Life Fitness Signature Series CMDAP User manual

Signature Series Cable Motion
CMDAP Dual Adjustable Pulley
Parts List
CUSTOMER SUPPORT SERVICES
SERIAL NUMBER CMDAP0908041 & UP

CMDAP DUAL ADJUSTABLE PULLEY
Page 2
CONTENTS
________________________________________
PAGE
COMPONENT ASSEMBLY 3
COMPONENT ASSEMBLY LEGEND 4
RIGHT HAND TOWER ASSEMBLY 5
RIGHT HAND TOWER ASSEMBLY LEGEND 6
RIGHT HAND CARRIAGE ASSEMBLY 7
ADJ. PULLEY COLUMN ASSEMBLY 8
CHIN SUPPORT ASSEMBLY 9
OPTIONAL NOHANDLE BOOM 10
REAR SUPPORT ASSEMBLY 11
LEFT HAND TOWER ASSEMBLY 12
LEFT HAND TOWER ASSEMBLY LEGEND 13
LEFT HAND CARRIAGE ASSEMBLY 14
STACK PULLEY ASSEMBLY 15
390LB. WEIGHT STACK ASSEMBLY 16
LONG BAR ASSEMBLY 17
SPORT BAR ASSEMBLY 18
ACCESSORIES 19
OPTIONAL FRONT SHROUD KIT 20
IMAGE 21

COMPONENT ASSEMBLY
Page 3
SEE PAGE 4 FOR LEGEND
________________________________________
CMDAP DUAL ADJUSTABLE PULLEY
3
2
7
8
5
6
9
10
1
4
11
3

Page 4
________________________________________
COMPONENT ASSEMBLY LEGEND
CMDAP DUAL ADJUSTABLE PULLEY
ITEM NO QTY PART NO DESCRIPTION
1 1 7714201 ASSY, CMDAP RH TOWER
2 1 7714301 ASSY, CMDAP LH TOWER
3 1 7713901 ASSY, CMDAP CHIN SUPPORT
OR
3 1 8539101 ASSY, CMDAP BOOM - NOHANDLES
4 2 7714101 ASSY, CMDAP REAR SUPPORT
5 12 3236220 M10 X 1.5 X 130 HXS SOC CS SS
6 12 7630101 RETAINER, CM/MJ, PULLEY
7 12 7335401 NUT, SOCKET HEAD M10 X 1.5 SS
8 12 7634701 SPACER, CM/MJ, .565 X .815
9 1 7571301 LABEL, SERIAL NUMBER
10 1 7422004 LABEL, 2IN ASTM WARN
11 2 3250201 SNAP LINK, 3/8" DIA

Page 5
SEE PAGE 6 FOR LEGEND
RIGHT HAND TOWER ASSEMBLY - 7714201
________________________________________
CMDAP DUAL ADJUSTABLE PULLEY
1
2
3
4
5
6
7
8
9
9
10
11
12
13
14
15
16
18
19
18
20
21
22
23
24
25
26
32
33
27
16
28
29
30
31
34
35
36
37
38
39
11
15
20
17
19
17
24
920
20
15

Page 6
________________________________________
CMDAP DUAL ADJUSTABLE PULLEY
RIGHT HAND TOWER ASSY. LEGEND
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7642401 WLDMT, CMDAP RH TOWER
2 1 7708401 ASSY, CM/MJ, ADJ PLLY COLUMN
3 1 8346801 ASSY, CMDAP RH CARRIAGE
4 1 7645702 CABLE, MJDAP
5 1 7353601 ASSY, 390LB STACK
6 1 7750701 ASSY, CMDAP STACK PULLEYS
7 1 7749301 WLDMT, CM/MJ, PLACARD BRKT-2
8 2 7730901 BRKT, COVER/CABLE RETAINER
9 7 3237801 PULLEY, 4.5" OD
10 1 7333901 CAP, LARGE FLOV- END
11 6 7630001 COVER, PULLEY BOLTED PARTIAL
12 2 7629901 COVER, PULLEY- BOLTED FULL
13 1 7732401 BRKT, STACK BUMPER MOUNT
14 1 7642301 BUMPER, CM/MJ, PLUG
15 8 7630101 RETAINER, CM/MJ, PULLEY
16 3 3236206 SCREW, M10 X1.5 45MM
17 2 3236209 SCREW, M10 X1.5 60MM
18 6 3236601 WASHER, 3/8 SAE SS
19 5 3236801 NUT, M10 HEX NYLOCK SS
20 8 7335401 NUT, M10 X 1.5 SOCKET HEAD
21 4 3236207 SCREW, M10 X1.5 50MM
22 1 7301101 PLATE, PULLEY
23 8 7642001 BRKT, CM/MJ, REAR SHROUD
24 22 3239101 SCREW, M5X10 PHL PAN TT ST
25 1 7642101 SHIELD, CM/MJ REAR
26 8 7385201 SPACER, .406 X .750 X .250
27 8 3236201 SCREW, M10 X1.5 20MM
28 1 3236902 NUT, M16 X 2 HEX JAM SS
29 1 7749401 LABEL, PLACARD CMDAP RH
30 2 3240502 M10 X 1.5 X 50 HXS NO CUP ST BO
31 2 7634401 RETAINER, CM/MJ, GUIDEROD
32 2 7352101 CUSHION, WEIGHT STACK
33 2 7328618 GUIDE ROD, .75 OD SOLID 71.50
34 2 3232421 RING, BRE .940, 5100-100 ST PP B
35 2 7334001 FOOT, 2.50 X 4.49 FLOV
36 4 3251202 SCREW, M10 X1.5 X 25MM UNS HEX CS ST ZN
37 2 7340201 COVER, FOOT - STRAIGHT
38 1 7348001 LABEL, LIFE FITNESS LOGO
39 1 7744501 LABEL, WEIGHT AT HANDLE

