LGMG SS0407E User manual

Maintenance Manual
SS0407E/AS0607E/AS0812E/AS1012E/
AS1212E/AS1413E
Mobile Elevating Work Platform
△
!Warning
Before operation and maintenance, the
drivers and service personnel shall
always read and thoroughly understand
all information in this manual. Failure to
do so may result in, fatal accidents or
personal injury.
This manual must be kept with this
machine at all times.
LINGONG GROUP JINAN HEAVY MACHINERY CO., LTD.

Mobile Elevating Work Platform
Maintenance Manual
880*1230 mm sixteen format 8 printed sheet
Fourth edition and printed for the first time in December 2021
LINGONG GROUP JINAN HEAVY MACHINERY CO.,LTD
Add: F12,Building 3 LushangGuoao Plaza, 9777 Jingshi Road,Lixia District, Jinan,
Shandong, 250000,China
Tel: [phone] Technical service: 86-0531-67605017
Fax: [phone] Accessory sales: 86-0531-67605016
Web: www.lgmg.com.cn

Maintenance Manual of Elevating Work Platform
I
Contents
Forewords ............................................... II
Safety precaution ........................................ III
Chapter 1 Maintenance..................................... 1
Chapter 2 Appendix ....................................... 29

Maintenance Manual of Elevating Work Platform
II
Forewords
Thanks for purchasing and using the elevating work platform of Lingong Group Jinan Heavy Machinery Co.,
Ltd. The mechanism, drive, operation, maintenance, adjustment, technical parameter, repair adjustment data
of elevating work platform are specified in this manual for safety guidance and correct use & maintenance of
this machine.
How to achieve the best benefit with this machine is our common pursue, which is greatly depending on the
acknowledge and maintenance of your machine. We sincerely wish you can go through this manual before
the first start, operation, repair and maintenance of this machine and wish you are familiar with the operation
and maintenance specified.
The correct illustration and instructions are provided in this manual at the moment of publication. However,
the structure and performance of our products are continuously improved and completed. Changes of related
design, operation and maintenance instruction will be made without notice. Thanks for understanding. For any
doubts of the latest machine information and the manual, please consult us.
This manual is applicable to the elevating work platform. The user shall make the maintenance to the machine
strictly according to the interval specified in the maintenance schedule.
Please keep the manual at the specified location for convenience of reference at any time. This manual is one
part of this machine. When the ownership or use right of this machine is transferred, this manual shall be
transferred with this machine. For any loss, damage or identification problem, please replace the manual in
time.
Lingong Group Jinan Heavy Machinery Co., Ltd refers the copyright of this manual. The reproduction or copy
of this manual is not allowed without the written approval of the company.
△
!Warning
Only the staff receiving the professional training and having corresponding
qualifications are allowed to operate, repair and maintain this machine.
The incorrect operation, maintenance and repair are very dangerous and can
cause the personal injury and death.
Before the operation or maintenance, the operator shall carefully go through this
manual. Do not make any operation, maintenance and repair on this machine
before going through and comprehending this manual.
The user shall load the platform strictly according to the rated one and shall be
responsible for consequences caused due to overload or any modification
without permission.
The operation regulations and preventions in this manual are only applicable for
the specified use of this machine. For any un-forbidden operation beyond the
regulation, be sure to ensure such operation will not cause any personal injury.

