Life Span TR3000i User manual

TR3000i / TR4000i / TR5500i
Folding Treadmills
Owner’s Manual

1
Congratulations on Purchasing Your LifeSpan Treadmill!
At LifeSpan we take pride in the quality, safety, and reliability of our products
as well as the professionalism of our sales support and customer service teams.
Making it our number one priority that you have an exceptional experience using
our products.
In support of this quality focus we pre-assemble parts on the manufacturing line
whenever possible to reduce the number of steps and complexity of customer
assembly, independently certify our products to comply with the latest industry
Safety Standards, and use state of the art production processes and quality
components.
Then we back LifeSpan products with excellent warranties and a responsive
customer service department making it simple and easy to get assistance should
the need arise.
This attention to quality, our high standard for customer service and focus on
innovation has earned LifeSpan numerous awards and consistent praise from
independent review groups, industry authorities and you the consumer.
Thanks for choosing LifeSpan.
Please thoroughly read this manual before you assemble or operate your treadmill.
Neither LifeSpan nor its representatives can accept responsibility for any damages or injury incurred as a
result of information presented in this manual except under the terms of the product warranty.
Welcome

3
Contents
Welcome
Safety First.........................................................................................................5
Safety Tips
Safety Key
Grounding
Assembling Your Treadmill.............................................................. 10
Exploded View & Hardware
Assembly Instructions
Console Basics ........................................................................................... 18
Console Overview
Display and Keyboard
Operations ................................................................................................... 25
Home Screen and Personal Settings
Bluetooth Speaker, Heart Rate Strap Set-up
QuickSTART and Manual
Preset Programs
Custom User Set-Up Programs
Heart Rate Control Programs
Summary
Equipment Settings
Program Proles
Saving Your Results................................................................................ 49
Maintenance and Tips.......................................................................... 50
Heart Rate Monitoring
Cleaning / Lubrication
Folding & Unfolding
Moving
Belt Tensioning
Belt Alignment
Troubleshooting
About Your Treadmill............................................................................ 59
Unique Features
Specications
Warranty / Registration

5
When using exercise equipment, basic precautions should always be followed,
including:
• Never drop or insert any object into any opening. If an object falls into an
opening, turn the power o and unplug the power cord from the outlet.
Remove the object or call customer service at 877.654.3837 x4.
• Never operate this treadmill if it has been damaged or partially submersed in
water.
• To reduce the risk of electric shock, unplug the treadmill from the wall outlet
when not in use, before performing any maintenance, or before moving the
treadmill.
• Do not use outdoors or in areas of high humidity or extreme temperature
changes.
• Do not lean against or climb on the treadmill.
• Do not operate where aerosol spray products are being used or where oxygen
is being administered.
• Never place the power cord under carpeting or place any object on top of
the cord, this may pinch or damage the cord causing re damage or personal
injury.
• Use this exercise product for its intended use as described in this Owner’s
Manual. Do not use attachments that are not recommended by LifeSpan.
• Do not leave your treadmill running while not in use.
Children and Pets
• Keep children from playing on your treadmill at all times.
• When in use children and pets should be kept at least 10 feet (3m) away.
• This treadmill can be used by children ages 12 years and above and persons
with reduced physical, sensory or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
• Cleaning and user maintenance shall not be made by children without
supervision.
Safety First

6
Safety Tips While in Use
• Always consult a physician before beginning an exercise program.
• If you experience chest pains, nausea, dizziness or shortness of breath, stop
exercising immediately and consult your physician before continuing. Do not
wear clothing or jewelry that might catch on any part of the treadmill.
• Wear shoes with high traction rubber soles. Do not wear shoes with heals,
leather soles, cleats or spikes.
• In case of emergency, grab onto the side handrails and place your feet on the
side rails located on each side of the running belt.
• Do not walk or run backwards on the treadmill, always face forward.
• Allow the running belt to fully stop prior to getting o the treadmill.
• Keep the treadmill on a solid surface, with the side rails and front of the
treadmill a minimum of 2 feet (0.6m) from any walls or furniture. Make sure that
the area behind the treadmill remains completely clear during use. A minimum
of 7 feet (2m) of clearance is required for safety reasons.
Safety First
2 Feet (.6 m)
7 Feet (2.0 m) 2 Feet (.6 m)
2 Feet (.6 m)
Safety Clearance

