SIMPLE MANUAL
Wireless
Sound Bar
Please read this manual carefully before operating your set and
retain it for future reference.
To view the instructions of advanced features, visit
http://www.lg.com and then download Owner’s Manual.
Some of the content in this manual may differ from your unit.
MODEL
DSNH5
2004_Rev01
MFL71670118
ENGLISH DEUTSCH FRANÇAIS NEDERLANDS ITALIANO SLOVENŠČINA
SNH5.DDEULLK(DSNH5)_SIM_ENG_MFL71670118.indd 1 2020-03-23   11:36:07

Front Panel
1(Standby) ··········Switches the unit ON or OFF.
F(Function) ························Selects function.
p/o(Volume)····················Adjusts volume.
Rear Panel
WOOFER 3 Ω···············Connect to a Subwoofer.
HDMI OUT (TV ARC)··············· Connect to a TV.
HDMI IN ··········Connect to device with HDMI OUT.
OPTICAL IN ············Connect to an optical device.
USB Port ····················Connect to a USB device.
Make sure to properly align and connect the
optical cable; improper alignment may cause
damage to the jack.
Subwoofer Connection
Place the subwoofer near the sound bar and follow
steps below.
a Connect a subwoofer cord to the sound bar.
• When connecting a Subwoofer cord to the
unit, insert the connector until it clicks.
b Turn on the sound bar.
SNH5.DDEULLK(DSNH5)_SIM_ENG_MFL71670118.indd 2 2020-03-23   11:36:09

TV Connection
Connect the sound bar and TV using Optical ( ) or
HDMI ARC ( ).
Optical Connection
a Connect the sound bar to the TV using Optical
cable.
b Set up [External Speaker (Optical)] on your TV
setting menu.
TV
HDMI (ARC) Connection
a Connect the sound bar to the TV using HDMI
cable.
b Set up [External Speaker (HDMI ARC)] on your
TV setting menu.
TV
• HDMI connection is unavailable if your TV
does not support HDMI ARC.
• If this unit is connected by OPTICAL and
ARC at the same time, the ARC signal
has a higher priority.
Additional Device Connection
a Connect to the external device like as follow.
OR
TV
(Set-top Box,
Player etc.)
OR
b Set the input source by pressing Frepeatedly.
Remote control
Replacement of Battery
C/V:Skip/Search
N:Play/Pause
-Bluetooth connection lock (BT LOCK): Select
the Bluetooth function by pressing Frepeatedly.
Long press Nand press it again to limit
Bluetooth connection to only BT and LG TV.
SOUND EFFECT: Selects a sound effect mode.
-TV remote: Long press SOUND EFFECT and
press it again to use TV remote control.
FOLDER W/S: Searches a folder.
J:Displaystheinformationofale,aninputsource
or connected Bluetooth device name.
-Auto Power ON/OFF: Long press Jand press
it again.
: Adjusts sound level of each speaker.
REPEAT:Listenstoyourlesrepeatedlyorrandomly.
SNH5.DDEULLK(DSNH5)_SIM_ENG_MFL71670118.indd 3 2020-03-23   11:36:11

Additional Information
Specication
Power
Requirements Refer to the main label.
Power
consumption
Refer to the main label.
Networked standby : 1.5 W
(If all network ports are
activated.)
Dimensions
(W x H x D)
Approx.
990.0 mm X 97.0 mm X
125.0 mm With foot
Bus Power
Supply (USB) 5 V 0500 mA
Amplier
(Total RMS
Output
power)
600 W RMS
Designandspecicationsaresubjecttochange
without notice.
How to disconnect the wireless network
connection or the wireless device
Set up the AUTO POWER ON/OFF function to off
and turn off the unit.
OPEN SOURCE SOFTWARE NOTICE
INFORMATION
To obtain the source code under GPL, LGPL, MPL, and
other open source licenses, that is contained in this
product, please visit http://opensource.lge.com.
In addition to the source code, all referred license
terms, warranty disclaimers and copyright notices are
available for download.
LG Electronics will also provide open source code to
you on CD-ROM for a charge covering the cost of
performing such distribution (such as the cost of
media, shipping, and handling) upon email request to
opensourc[email protected].
This offer is valid for a period of three years after our
last shipment of this product. This offer is valid to
anyone in receipt of this information.
Declaration of Conformity
Hereby, LG Electronics declares that the radio
equipment type Wireless Sound Bar is in compliance
with Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the following
internet address:
http://www.lg.com/global/support/cedoc/cedoc#
For consideration of the user, this device should be
installed and operated with a minimum distance of
20 cm between the device and the body.
Frequency range Output power (Max.)
2402 to 2480 MHz 10 dBm
