LGMG S0607EII User manual

Maintenance Manual
Scissors Mobile Elevating Work Platform
S0607EⅡ/S0608EⅡ/S0808EⅡ/S0812EⅡ
S1012EⅡ/S1212EⅡ/S1413EⅡ
△
!
WARNING
Before operation and maintenance, the
drivers and service personnel shall
always read and thoroughly understand
all information in this manual. Failure to
do so may result in, fatal accidents or
personal injury.
This manual must be kept with this
machine at all times.

Scissors Mobile Elevating Work Platform
Maintenance Manual
880*1230 mm sixteen format 8 printed sheet
First edition and printed for the first time in February 2023
LINGONG HEAVY MACHINERY CO., LTD.
Add: F12,Building 3 LushangGuoao Plaza, 9777 Jingshi Road,Lixia District, Jinan, Shandong,
250000,China
Tel: [phone] Technical service: 86-0531-67605017
Fax: [phone] Accessory sales: 86-0531-67605016
Web: www.lgmg.com.cn

Maintenance Manual of Scissors Mobile Elevating Work Platform
I
Foreword
Thank you for choosing to use this Mobile Elevating Work Platform from LGMG. This machine is designed
according to AS/NZS 1418.10:2011. The information specified in this manual is intended for the safe and proper
operation of this machine for its’ intended purpose.
For maximum performance and utilization of this machine, thoroughly read and understand all the information in
this manual before starting, operating, or performing maintenance on this machine.
Due to continuous product improvements, LGMG reserves the right to make specification changes without any
prior notifications. For any updated information, contact LGMG.
Ensure all preventive maintenance to the machine is performed according to the interval specified in the
maintenance schedule.
Keep this manual with this machine for reference at all times. When the ownership of this machine is transferred,
this manual shall be transferred with this machine. This manual must be replaced immediately if it is lost,
damaged, or becomes illegible.
This manual is copyrighted material. The reproduction or copy of this manual is not allowed without the written
approval of LGMG.
The information, technical specifications and drawings in this manual are the latest available when this manual is
issued. Due to continuous improvement, LGMG reserves the right to change the technical specifications and
machine design without notice. If any specifications and information in the manual are not consistent with your
machine, please contact the service department of LGMG.
△
!WARNING
Only personnel who have been properly trained and qualified to operate or maintain this machine
can operate, repair and maintain this machine.
Improper operation, maintenance, and repair are dangerous and can cause personal injury and
death.
Before any operation or maintenance, the operator shall thoroughly read this manual. Do not
operate, perform any maintenance or make any repairs on this machine before reading and
understanding this manual.
The user shall load the platform strictly according to the load rating of the platform. Do not
overload the platform or make any modifications to the platform without permission from LGMG.
The operation regulations and preventions in this manual are only applicable for the specified
use of this machine.

Maintenance Manual of Scissors Mobile Elevating Work Platform
II
Safety Precautions
The operator of this machine shall understand and follow the existing safety regulations of state and local
governments. If these are unavailable, the safety instructions in this manual shall be followed.
To help prevent accidents, read and understand all warnings and precautions in this manual before
operation or performing maintenance.
It is impossible to foresee every possible hazard and the safety instructions in this manual may not cover all
safety prevention measures. Always ensure the safety of all personnel and protect the machine against any
damage. If unable to confirm the safety of some operations, contact LGMG.
The operation & maintenance prevention measures listed in this manual are only applicable to the specified
uses of this machine. LGMG assumes no responsibility if this machine is used beyond the range of this
manual. The user and the operator shall be responsible for the safety of such operations.
Do not perform any operation forbidden in this manual in any situation.
The following signal words are applicable for identifying the level of safety information in this manual.
△
!DANGER:
An imminent situation, that if not avoided, will result in severe injuries or death. This is also
applicable to situations that will cause serious machine damage, if not avoided.
△
!WARNING:
A potentially dangerous situation, that if not avoided, may result in severe injuries or death. This is
also applicable to situations that may cause serious machine damage, if not avoided.
△
!NOTICE:
A situation, that if not avoided, may result in minor or intermediate injury. This is also applicable to
situations that may cause machine damage or shorten machine service life.

