LG VS86 Series User manual

DWG.
No.
TRIG.
DR COMPLETED
도면 DR 완료
완료일 :
LG 전자 (주)
LG Electronics Inc.
UNIT SCALE 11 mm
REVIEWEDDESIGNED
RELATED DWG.
CHECKED APPROVED
성 은 지 황 만 태
16.05.16 16.05.16
MODELING I
T
L
E
T
APPROVED
승인자
PREPARED
시방자
DATE
년/월/일
REF. NO.
이 창 훈신 주 은2016.07.22EKFG700250
시방 번호
REV. NO.
기호
REVISION DESCRIPTION
LG 로고 변경
이 창 훈신 주 은2017.01.05EKFH100047배터리 이슈에 따른 문구 추가, 신포맷 적용
김 현 우송 재 현2017.03.20EKFH300230‘전원 무’ Claim 개선을 위한 문구 추가
변경 사항
8
RELEASING THIS DRAWING
WITHOUT PERMISSION LG
Electronics SHOULD BE
ACCUSED ACCORDING TO THE
LAWS AND COMPANY RULES.
이 도면은 LG전자의 자산으로 불법
유출시 관계법과 회사규정에 의해 처벌됨.
PDF
ILLUSTRATOR
148
210
MFL67983122
MANUAL,OWNER’S
Cloud-I 물걸레 대만향
1/1
MFL67983122
<< 주기 >>
1. 재질, 인쇄방법, 인쇄도수, 외곽치수등은 작업표에 준한다.
2. 인쇄내용, 문자크기 및 형상, 선의 굵기 등은 설계에서 제시된 도면에 준함.
3. 외곽치수는 절단후 치수임.
4. 양산전에 설계 한도를 득할 것.
5. 본 부품에 금지물질이 포함되지 않도록 하고, 상세내용은 LG(63)-A-5501-34
를 만족할 것.
<< NOTES >>
1. Material, printing and exterier size are refer to work tables.
2. Printing, text size and line are based on LG design drawing.
3. Exterier size on the drawing is cutting line.
4. Before product controlled by criteria sample.
5. The part should not contain prohibited substances(Pb,Cd,Hg,Cr+6,PBB,
PBDE) and details should comply with LG standard of LG(63)-A-5501-34
WORK
적용모델
20
재 질 인쇄방법
인 쇄 도 수
표 지 내 지
1도 1도
OFFSET 인쇄 32, A5
PAGE
REMARK
SEC.
VS8600SWM
7
6
5
4
3
2
1
모조지 80g OFFSET 인쇄
대만향
Taiwan

MFL67983122
www.lg.com
VS86*****
使用手冊
OWNER’S MANUAL

2
LG 無線直立式吸塵器
本說明書包含真空吸塵器安全使用和維護的重要資訊和說明。為了您的
安全，請閱讀第 4、5 和 6 頁上的所有資訊。請將本說明書置於容易觸
及的位置，以作日後參考之用。
購買產品後，首次使用前請務必將電池充飽電。
LG CORDLESS HANDY-STICK CLEANER
This manual contains important information and instructions for the
safe use and maintenance of the vaccum cleaner. Please read all of
the information on page 7, 8, 9 for your safety. Please keep this manual
in an easily accessible place for future reference.
Be sure to charge the battery fully before using the product for the rst
time after purchase.

3
目錄
Table of contents
重要安全說明 ........................................................................................................ 4~6
Important safety instructions.............................................................................. 7~9
元件與功能 ............................................................................................................... 10
Components and functions
使用方法 ............................................................................................................ 11~27
How to use
組裝真空吸塵器 .................................................................................................................. 11
Assembling vacuum cleaner
組裝充電器 ......................................................................................................................... 12
Assembling Charger
如何安裝和拆下水箱 ........................................................................................................... 13
How to mount and detach the water reservoir
如何裝上濕抹布 .................................................................................................................. 14
How to attach the wet mop
如何補水 ............................................................................................................................. 15
How to replenish water
如何使用乾抺布 .................................................................................................................. 16
How to use the dry mop
使用本產品 ................................................................................................................... 17~19
Using the Product
各種情境下的清潔指示 ................................................................................................. 20~21
Cleaning instructions for various situations
充電 .................................................................................................................................... 22
Charging
如何存放水箱 ..................................................................................................................... 23
How to store the water reservoir
如何安裝/取下水箱密封墊 .................................................................................................. 24
How to attach/detach the water reservoir gasket
清潔集塵筒 ......................................................................................................................... 25
Cleaning Dust bin
組裝集塵筒 ......................................................................................................................... 26
Assembling Dust bin
清潔吸嘴 ............................................................................................................................. 27
Cleaning Nozzle
注意事項 .................................................................................................................. 28
Troubleshooting Guide ......................................................................................... 29

