INSTRUCTION MANUAL
PORTABLE WRIST
BLOOD PRESSURE
MONITOR
Model HEM-629
R
Distributed by:
OMRON HEALTHCARE, INC.
300 Lakeview Parkway
Vernon Hills, Illinois 60061
www.omron. om/ohi
Copyright © 2000 Omron Health are, In .
Made in China
629INST Rev A
For Customer Service
Call Toll Free
1-800-634-4350

TABLE OF CONTENTS
2
Introduction ……………………………………………………………3
Know Your Unit…………………………………………………………4
Battery Installation/Replacement………………………………………5
Suggestions Before Measuring Blood Pressure ………………………6
How To Apply The Wrist Cuff …………………………………………7
How To Take A Reading ……………………………………………8-9
Memory Feature Instruction …………………………………………10
Troubleshooting ………………………………………………………11
Caution ………………………………………………………………12
Care and Maintenance ………………………………………………13
Warranty………………………………………………………………14
Specifications …………………………………………………………15
INTRODUCTION
3
Thank you for pur hasing the Omron HEM-629 Portable Wrist Blood
Pressure Monitor. This remarkable instrument is ideal for people
who frequently monitor their own blood pressure be ause it’s so
ompa t and easy to use. There is no tri ky arm uff, just a small,
pre-formed wrist uff that is easy to apply. With the push of a button
the Omron Wrist Monitor measures your blood pressure and pulse
rate and displays the reading on a lear digital panel. Perfe t for
qui k, easy readings at home, at work, and during travel.
The Omron Wrist Monitor uses the os illometri method of
blood pressure measurement. This means the monitor dete ts
your blood’s movement through the artery in your wrist and
onverts the movements into a digital reading. An os illometri
monitor does not need a stethos ope so the monitor is simple to
use and measurements are easy to obtain.
Clini al resear h has proven a dire t relationship between blood
pressure in the wrist and blood pressure in the arm. Changes in wrist
bloodpressure refle t hanges in arm blood pressure be ause the arteries
in the wrist and the arm are lose to ea h other. Frequently measuring the
blood pressure in your wrist will provide you and your do tor with an
a urate indi ation of hanges in your blood pressure.
Consult your physcician before measuring blood pressure
at the wrist if you have any of the following conditions:
severe hypertension, severe diabetes, severe arterialsclerosis,
severe kidney disease, or vasculor disease that may
compromise circulation.
Please read this instruction manual thoroughly before
using the Omron Portable Wrist Blood Pressure onitor.
For specific information on your own blood pressure,
CONTACT YOUR PHYSICIAN.

SUGGESTIONS BEFORE
MEASURING BLOOD PRESSURE
1. Eating, smoking, and exer ising within 30 minutes
before taking a measurement may affe t your blood
pressure. To take baseline blood pressure, rest for
at least 5 minutes before taking a reading.
2. Mental stress raises blood pressure.
3. Throughout the measurement, the
unit should be held at your heart
level. The arring ase is large
enough to raise the arm to
heart level.
4. Remain still and do not talk
during the measurement.
4
KNOW YOUR UNIT
5
Systolic Blood Pressure
Diastolic Blood Pressure/
Pulse Rate
ON/OFF Button
START Button
Wrist Cuff
Battery Cover
MEMORY
button “M”
Digital Display

BATTERY INSTALLATION/REPLACEMENT
6
1. Slide the battery over off
in the dire tion of the arrow.
2. Insert or repla e 2 "AAA" size
batteries so that the + (positive)
and - (negative) markings
mat h those in the battery
ompartment.
3. Repla e the battery over.
4. If the Low Battery Indi ator
appears on the display, repla e
both batteries. Long-life alkaline
batteries are re ommended.
5. Remove the batteries if the
monitor will not be used for
an extended period of time.
Low Battery Indicator
HOW TO APPLY THE WRIST CUFF
7
1. Hold your left arm in front of you
with your palm fa ing up. Apply
the uff so that the monitor is on
the inside of your wrist with the
display in easy view.
2. The uff’s edge should be
approximately 1/4 to 1/2 in h
from below your palm.
3. Wrap the uff snugly around your
wrist. The top and bottom edges
of the uff should be tightened
evenly around your wrist.
4. When the uff is positioned
orre tly, se ure it in pla e by
pressing the pile material firmly
against the hook material.
SYSTOLIC
mmHg
DIASTOLIC
mmHg
PULSE/min
ON/OFF
START
1/4" - 1/2"
SYSTOLIC
mmHg
DIASTOLIC
mmHg
PULSE/min
ON/OFF
START

