LG Banter Touch UN510 User manual

P/NO : MMBB0390201(1.0)
Printed in Korea H
LG-UN510

Copyright ©2010 LG Electronics, Inc. All rights reserved.
LG and the LG BanterTM are registered trademarks of LG
Group and its related entities. All other trademarks are the
property of their respective owners.

Important Safety Precautions
1
Important Safety Precautions
Read these instructions. Breaking the rules may be dangerous or
illegal. Further detailed information is given in this user guide.
WARNING! Violation of the instructions may cause serious injury or
death.
1. Never use an unapproved battery since this could
damage the phone and/or battery and could cause
the battery to explode.
2. Never place your phone in a microwave oven as it will
cause the battery to explode.
3. Never store your phone in temperatures less than
-4°F or greater than 122°F.
4. Do not dispose of your battery by fire or with
hazardous or flammable materials.
5. When riding in a car, do not leave your phone or set
up the hands-free kit near tothe air bag. If wireless
equipment is improperly installed and the air bag is
deployed, you may be seriously injured.
6. Do not use a hand-held phone while driving.
7. Do not use the phone in areas where its use is
prohibited. (For example: aircraft)

Important Safety Precautions
2
Important Safety Precautions
1. Do not expose the battery charger or adapter to direct
sunlight or use it in places with high humidity, such as
abathroom.
2. Do not use harsh chemicals (such as alcohol, benzene,
thinners, etc.) or detergents to clean your phone. This
could cause a fire.
3. Do not drop, strike, or shake your phone severely. It
may harm the internal circuit boards of the phone.
4. Do not use your phone in high explosive areas as the
phone may generate sparks.
5. Do not damage the power cord by bending, twisting,
pulling, or heating. Do not use the plug if it is loose as
it may cause a fire or electric shock.
6. Do not place any heavy items on the power cord. Do
not allow the power cord to be crimped as it may
cause electric shock or fire.
7. Do not handle the phone with wet hands while it is
being charged. It maycause an electric shock or
seriously damage your phone.
8. Do not disassemble the phone.

3
Important Safety Precautions
1. Do not place or answer calls while charging the phone as it may
short-circuit the phone and/or cause electric shock or fire.
2. Do not hold or let the antenna come in contact with your body
during a call.
3. Make sure that no sharp-edged items such as animal’s teeth or
nails, come into contact with the battery. This could cause a fire.
4. Storethe battery out of reach of children.
5. Be careful thatchildren do not swallow any parts (such as
rubber plugs, earphone, connection parts of the phone, etc.)
This could cause asphyxiation or suffocation resulting in serious
injury or death.
6. Unplug the power cordand charger during lightning storms to
avoid electric shock or fire.
7. Only use the batteries and chargers provided by LG. The
warrantywill notbe applied toproductsprovided by other
suppliers.
8. Only authorized personnel should service the phone and its
accessories. Faulty installation or service may result in accidents
and consequently invalidate the warranty.
9. Your service provider programs one or more emergency phone
numbers, such as 911, that you can call under any
circumstances, even when your phone is locked. Your phone’s
preprogrammed emergency number(s) may not work in all
locations, and sometimes an emergency call cannot be placed
due to network, environmental, or interference issues.

Table of Contents
4
Table of Contents
Important Safety
Precautions 1
Table of Contents 4
Welcome 10
Technical Details 11
FCC RF ExposureInformation 13
BodilyContact During Operation 13
Vehicle-Mounted the External
Antenna 14
FCC Notice and Cautions 14
Caution 15
Part 15.19 statement 15
Part 15.21statement 15
Part 15.105 statement 16
Phone Overview 17
Touch Keys 18
Menus Overview 22
Menu Access 22
Getting Started with Your
Phone 26
The Battery 26
Installing the Battery 26
Removing the Battery 26
Charging the Battery 26
How to Install Your microSD™
Card 27
How to Remove Your microSD™
Card 28
Battery Charge Level 28
Turning the Phone On and Off 28
Turning the Phone On 28
Turning the Phone Off 28
Signal Strength 29
Screen Icons 29
Making Calls 29
Correcting Dialing Mistakes 30
Redialing Calls 30
Receiving Calls 30
Quick Access to
Convenient Features 31
Lock Mode 31
Speakerphone Function 31
Volume Quick Adjustment 31

