LifeSource ADVANCE MEMORY WRIST UB512 Manual
Trilingual Instruction Guide – MODEL UB-512
AM/PM MEMORY WRIST
Blood Pressure Monitor
Please read this important information before using your monitor.
☞
Please remember that only a medical practitioner is qualified to
interpret your blood pressure measurements. Use of this device
should not replace regular medical examinations.
☞
Have your physician review your procedure for using this device.
He or she will want to verify blood pressure measurements before
prescribing or adjusting medications.
☞
Consult your physician if you have any doubt about your readings.
Should a mechanical problem occur, contact A&D Medical.
☞
Make sure to use the correct cuff size when measuring your blood
pressure.
☞
Make sure to follow instructions when measuring your blood
pressure to ensure accurate results.
☞
Do not attempt to service, calibrate, or repair this monitor.
☞
Because your UB-512 monitor contains delicate, high-precision
parts, avoid exposing it to extremes in temperature or humidity
or to direct sunlight, shock and dust. A&D Medical guarantees the
accuracy of this monitor only when it is stored and used within the
temperature and humidity ranges noted on page E-17.
☞
Clean the monitor and cuff with a dry, soft cloth or a cloth
dampened with water and a mild detergent. Never use alcohol,
benzene, thinner or other harsh chemicals to clean monitor or cuff.
☞
Remove and replace batteries if monitor is not used for more than
six months. Alkaline batteries recommended.
PRECAUTIONS
The UB-512 is designed to be used at home, by those who are eighteen
(18) years and older, to monitor blood pressure (systolic and diastolic) and
pulse rate.
IMPORTANT INFORMATION ✓
Fast. Easy. Accurate.
Congratulations on purchasing a state-of-the-art
LifeSource®blood pressure monitor—one of the most
technologically advanced monitors available today.
Designed for ease of use and accuracy, this monitor
will facilitate your daily blood pressure regimen.
Physicians agree that daily self-monitoring of blood
pressure is an important step individuals can take to
maintain cardiovascular health and prevent the serious
consequences associated with undetected and untreated
hypertension.
A&D Medical has been manufacturing high quality
healthcare products for over 20 years. We are committed
to providing you and your family with monitoring devices
that provide the utmost in accuracy and convenience.
LifeSource - Designed for Life.
LifeSource Health Line (Toll-Free): 1-888-726-9966
E-1
?WHAT DISPLAY SYMBOLS MEAN.........................E-2
MONITOR COMPONENTS.............................. E-3
HOW UB-512 WORKS................................ E-4
ABOUTAM/PMMEMORY ..............................E-4
BEFORE YOU START ................................. E-4
TAKING YOUR BLOOD PRESSURE........................ E-5
WHAT IS AN IRREGULAR HEARTBEAT . . . . . . . . . . . . . . . . . . . . .E-8
ABOUT CUFF INFLATION METER..........................E-8
ABOUTAVERAGEREADING.............................E-9
ABOUT PRESSURE RATING INDICATOR™ ...................E-9
ABOUTMEMORY ...................................E-10
ABOUT BLOOD PRESSURE............................ E-11
TROUBLESHOOTING.................................E-16
SPECIFICATIONS .................................. E-17
CONTACT INFORMATION ............................. E-18
INSTRUCCIÓNS EN FRANÇAIS .......................... F-1
INSTRUCCIONES EN ESPAÑOL.......................... S-1
TABLE OF CONTENTS
In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991
E-2
?WHAT DISPLAY SYMBOLS MEAN
?