4
在您使用真空吸塵器之前，請閱讀並遵守所有說明，以防止在使用真空吸塵器時出現火災、觸電、人身
傷害或財產損失等風險。本指南不包含可能出現的所有可能情況。若存在無法理解的問題，請務必聯絡
您的服務代理商或製造商。
這是安全警示符號。
此符號提醒您注意可能傷害您和其他人或可能致命的潛在危險。
所有的安全訊息均將顯示在安全警示符號和「警告」或「注意事項」文字之後。
「警告」或「注意事項」的涵義：
此符號將提醒您注意可能造成嚴重人身傷害或死亡的危險或不安全行為。
此符號將提醒您注意可能造成人身傷害或財產損壞的危險或不安全行為。
重要安全說明
注意事項
警告
警告
1. 身體、感知或心理能力較弱者或缺乏經驗及知
識的人群 (包括兒童) 不宜使用該電器，除非有
負責其安全的人員給予有關使用該電器的監督
或指引。
2. 應監督兒童，避免其把玩該電器。
3. 如電源線損壞，請務必由 LG 電子產品服務代
理商更換，以免造成危險。
4. 8 歲以下的兒童和身體、精神或感知能力有缺
陷的人，以及沒有操作經驗者和對此設電器知
識不足的人，需在監督或得到有關安全使用該
產品並理解其危險的指導後方可使用。

5
警告
重要安全說明
• 本電器專為正常室內家用而設計。本電器非供用
於任何辦公或商業應用之中。
• 僅維修技術人員才可拆卸或修改本產品。
否則可能會造成火災或觸電。
• 請勿在吸塵器及其充電座附近噴灑汽油或溶劑等
易燃材料、清潔劑或沐浴產品等表面活性劑或各
種飲料。
否則可能造成爆炸或火災。
• 請勿使電源線遭到重物擠壓、扭結或切割。
使用損壞的電源線或插頭可能會造成火災或觸
電。電源線損壞時十分危險，請由獲授權的服務
中心進行更換。
• 請勿讓水等液體進入本產品，並請勿使用本裝置
吸取液體、尖銳物品或熱灰燼。
否則可能造成火災或觸電。
若不慎使水進入本裝置，請立即關閉主機身電源
開關並拔下電源插頭，然後聯絡 LG 電子產品服
務代理商以避免發生危險。
• 請勿在吸塵器及其充電座內部或附近插入別針或
尖銳器具。
否則有觸電的風險。
• 若可偵測到氣體氣味，則請勿使用該電器。
拔下本裝置的電源插頭並進行通風，以避免可能
的危險。
否則有火災或爆炸的風險。
• 請確定本裝置插入電流超過 10amp 且未過載的
牆壁插座之中。
任何牆壁插座的過載均可導致火災和產品故障。
• 若電源線或插座出現任何鬆動或損壞，請勿使用
本電器。
否則可能造成火災或觸電。
• 請勿在吸入口或出口堵塞的情況下使用本電器。
否則會導致主機身變形或由於過熱而導致火災。
• 在取出集塵筒時。
請勿使用吸塵器否則有產品損壞或觸電受傷的風
險。
• 請勿將電源線和本產品放在加熱裝置附近。否則
可造成機身變形、故障或火災。
• 請注意，當您從電源插座上拔下插頭時，請勿用
手指觸摸插針。
否則可造成觸電。
• 請勿讓兒童或寵物把玩本產品或將本產品作為玩
具使用。
否則可造成人身傷害或本裝置損壞。
• 請勿用濕手觸摸電源插頭。
否則可能會造成觸電。
• 請勿用水清洗入口並且在弄乾元件之後立即使用
本產品。
否則可能會造成觸電和故障。
• 當您清潔本產品外部時，請確保拔出電源插頭並
且勿使用刺激性強的溶液或腐蝕性溶液進行清
洗。
否則可造成觸電與外部損壞。
• 在電器運作時，請勿將雙手置於電器的吸入口
內。使本裝置停止運作並與牆壁插座中斷連接以
避免任何人身傷害。
• 請勿用水或清潔劑清洗入口或底面的外部。僅可
使用濕抹布。
否則可能會損壞產品或造成觸電。
• 若電源線損壞，必須由製造商或其服務代理商或
類似合格人員進行更換，以避免危險發生。
• 請勿在有大量工業油煙或金屬微粒的場所使用本
產品。否則可能會造成火災或產品故障。
• 請勿在有易燃氣體洩漏或可能有易燃氣體洩漏的
場所使用本產品。
否則可能會造成火災或爆炸。
• 請勿拆卸電池。
否則有火災或爆炸的風險。
• 請勿使本產品暴露於熱或火焰下。
請勿使本產品暴露於直射的陽光。
否則有火災和爆炸的風險。
• 請勿對電池給予物理衝擊。
否則有火災和爆炸的風險。
• 僅可使用指定的充電器充電。
(產品包裝箱中包含原廠變壓器)
請勿將隨附的變壓器與其他產品搭配使用，或將
變壓器用於預期使用目的以外的其他用途。
請採用正確方式充電。
電池可能受損並且可能造成火災。
• 若電池內洩漏出任何液體，請避免接觸皮膚或眼
睛。若您碰觸到電池液，請用大量清水沖洗接觸
部位並取得醫療照護。
否則有燒傷和失明的風險。