Maintenance Manual of Elevating Work Platform
III
Safety precaution
The operator shall understand and follow the existing safety regulations of the state and the local
government. If these are unavailable, the safety instructions in this manual shall be followed.
Most accidents are caused due to the violation to the operation and maintenance regulations of the
machine. To avoid accidents, please go through, comprehend and follow all warnings and precautions in
this manual before the operation and maintenance.
As it is impossible to foresee every possible hazard, the safety instructions in this manual may not cover
all safety prevention measures. Be sure to ensure the safety of yourself and others and protect the
machine against any damage, if the steps and operation beyond this manual are adopted. If you are
unable to confirm the safety of some operations, please feel free to consult us or the distributor.
The operation & maintenance prevention measures listed in this manual are only applicable to the
specified uses of this machine. Our company shall assume no responsibility if this machine is used
beyond the range of this manual. The user and the operator shall be responsible for the safety of such
operations.
Do not carry on any operation forbidden in this manual in any cases.
The following signal words are applicable for identifying the safety information of this manual.
△
! Hazard:
If not avoided, the dangerous results as severe injuries or death can be caused. This
word is also applicable to the situation that serious machine damage can be caused,
if not avoided.
△
! Warning:
If not avoided, the potential dangerous results as severe injuries or death can be
caused. This word is also applicable to situation that the serious machine damage
may be caused, if not avoided.
△
! Notice:
If not avoided, the minor or intermediate injury may be caused. This word is also
applicable to situation that the machine damage may be caused or the machine
service life may be shortened, if not avoided.

Maintenance Manual of Elevating Work Platform
1
Chapter 1 Maintenance

Maintenance Manual of Elevating Work Platform
2

Maintenance Manual of Elevating Work Platform
3
△
!Warning: Compliance and
obedience
The operator shall only carry on the
routine maintenance items
specified in this manual.
The regular maintenance and
inspection shall be made by the
trained maintenance technician as
per the requirements of the
manufacturer
1.1Battery inspection
The good condition of battery is essential to
performance and safe operation. The unsuitable
electrolyte liquid level or damaged cable and
wiring may cause the component damage and
even the hazard
△
!Notice: This inspection is not
required for the machine with the sealed
battery or maintenance-free battery.
Other positions shall be checked.
△
!Hazard
Electrocution hazard：
The live operation may cause severe
personal injury or death. Take off all
rings, watches and other jewelry in the
operation process.
Personal injury hazard：
The battery electrolyte is corrosive. Do
not expose the hands or any body parts
to the overflowed electrolyte, for fear of
injury. Please neutralize the overflowed
electrolyte with the sodium bicarbonate
solution
△
!Notice: the following inspections
shall be made when the battery level
is sufficient：
Put on the protective clothing and
the safety goggles.
Ensure that the wiring of battery
cable is firm and free of erosion.
Ensure that the battery locking rod
is stable and firm.
Remove the battery ventilation
cover.
Check the battery electrolyte fluid
level. If necessary, add distilled
water from the bottom of battery
fluid add pipe. Do not add excessive
distilled water.
Install the ventilation cover.

Maintenance Manual of Elevating Work Platform
4
△
!Notice: the wiring-end protector
and the anti-corrosion sealant will
protect the battery wiring end and the
cable against corrosion.
1.2Battery Maintenance
Schedule
See the appendix for the maintenance plan of
battery.
1.3 Hydraulic oil level
inspection
The suitable hydraulic oil level is essential to the
machine operation. If the hydraulic oil level is
unsuitable, the hydraulic component may be
damaged. The hydraulic oil level change can be
determined by the inspector via the daily
inspection. This change main indicate the
problem of the hydraulic system
△
!Notice: this process shall be done
when the platform is folded.
Visually inspect the fluid level of the
hydraulic oil tank.
Result: the hydraulic oil shall be located
at the oil tank mark.
Please add the hydraulic oil based on
the demand and do not add excessive
hydraulic oil.
△
! Notice: To fill the hydraulic oil, it
is required to use the applicable
hydraulic oil in accordance with the use
environment and temperature with
reference to the followings:
L-HM 46 antiwear hydraulic oil: minimum air
temperature＞-9℃;
L-HV 46 low temperature hydraulic oil: -33℃
＜minimum air temperature≤-9℃;
L-HS 46 Ultralow temperature hydraulic oil:
-39℃＜minimum air temperature≤-33℃;
10# aviation hydraulic oil: minimum air
temperature ≤-39℃;
1.4 Pre-delivery preparation
report
1) The pre-delivery preparation report shall
cover the inspection items of each type..
2) The pre-delivery preparation report shall be
prepared for each inspection. Such report
shall be saved as required after being
completed.