7
NOTE: Read all instructions and save for future reference.
Safety Key
The safety key is required to operate this treadmill. With the safety key installed
the treadmill is operational. With the safety key pulled, power is turned o to the
motor making the treadmill inoperable.
CAUTION: For your safety always attach safety key clip to an article of
clothing prior to use. The safety key clip needs to be securely attached to
clothing parallel to or above the height of the safety key.
WARNING: Heart rate monitoring systems may be
inaccurate. Over exercising may result in serious injury or
death. If you feel faint stop exercising immediately.
Safety First
!
!
Insert safety key
Securely attach safety
key clip in case of a fall

8
Proper Grounding
LifeSpan equipment must be grounded. Improper connection of the equipment’s
grounding conductor can result in the risk of electric shock. Check with a qualied
electrician or service person if you are in doubt as to whether the outlet is
properly grounded. Do not modify the plug provided with the product or use a
ground plug adapter to adapt to a non-grounded outlet. If the plug will not t in
the outlet, have the proper outlet installed by a qualied electrician.
Power Cord Options
This treadmill should only be used with the proper power cord and power outlet.
Several power cord options (shown below) are available from LifeSpan. We do
our best do include the correct power cord with the treadmill for your area. In the
event that the correct power cord is not included in the packaging please contact
your local distributor.
Do not use extension cords between the treadmill and power outlet.
Do not plug into a GFI outlet or circuit as it may trip the breaker.
Safety First
!
!
Power Cord Options
C
I
R
C
U
I
T
B
R
E
A
K
E
R
POWER
SOCKET
SWITCH
AC POWER
OVERLOAD
SWITCH
Treadmill Outlet
P
R
E
S
S
T
O
R
E
S
E
T

10
Assembling Your Treadmill
Exploded View
Prior to starting the assembly process take all of the parts out of the box.
Remove plastic bags and lay them out on the oor to become familiar with the
components.
Since your treadmill is a heavy piece of equipment it is recommended you use
two people during assembly and follow these assembly instructions to reduce
any problems that could occur.
8
2
1
3
4
5
6
7
9
10
11
12
13

11
Hardware Included
Item# Part Description
1 Right Upright Post
2 Left Upright Post
3 Right Upright Post Cover
4 Left Upright Post Cover
5 Console
6 Right Cup Holder
7 Left Cup Holder
8 Cover for Optional Bluetooth Adapter
Hardware Bag Contents
Item # Qty. Hardware Description
N/A 1 6mm Allen Wrench
N/A 1 5mm Allen Wrench with Phillips Screw Driver
9 4 M10 x 45L Bolt - (Upright Attachment)
10 4 M10 Washer - (Upright Attachment)
11 2 M8 x 100L Bolt - (Handlebar Hold Down)
12 2 M8 Washer - (Handlebar Hold Down)
Pre-installed Hardware (not shown)
Item # Qty. Hardware Description
13 2 M4 x 8L - (Upright Cover Attachment)
14 4 M8 x 15L Bolt - (Console Attachment)
15 4 M4 x 8L Screw - (Cup Holder Attachment)
Assembling Your Treadmill
M10 x 45L
(x4)
6mm Allen
Wrench
5mm Allen
Wrench w/
Phillips
M10 Washer
(x4)
M8 x 100L
(x2)
M8 Washer
(x2)
M8 x 15L
(x4)
M4 x 8L
(x4)
M4 x 8L
(x2)

