Life Fitness C 15 LIFECYCLE Installation guide

Tools Required: Metric Wrench Set, Metric Allen Wrench Set, Phillips Screwdriver
1. Locate and install the two LEVELER FEET (A) to the bottom of the REAR STABILIZER (B).
With the bends facing rearward, attach the REAR STABILIZER (B) to the BASE UNIT (C) using two 50 mm BUTTON HEAD SCREWS (1) from the top of the REAR
STABILIZER BRACKET (D) and two 20 mm BUTTON HEAD SCREWS (2) from the front side of the REAR STABILIZER BRACKET. Tighten the SCREWS securely.
2. Locate the MONOCOLUMN (E). Slide the MONOCOLUMN COVER (F) onto the MONOCOLUMN as shown. Slide the MONOCOLUMN COVER up to the CONSOLE
SUPPORT (G).
With the CONSOLE SUPPORT (G) facing the front of the unit as shown, slide the MONOCOLUMN (E) into the MONOCOLUMN BRACKET (J) of the BASE UNIT (C) .
Slide the MONOCOLUMN down until it is fully seated. Secure the MONOCOLUMN to the MONOCOLUMN BRACKET using two 100 mm HEX HEAD BOLTS (3) and
three THICK FLAT WASHERS (4) (as shown) from the rear side of the MONOCOLUMN. Use two 60 mm HEX HEAD BOLTS (5) and two THICK FLAT WASHERS (4)
from the user left side of the MONOCOLUMN BRACKET. Tighten the BOLTS securely.
CAUTION: Be careful not to pinch the WIRE (K) leading from the MONOCOLUMN BRACKET (J) when inserting the MONOCOLUMN (E) into the MONOCOLUMN
BRACKET.
3. Untape the WIRE TIE (H) attached to the front of the MONOCOLUMN (E). Carefully pull the CONSOLE WIRE (L) through the SIDE ACCESS HOLE (M) of the
MONOCOLUMN (E). Feed the CONSOLE WIRE through the GROMMET (N) as shown and insert the GROMMET into the SIDE ACCESS HOLE.
Connect the WIRE (K) leading from the MONOCOLUMN BRACKET (J) to the corresponding WIRE (L) from the SIDE ACCESS HOLE (M) of the
MONOCOLUMN (E). Slide the MONOCOLUMN COVER (F) downward to the meet the MAIN SHROUDS. Secure the MONOCOLUMN COVER to the MAIN
SHROUDS using four 12 mm PHILLIPS SCREWS (6) and matching FLAT WASHERS (7). Tighten the SCREWS securely. Do not overtighten the SCREWS.
4. Locate the SEAT (O) and SEAT POST (P). Remove the three NYLOCK NUTS (8) and FLAT WASHERS (9) from the threaded studs on the bottom of the SEAT. Align
the threaded studs of the with the mounting holes in the SEAT POST MOUNTING PLATE (Q). Secure the seat to the using the
three previously removed and . Tighten the securely.
Locate the SEAT POST CAP (R). With the curved side facing upward toward the SEAT (O) and the inside notch aligned with the SEAT POST (P) adjustment decal,
slide the SEAT POST CAP over the SEAT POST.
Locate and slide the SEAT POST SPACER (S) over the end of the SEAT POST (P). Be sure the locking tabs fully engage the holes located at the bottom of the
. Secure the
With the nose of the SEAT (O) facing forward, insert the SEAT POST (P) into the SEAT POST SUPPORT (T).
Slide the SEAT POST CAP (R) downward to meet the top of the SEAT POST SUPPORT (T). Secure the SEAT POST CAP to the SEAT POST SUPPORT using two 6
mm PHILLIPS SCREWS (11). Tighten the SCREWS securely. Do not overtighten the SCREWS.
Begin inserting the SEAT ADJUSTMENT KNOB (U). Lift upward on the (O) and SEAT POST (P) until the locks into a position. Tighten the SEAT
ADJUSTMENT KNOB fully. Insert the 6 mm PHILLIPS SCREW W/LOCKING COMPOUND (12) and tighten securely.
A plastic zip-tie has been included to keep the MONOCOLUMN COVER (F) from falling during assembly.
The MONOCOLUMN COVER (F) must slide over the WIRE TIE (H) taped to the front of the MONOCOLUMN (E).
CONSOLE
SEAT SEAT POST MOUNTING PLATE
NYLOCK NUTS FLAT WASHERS NUTS
SEAT
POST SEAT POST SPACER using two 8 mm PHILLIPS SCREWS (10).
SEAT SEAT POST
While holding the CONSOLE WIRE (X) and HEART RATE WIRE (Y), cut the wire tie securing the CONSOLE WIRES to the DISPLAY CONSOLE BRACKET. Feed the
CONSOLE WIRES through the center hole of the ACCESSORY TRAY MOUNTING BRACKET (Z). Secure the ACCESSORY TRAY to the DISPLAY CONSOLE BRACKET
using two 10 mm PHILLIPS SCREWS with WASHERS (13). Tighten the SCREWS securely.
Be careful not to pinch the CONSOLE WIRE (X) and HEART RATE WIRE (Y) when securing the ACCESSORY TRAY (V) to the DISPLAY CONSOLE
BRACKET (W).
Be careful not to let the CONSOLE WIRE (X) and HEART RATE WIRE (Y) fall into the DISPLAY CONSOLE BRACKET (W).