Maintenance Manual of Scissors Mobile Elevating Work Platform
III
Contents
Chapter 1 Maintenance ......................................................................................1
1.1 Battery Inspection....................................................................................................................... 1
1.2 Battery Maintenance Schedule................................................................................................... 1
1.3 Hydraulic Oil Level...................................................................................................................... 1
1.4 Pre-Delivery Preparation Report................................................................................................. 2
1.5 Maintenance Schedule............................................................................................................... 2
1.6 Maintenance and Inspection Report ........................................................................................... 2
1.6.1 General Information ............................................................................................................. 2
1.6.2 Description........................................................................................................................... 3
1.7 Pre-Delivery Preparation Report................................................................................................. 3
1.7.1 General Information ............................................................................................................. 3
1.7.2 Description........................................................................................................................... 3
1.8 Checklist A ................................................................................................................................. 4
1.8.1 A-1 Inspection of Manual and Decals................................................................................... 4
1.8.2 A-2 Pre-Operation Inspection............................................................................................... 4
1.8.3 A-3 Function Test................................................................................................................. 4
1.8.4 A-4 30-Day Maintenance ..................................................................................................... 4
1.9 Checklist B ................................................................................................................................. 5
1.9.1 B-1 Battery Inspection.......................................................................................................... 5
1.9.2 B-2 Wiring Inspection........................................................................................................... 6
1.9.3 B-3 Inspection of Electrical Contactor .................................................................................. 8
1.9.4 B-4 Inspection of Tire and Wheel......................................................................................... 8
1.9.5 B-5 Testing the Emergency Stop Switches .......................................................................... 9
1.9.6 B-6 Testing the Key Switch.................................................................................................. 9
1.9.7 B-7 Testing the Horn.......................................................................................................... 10

Maintenance Manual of Scissors Mobile Elevating Work Platform
IV
1.9.8 B-8 Testing the Driving and Braking Functions................................................................... 10
1.9.9 B-9 Testing Drive Speed from the Platform Stowed Position.............................................. 10
1.9.10 B-10 Testing Drive Speed from the Platform Elevated Position........................................ 11
1.9.11 B-11 Low Speed Drive Test ............................................................................................. 12
1.9.12 B-12 Visual Inspection of the Hydraulic Oil....................................................................... 12
1.9.13 B-13 Hydraulic Oil Tank Ventilation Inspection................................................................. 13
1.9.14 B-14 Inspection of the Chassis Tray Locking Mechanism................................................. 13
1.9.15 B-15 Inspection of the Down Limit and Pothole Limit Switches......................................... 13
1.9.16 B-16 Inspection of the Upper Limit Switch........................................................................ 16
1.9.17 B-17 Inspection of Steering Knuckle ................................................................................ 17
1.9.18 B-18 Check and Replacement of Electric Brush (If Equipped).......................................... 18
1.10 Checklist C............................................................................................................................. 19
1.10.1 C-1 Testing the Platform Overload System (If Equipped)................................................. 19
1.10.2 C-2 Replacement of the Hydraulic Tank Breather Cap..................................................... 21
1.11 Checklist D............................................................................................................................. 21
1.11.1 D-1 Inspection of the Scissor Arm Slide Blocks................................................................ 21
1.11.2 D-2 Replacement of Oil Return Filter in the Hydraulic Tank ............................................. 22
1.12 Checklist E ............................................................................................................................. 23
1.12.1 E-1 Test and replacement of Hydraulic Oil....................................................................... 23
Chapter 2 Maintenance Schedules...................................................................25
2.1 Battery Maintenance Schedule................................................................................................. 25
2.2 Maintenance Schedule............................................................................................................. 26
2.2.1 Routine Inspection and Maintenance Intervals................................................................... 26
2.2.2 Hydraulic Oil Selection and Specifications ......................................................................... 29
Chapter 3 Error Codes and Troubleshooting.....................................................31
3.1 Error Codes.............................................................................................................................. 31
3.2 Troubleshooting Guide ............................................................................................................. 33