5
Table of Contents
Call Waiting 31
Caller ID 32
Speed Dialing 32
Entering and Editing
Information 33
Text Input 33
Contactsin Your Phone’s
Memory 34
The Basics of Storing Contacts
Entries 34
Phone Numbers With Pauses 34
Storing a Number with Pauses 35
Adding a Pause toan Existing
Number 35
Searching Your Phone’sMemory 35
Accessing Options 36
Making a Call From Your Phone’s
Memory 37
Using Phone Menus 38
Contacts 38
1. New Contact 38
2. Contact List 38
3. Speed Dials 39
4. Groups 39
5. My vCard 40
Call History 40
1. Missed Calls 40
2. Received Calls 41
3. Dialed Calls 41
4. All Calls 42
5. Call Timer 42
6. Data Counter 42
Messaging 43
1. New Text Message 43
2. New Picture Message 45
3. Inbox 46
4. Drafts 48
5. Outbox 48
6. Voicemail 50
7. Templates 50
8. DeleteAll 50
9. Message Settings 51
9.1 All Messages 51
9.2 Text Messages 52

Table of Contents
6
Table of Contents
9.3 Picture Messages 52
9.4 Voicemail Number 52
New Text Message 52
easyedge 53
Browser 54
Dialer 61
Bluetooth
®
61
1. Power 61
2. Add New 62
3. Paired Devices 63
4. Settings 63
4.1 My Visibility63
4.2 Device Name 63
4.3 My Bluetooth Info 64
4.4 Supported Profiles 64
4.5 Found Devices 64
4.6 Delete All 64
Toneroom Deluxe 65
PAC-MAN 65
My Stuff 65
Record Voice 65
Photos 66
Videos 68
Gallery 69
Music 71
1. Now Playing/ Recently
Played 71
2. All Songs 71
3. Artists 72
4. Albums 72
5. Genres 73
6. My Playlists 73
7.Settings 73
7. 1Repeat 73
7. 2Shuffle Songs 74
7. 3Background Music 74

7
Table of Contents
Voice Command 75
1. Start Command 75
1.1 Call <Name> or <Number> 75
1.2 Voicemail 75
1.3 Missed Calls 75
1.4 Messages 76
1.5 Time & Date 76
1.6 Help 76
2. Command Mode 77
3. Announce Alert 77
4. Train Word 77
5. Best Match 78
Notepad 78
Calendar 78
EZ Tip Calculator 79
Alarm Clock 80
World Clock 80
Calculator 81
Tools 81
1. Date Finder 81
2. Unit Converter 82
3. Stopwatch 82
4. Drawing Panel 83
Sound Settings 84
1. Ringers 84
2. Volume 84
3. Message Alerts 85
4. Alert Type 85
5. Service Alerts 86
6. Power On/Off Tones 86
Display Settings 87
1. Wallpaper 87
2. Banner 87
3. LCD Settings 88
3.1 Power Save 88
3.2 Backlight 88
3.3 Brightness 88
4. Idiomas(Languages) 89
5. Clock & Calendar 89
6. Font Settings 89