Maintenance Manual of Elevating Work Platform
5
1.5Maintenance schedule
The daily, quarterly, semi-annual, annual and
once-per-two-year maintenance must be done as
per the schedule. The product maintenance
program and the pre-delivery preparation report
can be divided into A, B, C, D E and F sub items.
The steps of each inspection are as shown in the
table below.
△
!Notice:
The working hours are based on the
meter.
Lubricate the steering knuckles
every month to ensure that the
equipment meets the requirements.
1.6 Maintenance and
inspection report
1) The maintenance and inspection report shall
cover the inspection items of each type.
2) The maintenance and inspection report shall
be prepared for each inspection. Please
3) Keep the report for at least 4 years after the
inspection or keep it as specified by the
owner and laws and regulations of the
workstation and government.
Legend description
Y= Accepted
N=Rejected
R=Repaired
Check list A
Y
N
R
A-1 Inspection of manual and
label
A-2 Pre-operation inspection
A-3 Function test
25 hours later
A-4 30-day maintenance
Check list B
Y
N
R
B-1 Battery
B-2 Wire
B-3 Tyre and rim
B-4 Emergency stop
B-5 Key switch
B-6 Horn
B-7 Drive brake
B-8 Driving speed in the
folding status
B-9 Driving speed in the lifting
status
B-10 Slow-speed driving
B-11 Hydraulic oil analysis
B-12 Exhaust System
B-13 Chassis tray component
B-14 Test of lower limit and
hollow protector switch
B-15 Test of upper limit switch
Check list C
Y
N
R
C-1 Platform overload system
C-2 Replacement of
ventilation pipe of hydraulic oil
tank
Check list D
Y
N
R
D-1 Inspection for
wear-resistance slide block of
scissor
D-2 Replacement of hydraulic
oil filter core
Checklist E
Y
N
R
E-1 Hydraulic oil

Maintenance Manual of Elevating Work Platform
6
1.7 Pre-delivery preparation
report
1.7.1 Basic principle
1) The distributor shall be responsible for the
pre-delivery preparation.
2) The priority shall be given to the pre-delivery
preparation for each product delivery. This
inspection is aimed to find the significant
problem of equipment before use.
3) The damaged and modified equipment are
forbidden to use. Once any damage or
inconformity is found during the equipment
delivery, please mark the machine at once
and stop the work.
4) The equipment must be repaired by the
authorized technical as per the specification
of manufacturer and the requirements of this
manual.
1.7.2 Description
1) Please follow the operation manual on the
equipment.
2) The pre-delivery preparation composed of
the operation check, maintenance item and
function test.
3) Record the result with a table. Complete
each completed item in corresponding table
Inspection cycle
Inspection item
Every day or every 2 hours
A
Every month or every 25 hours
A+B
Every season or every 50 hours
A+B+C
Each half a year or every 100 hours
A+B+C+D
Each year or every 200 hours
A+B+C+D+E
Every two years or every 400 hours
A+B+C+D+E+F
Legend description
Y=Yes, completed
N=No, un-completed
R=Repaired
Evaluation
Pre-delivery preparation
Y
N
R
Operation inspection completed
Maintenance item completed
Function test completed
Model
Serial number
Date
Owner
Inspector (printed)
Signature of inspector
Title of inspector
Inspection company