12
Step 1: Unpacking Treadmill
A. Cut packaging straps and
remove.
B. Remove the box top.
C. Remove small parts and
packaging material and
unwrap parts.
D. Cut the corners of the bottom box and remove all packaging material to
begin assembly. The treadmill can be assembled in the box. No need to pick
the treadmill up to remove it from box.
Step 2: Upright Post Attachment
A. Carefully fold the uprights
with handlebars up into the
upright position.
B. Carefully lay handlebars
down as the uprights are
brought up into position.
This will protect against any
accidental damage to wires
coming up through the
upright into the handlebars.
C. Align the holes in the lower
portion of the upright with
the threaded holes in the
frame.
D. Install the four M10 x 45L
bolts (9) and M10 washers
(10), two in each upright. The
best way to handle this is to
loosely install all four bolts
and washers and then tighten
once all bolts are installed.
Assembling Your Treadmill
10
10
9
9
Support
handlebars
as you lift
M10 x 45L
(x4)
M10 Washer
(x4)
6mm Allen
Wrench

13
Step 3: Upright Post Cover
Attachment
A. Remove pre-installed M4x8L
screw (13).
B. Install the left upright cover (4)
by sliding the front of the cover
around the upright and centering
or aligning the cover on the
upright.
C. Install the M4 x 8L screw (13).
D. Repeat steps A and B for the right
upright cover.
Step 4: Handlebar Attachment
A. Place the M8 x 100L bolt (11)
and M8 washer (12) through
the left handlebar and into
the uprights being careful not
to damage any wires running
through the handlebar. Repeat
for the right handlebar.
B. Loosely thread both bolts into
the upright prior to tightening.
C. Fully tighten both handlebar
attachment bolts.
Assembling Your Treadmill
13
4
5mm Allen
Wrench w/
Phillips
M4 x 8L
(x2)
12
11
M8 x 100L
(x2)
M8 Washer
(x2)
6mm Allen
Wrench

14
5B C3C5 C4
Step 5: Console Harness Attachment
A. Slide the square mounting tubes
(protruding from the front of the
console) (5) partially into the
console mount as shown in the gure
to the left. Do not slide the console all
the way in as wire
connections need to be made.
B. Connect the ribbon cables
(at connectors).
Assembling Your Treadmill
5
A
NOTE: Plug the ribbon cables
together so that the colored dots
are on the same side (matching).

15
C5 C2C4 C1
Assembling Your Treadmill
C. Securely attach the seven remaining cable connectors – There are four 2-pin,
two 3-pin and one 7-pin connector that will need to be connected.
1. Attach the 7-pin connectors together (C1) .
2. Attach the wires labeled“SK” together (C2).
3. Attach the White 2-pin connector wires together (C3).
4. Next, attach the two 3-pin connectors (C4) together. There are labels on
these that say L and R. Connect the L to L and the R to R. These are for the
handlebar speed and incline switches.
5. The remaining two 2-pin connectors are for the contact heart rate
sensors and it doesn’t matter which gets plugged into the other.
D. Carefully tuck all wires into the bottom or top console housing.

16
View from beneath
Pre-installed
14
M8 x 15L
(x4)
6mm Allen
Wrench
Step 6: Securing Console
A. Slide the console fully into the mounting brackets, being careful not to
damage any wires. If the console does not want to slide in completely,
loosen the four pre-installed M8 x 15L bolts (14) with the provided 6mm
Allen wrench to eliminate any friction.
B. Once the console is fully installed, tighten the four M8 x 15L Bolts.
Step 7: Cup Holder Attachment
A. Remove the two pre-installed M4 x 8L
screws (15) with the provided Phillip’s
head screwdriver from the bottom of
the right cup holder. 15
Pre-installed
5mm Allen
Wrench w/
Phillips
M4 x 8L
(x2)
A
Assembling Your Treadmill

17
B. Place the right
cup holder
(6) over the
handlebar and
into the frame as
shown.
C. Loosely install
the two screws
removed in step A.
Once both screws
are installed,
securely tighten
both screws.
D. Repeat steps A
through C for
installing the left
cup holder (7)
Step 8: Remove
Shipping Strap
A. Cut plastic shipping
strap holding deck
frame to base.
6
7
15 5mm Allen
Wrench w/
Phillips
M4 x 8L
(x2)
B
C
Assembling Your Treadmill
WARNING: To avoid personal injury, never attempt to pick the treadmill
up and carry it from this position once this strap is cut. The treadmill
should be folded and rolled to the new location or folded and carried to
the new location.

18
Console Basics
USB Charging
Power Button
Safety Key
Cooling Fan
Keyboard
