Lift-rite Titan series User manual

Owner’s Manual, Operating

Instructions Manual, and

Replacement Parts Manual

Lift-Rite Titan Series Hand Pallet Trucks

Models LCR55 and LCS55 Versions

This publication, 1130442/001E, applies to the Lift-Rite Titan Series Hand Pallet Trucks, Models LCR55

and LCS55 versions, and to all subsequent releases of this product until otherwise indicated in new

editions. Changes occur periodically to the information in this publication.

To order additional copies of this manual, part number 1130442/001E, contact your local authorized

Lift-Rite Sales and Service Center.

If you need assistance with your lift truck, contact your local authorized Lift-Rite Sales and Service Center.

For more information please visit www.liftrite.com

TABLE OF CONTENTS

BEFORE YOU BEGIN 2

DELIVERY INSPECTION 2

OPERATING INSTRUCTIONS 2

SAFETY PROCEDURES 3

DAILY INSPECTION 3

MAINTENANCE 4

LUBRICATION 4

PUSH BAR LINKAGE ADJUSTMENT 4

LCR55 MODEL 4

LCS55 MODEL 4

HYDRAULIC SYSTEM 5

ADDING OIL (IF REQUIRED) 5

TROUBLESHOOTING 6

COMPLETE HYDRAULIC ASSEMBLY (PL-30278BN) 7

MODEL LCR55 CHASSIS DIAGRAM 8

MODEL LCS55 CHASSIS DIAGRAM 9

RECYCLE YOUR OLD LIFT-RITE PARTS 10

HAND PALLET TRUCK WARRANTY 11

SELECTED OSHA REGULATIONS FOR LIFT TRUCKS 12

BEFORE YOU BEGIN

Always follow your facility’s rules regarding wearing Personal Protective Equipment such as safety

shoes and protective glasses whenever operating, working with, or assembling or dismantling

hand pallet trucks.

DELIVERY INSPECTION

Visually inspect hand pallet truck frame components and hydraulic unit for damage during

shipment by carrier. If damage is evident, notify delivering carrier immediately and file necessary

claims. Test the hand pallet truck pump for proper operation.

If the hydraulic pump does not respond to movement of the handle, an air lock may have

developed during shipping. To remedy this, go to the user friendly TROUBLESHOOTING

guide in this manual.

OPERATING INSTRUCTIONS

(Read and understand prior to using this product)

To raise the load, push

down on the fingertip

control. Pump the

handle to raise the load

from the floor.

NOTE: The neutral position

disengages the pump from the

lifting mechanism. This frees

the handle, which makes

pulling loads easier. In addition,

the pump is not subject to shock

pressures while the truck is in

motion.

To lower the load, pull

up on the fingertip

control.

For free handle

movement, place the

fingertip control in the

neutral position.

SAFETY PROCEDURES

(Read and understand prior to using this product)

• Read and obey all labels on this product. If you have any questions about these, ask your

supervisor.

• Do not operate this hand pallet truck unless you are authorized and trained to do so.

• Never overload your hand pallet truck. Stay within its rated capacity.

• Do not operate this truck if damaged or not in proper working order.

• Distribute the load evenly on the forks. Do not concentrate loads at one point or load one fork

more than the other.

• When the load impairs visibility, the hand pallet lift truck should be pulled and not pushed.

• Always look where you are operating. Keep a clear view.

• Only handle loads on flat level surfaces. Do not use a loaded truck on inclines or declines.

• Never carry passengers.

• Never put your feet, hands, or any other body part under the frame assembly.

• Always yield right of way to pedestrians.

• Do not allow your hand pallet truck to drop from one level to another. Even a drop of 1 in.

(25 mm) more than doubles the effective load momentarily and results in a loading that can

bend or break components.

• Move loads only with the hand pallet truck in its lowest position.

• Always make sure that the load is stable before moving to eliminate the opportunity for load

shift.

• Use extreme care when rounding corners. Too fast a speed could cause a hand pallet lift truck to

tip. If loaded, the load could shift and fall.

• When not in use, fully lower the forks.

DAILY INSPECTION

At the start of your shift, check the items listed below. Report any malfunctions or unsafe conditions

to your supervisor. Do not use this product until it is repaired.

CHECK

POINTS

Steering Hydraulic

System

Wheels Chassis/

Handle

Lifting/

Lowering

Labels

ACTION Check full

rotation

Check for

excessive oil

on exterior

and check for

function

Check for wear,

damage, and

remove debris

Check for

damage and

remove debris

Check for

function

Check for

readability

MAINTENANCE

LUBRICATION

All pivot points are equipped with permanently lubricated bushings and bearings. To increase

bearing life, it is recommended that a few drops of light machine oil be applied at each pivot point

every 6 months. The thrust plate is equipped with three grease fittings. Apply grease under normal

conditions every 6 months.