6
注意事項
重要安全說明
• 請勿在額定電壓之外使用本吸塵器。
否則可能會造成火災和無法修復的產品損壞。
• 若產品長時間不使用，請拔下電源插頭。
• 在清潔過程中，機身上可能產生靜電。
吸塵器可能會由於靜電能而出現故障，因此請
拔出電源線然後再將其放回。
• 在清潔過程中，短襪、長襪、紙巾等較大物件
可能阻塞入口，因此在開始清潔之前請先將其
清除。
本電器僅可用於清除灰塵。
• 請勿將本裝置停在一個地方或長時間重複使用
於同一個地方。
否則使用表面可能會由於摩擦和震動而受損。
• 在本電器運作時，請勿使手腳碰觸到電器底
面。
• 請勿在未裝好集塵筒和外蓋時操作本電器。 請
務必確保在集塵筒容量達到其極限時或之前對
其進行清理。
若在集塵筒已滿情況下繼續使用本電器，則將
導致故障與過熱。
• 為避免火災或觸電的風險，在移除插頭時請務
必抓住插頭。並且在從牆壁插座上拔下插頭
時，切勿拉拽電源線。
• 若集塵筒底面附有異物，請在使用本產品之前
將其清除。
否則可能會使抽吸馬達性能減弱並且造成故障
和損壞。
• 切勿將本產品用於清除有毒氣體。
否則本產品可能故障並且無法去除有毒氣體。
• 請在平坦區域使用或放置本裝置，並且勿向本
裝置施力。否則可能會造成火災或產品故障。
• 請以正確方式處置本產品。
否則有火災和爆炸的風險。
• 當水箱安裝於主機身時，請勿將吸塵器直立擺
放於地板上。
• 當水箱安裝於主機身時，不可將吸塵器置於充
電裝置上。
• 水箱請勿存放在 0 ℃ 或更低的溫度下。
• 所有電氣和電子產品均應在政府或當地機構規
定的指定收集廠從市政垃圾流中分開處理。
• 更多有關處理您的舊電器的資訊，請連絡您市
政府辦公室、垃圾處理服務或您購買該產品的
商店。
• 所有電池/蓄電池均應經由政府或當地主管機
關規定的指定收集設施處置而與市政垃圾流分
開。
• 若要瞭解更多有關處置您舊電池/蓄電池的詳細
資訊，請聯絡您的市政府辦公室、垃圾處置服
務或您購買該產品的商店。

