LifeSource ADVANCE MEMORY WRIST UB512 Manual

Trilingual Instruction Guide – MODEL UB-512
English • Français • Español
DUAL MEMORY WRIST
Blood Pressure Monitor

Please read this important information before using your monitor.
☞
Please remember that only a medical practitioner is qualified to interpret
your blood pressure measurements. Use of this device should not replace
regular medical examinations.
☞
Have your physician review your procedure for using this device. He or
she will want to verify blood pressure measurements before prescribing or
adjusting medications.
☞
Consult your physician if you have any doubt about your readings. Should
a mechanical problem occur, contact A&D Medical.
☞
Make sure to use the correct cuff size when measuring your blood
pressure.
☞
Do not attempt to service, calibrate, or repair this monitor.
☞
Because your UB-512 monitor contains delicate, high-precision parts,
avoid exposing it to extremes in temperature or humidity or to direct
sunlight, shock and dust. A&D Medical guarantees the accuracy of this
monitor only when it is stored and used within the temperature and
humidity ranges noted on page E-17.
☞
Clean the monitor and cuff with a dry, soft cloth or a cloth dampened with
water and a mild detergent. Never use alcohol, benzene, thinner or other
harsh chemicals to clean monitor or cuff.
☞
Remove and replace batteries if monitor is not used for more than
six months. Alkaline batteries recommended.
PRECAUTIONS
The UB-512 is designed to be used at home, by those who are eighteen (18) years
and older, to monitor blood pressure (systolic and diastolic) and pulse rate.
IMPORTANT INFORMATION ✓

Fast. Easy. Accurate.
Congratulations on purchasing a state-of-the-art
LifeSource®blood pressure monitor—one of the most
technologically advanced monitors available today.
Designed for ease of use and accuracy, this monitor
will facilitate your daily blood pressure regimen.
Physicians agree that daily self-monitoring of blood pressure
is an important step individuals can take to maintain
cardiovascular health and prevent the serious consequences
associated with undetected and untreated hypertension.
A&D Medical has been manufacturing high quality
healthcare products for over 20 years. We are committed to
providing you and your family with monitoring devices that
provide the utmost in accuracy and convenience.
LifeSource - Designed for Life.
LifeSource Health Line (Toll-Free): 1-888-726-9966

E-1
?WHAT DISPLAY SYMBOLS MEAN . . . . . . . . . . . . .E-2
MONITOR COMPONENTS . . . . . . . . . . . . . . . . . . E-3
HOW UB-512 WORKS . . . . . . . . . . . . . . . . . . . . . E-4
BEFORE YOU START . . . . . . . . . . . . . . . . . . . . . E-4
TAKING YOUR BLOOD PRESSURE . . . . . . . E-5 — E-7
WHAT IS AN IRREGULAR HEARTBEAT . . . . . . . . .E-8
ABOUT CUFF INFLATION METER . . . . . . . . . . . . .E-8
ABOUT AVERAGE READING . . . . . . . . . . . . . . . . .E-9
ABOUT PRESSURE RATING INDICATOR™ . . . . . . .E-9
ABOUT MEMORY . . . . . . . . . . . . . . . . . . . . . . .E-10
ABOUT BLOOD PRESSURE . . . . . . . . . . E-11 — E-15
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . .E-16
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . E-17
CONTACT INFORMATION . . . . . . . . . . . . . . . . . E-18
FRENCH INSTRUCTIONS . . . . . . . . . . . . . . . . . . . F-1
SPANISH INSTRUCTIONS . . . . . . . . . . . . . . . . . . S-1
TABLE OF CONTENTS
In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991