Maintenance Manual of Scissors Mobile Elevating Work Platform
V
Chapter 4 Control System.................................................................................37
4.1. ECU Introduction..................................................................................................................... 37
4.2. ECU Parameter Setting........................................................................................................... 37
4.2.1 Parameter Adjustment ....................................................................................................... 37
4.2.2 Function Configuration....................................................................................................... 40
4.2.3 Calibration Function........................................................................................................... 41
4.2.4 Historical fault information.................................................................................................. 44
4.2.5 About this Unit.................................................................................................................... 44
4.2.6 Status Monitoring............................................................................................................... 45
4.3 Introduction to Thermal Management Strategy of Lithium-Ion Battery....................................... 46
4.3.1 Introduction........................................................................................................................ 46
4.3.2 Thermal Management Strategy.......................................................................................... 46
Chapter 5 Schematics ......................................................................................49

Maintenance Manual of Scissors Mobile Elevating Work Platform
VI
This page left blank intentionally

Maintenance Manual of Scissors Mobile Elevating Work Platform
1
Chapter 1 Maintenance
△
! WARNING
Observe and Obey:
Only qualified technicians shall perform
maintenance on components specified
in this manual.
Regular maintenance and inspection shall only be
made by trained maintenance technicians as per
the requirements of LGMG.
1.1 Battery Inspection
Maintaining the battery in good condition is
essential to performance and safe operation of
this machine. Improper electrolyte level or
damaged cables or wiring may cause component
damage or a hazardous condition.
△
! DANGER
Electrocution Hazard
Take measures to prevent electric shock
due to touching the battery terminals or
connectors. When working on the
batteries or electrical circuits, remove all
jewelry and metallic objects.
△
!WARNING
Personal Injury Hazard
Battery electrolyte is corrosive. Do not
expose hands or body parts to
overflowed or spilled electrolyte, due to
risk of personal injury. Neutralize the
overflowed or spilled electrolyte with the
sodium bicarbonate solution.
1.2 Battery Maintenance
Schedule
Refer to the Maintenance Schedule for the
maintenance plan of the batteries.
1.3 Hydraulic Oil Level
Maintaining proper hydraulic oil level is essential
to efficient and reliable machine operation. If the
proper hydraulic oil level is not maintained,
hydraulic components may be damaged and/or
cease functioning. Changes in hydraulic oil level
can be determined by the inspector when
performing the daily inspection. Changes in the
hydraulic oil level may indicate a leak or other
problem in the hydraulic system.
△
! NOTICE
To fill the hydraulic oil, it is a
requirement to use the proper hydraulic
oil in accordance with the work site

Maintenance Manual of Scissors Mobile Elevating Work Platform
2
environment and ambient temperature
with reference to the following:
Grade
Brand
Rando MV32
Chevron
△
! CAUTION: Do not top off with
incompatible hydraulic fluids. Hydraulic
fluids may be incompatible due to the
differences in base additive chemistry.
When incompatible fluids are mixed,
insoluble materials may form and
deposit in the hydraulic system,
plugging hydraulic lines, filters, control
valves and may result in component
damage.
1.4 Pre-Delivery Preparation
Report
1) The pre-delivery preparation report shall
cover the inspection items of each type.
2) The pre-delivery preparation report shall be
prepared for each inspection. Such report
shall be saved as required after being
completed.
1.5 Maintenance Schedule
The daily, quarterly, semi-annual, annual and
once-per-two-year maintenance must be done as
per the schedule. The product maintenance
program and the pre-delivery preparation report
can be divided into A, B, C, D, E and F sub items.
The steps of each inspection are as shown in the
table below.
Table 1 Inspection Checklists
Table 2 Inspection Report
1.6 Maintenance and
Inspection Report
1.6.1 General Information
1) The maintenance and inspection report shall
cover each type of inspection item.
2) The maintenance and inspection report shall
Inspection Cycle
Inspection item
Every day or every 2 hours
A
Every month or every 25 hours
A+B
Every season or every 50 hours
A+B+C
Each half a year or every 100 hours
A+B+C+D
Each year or every 200 hours
A+B+C+D+E
Every two years or every 400 hours
A+B+C+D+E+F
Legend description
Y=Yes, completed
N=No, un-completed
R=Repaired
Evaluation
Pre-delivery preparation
Y
N
R
Operation inspection
completed
Maintenance item
completed
Function test completed
Model
Serial number
Date
Owner
Inspector (printed)
Signature of inspector
Title of inspector
Inspection company

