LG CM4750 Specification sheet

Mini Hi-Fi
System
Model : CM4750
Speaker connection
Radio Operation
ANTENNA
a
Using External Device ( or, ) Disc & Data Playback
a
Presetting Radio Station
AUX Connection
PORT. IN Connection
AUX IN
AUX IN
L
R
<
a
z
Play the music on the connected external
device.
c
Select the AUX or PORTABLE.
b
Select the Radio.
b
a
b
Select the station to preset.
c
Select the preset number and store the
station.
Select the preset station to listen.
Use the speakers far away from either TV screen or PC monitor.
,
Tune the desired frequency.
Connect the USB or insert the CD you want
to play.
Press and hold.
a
bPress PROGRAM/MEMORY when
“ERASEALL”blinks to conrm.
To delete all the saved station
c
www.lg.com
ENGLISH | SIMPLE MANUAL (1 of 2)
To view the instructions of advanced features, visit http://
www.lg.com and then download Owner’s Manual. Some of
the content in this manual may differ from your unit.
FM Antenna
Auto tuning : Press and hold.
,
Manual tuning : Press.
,
FM 87.50
FM 87.50
01 87.50
ERASEALL
Select the CD or USB.
b
c
Select the desired song and the song is
played.
CD USB
Red
Black
*MFL69543870*
CM4750-FB_DKENHLK_SIM_3870_1416.indd 1 2016-03-21  9:47:39

Set on the Bluetooth and select “LG
CM4750 (XX)” on your Bluetooth device.
Using BLUETOOTH®
Select the Bluetooth function.
BT READY
LG Sound Sync
aSelect LG TV function.
LG Sound Sync enables you to control some functions of this unit by a remote control of your LG TV.
Controllable functions are volume up/down and mute. Make sure that your TV has LG Sound Sync logo as
shown above.
Auto Power On
This unit automatically turns on by an input source : LG TV or Bluetooth
If you have already paired with this unit, automatically this unit can turn on by an input source when this unit
is turned o.
LG TV
aPlay a music on your Bluetooth device.
Even when this unit is connected to 3 Bluetooth devices in the Bluetooth mode, you can play and
control music by using only one of the connected devices.
The multi pairing connection is only supported on Android or iOS devices. (Multi pairing connection
may not be supported depending on the connected device specications.)
A removable/detachable Bluetooth device (Ex : Dongle etc.) doesn’t support multi pairing.
Even when this unit is connected with multiple Bluetooth devices, only one device which is playing
will keep the Bluetooth connection, even if you change the function of the other devices.
,
,
,
,
c
b
PAIRED
Enter the PIN code (0000) as needed.
,
When this unit is successfully connected with your Bluetooth device, “PAIRED”will be appear on the
display window. The display will change to the Bluetooth device’s name soon after.
,
If the device name isn’t available on the unit,“_” will be displayed.
,
Auto Function Change
This unit recognizes input signals such as Bluetooth and LGTV and then changes suitable function
automatically.
To use this unit more comfortably, install “Music Flow Bluetooth”on your Bluetooth devices. Select a way of
installation ( , ).
Using “Music Flow Bluetooth” App
Searching for“Music Flow Bluetooth”on the
Google Play Store.
Scanning QR code.
HELLO
Auto DJ blends the end of one song into the beginning of another for seamless playback.
Press repeatedly to select the mode you
want.
RANDOM (AUTO DJ RANDOM) -> RPT (AUTO
DJ SEQUENTIAL) -> (AUTO DJ OFF)
AUTO DJ
Only AUTO DJ SEQUENTIAL is selected when played Programmed list.
,
bSet up the sound output of your TV : TV
setting menu [[Sound] [[TV Sound
output] [[LG Sound Sync (Wireless)]
LG TV
PAIRED
For specic information of operating, refer to the instruction manual of yourTV.
,
If the connection fails, check the conditions of this unit and your TV : power, function.
,
The amount of time to turn o this unit is dierent depending on your TV.
