Connecting10
Connecting
2
yIf you use a tripod, use the tripod only for
speaker.
yBefore buying a tripod, check the
specications for maximum bearing load of
the center column.
(Unit’s net weight : about 12.3 kg)
(B)
(A)
35 mm
yUse tripod as below :
(A) From tripod’s center to tripod’s leg :
above 600 mm.
(B) From top of tripod to bottom of tripod :
below 900 mm.
(C) Tripod net weight : over 3.9 kg
yFor safe use set the tripod as low as
possible.
yYou should pull the center column to the
maximum only in case of need.
yMount only one unit on each tripod.
yDo not try to extent the tripod legs beyond
it’s allowed range.
yMake sure the tripod is correctly assembled
and all its components are tightly
connected.
yDo not try to assemble the tripod if parts
are missing or defective.
yAfter installation, make sure the unit is set
up rmly on the tripod.
yDo not place the unit on anything unstable
where it might accidentally fall over.
yAdd weight such as sand bags around the
tripod legs to prevent the tripod from falling
over.
, Note
yYou should limit people around the unit
while its on a tripod. Otherwise it may result
in an accident and may cause personal injury
and/or property damage.
yStanding on the stool to reach unit’s control
panel is risky and might lead to injuries.
yDo not put or attach other objects on the
tripod.
yDo not shake or push the unit when the
tripod is installed.
yRefrain from moving around the tripod after
unit is installed.
yRemove all connected cables to the unit
on the tripod before moving the tripod or
adjusting its height.
yWhen transporting or moving the unit,
always use two or more people.
yWhen you use the tripod, use an extension
cord. Always be careful with the movement
of the cable.
yIt is prohibited to use this unit outside.
(Indoor use only)
yDo not expose the unit to excessive dust,
vibrations, extreme cold or heat (such as in
direct sunlight or near a heater) to prevent
the possible disgurement of the panel or
damage to the internal components.
yWhen using the external input cable (Mic,
etc.) after installing the unit on the tripod,
external input cable can cause the unit to
fall down.
yWatch out because people can trip over the
input cable (Mic, etc.) connected the unit.
yAlways be careful not to trip over the unit.
, Note