Display
Symbol
123
123
123
123
123
123
123
123
123
123
123
123
err CUf
p-3
1932-1AIc UA787EXC•06 illust•03,12p symbols.FH7
123
123
123
123
123
123
123
123
123
123
123
123
err CUf
p-3
1932-1AIc UA787EXC•06 illust•03,12p symbols.FH7
123
123
123
123
123
123
123
123
123
123
123
123
err CUf
p-3
1932-1AIc UA787EXC•06 illust•03,12p symbols.FH7
123
123
123
123
123
123
123
123
123
123
123
123
err CUf
p-3
1932-1AIc UA787EXC•06 illust•03,12p symbols.FH7
123
123
123
123
123
123
123
123
123
123
123
123
err CUf
p-3
1932-1AIc UA787EXC•06 illust•03,12p symbols.FH7
Battery Full
123
123
123
123
123
123
123
123
123
123
123
123
err CUf
p-3
1932-1AIc UA787EXC•06 illust•03,12p symbols.FH7
Battery Low
PULSE DISPLAY ERROR
123
123
123
123
123
123
123
123
123
123
123
123
err CUf
p-3
1932-1AIc UA787EXC•06 illust•03,12p symbols.FH7
Recommended
Action
Measurement is in progress,
remain as still as possible.
Take measurement again
and consult with your
physician.
Replace all batteries with
new ones when the symbol
blinks. Alkaline batteries
recommended.
Try the measurement again.
Remain very still during the
measurement.
Fasten the cuff correctly, and
try the measurement again.
Check cuff to ensure fit and
fastening is correct, and
measure again.
Refasten the cuff and retake
measurement.
Try the measurement again.
Remain very still during
the measurement.
Measurement is in progress,
remain as still as possible.
Refer to the section “About
Pressure Rating Indicator™”
for further explanation
Condition/Cause
The symbol shown
while measurement is in
progress. It blinks while
detecting the pulse.
An irregular heartbeat or
body movement may have
occurred. Refer to page E-8
for more information on
irregular heartbeats.
Previous measurement
stored in MEMORY.
The battery power
indicator during
measurement.
The batteries are low when
it blinks.
Unstable blood pressure
due to excessive body
movement.
The systolic and diastolic
values are within 10
mmHg of each other.
The pressure value did not
increase during inflation.
The cuff is not fastened
correctly.
The pulse is not detected
correctly.
Cuff Inflation Meter
Pressure Rating
Indicator™
LifeSource Health Line (Toll-Free): 1-888-726-9966
AM
PM
E-3
CasE
aaa BaTTERIEs
MONITOR COMPONENTS ?
?
BaTTERy
holdER
CovER
PM sTaRT BuTTon
sysTolIC
PREssuRE
dIasTolIC
PREssuRE
METER
PREssuRE
RaTInG
IndICaToR
PulsE RaTE
In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991
aM sTaRT BuTTon
E-4
The UB-512 provides accurate readings on wrists with a circumference
between 5.3" and 8.5" (13.5 cm and 21.5 cm).
The unit requires two "AAA" (1.5 volt) batteries to operate (alkaline
batteries recommended). To install batteries (or to replace when "Low
Battery" symbol appears), proceed as follows:
1. Slide the battery cover as shown to
remove from the device.
2. Insert batteries into designated areas
ensuring a correct match with positive (+)
and negative (-) terminals.
3. Return battery cover by sliding back on to
monitoring device.
NOTE:
HOW UB-512 WORKS
?
BEFORE YOU START
LifeSource
®
Blood Pressure Monitors are easy to use, accurate and display
clear digital measurements. Our technology is based on the “oscillometric
method”. The term “oscillation” refers to the measure of vibrations caused
by the arterial pulse and is a non-invasive method to determine blood
pressure.
Our monitors examine the pulsatile pressure generated by the arterial wall
as it expands and contracts with each heartbeat against the monitor’s cuff.
This monitor measures your blood pressure while the cuff is inflating.
AM/PM Memory
This monitor is able to store each measurement as an AM or PM
reading in memory (note: Users must designate AM or PM prior to each
measurement. See E-5 for more information.). Healthcare providers agree
that understanding your AM and PM readings can assist in the proper
diagnosis and management of your heart health through lifestyle and/or
medication modifications.
LifeSource Health Line (Toll-Free): 1-888-726-9966
?!
E-5
The UB-512 has several modes available to fit your blood pressure
monitoring needs.
Normal Measurement with AM or PM Readings Stored in Memory
Press the AM START or PM START button depending on time of day.
Your blood pressure is measured and the reading is stored into the
appropriate AM or PM memory. Each START button can store up to 30
readings in memory.
