LG OM4560 Specification sheet

SIMPLE MANUAL
MINI HI-FI
AUDIO
To view the instructions of advanced features,
visit http://www.lg.com and then download Owner’s Manual.
Some of the content in this manual may differ from your unit.
MODEL
OM4560
*MFL69304452* www.lg.com
ENGLISH

Front Panel
a 1/!(Power) : Switches the unit ON or OFF.
MIC +/- : Adjusts microphone volume.
bF / WIRELESS LINK : Selects the function and input source.
/ Press and hold for 3 seconds to select WIRELESS PARTY
LINK mode.
REGION EQ / BASS BLAST : Chooses region equalizer. /
Press and hold for 3 seconds to select BASS (BASS BLAST)
effect directly.
VOICE CANCELLER :You can enjoy the function while
playing the music, by reducing singer vocal of music in the
various source.
USB REC / DEMO : Records to USB. / Shows Demo mode.
c MIC 1 : Connect a microphone.
d Display window
e R: Opens and closes the disc tray.
f USB Port : You can play or record sound les by connecting
the USB device.
g Y/U : Skips fast backward or forward. / Searches for a
section within a track/file.
I: Stops playback or cancels DELETE function.
z: Starts or pauses playback.
h VOL +/- : Adjusts speaker volume.
LIGHTING / PARTY LINK : Turns on/off the lighting effects. /
Press and hold for 3 seconds to select PARTY LINK mode.
aPower cord
bFM ANTENNA
cAUX IN (L/R)
AUX OUT (L/R)
Download the Music Flow Bluetooth App to your
device.
For more information, download the online owner’s
manual. http://www.lg.com
LG Sound Sync (Wireless)
Controller App
Specication
Power
requirements Refer to main label.
Power
consumption
Refer to main label.
Networked standby : 0.5 W
(If all network ports are
activated.)
Dimensions
(W x H x D)
Approx. 451.5 mm x 311 mm
x 302.5 mm
Net Weight Approx. 7.5 kg
Bus Power Supply
(USB) 5 V 0 500 mA
Amplier
(Total RMS output
power)
220 W x 1 (3 Ωat 1 kHz,
25 % THD)
Design and specications are subject to change without
notice.
How to disconnect the wireless network
connection or the wireless device
Turn off the unit by pressing the power button for more
than 5 seconds.
Replacement of battery
(R03)
(R03)
Additional Information
Rear Panel
a b g hd fec
a b c
POWER: This unit operates on a mains supply of
200-240V~, 50/60Hz.
Wiring: This unit is supplied with a BS 1363 approved
main plug. When replacing the fuse, always use of the
same rating approved to BS 1362. Never use this plug
with the fuse cover omitted. To obtain a replacement fuse
cover contact your dealer. If the type of plug supplied is
not suitable for the mains sockets in your home, then the
plug should be removed and a suitable type tted. Please
refer to the wiring instructions below:
Warning: A mains plug removed from the mains lead
of this unit must be destroyed. A mains plug with bared
wires is hazardous if inserted in a mains socket. Do not
connect either wire to the earth pin, marked with the
letter E or with the earth symbol or coloured green
or green and yellow. If any other plug is tted, use same
rating of fuse in the plug.
Important: The wires in this mains lead are coloured in
accordance with the following codes:
- BLUE: NEUTRAL, BROWN: LIVE - As the colours of the
wires in the mains lead of this unit may not correspond
with the coloured marking identifying the terminals in
your plug, proceed as follows: The wire which is coloured
blue must be connected to the terminal which is marked
with the letter N or coloured black. The wire which is
coloured brown must be connected to the terminal which
is marked with the letter L or coloured red.