E-2
?WHAT DISPLAY SYMBOLS MEAN
?
Display
Sy bol
Battery Full
Battery Low
PULSE DISPLAY ERROR
Reco ended
Action
Measurement is in progress,
remain as still as possible.
Take measurement again and
consult with your physician.
Replace all batteries with new
ones when the symbol blinks.
Alkaline batteries recommended.
Try the measurement again.
Remain very still during the
measurement.
Fasten the cuff correctly, and try
the measurement again.
Check cuff to ensure fit and
fastening is correct, and
measure again.
Refasten the cuff and retake
measurement.
Try the measurement again.
Remain very still during
the measurement.
Measurement is in progress,
remain as still as possible.
Refer to the section “About
Pressure Rating Indicator™” for
further explanation
Condition/Cause
The symbol shown while
measurement is in progress. It
blinks while detecting the
pulse.
An irregular heartbeat or
body movement may have
occurred. Refer to page E-8
for more information on
irregular heartbeats.
Previous measurement stored
in MEMORY.
The battery power indicator
during measurement.
The batteries are low when it
blinks.
Unstable blood pressure due
to excessive body movement.
The systolic and diastolic
values are within 10 mmHg
of each other.
The pressure value did not
increase during inflation.
The cuff is not fastened
correctly.
The pulse is not detected
correctly.
Cuff Inflation Meter
Pressure Rating Indicator™
LifeSource Health Line (Toll-Free): 1-888-726-9966

E-3
2
1
CASE
AAA
BATTERIES
MONITOR COMPONENTS ?
?
BATTERY
HOLDER
COVER
START BUTTONS
CUFF
SYSTOLIC
PRESSURE
DIASTOLIC
PRESSURE
CUFF
INFLATION
METER
PRESSURE
RATING
INDICATOR
PULSE RATE
In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991

E-4
The UB-512 provides accurate readings on wrists with a circumference between
5.3" and 8.5" (13.5 cm and 21.5 cm).
The unit requires two "AAA" (1.5 volt) batteries to operate (alkaline batteries
recommended). To install batteries (or to replace when "Low Battery" symbol
appears), proceed as follows:
1. Slide the battery cover as shown to remove
from the device
2. Insert batteries into designated areas ensuring
a correct match with positive (+) and negative
(-) terminals.
3. Return battery cover by sliding back on to
monitoring device.
NOTE: Rechargeable batteries will not work with this monitor.
HOW UB-512 WORKS
?
BEFORE YOU START
LifeSource®Blood Pressure Monitors are easy to use, accurate and display clear
digital measurements. Our technology is based on the “oscillometric method”. The
term “oscillation” refers to the measure of vibrations caused by the arterial pulse
and is a non-invasive method to determine blood pressure.
Our monitors examine the pulsatile pressure generated by the arterial wall as it
expands and contracts with each heartbeat against the monitor’s cuff. This monitor
measures your blood pressure while the cuff is inflating.
LifeSource Health Line (Toll-Free): 1-888-726-9966
?!

E-5
The UB-512 has several modes available to fit your blood pressure monitoring
needs.
Normal Measurement with Readings Stored in Memory
Press the START 1 or START 2 button. Your blood pressure is measured and the
reading is stored into memory. Each START button can store up to 30 readings in
memory.
Recalling Previous Measurements
To recall previous measurements in memory, press and hold the START 1 or
START 2 button. Release the button after you see the first reading recalled from
memory. The previous measurements are displayed from most recent to oldest.
Clearing Memory
Remove batteries to clear memory. Insert batteries again to resume blood pressure
measurements.
Taking a Measurement without Reading Stored in Memory (Guest Mode)
This mode can be used when there is a third person taking measurements or
storing readings in memory is not desired. Press both the START 1 and START 2
buttons at the same time. A reading will be taken, but not stored into memory.
TAKING YOUR BLOOD PRESSURE
In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991