PUSH BAR LINKAGE ADJUSTMENT

If the forks do not rise evenly at the tips, or the roller levers begin to drag on the floor, the following

adjustment is necessary:

LCR55 MODEL

• Turn the hand pallet truck over so that the underside of the forks are accessible.

• Remove one split pin (PN-20269B) with a 3/16 in. punch.

• Remove the pin (PN-20227) from the bracket.

• Adjust the eyebolts (PN-20226). Turn counterclockwise to raise the fork tips and clockwise to

lower the fork tips.

• Replace the pin (PN-20227, through the eyebolt and replace the split pin (PN-20269B).

• When adjusted properly, the forks should be 3 in. low height from ground level in the lowered

position.

LCS55 MODEL

• Turn the hand pallet truck over so that the underside of the forks are accessible.

• Remove one split pin (PL-20269) with a 3/16 in. punch.

• Remove the pin (PL-20227) from the bracket.

• Adjust the eyebolts (PL-20226). Turn counterclockwise to raise the fork tips and clockwise to

lower the fork tips.

• Replace the pin (PL-20227), through the eyebolt and replace the split pin (PL-20269).

• When adjusted properly, the forks should be 3 in. (LCS) low height from ground level in the

lowered position.

MAINTENANCE (CONT.)

HYDRAULIC SYSTEM

Your hydraulic system is maintenance free. Do not add hydraulic oil unless there is, or was, a leak.

Use Premium HVI hydraulic oil or equal. Other oils, fluids, or solvents may damage your hydraulic

system. If you suspect additional oil is required, follow these steps:

1. Check for and fix any possible oil leaks.

2. Lower the truck and load with 600 lbs. (approximate).

3. Pump the truck to its maximum lift height.

4. Measure the vertical height of the exposed piston (215030) and refer to the chart below.

ADDING OIL (IF REQUIRED)

1. Place and secure the truck on its right side (release valve facing the floor).

2. Pull up on the release lever (PL-40274BDM) and extend the lift piston fully.

3. Remove screw (221586) and add the amount of oil determined by the chart in step 4.

4. Reinstall screw (221586) but do not tighten. Leave a 1/32 in. gap.

5. Pull up on the release lever (PL-40274BDM) and collapse the lift piston until oil starts to

ooze from the screw.

CAUTION! - It is extremely important that step 5 is performed. Otherwise, air in

the pump can force out the wiper seal (20066). Take care when adding oil not to

introduce impurities into the hydraulic system.

6. Tighten the screw (221586) fully and return the truck upright.

Distance (inches) 5-1/8 in. 4-3/4 in. 4-3/8 in. 4 in. 3-1/2 in. 3-1/8 in. 2-3/4 in. 2-3/8 in.

Oil to add (Fl. Oz.) 0 2.7 3.0 3.4 3.7 4.0 4.4 4.7

TROUBLESHOOTING

CONDITION POSSIBLE CAUSE ACTION

Pump does not lift load. An air lock in the hydraulic

system.

Pull up on fingertip control and hold

while pumping the handle 8 to 10 times

to bleed air from the system.

Lifting, neutral, and lowering

do not function properly.

Chain anchor out of adjustment. Turn nut (21094) on chain anchor

clockwise until pumping action, while in

neutral, does not raise forks.

Forks raise and sink with

pump action.

Dirt or foreign particle caught in

cone valve seat.

Pull up on fingertip control and hold

while pumping the handle 8 to 10 times

to purge the valve system.

Pump does not lift load to

complete raised height.

Pump is low on oil. Check for and fix any leaks. Then add oil

as instructed in the MAINTENANCE

section.

Forks are not lowering

completely.

Push jam nut is loose. Push bars

require adjustment.

Refer to Push Bar Linkage Adjustment

in the MAINTENANCE section.

COMPLETE HYDRAULIC ASSEMBLY (PL-30278BN)

ITEM DESCRIPTION QTY PART NO.

COMPLETEHYDRAULIC ASSEMBLY:

Includes standard pump, standard-

handle, and black nylon steer

wheels.

