OWNER'S MANUAL
CHIMNEY HOOD
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
HCEZ2415S2
MFL62060365
Rev.00_112322
www.lg.com
Copyright © 2022 LG Electronics Inc. All Rights Reserved.
global_main.book.book Page 1 Wednesday, November 23, 2022 7:44 AM

TABLE OF CONTENTS
This manual may contain images or
content that may be different from the
model you purchased.
This manual is subject to revision by the
manufacturer.
SAFETY INSTRUCTIONS
WARNING............................................................................................................3
CAUTION .............................................................................................................6
CARING FOR THE ENVIRONMENT....................................................................8
INSTALLATION
Product Overview...............................................................................................9
Installation ..........................................................................................................9
OPERATION
Using the Appliance.........................................................................................12
MAINTENANCE
Cleaning and Replacing...................................................................................13
TROUBLESHOOTING
Before Calling for Service................................................................................15
global_main.book.book Page 2 Wednesday, November 23, 2022 7:44 AM

3
SAFETY INSTRUCTIONS
ENGLISH
SAFETY INSTRUCTIONS
WARNING
WARNING
• To reduce the risk of explosion, fire, death, electric shock, injury or
scalding to persons when using this product, follow basic
precautions, including the following:
Installation
• The manufacturer will not be held liable for any damages resulting
from incorrect or improper installation.
• The minimum safety distance between the cooker top and the
extractor hood is 650 mm (some models can be installed at a lower
height, refer to the paragraphs on working dimensions and
installation).
• Check that the mains voltage corresponds to that indicated on the
rating plate fixed to the inside of the hood.
• For Class I appliances, check that the domestic power supply
guarantees adequate earthing.
• Connect the extractor to the exhaust flue through a pipe of minimum
diameter 120 mm. The route of the flue must be as short as possible.
• Do not connect the extractor hood to exhaust ducts carrying
combustion flumes (boilers, fireplaces, etc.).
• If the extractor is used in conjunction with non-electrical appliances
(e.g. gas burning appliances), a sufficient degree of aeration must be
guaranteed in the room in order to prevent the backflow of exhaust
gas. The kitchen must have an opening communicating directly with
the open air in order to guarantee the entry of clean air. When the
cooker hood is used in conjunction with appliances supplied with
energy other than electric, the negative pressure in the room must
not exceed 0.04 mbar to prevent fumes being drawn back into the
room by the cooker hood.
global_main.book.book Page 3 Wednesday, November 23, 2022 7:44 AM

4
SAFETY INSTRUCTIONS
• If the instructions for installation for the gas hob specify a greater
distance specified above, this has to be taken into account.
Regulations concerning the discharge of air have to be fulfilled.
Operation
• The extractor hood has been designed exclusively for domestic use to
eliminate kitchen smells.
• Never use the hood for purposes other than for which it has been
designed.
• Never leave high naked flames under the hood when it is in
operation.
• Adjust the flame intensity to direct it onto the bottom of the pan only,
making sure that it does not engulf the sides.
• Deep fat fryers must be continuously monitored during use:
overheated oil can burst into flames.
• Do not flame under the hood; risk of fire.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
• Children should be supervised to ensure that they do not play with
the appliance.
• There shall be adequate ventilation of the room when the hood is
used at the same time as appliances burning gas or other fuels.
• The air must not be discharged into a flue that is used for exhausting
fumes from appliances burning gas or other fuels.
• Accessible parts may become hot when used with cooking
appliances. Never touch hot parts. Keep children at a safe distance.
• Grease deposits in the grease filter may catch fire. Never work with
naked flames close to the appliance (e.g. flambéing). Do not install
the appliance near a heatproducing appliance for solid fuel (e.g.
wood or coal) unless a closed, nonremovable cover is available. There
must be no flying sparks.
global_main.book.book Page 4 Wednesday, November 23, 2022 7:44 AM

5
SAFETY INSTRUCTIONS
ENGLISH
• Hot oil and fat can ignite very quickly. Never leave hot fat or oil
unattended. Never use water to put out burning oil or fat. Switch off
the hotplate. Extinguish flames carefully using a lid, fire blanket or
something similar.
• When gas burners are in operation without any cookware placed on
them, they can build up a lot of heat. A ventilation appliance installed
above the cooker may become damaged or catch fire. Only operate
the gas burners with cookware on them.
• Operating several gas burners at the same time gives rise to a great
deal of heat. A ventilation appliance installed above the cooker may
become damaged or catch fire. Never operate two gas burners
simultaneously on the highest flame for longer than 15 minutes. One
large burner of more than 5 kW (wok) is equivalent to the power of
two gas burners.
• Components inside the appliance may have sharp edges. Wear
protective gloves.
• Items placed on the appliance may fall down. Do not place any
objects on the appliance.
• The light emitted by LED lights is very dazzling, and can damage the
eyes (risk group 1). Do not look directly into the switched on LED
lights for longer than 100 seconds.
• The appliance is not intended for use by young children or infirm
persons without supervisions.
• Young children should be supervised to ensure they do not play with
the appliance.
• Plug the power cord to socket outlet with earthing continuity
terminal.
• Do not use open flame, or allow oil to go beneath the appliance.
• Use the unit according to the instructions to avoid any fire hazard.
• The exhaust air must not be introduced into a smoke flue or chimney
that is used for exhausting fumes from appliances burning gas.
• Follow the local laws applicable for external air evacuation.
global_main.book.book Page 5 Wednesday, November 23, 2022 7:44 AM

