Life Smart ZCFP2042US User manual

Questions, problems, missing parts? Contact technical support department at
657-341-0362, 8:00 a.m. - 5 p.m., CST, Monday - Friday or visit us online at
www.lifesmartcomfort.com
Please have your model and serial number ready
1
ATTACH YOUR RECEIPT HERE
Purchase Date ____________Serial Number (located on back of unit) __________________
lifesmart® is a registered trademark of
Supply Chain Sources LLC., All Rights Reserved.
REV1-080317
INFRARED QUARTZ
FIREPLACE
Customer number:
ZCFP2042US

2
TABLE OF CONTENTS
Package Contents ............................................................... 3
Safety Information .............................................................. 4
Frequently Asked Questions ...................................................... 6
Preparation .................................................................... 8
Troubleshooting ................................................................ 8
Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Remote Control ................................................................ 10
Operating Instructions .......................................................... 11
Care and Maintenance .......................................................... 13
One-Year Limited Warranty ...................................................... 14
Replacement Parts List ......................................................... 15

3
PACKAGE CONTENTS
B
AC
D
E
PART DESCRIPTION QUANTITY
A Infrared Heater 1
B Remote Control 1
C Control Panel (preassembled to Infrared Heater (A)) 1
D Temperature Sensor (preassembled to Infrared Heater (A)) 1
E 3-prong Power Cord (preassembled to Infrared Heater (A)) 1

4
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate, or install the product.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: POTENTIAL ELECTRICAL HAZARD IF NOT ADHERED TO. When using electrical
appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and
injury to persons, including the following:
• This heater must be plugged into a 120 V, 15 amp (or more) circuit of its own. Do not plug anything
else into the same circuit. If unsure if your home meets this specification, consult a certified
electrician prior to use. Risk of fire, overheating, malfunction, property damage, injury, or even
death may result if not adhered to!
• Connect to a properly grounded, 3-prong outlet only. Do not connect the heater to extension cords,
surge protectors, timers, direct breakers, or an outlet with other appliances connected to the same
outlet. Risk of fire, overheating, malfunction, property damage, injury, or even death may result
if not adhered to!
• This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. Use handles
(certain models) or wheels to move this heater.
• Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at
least 3 ft. (0.9 m) from the front of the heater and keep them away from the sides and rear of the
heater.
• Extreme caution is necessary when any heater is used by or near children, invalids, pets, or when
the heater is left operating unattended.
• Always unplug the heater when not in use.
• Do not operate any heater with a damaged cord or plug or after the heater malfunctions, has been
dropped, or damaged in any manner. Contact the manufacturer for resolution options.
• Do not use outdoors. Exposure to outdoor elements such as rain, snow, sun, wind, or extreme
temperatures may cause the heater to become a safety hazard.
• This heater is not intended for use in bathrooms, laundry areas, and similar indoor locations, nor
any locations that use GFCI outlets.
• Never place the heater where it may fall into a bathtub or other water receptacles.
• Do not run the cord under carpet. Do not cover the cord with throw rugs, runners, or similar
coverings. Arrange the cord away from traffic areas and where it will not be tripped over.
• The heater must be plugged into a wall outlet that is a dedicated circuit with a minimum 15 amp
rating on that individual circuit.
• To disconnect the heater, first turn the power button to the OFF position and then remove the plug
from the wall outlet.
• Do not allow foreign objects to enter or block any ventilation or exhaust opening as this may cause
electric shock, fire, or damage the heater.
• Allow at least 3 ft. of unobstructed space to the front and rear of the heater to allow for maximum
heat, air, and ventilation flow.
• A heater has hot and arcing or sparking parts inside. Do not use it in areas where gasoline, paint,
or flammable liquids are used or stored, nor use flammable solvents to clean the heater. Keep the
heater dry at all times.
• Use this heater only as described in this manual. Any other use not recommended by the
manufacturer may cause fire, electric shock, or injury to persons.
• Do not use abrasive solvents to clean the heater as it may cause damage to the finish or casing.
• To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not use on soft
surfaces, like a bed, where opening may become blocked.
• Always plug heaters directly into a wall outlet/receptacle. Never use with an extension cord or
relocatable power tap (outlet/power strip).
SAVE THESE INSTRUCTIONS