Maintenance Manual of Elevating Work Platform
7
according to the description in the operation
manual.
4) If any inspection result “N” appears, stop the
equipment work, repair and check the
equipment again. Make a mark on the
position R after the inspection.
1.8 Maintenance and
inspection report
△
!Description：
One report is applicable for each
inspection.
Choose the appropriate check list
according to the check items.
Every day or every 2 hours
A
Every month or every 25 hours
A+B
Every season or every 50
hours
A+B+C
Each half a year or every 100
hours
A+B+C+D
Each year or every 200 hours
A+B+C+D+E
Every two years or every 400
hours
A+B+C+D+E+F
Tick on the corresponding position
after each inspection.
Learn how to make the inspection
step by step.
If the inspection result “N” is made, mark and
stop the machine work until it is repaired and
checked again. Tick on the position “R” after
the repair.①Before delivery②Completion of
operation check ③Project maintenance
completion④Functional test completion
1.9 Steps of checklist A
A-1
Inspection of manual and label
The completeness of operation and maintenance
manual is the key of safe operation. Each
equipment is supplied with a manual which is kept
in a box on the platform. The illegible or
incomplete manual is unable to provide sufficient
safe operation information.
Besides, be sure to keep all safety labels in good
conditions. The label can provide the potential
operation hazards of the machine to the operator.
Meanwhile, it also provides the operation and
maintenance information to the user. The illegible
labels cannot play the role of warning, but may
cause the dangerous operation environment.
1) Check and ensure that the operation and
maintenance manual is kept in the manual
box.
2) Check the manual for its clear writing and
completeness
Result: the manual is matched with the
model and all writings on the manual are
clear and complete.
Result: the manual is not matched with the
model and all writings on the manual are
illegible and incomplete. Stop the work of

Maintenance Manual of Elevating Work Platform
8
machine before replacing the manual.
3) Open the label check diagram and carefully
check if the label is illegible or complete.
Result: All labels are complete, clear and
intact.
Result: The labels are missing, illegible or
incomplete. Stop the work of machine before
replacing the label.
4) Return the manual to its original position after
the use. Notice: please contact LGMG for
manual or label replacement, if necessary.
A-2
Pre-operation inspection
The pre-operation inspection is essential to the
safe operation of machine. The pre-operation
inspection is made in the form of visual inspection
before the machine operation. This inspection is
used for discovering the significant problems of
machine before the function test and for
determining if the routine maintenance
procedures are necessary.
For all inspection procedures, please refer to
“Pre-operation inspection” in this manual.
A-3
Function test
The function test is essential to the safe operation
of machine. The function test is aimed to
discovering the functional defects of the machine
before the operation. The defected machine
cannot be put into service. Once any functional
defects are found, please mark the machine
immediately and discontinue the use.
For all inspection procedures, please refer to
“Function test” in this manual.
A-4
30-day maintenance
The 30-day maintenance is made on the first 30
day or the first 25h after the machine operation.
After this step, Please continue to check the
maintenance items on the check list.
The maintenance shall be made according to the
steps below：
1) B-3 Tyre and rim
1.10 Steps of checklist B
B-1
Battery inspection
This check item shall be made once per 25h or
per month, whichever is shorter.
The well battery status is essential to machine
performance and operation safety. The incorrect
electrolyte fluid level and the damaged cable or
connector may cause the machine part damage
and hazard.
△
!Warning: Electrocution hazard
The live operation may cause severe
personal injury or death. Take off the
ring, watch and other jewelry in the
operation process.
△
! Warning: Personal injury hazard

Maintenance Manual of Elevating Work Platform
9
The battery electrolyte is corrosive. Do
not expose the hands or any body parts
to the overflowed electrolyte, for fear of
injury. Please neutralize the overflowed
electrolyte with the sodium bicarbonate
solution.
1) Put on the protective clothing and the safety
goggles.
2) Release the battery tray lock on the chassis
side and rotate the chassis battery tray
outward.
3) Protect the battery cable connector against
erosion.
△
!Notice: add a wiring end protector
and coat the anti-corrosion glue to
protect the battery connector cable
against erosion.
4) Firmly fix the battery and the cable.
5) Fully charge the battery and stay it for at
least 24h
△
!Notice: Steps 6 thru 12 do not
apply to sealed or maintenance free
batteries.
6) Open the battery cover, check the specific
weight with a specific gravity hydrometer and
make the record.
7) Check the ambient temperature and adjust
the specific liquid gravity of each battery
according to the instructions below:
Increase the specific liquid gravity by 0.004
per 5℃, if the temperature is higher than
27℃.
Decrease the specific liquid gravity by 0.004
per 5℃, if the temperature is lower than
27℃.
Result: the specific liquid gravity of each
battery is greater than 1.277 after the
adjustment. Fully charge the battery and turn
to Step 12.
Result: if the specific liquid gravity of each
battery is lower than 1.250, turn to Step 8
8) Charge the battery in a balanced way or fully
charge the battery and stay the battery still
for at least 6h (preferably 24h).
9) Open the battery cover, check the specific
weight with a specific gravity hydrometer and
make the record.
10) Check the ambient temperature and adjust
the specific liquid gravity of each battery
according to the instructions below:
Increase the specific liquid gravity by 0.004
per 5℃, if the temperature is higher than
27℃.
Decrease the specific liquid gravity by 0.004
per 5℃, if the temperature is lower than
27℃.
Result: the specific liquid gravity of each
battery is greater than 1.277 after the

