Light Emotion P64100RGB Operator's manual

WWW.LIGHTEMOTION.COM.AU
P64100RGB
User’s instruction manual
This manual contains important information about the safe installation and use of this product
Please read this instruction manual carefully before installing or operating
Please keep these instructions in a safe place for future reference
www.lightemotion.com.au

2
Congratulations on the purchase of your P64100RGB by Light Emotion. We are confident that you will
be satisfied with your purchase. We have prepared this manual to assist you with the operation of this
item.
CONTENTS
SECTION Page
WHAT IS INCLUDED, SAFETY INSTRUCTION 2
POWER, FUSE, INSTALLATION 3
MAINTENANCE & PERIODIS CHECKS, DMX LEAD, DMX TERMINATOR, FEATURES 4
OPERATION 5
SPECIFICATIONS 11
Please note that as part of out ongoing commitment to continuous improvement and product
development, the specifications in this manual are subject to change without notice. Whilst every care
has been taken in the preparation of this manual we reserve the right to change specifications in the
course of product improvement.
WHAT IS INCLUDED:
CAUTION: Do not use sharp objects whilst unpacking this product
• 1x P64100RGB
• 1x Warranty Card
• 1x User Manual
Please note: Some of the items above may be fitted to the product by the manufacturer.
SAFETY INSTRUCTIONS:
Please read these instructions carefully. It includes important information about the installation usage
and maintenance of this product.
• Please keep this User Manual for future consultation. If you sell the unit to another user, be sure
that they also receive this instruction booklet.
• Always make sure that you are connecting to the proper voltage and that the line voltage you are
connecting to is not higher than that stated on the rear panel of the fixture.
• This product is intended for indoor use only! To prevent risk of fire or shock, do not expose
fixture to rain or moisture.
• Make sure there are no flammable materials close to the unit while operating.
• The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surface. Be sure that no ventilation slots are blocked.
• Always disconnect from power source before servicing or replacing fuse and be sure to replace
with same fuse source.
• Secure fixture to fastening device using a safety chain.
• Maximum ambient temperature is 40˚C. Do not operate fixture at temperatures higher than this.

3
• In the event of serious operating problem, stop using the unit immediately. Never try to repair
the unit by yourself. Repairs carried out by unskilled people can lead to damage or malfunction.
Please contact the nearest authorized technical assistance center.
• Never connect the device to dimmer pack.
• Make sure power cord is never crimped or damaged.
• Never disconnect power cord by pulling or tugging on the cord.
• Never carry the fixture directly from the cord. Always use the hanging/mounting bracket.
• Avoid direct eye exposure to the light source while it is on.
POWER:
CAUTION:
This lighting effect is designed to operate at 240V. Power Consumption: 90W
FUSE:
CAUTION:
Only use the correct fuse as specified on the rear panel of the
lighting effect.
Disconnect the lighting effect from the mains before attempting to
replace the fuse
NOTE:
This lighting effect has a position for a spare fuse located in the fuse
holder toward the outside of the fixture
To replace the fuse please follow the following steps
1. Remove the fuse holder by levering the holder out with a
screwdriver
2. Remove existing fuse
3. Fit new fuse
4. Refit the fuse holder
INSTALLATION:
CAUTION: For safe mounting read the following instructions
carefully.
•Use suitable hook clamps* for hanging the lighting effect.
•Use a safety wire* with a breaking strain of more than
double the lighting effect.
•Do not look directly into the light source.
•Make sure the lighting effect has suitable ventilation as per
the instructions below.
•This lighting effect is intended for indoor use only.
•To avoid electrical shock keep away from rain and
moisture.
•Keep unit out of reach from children.

4
NOTE:
Use washers* and spring washers* when attaching your hook clamp* to the yoke.
1. For installation of the hook clamps* and safety wire*.
2. This lighting effect must be 0.5m away from any flammable materials or any walls or ceilings.
3. Do not block or inhibit the air flow from the ventilation holes.
Light Emotion have various hook clamps* and safety wires* suitable for your PAR 64LED Please
contact your local dealer for more information
*Not included.
MAINTENANCE & PERIODIC CHECKS:
CAUTION:
Some maintenance and checks may require the product to be opened and should only be done by
qualified persons. Warranty may be void if damage has been caused by improper maintenance.
DMX LEAD:
The DMX lead is used to link up multiple units.
DMX TERMINATOR:
A DMX terminator helps to reduce ‘noise’ on the DMX chain, and makes the light respond to control
more accurately. It should be plugged in to the last fixture in any chain.
FEATURES:
Manual dimmer color mode
Sound active mode
Auto-run program mode
Static color select mode
Master /Slave mode
DMX mode
DMX512
PIN
FUNCTION
1 GND
2 DATA
3 DATA +