1
2
9
5
12
13
3
417
6
16
15
8
7
10
8
811
14
10
18
19
20
Page 7
RIGHT HAND CARRIAGE ASSEMBLY - 8346801
________________________________________
CMDAP DUAL ADJUSTABLE PULLEY
ITEM NO. QTY. PART NO. DESCRIPTION ITEM NO. QTY. PART NO. DESCRIPTION
1 3 7637901 ASSY, ROLLER-CONCAVE 11 4 3239101 SCREW, M5X10 PHL PAN TT ST
2 1 8327901 ASSY, CM/MJ PULL PIN, BEVEL NOSE 12 1 3237801 PULLEY, 4.5" OD
3 1 7351501 SPRING, PULL PIN LARGE 13 1 3245701 PULLEY, 3.5" OD, 10MM ID SG
4 1 7351401 KNOB, TULIP STYLE 14 3 3236216 SCREW, M10 X1.5 95MM
5 1 7645401 SHAFT, CM/MJ, 6203 BRNG 15 2 3236206 SCREW, M10 X1.5 45MM
6 2 3245901 BEARING, 6203 16 1 8039501 LABEL, WARNING,TRIANGLE
7 2 3232413 RING, BRE .631, 5100-66, ST PP B 17 1 7821001 LABEL, WARNING ADJ. CARRIAGE
8 12 3236601 WASHER, 3/8 SAE SS 18 1 8346901 WLDMT, CMDAP RH CARRIAGE
9 1 3236217 SCREW, M10 X1.5 100MM 19 1 7633301 WLDMT, CM/MJ, SWIVEL PULLEY
10 6 3236801 NUT, M10 HEX NYLOCK SS 20 1 7631801 BRKT, CM/MJ, CARRIAGE SHROUD

3
6
5
2
1
4
Page 8
ADJ. PULLEY COLUMN ASSEMBLY - 7708401
________________________________________
CMDAP DUAL ADJUSTABLE PULLEY
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 8264101 TUBE, CM/MJ ADJ COLUMN
2 4 7645501 SPACER, CM/MJ, SM FLOV CONCAVE
3 2 7630101 RETAINER, CM/MJ, PULLEY
4 2 3236215 SCREW, M10 X1.5 90MM
5 2 7335401 NUT, M10 X 1.5 SOCKET HEAD
6 1 7333801 CAP, SMALL FLOV- END

3
3
3
2
2
21
1
1
4
5
Page 9
________________________________________
CMDAP DUAL ADJUSTABLE PULLEY
CHIN SUPPORT ASSEMBLY - 7713901
ITEM NO. QTY. PART NO. DESCRIPTION
1 6 3235801 GRIP, 1.25 OD X .125 WALL OPEN END
2 6 7662901 CAP, GRIP 1.25 OD
3 6 7662801 RING, GRIP 1.25 OD
4 24 3247701 M4 X .7 HXS NO CUP ST BO
5 1 7642701 WLDMT, CMDAP CHIN SUPPORT

Page 10
OPTIONAL NO HANDLE BOOM ASSY. - 8539101
________________________________________
CMDAP DUAL ADJUSTABLE PULLEY
1
7
5
5
2
2
4
3
6
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 8539001 WLDMT, CMDAP BOOM - NOHANDLES
2 4 7630101 RETAINER, CM/MJ, PULLEY
3 2 3236220 SCREW, M10 X1.5 130MM
4 2 3236221 SCREW, M10 X1.5 140MM
5 4 7634701 SPACER, CM/MJ, .565 X .815
6 2 7335401 NUT, M10 X 1.5 SOCKET HEAD
7 2 3236801 NUT, M10 HEX NYLOCK SS