HOW TO TAKE A READING
8
1. Press the ON/OFF Button.
a) All the display symbols appear
for approximately one se ond.
This is the initial LCD test.
b) The display symbols disappear
and the Deflation Indi ation
Symbol ( ) starts to flash.
c) When the monitor ompletes
the ne essary preparations
before measurement, the
Heart Symbol (♥)appears
with a zero.
➧
2. Hold the unit at your heart level and press the START button.
The uff automati ally inflates to approximately 180 mm Hg.
a) Keep the unit at the heart level until the measurement is ompleted.
Read and follow directions in "Suggestions Before
Measuring Blood Pressure" and "How To Apply
The Wrist Cuff" before taking a reading.
SYSTOLIC mm Hg
DIASTOLIC mm Hg
PULSE/min
SYSTOLIC mm Hg
DIASTOLIC mm Hg
PULSE/min
SYSTOLIC mm Hg
DIASTOLIC mm Hg
PULSE/min
HOW TO TAKE A READING
SYSTOLIC mm Hg
DIASTOLIC mm Hg
PULSE/min
SYSTOLIC mm Hg
DIASTOLIC mm Hg
PULSE/min
SYSTOLIC mm Hg
DIASTOLIC mm Hg
PULSE/min
b) If during your measurement (deflation) the
monitor determines that a higher pressure
value is required, it will momentarily stop
deflation and automati ally in rease the
pressure value to 230 mmHg.
c) To inflate higher than 230 mm Hg, during
deflation press and hold the START button
until the ne essary pressure value is rea hed.
DO NOT INFLATE HIGHER THAN 280 mmHg.
3. When the uff rea hes your orre t inflation
level, it begins to deflate automati ally.
As the uff deflates, de reasing numbers
appear on the display. The Heart Symbol
(♥)flashes at every heart.
4. The monitor exhausts the residual air when the
measurement is omplete. The Heart Symbol
(♥) stops flashing and your blood pressure
and pulse rate display alternately.
NOTE: Wait 2-3 minutes before taking another blood pressure
measurement. Waiting allows the engorged blood vessels to return
to normal. You may require more rest time between readings depending
on your individual physiologi al hara teristi s.
Remember To Keep A Record Of Your Blood Pressure And
Pulse easurements.
9

TROUBLESHOOTING
11
NOTES:
- Wait 2-3 minutes before taking another measurement.
- If you ontinue to have diffi ulty obtaining a reading, all
O RON HEALTHCARE CUSTO ER SERVICE
TOLL FREE 1-800-634-4350. Please tell the representative
you have an Omron HEM-629 Portable Wrist Blood Pressure Monitor.
Error Indicator Cause Correction
Cuff under-inflated
Movement during
measurement.
No pulse or blood pressure
reading due to very weak
pulse.
Cuff over-inflated (more
than 300 mmHg).
Battery voltage is
ex essively low
Repla e both “AAA” batteries
(See page 5).
Retake measurement by setting
uff inflation level 40 mmHg
higher than previous level, by
keep pressing the START
BUTTON until the uff
pressure rea hes the
ne essary level.
Wrap the uff snugly around
your wrist, arefully read and
repeat steps listed under “How
To Apply The Wrist Cuff”
(page 6).
Release the START BUTTON
before the pressure indi ation
rea hes 280 mmHg or higher.
Be sure not to move and talk
during the measurement.
MEMORY FEATURE INSTRUCTIONS
1. How to store the measured blood pressure values...
The measured and displayed blood pressure and pulse rate readings
are automati ally stored in the memory.
The memory an store the readings of up to fourteen measurements.
The memory stores the most re ent 14 readings. When more than 14 readings
have been taken the earliest readings are erased and repla ed by the most
re ent readings. The memory is not erased when the batteries are repla ed.
2. How to recall previously measured readings from memory...
While the (♥) symbol is displayed, you an re all and display readings
from the memory starting with the previous measured readings.
When you push the MEMORY Button “M”, if there is any measured reading
stored in the memory, M1 indi ating the latest memory, the systoli and the
diastoli blood pressures, and the pulse rate are displayed alternatively.
In order to re all the readings measured previously, push the MEMORY
Button “M” again. The values will be displayed as M2, M3,... et .
If there is no measured reading in the memory, a blank s reen with dashed
lines will be displayed, when the MEMORY Button “M” is pushed.
3. How to erase the memory...
All the measured readings stored in the memory an be erased simultaneously
by operating the buttons as follows:
While the (♥)symbol is displayed, push the MEMORY “M” and the START
Buttons simultaneously. Hold both buttons down for at least two se onds, a
blank s reen with dashed lines will be displayed and the measured readings
stored in the memory will be erased.
10