Remove the DISPLAY CONSOLE (AA) from its shipping carton. Position the DISPLAY CONSOLE above the ACCESSORY TRAY (V). Connect the CONSOLE WIRE (X),
HEART RATE WIRE (Y) (RED), and GROUND WIRE (BB) (GREEN) to the corresponding JACKS located on the back of the DISPLAY CONSOLE. Secure the DISPLAY
CONSOLE to the DISPLAY CONSOLE BRACKET (W) using four 12 mm PHILLIPS SCREWS (6) and WASHERS (7). Tighten the SCREWS securely. Do not overtighten
the SCREWS.
NOTE:
NOTE:
5.
CAUTION:
NOTE:
C3-5 Only: Locate the ACCESSORY TRAY (V). Position the ACCESSORY TRAY near the top of the MONOCOLUMN (E) at the DISPLAY CONSOLE BRACKET (W).
Item Qty Description
C15C351) 2)
3)
5) 6)
4)
7)
8) 9)
11) 12)
C1 C3& Upright Bikes55
Hardware List
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
2
2
2
5
2
10
8
3
3
2
2
1
4
4
2
2
2
5
2
8
8
3
3
2
2
1
2
4
4
50 mm Button Head Screw
Button Head Screw
Hex Head Bolt
Thick Flat Washer - 16 mm O.D.
Hex Head Bolt
Small Head Phillips Screw
Flat Washer - 12 mm O.D.
Nylock Nut (on seat)
Flat Washer (on seat)
Phillips Screw
Phillips Screw
Phillips Screw
w/Locking Compound
Phillips Screw w/Washers
Button Head Screw
Flat Washer - 18 mm O.D.
20 mm
100 mm
60 mm
12 mm
8mm
6mm
6mm
10 mm
15 mm
Assembly Guide:
Look for the number coded
hardware bags that match the
assembly sequence.
Q
9
8
O
P
R
11
10
12
T
U
1
D
2
AB
C
AA
V
CC
14
15
6
W
Z
13
DD
FF
EE
GG
6
E
HH
JJ
securing the CONSOLE WIRE to the DISPLAY CONSOLE BRACKET (W). Position the DISPLAY CONSOLE above the DISPLAY CONSOLE BRACKET. Connect
the CONSOLE WIRE and HEART RATE WIRE to the corresponding JACKS located on the back of the DISPLAY CONSOLE. Secure the DISPLAY CONSOLE to the
DISPLAY CONSOLE BRACKET using four 12 mm PHILLIPS SCREWS (6) and WASHERS (7). Tighten the SCREWS securely. Do not overtighten the SCREWS.
Be careful not to let the CONSOLE WIRE (X) and HEART RATE WIRE (Y) fall into the DISPLAY CONSOLE BRACKET (W).
Connect the WIRES (DD) leading from the HANDLEBAR ASSEMBLY and the MONOCOLUMN. Slide the HANDLEBAR ASSEMBLY fully into the MONOCOLUMN.
Secure the HANDLEBAR ASSEMBLY to the MONOCOLUMN using four 15 mm BUTTON HEAD SCREWS (14) and matching FLAT WASHERS (15). Tighten the
SCREWS securely.
Be careful not the pinch the WIRES (DD) when sliding the HANDLEBAR ASSEMBLY (CC) into the MONOCOLUMN (E).
Locate the RIGHT PEDAL (EE) (marked with an "R") and PEDAL STRAP (FF) (marked with an "R"). With the side of the PEDAL STRAP marked with an “R” facing
upward, slide the slotted end of the PEDAL STRAP through the left slot in the PEDAL. Fasten one of the slots onto the tab located under the left slot of the
PEDAL. Bend the PEDAL STRAP upward and slide the remaining end of the PEDAL STRAP through the right slot in the PEDAL and into the strap adjustment clip.
The PEDAL STRAP should securely engage the strap adjustment clip.
Install the RIGHT PEDAL (EE) to the USER RIGHT CRANK ARM (GG). Repeat for the LEFT PEDAL (marked with an "L") and PEDAL STRAP (marked with an "L").
The LEFT PEDAL has reverse threads.
Pedals need to be securely tightened or clicking may occur.
Locate the WATER BOTTLE BRACKET (HH). Secure the WATER BOTTLE BRACKET to the underside of the MONOCOLUMN (E) using two 12 mm
PHILLIPS SCREWS (6). Tighten the screws securely. Insert the WATER BOTTLE (JJ) into the WATER BOTTLE BRACKET.
Position the unit in the desired location for use. The unit can be easily moved into place by lifting the rear of the unit and rolling it on the front rollers. Level the unit
before use. Refer to the leveling instructions stated in the Operation Manual.
C1-5 Only: Remove the DISPLAY CONSOLE (AA) from its shipping carton. While holding the CONSOLE WIRE (X) and HEART RATE WIRE (Y) (RED), cut the wire
tie
Locate the HANDLEBAR ASSEMBLY (CC). With the handlebars facing forward, position the HANDLEBAR ASSEMBLY near the top of the MONOCOLUMN (E).
NOTE:
6.
CAUTION:
7.
NOTE:
NOTE:
8. C1-5 Only:
1. 7.
5.&6.
8. (C15 Only)
Assembly Sequence
Monocolumn, Wiring & Cover
Rear Stabilizer
4.
Seat & Seat Post Pedals
Accessory Tray, Console &
Handlebar
Water Bottle & Bracket
6 7
N
LE
F
4 K
J4
3
5
M
G
H
13)
14) 15)
6) 7)
10 706020 8030 9040 100 12050 110 130 140 150 160
7
10)
S
2.&3.
XBB Y
X YBB

© 2005 Life Fitness, a division of Brunswick Corporation. All rights reserved. Life Fitness is a registered trademarks of Brunswick
Corporation. Any use of this trademark, without the express written consent of Life Fitness is forbidden. 7903401 RevB (05/05)