1
2
34
5
6
Page 11
________________________________________
REAR SUPPORT ASSEMBLY - 7714101
CMDAP DUAL ADJUSTABLE PULLEY
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7642601 WLDMT, CMDAP REAR SUPPORT
2 1 7644895 WLDMT, CM ACC RACK
3 2 3236601 WASHER, 3/8 SAE SS
4 2 3236212 SCREW, M10 X1.5 75MM
5 2 7335401 NUT, M10 X 1.5 SOCKET HEAD
6 3 7749601 SLEEVE, .50" ID X 2.25"

Page 12
________________________________________
LEFT HAND TOWER ASSEMBLY - 7714301
CMDAP DUAL ADJUSTABLE PULLEY
1
2
3
4
5
6
7
8
9
9
10
11
11
12
13
14
15
16
17
18
19
20
20
20
21
22
23
24
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
18
19
15
21
17
17
SEE PAGE 13 FOR LEGEND

Page 13
________________________________________
LEFT HAND TOWER ASSEMBLY LEGEND
CMDAP DUAL ADJUSTABLE PULLEY
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7642501 WLDMT, CMDAP LH TOWER
2 1 7708401 ASSY, CM/MJ, ADJ PLLY COLUMN
3 1 8346601 ASSY, CMDAP LH CARRIAGE
4 1 7645702 CABLE, MJDAP
5 1 7353601 ASSY, 390LB STACK
6 1 7750701 ASSY, CMDAP STACK PULLEYS
7 1 7647001 WLDMT, CM/MJ, PLACARD BRKT
8 2 7730901 BRKT, COVER/CABLE RETAINER
9 7 3237801 PULLEY, 4.5" OD
10 1 7333901 CAP, LARGE FLOV- END
11 6 7630001 COVER, PULLEY BOLTED PARTIAL
12 2 7629901 COVER, PULLEY- BOLTED FULL
13 1 7732401 BRKT, STACK BUMPER MOUNT
14 1 7642301 BUMPER, CM/MJ, PLUG
15 8 7630101 RETAINER, CM/MJ, PULLEY
16 3 3236206 SCREW, M10 X1.5 45MM
17 2 3236209 SCREW, M10 X1.5 60MM
18 6 3236601 WASHER, 3/8 SAE SS
19 5 3236801 NUT, M10 HEX NYLOCK SS
20 8 7335401 NUT, M10 X 1.5 SOCKET HEAD
21 4 3236207 SCREW, M10 X1.5 50MM
22 1 7301101 PLATE, PULLEY
23 8 7642001 BRKT, CM/MJ, REAR SHROUD
24 22 3239100 SCREW, M5X.8 PHL PAN TT ST BZ
25 1 7642101 SHIELD, CM/MJ REAR
26 8 7385201 SPACER, .406 X .750 X .250
27 8 3236201 SCREW, M10 X1.5 20MM
28 1 3236902 NUT, M16 X 2 HEX JAM SS
29 1 7749501 LABEL, PLACARD CMDAP LH
30 2 3232421 RING, BRE .940, 5100-100 ST PP B
31 2 7352101 CUSHION, WEIGHT STACK
32 2 7328618 GUIDE ROD, .75 OD SOLID 71.50
33 2 7634401 RETAINER, CM/MJ, GUIDEROD
34 2 3240502 M10 X 1.5 X 50 HXS NO CUP ST BO
35 2 7334001 FOOT, 2.50 X 4.49 FLOV
36 2 7340201 COVER, FOOT - STRAIGHT
37 1 7348001 LABEL, LIFE FITNESS LOGO
38 1 7744501 LABEL, WEIGHT AT HANDLE
39 4 3251202 SCREW, M10 X1.5 X 25MM HEX CS ST ZN

Page 14
LEFT HAND CARRIAGE ASSEMBLY - 8346601
________________________________________
CMDAP DUAL ADJUSTABLE PULLEY
3
18
20
19
1
7
2
4
5
6
10
9
8
8
12
13
13
11
14
17
16
15
ITEM NO. QTY. PART NO. DESCRIPTION ITEM NO. QTY. PART NO. DESCRIPTION
1 3 7637901 ASSY, ROLLER-CONCAVE 11 1 7351401 KNOB, TULIP STYLE
2 1 7645401 SHAFT, CM/MJ, 6203 BRNG 12 2 3245901 BEARING, 6203
3 4 3239101 SCREW, M5X10 PHL PAN TT ST 13 12 3236601 WASHER, 3/8 SAE SS
4 1 3237801 PULLEY, 4.5" OD 14 1 3236217 SCREW, M10 X1.5 100MM
5 1 3245701 PULLEY, 3.5" OD, 10MM ID SG 15 2 3236206 SCREW, M10 X1.5 45MM
6 2 3232413 RING, BRE .631, 5100-66, ST PP B 16 1 8039501 LABEL, WARNING,TRIANGLE
7 3 3236216 SCREW, M10 X1.5 95MM 17 1 7821001 LABEL, WARNING ADJ. CARRIAGE
8 6 3236801 NUT, M10 HEX NYLOCK SS 18 1 8346701 WLDMT, CMDAP LH CARRIAGE
9 1 7351501 SPRING, PULL PIN LARGE 19 1 7633301 WLDMT, CM/MJ, SWIVEL PULLEY
10 1 8327901 ASSY, CM/MJ PULL PIN, BEVEL NOSE 20 1 7631801 BRKT, CM/MJ, CARRIAGE SHROUD