6
SAFETY INSTRUCTIONS
Maintenance
• In the event of damage to the power cable, it must be replaced by the
manufacturer or by the technical service department, in order to
prevent any risks.
• Cleaning and user maintenance shall not be made by children
without supervision.
• There is a fire risk if cleaning is not carried out in accordance with the
instructions.
• Switch off or unplug the appliance from the mains supply before
carrying out any maintenance work.
• Clean and/or replace the filters after the specified lime period (Fire
hazard).
• Fatty deposits in the grease filter may catch fire. Regularly clean the
grease filter. Never operate the appliance without a grease filter.
• Prior to any maintenance, cleaning operation, ensure the power is cut
off.
• If the supply cord is damaged, it must be replaced by the
manufacturer, service agent or similarly qualified person in order to
avoid a hazard. The replaced power cord should be provided by
manufacturer or seller.
• If the plug or cord is damaged, contact an LG Electronics Customer
Information Centre.
• There is a fire risk if cleaning is not carried out in accordance with the
instruction.
• In case of damaged connecting wire, refer to the manufacturer, after-
sale service personnel or other qualified technicians.
CAUTION
CAUTION
• To reduce the risk of injury to persons, malfunction, or damage to the
product or property when using the appliance, follow basic safety
precautions, including the following:
global_main.book.book Page 6 Wednesday, November 23, 2022 7:44 AM

7
SAFETY INSTRUCTIONS
ENGLISH
Operation
• The filter is made of high density aluminum.
• The appliance uses 4 hob elements at most.
• The cooker hood is for home use only, not suitable for barbecue,
roast shop and other commercial purposes.
• Keep the kitchen room ventilated.
Maintenance
• Do not use corrosive detergent for cleaning. The proper function of
the unit is conditioned by the regularity of the maintenance.
• To protect the main body from corrosive of the long time
accumulation of dirt, the cooker hood should be cleaned with hot
water with non-corrosive detergent every two months.
• Clean the hood using a damp cloth and a neutral liquid detergent.
• The cooker hood and its filter should be cleaned regularly according
to the instruction.
• If there is any fault occurred with the appliance, contact an LG
Electronics Customer Information Centre.
• Do not repair or replace any part of the appliance unless specifically
recommended in the manual. All other servicing should be done by a
qualified technician.
global_main.book.book Page 7 Wednesday, November 23, 2022 7:44 AM

8
SAFETY INSTRUCTIONS
CARING FOR THE ENVIRONMENT
Disposal of Your Old Appliance
• This crossed-out wheeled bin symbol indicates that waste
electrical and electronic products (WEEE) should be
disposed of separately from the municipal waste stream.
• Old electrical products can contain hazardous substances
so correct disposal of your old appliance will help prevent
potential negative consequences for the environment and
human health. Your old appliance may contain reusable
parts that could be used to repair other products, and
other valuable materials that can be recycled to conserve
limited resources.
• You can take your appliance either to the shop where you
purchased the product, or contact your local government
waste office for details of your nearest authorised WEEE
collection point. For the most up to date information for
your country please see www.lg.com/global/recycling.
global_main.book.book Page 8 Wednesday, November 23, 2022 7:44 AM

9
INSTALLATION
ENGLISH
INSTALLATION
Product Overview
Parts
a Control Panel
b Light
c Hood Body
d Filter
Accessories
a Hood Fixing Bracket (1 ea)
b Chimney Fixing Brackets (2 ea)
c Screws (Φ4.2 mm x 9.5 mm, 6 ea)
d Screws (Φ5 mm x 50 mm, 7 ea)
e Wall Plugs (7 ea)
f Exhaust Pipe (1 ea)
g Upper Decorative Chimney (1 ea)
h Lower Decorative Chimney (1 ea)
NOTE
• Type and quantity of accessories is subject to
actual demand.
Technical Specifications
The parameters are tested under conditions of 230
V 50 Hz when the voltage is 220-240 V~ 50/60 Hz.
Installation
Dimensions and Clearances
• It cannot share the same air ventilation tube with
other appliances such as gas tube, warmer tube,
and hot wind tube. Doing so may cause hazards
such as reduced pressure, combustion
impairment, or harmful gases being drawn back.
• The bending of the ventilation tube should be
2 120°, parallel or above the start point/should
be connected to the external wall.
Hood HCEZ2415S2
Voltage 220 - 240 V ~ 50/60 Hz
Rated Power 253 W
Lighting Power 2 x 1.5 W
Motor Power 250 W
Diameter of Air Tube 150 mm
Air Flow 630 m
3
/h (High), 800
m
3
/h (Booster)
global_main.book.book Page 9 Wednesday, November 23, 2022 7:44 AM