Recalling Previous Measurements
To recall previous measurements stored in memory, press and hold the
AM START or PM START button. Release the button after you see the first
reading recalled from memory. The previous measurements are displayed
from most recent to oldest.
Clearing Memory
To clear both AM and PM memory, simply remove batteries. Insert
batteries again to resume blood pressure measurements.
Taking a Measurement without Reading Stored in Memory (Guest Mode)
This mode can be used when storing readings in memory is not desired.
Readings stored in memory are automatically averaged and it is important
only to store your readings as other people's readings will affect your
average. Press both the AM START and PM START buttons at the same
time. A reading will be taken, but not stored into memory.
TAKING YOUR BLOOD PRESSURE
In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991
E-6
TAKING YOUR BLOOD PRESSURE
Tips for Blood Pressure Monitoring:
☞
Relax for about 5 minutes before measurement.
☞
Do not smoke or ingest caffeine at least 30 minutes prior to
measurement.
☞
Remove constricting clothing and place cuff on bare wrist.
☞
Unless your physician recommends otherwise, use left arm
to measure pressure.
☞
Do not talk during measurement.
☞
Do not cross legs. Keep you feet flat on floor during
measurement.
Now you are ready. Follow these simple steps:
1. Sit comfortably in a chair near a flat surface.
2. With palm facing upward, attach monitor
to the inside of your left wrist and fasten
securely. The top edge of the cuff should
align with the crease of your wrist.
3. Position your wrist so it is level with
your heart, using an arm rest if needed.
Positioning of the wrist at heart level is
critical for accurate measurement.
4. To keep track of your AM or PM readings
accurately, use the AM START button for
morning readings, and use the PM START
button for afternoon or evening readings.
START
2
1
LifeSource Health Line (Toll-Free): 1-888-726-9966
E-7
5. Press the AM START or PM START button. Your average
blood pressure reading will appear with the number of
measurements stored in memory (i.e. A25 = total of 25
measurements stored in memory). As the cuff pressurizes,
measurement will begin and the Cuff Inflation Meter will
show on the display screen. It is normal for the cuff to feel
very tight.
NOTE:
NOTE:
6. As the cuff is inflating, the ❤will appear to indicate that the
measurement is in progress. The monitor measures your blood
pressure while the cuff is inflating, so remain still. Once the pulse is
detected, the symbol will flash with each pulse beat.
7. When measurement is complete, the systolic
and diastolic pressure and pulse rate readings
are displayed. The cuff will automatically
deflate completely, releasing any remaining air.
8. Press either START button once to turn
off power. The device has an automatic
power-down feature which turns off power
automatically one minute after measurement is obtained.
For the most useful blood pressure history, we recommend that you record
the date and time after each measurement. The most accurate history
relies not on a single or sporadic readings, but on a consistent monitoring
pattern over time.
NOTE:
sysTolIC
dIasTolIC
PulsE
TAKING YOUR BLOOD PRESSURE
In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991
E-8
WHAT IS AN IRREGULAR HEARTBEAT
The UB-512 Blood Pressure Monitor provides a blood pressure and pulse
rate measurement even when an irregular heartbeat occurs. The Irregular
Heartbeat symbol
123
123
123
123
123
123
123
123
123
123
123
123
err CUf
p-3
1932-1AIc UA787EXC•06 illust•03,12p symbols.FH7
will appear in the display window in the event
an Irregular Heartbeat has occurred during measurement. An irregular
heartbeat is defined as a heartbeat that varies by 25% from the average
of all heartbeat intervals during the blood pressure measurement. It is
important that you relax, remain still and refrain from talking during
measurements.
NOTE:
123
123
123
123
123
123
123
123
123
123
123
123
err CUf
p-3
1932-1AIc UA787EXC•06 illust•03,12p symbols.FH7
ABOUT CUFF INFLATION METER
The Cuff Inflation Meter is located on the left side of the display screen
to tell you when the blood pressure monitor is inflating the cuff. The Cuff
Inflation Meter moves up during inflation.
NOTE:
LifeSource Health Line (Toll-Free): 1-888-726-9966
E-9
The UB-512 provides an average blood pressure reading
based on the total measurements stored in memory. When
taking a measurement, the average blood pressure reading
will appear and the number of measurements stored in
memory will flash several times before the cuff begins
to inflate. The average blood pressure reading will also
appear briefly when you recall the measurements stored in
memory.