5
OPERATION:
There are six operation modes which are selected by ‘MODE’ button. The dot that locates at the
fourth LED display letter will flick when you operate it, and the dot will automatically turn off after
60 seconds if you do not select anything. The LED display shows the current operation mode.
When LED display switches off, press the ‘MODE’ button to switch back on again.
MODE
manual
SET UP manual
UP/DOWN
manual
Instruction
Address ~ Sets the DMX starting address
1 channel mode
2 channels mode
3 channels mode
3A channels mode
4 channels mode
5 channels mode
6 channels mode
DMX
Channel mode
7 channels mode
Master/Slave Slave mode Set the unit into slave mode
Red dimmer ~ Adjust the intensity of the red color
Green dimmer ~ Adjust the intensity of the green color
Blue dimmer ~ Adjust the intensity of the blue color
Dimmer
Strobe ~ Adjust the flash speed, is flash off,
is the slowest, is the fastest
Program ~ Select the built-in sound mode
Sound
Active
Sensitivity
select
~ Adjust the sensitivity of the sound-
active, is the lowest level, is the
highest level
Dreaming
mode
~ Select the built-in dreaming mode
Jumping
mode
~ Select the built-in jumping mode
Dreaming &
Jumping mode Set the light in auto dreaming & jumping mode, the dreaming mode and jumping mode
will run in a continuous cycle
Auto Run
Speed set ~ Adjust the speed of the dreaming/jumping
mode
Color select ~ Select the eight static colorsStatic Color
Strobe ~ Adjust the flash speed, is flash off,
is the slowest, is the fastest
LED display always stays onDisplay
on/off LED display turns off automatically after 60
seconds if there is no operation.
LED display normalDisplay
normal/inverse LED display inversion
Other
Function
Initialization
mode Initialize the unit at the extra factory setting

6
1. Manual color mode
1) Manual color select
Set up color: Press "MODE" button, select the manual color select mode. Use "UP" or "DOWN"
button to set the dimming rate from 0 to 255 for Red, Green and Blue. Press "SET UP" to confirm
your setting.
Set up strobe speed: Press "SET UP" to choose the flash speed select mode. At this time, the LED
display displays" ~ ". Press "UP" or "DOWN" button to select the strobe speed 00-
15, 00 is flash off, 01 is the slowest flash speed, 15 is the fastest strobe speed.
2. Sound active mode
Press "MODE" button, select the sound active mode. Press the "SET UP" button to change sound
active setting.
1) Set sound active program
Press "SET UP" button until LED display displays" ~ ", then press "UP" or "DOWN"
to select the sound active program, you have 8 choices.
2) Set sound sensitivity
Press "SET UP" button until LED display displays" ~ ", then press "UP" or
"DOWN" to select the mic sensitivity 1-8. 1 is off sound-active, 2 is the lowest sensitivity, 8 is the
highest sensitivity.
3. Auto-run program mode
Press "MODE" button, select the auto-run program mode. Use "SET UP" button to choose three
different groups of auto-run program.
1) Set Color dreaming program
Press "SET UP" button until LED display displays " ~ ", then press "UP" or
"DOWN" button to choose color dreaming program. There are 8 colors dreaming programs for you
to select.
2) Set Color jumping program
Press "SET UP" button until LED display displays " ~ ", then press "UP" or
"DOWN" button to select color jumping program. There are 8 colors jumping programs for you to
select.
3) Set Auto dreaming & jumping program
Press "SET UP" button until LED display displays " " to go to dreaming mode and jumping
mode.
4) Set auto-run speed
Press "SET UP" button until LED display displays" ~ ". Press "UP" or "DOWN"
button to select auto-run color change speed from 01 to 16, 01 is the slowest speed,16 is the fastest
speed.
4. Static color mode
Press "MODE" button, select the static color mode.
1) Set static color
Press "SET UP" button until LED display displays" ~ ", then press "UP" or "DOWN"
to select your static color. There are 7 colors for you to select.
2) Strobe speed select
Press "SET UP" button until LED display displays" ~ ", then press "UP" or
"DOWN" button to select the static color strobe speed 00-15, 00 is flash off, 01 is the slowest flash
speed, 15 is the fastest flash speed.