E-
TAKING YOUR BLOOD PRESSURE
Tips for Blood Pressure Monitoring:
☞
Relax for about 5 minutes before measurement.
☞
Do not smoke or ingest caffeine at least 30 minutes prior to
measurement.
☞
Remove constricting clothing and place cuff on bare arm.
☞
Unless your physician recommends otherwise, use left arm
to measure pressure.
☞
Do not talk during measurement.
☞
Do not cross legs and keep you feet flat on floor during measurement.
Now you are ready. Follow these simple steps:
1. Sit comfortably in a chair near a flat surface.
2. With palm facing upward, attach monitor to left
wrist and fasten securely. The top edge of the
cuff should align with the crease of your wrist.
3. Position your wrist so it is level with your heart,
using an arm rest if needed. Positioning of the
wrist at heart level is critical for accurate
measurement.
4. Designate yourself as User 1 or User 2. To keep
track of your previous blood pressure
measurements accurately, User 1 should use the
START 1 button (orange color) and User 2
should use the START 2 button (green color).
START
UB-512
2
1
LifeSource Health Line (Toll-Free): 1-888-726-9966

E-7
5. Press the START 1 or START 2 button. Your average blood
pressure reading will appear with the number of measurements
stored in memory (i.e. A25 = total of 25 measurements stored in
memory). As the cuff pressurizes, measurement will begin and
the Cuff Inflation Meter will show on the display screen. It is
normal for the cuff to feel very tight.
NOTE: If viewing measurements or storing readings in
memory are not desired, press both the START 1 and START 2 buttons at
the same time. A reading will be taken, but not stored into memory.
NOTE: To stop inflation at any time, press either START button.
6. As the cuff is inflating, the ❤will appear to indicate that the measurement is
in progress. The monitor measures your blood pressure while the cuff is
inflating, so remain still. Once the pulse is detected, the symbol will flash
with each pulse beat.
7. When measurement is complete, the systolic and
diastolic pressure and pulse rate readings are
displayed. The cuff will automatically deflate
completely, releasing any remaining air.
8. Press START button once to turn off power. The
device has an automatic power-down feature which
turns off power automatically one minute after
measurement is obtained.
For the most useful blood pressure history, we recommend that you record the
date and time after each measurement. The most accurate history relies not on a
single or sporadic readings, but on a consistent monitoring pattern over time.
NOTE: If you wish to take your blood pressure measurement again, relax
and wait 5 minutes to enable the flow of blood in the arm to return to
normal.
NOTE: If you have poor blood circulation in winter (especially when your
hands and wrists are cold), you may not get a blood pressure
measurement.
SYSTOLIC
DIASTOLIC
PULSE
TAKING YOUR BLOOD PRESSURE
In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991

E-8
WHAT IS AN IRREGULAR HEARTBEAT
The UB-512 Blood Pressure Monitor provides a blood pressure and pulse rate
measurement even when an irregular heartbeat occurs. The Irregular Heartbeat
symbol will appear in the display window in the event an Irregular
Heartbeat has occured during measurement. An irregular heartbeat is defined as a
heartbeat that varies by 25% from the average of all heartbeat intervals during the
blood pressure measurement. It is important that you relax, remain still and
refrain from talking during measurements.
NOTE: We recommend contacting your physician if you see this
symbol frequently.
ABOUT CUFF INFLATION METER
The Cuff Inflation Meter is located on the left side of the display screen to tell you
when the blood pressure monitor is inflating the cuff. The Cuff Inflation Meter
moves up during inflation.
Inflation in Progress Inflation/Measurement
Complete Measurement Displayed
NOTE: The motor will inflate the cuff at a slow speed starting at 20mmHg
to begin the blood pressure measurement process.
LifeSource Health Line (Toll-Free): 1-888-726-9966

