement of Battery
SOUND EFFECT: Selects a sound effect mode.
- TV remote: Long press SOUND EFFECT and
press it again to use TV remote control.
:Standby and Stops feedback of Google
Assistant.
: Adjusts sound level of each speaker.
- Surround sound: Long press and press it
again.
8:Turns on or off the Night time mode.
FOLDER W/S:Searches a folder.
J:Displaystheinformationofale,aninput
source, a connected Bluetooth device name or an
application name.
AUTO POWER: Automatically turns on by an input
source.
REPEAT:Listenstoyourlesrepeatedlyorrandomly.
Additional Information
Specication
Power
consumption
Refer to the main label.
Networked standby : 5.0 W
(If all network ports are
activated.)
AC adapter
• Model: DA-50F25
• Manufacturer : Asian Power
Devices Inc.
• Input: 100 - 240 V ~
50 - 60 Hz
• Output: 25 V 02 A
Dimensions
(W x H x D)
Approx.
1060.0 mm x 57.0 mm x
119.0 mm (with foot)
Bus Power
Supply
(USB)
5 V 0500 mA
Amplier
(Total RMS
Output
power)
440 W RMS
Designandspecicationsaresubjecttochange
without notice.
Rear Speakers Ready
Ready for surround sound with Rear
Speakers Kit sold separately. (SPK8-S)
To enjoy content containing Dolby Atmos® and
DTS:X®, the connected device and content must
support Dolby Atmos® and DTS:X®.
How to disconnect the wireless network
connection or the wireless device
Turn off the unit by pressing the power button for
more than 3 seconds.
SN8YG.DNLDLLK_SIMPLE_ENG_MFL71828463.indd 6 2021-04-12  1:13:55

OPEN SOURCE SOFTWARE NOTICE
INFORMATION
To obtain the source code under GPL, LGPL, MPL, and
other open source licenses, that is contained in this
product, please visit http://opensource.lge.com.
In addition to the source code, all referred license
terms, warranty disclaimers and copyright notices are
available for download.
LG Electronics will also provide open source code to
you on CD-ROM for a charge covering the cost of
performing such distribution (such as the cost of
media, shipping, and handling) upon email request to
opensourc[email protected].
This offer is valid for a period of three years after our
last shipment of this product. This offer is valid to
anyone in receipt of this information.
For more information about Google’s open source,
visit device settings of Google Home app.
Disclaimers
• Google, Google Home, Google Play, Chromecast built-
in and other related marks and logos are trademarks
of Google LLC.
• The Google Assistant requires an internet/data
connection. Data rates may apply.
• The Google Assistant is not available in certain
languages and countries.
• Subscriptions may be required, and additional terms,
conditions and/or charges may apply.
• Controlling certain devices and features in your home
requires a compatible smart device.
Declaration of Conformity
Hereby, LG Electronics declares that the radio
equipment type Wi-Fi SOUND BAR is in compliance
with Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the following
internet address:
http://www.lg.com/global/support/cedoc/cedoc#
The use of the 5150 – 5350 MHz band is restricted
to indoor use only. This restriction exists in Belgium
(BE), Bulgaria (BG), Czech Republic (CZ), Denmark
(DK), Germany (DE), Estonia (EE), Ireland (IE), Greece
(EL), Spain (ES), France (FR), Croatia (HR), Italy (IT),
Cyprus (CY), Latvia (LV), Lithuania (LT), Luxembourg
(LU), Hungary (HU), Malta (MT), Netherlands (NL),
Austria (AT), Poland (PL), Portugal (PT), Romania
(RO), Slovenia (SI), Slovakia (SK), Finland (FI), Sweden
(SE), Northern Ireland (UK(NI)), Switzerland
(CH), Iceland (IS), Liechtenstein (LI), Norway
(NO), and United Kingdom (UK).
For consideration of the user, this device should be
installed and operated with a minimum distance of
20 cm between the device and the body.
Frequency range Output power (Max.)
2402 to 2480 MHz 9 dBm
2412 to 2472 MHz 20 dBm
5180 to 5320 MHz 23 dBm
5500 to 5700 MHz 23 dBm
5730 to 5821 MHz 13 dBm
SN8YG.DNLDLLK_SIMPLE_ENG_MFL71828463.indd 7 2021-04-12  1:13:55

SN8YG.DNLDLLK_SIMPLE_ENG_MFL71828463.indd 8 2021-04-12  1:13:55
