Life Fitness Signature Series SADB User manual

SIGNATURE SERIES
SADB
Customer Support Services
PARTS LIST
Page 1
SIGNATURE ADJUSTABLE DECLINE BENCH

Page 2
CONTENTS
________________________________________
SADB SIGNATURE ADJUSTABLE DECLINE BENCH
________________________________________
NOTE: SUBSTITUTE PART NUMBERS ENDING
WITH ‘XX’ WITH THE REQUIRED COLOR CODES.
01 = WHITE
FRAME PADS
02 = PLATINUM
03 = BLACK
01 = BLACK
99 = CUSTOM
PAGE
COMPONENT ASSEMBLY 3
COMPONENT ASSEMBLY LEGEND 4
BASE FRAME ASSEMBLY 5
BACK ASSEMBLY 6
BACK ASSEMBLY LEGEND 7
BASE ASSEMBLY 8
SEAT ADJUST ASSEMBLY 9
IMAGE 10

COMPONENT ASSEMBLY
________________________________________
Page 3
SEE PAGE 4 FOR LEGEND
SADB SIGNATURE ADJUSTABLE DECLINE BENCH
9
717
8
6
14
3
13
2
12
1
11
19
5
4
16
15
18
10

Page 4
________________________________________
COMPONENT ASSEMBLY LEGEND
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 82390XX PTD ASSY, SADB, BASE FRAME
2 1 82374XX PTD ASSY, SADB, BACK FLOV
3 1 82377XX PTD ASSY, SADB, BASE
4 1 82463XX PTD ASSY, SADB, SEAT ADJ
5 2 3256205 SCREW, M10 X 1.5 40MM ZN
6 10 3256202 SCREW, M10 X 1.5 25MM ZN
7 5 3256204 SCREW, M10 X 1.5 35MM ZN
8 7 3237403 PLUG, 1" HOLE
9 2 3242002 NUT, M10 X 1.5 HEX NYLOCK
10 4 74247XX ASSY, ROLLER PAD SHORT
11 1 78219XX PAD, HEAD REST, FLAT
12 13 3102514 WASHER, FLAT 3/8" SAE ST ZN
13 2 8239501 SHAFT, 0.75" OD X 4.82"
14 4 7308701 CAP, BEARING HOUSING
15 4 7322301 PLATE, 1.97 OD X .447 ID 10GA
16 2 8140201 SPACER, 0.94 OD X .42 ID X 1" LONG
17 1 8140101 SHAFT; PIVOT, SMAB
18 1 8137801 DECAL, WARNING, VERT, MULTI-LANG SHT, BNR
19 1 78218XX PAD, 36 X 11 FLAT
SADB SIGNATURE ADJUSTABLE DECLINE BENCH

Page 5
BASE FRAME ASSEMBLY - 82390XX
________________________________________
SADB SIGNATURE ADJUSTABLE DECLINE BENCH
8
9
7
6
5
4
3
2
1
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 82393XX WLDMT, SADB, BASE SPRT
2 2 7800401 CAP; LRG FLOV END
3 2 7810801 PAD, RUBBER FOOT, 10-0101-006, BNR
4 8 3114407 WASHER, FLAT #10 SAE ST BZ
5 20 3239102 SCREW, M5 X .8 X 12 PHL PAN TT ST BZ
6 4 3232405 RNG, BRE .352,5100-37,ST,PP,B
7 2 7656301 WHEEL, 2 OD X 3/8 ID RUBBER
8 2 7705302 AXLE, WHEEL
9 2 7821702 GUARD, PAINT, LONG, 10-0115-0009, BNR

Page 6
________________________________________
BACK ASSEMBLY - 82374XX
SEE PAGE 7 FOR LEGEND
SADB SIGNATURE ADJUSTABLE DECLINE BENCH
4
5
11
10
10
1
3
9
8
6
7
8
6
2

Page 7
________________________________________
BACK ASSEMBLY LEGEND
SADB SIGNATURE ADJUSTABLE DECLINE BENCH
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 82373XX WLDMT, SADB, BACK FLOV
2 4 3114407 WASHER, FLAT #10 SAE ST BZ
3 2 7800401 CAP; LRG FLOV END
4 1 7810801 PAD, RUBBER FOOT, 10-0101-006, BNR
5 4 3239102 SCREW, M5 X .8 X 12 PHL PAN TT ST BZ
6 2 7662901 CAP, GRIP 1.25 OD
7 1 7662801 RING, GRIP 1.25 OD
8 6 3247701 M4 X 0.7 X 3 HZS NO CUP ST BO
9 2 3104901 BEARING, FLG .75 ID X 1.00 OD
10 2 3235801 GRIP, 1.25 OD X .125 WALL OPEN END
11 4 7357901 COLLAR, SHAFT 1.53 ID ALUM

________________________________________
BASE ASSEMBLY - 82377XX
Page 8
SADB SIGNATURE ADJUSTABLE DECLINE BENCH
2
7
8
6
3
4
5
1
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 82377XX PTD ASSY, SADB, BASE
2 1 8106101 LABEL LIFE FIT 13/16 X 4-3/8" SG, 10-0101-016, BNR
3 1 7002401 LABEL; V WARNING 4.5 X 1.625
4 1 8106801 LABEL, SERIAL NUMBER, LARGE, 10-0123-001, BNR
5 1 7800401 CAP; LRG FLOV END
6 1 7810801 PAD, RUBBER FOOT, 10-0101-006, BNR
7 4 3239102 SCREW, M5 X .8 X 12 PHL PAN TT ST BZ
8 4 3114407 WASHER, FLAT #10 SAE ST BZ

Page 9
________________________________________
SEAT ADJUST ASSEMBLY - 82463XX
SADB SIGNATURE ADJUSTABLE DECLINE BENCH
5
9
7
2
4
1
3
8
6
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 82397XX WLDMT, SADB, SELECTOR TUBE
2 1 82463XX PTD ASSY, SADB, SEAT ADJ
3 4 3104901 BEARING, FLG .75 ID X 1.00 OD
4 1 7351501 SPRING; PULL PIN LARGE
5 2 8039501 LABEL, WARNING, TRIANGLE, 10-0099-067, BNR
6 2 8087201 BUSHING, SLIP TUBE, PLASTIC, 55.3MM OD X 45.2MM ID, BNR
7 1 7351302 PIN, PULL X 3.375
8 1 3251702 M10 X 1.5 25 HXS SOC CS ST ZN
9 1 7351401 KNOB, TULIP STYLE

Page 10
________________________________________
SADB SIGNATURE ADJUSTABLE DECLINE BENCH