7
Read and follow all instructions before using your vacuum cleaner to prevent the risk of fire, electrical shock, personal
injury, or damage when using the vacuum cleaner. This guide does not cover all possible conditions that may occur.
Always contact your service agent or manufacturer about problems that you do not understand.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “WARNING” or “CAUTION.”
These words mean:
This symbol will alert you to hazards or unsafe practices which could cause serious
bodily harm or death.
This symbol will alert you to hazards or unsafe practices which could cause bodily
injury or property damage.
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
WARNING
WARNING
1. This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
2. Children should be supervised to ensure that they
do not play with the appliance.
3. If the supply cord is damaged, it must be replaced
by LG Electronics Service Agent in order to avoid a
hazard.
4. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning use of the appliance in
a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children
without supervision.

8
WARNING
IMPORTANT SAFETY INSTRUCTIONS
• This appliance is designed for normal indoor
domestic use only. It is not to be used for any
office or commercial application.
• No one other than a repair technician shall
disassemble or modify the product.
It may cause fire or electrical shock.
• Do not spray combustible materials such as
gasoline or solvents, or surfactants such as
detergents or bathing goods, or drinks near the
cleaner and its charging stand.
It can cause an explosion or fire.
• Do not allow the power cord to be crushed,
kinked or cut by heavy objects.
Using a damaged cord or plug could cause fire or
electrical shock. When the power cord is damaged,
it is dangerous, so please have the cord replaced by
an authorised service center.
• Do not let liquid such as water enter the product,
and do not use the unit to pick up liquids, sharp
pointy objects, or hot embers.
It causes fire or electrical shock.
If water accidently enters the unit, immediately turn
off the power switch of the main body, pull out the
power plug, and contact LG Electronics Service
Agent to avoid hazard.
• Do not insert pins or sharp pointy utensils into or
around the cleaner or its charging stand.
There is a risk of electrical shock.
• Do not use the appliance if gas odors can be
detected. Unplug the unit and provide ventilation
to avoid possible dangers.
There is a risk of fire or explosion.
• Make sure that the unit is plugged into a wall
socket over 10amp and not overloaded.
Overloading of any wall socket can cause fires and
product malfunction.
• Do not use the appliance if the power cord or
socket is in any way loose or damaged.
It can cause fire or electrical shock.
• Do not operate the appliance with the suction
inlet or outlet which are blocked.
It causes deformation of main body or fire by
overheating.
• Do not operate the cleaner while dust bin is taken
out.
There is a risk of product damage or electrical shock
injury.
• Do not place power cord and the product near
heating devices.
It can cause deformation of main body, malfunction,
or fire.
• Be careful that your fingers do not touch the pins
when you pull out the plug from the mains outlet.
It can cause electrical shock.
• Do not allow children or pets to play with the
product or use the product as a toy.
It can cause personal injury and damage to the unit.
• Do not handle the plug with wet hands.
It may cause electrical shock.
• Do not clean the inlet with water and then use
immediately without sufficiently drying the
components first.
It may cause electrical shock and malfunction.
• When you clean the exterior, make sure to pull
out the power plug, and do not wash with harsh
or abrasive solutions.
It can cause electrical shock and exterior damage.
• Do not place hands into the intake while the
appliance is operating. Allow the unit to stop
operating and disconnect from the wall socket to
avoid any personal injury.
• Do not wash the exterior of inlet or bottom
surface with water or detergent. Use only a damp
cleaning cloth.
It may damage product or cause electrical shock.
• If the supply cord is damaged, it must be
replaced by the manufacturer, its authorised
service agent or similarly qualified persons in
order to avoid a hazard.
• Do not use the product at a place subject to lots
of industrial oil fumes or metal particulates.
Doing so can cause fire or product failure.
• Do not use the product at a place subject to
leakage or probable leakage of combustible
gases.
It may result in fire or explosion.
• Do not disassemble the battery.
There is a risk of fire or electric shock.
• Do not expose product to heat or fire.
Do not expose product direct sunlight.
There is a risk of fire and explosion.
• Do not physically impact the battery.
There is a risk of fire and explosion.
• Charge only as specified charger.
(Genuine adapter included in the product box)
Do not use the provided adapter with any other
products or for any other purpose than its
intended use.
Please charge the right way.
The battery may be damaged and may cause a fire.
• If any liquid leaks from the batteries, avoid
contact with the skin or eyes.
If you touched the liquid, wash contact area with
plenty of water and get medical attention.
There is a risk of burns and blindness.