Maintenance Manual of Scissors Mobile Elevating Work Platform
3
be prepared for each inspection.
3) Keep the report for at least 4 years after
inspection or as specified by local
government laws and regulations.
1.6.2 Description
One report is applicable for each inspection.
Choose the appropriate checklist according
to the items to be checked.
Place a check mark on the corresponding
box on the inspection form after each item is
inspected.
Learn how to make step-by-step inspections.
If the item’s inspection results in an “N” result,
tag out the machine’s controls until it is
repaired and checked again. Mark an “R”in
the appropriate box on the inspection form
after the repair has been made;
①Before delivery.
②Completion of operation check.
③Project maintenance completion.
④Functional test completion.
1.7 Pre-Delivery Preparation
Report
1.7.1 General Information
1) The distributor shall be responsible for
Pre-Delivery Preparation.
2) Priority shall be given to pre-delivery
preparation for each individual product
delivery. The purpose of this inspection is to
find any problems with the equipment prior to
use.
3) Using damaged or modified equipment is
strictly forbidden. If any damage or
inconformity is found during equipment
delivery, tag out the machine controls at once
and do not use the machine until it is
repaired.
4) The machine must be repaired by an
authorized technician per the specification of
the manufacturer and the requirements of
this manual.
1.7.2 Description
1) Thoroughly read, understand, and adhere to
the instructions in the Operation Manual with
this machine.
2) The pre-delivery preparation composed of
the operation check, maintenance item and
function test.
3) Record the result with a table. Complete
each completed item in corresponding table
according to the description in the operation
manual. Refer to Table 2 –Inspection Report.
4) If any inspection results in an “N” (No,
Uncompleted) rating, stop using the machine
immediately. Repair and check the
equipment again. Mark the item “R”
(Repaired) after the item has passed
inspection.

Maintenance Manual of Scissors Mobile Elevating Work Platform
4
1.8 Checklist A
1.8.1 A-1 Inspection of Manual and
Decals
Each machine is supplied with an Operation
Manual in the manual storage box on the platform.
An illegible, damaged, or missing manual must be
replaced immediately.
Keep all decals and signs clean and in good
condition. The decals can inform the operator of
potential operational hazards of the machine. The
decals also provide operation and maintenance
information to the operator.
1) Ensure the operation and maintenance
manual is kept in the manual box in the
platform.
2) Check the legibility or any damaged or
missing pages. Make sure the model of the
manual is matched with the model of the
machine.
3) If the manual is missing, not matched with the
model of the machine, or is illegible or
damaged, cease using the machine until the
manual is replaced.
4) Refer to the decal diagram and check if each
decal is illegible or damaged.All labels
should be legible and undamaged. If any
decals are missing, illegible, or damaged,
stop using the machine until any missing or
damaged decals have been replaced.
5) Make sure the Operation Manual is always
returned to the manual storage box in the
platform after each use.
6) Contact LGMG for manual or decal
replacements.
1.8.2 A-2 Pre-Operation Inspection
The pre-operation inspection is essential to
ensure the proper operation of the machine. The
pre-operation inspection is made in the form of
visual inspection before machine operation. This
inspection is used for discovering significant
problems before the function test and for
determining if routine maintenance is necessary.
For all inspection procedures, please refer to
“Pre-Operation Inspection” in this manual.
1.8.3 A-3 Function Test
The function test is essential for the proper
operation of machine. The function test is used to
discover any functional defects the machine may
have prior to operation. Amachine with any
operating defects cannot be put into service. If
any functional defects are found, please tag out
the machine controls immediately and discontinue
operation.
For all inspection procedures, please refer to
Function Test in this manual.
1.8.4 A-4 30-Day Maintenance
The 30-day maintenance check is made after the
first 30 days or the first 25 hours of machine
operation.After this step, continue to check the
maintenance items on the check list.
Maintenance items on the list are:
1) B-3 Inspection of tire and Wheel.