Table of Contents
8
Table of Contents
7. Dial Font Size 90
8. Theme 90
8.1 Background Style 90
8.2 Menu Style 90
9. Name Match for Dialing 90
Call Settings 91
1. Answer Options 91
2. Auto Retry 91
3. One Touch Dial 91
4. Voice Privacy 92
5. Auto Volume 92
6. Airplane Mode 93
7. TTY Mode 93
Touch Settings 94
1. Touchscreen Calibration 94
2. Touchscreen Effect 94
Phone Settings 95
1. Auto Touch Lock 95
2. Security 96
2.1 Lock Phone 96
2.2 Restrictions 97
2.3 Emergency Numbers 97
2.4 Change Lock Code 98
2.5. Master Reset 98
3. Memory 99
4. Phone Info 99
4.1 My Number 99
4.2 ESN/MEID 100
4.3 Icon Glossary 100
4.4 SW/HW Version 100
4.5 easyedge Version 100
System 101
1. Network 101
1.1 System Select 101
1.2 Set NAM 101
1.3 AutoNAM 101
1.4 Serving System 102
2. Location 102
Speed Dials 103
USB Connection 103
Troubleshooting 104

9
Welcome
Safety 106
TIA Safety Information 106
Exposure to Radio Frequency
Signal 106
Antenna Care 107
Phone Operation 107
Tips on Efficient Operation 107
Driving 107
Electronic Devices 107
Pacemakers 108
Persons with pacemakers: 108
Hearing Aids 108
Other Medical Devices 108
Health Care Facilities 109
Vehicles109
Posted Facilities109
Aircraft 109
Blasting Areas 109
Potentially Explosive Atmosphere 109
For Vehicles Equipped with an
Air Bag 110
Battery Information and
Care 110
Safety Information 111
Charger and Adapter Safety 112
Battery Information and Care 113
Explosion, Shock, and Fire
Hazards 114
General Notice 114
Warning! Important safety
information 116
Avoiding hearing damage 116
Using your phone safely 116
Using headsets safely 117
FDA Consumer Update 117
10 Driver Safety Tips 128
Consumer Information
on SAR 131
FCC Hearing-Aid Compatibility
(HAC) Regulations for
Wireless Devices 135
Accessories 138
Limited Warranty
Statement 139
Index 143

Welcome
10
Technical Details
Thank you for choosing the
cellular phone designed
to operate with the latest digital
mobile communication technology,
Code Division Multiple Access
(CDMA). Along with the many
advanced features of the CDMA
system, this compact phone offers:
●
Music playing capability.
●
microSD™card slot.
●
Significantly enhanced voice
clarity.
●
Slim and sleek design with
internal antenna.
●
Large, easy-to-read, backlit LCD
with status icons.
●
Messaging, voice mail, and caller
ID.
●
7exterior keys, QWERTY
keypad, and touchscreen.
●
Speakerphone feature.
●
2.0 megapixel camera
●
Menu-driven interface with
prompts for easy operation and
configuration.
●
Any key answer, auto with
handsfree answer, auto retry,
one-touch and speed dialing
with 99memory locations.
●
Bilingual (English and Spanish)
capabilities.
●
Bluetooth®wireless technology.
Note
The Bluetooth®word mark and
logos are owned by the Bluetooth®
SIG, Inc. and any use of such marks
by LG Electronics is under license.
Other trademarks and trade names
are those of their respective owners.

Technical Details
11
Technical Details
Important Information
This user’s guide provides
important information on the use
and operation of your phone.
Please read all the information
carefully prior to using the
phone for the best performance
and to prevent any damage to or
misuse of the phone. Any
unapproved changes or
modifications will void your
warranty.
FCC Part 15 Class B
Compliance
This device and its accessories
comply with part 15 of FCC rules.
Operation is subject to the
following two conditions: (1) This
device and its accessories may not
cause harmful interference, and
(2) this device and itsaccessories
must acceptanyinterference
received, including interference
thatcausesundesired operation.
Technical Details
The is an all digital
phone that operates on both
Code Division Multiple Access
(CDMA) frequencies: Cellular
services at 800 MHz and
Personal Communication Services
(PCS) at 1.9 GHz.
CDMA technology uses a feature
called DSSS (Direct Sequence
Spread Spectrum) that enables the
phone to keep communication from
being crossed and to use one
frequency channel by multiple users
in the same specific area. This results
in a 10-fold capacity increase when
compared with analog mode. In
addition, features such as soft /
softer handoff, hard handoff, and
dynamic RF power control
technologies combine to reduce call
interruptions.
The Cellular and PCS CDMA
networks consist of MSO (Mobile
Switching Office), BSC (Base
Station Controller), BTS (Base
Station Transmission System), and
MS (Mobile Station).