The Pressure Rating Indicator™ is a feature which
provides a snapshot of your blood pressure classi-
fication based on your measurements. This will
let you quickly know what your blood pressure
readings mean. Each segment of the bar indicator
corresponds to the Seventh Report of the Joint
National Committee (JNC7) on Prevention,
Evaluation and Treatment of High Blood Pressure
from the National Heart, Lung and Blood Institute
- May 2003. For a more detailed look at this blood
pressure classification, please refer to “Assessing High Blood Pressure” on
page E-12.
:The indicator displays a segment, based on the current measurement,
corresponding to the JNC7 Classification.
NOTE:
NOTE:
avERaGE
ABOUT PRESSURE RATING INDICATOR™
ABOUT AVERAGE READING
In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991
E-
ABOUT MEMORY
The memory function on the UB-512 blood pressure monitor is designed
for categorizing each reading as an AM or a PM reading. For each START
button, the monitor can store up to 30 readings in memory. To keep track
of previous measurements accurately, we recommend that you use the
appropriate START button each time you take a blood
pressure reading.
To recall previous measurements in memory, press and
hold the AM START or PM START button. Your average
blood pressure reading will appear with the number of
measurements taken flashing several times. Release the
button after the display switches to the memory index
number (see illustration on right).
The previous measurements are displayed from most recent
to oldest. When viewing previous measurements, you will
see the "M" symbol appear on the upper left corner of this
display. You can stop this by pressing either START button
again.
NOTE:
LifeSource Health Line (Toll-Free): 1-888-726-9966
E-11
What Is Blood Pressure?
Blood pressure is the force exerted by blood against the walls of the
arteries. Systolic pressure occurs when the heart contracts; diastolic
pressure occurs when the heart expands. Blood pressure is measured in
millimeters of mercury (mmHg).
What Affects Blood Pressure?
Blood pressure is affected by many factors: age, weight, time of day,
activity level, climate, altitude and season. Certain activities can signifi-
cantly alter one’s blood pressure. Walking can raise systolic pressure by
12 mmHg and diastolic pressure by 5.5 mmHg. Sleeping can decrease
systolic blood pressure by as much as 10 mmHg. Taking your blood
pressure repeatedly without waiting an interval of 5 minutes between
readings, or without raising your arm to allow blood to flow back to the
heart, can also affect it.
In addition to these factors, beverages containing caffeine or alcohol,
certain medications, emotional stress and even tight-fitting clothes can
make a difference in the readings.
What Causes Variations In Blood Pressure?
An individual’s blood pressure varies greatly from day to day and season
to season. For hypersensitive individuals, these variations are even more
pronounced. Normally, blood pressure rises during work or play and falls
to its lowest levels during sleep.
ABOUT BLOOD PRESSURE
In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991
E-12
ABOUT BLOOD PRESSURE
Assessing High Blood Pressure for Adults
The following standards for assessing high blood pressure (without
regard to age or gender) have been established as a guideline. Please note
that other risk factors (e.g. diabetes, obesity, smoking, etc.) need to be
taken into consideration and may affect these figures. Consult with your
physician for an accurate assessment.
JNC7 Classification Table – for adults within the U.S
BP Classification Systolic (mmHg) Diastolic (mmHg)
Normal less than 120 and less than 80
Prehypertension 120-139 or 80-89
Stage 1 Hypertension 140-159 or 90-99
Stage 2 Hypertension 160 or 100
SOURCE:
WHO Classification Table – for adults outside of the U.S.
(e.g. Canada, Mexico)
BP Classification Systolic (mmHg) Diastolic (mmHg)
Optimal less than
120 and less than 80
Normal less than 130 or less than
85
High-Normal 130-139 or 85-89
Stage 1 Hypertension 140-159 or 90-99
Stage 2 Hypertension 160-179 or 100-109
Stage 3 Hypertension 180 or 110
SOURCE:
greater than
or equal to
greater than
or equal to
greater than
or equal to greater than
or equal to
LifeSource Health Line (Toll-Free): 1-888-726-9966
E-13
What Is Hypertension?
