LIFEPLUS WTF-006 User manual
Thank you for your purchase
Please read this manual in detail before using.
Please keep it for future reference.
SECTION 1
SAFETY PRECAUTIONS
SECTION 2
INTRODUCTION
TECHNICAL SPECIFICATION
PRODUCT DIAGRAM
SECTION 3
OPERATING THE AIR COOLER
OPERATING THE WATER TANK
USING THE ICE BOXES
SECTION 4
CLEANING AND MAINTENANCE
SECTION 5
TROUBLESHOOTING GUIDE
SECTION 6
WARRANTY
PAGE 1
PAGE 1
PAGE 2
PAGE 2
PAGE 3-5
PAGE 5
PAGE 5
PAGE 5-6
PAGE 6
PAGE 7
TABLE OF CONTENTS
SAFETY PRECAUTIONS
• Make sure this appliance and the power cord is not damaged before operating. In case of
damage, please consult your authorized technical service.
• Unplug the power cord plug before taking out the water tank.
• Do not insert any objects to the ventilation or exhaust opening for this may damage the=
product and could cause electrical shock or fire.
• Do not operate your unit with a cover on it as this may result to overheat and motor
damage.
• The plug must be removed from the electrical outlet when not in use and before moving,
installing, uninstalling and cleaning.
• Do not add any chemical or metal ingredients into the water tank.
These materials are dangerous and may cause problems.
• Be careful not to expose infant or elder directly to the air cooler for a long time.
• This appliance should be used at the rated voltage and frequency as indicated in rating
label.
• This appliance is not intended for use of persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance.
• Do not use your air cooler in or around water, that may cause electric shock and risk of fire.
• Do not pull the unit while the power is on. Always ensure that the plug is fully inserted into
the electrical outlet before operating.
• Do not attempt to disassemble, repair or modify this appliance for the warranty will be void
if repair is carried out by unauthorized person/services.
• Do not leave your unit under direct sunlight for a long time.
• Before using the evaporative air cooler function, always ensure that it contains water.
Clean the tank with fresh tap water every two weeks.
TECHNICAL SPECIFICATION
PRODUCT DIAGRAM
Rated Voltage
Rated Frequency
General Power
Water Tank Capacity
120V
60Hz
80W
5L
INTRODUCTION
The evaporative air cooler product is specially designed with cooler function.The air cooler
cools the air by the process of evaporation of water,which in turn helps reducing the green
house effect. The evaporative air cooler should not be used in enclosed spaces. It is
recommended to place it near an open window to create a “flow-through” effect and
experience the desired cooling effect. For the best performance, it is advised to fill the water
tank with water or ice if available when using this unit. This product is suitable for diversified
climatic environment for a relaxing and comforting atmosphere.
1 2
Water level display
Air outlet
Open the lid and
Operation panel
Base support
Water tank
Tank lock
Power cord
Wet curtain paper
Filter screen
Lag spike
OPERATING THE AIR COOLER
Natural: Natural setting provides a soft and comfortable environment with a selection of
low, medium and high speed.
Sleep: When the "Speed" Mode is at high level, the sleep function will run at high-speed
natural wind for 30 mins, then switch to medium-speed natural wind for 30 mins, and then
keep running at low-speed natural wind.
When the "Speed" Mode is at medium level, the sleep function will run at medium-speed
natural wind for 30 mins, then switch to low-speed natural wind and keep running at low-
speed natural wind.
When the "Speed" Mode is at low level, the sleep function will keep running at low-speed
natural wind.
4. Timer
Press "Timer" button to set the fan between 1-12 hours, the indicator light will show the
selected time and the unit will operate until the preset time. Continuously press the button
to your desired running time.
To cancel the timer, simply press the button until the indicator shows "00".
5. Swing
Press "Swing" button to change the wind direction. The swing icon will appear on the screen
when the function is activated. Press the button again to stop the oscillation. The vertical
direction of air flow can be adjusted manually by directing the outlet louvers up and down.
6. Cooler
Press this key to activate the air cooler function. Water pump will take the water from the
tank and pour it onto the cooling pad. Cooling pad absorbs the heat of the water and
evaporated air is blown out through the fan. The cool breeze by the cooler drops the
temperature and creates a relaxing cooling effect.
Caution:
If the water level is low or there is no water in the tank, do not activate the "Cooler"
function.