12
CAUTION
NOTE:
POTENTIAL FOR RADIO/TELEVISION INTERFERENCE (for U.S.A. only)
This produ t has been tested and found to omply with the limits for a
Class B digital devi e, pursuant to part 15 of the FCC rules.These limits
are designed to provide reasonable prote tion against harmful interferen e
in a residential installation. The produ t generates, uses, and an radiate
radio frequen y energy and, if not installed and used in a ordan e with
the instru tions, may ause harmful interferen e to radio ommuni ations.
However, there is no guarantee that interferen e will not o ur in a parti ular
installation. If the produ t does ause harmful interferen e to radio or television
re eption, whi h an be determined by turning the produ t on and off, the user is
en ouraged to try to orre t the interferen e by one or more of the following
measures:
• Reorient or relo ate the re eiving antenna.
• In rease the separation between the produ t and re eiver.
• Conne t the produ t into an outlet on a ir uit different from that
to whi h the re eiver is onne ted.
• Consult the dealer or an experien ed radio/TV te hni ian for help.
POTENTIAL FOR RADIO/TELEVISION INTERFERENCE (for Canada only)
This digital apparatus does not ex eed the Class B limits for radio noise
emissions from digital apparatus as set out in the interferen e- ausing equipment
standard entitled "Digital Apparatus", ICES-003 of the Canadian Department of
Communi ations.
Cet appareil numerique respe te les limites de bruits radioele triques
appli ables aux appareils numeriques de Classe B pres rites dans la
norme sur le materiel brouilleur: "Appareils Numeriques," NMB-003
edi tee par le ministre des ommuni ations.
CAUTION:
Changes or modifications not expressly approved by Omron
Healthcare, Inc. will void the user’s warranty.
LICENSED UNDER U.S. PAT.
4829419, 4942516, 4896260, 4531182, 4825364, 4686622, 4121284
4396976, 4371923, 4471385, 4120583, 4435732, 4672457, 4739396
CARE AND MAINTENANCE
13
To protect your monitor from damage and loss
of warranty, please AVOID the following:
• Subje ting your monitor to extreme temperatures,
humidity, and dire t sunlight.
• Washing or moistening the uff.
• Disassembling the monitor.
• Subje ting the monitor to strong sho ks
(for example, dropping the monitor on the floor).
• Cleaning the monitor with volatile liquids. THE MONITOR
SHOULD BE CLEANED WITH A SOFT, DRY CLOTH.

LIMITED FIVE YEAR WARRANTY
14
Your Omron HEM-629 Portable Wrist Blood Pressure Monitor is warranted to
be free from manufa turing defe ts for a period of five years under normal use.
The five year warranty ex ludes the monitor uff. The uff is warranted for
a one year period. This warranty extends only to the original retail pur haser.
Should repair be needed within the warranty period, ship the unit prepaid to
Omron Health are, In ., Attn: Repair Dept., 300 Lakeview Parkway, Vernon
Hills, IL 60061, in lude $5.00 for the return shipping and insuran e. Be sure
to in lude the model number of your unit and your phone number on
any orresponden e.
We will either repair or repla e (at our option) free of harge any parts
ne essary to orre t defe ts in the materials or workmanship.
The above warranty is omplete and ex lusive. The warrantor expressly
dis laims liability for in idental, spe ial, or onsequential damages of any
nature. (Some states do not allow the ex lusion or limitation of in idental
or onsequential damages, so the above warranty may not apply to you.)
Any implied warranties arising by the operation of law shall be limited in
duration to the term of this warranty. (Some states do not allow limitations
on how long an implied warranty lasts, so the above limitation may not
apply to you.)
This warranty gives you spe ifi legal rights and you may have other rights
whi h vary from state to state. As a ondition to operation of your warranty,
the en losed registration ard must be ompleted and sent to us within
10 days from the date of pur hase.
FOR CUSTOMER SERVICE CALL TOLL FREE:
1-800-634-4350
15
SPECIFICATIONS
Model: HEM-629
Display: Liquid Crystal Digital Display
Measurement Range: Pressure: 0 to 280mmHg
Pulse: 40 to 200/minute
Accuracy/Calibration: Pressure: ±3mmHg or 2% of reading
Pulse: ±5% of reading
Inflation: Automati by ele tri pump
Deflation: Automati deflation system
Rapid Pressure Release: Automati pressure release valve
Pressure Detection: Capa itive pressure sensor
Measurement Method: Os illometri method
Pulse Wave Detection: Capa itive pressure sensor
Power Source: 2 "AAA" batteries
Battery Life: Approximately 1 year when used
on e a day for two minutes*
Operating Temperature/Humidity: 50°F to 104°F (10°C to 40°C)
30 to 85% RH maximum
Storage Temperature/Humidity: 14°F to 140°F (-10°C to 60°C)
10 to 95% RH maximum
Console Weight: Approximately 5 oz. (140g) with batteries
Outer Dimensions: Approximately 3" (l) x 3" (w) x 1 1/2" (h)
(76mm x 76mm x 38mm)
Cuff Dimensions: Approximately 3" x 12" (76mm x 304mm)
Wrist Circumference Range: Approximately 5 1/4" x 7 3/4" (135mm x 195mm)
Accessories: Carrying ase, instru tion manual, 2 "AAA" batteries*
These spe ifi ations are subje t to hange without noti e for purposes of improvement.
* The atta hed batteries are only to onfirm the unit operation. They may run out before
indi ated battery life.
