Light Emotion BRUTE Operator's manual

WWW.LIGHTEMOTION.COM.AU
BRUTE
18 x 10Watt 4in1 RGBW LED Flat Par Light
User’s Instruction Manual
This manual contains important information about the safe installation and use of this product.
Please read this instruction manual carefully before installing or operating.
Please keep these instructions in a safe place for future reference.
www.lightemotion.com.au

2
1 SECURITY TIPS
WARNING!!! To reduce the risk of fire, electric shock, or injury
to persons, follow these important safety instructions:
 Non-professionals, do not disassemble the light nor access the
lighting accessories inside.
 Rated voltage range: AC110V-120V/60Hz or AC200V-240V / 50HZ
 The light source should be maintained at least 1M from flammable
materials.
 Keep away from liquids and avoid using in a humid environment.
 Before using the light ensure a reliable power source and connect via
the powercon cable.
 Ensure regular maintenance and inspection to provide long life and
lasting performance.
 Consecutive working hours for the fixture is not recommended to be
greater than 10 hours.
 Stop using the lights in any unusual conditions such as extreme
weather or interrupted power supply.
 Regularly check the fan opening and clean out any accumulated dust
to prevent any build up.
2 TECHNOLOGY REFERENCE
Input voltage: A C 100-240V, 50-60Hz
Power supply: 180W
Colour : RGBW
Channel: 8/4CH
Operation: DMX512, Auto,Sound,Master-Slave

3
3 Control Panel Instructions
Press button A, there will be eight different effects. The first two letters
stand for function (refer to Diagram II). The last two letters stand for DMX
address, or speed. You can modify it with B or C button. And press D button
for confirmation.
Show Function Instruction
D001
DMX address
(001-512)
DMX-512 address set,4 channels mode
A001
DMX address
(001-512)
DMX-512 address set,8 channels mode
R255
Red
(000-255)
UP, DOWN change brightness
G255
Green
(000-255)
UP, DOWN change brightness
B255
Blue
(000-255)
UP, DOWN change brightness
U255
White
(000-255)
UP, DOWN change brightness
FH99
Strobe flash
(01-99)
UP, DOWN change the speed
CL01
Different
color output
(01-08)
UP, DOWN change brightness
CC99
Color jump UP, DOWN change the speed

4
change
(01-99)
1DE99
Color gradate
(01-99)
UP, DOWN change the speed
CP99
Color pulse
change
(01-99)
UP, DOWN change the speed
SU01
Color
soundactive
(01-99)
UP,DOWN change the effects

5
4 DMX CHANNEL SHEET
8ch
Channel Function
Explanation
1channel Dimmer
R, G, B, W dimmer: from dark to bright
2channel R dimmer R dimmer: from dark to bright
3channel G dimmer G dimmer:from dark to bright
4channel B dimmer B dimmer:from dark to bright
5channel W dimmer B dimmer:from dark to bright
6channel Strobe R,G,B,W strobe: from slow to fast
7channel Function choice
0-50:DMX 8CH Control
51-100:different colors output
101-150:colors jump change
152-200:color gradate
201-250:color pulse change
251-255:Sound-active
8channel Function Speed Speed function, from slow to fast
4ch
Channel Function Explanation
1channel R Dimmer Dimmer-Dark to
bright
2channel G Dimmer Dimmer-Dark to
bright
3channel B Dimmer Dimmer-Dark to
bright
4channel W Dimmer Dimmer-Dark to
bright

6
5 SECURING EQUIPMENT
Please fasten the fixture to a clamp before hanging. The clamp can be
fastened by the hole in the middle of the bracket, then one hung tie with
a safety chain. The loading capacity of the safety chain should be 10
times the weight of the fixture itself.
6 CONNECTION OF DMX-512 AND
CONNETION WITH THE LIGHT EQUIPMENT
Please connect the XLR-XLR control cable in series with every light
from the output of DMX.
XLR connection :

7
ATTENTION: Remember to connect an XLR plug on the output signal
of the last fixture to terminate the DMX run. And make sure this XLR
plug is connected to a 120ohm resistance between terminals 2 and 3 of
the XLR plug. Terminating the DMX signal can avoid the signal flash
phenomena of DMX512 during operation.
7 Maintenance
Problems Check list Trouble Shooting
The fixture
does not
work
1. If your power setting
matches the input of the
Par.
2. If the fuse was broken.
1. Make sure the voltage is
correct.
2. Replace with the same
fuse.
LED
dimmed
If your power us same as
the input of the machine.
Make sure the voltage input.
No DMX
input
1. If the polarity is
opposite in the DMX
controller.
2. If it is in DMX mode.
3. If there are 2 Masters in
the chain.
1. Correct the DMX
polarity.
2. Change to the DMX
mode.
3. Set one piece into Slave
mode.
Par light
works
abnormally
1. Check if the light is
programmed correctly on
the control display
1. Program the Par correctly
based on the chart above

8
Note:
Based on product improvements and upgrades product specifications
may change without notice. LSW retains its right to change
specifications when the product is improved. Thank you for your
understanding.