,
AUTO DJ
RANDOM AUTO DJ
SEQUENTIAL
AUTO DJ OFF
aPress to move superior or subordinate folder
from the root folder.
Empty folders are not searched.
,
bSelect the folder to play. The rst le of the
folder is played.
Folder Searching
Android O/S : Ver 4.0.3 (or later)
,
Refer to the guide from the “Music Flow Bluetooth” app on your smart device.
,
LGCM4750 (XX) LG CM4750 (XX)
TV Speaker
External Speaker
LG Sound Sync (Optical)
LG Sound Sync (Wireless)
CM4750-FB_DKENHLK_SIM_3870_1416.indd 2 2016-03-21  9:47:40

Mini Hi-Fi
System
Model : CM4750
ENGLISH | SIMPLE MANUAL (2 of 2)
To view the instructions of advanced features, visit http://
www.lg.com and then download Owner’s Manual. Some of
the content in this manual may differ from your unit.
USB Recording
a
b
Press to stop the recording
Press to pause the recording. (OnlyTUNER,
AUX, PORTABLE)
Press and hold for 3 seconds.
a
To select bitrate and recording speed
USB REC
bSelect the bitrate and conrm.
USB REC
c
USB REC
Connect a USB storage and select the
source (CD, AUX, PORTABLE, TUNER) to
record.
USB REC
Press to start recording. During recording,
“REC” displayed.
,
Select the recording speed and conrm.
(Only CD function)
,Status Recording (Only CD function)
Playback One track/le
Programmed playback Programmed the track(s)/le(s)
Full stop All track(s)/le(s)
Deleting le
,
This function is supported only in stop status. (USB only)
,
a
Press to exit the current mode.
Select the le you want to delete.
DELETE
cPress to delete le, folder or format.
Select the folder you want to delete.
bSelect the DEL FILE, DEL DIR or FORMAT.
DEL DIR
FORMAT DEL FILE
Additional Feature
USB copying
Connect USB devices to USB ports and
select USB 1.
a
b
USB REC
Press USB REC to start recording. Audio les
in USB 1 are copied to USB 2.
Press to stop recording
,
Press to pause the recording. (OnlyTUNER,
AUX, PORTABLE)
,Status Recording
Playback One track/le
Programmed playback Programmed the track(s)/le(s)
Full stop All track(s)/le(s)
AUDIO CD MP3/WMA The other source* TUNER
A le is recorded by about 512 Mbyte when you record for a long term.
,
When you stop recording during playback, the le that has recorded at that time will be stored.
(Except MP3/WMA le)
,
It’ll be stored as follows. * The other source : AUX and the like.
,
Press and hold.
a
b
AM 12:00 0:00
10 OFF 120 ... 180 150
FILE-XXX_001
Alarm function works only after clock is set.
,
XX:00
00:XX
c
d
Press and hold.
a
b
c
d
e
XX:00
00:XX
VOL XX
CD
USB1
TUNER
USB2
CM4750-FB_DKENHLK_SIM_1415_1416.indd 3 2015-02-26 �� 4:28:07

To enjoy Programmed Playback
Press again after you make the list.
a
Press twice to exit from Programmed
Playback mode.
To delete Programmed Playback List
Press in stop status.
a
bPress repeatedly to select a track/le.
Press to delete selected song.
c
DELETE
Programmed Playback
bPress to play the list.
Specication
ENGLISH
Power Requirements Refer to the main label on
the unit.
Power Consumption
Refer to the main label on
the unit.
Networked standby : 0.4 W
(If all network ports are
activated.)
Bus Power Supply
(USB) 5 V 0500 mA
Total Output 1000 W
Design and specications are subject to change
without notice.
Additional Information
Music File Requirement
Sampling frequency
yMP3 : 32 - 48 kHz
yWMA : 32 - 48 kHz
Bit rate
yMP3 : 32 - 320 kbps
yWMA : 40 - 192 kbps
Maximum les Data CD : 999 / USB : 2000
Maximum folders Data CD : 99 / USB : 200
File extensions
y“.mp3”
y“.wma”
CD-ROM le format ISO9660+JOLIET
USB Flash Drive Devices that support USB2.0 or USB1.1.