Maintenance Manual of Elevating Work Platform
10
adjustment. Fully charge the battery and turn
to Step 12.
Result: the specific liquid gravity difference
between the battery cells is greater than 0.1
or the specific liquid gravity of more than one
battery cell is less than 1.217. In such case,
please replace the battery.
11) Check the battery electrolyte height. If
necessary, add the distilled water to the
highest liquid level indicator and do not add
the excessive distilled water.
12) Close the battery cover and neutralize the
spilled electrolyte with the sodium
bicarbonate solvent.
△
!Notice: The following checks are
suitable for batteries of any type:
13) Check if the battery cells in each battery pack
are correctly connected..
14) Check the excessive abrasion and damage
of the battery charger plug and the wire
insulation. Replace the worn and damaged
one in time, in any.
15) Correctly connect the battery charge to the
100-240V, 50/60HZ AC power supply.
Result: The charger is running and charging
the battery.
Result: The charger alarm rings and the
indicator flashes. Please check and correct
the connection of fuse and charger.
Guarantee the normal operation of charger
and charge the battery.
△
!Notice: to achieve good effect,
please make use of the wire with
appropriate length. Keep the total length
below 15m.
△
!Notice: for more information of
charger operation, please contact the
after-sales service department of LGMG.
B-2
Wire inspection
This check item shall be made once per 25h or
per month, whichever is shorter.
Keeping the wire in good conditions is essential to
safe operation and good machine performance. If
the burn, scratched, eroded or bent wire is not
discovered and replaced and is used in the
unsafe operation environment, the machine
element may be damaged
△
!Danger: Electrocution/explosion
danger
The thermal contact or the conductor may cause
the serious injury and death. Do not put on the
ring, watch and other jewelry.
1) Check if the ground wire below the chassis is
lost or damaged.
2) Check if there is any burn, scratched, eroded,
bent or loosened wire in the areas below:
Internal of ground controller box
Wire of hydraulic block

Maintenance Manual of Elevating Work Platform
11
Wire in battery area of the battery tray
Internal of platform controller box
3) Switch the key switch to the platform
controller and draw out the red emergency
stop buttons from the ground and platform
controller.
4) Lift the platform for a given height above the
ground. The lifting height of every model is
given in the following table.
Model
Height (m)
SS0407E
1.8
AS0607E
2.5
AS0812E
3.2
AS1012E
3.73
AS1212E
4
AS1413E
5) Lift the safety prop, move it to the center of
the scissor sleeve center and rotate it upward
until it is vertical
6) Lower the platform height until the safety
prop completely contacts the shaft sleeve
△
!Hazard：Crush hazard
Be sure to put your hand on correct
position of the safety prop when
lowering the platform
7) Check if there is any burn, scratched, eroded,
bent and loosened wire in chassis and the
scissor area..
8) Check if there is any burn, scratched, eroded,
bent and loosened wire in the areas below:
Wire of scissor arm
ECU to the platform
Harness connector connected on the
platform
9) Check the free coating of the insulating oil on
the positions below:
Harness connector connected between ECU
and platform controller
All harness connectors connected the level
sensor
10) Raise the platform and recover the safety
prop to the installation position.
11) Lower the platform to the folding position and
then shut down the machine
B-3
Inspection of tyre and rim
This check shall be made once per 25h or per
month, whichever is shorter.
Keeping the tyre and rim in good conditions is
essential to safe operation and good performance.
The failure of tyre and rim is possible to tip over
the machine. The machine elements can also be
damaged, if the defected tyres and rims are not
discovered and repaired.
1) Check if the tread and sides of the tyre
contain any scratch, crack, hole and other
abnormal wear.
2) Check if the rim is damaged, bent and
cracked
3) Remove the cotter pin and check the nut
torque