PL-30278BN

1 COMPLETE HANDLE (ITEMS 2-10) 1 PL-40276M

2SPLIT PIN 120105

3 CONTROL LEVER 1 PL-40274BDM

4CONTROL LEVER SLEEVE 154140

5 CONTROL LEVER SPRING 1 218182

6CHROME BALL 220065

7 CONTROL ROD ASSEMBLY 1 215775

8SPLIT PIN 120461

9 AXLE 1 47930

10 ROLLER W/BUSHING 1202755

11 AXLE 1 7500086

12 ADJUSTING NUT 121094

13 LOCKING PIN 1 220312

14 LOWERING ARM 1215128

15 COVER 2 156623BT

16 LOCKING RING 120043

17 SLEEVE 1 215803

18 WASHER 1215282

19 SPRING 1 215156

20 PISTON 1215030

21 PISTON 1 215286

22 SEALING RING 17500105CE

23 LOCKING RING 1 20642

24 SEALING 120066

25 SEALING 1 215866

26 SEALING 1215867

27 LOCKING PIN 1 20014

28 BUSHING 2215913

29 SCREW 1 221586

30 O-RING 124213

31 WASHER 1 235545

32 SPRING 139106

33 VALVE CONE 1 223935

34 SCREW (OVERLOAD) 1221232

35 O-RING (OVERLOAD) 1 22032

36 SPRING (OVERLOAD) 1221227

37 GUIDE PIN (OVERLOAD) 1 221231

38 BALL (OVERLOAD) 122055

39 BALL 1 20065

40 WASHER 1215288

41 O-RING 1 22032

42 VALVE BODY 17500112

43 SPRING 1 47071

45 U-RING 17500100

46 PISTON 1 7500116

47 LOWERING VALVE (COMPLETE) 17518604CE

48 BALL BEARING 1 213056

49 LOCKING PIN 1220312

50 LOCKING PIN 2 20001

51 THRUST PLATE 1215092

52 LOCKING PIN 1 21737

53 GREASE NIPPLE 127662

54 LOCKING RING 2 20019

55 SPACER 2161637

(REQUIRED WITH 200965BT ONLY)

56 AXLE 1220310

57 BEARING 4 22226

58 WHEEL COMPLETE

NYLON 2 251189

POLY 2160422

POLY/STEEL 2 200965BT

STEEL 2160433

60 HYDRAULIC UNIT 1 220069

REBUILD KIT 1243772

ITEM DESCRIPTION QTY PART NO.

MODEL LCR55 CHASSIS DIAGRAM

ITEM DESCRIPTION QTY PART NO.

1 CHASSIS 1 (CONSULT FACTORY)

(SPECIFY LENGTH AND WIDTH)

2 TORSION BAR 1

20.5 IN. WIDE TRUCK PN-30201

27 IN. WIDE TRUCK PN-30202

3BUSHING 1PN-20203A

4 BULKHEAD PIN 2 PN-20204

5SPLIT PIN 220174

6 EYE BOLT PIN 2 PN-20227

7SPLIT PIN 2PN-20269B

8 THRUST PLATE PIN 2 166701

(W/GREASE FITTING)

9 BUSHING 2 PL-30206

10 GREASE FITTING 227662

11 EYE BOLT 2 PN-20226

12 JAM NUT 2PN-10224AF

13 BUSHING 2 PN-20226A

14 PUSH BAR

36 IN. LONG FORK 2 PN-20224X36

42 IN. LONG FORK 2PN-20224X42

48 IN. LONG FORK 2 PN-20224X48

15 EXIT ROLLER 2PN-20220

16 BUSHING 4 PL-20206

17 BUSHING 4PN-20203

18 LEVER ARM ASSEMBLY W/BUSHINGS 2 PN-20212

19 SPLIT PIN 4PN-20269

20 FORK PIN 2 PN-20219

21 LOAD ROLLER

NYLON W/BEARINGS 2 PL-20210BN-B

POLY W/BEARINGS 2167609

STEEL W/BEARINGS 2 PL-20210S-BRG

22 LOAD ROLLER BEARING 4PL-20214

23 AXLE ASSEMBLY 2 PL-20215

24 LOCK NUT 2PL-10218

MODEL LCS55 CHASSIS DIAGRAM

ITEM DESCRIPTION QTY PART NO.