Maintenance Manual of Scissors Mobile Elevating Work Platform
5
1.9 Checklist B
1.9.1 B-1 Battery Inspection
This check item shall be made once every 25
hours of operation or every month, whichever
interval is shorter.
Keeping the batteries in good condition is
essential to machine performance and proper
operation. Incorrect electrolyte level or damaged
cables or connectors may cause the machine
damage and hazardous working conditions.
△
! WARNING
Electrocution Hazard
Coming in contact with live electricity
during operation may cause severe
personal injury or death. Take off all
jewelry and metallic objects while
operating the machine.
△
! WARNING
Personal Injury Hazard
Battery electrolyte is corrosive. Do not
expose hands or any body parts to
electrolyte to prevent injury. Neutralize
any overflowed electrolyte with a
sodium bicarbonate solution.
1) When working on or around the batteries,
wear protective clothing and safety goggles
2) Release the battery tray lock on the chassis
side and rotate the chassis battery tray
outward.
3) Ensure the battery cables, connectors, and
battery terminals are firmly attached.
4) Protect the battery cable connector against
corrosion.Add a wiring end protector and
coat the battery terminals with an
anti-corrosion product to protect the battery
connector cables and terminals against
corrosion.
5) Fully charge the batteries and maintain the
charge for at least 24 hours.
△
! NOTICE
Steps 6 thru 12 do not apply to
sealed or maintenance free batteries.
6) Open the battery cell cover(s), check the
specific weight with a specific gravity
hydrometer and record the value.
7) Check ambient temperature and adjust the
specific liquid gravity of each battery
according to the instructions in the following
steps.
Increase the specific liquid gravity by 0.004
per 5°C, if the temperature is higher than
27°C.
Decrease the specific liquid gravity by 0.004
per 5°C, if the temperature is lower than
27°C.
Result: The specific liquid gravity of each
battery is greater than 1.277 after the
adjustment. Fully charge the battery and turn
to Step 11.
Result: If the specific liquid gravity of each

Maintenance Manual of Scissors Mobile Elevating Work Platform
6
battery is lower than 1.250, turn to Step 8.
8) Charge the battery in a balanced way or fully
charge the battery and maintain the charge
for at least 6 hours (preferably 24 hours).
9) Open the battery cell cover(s), check the
specific weight with a specific gravity
hydrometer and record the value.
10) Check ambient temperature and adjust the
specific liquid gravity of each battery
according to the instructions in the following
steps.
Increase the specific liquid gravity by 0.004
per 5°C, if the temperature is higher than
27°C.
Decrease the specific liquid gravity by 0.004
per 5°C, if the temperature is lower than
27°C.
Result: the specific liquid gravity of each
battery is greater than 1.277 after the
adjustment. Fully charge the battery and turn
to Step 11.
Result: the specific liquid gravity difference
between the battery cells is greater than 0.1
or the specific liquid gravity of more than one
battery cell is less than 1.217. In such case,
please replace the battery.
11) Check the battery acid level. If needed,
replenish with distilled water to 3 mm below
the bottom of the battery fill tube. Do not
overfill.
12) Install the vent caps and neutralize any
electrolyte that may have spilled.
△
! NOTICE
The following checks are suitable for
batteries of any type.
13) Ensure the battery cells in each battery pack
are correctly connected.
14) Check for excessive abrasion or damage to
the battery charger plug and wire insulation.
If the plug or wire are damaged, replace them
immediately.
15) Connect the battery charger to a 100-240V,
50/60HZ AC power supply.
Result: the charger is running and charging
the battery.
Result: The charger alarm sounds and the
indicator flashes. Please check and correct
the connection of charger.
Ensure the charger is operating properly and
charge the battery.
△
! NOTICE:
For best results, ensure the total length
of the charger cord is less than 50 ft.
(15m).
For more information on charger
operation, please contact the after-sales
service department of LGMG.
1.9.2 B-2 Wiring Inspection
This check item shall be made once every 25
hours of operation or every month, whichever
interval is shorter.
Keeping the wiring in good condition is essential
to proper operation and machine performance. If
any wiring is found to be burnt, damaged,