E-9
The UB-512 provides an average blood pressure reading based
on the total measurements stored in memory. When taking a
measurement, the average blood pressure reading will appear and
the number of measurements stored in memory will flash several
times before the cuff begins to inflate. The average blood pressure
reading will also appear briefly when you recall the
measurements stored in memory.
The Pressure Rating Indicator™ is a feature which
provides a snapshot of your blood pressure classification
based on your measurements. This will let you quickly
know what your blood pressure readings mean. Each
segment of the bar indicator corresponds to the Seventh
Report of the Joint National Committee (JNC7) on
Prevention, Evaluation and Treatment of High Blood
Pressure from the National Heart, Lung and Blood
Institute - May 2003. For a more detailed look at this
blood pressure classification, please refer to “Assessing
High Blood Pressure” on page E-12.
:The indicator displays a segment, based on the current measurement,
corresponding to the JNC7 Classification.
NOTE: Due to other risk factors (e.g. diabetes, obesity, smoking, etc.) in
addition to your blood pressure measurement, the Pressure Rating
Indicator is approximate. Please consult with your physician for
interpretation and diagnosis of your blood pressure measurements.
NOTE: Residents outside of the United States (e.g.. Canada and Mexico)
should refer to the WHO Classification Table on page E-12 for assessment
of their blood pressure measurement.
NUMBER OF MEASUREMENTS STORED
IN MEMORY
AVERAGE
ABOUT PRESSURE RATING INDICATOR™
ABOUT AVERAGE READING
In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991

E-10
ABOUT MEMORY
The memory function on the UB-512 blood pressure monitor is designed for two
or more people. For each START button, the monitor can store up to 30 readings
in memory. To keep track of previous measurements accurately, we recommend
that you use the same START button each time you take a blood pressure reading.
To recall previous measurements in memory, press and hold the
START 1 or START 2 button. Your average blood pressure
reading will appear with the number of measurements taken
flashing several times. Release the button after the display
switches to the memory index number (see illustration on right).
The previous measurements are displayed from most recent to
oldest. When viewing previous measurements, you will see the
"M" symbol appear on the upper left corner of this display. You can
stop this by pressing either START button again.
NOTE: Memory will be lost if batteries become low or are
removed.
LifeSource Health Line (Toll-Free): 1-888-726-9966

E-11
What Is Blood Pressure?
Blood pressure is the force exerted by blood against the walls of the arteries.
Systolic pressure occurs when the heart contracts; diastolic pressure occurs when
the heart expands. Blood pressure is measured in millimeters of mercury (mmHg).
What Affects Blood Pressure?
Blood pressure is affected by many factors: age, weight, time of day, activity level,
climate, altitude and season. Certain activities can significantly alter one’s blood
pressure. Walking can raise systolic pressure by 12 mmHg and diastolic pressure
by 5.5 mmHg. Sleeping can decrease systolic blood pressure by as much as 10
mmHg. Taking your blood pressure repeatedly without waiting an interval of 5
minutes between readings, or without raising your arm to allow blood to flow
back to the heart, can also affect it.
In addition to these factors, beverages containing caffeine or alcohol, certain
medications, emotional stress and even tight-fitting clothes can make a difference
in the readings.
What Causes Variations In Blood Pressure?
An individual’s blood pressure varies greatly from day to day and season to season.
For hypersensitive individuals, these variations are even more pronounced.
Normally, blood pressure rises during work or play and falls to its lowest levels
during sleep.
ABOUT BLOOD PRESSURE
In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991

E-12
ABOUT BLOOD PRESSURE
Assessing High Blood Pressure for Adults
The following standards for assessing high blood pressure (without regard to age
or gender) have been established as a guideline. Please note that other risk factors
(e.g. diabetes, obesity, smoking, etc.) need to be taken into consideration and may
affect these figures. Consult with your physician for an accurate assessment.
JNC7 Classification Table – for adults within the U.S
BP Classification Systolic ( Hg) Diastolic ( Hg)
Normal less than 120 and less than 80
Prehypertension 120-139 or 80-89
Stage 1 Hypertension 140-159 or 90-99
Stage 2 Hypertension 160 or 100
SOURCE: The Seventh Report of the Joint National Committee on
Prevention, Evaluation and Treatment of High Blood Pressure for adults.
National Heart, Lung and Blood Institute - May 2003.
WHO Classification Table – for adults outside of the U.S.
(e.g. Canada, Mexico)
BP Classification Systolic ( Hg) Diastolic ( Hg)
Optimal less than 120 and less than 80
Normal less than 130 or less than 85
High-Normal 130-139 or 85-89
Stage 1 Hypertension 140-159 or 90-99
Stage 2 Hypertension 160-179 or 100-109
Stage 3 Hypertension 180 or 110
SOURCE: Standards to assess high blood pressure, without regard to age
or gender, have been established by the World Health Organization (WHO).
greater than
or equal to
greater than
or equal to
greater than
or equal to greater than or equal to
LifeSource Health Line (Toll-Free): 1-888-726-9966