Hypertension (high blood pressure) is the diagnosis given when readings
consistently rise above normal. It is well known that hypertension can
lead to stroke, heart attack or other illness if left untreated. Referred to as a
“silent killer” because it does not always produce symptoms that alert you
to the problem, hypertension is treatable when diagnosed early.
Can Hypertension Be Controlled?
In many individuals, hypertension can be controlled by altering lifestyle
and minimizing stress, and by appropriate medication prescribed and
monitored by your doctor. The American Heart Association recommends
the following lifestyle suggestions to prevent or control hypertension:
Don’t smoke. Have regular
Reduce salt and fat intake. physical checkups.
Maintain proper weight. Monitor your blood
Exercise routinely. pressure at periodic
intervals.
Why Measure Blood Pressure at Home?
It is now well known that, for many individuals, blood pressure readings
taken in a doctor’s office or hospital setting might be elevated as a result
of apprehension and anxiety. This response is commonly called “white
coat hypertension.”
In any case, self-measurement at home supplements your doctor’s
readings and provides a more accurate, complete blood pressure history.
In addition, clinical studies have shown that the detection and treatment
of hypertension is improved when patients both consult their physicians
and monitor their own blood pressure at home.
ABOUT BLOOD PRESSURE
In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991
E-14
ABOUT BLOOD PRESSURE
Answers to Why Your Readings are Different Between Home
and at the Doctor’s Office
Why are my readings different between home and at a doctor’s office?
Your blood pressure readings taken in a doctor’s office or hospital setting
may be elevated as a result of apprehension and anxiety. This response is
known as white coat hypertension.
When I bring my monitor to a doctor’s office, why do I get a different
measurement from my monitor to that taken by a doctor or nurse?
The healthcare professional may be using a different sized cuff. The size of
the bladder inside the cuff is critical for the accuracy of the measurement.
This may give you a different reading. A cuff too large will produce
a reading that is lower than the correct blood pressure; a cuff that is
too small will produce a reading that is higher than the correct blood
pressure. There may also be other factors that can cause the difference in
measurements.
Keys to Successful Monitoring:
Blood pressure fluctuates throughout the day. We recommend that you are
consistent in your daily measurement routine:
• Measureatthesametimeeveryday.
• Sitinthesamechair/position.
• Donotcrosslegsandkeepyourfeetflatonthefloor.
• Relaxfor5minutesbeforemeasurement.
• Usethecorrectcuffsizetogetanaccuratereading.
• Sitstillduringmeasurement–notalking,eatingorsudden
movements.
• Recordyourmeasurementinalogbook.
LifeSource Health Line (Toll-Free): 1-888-726-9966
E-15
Establishing Baseline Measurements
The most important method to get an accurate blood pressure
measurement is consistency. To get the most benefit out of your monitor,
it is important to establish a “baseline measurement.” This helps build a
foundation of measurements that you can use to compare against future
readings. To build this baseline measurement, devote two weeks for
consistent blood pressure monitoring. This involves doing everything
the same way when you measure (e.g. measuring during the same time
of day, in the same location, sitting in the same chair, using the same
cuff, etc.). Once you establish your baseline measurement, you can start
evaluating if your measurement has been affected based on things like
lifestyle changes or medication treatment.
How Do I Record My Blood Pressure?
Blood pressure readings are typically recorded with the systolic pressure
written first, followed by a slash mark and the diastolic pressure. For
example, 120 mmHg systolic and 80 mmHg diastolic measurements are
written as 120/80. Pulse is simply written with the letter “P” followed by
the pulse rate—P 72, for example. Please see the back of the manual for
the blood pressure tracking record.
Customer Support Tools Online
Additional tools are available on www.LifeSourceOnline.com (in Canada
- www.autocontrol.com) to help you get the most out of your blood
pressure monitoring. These include:
• LargePrintInstructionManuals
• AnimatedOperatingInstructionsforselectmodels
• AdditionalLogbookSheets
ABOUT BLOOD PRESSURE
In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991
E-16
TROUBLESHOOTING
Corrective action
Replace all batteries with
new ones. Alkaline batteries
recommended.