Bluetooth Codec SBC
Safety Information
Press to enter the edit mode.
a
bSelect a track/le and conrm.
Press again to exit from the edit mode.
c
You can make a playlist of your favourite tracks/les from a disc or USB device using Programmed Playback.
To make Programmed Playback list
A playlist of up to 20 tracks/les can be entered for CD/USB1/USB2.
,
Repeat steps bto store other les.
,
,This function is supported only on stop status.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT
REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This lightning ash with arrowhead symbol
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
dangerous voltage within the product’s
enclosure that may be of sucient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the product.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
CAUTION: The apparatus shall not be exposed to water (dripping
or splashing) and no objects lled with liquids, such as vases, shall
be placed on the apparatus.
WARNING: Do not install this equipment in a conned space such
as a book case or similar unit.
CAUTION: Do not use high voltage products around this product.
(ex. Electrical swatter) This product may malfunction due to
electrical shock.
CAUTION: Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
Slots and openings in the cabinet are provided for ventilation and
to ensure reliable operation of the product and to protect it from
over heating. The openings shall be never be blocked by placing
the product on a bed, sofa, rug or other similar surface. This product
shall not be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the manufacturer’s
instruction has been adhered to.
CAUTION: This product employs a Laser System.To ensure proper
use of this product, please read this owner’s manual carefully and
retain it for future reference. Shall the unit require maintenance,
contact an authorized service center.
Use of controls, adjustments or the performance of procedures
other than those specied herein may result in hazardous radiation
exposure. To prevent direct exposure to laser beam, do not try to
open the enclosure.
CAUTION concerning the Power cord
The Power Plug is the disconnecting device. In case of an
emergency, the Power Plug must remain readily accessible.
This device is equipped with a portable battery or accumulator.
Safety way to remove the battery or the battery from the
equipment: Remove the old battery or battery pack, follow the
steps in reverse order than the assembly.To prevent contamination
of the environment and bring on possible threat to human
and animal health, the old battery or the battery put it in the
appropriate container at designated collection points. Do not
dispose of batteries or battery together with other waste. It is
recommended that you use local, free reimbursement systems
batteries and accumulators. The battery shall not be exposed to
excessive heat such as sunshine, re or the like.
POWER: This unit operates on a mains supply of 200 - 240 V ~,
50 / 60 Hz.
Wiring: This unit is supplied with a BS 1363 approved main plug.
When replacing the fuse, always use of the same rating approved
to BS 1362. Never use this plug with the fuse cover omitted. To
obtain a replacement fuse cover contact your dealer. If the type of
plug supplied is not suitable for the mains sockets in your home,
then the plug should be removed and a suitable type tted. Please
refer to the wiring instructions below:
Warning: A mains plug removed from the mains lead of this unit
must be destroyed. A mains plug with bared wires is hazardous
if inserted in a mains socket. Do not connect either wire to the
earth pin, marked with the letter E or with the earth symbol 6or
coloured green or green and yellow. If any other plug is tted, use
same rating of fuse in the plug.
Important: The wires in this mains lead are coloured in accordance
with the following codes:
- BLUE: NEUTRAL, BROWN: LIVE - As the colours of the wires in
the mains lead of this unit may not correspond with the coloured
marking identifying the terminals in your plug, proceed as follows:
The wire which is coloured blue must be connected to the terminal
which is marked with the letter N or coloured black. The wire which
is coloured brown must be connected to the terminal which is
marked with the letter L or coloured red.
The USB function of this unit does not support all USB devices.
,
External HDD, Card readers, Locked devices, or hard type USB devices are not supported.
Using NTFS le system is not supported. (Only FAT(16/ 32) le system is supported.)
,
,
,
The DTS is not supported. In case of DTS audio format, audio is not output.
,How to disconnect the wireless network connection or the wireless device
Turn o the unit by pressing the power button for more than 5 seconds.
CM4750-FB_DKENHLK_SIM_1415_1416.indd 4 2015-02-26 �� 4:28:09