Maintenance Manual of Elevating Work Platform
12
△
!Notice: the new cotter pin must be
used when installing the tyre and rim
again.
4) Install and lock a new cotter pin
Torque of
lubrication-free nut
410-540Nm
△
!Notice: Model suitable for electric drive
5) Check torque of each bolt。
Torque of
lubrication-free bolt
90Nm
6) Lubricate the steering knuckles.
B-4
Inspection of emergency stop
This check shall be made once per 25h or per
month, whichever is shorter.
1) The normal emergency stop function is
essential for the proper operation of the
machine. If it does not cut off the power
supply and stop all functions of the machine
a hazardous working condition can be the
result.
2) As a safe function, besides the red
emergency stop button on the platform, the
selection and operation of ground controller
shall be superior to those of the platform
controller.
3) Switch the key switch to the ground controller
and draw out the red emergency stop buttons
from the ground and platform controller.
4) Press the red emergency stop button on the
ground controller to the OFF position.
Result: No action is enabled by the machine。
5) Press the red emergency stop button on the
platform controller to the OFF position.
Result: No action is enabled by the machine
△
!Notice: the red emergency stop
button of the ground controller can stop
all operations of the machine, even if the
key switch is switched to the platform
controller.
B-5
Test of key switch
This check shall be made once per 25h or per
month, whichever is shorter.
1) The correct action of key switch and
essential to the safe operation of equipment.
The machine can be operated via the ground
controller or the platform controller. The key
switch is used for switching the control. The
failed switch may cause the dangerous
operation.
2) As this step is carried out on the ground with
a platform controller, no person shall stand
on the platform.
3) Pull out the emergency stop switches from
the ground and platform controllers.
4) Turn the key switch to the platform controller
position.
5) Check the lifting and lowering functions from
the ground controller. Result: No action is
enabled by the machine.
6) Turn the key switch to the ground controller
position.

Maintenance Manual of Elevating Work Platform
13
7) Check the lifting and lowering functions from
the platform controller. Result: No action is
enabled by the machine.
8) Turn the key switch to the OFF position.
Result: No action is enabled by the machine.
B-6
Test of horn
This check shall be made once per 25h or per
season, whichever is shorter.
1) The horn is used for giving the warning to the
ground staff by the control staff on the
platform. It is unable to remind the hazard
and unsafe status to the ground staff with the
abnormal horn.
2) Switch the key switch to the platform
controller and draw out the red emergency
stop buttons from the ground and platform
controller.
3) Press the horn button on the horn controller.
Result: the horn outputs the sound.
B-7
Test of driving and braking function
This check shall be made once per 25h or per
month, whichever is shorter.
1) The normal braking function is essential to
the operation safety. The brake shall be
stable and free of delay, vibration and
abnormal sound. The hydraulic releasing of
braking system shall be normal.
2) Be sure to complete the braking function
inspection on a solid and level ground
without any barrier. Ensure the machine is
folded and the extending platform is
completed retracted.
①Make a reference test line on the ground.
②Switch the key switch to the platform
controller and draw out the red emergency
stop buttons from the ground and platform
controller.
③Lower the platform to the folding position.
④Press the drive function selector button.
⑤Select one point (such as the touchdown
point on the wheel) from the machine as the
visual inspection reference of the test line.
⑥Drive the machine at the maximum speed
and release the handle at the moment
when the reference point passes the
ground test line.
⑦Measure the distance between the
reference point and the survey line.
Result: The machine is stopped within the
specified braking distance. No action is
required.
Result: The machine is not stopped within
the specified braking distance.
△
!Notice: the brake must be valid
within the allowable gradeability range
of the machine.
⑧Replace the brake and repeat the process
above from Step 1.
B-8
Test of driving speed-folding status