Technical Details
12
Technical Details
*TSB-74: Protocol between an IS-
95A system and ANSI J-STD-
008
Its battery life is twice as long as
IS-95. High-speed data
transmission is also possible.
The following table lists some
major CDMA standards.
CDMA Standard
Basic Air
Interface
TIA/EIA-95A
TSB-74
ANSI J-STD-008
TIA/EIA-IS2000
CDMA Dual-Mode Air Interface
14.4kbps radio link protocol and inter-
band operations
IS-95 adapted for PCS frequency band
CDMA2000 1xRTT Air Interface
MAS-BS
PCSC-RS
Intersystem operations
Non-signaling datacomm.
CDMA2000 High Rate Packet Data Air
Interface
1xEV-DO Inter-Operability Specification for
CDMA2000 Access Network Interfaces
Recommended Minimum Performance
Standards for CDMA2000 High Rate
Packet Data Access Terminal Test
Application Specification (TAS) for High
Rate Packet Data Air Interface
TIA/EIA/IS-634
TIA/EIA/IS/651
TIA/EIA/IS-41-C
TIA/EIA/IS-124
TIA/EIA/IS-856
TIA/EIA/IS-878
TIA/EIA/IS-866
TIA/EIA/IS-890
TIA/EIA/IS-96-B
TIA/EIA/IS-637
TIA/EIA/IS-657
IS-801
TIA/EIA/IS-707-A
Speech CODEC
Short Message Service
Packet Data
Position Determination Service (gpsOne)
High Speed Packet Data
Network
Service
1x EV-DO
Related
interface
Designator Description

13
Technical Details
FCC RF Exposure Information
WARNING! Read this
information before operating
the phone.
In August 1996, the Federal
Communications Commission
(FCC) of the United States, with
its action in Report and Order
FCC 96-326, adopted an
updated safety standard for
human exposure to Radio
Frequency (RF) electromagnetic
energy emitted by FCC regulated
transmitters. Those guidelinesare
consistent with the safety
standard previously set by both
U.S. and international standards
bodies. The design of this phone
complies with the FCC guidelines
and these international
standards.
Bodily Contact During
Operation
This device was tested for typical
use with the back of the phone
kept 0.79 inches (2.0 cm) from
the body. To comply with FCC
RF exposure requirements, a
minimum separation distance of
0.79 inches (2.0 cm) must be
maintained between the user’s
body and the back of the phone,
including the antenna, whether
extended or retracted. Third-
partybelt-clips, holsters, and
similar accessories containing
metallic componentsshould not
be used. Avoid the use of
accessories that cannot maintain
0.79inches (2.0 cm) distance
between the user’s body and the
back of the phone and have not
been tested for compliance with
FCC RF exposure limits.

Technical Details
14
Technical Details
Vehicle-Mounted the External
Antenna
(Optional, if available.)
To satisfy FCC RF exposure
requirements, keep 8 inches (20
cm) between the user /
bystander and vehicle-mounted
the external antenna. For more
information about RF exposure,
visit the FCC website at
www.fcc.gov.
FCC Notice and Cautions
This device and itsaccessories
complywith part 15of FCC
rules. Operation is subject to the
following twoconditions: (1)
This device and its accessories
maynot cause harmful
interference, and (2) this device
and its accessories must accept
anyinterference received,
including interference that
causes undesired operation.
Any changes or modifications
not expressly approved in this
user guide could void your
warranty for this equipment. Use
only the supplied antenna. Use
of unauthorized antennas (or
modifications to the antenna)
could impair call quality, damage
the phone, void your warranty
and/or violateFCC regulations.
Don't use the phone with a
damaged antenna. A damaged
antenna could cause a minor skin
burn. Contact your local dealer
for a replacement antenna.