Reinstall the batteries with
negative and positive terminals
matching those indicated in the
battery compartment.
Replace all batteries with
new ones. Alkaline batteries
recommended.
Fasten the cuff correctly.
Make sure you remain very
still and quiet during the
measurement.
Sit comfortably and still. Make
sure the cuff is at the same level
as your heart.
See Pg. E-14 "Answers to Why
Your Readings are Different
Between Home and at the
Doctor's Office."
See Pg. E-13 "Why Measure Blood
Pressure at Home?"
Probable cause
Batteries are drained.
Battery terminals
are not in the correct
position.
Battery voltage is
too low. Low battery
symbol blinks. [If the
batteries are drained
completely, the mark
does not appear.]
The cuff is not fastened
properly.
You moved your arm
or body during the
measurement.
The cuff position is not
correct.
The healthcare profes-
sional may be using a
different sized cuff.
Your measurements
may be elevated
by white coat
hypertension.
Problem
Nothing appears
in the display,
even when the
power is turned
on.
The cuff does not
inflate.
The unit does
not measure.
Readings are too
high or too low.
The value is
different from
that measured
at a clinic or
doctor’s office.
NOTE:
E-17
Model
................................UB-512
Type
.................................Oscillometric
Display
...............................Digital, 10/7-mm character
height, Pressure/Pulse displayed
simultaneously
Memory
..............................60 readings
Measurement range
.....................Pressure: 20 mmHg to 280
mmHg
Pulse: 40 pulses to 180pulses/
minute
Accuracy
.............................Pressure: ± 3 mmHg or ± 2%,
whichever is greater, Pulse: ± 5%
Pressurization
.........................Automatic, using micropump
Depressurization
.......................Constant air release-valve system
Power source
..........................2 type AAA (1.5 volt)
batteries (included)
Battery life
............................Approximately 400
measurements
Operating environment
..................50ºF to 104ºF (10ºC to 40ºC)
Less than 95% relative humidity
Storage environment
....................14ºF to 140ºF (-10ºC to 60ºC)
Less than 95% relative humidity
Wrist Circumference Range
..............5.3–8.5”(13.5–21.5cm),
Dimensions
............................Depth: 0.8” (21 mm), Width: 2.5”
(63 mm), Height: 2.2” (56 mm),
Dimensions with case
...................Length: 4.0” (102 mm),
Width: 3.0” (76 mm), Height: 3.3”
(83 mm), approximately
Weight
...............................2.9 oz. (82 g) without batteries
Blood pressure measurements determined by the UB-512 are equivalent to those obtained by a trained
observer using the cuff/stethoscope auscultation method within the limits prescribed by the American
National Standards Institute for electronic or automated sphygmomanometers.
SPECIFICATIONS
Other manuals for ADVANCE MEMORY WRIST UB512
3
Table of contents
Other LifeSource Blood Pressure Monitor manuals
LifeSource
LifeSource UA-767 Plus Manual
LifeSource
LifeSource UA-767T User manual
LifeSource
LifeSource UB-351 User manual
LifeSource
LifeSource UA-767 Plus Manual
LifeSource
LifeSource UA-767T Manual
LifeSource
LifeSource ADVANCE MEMORY WRIST UB512 Manual
LifeSource
LifeSource UA-100 Manual
LifeSource
LifeSource ADVANCE MEMORY WRIST UB512 User manual
LifeSource
LifeSource UA-853 Manual
LifeSource
LifeSource UA-851V User manual
LifeSource
LifeSource UA-851 Manual
LifeSource
LifeSource UA-705 Manual
LifeSource
LifeSource UA-767 Manual
LifeSource
LifeSource UA-767T User manual
LifeSource
LifeSource UA-100 Manual
LifeSource
LifeSource UA-851THW User manual
LifeSource
LifeSource UA-774 Manual
LifeSource
LifeSource UA-787W User manual
LifeSource
LifeSource ADVANCE MEMORY WRIST UB512 Manual
LifeSource
LifeSource UB-521CN Manual