5
SAFETY INFORMATION
Child Lock Safety Feature
Press and hold the child lock button located on the control panel for 5 seconds or
remote control for 3 seconds. Locking is confirmed when a buzzer rings and the
control panel displays “CL”. When locked, the control panel and remote control (if
provided) will not function.
To unlock the control panel or remote (if provided), repeat this procedure.
Unlocking is confirmed when a buzzer rings and the lock indication disappears.
Tip-Over Safety Feature
This heater is equipped with a tip-over safety feature. Once the heater is tipped over, an internal switch
will automatically shut the heater off. Once the heater is restored to an upright position, the heater will
reset. To continue operation, turn on the heater using the control panel or supplied remote control (if
provided) on the heater.
Overheat Safety Feature
This heater is equipped with an overheat safety feature. When the internal components of the heater
reach a certain temperature that could cause overheating or possible fire, the heater will automatically
shut off. If the unit has been overheated, you will need to unplug the unit from the wall and replug it in
to use the heater again.
WARNING: This heater has a voltage rating of
120 volts. The cord has a three-blade, grounding-
type plug. An adapter is available for connecting
three-blade grounding-type plugs to two-slot
receptacles. The grounding lug extending from
the adapter must be connected to a permanent
ground such as a properly grounded outlet box.
The adapter should not be used if a three-slot
grounded receptacle is available.
DO NOT DEFEAT THE SAFETY PURPOSE OF THE
GROUNDED PLUG.
Grounding Pin
Grounding Means
Grounding Pin
Metal Screw
Cover of Grounded
Outlet Box
WARNING: It is normal for the power cord to feel warm to the touch. However, a loose fit between
the outlet and the plug may cause overheating of the plug. If this occurs, try inserting the plug into a
different outlet. Contact a qualified electrician to inspect the original outlet for damage.
Specifications
Voltage Rating 120 V (60 Hz)
Power Consumption 1,000 W/1,500 W
Unit Size 28.5 in. (W) x 11.0 in. (D) x 21.7 in. (H)
Unit Weight 44.3 lbs.

6
FREQUENTLY ASKED QUESTIONS
Please review these frequently asked questions on the next few pages prior to using your heater.
Q. My heater emits a strange odor when I first open the box and when I turn the heater on for the first
time. Why is this happening?
A. This is normal. This heater is treated with a special heat safe/resistant coating. This odor will
sometimes be present when the box is opened. When the coating is exposed to heat, it produces this
particular odor during the first few hours of operation. This will dissipate after the break-in period. If
you are sensitive to odors, you may want to pre-burn the unit in a garage with the door open until the
initial odor dissipates.
Q. If my heater runs on its max wattage setting, how many BTUs is that?
A. This heater is intended to be used as supplemental heat in areas most needed. It may take several
minutes to several hours to heat your area, depending on various factors. The below chart provides BTU
translations for different wattages.
WATTAGE BTUS
1,500 5,118
1,000 3,412
750 2,559
500 1,706
Q. Can the heating elements be replaced?
A. Replacement heating elements can be obtained from the manufacturer. All parts may be purchased
through the manufacturer if your product is out of warranty. If you feel that the elements are definitely
faulty right out of the box, contact Customer Support. A representative can then direct you to the next
step.
Q. Once I plug the unit in and turn it on, how long will it take to heat my room?
A. The heating process in the heater begins immediately upon powering on and setting the desired
temperature above the ambient temperature. A noticeable change in the ambient temperature of the
room will vary due to variables such as the location of the heater (in the home), floor plan and size of
the room, how well the room is insulated, how many doors/windows, how much bare concrete (acts as
a heat sink with any type of heating), the opening and closing of an exterior door, long hallways, high
ceilings, etc. Customers with smaller rooms experience quick heat changes. Rooms with larger and
open floor plans can expect up to 24 hours to completely heat up.
Q. I do not have a grounded outlet. Can I use adapters, a 2-prong power strip, or remove the ground
prong from the cord?
A. NO! If you do not have a grounded outlet, contact a certified electrician for advice. Removing or
altering any part of the heater’s original design or intent (including the power cord) will void the
warranty and make you liable for any unexpected or hazardous results.
Q. My Heater has an ECO setting? How does this setting work?
A. The ECO mode on your heater is a program that attempts to keep the temperature strictly at a
“warm” 68° F (20°C). This also helps with efficiency, as it is programmed to 1) Increase the power
to the unit’s maximum wattage if the temperature drops below 64.4°F (18°C) 2) Gradually reduce the
wattage used as it approaches 66.2° (19°C) F and 3) Stop heating when 68° F (20°C) is achieved. This
is considered an Economical function, since in the ECO setting, the heater is almost never running at
the maximum watts.