Maintenance Manual of Scissors Mobile Elevating Work Platform
7
corroded or bent is found, it must be repaired or
replaced immediately. If the machine is operated
with damaged wiring, the machine may be
damaged.
△
!DANGER
Electrocution/Explosion Danger
Contact with electrical components may
cause serious injury or death. Take off
all jewelry and metallic objects while
performing inspection or maintenance
of electrical components.
1) Check to see if the ground wire below the
chassis is missing or damaged.
2) Check if there is any burnt, damaged,
corroded, bent or loose wiring in the areas
below:
①Inside the ground controller box
②Wiring of hydraulic control valves
③Wiring in the battery area of the battery tray
④Inside the platform controller box
3) Position the key switch to the platform
controller and pull out the emergency stop
switches on the ground and platform
controllers.
4) Elevate the platform to the height given in the
following table:
Table 3 - Safety Prop Deployment Height
Model
Height
S0607EⅡ
2.4m
S0808EⅡ
3.2m
S0812EⅡ
S1012EⅡ
S1212EⅡ
4m
S1413EⅡ
5) Lift the safety arm, move it to the center of
the scissor cross tube and rotate it upward
until it is vertical.
6) Slowly lower the platform until the safety arm
completely contacts the scissor cross tube.
△
! DANGER
Crushing Hazard
Be sure to put your hand on correct
position of the safety arm when lowering
the platform.
7) Check for any burnt, damaged, corroded,
bent, or loose wiring in chassis and scissor
area.
8) Check if there is any burnt, damaged,
corroded, bent, or loose wiring in the areas
below:
Wiring running through the scissor arms
ECU to the platform
Harness connector on the platform
9) Check the dielectric grease on the positions
below:

Maintenance Manual of Scissors Mobile Elevating Work Platform
8
Harness connector connected between
ECU and platform controller
All harness connectors connected to the
level sensor
10) Raise the platform and return the safety arm
to the stowed position.
11) Lower the platform to the stowed position and
shut down the machine.
1.9.3 B-3 Inspection of Electrical
Contactor
This check item shall be made once every 25
hours of operation or every month, whichever
interval is shorter.
Keeping the electrical contactor in good condition
is essential to proper operation and machine
performance. Failure to locate a worn or damaged
contactor could result in an unsafe working
condition and component damage.
1) At the ground controls, turn the key switch to
the off position.
2) Push in the red emergency stop switch at the
ground controls to the off position.
3) Press the DC power switch to disconnect the
Power of whole machine.
4) Open the battery tray and find the electrical
contactor.
5) Visually inspect the contact points of the
contactor for the following items:
Excessive burns
Excessive arcs
Excessive pitting
6) If damaged, replace it.
△
! DANGER
Contact with hot or live circuits could
result in death or serious injury. Remove
all rings, watches and other jewelry.
1.9.4 B-4 Inspection of Tire and Wheel
This check item shall be made once every 25
hours of operation or every month, whichever
interval is shorter.
Keeping the tire and wheel in good conditions is
essential to proper operation and good
performance. The failure of tire and wheel could
potentially cause the machine to tip over causing
damage to the machine and personal injury. If
defective tires and wheels are found, they must
be replaced immediately.
1) Check if the tread and sides of the tire show
any damage, cracks, holes or other abnormal
wear.
2) Check if the rim is damaged, bent, or
cracked.
3) Remove the cotter pin and check the wheel
nut torque on each wheel lug. Torque should
be 410-540N on hydraulic drive machines,
and 90N on electric drive machines.
△
! NOTICE
A new cotter pin must be used when
reinstalling the tire and wheel.
4) Install and secure a new cotter pin.
5) Lubricate the steering spindles.