STACK PULLEY ASSEMBLY - 7750701
________________________________________
CMDAP DUAL ADJUSTABLE PULLEY
Page 15
3
2
7
1
6
5
4
4
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7644001 WLDMT, HEAD PLATE DBL PULLEY
2 2 3237801 PULLEY, 4.5" OD
3 1 3236801 NUT, M10 HEX NYLOCK SS
4 2 3236601 WASHER, 3/8 SAE SS
5 1 3236213 SCREW, M10 X1.5 80MM
6 1 3236902 NUT, M16 X 2 HEX JAM SS
7 1 7385201 SPACER, .406 X .750 X .250

390 LB. WEIGHT STACK ASSEMBLY - 7353601
________________________________________
CMDAP DUAL ADJUSTABLE PULLEY
Page 16
3
5
1
2
7
8
9
4
5
10
WEIGHT PLATE LABELS
PART NO. DESCRIPTION
8068701 LABEL, WGHT STK, 97.5 LBS
8069301 LABEL, WGHT STK, 48.75 KG
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7353901 HEADPLATE, WT. STACK
2 1 7356601 STEM, PRO2 19 HOLE
3 19 7328401 WEIGHT PLATE, 20 LB
4 1 3236001 BUSHING, SPRING PIN
5 2 7338001 BUSHING, HEADPLATE
7 1 7353001 ASSY, SELECTOR PIN
8 1 7356501 PLUG, LANYARD ATTACHMENT
9 1 7523601 CRIMP, CABLE
10 1 7711501 WEIGHT, 5 LB. ADD-ON

LONG BAR ASSEMBLY - 7753101
________________________________________
CMDAP DUAL ADJUSTABLE PULLEY
Page 17
3
3
2
5
6
7
8
1
4
4
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7760995 TUBE, 1.00 OD 10GA X 44
2 2 7760695 WLDMT, LONG BAR SWIVEL
3 4 7435301 COLLAR, SHAFT 1.020 ID
4 4 3104906 1.00" ID 1.25" OD BRONZ BUSHING
5 2 3235801 GRIP, 1.25 OD X .125 WALL OPEN END
6 2 7662801 RING, GRIP 1.25 OD
7 4 3247701 M4 X .7 HXS NO CUP ST BO
8 2 3119304 CAP, END 1 DIA RD 10-12GA

SPORT BAR ASSEMBLY - 7753201
________________________________________
CMDAP DUAL ADJUSTABLE PULLEY
Page 18
3
2
5
6
1
4
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7760395 WLDMT, SPORT BAR
2 1 3235801 GRIP, 1.25 OD X .125 WALL OPEN END
3 1 7662801 RING, GRIP 1.25 OD
4 1 7662901 CAP, GRIP 1.25 OD
5 4 3247701 M4 X .7 HXS NO CUP ST BO
6 1 3119304 CAP, END 1 DIA RD 10-12GA

ACCESSORIES
________________________________________
CMDAP DUAL ADJUSTABLE PULLEY
Page 19
ITEM NO. QTY. PART NO. DESCRIPTION
1 2 8219601 HANDLE, CM/MJ, SHORT STRAP
2 1 6851501 ROPE, TRICEP
3 1 7753001 LE/LC STRAP
4 1 7752901 TRAINING BELT (NO LONGER AVAILABLE)
5 1 7734701 STRAP, 4-WAY ANKLE
6 2 8219701 HANDLE, CM/MJ, LONG STRAP
7 1 7762301 POSTER, CMDAP INSTRUCTIONAL
8 1 7730801 CD-ROM, CMDAP/CMCC
1
23
CMDAP INSTRUCTIONAL POSTER
7
4
568

32
6
5
4
1
OPTIONAL FRONT SHROUD KIT - 7766701
________________________________________
CMDAP DUAL ADJUSTABLE PULLEY
Page 20
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7763695 BRKT, SHROUD, CM/MJ BOTTOM SG
2 1 7763795 BRKT, SHROUD, CMDAP TOP SG
3 4 3238601 M10X1.5 BLIND THREADED INSERT (HEX)
4 2 7634001 SHROUD, CM/MJ FRONT
5 4 3236601 WASHER, 3/8 SAE SS
6 4 3236201 SCREW, M10 X1.5 20MM