7
FREQUENTLY ASKED QUESTIONS
Q. The temperature on my heater does not match the temperature display on my wall, or external
thermostat. Why?
A. This is completely normal. The temperature display on your heater may vary from the temperature
display on another thermostat (like the one mounted to your wall or a purchased external thermostat).
This is because the temperature sensor on the heater reads the temperature directly around the heater.
With the heater near the cold floor (and heat rising), any readings on elevated or external thermostats
will differ in readings on the heater. The best way to operate your heater is to set the unit on High and
dial up to a temperature that feels comfortable to you. Then, leave it at that temperature, regardless of
the mismatch. The heater will cycle off when the set temperature is met or exceeded slightly.
Q. Can I use more than one heater at a time? Can I use the heater and another appliance at the same
time?
A. Yes, but make sure they are not plugged into the same circuit. Each heater requires its own minimum
15-amp circuit with no other items plugged into that circuit or outlet. This is because heaters are
considered appliances and draw out high amperage. If you are unsure your circuit meets these
requirements, verify with a certified electrician.
WARNING: Risk of fire, damage to property, or injury may result if requirements are not met.
Q. Why does my heater’s fan continue to run after the set temperature is reached or the power is turned
off?
A. This is normal. The heater’s fan will continue to run even after the heater automatically cycles down.
The fan continues to run so that every last bit of heat is blown out of the heat chamber while allowing
the unit to continue filtering your air. Once the internal box/components cool completely, the fan should
then shut off on its own. In this case, allow a few minutes after the heat cycles off (with power on). The
fan will shut off faster when the power is turned off.
Q. My heater’s display shows my ambient temperature to be in the 20s when I know it is warmer than
that. Why?
A. The heater’s display is defaulted to read the temperature as Fahrenheit. If your heater is definitely
heating but shows it is in the 20s you probably have the setting to read your temperature in Celsius
rather than Fahrenheit.
Q. My heater’s power cord gets warm. My cord is showing signs of heat or melting at the outlet. Is
this normal?
A. A warm power cord is normal. These power cords are rated safe for up to 105°C/ 221°F by the UL,
CSA, or ETL. The exception is, if you detect heat, smoke, or signs of melting at the contact point of
the wall outlet, it may be due to loose or worn wall contacts (or arcing). Please stop using the heater
immediately, contact warranty support for a replacement power cord, and have a certified electrician
replace the wall outlet as soon as possible.

8
PREPARATION
Place the heater on a firm, level surface and plug into a grounded 120 V, 60 Hz power outlet and turn on
the power switch on the rear of the unit. Only operate heater in upright position.
Insert two AAA batteries into the remote control before using (batteries not included). *(Not all products
will include a remote control.)
Please note that infrared heaters do not heat like a traditional space heater. You should not expect
infrared heaters to blow hot air like a traditional space heater. Infrared heaters heat objects not air.
Infrared heaters are intended to supplement an already heated, insulated room. Square footage
specifications assume a single enclosed room not an entire home. Infrared heaters do not heat through
walls, floors, and are not intended to replace a main heat source. Infrared heat can take at least 24
hours to warm a room but operate much more efficiently to maintain the desired temperature. Infrared
heaters will not work well in uninsulated unheated spaces like screened in porches, RV’s, garages,
unheated basements, etc.
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
The heater
does not turn
on.
1. The power cord is not plugged in.
2. The electricity at the main fuse
box is not working.
3. The battery in the remote control
is dead.
4. The thermostat on the heater
is set lower than the room
temperature.
1. Plug the power cord into an electrical
outlet.
2. Check the electricity at the main fuse
box.
3. Replace the batteries in the remote
control.
4. Increase the thermostat temperature
on the heater for a higher heat setting.
The heater
displays an
error code
“E1”
1. The heater has overheated.
2. Insufficient power to the unit
3. Insufficient air flow to the heater.
1. Unplug the heater from the wall, wait a
few seconds then plug the power cord
back in.
2. Make sure the unit is plugged into
a dedicated 3-prong outlet, with no
extension cords or surge protectors.
3. Move the unit at least 3ft from the wall.
The heater
displays an
error code
“E2”
1. Temperature sensor not
functioning properly.
1. Please contact technical support.

9
CONTROL PANEL
1 2 3 4
567891011
12
13
14
PART NAME DESCRIPTION
1 Digital Display Readout of the set room temperature or timer value
2 Celsius Indicator Light Indicates that the temperature is being displayed in Celsius
3 Fahrenheit Indicator Light Indicates that the temperature is being displayed in Fahrenheit
4 Power Indicator Light Indicates when the unit is receiving power from the wall outlet
5 Power Switch Button Powers the heater ON or OFF
6 Flame Effect Button Toggles the Flame Effect from High/Med/Low/Off
7 Temp-Down Button Decreases the set temperature
8 Temp-Up Button Increases the set temperature
9 Timer Button Engages the on/off timer function
10 Heater Mode Button Toggles between Hi / Low / Eco Modes
11 Safety Lock Button Hold to Lock / Unlock heater’s control panel
12 Low Heat Indicator Indicates when Low Heat mode is on
13 High Heat Indicator Indicates when High Heat mode is on
14 Energy Saving Indicator Indicates when energy-saving mode is on

10
REMOTE CONTROL
1
26
5
3
4
PART NAME DESCRIPTION
1 Temp Up Button Increases the set temperature value
2 Mode Button Toggles between the three heat modes available
3 Temp Down Button Decreases the set temperature value
4 Power Button Powers the heater on or off
5 Flame/Lock Button Short press: Toggles the Flame Effect from High/Med/Low/Off. /
Long press: for 3 seconds to activate lock function.
6 Timer Button Engages the timer on or off