9
CAUTION
IMPORTANT SAFETY INSTRUCTIONS
• Do not use this cleaner on anything other than
rated voltage.
It may cause fire and unrepairable product
damage.
• If the product is not in use for a long period of
time, pull out the power plug.
• Static Electricity may be generated at main
body during the cleaning.
Cleaner may malfunction due to electrostatic
energy, so pull out the power cord and put it back
in again.
• Big objects such as socks, stocking, tissues,
etc., may block the inlet during the cleaning,
so please remove them before starting the
cleaning.
This appliance must be used to remove dust only.
• Do not stop on one spot or use it on the same
spot repeatedly for a long time.
The surface may be damaged by the friction and
vibration.
• Do not touch the bottom surface with hand or
foot while the appliance is in operation.
• Do not operate the appliance without the dust
bin and its covers in place. Always ensure the
dust bin is cleaned when it reaches its limit or
beforehand.
If it is used continuously while dust bin is full, it
will cause malfunction and overheating.
• To avoid the risk of fire or electric shock,
always grip it from the plug when removing.
And never pull on the power cord when
removing it from the wall socket.
• If a foreign object is attached to the bottom
surface of dust bin, remove it before using the
product.
It could compromise the suction motor and cause
malfunction and damage.
• Never use the product for removing toxic
gases.
The product may fail, and toxic gases will not be
removed.
• Use or place the unit on a level surface and
area and do not apply undue force to the unit
when using it.
Doing so can cause fire or product failure.
• If disposing the unit, it must be done correctly
as it contains battery cells that can cause fire
or explode if not disposed of correctly.
• Do not leave the cleaner standing on the floor
with the water reservoir mounted on the main
body.
• The cleaner cannot be placed in the charging
unit with the water reservoir mounted on the
main body.
• Do not store the water reservoir at
temperatures of 0 ˚C or lower.
• All electrical and electronic products should
be disposed of separately from the municipal
waste stream via designated collection
facilities appointed by the government or the
local authorities.
• For more detailed information about disposal
of your old appliance, please contact your
city office, waste disposal service or the shop
where you purchased the product.
• All batteries/accumulators should be disposed
separately from the municipal waste stream
via designated collection facilities appointed
by the government or the local authorities.
• For more detailed information about disposal
of Your old batteries/accumulators, please
contact Your city office, waste disposal
service or the shop where You purchased the
product.

10
元件：充電器、把手固定螺絲、
備用電池、水箱、濕抹布 (配有側面抹布)、
乾抹布 (也可作為濕抹布使用)
Components: Charger, Handle holding
screw, Spare battery, Water reservoir,
Wet mop (equipped with side mops),
Dry mop (can also be used as wet mop)
桿身電源按鈕
Stick power button
速度按鈕
Speed button
主機身
Main body
內建刷子
Built-in brush
充電座
Charging stand
充電指示燈
Charging indicator
手攜部釋放按鈕
Handy release buttons
手指掛鉤
- 請將手指放在此處，
增加使用的舒適性。
Finger hanger
- Place your finger here
for comfortable use.
手攜部電源按鈕
Handy power button
電池指示燈
Battery indicator
集塵筒釋放按鈕
Dust bin release button
抗糾結刷子
Anti-tangle brush
LED 照明
LED lighting
元件與功能
Components and functions

11
使用方法 組裝真空吸塵器
How to use Assembling vacuum cleaner
1 2
上桿部
Upper body part
下桿部
Lower body part
➊將手攜吸塵器裝到桿身
Assembling the Upper and Lower body parts
依照圖中所示的箭頭方向將上桿部連接到下桿部
(在組裝本產品時，請確定勿讓您的手指卡住)。
Attach upper body part to the lower body part in
arrow direction as shown in the figure.
(When assembling the product, make sure not to get
your finger stuck.)
➋鎖上固定螺絲
Fasten the fixing screw
本產品後側有一個固定孔。
使用本產品隨附的固定螺絲來組裝上與
下桿部。
There is a fixing hole on the rear side
the product.
Use the fixing screw provided with the
product to assemble and secure upper
and lower parts.