7
5. Other function
1) Display on / off
Press “SET UP” button to find " "(LED display always on) or " "(LED display turns
off automatically after 60 seconds if there is no operation), press UP or DOWN to select display on
or off.
2) Display normal / inversion
Press “SET UP” button, select display normal/inversion. Press UP or DOWN to select LED display
normal or reverse 180 degree. " " means display normal and " "means display had
been reversed.
3) Initialization select mode
Press “SET UP” button until LED control panel displays" " and flicker. Then press UP
button and DOWN button at the same time to initialize to original factory setting (1
st
color jumping
mode, control panel should display" ".)
6. Master/slave
Press "MODE" button, select Master/salve mode. When LED control panel displays " ", it is
in slave mode.
7. DMX mode
1) Set DMX address
The control Board allows you to assign the DMX address which is defined as the first channel of
the unit .Press “MODE” button until LED control panel displays “ ~ ”, press UP or
DOWN to set the DMX address. The LED control panel should flick when there is no controller
signal.
2) DMX setting
Press “SET UP” button until it displays“ ~ ”, then press UP or DOWN to set 8 DMX
channel mode.
• : 1 channel mode
CH1
000-031 Off
032-063 Red
064-095 Green
096-127 Blue
128-159 Yellow
160-191 Purple
192-223 Cyan
224-255 White
•: 2 channels mode
Channel Value
Function
000-031 Off
032-063 Red
064-095 Green
096-127 Blue
128-159 Yellow
160-191 Purple
192-223 Cyan
1
224-255 White
2 0 - 255 MASTER DIMMER 0% - 100%

8
• : 3 channels mode
Channel Value Function
000-031 Off
032-063 Red
064-095 Green
096-127 Blue
128-159 Yellow
160-191 Purple
192-223 Cyan
1
224-255 White
2 0 - 255 MASTER DIMMER 0% - 100%
0-15 STROBING OFF3
16-255 STROBING SLOW - FAST
• : 3A channels mode
Channel Value Function
1 0-255 RED 0% - 100%
2 0-255 GREEN 0% - 100%
3 0-255 BLUE 0% - 100%
•: 4 channels mode
Channel Value Function
1 0-255 RED 0% - 100%
2 0-255 GREEN 0% - 100%
3 0-255 BLUE 0% - 100%
4 0-255 MASTER DIMMER 0% - 100%

9
• : 5 channels mode
Channel Value Function
4 000-255 MASTER DIMMER 0% - 100%
Channel Value Function
1 0-255 RED 0% - 100%
2 0-255 GREEN 0% - 100%
000-031
3 0-255 BLUE 0% - 100%
032-063 Red
064-095 Green
096-127 Blue
128-159 Yellow
160-191 Purple
192-223 Cyan
5
224-255
Channel 1, 2 & 3 N/L
White
•: 6 channels mode
Channel Value Function
4 000-255 MASTER DIMMER 0% - 100%
0-15 STROBING OFF
5 16-255 STROBING SLOW - FAST
Channel Value Function
1 0-255 RED 0% - 100%
2 0-255 GREEN 0% - 100%
000-031
3 0-255 BLUE 0% - 100%
032-063 Red
064-095 Green
096-127 Blue
128-159 Yellow
160-191 Purple
192-223 Cyan
6
224-255
Channel 1, 2 & 3 N/L
White

10
• : 7 channels mode
FUNCTION
CH1 CH2 CH3 CH4 CH5 CH6 CH7
Red
0-255
(dim→
bright)
Green
0-255
(dim
→
bright)
Blue
0-255
(dim→
bright)
Dimmer
mode
(0-51)
N/L
000-031 Off
032-063 Red
064-095 Green
096-127 Blue
128-159 Yellow
160-191 Purple
192-223 Cyan
Strobe Off
(0-16)
Strobe
slowest to
fastest
(16-255)
Static
color
mode
(52-102)
224-255 White
000-031
Jumping 1
032-063
Jumping 2
064-095
Jumping 3
096-127
Jumping 4
128-159
Jumping 5
160-191
Jumping 6
192-223
Jumping 7
Color
jumping
mode
(103-153)
224-255 Jumping 8
000-031
Dreaming 1
032-063
Dreaming 2
064-095
Dreaming 3
096-127
Dreaming 4
128-159
Dreaming 5
160-191
Dreaming 6
192-223
Dreaming 7
Speed 0-255
(slow→fast)
Color
dreaming
mode
(154-204)
224-255
Dreaming 8
000-031
Sound 1
032-063
Sound 2
064-095
Sound 3
N/L
(0-31)
096-127
Sound 4
128-159
Sound 5
160-191
Sound 6
192-223
Sound 7
N/L
Master
Dimming
0-255
(dim→
bright)
Sensitivity
(32-255
insensitive→
sensitive)
Sound
active
mode
(205-255)
224-255
Sound 8

11
SPECIFICATIONS:
•Power input: AC 90V-240V/50HZ-60HZ
•Wattage: 90W
•LEDs: 1PC 100W (RGB 3 in 1) COB LED
•Beam angle of LEDs: 85 degree, 40 degree as accessory
•3-pin female XLR socket and 3-pin male XLR socket
•DMX mode: 8
•Built-in microphone
•Four button LED digit display
•Power cord daisy chain:7 fixtures max
•Weight: 3.2 kg
•Size: 330 x 245 x 192mm
