Lian-Li UNI FAN SL-INF User manual

安裝指南
注意!電源⽚分為⼤⼩兩種卡榫 安裝時須注意，
Note! The socket for the power module are in
different size, please be aware of the direction.
Installation Guide /
!
包裝內容物
Package Contents /
⽅向性。
UNI FAN SL-INF
x 1 pc x 1 pc
-
Fixed
Release
1
2
Power Module Installation / 電源⽚安裝
⾵扇扣鎖拆除
注 意!若 遇 到 ⽔ 冷 排 出 ⽔ 位 置 影 響 ⾵ 扇 扣 鎖 可 將 ⾵ 扇，
卡扣鎖移除。
Note! The fan interlocking key is removable if it is
affected by the radiator inlet and outlet.
!
1 2 3
Remove the Fan Interlocking Key /
A 6銅板紙或模糙紙100P單色雙面印刷
G50.1 2 S L I N 1 .00
x 4 pcs
RGB

Fan to Fan Connection /
Steps to Switch Orientation of the Cable on the Power Module /
⾵扇連接⾵扇
電源⽚電線轉換⽅向⽰意
注意!若遇到⽔冷排出⽔位置影響電源⽚上蓋 可將，
上蓋移除 以垂直⽅式⾛線， 。
Note! The top cover is removable if it is affected by the
radiator inlet and outlet, and route the cable vertically.
!
1
2
Fixed
Release
Remove Release
1 2 3
Fixed
4 5 6
Power Module to Motherboard connection / 電源⽚連接主板
Connect to PWM fan header
Connect to 5V ARGB
3 pin header
警告!請不要連接錯誤類型的 LED接頭 如果連接，
到12V接⼝ 將造成永久損壞， 。
Warning! Do not connect the wrong type of LED
connector. If it is connected to the 12 V connector,
permanent damage will occur.
5 V 12 V
!