Maintenance Manual of Scissors Mobile Elevating Work Platform
9
1.9.5 B-5 Testing the Emergency Stop
Switches
△
! NOTICE
The emergency stop button of the
ground controller can stop all
operations of the machine, even if the
key switch is switched to the platform
controller.
This check item shall be made once every 25
hours of operation or every month, whichever
interval is shorter.
1) The normal emergency stop function is
essential for the proper operation of the
machine. If it does not cut off the power
supply and stop all functions of the machine a
hazardous working condition can be the
result.
2) Besides the emergency stop button on the
platform, the selection and operation of the
ground controller shall be a priority to those
of the platform controller.
3) Turn the key switch to the ground controller
position and pull out the emergency stop
switch on both the ground and platform
controllers.
4) Press the emergency stop button on the
ground controller to the OFF position. Result:
No action is enabled by the machine.
5) Press the emergency stop button on the
platform controller to the OFF position. Result:
No action is enabled by the machine.
1.9.6 B-6 Testing the Key Switch
This check item shall be made once every 25
hours of operation or every month, whichever
interval is shorter.
1) The correct action and response of the key
switch is essential to the proper operation of
the machine. The machine can be operated
via the ground controller or the platform
controller. The key switch is used for
switching between the two controllers. A
failed switch may cause the dangerous or
improper operation.
△
! NOTICE
No personnel shall occupy the
platform while the following steps
are carried out from the ground
using the platform controller.
2) Pull out the emergency stop switches from
the ground and platform controllers.
3) Turn the key switch to the platform controller
position.
4) Check the lifting and lowering functions from
the ground controller. Result: No action is
enabled by the machine.
5) Turn the key switch to the ground controller
position.
6) Check the lifting and lowering functions from
the platform controller. Result: No action is
enabled by the machine.
7) Turn the key switch to the OFF position.
Result: No action is enabled by the machine.

Maintenance Manual of Scissors Mobile Elevating Work Platform
10
1.9.7 B-7 Testing the Horn
These check items shall be made once every 25
hours of operation or every month, whichever
interval is shorter.
1) The horn is used for giving a warning to
personnel on the ground by the operator in
the platform. If the horn is not functioning
properly, the operator would be unable to
alert ground personnel of any hazards or
unsafe conditions.
2) Switch the key switch to the platform
controller position and pull out the emergency
stop switch on both the ground and platform
controllers.
3) Press the horn button on the platform
controller. Result: The horn should sound.
1.9.8 B-8 Testing the Driving and Braking
Functions
These check items shall be made once every 25
hours of operation or every month, whichever
interval is shorter.
△
!NOTICE
The brake must be capable of stopping
and holding the machine within the
allowable gradeability range of the
machine. If it does not, replace the brake
and repeat the test process the
beginning.
1) Normal braking and brake release function is
essential to proper operation. The brake must
be stable and free of delay, vibration, and
abnormal sounds.
2) Ensure the machine is stowed and the
extending platform is completed retracted.
Complete the braking function inspection on
solid and level ground without any barriers.
3) Make a reference test line on the ground.
4) Turn the key switch to the platform controller
position and pull out the emergency stop
switches on both the ground and platform
controllers.
5) Press the drive function button.
6) Select one point (such as the contact patch of
a tire) from the machine as the visual
inspection reference of the test line.
7) Drive the machine at the maximum speed
and release the handle at the moment when
the reference point passes the ground test
line.
8) Measure the distance between the reference
point and the test line. Result: The machine
has stopped within the specified braking
distance. No action is required. Result: The
machine has not stopped within the specified
braking distance. Repair or replace the brake
and repeat the testing process beginning at
Step1.
1.9.9 B-9 Testing Drive Speed from the
Platform Stowed Position
This check item shall be made once every 25
hours of operation or every month, whichever
interval is shorter.
1) The normal driving function is essential for