Maintenance Manual of Elevating Work Platform
14
This check shall be made once per 25h or per
month, whichever is shorter.
1) The normal driving function is essential to
the operation safety. With the driving
function, a rapid and stable response shall
be given to the operator. No delay, vibration
and abnormal sound shall be outputted
during the normal operation and driving
process.
2) Be sure to complete the driving test on a
firm and level ground without any barrier.
①Draw two lines, spaced by 10m on the
ground, as the starting line and the
finishing line.
②Switch the key switch to the platform
controller and draw out the red
emergency stop buttons from the ground
and platform controller
③Lower the platform to the folding
position.
④Press the drive function selector button.
⑤Select one point from the machine as
the visual inspection reference for the
starting line and the finishing line.
⑥Drive the machine at the maximum
speed and start to count when the
reference point passes the starting line.
⑦Keep driving at the full speed and record
the time when the reference point
passes the finishing line. Refer to the
specification.
B-9
Test of driving speed-lifting status
This check shall be made once per 25h or per
month, whichever is shorter.
1) The normal driving function is essential to the
operation safety. With the driving function, a
rapid and stable response shall be given to
the operator. No delay, vibration and
abnormal sound shall be outputted during the
normal operation and driving process.
2) Be sure to complete the driving speed test on
a solid and level ground without any barrier.
①Draw two lines, spaced by 10m on the
ground, as the starting line and the
finishing line.
②Switch the key switch to the platform
controller and draw out the red emergency
stop buttons from the ground and platform
controller.
③Press the lifting function selector button.
④Press the enable key
⑤Lift the platform for a given height above
the ground. The lifting height of every
model is given in the following table.
Model
Height (m)
SS0407E
1.36
AS0607E
1.19
AS0812E
1.71
AS1012E
AS1212E
1.86
AS1413E
2.52

Maintenance Manual of Elevating Work Platform
15
⑥Press the drive function selector button.
⑦Select one point (such as the touchdown
point on the wheel) from the machine as
the visual inspection reference for the
starting line and the finishing line.
⑧Drive the machine at the maximum
speed per hour and start to count when
the reference point passes the starting
line.
⑨Keep driving at the full speed and record
the time when the reference point
passes the finishing line. Refer to the
specification.
B-10
Test of driving speed-slow speed
This check shall be made once per 25h or per
month, whichever is shorter.
1) The normal driving function is essential to the
operation safety. With the driving function, a
rapid and stable response shall be given to
the operator. No delay, vibration and
abnormal sound shall be outputted during the
normal operation and driving process.
2) Be sure to complete the driving test on a
solid and level ground without any barrier.
①Draw two lines, spaced by 10m on the
ground, as the starting line and the finishing
line.
②Switch the key switch to the platform
controller and draw out the red emergency
stop buttons from the ground and platform
controller.
③Lower the platform to the folding position.
④Press the driving speed selector button.
⑤Select one point (such as the touchdown
point on the wheel) from the machine as the
visual inspection reference for the starting
line and the finishing line.
⑥Drive the machine at the maximum speed
and start to count when the reference point
passes the starting line.
⑦Keep driving at the full speed and record the
time when the reference point passes the
finishing line. The driving time shall not be
less than 22.5s.
B-11
Visual Inspection of the Hydraulic Oil
This check item shall be made once every 25
hours of operation or every month, whichever
interval is shorter.
Collect a sample of hydraulic oil and place in a
clear container. Visually inspect the hydraulic oil
for the following:
1) Color: oil should be a clear, light-honey
colored.
2) Appearance: oil should be clear and not
cloudy or visibly distorts the view through the
sight glass or container.
3) Contains no particles, foreign objects, or
other contamination.
4) The hydraulic oil can be inspected by smell