15
Technical Details
Caution
Use only the supplied and
approved antenna. Use of
unauthorized antennas or
modifications could impair call
quality, damage the phone, void
your warranty and/or result in
violation of FCC regulations. Do
notuse the phone with a
damaged antenna. If a damaged
antenna comes into contact with
the skin a minor burn may result.
Contact your local dealer for a
replacement antenna.
Part 15.19 statement
This device and its accessories
comply with part15 of FCC rules.
Operation is subject to the
following two conditions:
(1) This device & its accessories
may not cause harmful
interference.
(2) This device & its accessories
must acceptanyinterference
received, including
interference that may cause
undesired operation.
Part 15.21 statement
Changesor modifications that
are not expressly approved by
the manufacturer could void the
user's authority to operate the
equipment.

Technical Details
16
Technical Details
Part 15.105 statement
This equipment has been tested
and found to comply with the
limits for a class B digital device,
pursuant to Part 15 of the FCC
Rules. These limits are designed
to provide reasonable protection
against harmful interference in a
residential installation. This
equipment generates, uses, and
can radiate radio frequency
energy and, if not installed and
used in accordance with the
instructions, may cause harmful
interference to radio
communications. However, there
is no guarantee that interference
will notoccur in a particular
installation. if this equipment
doescause harmful interference
or television reception, which can
be determined by turning the
equipment off and on, the user is
encouraged to try to correct the
interference by one or more of
the following measures:
-Reorient or relocate the
receiving antenna.
-Increase the separation between
the equipment and receiver.
-Connect the equipment into an
outlet on a circuit different from
that to which the receiver is
connected.
-Consult the dealer or an
experienced radio/TV
technician for help.

Phone Overview
17
Phone Overview
1.LED light Alerts you of new notifications.
2.Earpiece Lets you hear the caller.
3. Slide Slide open to access the QWERTY
keyboard.
4.LCD Screen Displays incoming calls,
messages and status icons as well as a
wide variety of content you select to view.
5.SEND Key Use to place or answer calls.
You can also press to access your most
Recent Calls.
6.BACK Key Deletes single spaces or
characters with a quick press. To delete
entire words, press and hold this key. This
key will also allow you to back out of
menus, one level at a time. Press and hold
from the standby screen to enable/disable
the Speakerphone.
7. END Key Use to end a call. Also returns
you to the Homescreen.
8.Accessory/Charger Port Connectsthe
phone tothe battery charger or other
compatible accessories.
9. Microphone Allows other callers to hear
you clearlywhen you are speaking to
them.
10. Alphanumeric Keypad Use toenter
numbers and characters and select
menuitems.
11. Speaker Lets you hear the caller's voice,
music and a video’saudio in
speakerphone mode.
12. CameraLens Use totake photos and
record video. Keep it clean for optimal
photo quality.

Phone Overview
18
Phone Overview
1.Volume Keys Use to adjust the Master
Volume from the Homescreen and the
Earpiece volume during a call.
2.Camera Key Use for quick access to
Multimedia functions. Press and hold to
open the Camera.
3.Earphone Jack Allows the use of a
headset to hear caller's voice.
4.Power/Lock Key Allows you to turn the
phone on and off. You can also lock and
unlock the phone.
Touch Keys
( , , , )
1. For optimal performance, make
sure your hands are clean and
dry. Remove any moisture from
the surface of your hands.
Don't use in a humid
environment.
2. Touch keysensors aresensitive
to your light touch. You don't
need to press them forcefully
touse them. Protect your
phone from severe impact and
can cause the touch key
sensors to become damaged
from harsh use.
microSD™cardslot (accommodates an optional
microSD™card up to 16GB.) Only use an LG-approved
microSD™card. Toaccess the microSD™cardslot you
must removethe cover located on the microSD™card
slot.