12
使用方法 組裝充電器
How to use Assembling Charger
將充電座的上部插入底座直到聽見「咔嗒」聲。
Insert the upper part of the charging stand to
the base until you hear a “click” sound.

13
咔嗒
Click
使用方法 如何安裝和拆下水箱
How to use How to mount and detach the water reservoir
咔嗒
Click
1 2
➊如何安裝水箱
How to mount the water reservoir
將水箱放在地板上，然後將吸塵器吸嘴插入
水箱中央的溝槽，直到您聽到「咔嗒」一聲
為止。
Place the water reservoir on the floor and
insert the nozzle of the cleaner into the
groove at the center of the reservoir until you
hear a “click” sound.
➋如何拆下水箱
How to detach the water reservoir
將一隻腳放在水箱上，把吸塵器往前推。
Placing one foot on the water reservoir, push
the cleaner forward.
警告
當水箱安裝於主機身時，請勿將吸塵器直立擺放於地板上。
水可能會流出並使地板受損。
WARNING
Do not leave the cleaner standing on the floor with the water
reservoir mounted on the main body.
Water may flow out and cause damage to the floor.

14
使用方法 如何裝上濕抹布
How to use How to attach the wet mop
① ② ③
① 抹布在使用前請先沾濕。
② 抹布在使用前務必充分扭乾，以去除多餘水分。
③ 請將濕抹布有魔鬼沾那一面朝上，然後裝到水箱上。
①Please wet the mop prior to use.
②Be sure to squeeze the wet mop sufficiently before use to
remove excess moisture.
③With the Velcro side of the wet mop facing up, attach to the
water reservoir.
使用提示
• 抹布若沒有先沾濕就裝上水箱，可能會導致清潔效果不佳。
若要使用乾抹布，請先清空水箱。
Helpful tip
• To maximize cleaning performance, please wet the mop
before using.
To use the dry mop, please empty the water reservoir.

15
使用方法 如何補水
How to use How to replenish water
①
②
③
① 請如圖例所示，打開水箱的蓋子。
② 如圖例所示，將水補到側面標示的「Max」線。
③ 補完水後，請關緊水箱的蓋子。
①Open the cap on the water reservoir as shown in the illustration.
②As shown in the illustration, fill the water reservoir up to the
“Max” line marked on the side.
③After filling with water, securely close the cap on the water
reservoir.
警告
建議您先裝上抺布，再於水箱中補水或移動吸塵器。
若未先裝上抺布，就移動吸塵器或於水箱中補水，可能會導
致水從注水口漏出。
WARNING
It is recommended that you attach the mop prior to filling the
water reservoir or moving the cleaner around.
Moving the cleaner or filling the water reservoir before
attaching the mop may cause water to leak from the spout.

16
使用方法 如何使用乾抺布
How to use How to use the dry mop
乾抺布把手
Dry mop handle
使用前裝到水箱上
When attaching to the water reservoir prior to use
① 請將乾抹布有魔鬼沾那一面朝上，然後裝到水箱上。
② 請先將水箱裝到主機身再行使用。
(若要使用乾抹布，請先清空水箱。)
①With the Velcro side of the dry mop facing up, attach to
the water reservoir.
②Please mount the water reservoir on the main body prior
to use.
(When using the dry mop, please empty the water
reservoir.)
徒手使用抺布
When using as a hand mop
請將手放在乾抺布背面的把手上。
Place your hand on the handle
provided on the back of the dry mop.
① ②
使用提示
• 乾抺布可用於擦拭水、灑出的
飲料或灰塵。
Helpful tip
• The dry mop may be used
to wipe off water or spilled
beverages or for dusting.