Check the water level first and add clean water if needed, also to replace the stale water. It is
recommended to replace water in the tank at least once a week.
7. Auto Lights Off
If there is no operation after 1 minute, the lights on the control panel will automatically turn
off. And press any button to turn on the lights.
Insert the plug into the electrical outlet. Press the "On/Off" button to turn the unit "ON". The
LED indicator automatically shows the room temperature and shifts the fan to standby mode.
The functions of the unit can be controlled via control panel or by remote.
1. On/Off
Pressing the "On/Off" button on the control panel or pressing the "On/Off" button on the
remote control will turn the unit "ON" at intermediate speed. After few minutes, the fan will
drop to show speed or to the pre-programmed memory setting. To switch back the standby
mode, simply press the "On/Off" button on control panel or press the "On/Off" button on
remote control.
2. Speed
Press this key to choose between high, medium and low fan speed. Each time the "Speed"
button is pressed, an icon will appear on the LED screen indicating the current speed level.
3. Wind
Press the "Wind" button to choose the type. Indicator light will display the selected type of
wind;
Normal: A continuous wind blow that can be adjusted to low, med and high speed.
34
TROUBLESHOOTING GUIDE
Fan does not work
• Power cord is not
plugged or not properly.
• The "On/Off" button
on the control panel is
not activated.
• Plug the power cord
properly.
• Press the "On/Off " button
on the control panel.
• Follow the steps in cleaning
the dust filter and cooling
pad.
• Unplug the unit, refill the
tank with clean tap water.
• Dust accumulates on
the dust filter and cooling
pad.
• Water level in the tank
is below "MIN" level.
The temperature
of air being expelled
by the cooler is not
cold enough.
Problem Possible Cause Solution
Dust Filter and Cooling Pad
1. First, please use a "+" shaped wrench to remove the 2 nails on the top of the filter.
2. Pull out the dust filter and the cooling pad carefully by hands.
3. Use mild cleaning agent and soft brush in removing the dust and dirt on the filter.
4. Use a clean cloth or soft brush to remove dust and dirt on the cooling pad. Rinse with clean
water if needed and leave open air dry.
Never use any harmful chemical solution for that may cause damage to the pad.
5. When done, first attach the bottom part of filter and the pad, then push the upper part
into the unit and tighten the 2 nails by wrench.
Warm tip: Your cooler takes water from narrow section of the water tank and pumps it on
the cooling pad. The water flowing through the cooling pad goes down to the large section
of the water tank. The cycle results to absorption of dust and dirt in the air which makes the
air safer and fresher to breathe.
8. Remote
Remote control operates with a CR2025 lithium cell.
Direct the remote control to the control panel of the evaporative air cooler. If remote doesn't
work, please check the battery first. Replace it if needed.
If you are not going to use it for a long time, take out the battery to prevent damages that
may occur due to battery leakage.
OPERATING THE WATER TANK
Check the level of water in the tank frequently. Be sure that water level is not below the “MIN”
marking which is located on the front of the unit. Activating the “Cooler ” function with
insufficient amount of water may cause malfunction of the water pump and warranty of your
product will be void.
Before refilling water, please turn your unit off and unplug the power cord.
USING THE ICE BOXES
In order to increase the cooling effect of your fan, you can use ice boxes which are included
with the unit. Before using, place them in the freezing compartment of your refrigerator for a
few hours. Then place them into the large section of the tank and add water reaching “MAX”
level. Utilizing ice boxes drops the temperature of the air flow which will create more effective
cooling effect.
CLEANING AND MAINTENANCE
Dusts may accumulate in the dust filter or cooling pad after some time and may affect the
cooler's function. Therefore it is recommended to clean your evaporative cooler regularly.
Below are written steps on how to clean this unit.
Turn off the air cooler and unplug the power cord before beginning to clean.
5 6
WARRANTY
After-sales Service Letter of Commitment
To provide customers with premium products and services is our commitment
to every customer.
All products purchased in our company are guaranteed to keep in good repair for 1 year.
If quality problems happen in guarantee period, our company will maintain for free or
provide replacement.
Additionally, our company provides technical support and fittings for life. After-sales
service isn't restricted by time and hear feedback idea of users and deal with them in
time. If you are caught in some problems when using our products, welcome to contact
us at any time.
