Life Span VKR Combo User manual

Product may vary slightly from the item pictured due to model upgrades
Read all instructions carefully before using this product. Retain this owner’s manual for
future reference.
VKR COMBO BENCH
OWNER’S MANUAL

2
X-25
TABLE OF CONTENTS
1. ASSEMBLY INSTRUCTIONS 3
2. EXPLODED DIAGRAM 9
6. PARTS LIST 10
7. WARRANTY 11

3
X-25
1. ASSEMBLY INSTRUCTIONS
PARTS LIST:
PART NO
DESCRIPTION
Q’TY
01
BOTTOM TUBE
2
02
LOW UPRIGHT TUBE
2
03
UP UPRIGHT TUBE
2
04
LEFT LAT BAR
1
05
MIDDLE CONNECT TUBE
1
06
UP CONNECT TUBE
1
07
FOOT SUPPORT TUBE
2
08
LEFT ARM TUBE
1
09
RIGHT ARM TUBE
1
10
HANDLE TUBE
2
11
LAT BAR
1
12
RIGHT LAT BAR
1
13
BACK CUSHION
1
14
ARM CUSHION
2
15
HEX BOLT M10*70mm
18
16
HEX BOLT M10*90mm
2
17
HEX BOLT M10*20mm
14
18
HEX BOLT M8*65mm
4
19
HEX BOLT M8*20mm
2
20
WASHER Φ10
54
21
WASHER Φ8
6
22
NYLON LOCK NUT M10
20

4
X-25
STEP 1:
1. Attach low upright tube (02) to bottom tube (01) using hex bolt M10*20 (17) and washer φ10 (20).
2. Attach middle connect tube (05) to low upright tube (02) using hex bolt M10*70 (15), washer φ10
(20) and nylon lock nut M10 (22).
3. Attach foot support tube (07) to bottom tube (01) and low upright tube (02) using hex bolt M10*70
(15), washer φ10 (20) and nylon lock nut M10 (22).

5
X-25
STEP 2:
1. Attach up upright tube (03) to low upright tube (02) using hex bolt M10*20 (17) and washer φ10
(20).

6
X-25
STEP 3:
1. Attach left arm tube (08) and right arm tube (09) to low upright tube (02) and up upright tube (03)
using hex bolt M10*70 (15), hex bolt M10*20 (17), washer φ10 (20) and nylon lock nut M10 (22).
2. Attach up connect tube (06) to left arm tube (08) and right arm tube (09) using hex bolt M10*70
(15), washer φ10 (20) and nylon lock nut M10 (22).

7
X-25
STEP 4:
1. Attach left lat bar (04) and right lat bar (12) to up upright tube (03) using hex bolt M10*70 (15),
washer φ10 (20) and nylon lock nut M10 (22).
2. Attach lat bar (11) to left lat bar (04) and right lat bar (12) using hex bolt M10*90 (16), washer φ10
(20) and nylon lock nut M10 (22).

8
X-25
STEP 5:
1. Attach back cushion (13) to up connect tube (06) using hex bolt M8*20 (19) and washer φ8 (21).
2. Attach arm cushion (14) to left arm tube (08) and right arm tube (09) using hex bolt M8*65 (18) and
washer φ8 (21).
3. Attach handle tube (10) to left arm tube (08) and right arm tube (09) using hex bolt M10*20 (17) and
washer φ10 (20).

9
X-25
2. EXPLODED DIAGRAM

10
X-25
3. PARTS LIST
NO.
Description
Qty
No.
Description
Qty
1
Computer
1
32
Square end cap J60*30*15
2
1a
Computer wire
1
33L/R
Front connect pole cover R
1
2
Bolt M5*10
4
34
Bolt ST4.2*16
10
3
End capφ25*16
2
35
Bolt M8*75
2
4
Mid-handbar
1
36L/R
Connect pole
1
5
Washer d6*Φ12*1.0
2
37L/R
Pedal L/R
1
6
Bolt ST4.0*19
2
38
Bolt M8*45
4
7
Pulse pad 配Φ25 管
2
39
Nut M8
4
8
Sponge tube Φ23*5*500
2
40
Bushing Φ31.8*Φ19.2*30
2
9
过线孔塞 Φ12*11*Φ3
1
41
Washer d10*Φ32*2.0
2
10
Spring washer d8
4
42
Nylon nut M10
2
11
Bolt M8*25
2
43
Bolt ST3*16
6
12
End cap φ32*22*φ50
2
44L/R
Rear connect pole cover R
1
13L/R
Handlebar L/R
各1
45L/R
Rear connect pole cover L
1
14
Bolt M8*43
4
46L/R
Front connect pole cover L
1
15
Sponge tube Φ30*5*630
2
47L/R
Cover L/R
1
16
Spring washer d8*Φ20*2*R16
4
48L/R
End cap with wheel L/R
PT80*40*71.5*90*65
1
17
Nylon nut M8
6
49
Washer d5*Φ13*1.0
4
18
Front tube
1
50
Computer wire 1
1
19
Bushing 2 Φ32*3*Φ28*21*Φ19.4
8
51
Bolt M8*50
4
20
Spring washer d19*Φ25*0.3
4
52
Rear tube
2
21
Bushing Φ31.8*Φ19.2*54
2
53
Adjusted end cap
PT80*40*71.5*90*65
2
22
Bolt M8*16
2
54
Bolt ST4.2*19
2

11
X-25
23
Washer d8*Φ32*2.0
2
55
Bolt ST4.2*25
1
24
Bushing 1 Φ32*3*Φ28*16*Φ14.3
4
56L/R
Nick cover L/R
1
25L/R
Swing pole L/R
1
57
Plastic cover
1
26L/R
Left swing pole cover
1
58
Bushing Φ14*Φ8.3*59
2
27L/R
Right swing pole cover
1
59
Computer wire 2
1
28
Handlebar post
1
60
Frame
1
29
Bolt M8*16
4
61
Pulse wire
1
30
washer d8*Φ16*1.5
10
31
Spring washer d8*Φ20*2*R30
2
4. WARRANTY
AUSTRALIAN CONSUMER LAW
Many of our products come with a guarantee or warranty from the manufacturer. In addition, they come with
guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement
or refund for a major failure and compensation for any other reasonably foreseeable loss or damage.
You are entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure. Full details of your consumer rights may be found at
www.consumerlaw.gov.au
Please visit our website to view our full warranty terms and conditions:
http://www.lifespanonline.com.au/Warranty-Policy