10
INSTALLATION
• Make sure the installation plate is placed
horizontally to avoid grease collection at one
end.
a Right b Wrong
• After installation, make sure that the plug can be
pulled out if necessary.
• The cooker hood should be placed 650-750 mm
up from the cooking plate for safety and
effective operation.
• There must be adequate ventilation of the room
when the cooker hood is working.
Installing the Appliance
1 Remove the protective film from the decorative
chimney and hood body.
2 Fix the hood fixing bracket c and the chimney
fixing bracket
a with the wall plugs b and
screws
d to the wall. Install 2 wall plugs b on
the wall for step 5.
b Wall Plugs (7 ea)
d Screws (Φ5 mm x 50 mm, 5 ea)
3 Fix the exhaust pipe a and lower decorative
chimney
c on the main body, connect the
chimney fixing bracket
b and lower decorative
chimney.
d Screws (Φ4.2 mm x 9.5 mm, 4 ea)
120 mm
120 mm
160 mm
50-350 mm
119 mm299 mm
650-750 mm
global_main.book.book Page 10 Wednesday, November 23, 2022 7:44 AM

11
INSTALLATION
ENGLISH
4 Hang the hood on the hood fixing bracket.
5 After connecting the exhaust pipe securely, fix
the chimney fixing bracket to prevent the hood
from accidentally sliding off the hood fixing
bracket.
a Screws (Φ5 mm x 50 mm, 2 ea)
6 Fix the upper decorative chimney.
a Screws (Φ4.2 mm x 9.5 mm, 2 ea)
Connections
Ducted Version Air Exhaust System
When installing the ducted version, connect the
hood to the chimney using either a flexible or rigid
pipe Φ150 mm, the choice of which is left to the
installer.
• Fix the exhaust pipe in position using sufficient
pipe clamps (not supplied).
global_main.book.book Page 11 Wednesday, November 23, 2022 7:44 AM

12
OPERATION
OPERATION
Using the Appliance
Control Panel
The appliance does not need to be switched on and
off separately. After plug-in, the hood will enter
standby state. When you press the button, a beep
will heard, the indicator light on the button will be
on/off.
a Light
The light can be switched on and off independently
of the ventilation system.
• Press the
Light button to turn on the light.
• If you want to turn off the light, press the
Light
button again.
b Speed Selection
Depending on the setting of each button, the hood
will operate in one of four modes: low speed mode,
middle speed mode, high speed mode, and boost
speed mode.
• Press the button to turn on the hood at the
desired speed.
• If you want to turn off the motor, press the
button again.
• If you want to change the speed mode, just press
the button of the desired speed.
•
c Low Speed
• d Middle Speed
• e High Speed
f Boost
This hood has a booster function (boost speed
mode). To activate the booster, press
Boost button
and it will increase speed for 8 minutes, before
slowing down again.
We recommend that you switch on the hood for a
few minutes before you start cooking, and then
leave it running for approximately 8 minutes
afterwards to ensure that all odours are extracted.
WARNING
• Accessible parts may become hot when used
with cooking appliances. To illuminate the
cooking area underneath the hood, push the
Light button into the “on” position. To switch off,
press the button again to return to the “off”
position.
• This appliance is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
• To operate the hood, press the button for the
required speed - select: low speed
c , middle
speed
d , high speed e or boost f . The
indicator light will illuminate to show when the
fan is operating. To switch off, press the button
of the active mode function.
global_main.book.book Page 12 Wednesday, November 23, 2022 7:44 AM

13
MAINTENANCE
ENGLISH
MAINTENANCE
Cleaning and Replacing
Cleaning
Cleaning the Filters
1 Remove the filters.
2 Put the filters into a dishwasher with
detergent, set the temperature below 60
degrees.
3 Do not use abrasive detergent for it will
damage the hood.
4 Make sure that the hood is shut off before
cleaning.
The pictures in this manual are for reference
only and may vary depending on the model.
NOTE
• Steam cleaner is not to be used.
Replacing
Replacing the Light
LED light
1 Switch off the extractor hood and isolate the
extractor hood by pulling out the mains plug or
switching off at the fuse.
2 Remove the grease filter.
3 Remove the light by levering its fitting from the
hood body (this may require pressure or force
to be applied).
4 Disconnect the connection to the light.
5 Replace the light with a new one of the same
type, and make sure that you connect the light
to the light cable correctly..
6 Reinstall the light back into the hood body.
Round/Diameter 70 mm
Max. Power 1.5 W
Voltage DC 12 V
Lamp Cap -
ILCOS D code DSR-1.5-S-70
global_main.book.book Page 13 Wednesday, November 23, 2022 7:44 AM