E-13
What Is Hypertension?
Hypertension (high blood pressure) is the diagnosis given when readings consis-
tently rise above normal. It is well known that hypertension can lead to stroke,
heart attack or other illness if left untreated. Referred to as a “silent killer” because
it does not always produce symptoms that alert you to the problem, hypertension
is treatable when diagnosed early.
Can Hypertension Be Controlled?
In many individuals, hypertension can be controlled by altering lifestyle and
minimizing stress, and by appropriate medication prescribed and monitored by
your doctor. The American Heart Association recommends the following lifestyle
suggestions to prevent or control hypertension:
Don’t s oke. Have regular
Reduce salt and fat intake. physical checkups.
Maintain proper weight. Monitor your blood
Exercise routinely. pressure at periodic
intervals.
Why Measure Blood Pressure at Ho e?
It is now well known that, for many individuals, blood pressure readings taken in
a doctor’s office or hospital setting might be elevated as a result of apprehension
and anxiety. This response is commonly called “white coat hypertension.”
In any case, self-measurement at home supplements your doctor’s readings and
provides a more accurate, complete blood pressure history. In addition, clinical
studies have shown that the detection and treatment of hypertension is improved
when patients both consult their physicians and monitor their own blood pressure
at home.
ABOUT BLOOD PRESSURE
In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991

E-14
ABOUT BLOOD PRESSURE
Answers to Why Your Readings are Different
Between Ho e and at the Doctor’s Office
Why are my readings different between home and at a doctor’s office?
Your blood pressure readings taken in a doctor’s office or hospital setting may be
elevated as a result of apprehension and anxiety. This response is known as white
coat hypertension.
When I bring my monitor to a doctor’s office, why do I get a different
measurement from my monitor to that taken by a doctor or nurse?
The healthcare professional may be using a different sized cuff. The size of the
bladder inside the cuff is critical for the accuracy of the measurement. This may
give you a different reading. A cuff too large will produce a reading that is lower
than the correct blood pressure; a cuff that is too small will produce a reading that
is higher than the correct blood pressure. There may also be other factors that can
cause the difference in measurements.
Keys to Successful Monitoring:
Blood pressure fluctuates throughout the day. We recommend that you are
consistent in your daily measurement routine:
• Measure at the same time every day.
• Sit in the same chair/position.
• Do not cross legs and keep your feet flat on the floor.
• Relax for 5 minutes before measurement.
• Use the correct cuff size to get an accurate reading.
• Sit still during measurement – no talking, eating or sudden movements.
• Record your measurement in a logbook.
LifeSource Health Line (Toll-Free): 1-888-726-9966

E-15
Establishing Baseline Measurements
The most important method to get an accurate blood pressure measurement is
consistency. To get the most benefit out of your monitor, it is important to
establish a “baseline measurement.” This helps build a foundation of
measurements that you can use to compare against future readings. To build this
baseline measurement, devote two weeks for consistent blood pressure
monitoring. This involves doing everything the same way when you measure (e.g.
measuring during the same time of day, in the same location, sitting in the same
chair, using the same cuff, etc.). Once you establish your baseline measurement,
you can start evaluating if your measurement has been affected based on things
like lifestyle changes or medication treatment.
How Do I Record My Blood Pressure?
Blood pressure readings are typically recorded with the systolic pressure written
first, followed by a slash mark and the diastolic pressure. For example, 120
mmHg systolic and 80 mmHg diastolic measurements are written as 120/80.
Pulse is simply written with the letter “P” followed by the pulse rate—P 72, for
example. Please see the back of the manual for the blood pressure tracking record.
Customer Support Tools Online
Additional tools are available on www.LifeSourceOnline.com (in Canada -
www.autocontrol.com) to help you get the most out of your blood pressure
monitoring. These include:
• Large Print Instruction Manuals
• Animated Operating Instructions for select models
• Additional Logbook Sheets
ABOUT BLOOD PRESSURE
In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991