25 CHASSIS 1 (CONSULT FACTORY)

(SPECIFY LENGTH & WIDTH)

26 TORSION BAR 1 (CONSULT

(SPECIFY TRUCK WIDTH) FACTORY)

27 BUSHING 2 PL-20203A

28 GREASE FITTING 227662

29 THRUST PLATE PIN 2 166701

(W/GREASE FITTING)

30 BUSHING 2 PL-30206

31 BULKHEAD PIN 2PL-20204

32 SPLIT PIN 6 PL-20269

33 EYE BOLT PIN 2PL-20227

35 EYE BOLT 2 PL-20226

36 JAM NUT 2PL-10224AF

37 BUSHING 2 PL-20226A

38 PUSH BAR

36 IN. LONG FORK 2 PL-20224X36

60 IN. LONG FORK 21124207-002

72 IN. LONG FORK 2 1124207-003

96 IN. LONG FORK 21124210-002

39 BUSHING 4 PL-20206

41 EXIT ROLLER 2PL-20220

42 FORK PIN 2 PL-20219

43 BUSHING 4PL-20203

44 LEVER ARM W/BUSHINGS 2 PL-20212

45 LOAD ROLLER

NYLON W/BEARINGS 2 PL-20210BN-B

POLY W/BEARINGS 2167609

STEEL W/BEARINGS 2 PL-20210S-BRG

46 LOAD ROLLER BEARING 2PL-20214

47 AXLE ASSEMBLY 2 PL-20215

48 LOCK NUT 2 PL-10218

RECYCLE YOUR OLD LIFT-RITE PARTS

Chassis Steel

Roller suspension Steel and cast iron

Bushings Brass

Grease fittings Steel

Rollers Nylon, polyurethane, steel

Hydraulic body Cast iron

Thrust plate Cast iron

Handle Steel

Wheel Nylon, polyurethane, steel

Bushings Brass

Hydraulic oil Disposal in accordance with local regulations

Assembly parts Steel, brass, nylon

HAND PALLET TRUCK WARRANTY

The Lift-Rite Titan Series Hand Pallet Trucks, Models LCR55 and LCS55 versions, are warranted against defects

in materials and workmanship for a period of two (2) years for the hydraulic pump, one (1) year for the truck

chassis, and six (6) months for wearable components. All periods begin from date of installation.

Wearable Components include but are not limited to:

• Wheels, Rollers, and Bearings

• Oilite Bearings and Bushings

Components found to be defective by an authorized Lift-Rite Sales and Service Center during the warranty

period will be replaced or repaired as indicated above. Replacement components installed during the defined

period set forth above, are warranted for the balance of the applicable truck warranty period, or 90 days,

whichever is longer. Additionally, freight charges for parts involved in the replacement or repair of a defective

component will be paid by Lift-Rite, provided that the replacement or repair is made by an authorized Lift-Rite

Sales and Service Center. Labor or miscellaneous costs involved in the replacement of any components

determined to be defective are not covered. Local taxes, if any, are excluded.

This warranty is void in the event of defects or damage caused by misuse, abuse, or accident. Any truck used

under adverse conditions, such as fish, meat or poultry processing plants, tanneries, freezer applications, or

any other application where the unit is operating in water or subjected to fluid or chemicals is NOT covered

under any warranty.

This warranty does not cover oil leaks, adjustments, or loose hardware.

Lift-Rite reserves the right to make changes and improvements in design without making changes to

previously manufactured vehicles.

Notwithstanding any other language contained herein, this warranty is expressly voided without any further

notice if any modification is made to the Lift-Rite equipment, or if additional components or devices are added

to the Lift-Rite equipment, without prior approval having been granted in writing by Lift-Rite.

SELECTED OSHA REGULATIONS FOR LIFT TRUCKS

Note: Some or all of the following may not be applicable to your hand pallet lift truck.

The use of forklift trucks in the workplace is governed by various regulations. In the United States, the Federal

Occupational Safety and Health Administration (OSHA) has issued regulations which cover the majority of workplaces.

In addition, several states have implemented regulations which apply instead of the Federal regulations.

Check with your local OSHA office or provincial Labor Bureau to confirm which regulations govern your workplace.

Because of their wide applicability, this section of your manual lists several parts of the Federal OSHA regulations that

might be of particular importance to your workplace.

The full text of the Federal regulations can be found in the Code of Federal Regulations at 29 CFR Section 1910.178.

The following citations are followed by a reference to the appropriate subparagraph of the regulations.

• Modifications and additions which affect capacity and safe operation shall not be performed by the customer or

user without manufacturers prior written approval. Capacity, operation and maintenance instruction plates, tags

or decals shall be changed accordingly. (a) (3)

• The user shall see that all nameplates and markings are in place and are maintained in a legible condition. (a) (6)

• The employer shall ensure that each powered industrial truck operator is competent to operate a powered

industrial truck safely, as demonstrated by the successful completion of the training and evaluation specified in

this paragraph. (l) (1) (i)

• Prior to permitting an employee to operate a powered industrial truck (except for training purposes), the employer

shall ensure that each operator has successfully completed the training required by this paragraph. (l) (1) (ii)

• Trainees may operate a powered industrial truck only under the direct supervision of persons who have the

knowledge, training, and experience to train operators and evaluate their competence and where such operation

does not endanger the trainee or other employees. (l) (2) (i) (A) (B)

• Training shall consist of a combination of formal instruction (e.g. lecture, discussion, interactive computer

learning, videotape, written material), practical training (demonstrations performed by the trainer and practical

exercises performed by the trainee), and evaluation of the operator’s performance in the workplace. (l) (2) (B) (ii)

[Editorial Note: For required training program content, refer to (l) (3) (i) (A-M) and (l) (3) (ii) (A-I).]