14
MAINTENANCE
WARNING
• Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of
electric shock.
global_main.book.book Page 14 Wednesday, November 23, 2022 7:44 AM

15
TROUBLESHOOTING
ENGLISH
TROUBLESHOOTING
Before Calling for Service
Repairs should be performed by a licensed technician only. Improper repair may result in considerable
danger to you and others. However, some minor problems can be resolved as in the table below:
If a problem is not solved, please contact an LG Electronics Customer Information Centre.
Parts and Features
The manufacturer will decline all responsibility if the recommendations and instructions regarding
installation, maintenance and use are not observed and respected when using the cooker hood.
Symptoms Possible Cause & Solution
Light on, but motor
does not work
The blades are blocked.
• Check that the blades are free to rotate.
The internal wiring of motor is cut off/disconnected. An unpleasant
smell may be produced.
• Call for service.
Both light and motor
do not work
Apart from the possibilities mentioned above, check the following:
Light is damaged.
• Call for service.
Power cord loose.
• Connect the cord as per the electrical diagram.
Oil leakage Outlet and the air ventilation entrance are not tightly sealed.
• Take down the outlet and seal with appropriate sealant.
Leakage from the connection of the U-shaped section and cover.
• Take the U-shaped section down and seal with soap or paint.
Vibration The blade, if damaged, can cause vibration.
• Call for service.
The motor is not tightly fastened.
• Fasten the motor tightly.
The cooker hood is not securely fixed.
• Fixed the cooker hood securely.
Insufficient suction The distance between the cooker hood and the cooker top is too great.
• Readjust the distance.
Too much ventilation from open doors or windows.
• Choose a new place to install the appliance or close some doors / windows.
global_main.book.book Page 15 Wednesday, November 23, 2022 7:44 AM

16
TROUBLESHOOTING
Electrical Diagram
The appliance is not
level
The fixing screws are not tight enough.
• Tighten the fixing screws and ensure that the appliance is horizontal.
The hanging screws are not tight enough.
• Tighten the hanging screws and ensure that the appliance is horizontal.
Symptoms Possible Cause & Solution
L
N
E
M
AC INPUT
POWER BOARD
CONTROL SWITCH
Capacitor
Light
White
Brown (S)
Black (H)
Blue (M)
Orange (L)
global_main.book.book Page 16 Wednesday, November 23, 2022 7:44 AM

ﺓﺭﻛﺫﻣ
ar-ae_main.book.book Page 15 Wednesday, November 23, 2022 8:38 AM

ﺓﺭﻛﺫﻣ
ar-ae_main.book.book Page 15 Wednesday, November 23, 2022 8:38 AM

ﺓﺭﻛﺫﻣ
ar-ae_main.book.book Page 14 Wednesday, November 23, 2022 8:38 AM

13
ﺎﻬﺣﻼﺻﺇﻭ ﻝﺎﻁﻋﻷﺍ ﻑﺎﺷﻛﺗﺳﺍ
ﺍﻟﻌﺭﺑﻳﺔ
ﻲﺑﺭﻬﻛﻟﺍ ﻁﻁﺧﻣﻟﺍ
ٍﻭﺗﺳﻣ ﺭﻳﻏ ﺯﺎﻬﺟﻟﺍ .ﺍًﺩﻳﺟ ﻖﻳﻠﻌﺗﻟﺍ ﺭﻳﻣﺎﺳﻣ ﻁﺑﺭ ﻡﺗﻳ ﻡﻟ
•.ﻲﻘﻓﺃ ﻊﺿﻭ ﻲﻓ ﺯﺎﻬﺟﻟﺍ ﻥﺃ ﺩﻛﺄﺗﻭ ،ﻖﻳﻠﻌﺗﻟﺍ ﺭﻳﻣﺎﺳﻣ ﻁﺑﺭ ﻡﺎﻛﺣﺈﺑ ﻡﻗ
ﺽﺍﺭﻋﻷﺍﻝﺣﻟﺍﻭ ﻝﻣﺗﺣﻣﻟﺍ ﺏﺑﺳﻟﺍ
L
N
E
M
AC INPUT
POWER BOARD
CONTROL SWITCH
Capacitor
Light
White
Brown (S)
Black (H)
Blue (M)
Orange (L)
ar-ae_main.book.book Page 13 Wednesday, November 23, 2022 8:38 AM