E-1
TROUBLESHOOTING
Corrective action
Replace all batteries with new ones.
Alkaline batteries recommended.
Reinstall the batteries with negative
and positive terminals matching
those indicated in the battery
compartment.
Replace all batteries with new ones.
Alkaline batteries recommended.
Fasten the cuff correctly.
Make sure you remain very still and
quiet during the measurement.
Sit comfortably and still. Make sure
the cuff is at the same level as your
heart.
Relax five minutes before each
measurement.
See Pg. E-14 "Answers to Why Your
Readings Are Different Between
Home and the Doctor’s Office."
See Pg. E-13 "Why Measure Blood
Pressure at Home."
Probable cause
Batteries are drained.
Battery terminals are not
in the correct position.
Battery voltage is too low.
Low battery symbol
blinks. [If the batteries are
drained completely, the
mark does not appear.]
The cuff is not fastened
properly.
You moved your arm or
body during the
measurement.
The cuff position is not
correct.
Taking too many readings
on the same arm in a
short period of time.
The healthcare profes-
sional may be using a
different sized cuff.
Your measurements may
be elevated by white coat
hypertension.
Problem
Nothing appears in
the display, even
when the power is
turned on.
The cuff does not
inflate.
The unit does not
measure. Readings
are too high or too
low.
The value is
different from that
measured at a clinic
or doctor’s office.
NOTE: If the actions described above do not solve the problem, call
1-888-72 -99 (In Canada - 1-800-4 1-0991). Do not attempt to repair
the device yourself.
LifeSource Health Line (Toll-Free): 1-888-726-9966

E-17
Model . . . . . . . . . . . . . . . . . . . . . . . . . . . UB-512
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Oscillometric
Display . . . . . . . . . . . . . . . . . . . . . . . . . . Digital, 10/7-mm character height,
Pressure/Pulse displayed simulta-
neously
Me ory . . . . . . . . . . . . . . . . . . . . . . . . . 60 readings
Measure ent range . . . . . . . . . . . . . Pressure: 20 mmHg to 280 mmHg
Pulse: 40 pulses to 180pulses/minute
Accuracy . . . . . . . . . . . . . . . . . . . . . . . . . Pressure: ± 3 mmHg or ± 2%,
whichever is greater, Pulse: ± 5%
Pressurization . . . . . . . . . . . . . . . . . . . Automatic, using micropump
Depressurization . . . . . . . . . . . . . . . . Constant air release-valve system
Power source . . . . . . . . . . . . . . . . . . . . 2 type AAA (1.5 volt)
batteries (included)
Battery life . . . . . . . . . . . . . . . . . . . . . . Approximately 400 measurements
Operating environ ent . . . . . . . . . . 50ºF to 104ºF (10ºC to 40ºC)
Less than 95% relative humidity
Storage environ ent . . . . . . . . . . . . 14ºF to 140ºF (-10ºC to 60ºC)
Less than 95% relative humidity
Wrist Circu ference Range . . . . . . 5.3 – 8.5”(13.5 – 21.5 cm),
Di ensions . . . . . . . . . . . . . . . . . . . . . . Depth: 0.8” (21 mm), Width: 2.5”
(63 mm), Height: 2.2” (56 mm),
Di ensions with case . . . . . . . . . . . Length: 4.0” (102 mm), Width: 3.0”
(76 mm), Height: 3.3” (83 mm),
approximately
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.9 oz. (82 g) without batteries
Blood pressure easure ents deter ined by the UB-512 are equivalent to
those obtained by a trained observer using the cuff/stethoscope auscultation
ethod within the li its prescribed by the A erican National Standards
Institute for electronic or auto ated sphyg o ano eters.
SPECIFICATIONS
In Canada - Auto Control Medical (Toll-Free): 1-800-461-0991