• Refresher training, including an evaluation of the effectiveness of that training, shall be conducted as required by

paragraph (l) (4) (ii) to ensure that the operator has the knowledge and skills needed to operate the powered

industrial truck safely. (l) (4) (i)

• An evaluation of each powered industrial truck operator’s performance shall be conducted at least once every three

years. (l) (4) (iii)

• The employer shall certify that each operator has been trained and evaluated as required by this paragraph (l). The

certification shall include the name of the operator, the date of the training, the date of the evaluation, and the

identity of the person(s) performing the training or evaluation. (l) (6)

• The employer shall prohibit arms or legs from being placed between the uprights of the mast or outside the running

lines of the truck. (m) (4)

• Brakes shall be set and wheel blocks shall be in place to prevent movement of trucks, trailers or railroad cars while

loading or unloading. Fixed jacks may be necessary to support a semitrailer when the trailer is not coupled to a

tractor. The flooring of trucks, trailers, and railroad cars shall be checked for breaks and weakness before they are

driven onto. (m) (7)

• Only approved industrial trucks shall be used in hazardous locations. (m) (11)

• All traffic regulations shall be observed, including authorized plant speed limits. A safe distance shall be

maintained approximately three truck lengths from the truck ahead, and the truck shall be kept under control at

all times. (n) (1)

• The driver shall be required to slow down and sound the horn at cross aisles and other locations where vision is

obstructed. If the load being carried obstructs forward view, the driver shall be required to travel with the load

trailing. (n) (4)

• Under all travel conditions the truck shall be operated at a speed that permits it to be brought to a stop in a safe

manner. (n) (8)

• Stunt driving and horseplay shall not be permitted. (n) (9)

• If at any time a powered industrial truck is found to be in need of repair, defective, or in any way unsafe, the truck

shall be taken out of service until it has been restored to safe operating condition. (p) (1)

• Any power-operated industrial truck not in safe operating condition shall be removed from service. All repairs shall

be made by authorized personnel. (q) (1)

• All parts of any such industrial truck requiring replacement shall be replaced only by parts equivalent as to safety

with those used in the original design. (q) (5)

• Industrial trucks shall be examined before being placed in service, and shall not be placed in service if the

examination shows any condition adversely affecting the safety of the truck. Such examination shall be made at

least daily. Where powered industrial trucks are used on a round-the-clock basis, they shall be examined after each

shift. Defects when found shall be immediately reported and corrected. (q) (7)

Part Kit Number

1357096/001

Part Kit Number

1357096/001

Other manuals for Titan Series

This manual suits for next models

Table of contents

Other Lift-Rite Forklift manuals

Lift-Rite

Lift-Rite LCF55 Manual

Lift-Rite

Lift-Rite Titan LCM50 User manual

Lift-Rite

Lift-Rite ERGO 3000 NOMIC User manual

Lift-Rite

Lift-Rite LFTSC Manual

Lift-Rite

Lift-Rite SS45 Manual

Popular Forklift manuals by other brands

East West Engineering

East West Engineering WP instruction manual

cascade corporation

cascade corporation Sideshifting Series Operator's guide

Komatsu

Komatsu AE50 Description of Device Parameters

Taylor

Taylor X-180S Service bulletin

Manitou

Manitou MHT-X 780 T-E3 Operator's manual

Hyster

Hyster J30XNT operating manual

Cascade

Cascade E Series Service manual

Gillison's Variety Fabrication

Gillison's Variety Fabrication GVF 5000 owner's manual

jcb

jcb RTFL 926 Operator's manual

WIFO

WIFO K90 Series Manual and safety instructions

Noblelift

Noblelift PS 30RP Instruction handbook

Still

Still RCD15 Original instructions

Hyundai

Hyundai 15LC-7M operating manual

Vestil

Vestil VHPS-2000-AA Operation & service manual

EKKO

EKKO EK20R Service manual

Jungheinrich

Jungheinrich EKS 310k operating instructions

Hyster

Hyster C024 manual

Yale

Yale MSW025-F maintenance

Lift-Rite Titan Series User manual

Popular Forklift manuals by other brands