17
使用方法 使用本產品
How to use Using the Product
購買真空吸塵器後, 請在完成充電後使用.
After purchasing the Vacuum Cleaner, please use it after charging fully.
桿身電源按鈕 / Handle power button
手持式電源按鈕
Vacuum power button
動力切換按鈕
Speed button
(High or Low)
電池指示燈
Battery indicator
溝槽
Groove
請確定組裝零件牢固固定。
Make sure the assembly
part has docked correctly.
凸部
Projection
電池指示燈
Battery indicator
按電源按鈕以啟動本產品。
• 在使用桿式吸塵器時，請用速度按鈕來調整吸塵器
速度。
• 在使用直立式吸塵器時，請用動力切換按鈕來調整
吸塵器強弱。
Press the power button to turn on the product.
• When you use the vacuum cleaner, select the
motor speed with the speed button.
• If the product doesn’t work, check the battery
indicator for a visual display.
電池指示燈會顯示剩餘電量。
• 完全充電的電池在高速時可持續 20 分鐘，而在中速時可持續 30 分鐘。
• 當電池電量低時，電池指示燈會顯示一個閃爍燈，接著電源很快就會關閉。
Battery indicator shows remaining charge.
• A fully charged battery lasts for 20 minutes at the high speed and for
30 minutes at the normal speed (depending on the floor type).
• When the battery power level is low, the battery indicator shows one
blinking light, and then the power turns off soon after.
將主機身後側底部如圖片上所示置於充
電器上。
請確定主機身牢固固定。
Place the rear bottom of the main body
on the charger as shown on the figure.
Make sure the assembly part has
docked correctly.
警告
不能進行液體吸取。
液體吸取可造成故障。
WARNING
Do not use this cleaner to vacuum liquids.
Vacuuming liquids will cause the unit to malfunction.

18
使用方法 使用本產品
How to use Using the Product
抗糾結刷子適合用於清潔短毛地毯或正常地板表面。
① 不建議將吸塵器使用於長毛地毯上。
② 若將吸塵器長時間使用於長毛毯上，則可能會造成抗糾結刷子停止運作。
–當抗糾結刷子因為馬達過載而停止運作時，請將真空吸塵器關閉然後開啟以讓其再
度運作。
③ 當您在使用吸塵器期間必須離開現場時，請將真空吸塵器置於地板或充電座上。
–當本產品翻倒時，可能會傷及兒童或寵物。
The anti-tangle brush is ideal for cleaning short-furred carpet or a normal timber floor
surface.
①It is not recommended to vacuum a carpet with long fur.
②If you vacuum a long piled carpet, it may cause the anti-tangle brush to stop rotating.
– When the anti-tangle brush stops due to a motor overload, turn the vacuum cleaner
off and on again to allow it to work again.
③After you have finished using the vacuum, place the vacuum cleaner on the floor or on
the charging stand.
– If the product falls over due to improper placement when not in use, it may damage
the unit or harm children or pets.
針對抗糾結刷子馬達過載保護的馬達過載保護是為了保護兒童或者在刷子跟紗線或布
料糾結時自動停止馬達。
The Anti-hair brush motor is fitted with overload protection which stops the motor from
rotating, to help prevent accidental injury or damage to tangled threads and fabrics.

19
使用方法 使用本產品
How to use Using the Product
為了使用者方便起見，內建刷子是內建在手持式吸塵器上。
在單獨使用手持式吸塵器時，請參閱下列指示。
For the convenience of the user,a built-in brush is attached to the hand held cleaner.
When using the hand held cleaner alone, refer to the following instructions.
使用內建刷子
Using built-in brush
依箭頭方向拉出位於真空吸塵器底部的內建刷子。
依箭頭方向移動刷子直到其鉤住並固定。
Pull out the built-in brush until it secures into place at
the bottom of the vacuum cleaner in the arrow direction.
Move the brush in the arrow direction until it is locked
into place.
重新裝回內建刷子。
Retracting the built-in brush
依箭頭方向移動內建刷子的刷子。
依箭頭方向將內建刷子放回外殼內。
Firmly slide the built-in brush in the
arrow direction.
Fold the built-in brush body back
into the enclosure in the arrow
direction.