Maintenance Manual of Scissors Mobile Elevating Work Platform
11
proper operation of the machine. The drive
function should respond quickly and
smoothly to operator control. No delay,
vibration and abnormal sound should occur
during the normal operation and driving
function.
2) Complete the driving test on firm and level
ground without any barriers.
3) Draw two lines, spaced by 10m on the
ground, as the starting line and the finishing
line.
4) Turn the key switch to the platform controller
position and pull out the emergency stop
switches from both the ground and platform
controllers.
5) Lower the platform to the stowed position.
6) Press the drive function selector button.
7) Select one point on the machine as the visual
inspection reference point for both the
starting line and the finishing line.
8) Drive the machine at maximum speed and
start to count when the reference point
passes the starting line.
9) Keep driving at the full speed and record the
time when the reference point passes the
finishing line. Refer to the specification.
1.9.10 B-10 Testing Drive Speed from the
Platform Elevated Position
This check item shall be made once every 25
hours of operation or every month, whichever
interval is shorter.
1) The normal driving function is essential for
proper operation of the machine. The
operator should experience a rapid and
stable response. No delay, vibration and
abnormal sound should occur during the
normal operation and driving function.
2) Complete the driving test on firm and level
ground without any barriers.
3) Draw two lines, spaced by 10m on the
ground, as the starting line and the finishing
line.
4) Turn the key switch to the platform controller
position and pull out the emergency stop
switches from both the ground and platform
controls.
5) Press the lifting function selector button.
6) Press and hold the enable switch on the
control handle.
7) Lift the platform for a given height above the
ground as shown in the following table.
Table 4 - Lifting Height for Drive Test
Model
Height
S0607EⅡ
1.21m
S0808EⅡ
1.31m
S0812EⅡ
1.32m
S1012EⅡ
1.81m
S1212EⅡ
1.94m
S1413EⅡ
2m
8) Press the drive function selector button.
9) Select one point (such as the contact patch of
a tire) on the machine as the visual
inspection reference for the starting line and
the finishing line.

Maintenance Manual of Scissors Mobile Elevating Work Platform
12
10) Drive the machine at maximum speed and
start to count when the reference point
passes the starting line.
11) Keep driving at the full speed and record the
time when the reference point passes the
finishing line. Refer to the specification.
1.9.11 B-11 Low Speed Drive Test
This check shall be made once per 25h or per
month, whichever interval is shorter.
1. Normal drive function is essential to the
proper operation and usage of the machine.
With the drive function, a rapid and stable
response shall be given to the operator. No
delay, vibration and abnormal sound shall
occur during normal operation and drive
process.
2. Complete the driving test on a solid and level
ground without any barriers.
3. Draw two lines10m apart, as the starting line
and the ending line on the ground.
4. Switch the key switch to the platform
controller position and pull out the red
emergency stop buttons from the ground and
platform controllers.
5. Lower the platform to the stowed position.
6. Press the drive speed selector button.
7. Select one point (such as the contact patch of
a tire) from the machine as the visual
inspection reference for the starting line and
the ending line.
8. Drive the machine at maximum speed and
start to count when the reference point
passes the starting line.
9. Keep driving at the full speed and record the
time when the reference point passes the
finishing line. Refer to the specification.
1.9.12 B-12 Visual Inspection of the
Hydraulic Oil
This check item shall be made once every 25
hours of operation or every month, whichever
interval is shorter.
Collect a sample of hydraulic oil and place in a
clear container. Visually inspect the hydraulic oil
for the following:
1) Color: Oil should be a clear, light-honey
colored.
2) Appearance: Oil should be clear and not
cloudy or visibly distorts the view through the
sight glass or container.
3) Contains no particles, foreign objects, or
other contamination.
4) The hydraulic oil can be inspected by smell
(can smell “hot” but not “burnt”) or rubbing
between fingers (should feel viscous and free
of any rough feel due to particles) If the
hydraulic oil passes all of the above
inspections, continue the scheduled
maintenance intervals. If the hydraulic oil fails
any of the above inspections, the hydraulic oil
must be tested by an oil distributor or
replaced.
Note: If the hydraulic oil has not been replaced for
two years, the oil must be tested every quarter by
an oil distributor until the oil fails the test and is
replaced. After the oil has been replaced,
continue the scheduled monthly maintenance
inspection.
